561969 - Switch Intellinet - Free user manual and instructions

Product Type	Unmanaged network switch
Model	Intellinet 561969
Number of ports	8 Ethernet ports 10/100/1000 Mbps
Switching speed	Up to 16 Gbit/s
Power supply	External power adapter 5 V DC, 1 A
Power consumption	5 W max
Dimensions (L x D x H)	160 x 85 x 28 mm
Weight	250 g
Network standards	IEEE 802.3, 802.3u, 802.3ab, 802.3x
Cable type	UTP Ethernet cable category 5e or higher
Management protocols	None (unmanaged)
Features	IEEE 802.3x flow control, automatic MDI/MDIX detection, store-and-forward switching
Operating temperature	0°C to 40°C
Operating humidity	10% to 90% non-condensing
Maintenance and cleaning	Disconnect before cleaning, use a dry soft cloth
Safety	Use only the supplied adapter, do not expose to moisture
Spare parts and repairability	Not user-serviceable, contact technical support
General information	2-year warranty, compatible with all standard network devices

Frequently Asked Questions - 561969 Intellinet

How to install the Intellinet 561969 switch?

Plug in the power adapter, connect your devices with Ethernet cables, and the switch works automatically without configuration.

What to do if the LED indicators do not light up?

Check the power supply and the power cable. If still off, test with another electrical outlet.

How to recognize a defective port?

If a connected device does not receive a signal, try another port. If the problem persists, the cable or device may be at fault.

Can I use cables longer than 100 meters?

No, the maximum recommended distance between the switch and the device is 100 meters to comply with Ethernet standards.

Does the switch support PoE?

No, the 561969 model is not PoE-compatible. Use a PoE injector if needed.

How to reset the switch?

This unmanaged switch does not require a reset. A restart (unplug/plug back in) is sufficient in case of malfunction.

What is the maximum speed of each port?

Each port supports up to 1000 Mbps (1 Gbps) in full-duplex.

Can I connect a switch to another switch?

Yes, you can cascade multiple unmanaged switches using a standard port on each.

What to do if the Internet connection is slow?

Check that all cables are in good condition and that devices are configured at 1000 Mbps. Avoid collisions by limiting the number of devices.

Where to find the full manual?

The manual is available for free download in PDF format on the website notice-facile.com.

USER MANUAL 561969 Intellinet

Console Reference Guide

Models 560559_v3, 561167_v3, 561198_v3, 561341_v3, 561426_v3, 508834

Two Intel Ethernet switches with network ports and I/O ports, displayed against a blue grid background (no text or symbols on the devices themselves)

INTELLINET®

NETWORK SOLUTIONS

intellinet-network.com

Contents

1. Access control list configuration command ....39

1.1.access-list....39

1.2.access-list ip-acl....39

1.3. no access-list....41

1.4.access-list mac-acl 41

1.5.access-list hybrid-acl....42

1.6. show access-list config ....45

1.7. show access-list config statistic....45

1.8. show access-list runtime statistic 45

1.9. show access-list runtime ....45

1.10. time-range ....46

1.11. absolute 46

1.12. periodic....47

1.13. no time-range ....47

1.14. show time-range....48

1.15.access-group....48

1.16. no access-group ....49

2. QOS Configuration Command ....50

2.1. rate-limit....50

2.2. two-rate-policer....51

2.3. traffic-redirect ....51

2.4. traffic-copy-to-cpu....52

2.5. traffic-priority ....53

2.6. traffic-statistic....54

2.7. clear traffic-statistic....54

2.8. mirrored-to....55

2.9. traffic-rewrite-vlan ....56

2.10. traffic-insert-vlan....56

2.11. show two-rate-policer ....57

2.12. show qos-info statistic....57
2.13. show qos-info traffic-copy-to-cpu....57
2.14. show qos-info all....58
2.15. show qos-info mirrored-to ....58
2.16. show qos-info traffic-priority ....58
2.17. show qos-info traffic-redirect....58
2.18. show qos-info traffic-statistic....59
2.19. show qos-info traffic-insert-vlan ....59

3. COS Configuration Command....59

3.1. queue-scheduler....59
3.2. queue-scheduler mode ....59
3.3. no queue-scheduler mode ....60
3.4. queue-scheduler cos-map....60
3.5. queue-scheduler dscp-map....61
3.6. queue-scheduler dscp-map....61
3.7. show queue-scheduler ....61
3.8. show queue-scheduler cos-map....62
3.9. show queue-scheduler dscp-map 62

4. ARP Learning configuration command....63

4.1. arp 63
4.2. arp vlan ......63
4.3. arp aging-time....63
4.4. arp peer ....64
4.5. arp bind dynamic....64
4.6. no arp....64
4.7. show arp....65
4.8. arp overwrite....65
4.9. gratuitous-arp....65
4.10. arp reply-repeat....66
4.11. arp reply-repeat [times]....66

4.12. show arp aging-time....66
4.13. show arp overwrite ....66
4.14. show arp peer....67
4.15. show arp reply-repeat ....67

1. ARP Proxy configuration command ....67

5.1. arp-proxy ....67
5.2. arp-proxy broadcast....67
5.3. show arp-proxy....68

1. IPv6ND Configuration command ....68

6.1. ipv6 neighbor ....68
6.2. ipv6 neighbor ....68
6.3. ipv6 neighbors max-learning-num....69
6.4. show ipv6 neighbors max-learning-num....69

6.5. ipv6 nd reachable-time....69

6.6. ipv6 nd dad attemps ....70

6.7. ipv6 nd ns retrans-time....70

6.8. ipv6 nd ra interval....70

6.9. ipv6 nd ra halt....71

6.10. ipv6 nd ra hop-limit ....71

6.11. ipv6 nd ra prefix....71

6.12. ipv6 nd ra router-lifetime....72

6.13. show ipv6 nd dad attemps....72

6.14. show ipv6 nd reachable-time ....72

6.15. show ipv6 nd ns retrans-time....72

6.16. show ipv6 nd ra halt....73

6.17. show ipv6 nd ra hop-limit....73

6.18. show ipv6 nd ra interval ....73

6.19. show ipv6 nd ra prefix ....73

6.20. show ipv6 nd ra router-lifetime....73

1. Anti ARP spoofing configuration command ....74

7.1. arp anti-spoofing ....74
7.2. arp anti-spoofing action ....74
7.3. arp anti-spoofing bind ....74
7.4. arp anti-spoofing gateway-disguiser ....75
7.5. arp anti-spoofing source-mac-check ....75
7.6. arp anti-attack trust....75
7.7. show arp anti-spoofing....76
7.8. show arp anti-spoofing bind....76
7.9. show arp anti-attack....76

8. Anti ARP flood configuration command....76

8.1. arp anti-flood....76
8.2. arp anti-flood action....77
8.3. arp anti-flood rate-limit....77
8.4. arp anti-flood recover-time....77
8.5. arp anti-flood recover....78
8.6. arp anti-flood bind blackhole ....78
8.7. show arp anti-flood ....79
8.8. show arp anti-flood rate-limit ....79

9. Anti Dos attack configuration command....79

9.1. anti-dos ip ttl 79
9.2. anti-dos ip fragment 79
9.3. anti-dos packets class....80
9.4. show anti-dos 81

10. Shutdown-Control Configuration Command 82

10.1. shutdown-control....82
10.2. shutdown-control-recover mode 82
10.3. shutdown-control-recover automatic-open-time....83
10.4. show shutdown-control interface....83

11. BPDU-Car Configuration command 83

11.1. port-car320....83

11.2. port-car-rate ....84
11.3. show port-car ....84

1. CPU-Car Configuration Command....84

12.1. cpu-car....84
12.2. show cpu-car ....85
12.3. show cpu-statistics ....85
12.4. clear cpu-statistics ....85
12.5. show cpu-classification....86
12.6. clear cpu-classification ....86
12.7. show cpu-utilization 86

1. Discard-BPDU Configuration Command....87

13.1. discard-bpdu....87
13.2. show discard-bpdu ....87

1. Anti DHCP configuration command ....87

14.1. dhcp anti-attack....87
14.2. dhcp anti-attack action....87
14.3. dhcp anti-attack bind blackhole 88
14.4. dhcp anti-attack threshold 88
14.5. dhcp anti-attack recover-time....89
14.6. dhcp anti-attack recover 89
14.7. dhcp anti-attack trust 89
14.8. show dhcp anti-attack 90
14.9. show dhcp anti-attack interface....90

1. Two level password authentication configuration command....90

15.1. enable password 0....90
15.2. enable password 7....91
15.3. enable password level....91

1. DHCP-Snooping Configuration command ....92

16.1. dhcp-snooping 92
16.2. dhcp-snooping trust 92

16.3. dhcp-snooping fast-remove ....92
16.4. dhcp-snooping max-learn-num 92
16.5. show dhcp-snooping interface 93
16.6. show dhcp-snooping vlan....93
16.7. show dhcp-snooping clients....93

1. DHCP-Server Configuration Command....94

17.1. dhcp-server....94

17.2. dhcp-server ip-pool 94

17.3. gateway 95

17.4. section 95

17.5. forbidden-ip....95

17.6. domain-name ....96

17.7. lease....96

17.8. option 96

17.9. unbind-client ....97

17.10. router....97

17.11. dns-list 98

17.12. nbns-list 98

17.13. dhcp-client bind....98

17.14. dhcp-client unbind-assign 99

17.15. dhcp-server traps 99

17.16. show dhcp-server 99

17.17. show dhcp-server interface....100

17.18. show dhcp-server ip-pool....100

17.19. show dhcp-server clients....100

17.20. show dhcp-client bind .... 101

1. DHCP-Relay Configuration Command ....101

18.1. dhcp-relay....101

18.2. dhcp-relay hide server-ip....102

18.3. dhcp-relay max-hops....102

18.4. dhcp-relay source-ip....102
18.5. show dhcp-relay ....103

1. DHCP Option82 Configuration Command ....103

19.1. dhcp-option82....103
19.2. dhcp-option82 device-id ....103
19.3. dhcp-option82 format....104
19.4. dhcp-option82 format verbose 104
19.5. dhcp-option82 information format....104
19.6. dhcp-option82 strategy 104
19.7. dhcp-option82 circuit-id user-defined 105
19.8. dhcp-option82 remote-id user-defined 105
19.9. show dhcp-option82....106

1. DHCPv6-Snooping Configuration Command 106

20.1. dhcpv6-snooping 106
20.2. dhcpv6-snooping trust 107
20.3. dhcpv6-snooping port-down-action fast-remove 107
20.4. dhcpv6-snooping max-clients....107
20.5. show dhcpv6-snooping clients....108
20.6. show dhcpv6-snooping interface....108
20.7. show dhcpv6-snooping vlan....108
20.8. clear dhcpv6-snooping....108

1. DHCPv6 Option18 configuration command....110

21.1. dhcpv6-snooping information option 18 ....110
21.2. dhcpv6-snooping information interface-id 110
21.3. show dhcpv6-snooping information 111

1. DHCPv6 Option37 Configuration command....111

22.1. dhcpv6-snooping information option 37 ....111
22.2. dhcpv6-snooping information remote-id....111
22.3. show dhcpv6-snooping information 112

1. File download configuration command ....112

23.1. load application xmodem....112

23.2. load application tftp 112

23.3. load application ftp....113

23.4. load whole-bootrom xmodem ....113

23.5. load whole-bootrom tftp....114

23.6. load whole-bootrom ftp 114

23.7. load configuration xmodem 115

23.8. load configuration tftp .....115

23.9. load configuration ftp....115

23.10. load keyfile private tftp ....116

23.11. load keyfile private ftp....116

23.12. load keyfile public tftp....117

23.13. load keyfile public ftp ....117

1. file upload configuration command ....118

24.1. upload application ftp ....118

24.2. upload application tftp ....118

24.3. upload logging ftp....119

24.4. upload logging tftp ....119

24.5. copy running-config startup-config....120

24.6. upload configuration ftp....120

24.7. upload configuration tftp ....120

24.8. upload automatically configuration ftp....121

24.9. upload automatically configuration tftp ....121

24.10. upload keyfile private tftp ....122

24.11. upload keyfile private ftp ....122

24.12. upload keyfile public tftp....123

24.13. upload keyfile public ftp....123

1. configuration management command....124

25.1. show running-config....124

25.2. show startup-config....124

25.3. copy startup-config running-config....125
25.4. clear startup-config ....125

1. Active and standby file system configuration command ....126

26.1. load secondary application tftp....126
26.2. load secondary application ftp....126
26.3. startup secondary application....127

1. Port mirror configuration command....127

27.1. mirror source ....127
27.2. mirror monitor ethernet ....128
27.3. no mirror....128
27.4. show mirror 128

1. Remote mirror configuration command ....129

28.1. mirror source .... 129
28.2. mirror monitor ethernet ....129
28.3. remote_mirror rspan local vlan ....129
28.4. no remote_mirror rspan local....130
28.5. remote_mirror rspan middle vlan....130
28.6. no remote_mirror rspan midd le vlan....130
28.7. remote_mirror rspan target vlan ....131
28.8. no remote_mirror rspan target vlan....131
28.9. remote_mirror rspan parse vlan 131
28.10. no remote_mirror rspan parse vlan....132
28.11. show remote_mirror....132

1. Configure flow mirror ....132

29.1. mirrored-to ....132
29.2. no mirrored-to....133
29.3. show qos-info mirrored-to....133

1. RMON configuration command....133

30.1.rmon statistics 133
30.2. no rmon statistics....134

30.3.rmon history....134

30.4. no rmon history ....134

30.5. show rmon statistics interface....135

30.6. show rmon history interface .....135

30.7.rmon event....135

30.8. no rmon event ....136

30.9. show rmon event....136

30.10. rmon alarm....136

30.11. no rmon alarm....137

30.12. show rmon alarm....137

1. Bandwidth-Control configuration command ....138

31.1. bandwidth .... 138

31.2. show bandwidth....138

1. MAC-address-management-configuration command ....139

32.1.mac-address-table age-time....139

32.2.mac-address-table 139

32.3.mac-address-table blackhole 140

32.4.mac-address-table learning....140

32.5.mac-address-table max-mac-count....141

32.6. no mac-address-table max-mac-count.....141

32.7. show mac-address max-mac-count.....141

32.8. show mac-address-table age-time 142

32.9. show mac-address-table .....142

32.10. show mac-address learning....143

32.11. show mac-address cpu 143

1. DLF-Control configuration command....143

33.1. unknown-discard unicast ....143

33.2. unknown-discard multicast vlan....144

33.3. unknown-discard multicast ....144

33.4. show unknown-discard ....144

1. Local-Switch configuration command....145

34.1. local-switch....145
34.2. show local-switch ....145

1. SLF-Control configuration command....146

35.1. unknown-discard src-mac ....146
35.2. show unknown-discard src-mac....146

1. Flow-Control configuration command 147

36.1. flow-control....147
36.2. show flow-control interface .....147

1. Error packet statistics....147

37.1. show statistics interface ethernet....147

1. IPv4 IF-Vlan Interface configuration command....148

38.1. interface vlan-interface....148
38.2. ip address ipv4 address....148
38.3. Ip address ....149
38.4. ip addres range .....149
38.5. ip icmp host-unreachable send....150
38.6. ip icmp mask-request receive ....150
38.7.description....150
38.8. show ip interface....151

1. IPv4 SuperVlanInterface configuration command ....151

39.1. interface supervlan-interface....151
39.2.subvlan....151
39.3. ip address....152
39.4. Ip address ....152
39.5. ip addres range .....153
39.6. ip icmp host-unreachable send....153
39.7. ip icmp mask-request receive 153
39.8. description....154
39.9. show ip interface....154

40. IPv6 IF-VlanInterface configuration command ....154

40.1. ipv6 address....154

40.2. ipv6 neighbors max-learning-num....155

40.3. ipv6 nd ns retrans-timer....155

40.4. ipv6 nd dad attempts value ....156

40.5. ipv6 nd reachable-time....156

40.6. ipv6 pathmtu value .....156

40.7. ipv6 nd ra halt....157

40.8. ipv6 nd ra hop-limit....157

40.9. ipv6 nd ra interval .....157

40.10. ipv6 nd ra prefix ....157

40.11. ipv6 nd ra router-lifetime....158

40.12. show ipv6 interface....158

40.13. show ipv6 neighbors .....158

40.14. show ipv6 nd dad attemps ....159

40.15. show ipv6 nd ns retrans-time....159

40.16. show ipv6 nd reachable-time ....159

40.17. show ipv6 route....159

41. IPv6 SuperVlanInterface configuration command ....160

41.1. ipv6 address ....160

41.2. ipv6 neighbors max-learning-num....160

41.3. ipv6 nd ns retrans-timer 161

41.4. ipv6 nd dad attempts value ....161

41.5. ipv6 nd reachable-time....161

41.6. ipv6 pathmtu value ..... 162

41.7. ipv6 nd ra halt....162

41.8. ipv6 nd ra hop-limit ....162

41.9. ipv6 nd ra interval 162

41.10. ipv6 nd ra prefix ....163

41.11. ipv6 nd ra router-lifetime....163

41.12. show ipv6 interface....164
41.13. show ipv6 neighbors .....164
41.14. show ipv6 nd dad attemps ....164
41.15. show ipv6 nd ns retrans-time....165
41.16. show ipv6 nd reachable-time....165
41.17. show ipv6 route....165

1. GMRP Configuration command....165

42.1.gmrp 165
42.2. garp permit multicast mac-address....166
42.3. show gmrp....166
42.4. show gmrp interface .....166
42.5. show garp permit multicast....167
42.6. show multicast....167

1. GMP-Snooping Configuration command ....167

43.1. igmp-snooping....167
43.2. igmp-snooping host-aging-time ....168
43.3. no igmp-snooping host-aging-time ....168
43.4. igmp-snooping max-response-time....168
43.5. no igmp-snooping max-response-time .....169
43.6. igmp-snooping fast-leave .....169
43.7. no igmp-snooping fast-leave .....169
43.8. igmp-snooping group-limit....169
43.9. no igmp-snooping group-limit....170
43.10. igmp-snooping overflow-replace ....170
43.11. igmp-snooping enable-vlan ....170
43.12. igmp-snooping [ permit | deny ]....171
43.13. igmp-snooping querier ....171
43.14. igmp-snooping robust-count....171
43.15. igmp-snooping last-member-query-interval....172
43.16. igmp-snooping version....172

43.17. igmp-snooping querier-vlan 172
43.18. igmp-snooping query-interval....173
43.19. igmp-snooping query-source....173
43.20. igmp-snooping router-port forward....173
43.21. igmp-snooping router-aging-time ....174
43.22. igmp-snooping router-port vlan 174
43.23. igmp-snooping multicast vlan ....174
43.24. igmp-snooping proxy....175
43.25. igmp-snooping proxy-source....175
43.26. igmp-snooping query-proxy ....175
43.27. igmp-snooping source-learning....176
43.28. igmp-snooping static-group .....176
43.29. igmp-snooping static-group proxy ....177
43.30. igmp-snooping drop .....177
43.31. igmp-snooping preview .... 178
43.32. igmp-snooping preview group-ip ....178
43.33. igmp-snooping preview times....178
43.34. igmp-snooping profile .....179
43.35. profile limit ....179
43.36.ip range....179
43.37.mac range....180
43.38. description....180
43.39. igmp-snooping profile refer ....181
43.40. show igmp-snooping ....181
43.41. show igmp-snooping router-dynamic 182
43.42. show igmp-snooping router-static....182
43.43. show igmp-snooping preview ....182
43.44. show igmp-snooping preview status....183
43.45. show igmp-snooping profile....183
43.46. show multicast ....183

44. Static multicast configuration command ....184

44.1. multicast....184
44.2. multicast proxy....184
44.3. multicast proxy-interval ....185
44.4. show multicast....185

45. MLD-Snooping Configuration command....186

45.1. mld-snooping....186
45.2. mld-snooping host-aging-time time 186
45.3. mld-snooping max-response-time .....186

45.4. mld-snooping fast-leave .....187

45.5. mld-snooping group-limit....187

45.6. mld-snooping [permit | deny]....188

45.7. mld-snooping....188

45.8. mld-snooping querier ....188

45.9. mld-snooping query-interval....189

45.10. mld-snooping query-max-respond....189

45.11. mld-snooping router-port forward....190

45.12. mld-snooping router-port-age 190

45.13. mld-snooping router-port vlan....190

45.14. mld-snooping multicast vlan ....191

45.15. show mld-snooping ....191

45.16. show mld-snooping router-dynamic 192

45.17. show mld-snooping router-static....192

45.18. show multicast mld-snooping ....192

46. I2protocol-tunnel Configuration command ....194

46.1. l2protocol-tunnel....194
46.2. l2protocol-tunnel user-protocol....194
46.3. I2protocol-tunnel drop-threshold .....195
46.4. show l2protocol-tunne interface....196
46.5. show l2protocol-tunnel drop-threshold....196

46.6. show l2protocol-tunnel tunnel-mac....196

1. LLDP Configuration Commands....197

47.1. lldp....197

47.2. lldp rx | tx | rxtx ....197

47.3. lldp hello-time ....198

47.4. lldp hold-times....198

47.5. lldp trap ....198

47.6. lldp management-address....199

47.7. show lldp 199

1. UDLD Configuration Command ....200

48.1. udd....200

48.2. uld error-down .... 200

48.3. udd message-interval .....201

48.4. udld reset....201

48.5. udld port shutdown....202

48.6. udd unidirectional-shutdown ..... 202

48.7. udd work-mode ....203

48.8. show udld 203

1. Managing IP restricted configuration commands....204

49.1. login-access-list ....204

49.2. login-access-list privilege-limit ....204

49.3. show login-access-list 205

1. Managing timeout configuration command ....205

50.1. timeout....205

1. SSH configuration command....206

51.1. ssh....206

51.2. ssh limit....206

51.3. ssh port....206

51.4. stop vty 207

51.5. crypto key zeroize rsa....207

51.6. crypto key refresh....207
51.7. crypto key generate rsa....208
51.8. load keyfile ....208
51.9. upload keyfile ....208
51.10. show keyfile....209

1. Telnet-Client Configuration command 210

52.1. telnet 210

1. Telnet-Server/Telnetv6-ServerConfiguration Command ....211

53.1. telnet enable ....211
53.2. telnet disable....211
53.3. telnet limit 211
53.4. telnet port 212
53.5. stop telnet client ....212
53.6. show telnet client....212
53.7. show telnet....213

1. Web Management configuration command....213

54.1.http enable 213
54.2. http disable....213
54.3.http timeout 214
54.4. show http....214

1. SNMP Management configuration command....215

55.1. snmp-server enable....215
55.2. snmp-server disable 215
55.3. snmp-server contact....215
55.4. snmp-server location....216
55.5. snmp-server name....216
55.6. snmp-server max-packet-length .....216
55.7. snmp-server trap-source ....217
55.8. snmp-server encrypt ....217
55.9. snmp-server view ......218

55.10. snmp-server community encrypt ....218

55.11. snmp-server community md5 encrypt-communityname ......219

55.12. snmp-server community .....219

55.13. snmp-server group ....220

55.14. snmp-server user....220

55.15. snmp-server enable 222

55.16. snmp-server host....222

55.17. show snmp-server community....223

55.18. show snmp-server contact 223

55.19. show snmp-server engineid ....224

55.20. show snmp-server group....224

55.21. show snmp-server host 224

55.22. show snmp-server location 225

55.23. show snmp-server max-packet-length....225

55.24. show snmp-server mib 225

55.25. show snmp-server name ......225

55.26. show snmp-server notify....226

55.27. show snmp-server user 226

55.28. show snmp-server view....226

1. User management configuration command 227

56.1.username <> 227

56.2.username change-password 227

56.3.username failmax....227

56.4.username online-max....228

56.5.username silent-time 228

56.6. stop <> 229

56.7. show users....229

56.8. show username silent....229

56.9. show username ....230

1. Auto-Reboot Configuration command 230

57.1. auto-reboot 230

1. System debug configuration command ....231

58.1. ping....231

58.2. ping ipv6 ....231

58.3. tracert....232

58.4. tracert ipv6 232

1. System information configuration and display command 233

59.1. show version....233

59.2. show system....233

59.3. show memory....233

59.4. show clock 233

59.5. hostname....234

1. Bootrom Configuration command....234

60.1. Ctrl-B....234

1. Telnetv6-Client Configuration command....235

61.1. telnet6 .....235

1. EFM Configuration command ....235

62.1.efm 235

62.2. efm mode....236

62.3.efm pdu-timeout 236

62.4.efm link-timeout....236

62.5. efm remote-response-timeout....237

62.6.efm remote-failure....237

62.7. efm link-monitor....237

62.8. efm link-monitor errored-symbol-period window 238

62.9. efm link-monitor errored-symbol-period threshold 238

62.10. efm link-monitor errored-frame window....239

62.11. efm link-monitor errored-frame threshold .....239

62.12. efm link-monitor errored-frame-period window 240

62.13. efm link-monitor errored-frame-period threshold 240

62.14. efm link-monitor errored-frame-seconds window .....241

62.15. efm link-monitor errored-frame-seconds threshold .....241

62.16. efm remote-loopback .....241

62.17. efm remote-loopback ignore....242

62.18. efm remote-loopback process 242

62.19. efm remote-loopback start|stop....242

62.20. efm variable-retrieval....243

62.21. show efm port....243

62.22. show efm remote-mib 243

62.23. show efm status interface....244

62.24. show efm summary 244

62.25. show efm discovery interface 244

62.26. show efm statistics interface....245

62.27. clear efm statistics interface....245

1. CFM Configuration command ....245

63.1. cfm md....245

63.2. no cfm md 246

63.3. cfm md format none level 246

63.4. cfm md format 246

63.5. cfm ma....247

63.6. no cfm ma 247

63.7. cfm ma format ....248

63.8. cfm mep direction....248

63.9. cfm mep state .....249

63.10. cfm mep priority....249

63.11. cfm rmep 249

63.12. cfm mip....250

63.13. cfm cc interval 250

63.14. cfm mep 250

63.15. cfm loopback mep .....251

63.16. cfm linktrace mep....251

63.17. cfm eth-slm mep 252

63.18. cfm eth-2dm mep....252

63.19. clear cfm cc 253

63.20. clear cfm cc database 253

63.21. show cfm md 254

63.22. show cfm ma 254

63.23. show cfm mp local 254

63.24. show cfm mp remote....254

63.25. show cfm cc....255

63.26. show cfm cc database .....255

63.27. show cfm errors ..... 255

1. POE Power supply configuration command....256

64.1. poe....256

64.2. poe max-power ....256

64.3. poe max-power ....256

64.4. poe standard 257

64.5. poe priority 257

64.6. poe status poll ....257

64.7. poe traps....258

64.8. poe force power on 258

64.9. show poe 258

64.10. show poe auto-check ....259

64.11. show poe power-on time-range....259

1. Statistics configuration command....260

65.1. show statistics interface ethernet....260

65.2. clear interface....260

65.3. clear cpu-statistics....261

65.4. clear cpu-classification ....261

65.5. port-rate-statistics interval....261

65.6. show statistics interface brief ....262

65.7. show statistics dynamic....262

65.8. show utilization 262

65.9. show interface 263

65.10. show cpu-utilization 263

65.11. show cpu-statistic....263

65.12. show cpu-classification....264

65.13. show statistics eth-trunk 264

1. Port loopback detection configuration command ....265

66.1. loopback 265

66.2. loopback-detection action....265

66.3. loopback-detection interface .....266

66.4. loopback-detection interval-time....266

66.5. loopback-detection recover-time....266

66.6. loopback-detection address-type....267

66.7. oopback-detection log....267

66.8. loopback-detection mode .....267

66.9. loopback-detection trap 268

66.10. loopback-detection vlan....268

66.11. show loopback-detection....269

1. VCT detection configuration command ......269

67.1. vct run....269

1. Port configuration commands....269

68.1. interface ethernet ....269

68.2. duplex....270

68.3.speed 270

68.4. priority....271

68.5. shutdown....271

68.6.description....271

68.7. switchport....272

68.8. ingress filtering 272

68.9. switchport pvid....273

68.10. ingress acceptable-frame ....273

68.11. switchport trunk allowed vlan....273

68.12. switchport hybrid untagged vlan....274

68.13. switchport hybrid tagged vlan....274

68.14. switchport link-type ....275

68.15. show interface ethernet....275

68.16. show interface brief ethernet 276

68.17. show interface brief vlan-intf 1....276

68.18. show description ethernet 276

68.19. show ingress ethernet....277

1. DDM detection ....278

69.1. show sfp....278

1. Flow control....278

70.1. flow-control 278

70.2. show flow-control....278

1. Storm-Control Configuration Command 279

71.1.storm-suppression....279

71.2. storm-suppression mode .....280

71.3. no storm-suppression....280

71.4. show storm-suppression....280

1. isolate-port Configuration command....281

72.1. no isolate-port uplink....281

72.2. isolate-port uplink ethernet 281

72.3. show isolate-port....281

1. Port-secureiy Configuration command 282

73.1. port-security enable|disable 282

73.2. port-security permit|deny mac-address 282

73.3. show port-security mac-address 282

73.4. port-security permit|deny ip-address ....283

73.5. show port-security ip-address....283

73.6. port-security maximum....284

73.7. port-security permit mac-address sticky.....284

73.8. port-security permit mac-address sticky.....284

73.9. show port-security....285

73.10. no port-security all 285

73.11. show port-security active-address 285

73.12. no port-security active-address ....285

73.13. port-security aging static....286

73.14. port-security aging time 286

73.15. port-security violation....286

73.16. port-security recovery 287

73.17. port-security recovery time....287

73.18. show port-security recovery....287

73.19. port-security violation log-interval 288

1. PPPoE+ Configuration command....288

74.1. pppoeplus....288

74.2. pppoeplus trust....288

74.3. show pppoeplus interface....289

74.4. pppoeplus strategy .....289

74.5. pppoeplus drop .....290

74.6. pppoeplus type....290

74.7. pppoeplus format....290

74.8. pppoeplus delimiter 291

74.9. pppoeplus circuit-id....291

1. IP-Source Configuration command 292

75.1. ip source....292

75.2. show ip source ....292

75.3. ip source binding....292

75.4. show ip source binding .....293
75.5. ip source vlan ....293
75.6. show ip source vlan....293
75.7. ip source permit-igmp....294
75.8. show ip source permit-igmp 294

1. IPv6-Source Configuration Command ....294

76.1. ipv6-source-guard....294
76.2. show ipv6-source-guard 295
76.3. ipv6-source-guard bind ip....295
76.4. show ipv6-source-guard bind....295
76.5. ipv6-source-guard vlan ....296
76.6. show ipv6-source-guard vlan 296

1. 802.1X Configuration command....296

77.1.dot1x 296
77.2. dot1x eap-relay enable|disable....297
77.3. dot1x port-method....297
77.4. dot1x port-control....297
77.5. dot1x re-authenticate 298
77.6. dot1x re-authentication ......298
77.7. dot1x timeout re-authperiod .....298
77.8. dot1x multicast-trigger 299
77.9. dot1x multicast-period .....299
77.10. dot1x max-user-num ....300
77.11. dot1x user cut 300
77.12. dot1x keepalive....300
77.13. dot1x keepalive period....301
77.14. dot1x timeout quiet-period ....301
77.15. dot1x timeout server-timeout ....301
77.16. dot1x timeout supp-timeout....302
77.17. dot1x portbased host-mode 302

77.18. dot1x guest-vlan 303

77.19. dot1x guest-acl ....303

77.20. dot1x max-authfail 303

77.21.dot1x default-active-vlan 304

77.22.dot1x eapol-relay....304

77.23. dot1x eapol-relay uplink 305

77.24.dot1x max-req 305

77.25.dot1x max-reauth 305

77.26. dot1x critical-vlan 306

77.27. dot1x radius-acl-format....306

77.28. dot1x native-vlan-free ....307

77.29.dot1x station-move....307

77.30. dot1x syslog ....307

77.31. show dot1x multicast-trigger ....308

77.32. show dot1x interface....308

77.33. show dot1x users....308

77.34. show dot1x eapol-relay ....309

77.35. show dot1x keepalive ....309

77.36. show dot1x config-vlan....310

77.37. show dot1x port-auth....310

77.38. show dot1x timeout....310

77.39. show dot1x .... 311

77.40. show dot1x guest-acl....311

77.41. show dot1x radius-acl....311

1. Radius Configuration command ....312

78.1. radius host....312

78.2. primary-auth-ip....312

78.3. second-auth-ip....312

78.4. primary-acct-ip 313

78.5. second-acct-ip 313

78.6. auth-secret-key....314
78.7. acct-secret-key 314
78.8. nas-ipaddress....314
78.9.username-format 315
78.10. realtime-account ....315
78.11. realtime-account interval 315
78.12.preemption-time 316
78.13. local-user username ....316
78.14. default domain-name ....316
78.15. domain....317
78.16. scheme ....317
78.17. radius host binding 317
78.18.access-limit 318
78.19. state....318
78.20. accounting-on....318
78.21. h3c-cams....319
78.22. radius accounting ....319
78.23. radius server-disconnect drop 1x....319
78.24. radius 8021p....319
78.25. radius password-encryption....320
78.26. radius vlan enable ....320
78.27. radius vlan-format ....320
78.28. radius mac-address-number ....320
78.29. radius config-attribute....321
78.30. radius attribute....321
78.31. dnrate-value .... 321
78.32.uprate-value 322
78.33. radius bandwidth-limit .... 322
78.34. show radius attribute .... 322
78.35. show radius config-attribute .... 322

78.36. show radius host .... 323
78.37. show rate-attribute-value .... 323
78.38. show domain 323

1. Pvlan Configuration command....324

79.1. private-vlan primary 324
79.2. private-vlan isolated 324
79.3. private-vlan community .... 324
79.4. private-vlan association....324
79.5. switchport private-vlan 325
79.6. show private-vlan 325
79.7. show private-vlan interface....325

1. Muser Configuration command....326

80.1.muser local 326
80.2.muser radius....326
80.3. aaa 326
80.4.muser tacacs+....327
80.5. show muser 327
80.6. tacacs+ encrypt-key ....327
80.7. tacacs+ authentication-type ....327
80.8. tacacs+ primary server....328
80.9. tacacs+ secondary server 328
80.10. tacacs+ preemption-time....329
80.11. show tacacs+ 329

1. Cpu-Alarm Command Manual....330

81.1. alarm cpu 330
81.2. alarm cpu threshold....330
81.3. show alarm cpu 330

1. Port-Alarm configuration manual....331

82.1. alarm all-packets....331
82.2. show alarm all-packets ....331

1. Sylsog configuration manual ....332

83.1. logging 332

83.2. show logging....332

83.3. logging sequence-numbers ...... 332

83.4. logging timestamps ....333

83.5. logging monitor all | monitor-num .... 333

83.6. logging monitor all | monitor-num level-value | none | level-list....334

83.7. show logging filter monitor .... 334

83.8. no logging monitor all | monitor-num filter....334

83.9. logging buffered .... 335

83.10. logging buffered level-value | none | level-list....335

83.11. show logging filter buffered .... 336

83.12. no logging buffered filter....336

83.13. show logging buffered....336

83.14. logging flash....337

83.15. logging flash level-value | none | level-list ....337

83.16. show logging filter flash....337

83.17. no logging flash filter .... 338

83.18. logging flash interval ...... 338

83.19. logging flash msg-number ....338

83.20. show logging flash .... 339

83.21. logging ip-address....339

83.22. logging host all | ip-address ....340

83.23. logging host all | ip-address level-value | none | level-list....340

83.24. no logging host all | ip-address filter ....341

83.25. logging facility....341

83.26. logging source....341

83.27. logging snmp-agent 342

83.28. logging snmp-agent level-value | none | level-list....342

83.29. show logging filter snmp-agent....343

83.30. no logging snmp-agent filter ....343
83.31. debug....343
83.32. show debug .... 344

1. STP/RSTP configuration command....344

84.1.stp 344
84.2. stp mode....344
84.3.stp hello-time 345
84.4. stp forward-time ....345
84.5.stp max-age 345
84.6. stp pathcost-standard 345
84.7. stp priority ....346
84.8. stp root-guard action....346
84.9. stp tc-protection....346
84.10. stp tc-protection interval....347
84.11. stp tc-protection threshold 347
84.12. stp time-factor....347
84.13.stp new-root-trap 348
84.14. stp topo-change-trap....348
84.15.stp bpdu-guard 348
84.16. stp bpdu-filter....348
84.17.stp cost 349
84.18.stp portfast 349
84.19.stp link-type 349
84.20.stp loop-guard 350
84.21.stp mcheck....350
84.22. stp port-priority 350
84.23. stp root-guard....350
84.24. stp tcn-restricted 351
84.25. stp transmit-limit....351
84.26. show stp interface 351

85. MSTP configuration manual....353

85.1.stp 353
85.2.stp mode....353
85.3. mstp hello-time .... 353
85.4. mstp forward-time ....353
85.5. mstp max-age 354
85.6. mstp max-hops 354
85.7. mstp instance priority....354
85.8. mstp root-guard action ....355
85.9. mstp tc-protection....355
85.10. mstp tc-protection interval 355
85.11. mstp tc-protection threshold 356
85.12. mstp time-factor....356
85.13. mstp bpdu-guard 356
85.14. mstp bpdu-filter....356
85.15. mstp instance vlan....357
85.16. mstp region-name ....357
85.17. mstp enable instance ....357
85.18. mstp disable instance....358
85.19. mstp revision 358
85.20. mstp flap-guard ....358
85.21. mstp external cost....358
85.22. mstp instance cost....359
85.23. mstp portfast....359
85.24. mstp link-type....359
85.25. mstp loop-guard 360
85.26. mstp root-guard ....360
85.27. mstp mcheck 360
85.28. mstp instance port-priority ....361
85.29. mstp config-digest-snooping 361

85.30. show mstp instance....361
85.31. show mstp disabled-instance 361
85.32. show mstp config-id .... 362

1. EAPS configuration manual ....362

86.1. eaps 362
86.2. eaps domain 362
86.3.control-vlan 362
86.4. fail-timer 363
86.5. hello-timer 363
86.6.preup-timer 363
86.7. ring....364
86.8. topo-collect ...... 364
86.9.work-mode 364
86.10. show eaps....365
86.11. show eaps control-vlan ....365
86.12. show eaps domain....365
86.13. show eaps statistics....365
86.14. show eaps topology....366
86.15. clear eaps....366

1. ERPS configuration manual ....366

87.1. erps....366
87.2. erps instance ....367
87.3.control-vlan 367
87.4. guard-timer....367
87.5. wtr-timer ....368
87.6.mel 368
87.7. protected-instance ....368
87.8. port0 ethernet 368
87.9. port1 ethernet....369
87.10. ring....369

87.11. show erps 369
87.12. show erps control-vlan 370
87.13. show erps instance 370
87.14. show erps instance statistics 370
87.15. show erps statistics ....370

1. PVST/Rapid-PVST configuration manual 371

88.1.stp 371
88.2. stp mode....371
88.3. pvst hello-time....371
88.4. pvst forward-time....372
88.5. pvst max-age 372
88.6. pvst instance vlan ....372
88.7. pvst instance priority ....373
88.8. pvst bpdu-guard 373
88.9. pvst bpdu-filter 373
88.10. pvst loop-guard ....373
88.11. pvst edge-port ....374
88.12. pvst instance cost 374
88.13. pvst instance port-priority....374
88.14. show pvst instance brief....375

1. Eth-Trunk 配置命令 ..... 375

89.1. interface eth-trunk .... 375
89.2. link-aggregation load-balance 375
89.3. link-aggregation mode ...... 376
89.4. link-aggregation members ethernet 376
89.5. link-aggregation eth-trunk 376
89.6.lacp mode 377
89.7. lacp period....377
89.8. lacp port-priority ....377
89.9. lacp system-priority....378

89.10. show lacp local ....378
89.11. show lacp sys-id....378
89.12. show lacp neighbor ....378

1. FlexLink configuration manual 379

90.1. flex-link group....379
90.2.master-port 379
90.3. slave-port....380
90.4.preemption mode....380
90.5.preemption delay 380
90.6. flex-link flush send....381
90.7. flex-link flush receive....381
90.8. show flex-link group 381
90.9. show flex-link flush....381

1. MonitorLink configuration manual 382

91.1. monitor-link-group 382
91.2. uplink interface....382
91.3. downlink interface....382
91.4. show monitor-link-group....383

1. Sntp-Client Configuration command....383

92.1. sntp client....383
92.2. sntp client mode....384
92.3. sntp client authenticate ....384
92.4. sntp client authentication-key encrypt 384
92.5. sntp client authentication-key....385
92.6. sntp client broadcastdelay....385
92.7. sntp client poll-interval....385
92.8. sntp client retransmit 386
92.9. sntp client retransmit-interval 386
92.10. sntp client summer-time dayly....386
92.11. sntp client summer-time weekly....387

92.12. sntp client valid-server....387
92.13. sntp trusted-key ....387
92.14. sntp server key....388
92.15. sntp server backup 388
92.16. sntp server....388
92.17. show sntp client ....389
92.18. show sntp client summer-time 389

1. System time configuration command....389

93.1. clock set 389
93.2. clock timezone....390
93.3. clock summer-time dayly 390
93.4. clock summer-time weekly 390
93.5. show clock 391

1. 1. Static route configuration commands....391

94.1. 1.1 ip route ....391
94.2.1.2 show ip route....392

1. 2 IPv6 static route configuration command....392

95.1. 2.1 ipv6 route ....392
95.2. 2.2 show ipv6 route....393

96.802.1Q Configuration command 394

96.1.vlan....394
96.2. switchport....394
96.3. switchport pvid....394
96.4. switchport link-type ....395
96.5. switchport trunk allowed vlan....395
96.6. switchport trunk tagged pvid 395
96.7. switchport hybrid untagged vlan....396
96.8. switchport hybrid tagged vlan ....396
96.9. priority....396
96.10. ingress acceptable-frame....397

96.11. ingress filtering....397
96.12. interface vlan-interface ....397
96.13. description ....398
96.14. show interface vlan brief....398

1. QINQ Configuration ....398

97.1.qinq 398
97.2. qinq inner-tpid....399
97.3. qinq mode 399
97.4. qinq outer-tpid ....399
97.5. vlan pass-through ....400
97.6. no vlan pass-through....400
97.7. show qinq....400
97.8. show vlan pass-through....401
97.9. no vlan insert ....401
97.10. vlan insert....401

1. GVRP Configuration 402

98.1. gvrp 402
98.2. garp permit vlan ....402
98.3. garp forbid vlan ....402
98.4. show gvrp....403
98.5. show gvrp interface ....403
98.6. show gvrp interface ethernet....403

1. Vlan Swap Command....403

99.1. vlan swap 403
99.2. show vlan-swap....404

1. Protocol-VLAN Configuration Command ....404

100.1. vlan-protocol....404
100.2. vlan-protocol profile 405
100.3. show vlan-protocol interface 405
100.4. show vlan-protocol profile....405

1. vlan-subnet Configuration command....406

101.1.vlan-subnet....406
101.2. no vlan-subnet....406
101.3. vlan-subnet precede....407
101.4. show vlan-subnet....407

1. Mac-vlan Configuration Command....407

102.1. vlan-mac-table....407
102.2. no vlan-mac-table ....408
102.3. show vlan-mac-table ....408

1. Vlan-trunking Configuration Commands ....408

103.1.vlan-trunking....408
103.2. vlan-trunk mode 409
103.3. show vlan-trunking ....409

1. Voice vlanConfiguration Commands ....409

104.1. voice vlan....409
104.2. voice vlan aging 410
104.3. voice vlan oui-mac....410
104.4. voice vlan security ....411
104.5. voice vlan enable | disable....411
104.6. voice vlan mode....412
104.7. voice vlan qos ....412
104.8. show voice vlan ....413
104.9. show voice vlan device 413
104.10. show voice vlan oui-mac ....413

1. Access control list configuration command

1.1. access-list

Command Function

access-list num match-order [auto| config]Command configuration ACL matching order

Command Format

access-list 1999 match-order auto

Parameter Declaration

Parameter	Parameter Declaration	Values
num	Access control list number	1-2999

1.2. access-list ip-acl

Command Function

access-list ip-acl num [match-order [ auto | config]]Command three layer access control list

{ permit | deny } [ ip-pro protocol ] [ established ] { source-IPv4/v6/masklength | any | ipv6any } [source-port wildcard ] { dest-IPv4/v6dest-wildcard | any | ipv6any } [dest-port wildcard ] [icmp-type icmp-code ] [igmp-type] [traffic-class traffic-class][ precedence precedence ] [ tos tos ] | [ dscp dscp ] [ fragments ][ time-range name ]Command three layer access control list

Command Format

access-list ip-acl 1
permit any any
access-list 1 permit any any

Parameter Declaration

Parameter	Parameter Declaration	Values
num	Three layer access control list number	1-999
protocol	The type of protocol hosted by IP	The range of time value is 0~255When expressed in a name, you can choose GRE、ICMP、IGMP、IPinIP、OSPF、TCP、UDP、ICMPv6。
established	The SYN marker in TCP	SYN mark position 1
{ source-IPv4/v6/ masklength | any | ipv6any }	Source address information of the specified ACL rule	Source-IPv4/v6/ masklength is used to determine the source IP address (IPv4/v6) scope of the packet. The address of IPv4 is expressed in decimal notation; the IPv6 address is expressed in sixteen hexadecimal.Masklen is 32 when the host address is represented;Any| ipv6any represents an arbitrary source address.
{ dest-IPv4/v6 / masklength | any | ipv6any }	Destination information for specifying the ACL rule	Dest-IPv4/v6 dest-wildcard is used to determine the destination IP address (IPv4/v6) range, IPv4 address is expressed in dot decimal notation, and IPv6 address is represented in sixteen hexadecimal.When masklength is 32, the host address is represented;Any| ipv6any represents an arbitrary destination address.
source-port/ dest-port wildcard	TCP/UDP source and destination port number	Wildcard - counter - determine the range of port number
icmp-type icmp-code	The type of ICMP message	Only when the protocol is configured to be icmp/icmpv6
igmp-type	IGMP protocol message type	Only when the protocol is configured to be IGMP
traffic-class	Ipv6headlinetraffic-class	Only valid for IPv6 message
precedence	precedencemessage priority	IP priority range 0~7
tos	Tos message priority	Range 0~15
dscp	DSCP priority	Range0~63
fragments	Presentation of a piecewise message	The definition rules are valid only for non - chip slices
time-rangename	customTime and name	Except? 1-32 characters outside

1.3. no access-list

Command Function

no access-list [ num | all | step ]Command deletion based on digital ACL

Command Format

no access-list 1

Parameter Declaration

Parameter	Parameter Declaration	Values
num	Access control list number	1-2999

1.4. access-list mac-acl

Command Function

access-list num { permit | deny } [ mac-pro protocol ] [ cos vlan-pri ][ source-mac-addr source-mac-wildcard ] [any] } [ dest-mac-addr dest-mac-wildcard ] | any } [ time-range name ]Command two layer access control list

access-list num { permit | deny } [ mac-pro protocol ] [ cos vlan-pri ]ingress { [ inner-vid vid ] [start-vlan-id end-vlan-id ] [ source-mac-addr source-mac-wildcard ] [ interface interface-num ] } | any } [ time-range name ]Command two layer access control list

Command Format

access-list mac-acl 1000 match-order auto

permit any any

access-list 1000 permit any any

Parameter Declaration

Parameter	Parameter Declaration	Values
num	Two layer access control list number	1000-1999
protocol	Protocol type of Ethernet frame load	In sixteen, the range is 0-FFFF. Optional ARP, IP, RARP
Cos	The priority of the Vlan label	0-7
Ingress	Direction of entry	/
inner-vid	The inner layer vid value of a double tag message	1-4094
start-vlan-id end-vlan-id	Used to represent the range of Vlan	If the dual tag message is the vid range of the outer tag, the single tag message is the vid range of the tag itself.
source-mac-addr source-mac-wildcard	Source MAC address options	Source-mac-wildcard can represent the source MAC range.
interface interface-num	Physical port number	Into ports and out ports
any	Any address	Into ports and out ports
time-range name	custom Time and name	Except? 1-32 characters outside

1.5. access-list hybrid-acl

Command Function

access-list num { permit | deny } [ mac-pro protocol ] [ ip-pro protocol ] [ cos

vlan-pri ] [ established ] { source-IPv4/v6/masklength | any | ipv6any }

[source-port wildcard ] [ source-mac-addr source-mac-wildcard ] | any }

{ [ dest-mac-addr dest-mac-wildcard ] | any } { dest-IPv4/v6 dest-wildcard |

any | ipv6any } [dest-port wildcard ] [icmp-type icmp-code ] [igmp-type]

[traffic-class traffic-class][ precedence precedence ] [ tos tos ] | [ dscp dscp ]

[fragments] [time-range name]

access-list num { permit | deny } [ mac-pro protocol ] [ ip-pro protocol ] [ cos vlan-pri ] [ established ] { source-IPv4/v6/masklength | any | ipv6any } [source-port wildcard ] ingress { { [ inner-vid vid ] [start-vlan-id end-vlan-id ] [ source-mac-addr source-mac-wildcard ] [ interface interface-num ] } | any } [icmp-type icmp-code ] [igmp-type] [traffic-class traffic-class][ precedence precedence ] [ tos tos ] | [ dscp dscp ] [ fragments ] [ time-range name ] Command configuration of a mixed access control list

Command Format

access-list 2000 permit anyip anyip access-lis 2000 permit anymac anymac

Parameter Declaration

Parameter	Parameter Declaration	Values
num	Two layer access control list number	2000-2999
mac-pro protocol	Protocol type of Ethernet frame load	In sixteen, the range is 0-FFFF. Optional ARP, IP, RARP
Cos	The priority of the Vlan label	0-7
Ingress	Direction of entry	/
inner-vid	The inner layer vid value of a double tag message	1-4094
start-vlan-id end-vlan-id	Used to represent the range of Vlan	If the dual tag message is the vid range of the outer tag, the single tag message is the vid range of the tag itself.
source-mac-addr source-mac-wildcard	Source MAC address options	Source-mac-wildcard can represent the source MAC range
interface interface-num	Physical portnumber	Into ports and out ports
any	Any address	Into ports and out ports
ip-pro protocol	The type of protocol hosted by IP	The range of time value is 1~255When names are used, you can select GRE, ICMP, IGMP, IPinIP, OSPF, TCP, UDP, ICMPv6.
established	The SYN marker in TCP	SYN mark position 1
{ source-IPv4/v6/ masklength | any | ipv6any }	Source address information of the specified ACL rule	Source-IPv4/v6/ masklength is used to determine the source IP address (IPv4/v6) scope of the packet. The address of IPv4 is expressed in decimal notation; the IPv6 address is expressed in sixteen hexadecimal.Masklen is 32 when the host address is represented;Any| ipv6any represents an arbitrary source address.
{ dest-IPv4/v6 / masklength | any | ipv6any }	Destination information for specifying the ACL rule	Dest-IPv4/v6 dest-wildcard is used to determine the destination IP address (IPv4/v6) range, IPv4 address is expressed in dot decimal notation, and IPv6 address is represented in sixteen hexadecimal.When masklength is 32, the host address is represented;Any| ipv6any represents an arbitrary destination address.
source-port/ dest-port wildcard	TCP/UDP source and destination port number	Wildcard - counter - determine the range of port number
icmp-type icmp-code	The type of ICMP message	Only when the protocol is configured to be icmp/icmpv6
igmp-type	IGMP protocol message type	Only when the protocol is configured to be IGMP
traffic-class	Ipv6 headerstraffic-class	Only valid for IPv6 message
precedence	precedence message priority	IP priority range 0~7
tos	Tos message priority	Range0~15
dscp	DSCP priority	Range0~63
fragments	Presentation of a piecewise message	The definition rules are valid only for non - chip slices
time-range name	customTime and name	Except? 1-32 characters outside

1.6. show access-list config

Command Function

show access-list config num | all command view configuration access control list information

Command Format

show access-list config 1

Parameter Declaration

Parameter	Parameter Declaration	Values
num	Access control list number	1-2999

1.7. show access-list config statistic

Command Function

show access-list config statisticCommand to view the number of access control lists in the configuration

Command Format

show access-list config statistic

Parameter Declaration

/

1.8. show access-list runtime statistic

Command Function

show access-list runtime statisticCommand to see the number of activated ACL statistics

Command Format

show access-list runtime statistic

Parameter Declaration

/

1.9. show access-list runtime

Command Function

show access-list runtime num | allCommand to view the run access control list information

Command Format

show access-list runtime 1

Parameter Declaration

Parameter	Parameter Declaration	Values
num	Access control list number	1-2999

1.10. time-range

Command Function

time-range name command creates time and enters time configuration mode.

Command Format

time-range time1

Parameter Declaration

Parameter	Parameter Declaration	Values
name	The name of the interval (the longest is 32 bytes, must start with [a-z, A-Z], not case sensitive).	1-32character

1.11. absolute

Command Function

(no)absolute [start start-time start-day [ end end-time end-day ]]Command configuration (delete) absolute time

Command Format

absolute start 1:1:1 2017/1/1 end 1:1:1 2017/12/1 no absolute start 1:1:1 2017/1/1 end 2:2:2 2017/12/1

Parameter Declaration

Parameter	Parameter Declaration	Values
start-time	Start time	00:00:00-23:59:59
start-day	Start Year/Month/Date	2000/01/01-2099/12/31
end-time	End time	00:00:00-23:59:59
end-day	End Year/Month/Date	2000/01/01-2099/12/31

1.12. periodic

Command Function

(no)periodic week start-time to end-time command configuration

(delete) relative time period

Command Format

periodic daily 1:1:1 to 2:2:2

no periodic daily 1:1:1 to 2:2:2

Parameter Declaration

Parameter	Parameter Declaration	Values
week	A special week	Daily, fri, mon, sat, sun, thu, tue, wed, week days, weekend
start-time	Start time	00:00:00-23:59:59
end-time	End time	00:00:00-23:59:59

1.13. no time-range

Command Function

no time-range [all | name name]Command deleting time

Command Format

no time-range all

Parameter Declaration

Parameter	Parameter Declaration	Values
name	The name of the interval (the longest is 32 bytes, must start with [a-z, A-Z], not case sensitive).	1-32character

1.14. show time-range

Command Function

show time-range [name name | all | statistic]Command to view the run access control list information

Command Format

show time-range all

Parameter Declaration

Parameter	Parameter Declaration	Values
name	The name of the time period (the longest is 32 bytes, must start with [a-z, A-Z], not case sensitive).	1-32

1.15. access-group

Command Function

access-group [ip-acl ip-num] [mac-acl mac-num] [hybrid-acl hyb-num]

[ subitem sub-num] in Command activation access control list

Command Format

access-group mac-acl 1000 subitem 1 in

Parameter Declaration

Parameter	Parameter Declaration	Values
ip-num	Three layer access control list number	1-999
mac-num	Two layer access control list number	1000-1999
hyb-num	Mixed access control list number	2000-2999
sub-num	The subitem number of the three, two, and mixed ACL list	0-127

1.16. no access-group

Command Function

no access-group [ all | ip-acl ip-num ] [ mac-acl mac-num ] [ hybrid-acl

hyb-num] [subitem sub-num] in Command to activate the access

control list

Command Format

no access-group mac-acl 1000 subitem 1 in

Parameter Declaration

Parameter	Parameter Declaration	Values
ip-num	Three layer access control list number	1-999
mac-num	Two layer access control list number	1000-1999
hyb-num	Mixed access control list number	2000-2999
sub-num	The subitem number of the three, two, and mixed ACL list	0-127

2. QOS Configuration Command

2.1. rate-limit

Command Function

rate-limit input [ip-acl ip-num] | [mac-acl mac-num] | [hybrid-acl hyb-num] [subitem sub-num] target-rate Command flow speed limit in global mode

rate-limit input [ip-acl ip-num] | [mac-acl mac-num] | [hybrid-acl hyb-num] [subitem sub-num] two-rate-policer id Command configures dual speed three color application strategy in global mode

Command Format

rate-limit input ip-acl 1 64

rate-limit input ip-acl 1 two-rate-policer 1

Parameter Declaration

Parameter	Parameter Declaration	Values
ip-num	Three layer access control list number	1-999
mac-num	Two layer access control list number	1000-1999
hyb-num	Mixed access control list number	2000-2999
sub-num	The subitem number of the three, two, and mixed ACL list	0-127
target-rate	The maximum rate (1000 bit per second) should be 64 times the integer.	16-1000000
id	Two rate policer ID for input	0-255

2.2. two-rate-policer

Command Function

two-rate-policer id cir cbs pir pbs

The command configures the parameters of two-rate-policer in global mode

Command Format

two-rate-policer 1 cir 16 cbs 64 pir 64 pbs 128

no two-rate-policer 1

Parameter Declaration

Parameter	Parameter Declaration	Values
id	Two rate policer ID for input	0-255
Cir-value	The Convention rate (bit per second) should be an integer multiple of 64.	16-1000000
cbs-value	For a burst size (KByte), the size of the target should be 4 times the power of 2.	1-12800
pir-value	Peak rate	16-1000000
pbs-value	Peak burst size	1-12800

2.3. traffic-redirect

Command Function

traffic-redirect [ip-acl ip-num] | [mac-acl mac-num] | [hybrid-acl hyb-num]

[ subitem sub-num] [ interface [eth-trunk trunk-id | ethernet port-id ] |

cpu ] Command configuration message redirection

no traffic-redirect [ip-acl ip-num] | [mac-acl mac-num] | [hybrid-acl hyb-

num] [ subitem sub-num] Command delete message redirection

Command Format

traffic-redirect ip-acl 1 interface ethernet 0/0/1

no traffic-redirect ip-acl 1 subitem 2 mac-acl 1000 subitem 1

Parameter Declaration

Parameter	Parameter Declaration	Values
ip-num	Three layer access control list number	1-999
mac-num	Two layer access control list number	1000-1999
hyb-num	Mixed access control list number	2000-2999
sub-num	The subitem number of the three, two, and mixed ACL list	0-127
trunk-id	Link convergence end number	1-8
port-id	Port number	According to the physical port of the switch, for example, the 28 switch: 0/0/1-0/1/4

2.4. traffic-copy-to-cpu

Command Function

traffic-copy-to-cpu [ip-acl ip-num] | [mac-acl mac-num] | [hybrid-acl hyb-num] string [subitem sub-num] The command configuration message is copied to CPU

no traffic-copy-to-cpu [ip-acl ip-num] | [mac-acl mac-num] | [hybrid-acl hyb-num] string [subitem sub-num] Command delete message copy to CPU

Command Format

traffic-copy-to-cpu ip-acl 1 no traffic-copy-to-cpu ip-acl 1

Parameter Declaration

Parameter	Parameter Declaration	Values
ip-num	Three layer access control list number	1-999
mac-num	Two layer access control list number	1000-1999
hyb-num	Mixed access control list number	2000-2999
string	Standard or extended access control list name	Except? Extras 1-32 characters
sub-num	The subitem number of the three, two, and mixed ACL list	0-127

2.5. traffic-priority

Command Function

traffic-priority { [ ip-acl ip-num[ subitem subitem ] ] | { [ mac-acl mac-num] [ subitem subitem ] ] } | { [hybrid-acl hyb-num] [ subitem subitem ] ] }{ [ dscp dscp-value ]
    [ cos cos-value | precedence pre-value } ] [ local-precedence local-value ] }Command configuration priority mark up
no traffic-priority { [ ip-acl ip-num[ subitem subitem ] ] | { [ mac-acl mac-num] [ subitem subitem ] ] } | { [hybrid-acl hyb-num] [ subitem subitem ] ] }Command delete priority markup

Command Format

traffic-priority mac-acl 1000 local-precedence 2 precedence 2 no traffic-priority ip-acl 1 subitem 21

Parameter Declaration

Parameter	Parameter Declaration	Values
ip-num	Three layer access control list number	1-999
mac-num	Two layer access control list number	1000-1999
hyb-num	Mixed access control list number	2000-2999
subitem	The subitem number of the three, two, and mixed ACL list	0-127
dscp-value	Matching a specific DSCP value	0-63
cos-value	A message matching a p priority to a specific value	0-7
pre-value	A message with a specific IP priority	0-7
local-value	Setting up localpriority	0-7

2.6. traffic-statistic

Command Function

traffic-statistic { [ ip-acl ip-num[ subitem subitem ] ] | { [ mac-acl mac-num] [ subitem subitem ] ] } | { [hybrid-acl hyb-num] [ subitem subitem ] ] } [in | out]Command configuration traffic statisticsno traffic-statistic { [ ip-acl ip-num[ subitem subitem ] ] | { [ mac-acl mac-num] [ subitem subitem ] ] } | { [hybrid-acl hyb-num] [ subitem subitem ] ] } [in | out]Command delete traffic statistics

Command Format

traffic-statistic hybrid-acl 2000 in no traffic-statistic hybrid-acl 2000 in

Parameter Declaration

Parameter	Parameter Declaration	Values
ip-num	Three layer access control list number	1-999
mac-num	Two layer access control list number	1000-1999
hyb-num	Mixed access control list number	2000-2999
subitem	The subitem number of the three, two, and mixed ACL list	0-127

2.7. clear traffic-statistic

Command Function

clear traffic-statistic {all | [ ip-acl ip-num[ subitem subitem ] ] | { [ mac-acl mac-num] [ subitem subitem ] ] } | { [hybrid-acl hyb-num] [ subitem subitem ] ] } [in | out]Command traffic statistics zero

Command Format

clear traffic-statistic hybrid-acl 2000 in

Parameter Declaration

Parameter	Parameter Declaration	Values
ip-num	Three layer access control list number	1-999
mac-num	Two layer access control list number	1000-1999
hyb-num	Mixed access control list number	2000-2999
subitem	The subitem number of the three, two, and mixed ACL list	0-127

2.8. mirrored-to

Command Function

mirrored-to { [ ip-acl ip-num[ subitem subitem ] ] | { [ mac-acl mac-num] }

[ subitem subitem ] } | { [hybrid-acl hyb-num] [ subitem subitem ] ] }

[interface port-id]

Command configuration flow imageno mirrored-to { [ ip-acl ip-num[ subitem

subitem ] | { [ mac-acl mac-num] [ subitem subitem ] ] } | { [hybrid-acl hyb-

num] [ subitem subitem ] }Command delete stream mirror

Command Format

mirrored-to ip-acl 1 subitem 2 interface ethernet 0/0/1

no mirrored-to ip-acl 1 subitem 2

Parameter Declaration

Parameter	Parameter Declaration	Values
ip-num	Three layer access control list number	1-999
mac-num	Two layer access control list number	1000-1999
hyb-num	Mixed access control list number	2000-2999
subitem	The subitem number of the three, two, and mixed ACL list	0-127
port-id	Port number	According to the physical port of the switch, for example, the 28 switch: 0/0/1-0/1/4

2.9. traffic-rewrite-vlan

Command Function

traffic-rewrite-vlan { [ ip-acl ip-num[ subitem subitem ] ] | { [ mac-acl mac-num] [ subitem subitem ] ] } | { [hybrid-acl hyb-num] [ subitem subitem ] ] }
vlan-idCommand configuration message VLAN rewrite
no traffic-rewrite-vlan { [ ip-acl ip-num[ subitem subitem ] ] | { [ mac-acl mac-num] [ subitem subitem ] ] } | { [hybrid-acl hyb-num] [ subitem subitem ] ] } Command delete message VLAN rewrite

Command Format

traffic-rewrite-vlan ip-acl 1 subitem 2 2
no traffic-rewrite-vlan ip-acl 1 subitem 2

Parameter Declaration

Parameter	Parameter Declaration	Values
ip-num	Three layer access control list number	1-999
mac-num	Two layer access control list number	1000-1999
hyb-num	Mixed access control list number	2000-2999
subitem	The subitem number of the three, two, and mixed ACL list	0-127
vlan-id	Rewrite VLAN ID	1-4094

2.10. traffic-insert-vlan

Command Function

traffic-insert-vlan { [ ip-acl ip-num[ subitem subitem ] ] | { [ mac-acl mac-num] [ subitem subitem ] ] } | { [hybrid-acl hyb-num] [ subitem subitem ] ] }
vlan-idCommand configuration message VLAN insert
no traffic-insert-vlan { [ ip-acl ip-num[ subitem subitem ] ] | { [ mac-acl mac-num] [ subitem subitem ] ] } | { [hybrid-acl hyb-num] [ subitem subitem ] ] }
Command delete message VLAN insert

Command Format

traffic-insert-vlan ip-acl 1 subitem 2 2
no traffic-insert-vlan ip-acl 1 subitem 2

Parameter Declaration

Parameter	Parameter Declaration	Values
ip-num	Three layer access control list number	1-999
mac-num	Two layer access control list numbe	1000-1999
hyb-num	Mixed access control list number	2000-2999
subitem	The subitem number of the three, two, and mixed ACL list	0-127
vlan-id	Insert VLAN ID	1-4094

2.11. show two-rate-policer

Command Function

show two-rate-policer Command to view double speed three color configuration information

Command Format

show two-rate-policer

Parameter Declaration /

2.12. show qos-info statistic

Command Function

show qos-info statistic The command displays all QoS statistics

Command Format

show qos-info statistic

Parameter Declaration /

2.13. show qos-info traffic-copy-to-cpu

Command Function

show qos-info traffic-copy-to-cpu The command shows the parameter settings of the message copied to the CPU

Console Reference Guide Intellinet Network Solutions

Command Format
show qos-info traffic-copy-to-cpu
Parameter Declaration
/

2.14. show qos-info all

Command Function
show qos-info all Command displays all QoS parameter settings
Command Format
show qos-info all
Parameter Declaration
/

2.15. show qos-info mirrored-to

Command Function
show qos-info mirrored-to Parameter setting of a command display stream image
Command Format
show qos-info mirrored-to
Parameter Declaration
/

2.16. show qos-info traffic-priority

Command Function
show qos-info traffic-priority Command display priority tag parameter settings
Command Format
show qos-info traffic-priority
Parameter Declaration
/

2.17. show qos-info traffic-redirect

Command Function show qos-info traffic-redirect Command display parameter settings for redirection
Command Format show qos-info traffic-redirect
Parameter Declaration

/

2.18. show qos-info traffic-statistic

Command Function
show qos-info traffic-statistic Command display traffic statistics
Command Format
show qos-info traffic-statistic
Parameter Declaration
/

2.19. show qos-info traffic-insert-vlan

Command Function
show qos-info traffic-insert-vlan Command display VLAN insert parameter settings
Command Format
show qos-info traffic-insert-vlan
Parameter Declaration
/

3. COS Configuration Command

3.1. queue-scheduler

Command Function
(no) queue-scheduler Command to open (close) queue scheduling
Command Format
queue-scheduler
no queue-scheduler

Parameter Declaration
/

3.2. queue-scheduler mode

Command Function
queue-scheduler mode[sp-wfq | sp-wrr | strict-priority | wfq | wrr] <queue

value> Command to configure queue scheduling mode

Command Format

queue-scheduler mode wrr 1 1 1 1 1 1 1 1

Parameter Declaration

Parameter	Parameter Declaration	Values
sp-wfq	Strict priority + Weighted fair robin
sp-wrr	Strict Priority + Weighted Round Robin
strict-priority	Strict priority queue(default)
wfq	Weighted fair queuing
wrr	Weighted round robin
queue value	Weight queue(%)	0-128

3.3. no queue-scheduler mode

Command Function

no queue-scheduler modeCommand configuration queue mode to restore the default

Command Format

no queue-scheduler mode

Parameter Declaration

None

3.4. queue-scheduler cos-map

Command Function

queue-scheduler cos-map <802.1p priority> < Queue of Class>Command to configure cos-map queue

Command Format

queue-scheduler cos-map 0 1

Parameter Declaration

Parameter	Parameter Declaration	Values
802.1p priority		0-7
Queue of Class		0-7

3.5. queue-scheduler dscp-map

Command Function

(no)queue-scheduler dscp-map Command to open (close) dscp-map

Command Format

queue-scheduler dscp-map

Parameter Declaration

none

3.6. queue-scheduler dscp-map

Command Function

queue-scheduler dscp-map <802.1p priority>Command to

configure the value of dscp-map

Command Format

queue-scheduler dscp-map 0 7

Parameter Declaration

Parameter	Parameter Declaration	Values
value	DSCP value	0-63
802.1p priority		0-7

3.7. show queue-scheduler

Command Function

show queue-schedulerView queue scheduling configurationp

Command Format

show queue-scheduler

Parameter Declaration

none

3.8. show queue-scheduler cos-map

Command Function

show queue-scheduler cos-map View cos-map queue scheduling

configurationp

Command Format

show queue-scheduler cos-map

Parameter Declaration

none

3.9. show queue-scheduler dscp-map

Command Function

show queue-scheduler dscp-map View dscp-map queue scheduling

configurationp

Command Format

show queue-scheduler dscp-map

Parameter Declaration

none

4. ARP Learning configuration command

4.1. arp

Command function

Configure arp short static tables

Command format

$$ \mathbf {a r p} < i p > < m a c > $$

Parameter Description

Parameter	Parameter Description	Value
ip	IP Address
mac	Mac Address

4.2. arp vlan

Command function

Configure arp long static tables

Command format

$$ \text { arp } < i p > < m a c > \text { vlan } < v l a n - i d > [ \text { interface ethernet } < p o r t - i d > ] $$

Parameter Description

Parameter	Parameter Description	Value
ip	IP Address
mac	Mac Address
vlan-id	Vlan ID
port-id	Port ID

4.3. arp aging-time

Command function

Configuring arp aging-time

Command format

$$ \text { arp aging - time } \quad < t i m e > $$

no arp aging-time

Parameter Description

Parameter	Parameter Description	Value
time		3-2880 minutes

4.4. arp peer

Command function

Configure arp peer

arp peer >

no arp peer

Parameter Description

Parameter	Parameter Description	Value
ip	IP Address
mac	Mac Address
port-num	Port ID

4.5. arp bind dynamic

Command function

Configure dynamic arp to static arp

Command format

arp bind dynamic

Parameter Description

Parameter	Parameter Description	Value
ip	IP Address
all	All dynamic arp

4.6. no arp

Command function

Delete the arp table

Command format

no arp < dynamic | static | all | ip>

Parameter Description

Parameter	Parameter Description	Value
ip	IP Address
all	All arp
dynamic	dynamic
static	Static

4.7. show arp

Command function

Show arp table

Command format

show arp < dynamic | static | all | ip|mac|vlan |interface

ethernet >

Parameter Description

Parameter	Parameter Description	Value
ip	IP Address
all	All arp
dynamic	dynamic
static	static
mac	Mac Address
vlan-id	Vlan-id
port-num	port-num

4.8. arp overwrite

Command function

Configure arp collision message under physical Interface

Command format

arp overwrite

no arp overwrite

Parameter Description

None

4.9. gratuitous-arp

Command function

Send free arp when configuration port is up under physical interface

Command format

gratuitous-arp

gratuitous-arp

Parameter Description

None

4.10. arp reply-repeat

Command function

Enable arp reply-repeat function under physical interface

Command format

arp reply-repeat

no arp reply-repeat

Parameter Description

None

4.11. arp reply-repeat [times]

Command function

Configure arp reply-repeat times per unit time globally

Command format

arp reply-repeat [times ] [interval ]

no arp reply-repeat [times ] [interval ]

Parameter Description

Parameter	Parameter Description	Value
times	times	1-3
mseconds	ms	10-1000ms

4.12. show arp aging-time

Command function

View arp aging-time

Command format

show arp aging-time

Parameter Description

None

4.13. show arp overwrite

Command function

View arp aging time

Command format

show arp overwrite [interface ethernet ]

Parameter Description

None

4.14. show arp peer

Command function

View peer

Command format

show arp peer

Parameter Description

None

4.15. show arp reply-repeat

Command function

View arp reply-repeat

Command format

show arp reply-repeat [interface ethernet ]

Parameter Description

None

5. ARP Proxy configuration command

5.1. arp-proxy

Command function

Vlan enables arp-proxy function firstly

Command format

arp-proxy

no arp-proxy

Parameter Description

None

5.2. arp-proxy broadcast

Command function

Enable the arp-proxy broadcast function of this vlan

Command format

arp-proxy broadcast

no arp-proxy broadcast

Parameter Description

None

5.3. show arp-proxy

Command function

Show arp-proxy

Command format

show arp-proxy

Parameter Description

None

6. IPv6ND Configuration command

6.1. ipv6 neighbor

Command function

Configure nd Short Static Table

Command format

ipv6 neighbor

Parameter Description

Parameter	Parameter Description	Value
ipv6	Ipv6 Address
mac	Mac Address

6.2. ipv6 neighbor

Command function

Configure the nd long static table

Command format

ipv6 neighbor

Parameter Description

Parameter	Parameter Description	Value
ipv6	Ipv6 Address
mac	Mac address
vlan-id	Vlan id
port-id	Port id

6.3. ipv6 neighbors max-learning-num

Command function

Configure neighbors max-learning-num of port and neighbors max-

learning-num globally.

Command format

ipv6 neighbors max-learning-num

no ipv6 neighbors max-learning-num

Parameter Description

Parameter	Parameter Description	Value
num		1-2000

6.4. show ipv6 neighbors max-learning-num

Command function

View the maximum number of accessible neighbors

Command format

show ipv6 neighbors max-learning-num

Parameter Description

None

6.5. ipv6 nd reachable-time

Command function

Configure reachable-time status aging time of L3 interface

configuration or reachable-time status aging time globally.

Command format

ipv6 nd reachable-time

no ipv6 nd reachable-time

Parameter Description

Parameter	Parameter Description	Value
time		1-3600 s

6.6. ipv6 nd dad attemps

Command function

Configure send dad message times of L3 interface or send dad message times globally

Command format

ipv6 nd dad attemps no ipv6 nd dad attemps

Parameter Description

Parameter	Parameter Description	Value
times		0-20

6.7. ipv6 nd ns retrans-time

Command function

Configure ipv6 nd ns retrans-time of L3 interface or ipv6 nd ns retrans-time globally.

Command format

ipv6 nd ns retrans-time

Parameter Description

Parameter	Parameter Description	Value
seconds		1-3600s

6.8. ipv6 nd ra interval

Command function

Configure ipv6 nd ra interval of L3 interface or ipv6 nd ra interval orally.

Command format

ipv6 nd ra interval No ipv6 nd ra interval

Parameter Description

Parameter	Parameter Description	Value
max-seconds	Maximum interval	4-1800
min-seconds	Minimum interval	3-1350

6.9. ipv6 nd ra halt

Command function

ipv6 nd ra halt of interface

Command format

ipv6 nd ra halt

no ipv6 nd ra interval

Parameter Description

none

6.10. ipv6 nd ra hop-limit

Command function

Configure sending ra message of hop-limits to L3 interface.

Command format

ipv6 nd ra hop-limit

no ipv6 nd ra hop-limit

Parameter Description

Parameter	Parameter Description	Value
num		0-255

6.11. ipv6 nd ra prefix

Command function

L3 Interface configuration for sending ra message prefix parameters

Command format

ipv6 nd ra prefix [valid-lifetime preferred-lifetime]

[off-link][no-autoconfig]

no ipv6 nd ra prefix

Parameter Description

Parameter	Parameter Description	Value
id	Prefix id	1-32
valid-lifetime	valid-lifetime	0-4294967295s
preferred-lifetime	preferred-lifetime	0-4294967295s
no-autoconfig	no-autoconfig
off-link	Connection determination

6.12. ipv6 nd ra router-lifetime

Command function

Configure router-lifetime of sending message to L3 interface

Command format

ipv6 nd ra router-lifetime

ipv6 nd ra router-lifetime

Parameter Description

Parameter	Parameter Description	Value
second		0-9000

6.13. show ipv6 nd dad attemps

Command function

Show sending times of dad

Command format

show ipv6 nd dad attemps

Parameter Description

None

6.14. show ipv6 nd reachable-time

Command function

Show reachable-time status time

Command format

show ipv6 nd reachable-time

Parameter Description

None

6.15. show ipv6 nd ns retrans-time

Command function

show ipv6 nd ns retrans-time

Command format

show ipv6 nd ns retrans-time

Parameter Description

None

6.16. show ipv6 nd ra halt

Command function

Show whether the L3 interface suppresses ra

Command formatshow ipv6 nd ra halt

Command format none

6.17. show ipv6 nd ra hop-limit

Command function Show the hop-limit of nd ra

Command formatshow ipv6 nd ra hop-limit

Command format none

6.18. show ipv6 nd ra interval

Command function show ipv6 nd ra interval

Command formatshow ipv6 nd ra interval

Command format none

6.19. show ipv6 nd ra prefix

Command function show ipv6 nd ra prefix

Command formatshow ipv6 nd ra interval

Command format none

6.20. show ipv6 nd ra router-lifetime

Command function show ipv6 nd ra router-lifetime

Command formatshow ipv6 nd ra router-lifetime

Command format none

7. Anti ARP spoofing configuration command

7.1. arp anti-spoofing

Command Function
Opening arp anti-spoofing function
Command Format
arp anti-spoofing
no arp anti-spoofing
Parameter Declaration
/

7.2. arp anti-spoofing action

Command Function
Processing of unknown ARP
Command Format
arp anti-spoofing action <discard|flood>
Parameter Declaration

Parameter Parameter Values
Declaration
discard Discard
flood diffuse red

7.3. arp anti-spoofing bind

Command Function
Configure the host protection function
Command Format
arp anti-spoofing bind ip <ip> interface [ethernet <port-list>]
no arp anti-spoofing bind ip <ip> interface [ethernet <port-list>]
Parameter Declaration

Parameter	Parameter Declaration	Values
ip	Ip address
port-list	Port list

7.4. arp anti-spoofing gateway-disguiser

Command Function
Three layer device configuration gateway anti deception function
Command Format
arp anti-spoofing gateway-disguiser
no arp anti-spoofing gateway-disguiser
Parameter Declaration
/

7.5. arp anti-spoofing source-mac-check

Command Function
ARP message source address consistency check
Command Format
arp anti-spoofing source-mac-check
no arp anti-spoofing source-mac-checkr
Parameter Declaration
/

7.6. arp anti-attack trust

Command Function
Configuring the interface to a trust port under a physical interface
Command Format
arp anti-attack trust
no arp anti-attack trust
Parameter Declaration
/

7.7. show arp anti-spoofing

Command Function
View fraud prevention configuration
Command Format
show arp anti-spoofing
Parameter Declaration
/

7.8. show arp anti-spoofing bind

Command Function
View the protected host
Command Format
show arp anti-spoofing bind
Parameter Declaration
/

7.9. show arp anti-attack

Command Function
View the trust port
Command Format
show arp anti-attack [interface ethernet port-id]
Parameter Declaration
/

8. Anti ARP flood configuration command

8.1. arp anti-flood

Command Function Opening arp anti-flood function

Command Format
arp anti-flood
no arp anti-flood

Parameter Declaration

/

8.2. arp anti-flood action

Command Function

Processing of ARP attack message

Command Format

arp anti-flood action

Parameter Declaration

Parameter	Parameter Declaration	Values
deny-all	Discarding all
deny-arp	Discarding ARP

8.3. arp anti-flood rate-limit

Command Function

Configuring the ARP rate threshold in a global or physical interface

Command Format

arp anti-flood rate-limit

no arp anti-flood rate-limit

Parameter Declaration

Parameter	Parameter Declaration	Values
num		1-100 pps

8.4. arp anti-flood recover-time

Command Function

Configure prohibited user auto recovery time

Command Format

arp anti-flood recover-time

no arp anti-flood recover-time

Parameter Declaration

Parameter	Parameter Declaration	Values
time		0-1440 min

8.5. arp anti-flood recover

Command Function

Manual recovery prohibition of users

Command Format

arp anti-flood recover

Parameter Declaration

Parameter	Parameter Declaration	Values
all	All prohibition of users
mac	The MAC address corresponds to the user

8.6. arp anti-flood bind blackhole

Command Function

The dynamic black hole generated by binding flood attacks is MAC static black hole MAC, and deny-all generates dynamic black hole Mac.

Command Format

arp anti-flood bind blackhole

Parameter Declaration

Parameter	Parameter Declaration	Values
all	All dynamic black holes
mac	MAC address

corresponds to a black hole

8.7. show arp anti-flood

Command Function
View the flood prevention configuration
Command Format
show arp anti-flood
Parameter Declaration
/

8.8. show arp anti-flood rate-limit

Command Function
View the port ARP threshold
Command Format
show arp anti-flood port-rate
Parameter Declaration
/

9. Anti Dos attack configuration command

9.1. anti-dos ip ttl

Command Function
Open the anti TTL attack mode
Command Format
anti-dos ip ttl
no anti-dos ip ttl
Parameter Declaration
/

9.2. anti-dos ip fragment

Command Function Open anti slice attack

Command Format

anti-dos ip fragment

no anti-dos ip fragment

Parameter Declaration

Parameter	Parameter Declaration	Values
num	The maximum number of IP slices	0-800

9.3. anti-dos packets class

Command Function

Open a message attack

Command Format

anti-dos packets class < type0|type1| type2| type3| type4 <icmpv4-len>|
    type5< icmpv6-len >| type6| type7| type8| type9
    <tpye9-len>| type10| type11| type12| type13|
    type14 <tcp-len>>
no anti-dos packets class < type0|type1| type2| type3| type4| type5|
    type6| type7| type8| type9| type10| type11|
    type12| type13| type14>

Parameter Declaration

Parameter	Parameter Declaration	Values
type0	Source object MAC equal package	Source object IP equal package Source destination UDP ports equal
tpye1
tpye2
tpye3	Source destinationTCP ports equalGreater than the specified lengthicmpv4 package	0-16384
tpye4
icmpv4-len	icmpv4 specified lengthGreater than the specified length ICMPv6 package
tpye5
icmpv6-len	ICMPv6 specified lengthTCP control flag, TCP package with serial number 0	0-16384
tpye6
tpye7	TCP SYN is 1, Source portnumber less than 1024, non sliceIf it is the first message of IP fragmentation, it is necessary to turn on the function to check the high level protocol field.
type8
type9
type9-len	specified length IPv6 fragment	0-65535
type10	Specified slice size
type11	Piecewise ICMP packages
type12	TCP fragments with offset 1 (*8)
type13	TCP's syn and fin set 1A TCP with FIN, URG, and PSH bits, with a sequence of 0.
type14
tcp-len	The first package of TCP less than the specified TCP header length	0-255

9.4. show anti-dos

Command Function

View the anti DOS configuration

Command Format

show anti-dos

Parameter Declaration

10. Shutdown-Control

Configuration

Command

10.1. shutdown-control

Command Function

Boot and configure shutdown rate in physical interface mode

Command Format

shutdown-control <broadcast | multicast|unicast> <rate>

no shutdown-control <broadcast | multicast|unicast>

Parameter Declaration

Parameter	Parameter Declaration	Values
broadcast	Radio broadcast
multicast	Multicast
unicast	unicast
rate	rate	1-32000000 pps

10.2. shutdown-control-recover mode

Command Function

Global configuration recovery method

Command Format

shutdown-control-recover mode < automatic | manual >

no shutdown-control-recover mode

Parameter Declaration

Parameter	Parameter	Values
	Declaration

automatic

Auto recovery

manual

Manual recovery

10.3. shutdown-control-recover automatic-open-time

Command Function

Global configuration auto recovery time

Command Format

shutdown-control-recover automatic-open-time

no shutdown-control-recover automatic-open-time

Parameter Declaration

Parameter

Parameter

Declaration

Values

seconds

5-3600s

10.4. show shutdown-control interface

Command Function

Look at the shutdown-control configuration

Command Format

show shutdown-control interface [ethernet ]

Parameter Declaration

Parameter

Parameter

Declaration

Values

port-list

Port list

11. BPDU-Car Configuration command

11.1. port-car

Command Function

Global or under port switch

Command Format

port-car

no port-car

Parameter Declaration /

11.2. port-car-rate

Command Function

The rate of sending CPU on the global or port configuration BPDU

Command Format

port-car-rate <rate>
no port-car-rate

Parameter Declaration

Parameter

Parameter Declaration

Values

rate

1-128 PPS in port mode 1-3000 PPS in global mode

11.3. show port-car

Command Function

View configuration information

Command Format

show port-car

Parameter Declaration /

12. CPU-Car Configuration Command

12.1. cpu-car

Command Function

The rate of sending CPU on the global configuration

Command Format

cpu-car <rate>

no cpu-car

Parameter Declaration

Parameter

Parameter

Declaration

Values

rate

1-1000 pps default: 800pps

12.2. show cpu-car

Command Function

View the running information

Command Format

show cpu-car

Parameter Declaration

/

12.3. show cpu-statistics

Command Function

Look at the CPU collection statistics

Command Format

show cpu-statistics [ethernet ]

Parameter Declaration

Parameter

Parameter

Declaration

Values

port-list

Port list

12.4. clear cpu-statistics

Command Function

Scavenging CPU collection statistics

Command Format

clear cpu-statistics

Parameter Declaration

/

12.5. show cpu-classification

Command Function

View the CPU collection classification statistics

Command Format

show cpu-classification [interface ethernet ]

Parameter Declaration

Parameter

Parameter

Declaration

Values

port-num

Port Number

12.6. clear cpu-classification

Command Function

Scavenging CPU collection classification statistics

Command Format

clear cpu-classification [interface ethernet ]

Parameter Declaration

Parameter

Parameter

Declaration

Values

port-num

Port Number

12.7. show cpu-utilization

Command Function

Look at the CPU usage rate

Command Format

show cpu-utilization

Parameter Declaration

/

13. Discard-BPDU Configuration Command

13.1. discard-bpdu

Command Function
Global or port configuration discards BPDU messages
Command Format
discard-bpdu
no discard-bpdu
Parameter Declaration
/

13.2. show discard-bpdu

Command Function
View the running information
Command Format
show discard-bpdu
Parameter Declaration
/

14. Anti DHCP configuration command

14.1. dhcp anti-attack

Command Function
Anti attack function switch
Command Format
dhcp anti-attack
no dhcp anti-attack
Parameter Declaration
/

14.2. dhcp anti-attack action

Command Function

Configuration processing

Command Format

dhcp anti-attack action

Parameter Declaration

Parameter	Parameter Declaration	Values
deny-all	Reject all
deny-dhcp	Refusing DHCP

14.3. dhcp anti-attack bind blackhole

Command Function

Binding black hole mac

Command Format

dhcp anti-attack bind blackhole

Parameter Declaration

Parameter	Parameter Declaration	Values
all	All
mac	Specific mac

14.4. dhcp anti-attack threshold

Command Function

Global or port configuration rate threshold

Command Format

dhcp anti-attack threshold

no dhcp anti-attack threshold

Parameter Declaration

Parameter	Parameter Declaration	Values
rate		1-100 pp

14.5. dhcp anti-attack recover-time

Command Function

Configure auto recovery time

Command Format

dhcp anti-attack recover-time

no dhcp anti-attack recover-time

Parameter Declaration

Parameter

Parameter Declaration

Values

time

0-1440 min

14.6. dhcp anti-attack recover

Command Function

Configure manual recovery

Command Format

dhcp anti-attack recover

Parameter Declaration

Parameter

Parameter Declaration

Values

all

A11

mac

Specific mac

14.7. dhcp anti-attack trust

Command Function

Port configuration port is trust port

Command Format

dhcp anti-attack trust no dhcp anti-attack trust

Parameter Declaration

/

14.8. show dhcp anti-attack

Command Function View the running information

Command Format show dhcp anti-attack Parameter Declaration /

14.9. show dhcp anti-attack interface

Command Function View port operation

Command Format show dhcp anti-attack interface [ethernet ] Parameter Declaration /

15. Two level password authentication configuration command

15.1. enable password 0

Command Function Configure the enable password

Command Format enable password 0

Parameter Declaration

Parameter	Parameter
	Declaration	Values
clear	enable password	STRING<1-32>

15.2. enable password 7

Command Function

Configuring encrypted password

Command Format

enable password 7 < encrypt>

Parameter Declaration

Parameter	Parameter Declaration	Values
encrypt	Encrypted cipher	STRING<1-32>

15.3. enable password level

Command Function

Configuring passwords for different levels

Command Format

enable password level <0 |7>

no enable password level

Parameter Declaration

Parameter	Parameter Declaration	Values
id	Level	1-15
0	Enable
7	Encrypted
string	Code	STRING<1-32>

16. DHCP-Snooping Configuration command

16.1. dhcp-snooping

Command function

(no) dhcp-snooping The dhcp-snooping command is configured in global or VLAN mode (delete the dhcp-snooping function)

Command format

dhcp-snooping no dhcp-snooping

Parameter Description

None

16.2. dhcp-snooping trust

Command function

(no) dhcp-snooping trust Command to configure (delete) trust ports in VLAN or port mode

Command format

dhcp-snooping trust no dhcp-snooping trust

Parameter Description

None

16.3. dhcp-snooping fast-remove

Command function

(no) dhcp-snooping fast-remove Command to configure (delete) action of port while port links down

Command format

dhcp-snooping fast-remove no dhcp-snooping fast-remove

Parameter Description

None

16.4. dhcp-snooping max-learn-num

Command function

(no) dhcp-snooping max-learn-num value Command to configure

(restore) the maximum number of users allowed to connect in port or vlan mode

Command format

dhcp-snooping max-learn-num 10

Parameter Description

Parameter	Parameter description	Value range
value	Maximum number of DHCP clients allowed	0-2048

16.5. show dhcp-snooping interface

Command function

show dhcp-snooping interface [ ethernet port-id ]

Command format

show dhcp-snooping interface ethernet 0/0/1

Parameter Description

Parameter	Parameter description	Value range
port-id	Port number	It depends on the physical port of switch, for example, 28 port switches: 0 / 0 / 1 / 0 / 1 / 4

16.6. show dhcp-snooping vlan

Command function

show dhcp-snooping vlan vlan-id

Command format

show dhcp-snooping vlan 2

Parameter Description

Parameter	Parameter description	Value range
vlan-id	VLAN id	1-4094

16.7. show dhcp-snooping clients

Command function

show dhcp-snooping client table items

Command format

show dhcp-snooping clients

Parameter Description

none

17. DHCP-Server Configuration Command

17.1. dhcp-server

Command function

(no) dhcp-server group-id ip-address

command creates and deletes the dhcp server

Command format

dhcp-server 1 192.168.1.1

no dhcp-server 1

Parameter Description

Parameter	Parameter description	Value range
group-id	group number	INTEGER<1-256>
Ip-address	dhcp server address	32 bit binary number in format of X:X:X:X

17.2. dhcp-server ip-pool

Command function

(no) dhcp-server ip-pool pool-name

command creates and deletes the ip pool and enters the ip pool configuration mode.

Command format

dhcp-server ip-pool aa

no dhcp-server ip-pool aa

Parameter Description

Parameter	Parameter description	Value range
pool-name	IP pool name	1-32 characters

17.3. gateway

Command function

gateway ip-address mask mask

Command format

gateway 1.1.1.1 255.255.255.0

Parameter Description

Parameter	Parameter description	Value range
ip-address	Configurable and effective IP addresses	32 bit binary number, format is X:X:X:X
mask	Configure mask	255.0.0.0-255.255.255.252

17.4. section

Command function

(no) section section-id start-ip end-ip

Command to configure (delete) allocatable addresses

Command format

Parameter	Parameter description	Value range
section-id	IP address pool address number	0-7
start-ip	Configurable and effective IP address	32 bit binary number, format is X:X:X:X
end-ip	Configurable and effective IP address	32 bit binary number, format is X:X:X:X

17.5. forbidden-ip

Command function

(no) forbidden-ip ip-address

command configure (delete) whether allow the ip address to be

assigned

Command format

Parameter	Parameter description	Value range
ip-address	Configurable and effective IP addresses	32 bit binary number, format is X:X:X:X

17.6. domain-name

Command function

domain-name name

command is used to configure DNS domain suffixes assigned to

DHCP clients in ip-pool mode

Command format

domain-name test.com

no domain-name

Parameter Description

Parameter	Parameter description	Value range
name	Domain name	STRING<1-32>

17.7. lease

Command function

lease time

command is used to configure the lease expiration function

DHCP IP address in the server interface address pool

Command format

lease 10:00:00

no lease

Parameter Description

Parameter	Parameter description	Value range
time	Lease time	format ddd:hh:mm, no more than 999 days

17.8. option

Command function

option code [ sub-option sub-code ] { ascii ascii-string | hex hex-string |

ip ip-address }

Custom options for configuring the DHCP address pool for the

current interface

Command format

option 22 sub-option 33 ip 1.1.1.1

no option 22 sub-option 33

Parameter Description

Parameter	Parameter description	Value range
code	Option code	INTEGER<4-254>
sub-code	Sub-option code	INTEGER<1-254>
ascii-string	ASCII format string	STRING<1-128>
hex-string	HEX integer	HEX<0-FF>
ip-address	Ip address	32 bit binary number in format of X:X:X:X

17.9. unbind-client

Command function

unbind-client section section-id

configures unbound clients

Command format

unbind-client section 1

no unbind-client section

Parameter Description

Parameter	Parameter description	Value range
section-id	Section id	INTEGER<0-7>

17.10. router

Command function

(no) router ip-address

command to configure (delete)gateway allowed by DHCP Client

Command format

router 1.1.1.1

no router

Parameter Description

Parameter	Parameter description	Value range
ip-address	Configurable and effective IP addresses	32 bit binary number, format is X:X:X:X

17.11. dns-list

Command function

(no)dns-list [ primary-ip | second-ip | third-ip | fourth-ip ] ip-address Command to configure (delete) the DNS server address assigned to the DHCP client

Command format

dns-list fourth-ip 1.1.1.1 no dns-list fourth-ip

Parameter Description

Parameter	Parameter description	Value range
ip-address	Configurable valid IP address	32 bit binary number, format is X:X:X:X

17.12. nbns-list

Command function

(no) nbns-list [ primary-ip | second-ip ] ip-address Command to configure(delete) WINS server address assigned by the DHCP client

Command format

nbns-list second-ip 1.1.1.1 no nbns-list second-ip

Parameter Description

Parameter	Parameter description	Value range
ip-address	Configurable valid IP address	32 bit binary number, format is X:X:X:X

17.13. dhcp-client bind

Command function

(no) dhcp-client bind ip-address mac-address vlan-id user-name

Command to enable (disable) ip address allocation in static bind way.

Command format

dhcp-client bind 1.1.1.1 00:00:00:00:00:06 3

no dhcp-client bind 00:00:00:00:00:06 3

Parameter Description

Parameter	Parameter description	Value range
ip-address	Configurable valid IP address	32 bit binary number, format is X:X:X:X
mac-address	MAC address	128 bit binary number, format is X:X:X:X
vlan-id	VLAN id	1-4094
user-name	user name	1-32 chars

17.14. dhcp-client unbind-assign

Command function

(no)dhcp-client unbind-assign

Command to enable (disable) whether allow allocate ip address

for unbound user

Command format

dhcp-client unbind-assign

Parameter Description

None

17.15. dhcp-server traps

Command function

dhcp-server traps

When the client gets IP address or releases IP address, trap

message is generated

Command format

dhcp-server traps

no dhcp-server traps

Parameter Description

none

17.16. show dhcp-server

Command function

show dhcp-server[group-id]

command to view dhcp server information

Command format

show dhcp-server

Parameter Description

Parameter	Parameter description	Value range
group-id	group number	INTEGER<1-256>

17.17. show dhcp-server interface

Command function

show dhcp-server interface [all]supervlan-interface supervlan-

id|vlan-interface vlan-id]

command to view dhcp server interface information

Command format

show dhcp-server interface all

Parameter Description

Parameter	Parameter description	Value range
supervlan-id	Supervlan id	1-128
vlan-id	Vlan id	1-4094

17.18. show dhcp-server ip-pool

Command function

show dhcp-server ip-pool [brief | [pool-name] section-id ]

Command to view the configured ip pool

Command format

show dhcp-server ip-pool pool1 1

Parameter Description

Parameter	Parameter description	Value range
pool-name	IP-pool name	1-32 character
section-id	IP Address pool address number	0-7

17.19. show dhcp-server clients

Command function

show dhcp-server clients [ip-address [mask] | pool-name | mac-address]

Command to view the ip address information obtained by the client

Command format

show dhcp-server clients

Parameter Description

Parameter	Parameter description	Value range
ip-address	Configurable and effective IP addresses	32 bit binary number, format is X:X:X
mask	Configure mask	255.0.0.0-255.255.255.252
pool-name	IP-pool name	1-32 characters
mac-address	MAC address	128 bit binary number, format is X:X:X:X:X:X

17.20. show dhcp-client bind

Command function

show dhcp-client bind [ip-address | mac-address | all]

Command to see if unbound users are allowed to assign ip addresses

Command format

show dhcp-client bind 00:00:00:00:00:06

Parameter Description

Parameter	Parameter description	Value range
ip-address	Configurable valid IP address	32 bit binary number, format is X:X:X:X
mac-address	MAC Address	128 bit binary number, format is X:X:X:X:X:X

18. DHCP-Relay Configuration Command

18.1. dhcp-relay

Command function

(no) dhcp-relay

command switch DHCP relay function

Command format

dhcp-relay

no dhcp-relay

Parameter Description

None

18.2. dhcp-relay hide server-ip

Command function

(no) dhcp-relay hide server-ip

Command to enable(disable) TP of Real DHCP Serve

Command format

dhcp-relay hide server-ip

no dhcp-relay hide server-ip

Parameter Description

None

18.3. dhcp-relay max-hops

Command function

(no) dhcp-relay max-hops hops-value

command to configure (delete) the maximum number of hops of the DHCP message

Command format

dhcp-relay max-hops 1

no dhcp-relay max-hops

Parameter Description

Parameter	Parameter description	Value range
hops-value	default to 8 hops	1-16

18.4. dhcp-relay source-ip

Command function

dhcp-relay source-ip [ egress | ingress ]

Command to configure the relay message using the source IP

Command format

dhcp-relay source-ip egress

Parameter Description

Parameter	Parameter	Value range
	description
egress	Server IP address egress	none
ingress	Server IP address ingress	none

18.5. show dhcp-relay

Command function

show dhcp-relay information

Command format

show dhcp-relay

Parameter Description

None

19. DHCP Option82 Configuration Command

19.1. dhcp-option82

Command function

(no) dhcp-option82

Command global switch

Command format

dhcp-option82

Parameter Description

none

19.2. dhcp-option82 device-id

Command function

(no) dhcp-option82 device-id

Command to configure (Delete) whether Suboption has Device

number information

Command format

dhcp option82 device-id

Parameter Description

None

19.3. dhcp-option82 format

Command function

dhcp-option82 format [ normal | verbose| user-defined ]

Command to configure (delete) DHCP option82 format.

Command format

dhcp-option82 format user-defined

Parameter Description

none

19.4. dhcp-option82 format verbose

Command function

dhcp-option82 format verbose [node-identifier[host-name|mac] user-defined defined -string]

Command to configure (delete)user-defined format of verbose format

Command format

dhcp-option82 format user-defined verbose node-identifier user-defined string

Parameter Description

Parameter	Parameter description	Value range
defined -string	User-defined format number	1-60 characters

19.5. dhcp-option82 information format

Command function

dhcp-option82 information format [ascii | hex ]

command to configure(delete) encapsulation format of verbose

format

Command format

dhcp-option82 information format ascii

no dhcp-option82 information format

Parameter Description

none

19.6. dhcp-option82 strategy

Command function

dhcp-option82 strategy [ drop | keep | replace ]

Command to configure (delete) process mode of DHCP messages

with Option 82 fields in port or VLAN mode

Command format

dhcp-option82 strategy replace

no dhcp-option82 strategy

Parameter Description

Parameter	Parameter description	Value range
drop	Discard messages from DHCPoption 82	none
keep	Keep the message for DHCP option 82	none
replace	Replace messages with DHCPoption 82	none

19.7. dhcp-option82 circuit-id user-defined

Command function

dhcp-option82 circuit-id user-defined string

Command to configure (delete) user-defined circuit-id in port or VLAN mode

Command format

dhcp-option82 circuit-id user-defined string

no dhcp-option82 circuit-id user-defined

Parameter Description

Parameter	Parameter description	Value range
string	User-defined format number	1-128 characters

19.8. dhcp-option82 remote-id user-defined

Command function

dhcp-option82 remote-id user-defined string

Command to configure(delete) user-defined remote-id in port or VLAN mode

Command format

dhcp-option82 remote-id user-defined string

no dhcp-option82 remote-id user-defined

19.9. show dhcp-option82

Command function

show dhcp-option82 [vlan [vlan-id] | interface ethernet port-id ]

Command format

show dhcp-option82 interface ethernet 0/0/1

Parameter Description

Parameter	Parameter description	Value range
vlan-id	vlan id	1-4094
port-id	Port id	Depending on the physical port of the switch, for example, 28 port switch: 0 / 0 / 1 / - 0 / 1 / 4

20. DHCPv6-Snooping Configuration

Command

20.1. dhcpv6-snooping

Command function

(no) dhcpv6-snooping

Command format

dhcpv6-snooping

no dhcpv6-snooping

Parameter Description

None

20.2. dhcpv6-snooping trust

Command function

(no) dhcpv6-snooping trust

Command to configure (delete) trust port in VLAN or port mode.

Command format

dhcpv6-snooping trust

no dhcpv6-snooping trust

Parameter Description

None

20.3. dhcpv6-snooping port-down-action fast-remove

Command function

(no) dhcpv6-snooping port-down-action fast-remove

Command to configure (delete) action of port while it links down.

Command format

dhcpv6-snooping port-down-action fast-remove

no dhcpv6-snooping port-down-action fast-remove

Parameter Description

None

20.4. dhcpv6-snooping max-clients

Command function

(no) dhcpv6-snooping max-clients value

Command to configure (restore) the maximum number of users allowed to connect in port or vlan mode

Command format

dhcpv6-snooping max-clients 2

Parameter Description

Parameter	Parameter description	Value range
value	Maximum number of DHCP clients allowed	0-2048

20.5. show dhcpv6-snooping clients

Command function

show dhcpv6-snooping clients

Command to view dhcpv6-snooping client table entries

Command format

show dhcpv6-snooping clients

Parameter Description

None

20.6. show dhcpv6-snooping interface

Command function

show dhcpv6-snooping interface [ ethernet port-id ]

Command to view the DHCPV6-Snooping port configuration

Command format

show dhcpv6-snooping interface

Parameter Description

Parameter	Parameter description	Value range
port-id	Port id	Depending on the physical port of the switch, for example, 28 port switches: 0 / 0 / 1 /- 0 / 1 / 4

20.7. show dhcpv6-snooping vlan

Command function

show dhcpv6-snooping vlan vlan-id

Command format

show dhcpv6-snooping vlan 2

Parameter Description

Parameter	Parameter description	Value range
vlan-id	VLAN id	1-4094

20.8. clear dhcpv6-snooping

Command function

clear dhcpv6-snooping [ ip ipv6-address| mac mac| vlan vid |

interface ethernet port-id ]

Command to delete dynamic table entries from DIICPv6 Snooping records

Command format

clear dhcpv6-snooping ip 2::1

Parameter Description

Parameter	Parameter description	Value range
lpv6-address	a valid ipv6 address can be configured	128-bit binary in X:X:X:X:X:X:X format
mac	Mac address	48-bit binary in X:X:X:X:X:X format
vid	VLAN id	1-4094
port-id	Port id	Depending on the physical port of the switch, for example, 28 port switches: 0 / 0 / 1 / - 0 / 1 / 4

21. DHCPv6 Option18 configuration command

21.1. dhcpv6-snooping information option 18

Command function

(no) dhcpv6-snooping information option 18

Command to enable (disable) DHCPV6 Option18

Command format

dhcpv6-snooping information option 18

no dhcpv6-snooping information option 18

Parameter Description

None

dhcpv6-snooping information interface-id

21.2. dhcpv6-snooping information interface-id

Command function

(no) dhcpv6-snooping information interface-id[hostname|ipv4-

address ipv4-address|ipv6-address ipv6-address|string string|user-

defined user-defined]

command is used to configure DHCPv6 format of Interface-ID

options in the message

Command format

dhcpv6-snooping information interface-id user-defined sysip

no dhcpv6-snooping information interface-id

Parameter Description

Parameter	Parameter description	Value range
Ipv4-address	Ipv4 address	32 bit binary number in format of X:X:X:X
Ipv6-address	a valid ipv6 address can be configured	128 bit binary number in format of X:X::X:X
string	string	STRING<1-64>
User-defined	User defined	STRING<1-128>

21.3. show dhcpv6-snooping information

Command function

show dhcpv6-snooping information

command to show DHCPv6 Option18

Command format

show dhcpv6-snooping information

Parameter Description

None

22. DHCPv6 Option37 Configuration command

22.1. dhcpv6-snooping information option 37

Command function

(no) dhcpv6-snooping information option 37

command to enable (disable) DHCPV6 Option37

Command format

dhcpv6-snooping information option 37

no dhcpv6-snooping information option 37

Parameter Description

None

22.2. dhcpv6-snooping information remote-id

Command function

(no) dhcpv6-snooping information remote-id [hostname | ipv4-

address ipv4-address| ipv6-address ipv6-address| string string |

user-defined user-defined] Command to enable (disable) DHCPv6

Remote TD content.

Command format

dhcpv6-snooping information remote-id ipv6-address 1::1

no dhcpv6-snooping information remote-id

Parameter Description

Parameter	Parameter description	Value
hostname	hostname	none
ipv4-address	Configurable valid IP address	32-bit binary in X:X:X:X format
lpv6-address	Configurable valid IPv6 address	128-bit binary in X:X:X:X:X:X:X format
string	User-defined string	1--64 Character
user-defined	Use-defined format alphabetic string	1--128 Character

22.3. show dhcpv6-snooping information

Command function

show dhcpv6-snooping information

Command to show DHCPv6 Option37

Command format

show dhcpv6-snooping information

Parameter Description

None

23. File download configuration command

23.1. load application xmodem

Command function

load application xmodem

Command to use xmodem to download the host program

Command format

load application xmodem

Parameter description

None

23.2. load application tftp

Command function

load application tftp inet[6] server-ip xxx.arj

Command to use tftp to download the host program

Command format

load application tftp inet 1.1.1.1 host.arj

load application tftp inet6 2001::1 host.arj

Parameter description

Parameter	Parameter description	Value
server-ip	Tftp server ip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X

23.3. load application ftp

Command function

load application ftp inet[6] server-ip xxx.arj username password

Command to use ftp to download the host program

Command format

load application ftp inet 1.1.1.1 host.arj admin admin

load application ftp inet6 2001::1 host.arj admin admin

Parameter description

Parameter	Parameter description	Value
server-ip	ftp server ip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X
username	ftp server username	STRING<1-64>
password	ftp server password	STRING<1-32>

23.4. load whole-bootrom xmodem

Command function

load whole-bootrom xmodem

Command to use xmodem to download the bootrom program

Command format

load whole-bootrom xmodem

Parameter description

None

23.5. load whole-bootrom tftp

Command function

load whole-bootrom tftp inet[6] server-ip xxx.bin

Command to use tftp to download the bootrom program

Command format

load whole-bootrom tftp inet 1.1.1.1 bootrom.bin

load whole-bootrom tftp inet6 2001::1 bootrom.bin

Parameter description

Parameter	Parameter description	Value
server-ip	tftp serverip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X

23.6. load whole-bootrom ftp

Command function

load whole-bootrom ftp inet[6] server-ip xxx.bin username password

Command to use ftp to download the bootrom program

Command format

load whole-bootrom ftp inet 1.1.1.1 bootrom.bin admin admin

load whole-bootrom ftp inet6 2001::1 bootrom.bin admin admin

Parameter description

Parameter	Parameter description	Value
server-ip	ftp serverip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X
username	ftp serverusername	STRING<1-64>
password	Ftp server password	STRING<1-32>

23.7. load configuration xmodem

Command function

load configuration xmodem

Command to use xmodem to download configuration files

Command format

load configuration xmodem

Parameter description

None

23.8. load configuration tftp

Command function

load configuration tftp inet[6] server-ip xxx

Command to use tftp to download configuration files

Command format

load configuration tftp inet 1.1.1.1 config

load configuration tftp inet6 2001::1 config

Parameter description

Parameter	Parameter description	Value
server-ip	ftp server ip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X

23.9. load configuration ftp

Command function

load configuration ftp inet[6] server-ip xxx username password

Command to use ftp to download configuration files

Command format

load configuration ftp inet 1.1.1.1 config admin admin

load configuration ftp inet6 2001::1 config admin admin

Parameter description

Parameter	Parameter description	Value
server-ip	ftp server ip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X
username	ftp server username	STRING<1-64>
password	ftp server password	STRING<1-32>

23.10. load keyfile private tftp

Command function

load keyfile private tftp inet[6] server-ip private.txt

Command to use tftp for private key download

Command format

load keyfile private tftp inet 1.1.1.1 private.txt

load keyfile private tftp inet6 2001::1 private.txt

Parameter description

Parameter	Parameter description	Value
server-ip	tftp server ip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X

23.11. load keyfile private ftp

Command function

load keyfile private ftp inet[6] server-ip private.txt username password

Command to use ftp for private key download

Command format

load keyfile private ftp inet 1.1.1.1 private.txt admin admin

load keyfile private ftp inet6 2001::1 private.txt admin admin

Parameter description

Parameter	Parameter description	Value
server-ip	ftp serverip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X
username	ftp serverusername	Any character available
password	ftp serverpassword	Any character available

23.12. load keyfile public tftp

Command function

load keyfile public tftp inet[6] server-ip public.txt

Command to use tftp for public key download

Command format

load keyfile public tftp inet 1.1.1.1 public.txt

load keyfile public tftp inet6 2001::1 public.txt

Parameter description

Parameter	Parameter description	Value
server-ip	tftp serverip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X

23.13. load keyfile public ftp

Command function

load keyfile public ftp inet[6] server-ip public.txt username password

Command to use ftp for public key download

Command format

load keyfile public ftp inet 1.1.1.1 public.txt admin admin

load keyfile public ftp inet6 2001::1 public.txt admin admin

Parameter description

Parameter	Parameter	Value
	description
server-ip	ftp serverip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X
username	ftp serverusername	STRING<1-64>
password	ftp serverpassword	STRING<1-32>

24. file upload configuration command

24.1. upload application ftp

Command function

upload application ftp inet[6] server-ip xxx.arj username password Command to use ftp method for host program upload

Command format

upload application ftp inet 1.1.1.1 host.arj admin admin upload application ftp inet6 2001::1 host.arj admin admin

Parameter description

Parameter	Parameter description	Value
server-ip	ftp server ip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X
username	ftp server username	STRING<1-64>
password	ftp server password	STRING<1-32>

24.2. upload application tftp

Command function

upload application tftp inet[6] server-ip xxx.arj Command to use tftp method for host program upload

Command format

upload application tftp inet 1.1.1.1 host.arj upload application tftp inet6 2001::1 host.arj

Parameter description

Parameter	Parameter description	Value
server-ip	tftp server ip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X

24.3. upload logging ftp

Command function

upload logging ftp inet[6] server-ip log.txt username password

Command to use ftp method for log files upload

Command format

upload logging ftp inet 1.1.1.1 log.txt admin admin

upload logging ftp inet6 2001::1 log.txt admin admin

Parameter description

Parameter	Parameter description	Value
server-ip	ftp server ip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X
username	ftp server username	STRING<1-64>
password	ftp server password	STRING<1-32>

24.4. upload logging tftp

Command function

upload logging tftp inet[6] server-ip log.txt

Command to use tftp method for log files upload

Command format

upload logging tftp inet 1.1.1.1 log.txt

upload logging tftp inet6 2001::1 log.txt

Parameter description

Parameter	Parameter description	Value
server-ip	tftp server ip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X

24.5. copy running-config startup-config

Command function

copy running-config startup-config

Command to save the current configuration to flash

Command format

copy running-config startup-config

Parameter description

None

24.6. upload configuration ftp

Command function

upload configuration ftp inet[6] server-ip config.txt username password

Command to use ftp method for configuration files upload

Command format

upload configuration ftp inet 1.1.1.1 config.txt admin admin

upload configuration ftp inet6 2001::1 config.txt admin admin

Parameter description

Parameter	Parameter description	Value
server-ip	ftp server ip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X
username	ftp server username	STRING<1-64>
password	ftp server password	STRING<1-32>

24.7. upload configuration tftp

Command function

upload configuration tftp inet[6] server-ip config.txt

Command to use tftp method for configuration files upload

Command format

upload configuration tftp inet 1.1.1.1 config.txt

upload configuration tftp inet6 2001::1 config.txt

Parameter description

Parameter	Parameter description	Value
server-ip	tftp server ip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X

24.8. upload automatically configuration ftp

Command function

upload automatically configuration ftp inet[6] server-ip config.txt username

password per hours hours-num minutes minutes -num

Command to use ftp method for automatically configuration files upload

Command format

upload automatically configuration ftp inet 1.1.1.1 config.txt admin admin

per hours 1 minutes 5

upload automatically configuration ftp inet6 2001::1 config.txt admin admin

per hours 1 minutes 5

Parameter description

Parameter	Parameter description	Value
server-ip	ftp server ip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X
username	ftp server username	STRING<1-64>
password	ftp server password	STRING<1-32>
hours-num	Interval hour	0-23
minutes -num	Interval minutes	5-59

24.9. upload automatically configuration tftp

Command function

upload automatically configuration tftp inet[6] server-ip config.txt per hours

hours-num minutes minutes -num

Command to use tftp method for automatically configuration files

upload

Command format

upload automatically configuration tftp inet 1.1.1.1 config.txt per hours 1

minutes 5

upload automatically configuration tftp inet6 2001::1 config.txt per hours 1

minutes 5

Parameter description

Parameter	Parameter description	Value
server-ip	tftp server ip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X
hours-num	Interval hour	0-23
minutes -num	Interval minutes	5-59

24.10. upload keyfile private tftp

Command function

upload keyfile private tftp inet[6] server-ip private.txt

Command to use tftp method for private key upload

Command format

upload keyfile private tftp inet 1.1.1.1 private.txt

upload keyfile private tftp inet6 2001::1 private.txt

Parameter description

Parameter	Parameter description	Value
server-ip	tftp server ip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X

24.11. upload keyfile private ftp

Command function

upload keyfile private ftp inet[6] server-ip private.txt username password

Command to use ftp method for private key upload

Command format

upload keyfile private ftp inet 1.1.1.1 private.txt admin admin upload keyfile private ftp inet6 2001::1 private.txt admin admin

Parameter description

Parameter	Parameter description	Value
server-ip	ftp server ip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X
username	ftp server username	STRING<1-64>
password	ftp server password	STRING<1-32>

24.12. upload keyfile public tftp

Command function

upload keyfile public tftp inet[6] server-ip public.txt Command to use tftp method for private key upload

Command format

upload keyfile public tftp inet 1.1.1.1 public.txt upload keyfile public tftp inet6 2001::1 public.txt

Parameter description

Parameter	Parameter description	Value
server-ip	tftp server ip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X

24.13. upload keyfile public ftp

Command function

upload keyfile public ftp inet[6] server-ip public.txt username password Command to use tftp method for public key upload

Command format

upload keyfile public ftp inet 1.1.1.1 public.txt admin admin

upload keyfile public ftp inet6 2001::1 public.txt admin admin

Parameter description

Parameter	Parameter description	Value
server-ip	ftp server ip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X
username	ftp server username	STRING<1-64>
password	ftp server password	STRING<1-32>

25. configuration management command

25.1. show running-config

Command function

show running-config [module | interface ethernet port-id|perlines lines]

Command to view the current configuration decompilation

Command format

show running-config if

show running-config interface ethernet 0/0/1

show running-config perlines 3

Parameter description

Parameter	Parameter description	Value
module	Various business types	Determined according to the switch feature module
port-id	The port number	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4
lines	Display several lines at a time	0-4096

25.2. show startup-config

Command function

show startup-config [module | perlines lines]

Command to view startup configuration

Command format

show startup-config if

show startup-config perlines 3

Parameter description

Parameter	Parameter description	Value
module	Various business types	Determined according to the switch feature module
lines	Display several lines at a time	0-4096

25.3. copy startup-config running-config

Command function

copy startup-config running-config

Command line load startup configuration in privileged mode

Command format

copy startup-config running-config

Parameter description

None

25.4. clear startup-config

Command function

clear startup-config [ with user-info]

Command to clear startup configuration

Command format

clear startup-config

clear startup-config with user-info

Parameter description

None

26. Active and standby file system configuration command

26.1. load secondary application tftp

Command function

load secondary application tftp inet[6] server-ip xxx.arj

Command to use tftp to download the host program

Command format

load secondary application tftp inet 1.1.1.1 host.arj

load secondary application tftp inet6 2001::1 host.arj

Parameter description

Parameter	Parameter description	Value
server-ip	tftp server ip/ipv6 address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X

26.2. load secondary application ftp

Command function

load secondary application ftp inet[6] server-ip xxx.arj username password

Command to use ftp to download the host program

Command format

load secondary application ftp inet 1.1.1.1 host.arj admin admin

load secondary application ftp inet6 2001::1 host.arj admin admin

Parameter description

Parameter	Parameter description	Value
server-ip	ftp server ip/ipv6address	32-bit binary number in the format X.X.X.X128-bit binary number in the formatX:X:X:X:X:X:X:X
username	ftp server username	Any character available
password	ftp server password	Any character available

26.3. startup secondary application

Command function

startup secondary application

Command to enable standby host program

no startup secondary application

Command to resume enabling host program

Command format

startup secondary application

no startup secondary application

Parameter description

None

27. Port mirror configuration command

27.1. mirror source

Command function

mirror source [ethernet port-id | cpu ] [ingress | egress | both]

Command to configure mirror source

Command format

mirror source ethernet 0/0/1 both

Parameter Description

Parameter	Parameter description	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28- port- switch: 0 / 0 / 1 - 0 / 1 / 4

27.2. mirror monitor ethernet

Command function

mirror monitor ethernet port-id

Command to configure mirroring destination port

Command format

mirror monitor ethernet 0/0/2

Parameter Description

Parameter	Parameter description	Value range
port-id	Port-id	Depend on the physical port of the switch, for example, 28- port- switch: 0 / 0 / 1 - 0 / 1 / 4

27.3. no mirror

Command function

no mirror [all | monitor ethernet port-id | source [cpu | ethernet

port-id ]]

Command to configure delete mirroring groups

Command format

no mirror source ethernet 0/0/1

Parameter Description

Parameter	Parameter description	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28- port- switch: 0 / 0 / 1 - 0 / 1 / 4

27.4. show mirror

Command function

show mirror

Command to view mirroring groups

Command format

show mirror

Parameter Description

None

28. Remote mirror configuration command

28.1. mirror source

Command function

mirror source [ethernet port-id | cpu ] [ingress | egress | both]

Command to configure mirror source

Command format

mirror source ethernet 0/0/1 both

Parameter Description

Parameter	Parameter description	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28- port- switch: 0 / 0 / 1 - 0 / 1 / 4

28.2. mirror monitor ethernet

Command function

mirror monitor ethernet port-id

Command to configure Mirror destination port.

Command format

mirror monitor ethernet 0/0/2

Parameter Description

Parameter	Parameter description	Value range
port-id	Port-id	Depend on the physical port of the switch, for example, 28- port- switch: 0 / 0 / 1 - 0 / 1 / 4

28.3. remote\_mirror rspan local vlan

Command function

remote_mirror rspan local vlan vlan-id

Command to configure remote mirror on the local mirror destination

port mode

vlan

Command format

remote_mirror rspan local vlan 33

Parameter Description

Parameter	Parameter description	Value range
vlan-id	Get vlan id	1-4094

28.4. no remote\_mirror rspan local

Command function

no remote_mirror rspan local vlan

Command to delete the remote mirror on the local mirror destination

port

Command format

no remote_mirror rspan local vlan

Parameter Description

Parameter	Parameter description	Value range
vlan-id	Get vlan id	1-4094

28.5. remote\_mirror rspan middle vlan

Command function

remote_mirror rspan middle vlan vlan-id

Command to configure remote mirror vlan for middle devices

Command format

remote_mirror rspan middle vlan 12

Parameter Description

Parameter	Parameter description	Value range
vlan-id	Get vlan id	1-4094

28.6. no remote\_mirror rspan midd le vlan

Command function

no remote_mirror rspan middle vlan vlan-id

Command to delete the remote mirror vlan for the middle device.

Command format

no remote_mirror rspan middle vlan 12

Parameter Description

Parameter	Parameter description	Value range
vlan-id	Get vlan id	1-4094

28.7. remote\_mirror rspan target vlan

Command function

remote_mirror rspan target vlan vlan-id

Command to configure the remote mirror vlan for the target device

Command format

remote_mirror rspan target vlan 12

Parameter Description

Parameter	Parameter description	Value range
vlan-id	Get vlan id	1-4094

28.8. no remote\_mirror rspan target vlan

Command function

no remote_mirror rspan target vlan vlan-id

Command to remove the remote mirror vlan from the target device

Command format

no remote_mirror rspan target vlan 12

Parameter Description

Parameter	Parameter description	Value range
vlan-id	Get vlan id	1-4094

28.9. remote\_mirror rspan parse vlan

Command function

remote_mirror rspan parse vlan vlan-id

Command to configure the remote mirror vlan for theparse device

Command format

remote_mirror rspan parse vlann 12

Parameter Description

Parameter	Parameter description	Value range
vlan-id	Get vlan id	1-4094

28.10. no remote\_mirror rspan parse vlan

Command function

no remote_mirror rspan parse vlan vlan-id

Command to remove the remote mirror vlan from the parse device

Command format

no remote_mirror rspan parse vlan 12

Parameter Description

Parameter	Parameter description	Value range
vlan-id	Get vlan id	1-4094

28.11. show remote\_mirror

Command function

show remote_mirror

Command to view remote mirror group

Command format

show remote_mirror

Parameter Description

None

29. Configure flow mirror

29.1. mirrored-to

Command function

mirrored-to [ hybrid-acl <2000-2999> | ip-acl<1-999> | mac-acl<1000-

1999> ] [subitem <0-127> | interface ethernet port-id ]

Command to configure stream mirror

Command format

mirrored-to mac-acl 1000 subitem 2 interface ethernet 0/0/1

Parameter Description

Parameter	Parameter description	Value range
port-id	Port-id	Depend on the physical port of the switch, for example, 28- port- switch: 0 / 0 / 1 - 0 / 1 / 4

29.2. no mirrored-to

Command function

no mirrored-to [ hybrid-acl <2000-2999> | ip-acl<1-999> | mac-acl<1000-1999> ] [subitem <0-127> ] Command to delete flow mirror

Command format

no mirrored-to mac-acl 1000 subitem 2

Parameter Description

None

29.3. show qos-info mirrored-to

Command function

show qos-info mirrored-to Command to view flow mirror

Command format

show qos-info mirrored-to

Parameter Description

None

30. RMON configuration command

30.1. rmon statistics

Command function

rmon statistics index [ owner string ] Command to create a statistics group in port mode

Command format

rmon statistics 1 owner 1

Parameter Description

Parameter	Parameter description	Value range
index	Table index	1-65535
string	Description string	1-127 character

30.2. no rmon statistics

Command function

no rmon statistics [index]

Command to delete statistic group in port mode

Command format

no rmon statistics 1

Parameter Description

Parameter	Parameter description	Value range
index	Table index	1-65535

30.3. rmon history

Command function

rmon history index bucket bucket-num interval value [owner string]

Command to create a history group in port mode

Command format

rmon history 1 buckets 1 interval 1 owner string

Parameter Description

Parameter	Parameter description	Value range
index	Table index	1-65535
bucket-num	Recorded number value	1-65535
value	Sample interval (seconds)	1-3600
string	Description string	1-127 character

30.4. no rmon history

Command function

no rmon history[index]

Command to delete a history group in port mode

Command format

no rmon history 1

Parameter Description

Parameter	Parameter description	Value range
index	Table index	1-65535

30.5. show rmon statistics interface

Command function

show rmon statistics interface [ethernet port-id]

Command to Statistic Group Information View

Command format

show rmon statistics interface ethernet 0/0/1

Parameter Description

Parameter	Parameter description	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28- port- switch: 0 / 0 / 1 - 0 / 1 / 4

30.6. show rmon history interface

Command function

show rmon history interface [ethernet port-id]

Command to view history group information

Command format

show rmon history interface ethernet 0/0/1

Parameter Description

Parameter	Parameter description	Value range
port-id	Port-id	Depend on the physical port of the switch, for example, 28- port- switch: 0 / 0 / 1 - 0 / 1 / 4

30.7. rmon event

Command function

rmon event index [ description string ] [ log | log-trap | trap | none ]

[ owner string ]

Command to Create event table item in global mode.

Command format

rmon event 1 description 2 log owner string

Parameter Description

Parameter	Parameter description	Value range
index	Table index	1-65535
string	Description string	1-127 character

30.8. no rmon event

Command function

no rmon event [index]

Command to delete event table items in global mode

Command format

no rmon event 1

Parameter Description

Parameter	Parameter description	Value range
index	Table index	1-65535

30.9. show rmon event

Command function

show rmon event [ event | eventlog ] [index]

Command history group information view

Command format

show rmon eventlog 1

Parameter Description

Parameter	Parameter description	Value range
index	Table index	1-65535

30.10. rmon alarm

Command function

rmon alarm index mib-oid value [ absolute | delta ] rising threshold-

value index falling threshold-value index [ owner string ]

Command to create alarm groups in global mode

Command format

rmon alarm 1 1.3.6.1.2.1.16.1.1.1.5 1 absolute rising 3 2 falling 2 2

owner string

Parameter Description

Parameter	Parameter	Value range
	description
index	Table index	1-65535
mib-oid	MIB object identity (for example: 1.3.6.1.2.1.16.1.1 .1.5.1)	1-127 character
value	Sample interval (seconds)	1-3600
threshold-value	Threshold value of sample statistics	1-2147483647
string	Description string	1-127 character

30.11. no rmon alarm

Command function

no rmon alarm [index]

Command to delete alarm groups in global mode

Command format

no rmon alarm 1

Parameter Description

Parameter	Parameter description	Value range
index	Table index	1-65535

30.12. show rmon alarm

Command function

show rmon alarm [index]

Command alarm Group Information View

Command format

show rmon alarm 1

Parameter Description

Parameter	Parameter description	Value range
index	Table index	1-65535

31. Bandwidth-Control configuration command

31.1. bandwidth

Command function

(no)bandwidth [ ingress [percentage value] | egress [percentage value] ] rate

Command in port module Bandwidth limit for configuring or deleting

outgoing and incoming directions

Command format

bandwidth egress 64

bandwidth egress percentage 12

no bandwidth egress

Parameter description

Parameter	Parameter Description	Value
value	Percentage of port	(1-99)%
rate	Specific bandwidth limit	16-1000000

31.2. show bandwidth

Command function

show bandwidth [ ethernet port-id]

Command to view port bandwidth limit information

Command format

show bandwidth ethernet 0/0/2

show bandwidth

Parameter Description

Parameter	Parameter Description	Value
port-id	The port number	According to the physical port of the switch, for example 28 ports: 0/0/1-0/1/4

32. MAC-address-management- configuration command

32.1. mac-address-table age-time

Command function

mac-address-table age-time [second| disable]

Command to configure or disable MAC address aging time

no mac-address-table age-time

Command to restore the default MAC address aging time

Command format

mac-address-table age-time 10

mac-address-table age-time disable

no mac-address-table age-time

Parameter Description

Parameter	Parameter Description	Value
second	MAC address aging time in seconds. The default is 300s.	10-1000000

32.2. mac-address-table

Command function

mac-address-table [static | permanent | dynamic] mac-add interface

ethernet port-id vlan

vlan-id

Command to manually add the MAC address table

no mac-address-table [static | permanent | dynamic] mac-add interface

ethernet port-id

vlan vlan-id

Manually delete the MAC address table

Command format

mac-address-table static 2:2:2:2:2 interface ethernet 0/0/1 vlan 2

no mac-address-table static 2:2:2:2:2:2 interface ethernet 0/0/1 vlan 2

Parameter Description

Parameter	Parameter Description	Value
mac-add	MAC address	48-bit binary number in the format X:X:X:X:X:X
port-id	The number port	According to the physical port of the switch, for example 28 ports: 0/0/1-0/1/4
vlan-id	Set vlan id	1-4094

32.3. mac-address-table blackhole

Command function

mac-address-table blackhole mac-add vlan vlan-id

Command to manually add the blackhole MAC address table

no mac-address-table blackhole mac-add vlan vlan-id

Command to manually delete the blackhole MAC address table

Command format

mac-address-table blackhole 2:2:2:2:2:2 vlan 1

no mac-address-table blackhole 2:2:2:2:2:2 vlan 1

Parameter Description

Parameter	Parameter Description	Value
mac-add	MAC address	48-bit binary number in the formatX:X:X:X:X:X
vlan-id	Set vlan id	1-4094

32.4. mac-address-table learning

Command function

(no) mac-address-table learning

Command to switch mac address learning globally or port

Command format

mac-address-table learning

no mac-address-table learning

Parameter Description

None

32.5. mac-address-table max-mac-count

Command function

mac-address-table max-mac-count count

Port or vlan mode configuration port learns the number of MAC

addresses

Command format

mac-address-table max-mac-count 1

Parameter Description

Parameter	Parameter Description	Value
count	Number of MAC address	1-8191

32.6. no mac-address-table max-mac-count

Command function

no mac-address-table max-mac-count

Port or vlan mode deletes the number of learned MAC addresses

Command format

no mac-address-table max-mac-count

Parameter Description

none

32.7. show mac-address max-mac-count

Command function

Show mac-address max-mac-count [ interface ethernet port-id | vlan vlan-id ]

View the number of MACs that can be learned on the port, aggregation group, or VLAN.

Command format

Show mac-address-table max-mac-count vlan 1

Show mac-address-table max-mac-count interface ethernet 0/0/2

Parameter Description

Parameter	Parameter Description	Value
port-id	The number port	According of the physical port of the switch, for example 28-port switch: 0/0/1-0/1/4
vlan-id	Set vlan id	1-4094

32.8. show mac-address-table age-time

Command function

show mac-address-table age-time

Command to view the MAC address aging time

Command format

show mac-address-table age-time

Parameter Description

None

32.9. show mac-address-table

Command function

show mac-address-table [static | permanent | dynamic | blackhole | vlan]

mac-add interface [ethernet | eth-trunk] port-id vlan vlan-id

Command to view the MAC address table

Command format

show mac-address-table static interface ethernet 0/0/1 vlan 1

Parameter Description

Parameter	Parameter Description	Value
mac-add	MAC address	48-bit binary number in the format X:X:X:X:X:X
port-id	The number port	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4
vlan-id	Set vlan id	1-4094

32.10. show mac-address learning

Command function

show mac-address learning interface [ethernet port-id]

Command to view the MAC address learning status, the default is open

Command format

show mac-address learning interface

show mac-address learning interface ethernet 0/0/1

Parameter Description

Parameter	Parameter Description	Value
port-id	The number	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4

32.11. show mac-address cpu

Command function

show mac-address cpu

Command to view cpu mac address

Command format

show mac-address cpu

Parameter Description

None

33. DLF-Control configuration command

33.1. unknown-discard unicast

Command function

(no)unknown-discard unicast

Command to switch the unknown unicast forwarding function in port

mode

Command format

unknown-discard unicast no unknown-discard unicast

Parameter Description

None

33.2. unknown-discard multicast vlan

Command function

(no)unknown-discard multicast vlan vlan-id [ethernet port-id]

Command to Switch Unknown Multicast Based on vlan and Port

Forwarding in Global Mode

Command format

unknown-discard multicast vlan 1 no unknown-discard multicast vlan 1

Parameter Description

Parameter	Parameter Description	Value
port-id	The number port	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4
vlan-ID	Vlan	1-4094

33.3. unknown-discard multicast

Command function

(no)unknown-discard multicast

Command to Switch Unknown Multicast Forwarding in Port Mode

Command format

unknown-discard multicast

no unknown-discard multicast

Parameter Description

None

33.4. show unknown-discard

Command function

show unknown-discard [ethernet|vlan vlan-id]

Command to view unknown unicast and multicast configurations

Command format

show unknown-discard ethernet 0/0/1

show unknown-discard vlan 1

Parameter Description

Parameter	Parameter Description	Value
vlan-id	Set vlan id	1-4094

34. Local-Switch configuration command

34.1. local-switch

Command function

(no)local-switch

Command to switch Local-switch under port

Command format

local-switch

no local-switch

Parameter Description

None

34.2. show local-switch

Command function

show local-switch [interface ethernet port-id]

Command view local-switch configuration

Command format

show local-switch

show local-switch interface ethernet 0/0/1

Parameter Description

Parameter	Parameter	Value
	Description
port-id	The number port	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4

35. SLF-Control configuration command

35.1. unknown-discard src-mac

Command function

(no)unknown-discard src-mac

Command Switching Source Unknown Forwarding Function

Configuration Under Port

Command format

unknown-discard src-mac

no unknown-discard src-mac

Parameter Description

None

35.2. show unknown-discard src-mac

Command function

Show unknown-discard src-mac[ethernet port-id]

Command view source unknown forwarding configuration

Command format

show unknown-discard src-mac

show unknown-discard src-mac ethernet 0/0/1

Parameter Description

Parameter	Parameter Description	Value
port-id	The number port	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4

36. Flow-Control configuration command

36.1. flow-control

Command function

(no)flow-control

Command to switch flow control function in port mode

Command format

flow-control

no flow-control

Parameter Description

None

36.2. show flow-control interface

Command function

Show flow-control interface [ ethernet port-id]

Command to view the port flow control configuration

Command format

Show flow-control interface

Show flow-control interface ethernet 0/0/1

Parameter Description

Parameter	Parameter Description	Value
port-id	The number port	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4

37. Error packet statistics

37.1. show statistics interface ethernet

Command function

show statistics interface ethernet port-id

Command to view all or single port error packet statistics

Command format

show statistics interface ethernet 0/0/1

show statistics interface

Parameter Description

Parameter	Parameter Description	Value
port-id	The number port	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4

38. IPv4 IF-Vlan Interface configuration command

38.1. interface vlan-interface

Command function

(no)interface vlan-interface vid Command to configure or delete a normal VLAN interface

Command format

interface vlan-interface 1 no interface vlan-interface 1

Parameter Description

Parameter	Parameter description	Value range
vid	VLAN id	1-4094

38.2. ip address ipv4 address

Command function

(no)ip address [ipaddress| primary] mask override Command to configure or delete the IP address of a normal VLAN interface

Command format

ip address 1.1.1.1 255.255.255.0

ip address 1.1.1.1 255.255.255.0 override

ip address primary 1.1.1.1

no ip address

no ip address 1.1.1.1 255.255.255.0

Parameter Description

Parameter	Parameter description	Value range
ipaddress	Configurable valid IP address	32-bit binary in X:X:X:X format
primary	Configure the IP address as the primary address	None
mask	Configure interface mask	255.0.0.0-255.255.255.252
override	Override the IP address of the main interface	None

38.3. Ip address

Command function

(no)ip address [dhcp|bootp] Command to configure or delete the dynamic IP address of a common VLAN interface

Command format

ip address dhcp

ip address bootpip address primary 1.1.1.1

no ip address dhcp

no ip address bootp

Parameter Description

none

38.4. ip addres range

Command function

(no)ip addres range start-ipadd end-ipadd Command to configure or delete the IP address range of a normal VLAN interface

Command format

ip address range 1.1.1.1 1.1.1.2

no ip address range

no ip address range 1.1.1.1 1.1.1.2

Parameter Description

Parameter	Parameter	Value range
	description
start-ipadd	Configurable valid IP address	32-bit binary in X:X:X:X format
end-ipadd	Configurable valid IP address,end-ipadd>=start-ipadd	32-bit binary in X:X:X:X format

38.5. ip icmp host-unreachable send

Command function

ip icmp host-unreachable send

Command to configure or delete

icmp unreachable

Command format

ip icmp host-unreachable send enable

ip icmp host-unreachable send disable

Parameter Description

None

38.6. ip icmp mask-request receive

Command function

ip icmp mask-request receive

Command to configure or delete

icmp mask-request

Command format

ip icmp mask-request receive enable

ip icmp mask-request receive disable

Parameter Description

None

38.7. description

Command function

(no)description string Command to add or delete interface description

information

Command format

(no"description vlan1

Parameter Description

Parameter	Parameter description	Value range
string	Description information	Any characters except ? , Space need to add double quotation marks

38.8. show ip interface

Command function

show ip interface vlan-interface Command to view interface

configuration IP address information

Command format

show ip interface vlan-interface 1

Parameter Description

Parameter	Parameter description	Value range
vlan-interface	Vlan interface	1-4094

39. IPv4 SuperVlanInterface configuration command

39.1. interface supervlan-interface

Command function

(no)interface supervlan-interface vid Command to configure or delete a normal supervlan interface

Command format

interface supervlan-interface 1 no interface supervlan-interface 1

Parameter Description

Parameter	Parameter description	Value range
vid	VLAN id	1-128

39.2. subvlan

Command function

(no)subvlan [vid] vlan-list] Command to configure or delete an supervlan subordinate subvlan

Command format

subvlan 2,3,4-10

Parameter Description

Parameter	Parameter description	Value range
vid	vlan-list	1-4094
vlan-list	VLAN id	Numeric string, case-insensitive, not support space, the length range is 1-128. String range is 1-4094

39.3. ip address

Command function

(no)ip address [ipaddress| primary] mask override Command to configure or delete the IP address of normal VLAN interface.

Command format

ip address 1.1.1.1 255.255.255.0

ip address 1.1.1.1 255.255.255.0 override

ip address primary 1.1.1.1

no ip address

no ip address 1.1.1.1 255.255.255.0

Parameter Description

Parameter	Parameter description	Value range
ipaddress	Configurable valid IP address	32-bit binary in X:X:X:X format
primary	Configure the IP address as the primary address	None
mask	Configure interface mask	255.0.0.0-255.255.255.252
override	Override the IP address of the main interface	None

39.4. Ip address

Command function

(no)ip address [dhcp|bootp] Command to configure or delete the dynamic IP address of a common VLAN interface

Command format

ip address dhcp

ip address bootpip address primary 1.1.1.1

no ip address dhcp

no ip address bootp

Parameter Description

none

39.5. ip addres range

Command function

(no)ip addres range start-ipadd end-ipadd Command to configure or delete the IP address range of a normal VLAN interface.

Command format

ip address range 1.1.1.1 1.1.1.2

no ip address range

no ip address range 1.1.1.1 1.1.1.2

Parameter Description

Parameter	Parameter description	Value range
start-ipadd	Configurable valid IP address	32-bit binary in X:X:X:X format
end-ipadd	Configurable valid IP address,end-ipadd>=start-ipadd	32-bit binary in X:X:X:X format

39.6. ip icmp host-unreachable send

Command function

ip icmp host-unreachable send Command to configure or delete

icmp unreachable

Command format

ip icmp host-unreachable send enable

ip icmp host-unreachable send disable

Parameter Description

None

39.7. ip icmp mask-request receive

Command function

ip icmp mask-request receive Command to configure or delete

icmp mask-request

Command format

ip icmp mask-request receive enable

ip icmp mask-request receive disable

Parameter Description

None

39.8. description

Command function

(no)description string Command to add or delete interface description

information.

Command format

(no"description vlan1

Parameter Description

Parameter	Parameter description	Value range
string	description information	Any characters except ? , Space need to add double quotation marks

39.9. show ip interface

Command function

show ip interface

supervlan-interface Command to view interfaceconfiguration IP

address

Information.

Command format

show ip interface supervlan-interface 1

Parameter Description

Parameter	Parameter description	Value range
supervlan-interface	Supervlan interface	1-128

40. IPv6 IF-VlanInterface configuration command

40.1. ipv6 address

Command function

(no)ipv6 address [ipv6-address|prefix-length] eui-64 command to

configure or delete local and

global unicast addresses for configuration sites in EUI-64 format of

interface.

(no)ipv6 address [ipv6-address|prefix-length] Command to configure or

delete interface manual and global unicast addresses

(no)ipv6 address autoconfig command to configure or delete interface Specify site local address and global unicast address automatically.

(no)ipv6 address ipv6-address link-localCommand to configure or delete manually specified link local addresses

Command format

ipv6 address 2001::1/64 eui-64

no ipv6 address 2001::1/64 eui-64

ipv6 address autoconfig

no ipv6 address autoconfig

ipv6 address fe91::11 link-local

no ipv6 address fe91::11 link-local

Parameter Description

Parameter	Parameter description	Value range
ipv6address	Configurable valid IPv6 addresses	128-bit binary in X:X:X:X:X:X:X format
prefix-length	Ipv6 address mask	1-128

40.2. ipv6 neighbors max-learning-num

Command function

(no)ipv6 neighbors max-learning-num number Command to configure or delete the number of neighbor caches

Command format

ipv6 neighbors max-learning-num 2 no ipv6 neighbors max-learning-num

Parameter Description

Parameter	Parameter description	Value
number	Neighbor cache number	1-2000

40.3. ipv6 nd ns retrans-timer

Command function

(no)ipv6 nd ns retrans-timer value

Command format

ipv6 nd ns retrans-timer 20

no ipv6 nd ns retrans-timer

Parameter Description

Parameter	Parameter description	Value
value	Retransmission interval	1-3600

40.4. ipv6 nd dad attempts value

Command function

(no)ipv6 nd dad attempts value Command to configure or delete times of sending neighbor request message while repeat address detects.

Command format

ipv6 nd dad attempts 20

no ipv6 nd dad attempts

Parameter Description

Parameter	Parameter description	Value
value	DAD times	0-20

40.5. ipv6 nd reachable-time

Command function

(no)ipv6 nd reachable-time value Command to configure or delete the time to keep neighbor reachable

Command format

ipv6 nd reachable-time 2 no ipv6 nd reachable-time

Parameter Description

Parameter	Parameter description	Value range
value	reachable time	1-3600

40.6. ipv6 pathmtu value

Command function

(no)ipv6 pathmtu value command to configure or delete ipv6 pathmtu

Command format

ipv6 pathmtu 1280

no ipv6 pathmtu

Parameter Description

Parameter	Parameter description	Value range
value	lpv6 pathmtu	1280-1500

40.7. ipv6 nd ra halt

Command function

(no)ipv6 nd ra halt

Command format

ipv6 nd ra halt

Parameter Description

None

40.8. ipv6 nd ra hop-limit

Command function

(no)ipv6 nd ra hop-limit value

Command format

ipv6 nd ra hop-limit 2

Parameter Description

Parameter	Parameter description	Value range
value	Number restriction	0-255

40.9. ipv6 nd ra interval

Command function

(no)ipv6 nd ra interval max-interval min-interval

Command format

ipv6 nd ra interval 4 4

Parameter Description

Parameter	Parameter description	Value range
max-interval	max-interval	4-1800
min-interval	min-interval	3-1350

40.10. ipv6 nd ra prefix

Command function

(no)ipv6 nd ra prefix prefix-name ipv6-address valid-lifetime

preferred-lifetime [no-autoconfig | off-link] Command ro configure or

delete router notification address prefix

Command format

ipv6 nd ra interval 4 4

Parameter Description

Parameter	Parameter	Value range
	description
prefix-nam	prefix-nam	1-32 characters
ipv6address	ipv6address	128-bit binary in X:X:X:X:X:X:X format
valid-lifetime	valid-lifetime	0-4294967295
preferred-lifetime	Select time	0-4294967295
no-autoconfig	Affix cannot be used for automatic address configuration	none
off-link	Prefix cannot be used for detection on link	none

40.11. ipv6 nd ra router-lifetime

Command function

(no)ipv6 nd ra router-lifetime value

Command format

ipv6 nd ra router-lifetime 4

Parameter Description

Parameter	Parameter description	Value range
router-lifetime	router-lifetime	0-9000

40.12. show ipv6 interface

Command function

show ipv6 interface [ vlan-inter | supervlan-inte | loopback-inter]

Command format

show ipv6 interface vlan-interface 1

show ipv6 interface supervlan-interface 1

show ipv6 interface loopback-interface 1

Parameter Description

Parameter	Parameter description	Value range
supervlan-inter	Supervlan interface	1-128
loopback-inter	Loopback interface	0-1
vlan-inter	Vlan interface	1-4094

40.13. show ipv6 neighbors

Command function

show ipv6 neighbors [ ipv6-add |all | dynamic| static|mac mac-add |

max-learning-num ]

Command format

show ipv6 neighbors all

Parameter Description

Parameter	Parameter description	Value range
mac-add	Configure port mac address	48-bit binary in X:X:X:X:X:X format

40.14. show ipv6 nd dad attemps

Command function

show ipv6 nd dad attemps

Command format

show ipv6 nd dad attemps

Parameter Description

None

40.15. show ipv6 nd ns retrans-time

Command function

show ipv6 nd ns retrans-time

Command format

show ipv6 nd ns retrans-time

Parameter Description

none

40.16. show ipv6 nd reachable-time

Command function

show ipv6 nd reachable-time

Command format

show ipv6 nd reachable-time

Parameter Description

None

40.17. show ipv6 route

Command function

show ipv6 route

Command format

show ipv6 route

Parameter Description

None

41. IPv6 SuperVlanInterface configuration command

41.1. ipv6 address

Command function

(no)ipv6 address [ipv6-address|prefix-length] eui-64 Command to configure or delete the local address and global unicast addresses of configuration sites in EUI-64 format of interface.

(no)ipv6 address [ipv6-address|prefix-length] Command to configure or delete interface manual and global unicast addresses

(no)ipv6 address autoconfig command to configure or delete interface Specify site local address and global unicast address automatically.

(no)ipv6 address ipv6-address link-local Command to configure or delete manually specified link local addresses

Command format

ipv6 address 2001::1/64 eui-64

no ipv6 address 2001::1/64 eui-64

ipv6 address autoconfig

no ipv6 address autoconfig

ipv6 address fe91::11 link-local

no ipv6 address fe91::11 link-local

Parameter Description

Parameter	Parameter description	Value range
ipv6address	Configurable valid ipv6 address	128-bit binary in X:X:X:X:X:X:X format
prefix-length	Ipv6 address mask	1-128

41.2. ipv6 neighbors max-learning-num

Command function

(no)ipv6 neighbors max-learning-num number

Command format

ipv6 neighbors max-learning-num 2

no ipv6 neighbors max-learning-num
Parameter Description

Parameter	Parameter description	Value range
number	Neighbor cache number	1-2560

41.3. ipv6 nd ns retrans-timer

Command function

(no)ipv6 nd ns retrans-timer value

Command format

ipv6 nd ns retrans-timer 20

no ipv6 nd ns retrans-timer

Parameter Description

Parameter	Parameter description	Value range
value	Retransmission interval	1-3600

41.4. ipv6 nd dad attempts value

Command function

(no)ipv6 nd dad attempts value

Command format

ipv6 nd dad attempts 20

no ipv6 nd dad attempts

Parameter Description

Parameter	Parameter description	Value range
value	DAD number of times	0-20

41.5. ipv6 nd reachable-time

Command function

(no)ipv6 nd reachable-time value Command to configure or delete

the time to keep neighbor reachable

Command format

ipv6 nd reachable-time 2

no ipv6 nd reachable-time

Parameter Description

Parameter	Parameter description	Value range
value	Reachable time	1-3600

41.6. ipv6 pathmtu value

Command function

(no)ipv6 pathmtu value

Command format

ipv6 pathmtu 1280

no ipv6 pathmtu

Parameter Description

Parameter	Parameter description	Value range
value	Maximum transmission unit value	1280-1500

41.7. ipv6 nd ra halt

Command function

(no)ipv6 nd ra halt

Parameter Description

ipv6 nd ra halt

Parameter Description

None

41.8. ipv6 nd ra hop-limit

Command function

(no)ipv6 nd ra hop-limit value

Command format

ipv6 nd ra hop-limit 2

Parameter Description

Parameter	Parameter description	Value range
value	Number restriction	0-255

41.9. ipv6 nd ra interval

Command function

(no)ipv6 nd ra interval max-interval min-interval

Command format

ipv6 nd ra interval 4 4

Parameter Description

Parameter	Parameter description	Value range
max-interval	max-interval	4-1800
min-interval	min-interval	3-1350

41.10. ipv6 nd ra prefix

Command function

(no)ipv6 nd ra prefix prefix-name ipv6-address valid-lifetime

preferred-lifetime [no-autoconfig | off-link] 命令配置删除路由器通告地

址前缀 Command to con figurdeleting router notification address prefix

Command format

ipv6 nd ra interval 4 4

Parameter Description

Parameter	Parameter description	Value range
prefix-nam	Prefix identification name	1-32 character
ipv6address	Configurable valid ipv6 address	128-bit binary in X:X:X:X:X:X:X format
valid-lifetime	Valid life time	0-4294967295
preferred-lifetime	Select time	0-4294967295
no-autoconfig	Affix cannot be used for automatic address configuration	none
off-link	Prefix cannot be used for detection on link	none

41.11. ipv6 nd ra router-lifetime

Command function

(no)ipv6 nd ra router-lifetime valueCommand to configure or delete

Router notification lifecycle.

Command format

ipv6 nd ra router-lifetime 4

Parameter Description

Parameter	Parameter description	Value range
router-lifetime	Router time	0-9000

41.12. show ipv6 interface

Command function

show ipv6 interface [ vlan-inter | supervlan-inte|loopback-inter]

Command format

show ipv6 interface vlan-interface 1

show ipv6 interface supervlan-interface 1

show ipv6 interface loopback-interface 1

Parameter Description

Parameter	Parameter description	Value range
supervlan-inter	Supervlan interface	1-128
loopback-inter	Loopback interface	0-1
vlan-inter	Vlan interface	1-4094

41.13. show ipv6 neighbors

Command function

show ipv6 neighbors [ ipv6-add |all | dynamic| static|mac mac-add |

max-learning-num]

Command to view ipv6 interface neighbor table items

Command format

show ipv6 neighbors all

Parameter Description

Parameter	Parameter description	Value range
mac-add	Configure port mac address	48-bit binary in X:X:X:X:X:X format

41.14. show ipv6 nd dad attemps

Command function

show ipv6 nd dad attempts command to view number of times of sending neighbor request message when repeat address detect

Command format

show ipv6 nd dad attemps

Parameter Description

none

41.15. show ipv6 nd ns retrans-time

Command function

show ipv6 nd ns retrans-time

Command format

show ipv6 nd ns retrans-time

Parameter Description

None

41.16. show ipv6 nd reachable-time

Command function

show ipv6 nd reachable-time Command to view the time that keep

neighborhood reachable state

Command format

show ipv6 nd reachable-time

Parameter Description

None

41.17. show ipv6 route

Command function

show ipv6 route Command to view the ipv6 routing table

Command format

show ipv6 route

Parameter Description

None

42. GMRP Configuration command

42.1. gmrp

Command function

(no)gmrp

Command to enable (disable) multicast registration protocol in

global or port mode

Command format

gmrp

no gmrp

Parameter Description

None

42.2. garp permit multicast mac-address

Command function

(no) garp permit multicast mac-address mac vlan vid

Command to configure (delete) multicast published by multicast

registration protocol

Command format

garp permit multicast mac-address 01:00:5e:00:01:01 vlan 12

no garp permit multicast mac-address 01:00:5e:00:01:01 vlan 12

Parameter Description

Parameter	Parameter description	Value range
mac	组播 MAC 地址	128 位二进制数,格式为 X:X:X:X:X:X
vid	VLAN id	1-4094

42.3. show gmrp

Command function

show gmrp

Command to view the enable state of the global multicast

registry protocol

Command format

show gmrp

Parameter Description

None

42.4. show gmrp interface

Command function

Show gmrp interface [ethernet port-id]

Command to view the enable state of the port multicast registry

protocol

Command format

show gmrp interface ethernet 0/0/1

Parameter Description

Parameter	Parameter description	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28- port- switch: 0 / 0 / 1 - 0 / 1 / 4

42.5. show garp permit multicast

Command function

show garp permit multicast

Command to view multicast registration protocol

Command format

show garp permit multicast

Parameter Description

None

42.6. show multicast

Command function

show multicast

Command to view local multicast group(Contains static and GMRP learning multicast groups)

Command format

show multicast

Parameter Description

None

43. GMP-Snooping Configuration command

43.1. igmp-snooping

Command function

(no)igmp-snooping

Command to enable (disable) Internet Group Management snooping Protocol

Command format

igmp-snooping

no igmp-snooping

Parameter Description

None

43.2. igmp-snooping host-aging-time

Command function

igmp-snooping host-aging-time time vlan vid

Command to configure dynamic multicast port member aging time

Command format

igmp-snooping host-aging-time 10 vlan 1

Parameter Description

Parameter	Parameter description	Value range
time	Aging time (seconds)	10-1000000 s
vid	VLAN list	1-128 character

43.3. no igmp-snooping host-aging-time

Command function

no igmp-snooping host-aging-time [vlan vid]

command to cancel the aging time of dynamic multicast port

members

Command format

no igmp-snooping host-aging-time vlan 1

Parameter Description

Parameter	Parameter description	Value range
vid	VLAN List	1-128 character

43.4. igmp-snooping max-response-time

Command function

igmp-snooping max-response-time time

Command to configure the query maximum response time

Command format

igmp-snooping max-response-time 1

Parameter Description

Parameter	Parameter description	Value range
time	Maximum	1-100s
	response time in seconds

43.5. no igmp-snooping max-response-time

Command function

no igmp-snooping max-response-time

Command to cancel the query maximum response time

Command format

no igmp-snooping max-response-time

Parameter Description

None

43.6. igmp-snooping fast-leave

Command function

igmp-snooping fast-leave

Command to configure port fast-leave in port mode.

Command format

igmp-snooping fast-leave

Parameter Description

None

43.7. no igmp-snooping fast-leave

Command function

no igmp-snooping fast-leave

Command to cancel port fast-leave mode

Command format

no igmp-snooping fast-leave

Parameter Description

None

43.8. igmp-snooping group-limit

Command function

igmp-snooping group-limit number

Command to configure port max learning multicast number in port mode

Command format

igmp-snooping group-limit 1

Parameter Description

Parameter	Parameter description	Value range
number	Multicast group number	0-1020

43.9. no igmp-snooping group-limit

Command function

no igmp-snooping group-limit

Command cancels the maximum number of multicast that the port can learn

Command format

no igmp-snooping group-limit

Parameter Description

None

43.10. igmp-snooping overflow-replace

Command function

igmp-snooping overflow-replace

Command to action configuration for full Multicast Group in Ports

Command format

igmp-snooping overflow-replace

Parameter Description

None

43.11. igmp-snooping enable-vlan

Command function

(no)igmp-snooping enable-vlan [vlan-list]

Command to configure (delete) default learning rules for multicast groups that are not on the black-and-white list

Command format

igmp-snooping enable-vlan 1

no igmp-snooping enable-vlan 1

Parameter Description

Parameter	Parameter description	Value range
vlan-list	VLAN list	1-128character

43.12. igmp-snooping [permit | deny]

Command function

(no)igmp-snooping [permit | deny] group mac vlan vid igmp-snooping [permit | deny] group-range mac multi-count num vlan vid Command to configure (delete) port multicast black-and-white list

Command format

igmp-snooping deny group 01:00:5e:00:01:01 vlan 2 no igmp-snooping deny group 01:00:5e:00:01:01 vlan 2 igmp-snooping permit group-range 01:00:5e:00:01:01 multi-count 2 vlan 2

Parameter Description

Parameter	Parameter description	Value range
mac	Multicast MAC address	48-bit hexadecimal, in the form of X: X: X: X: X
num	Multicast address number	1-64
vid	VLAN id	1-4094

43.13. igmp-snooping querier

Command function

(no)igmp-snooping querier Command to enable or disable the query

Command format

igmp-snooping querier no igmp-snooping querier

Parameter Description

None

43.14. igmp-snooping robust-count

Command function

(no)igmp-snooping robust-count [count] Command to configure or restore Multicast robust coefficients

Command format

igmp-snooping robust-count 2 no igmp-snooping robust-count

Parameter Description

Parameter	Parameter description	Value range
count	Robust-count value, the default value is 2	1-5

43.15. igmp-snooping last-member-query-interval

Command function

(no)igmp-snooping last-member-query-interval value

Command to configure or restore multicast specific query send intervals

Command format

igmp-snooping last-member-query-interval 2

no igmp-snooping last-member-query-interval

Parameter Description

Parameter	Parameter description	Value range
value	Interval time, default is 1 second	1-5s

43.16. igmp-snooping version

Command function

igmp-snooping version value

Command to configure the version of the query message

Command format

igmp-snooping version 2

Parameter Description

Parameter	Parameter description	Value range
value	IGMP version number, default IGMPv2	2-3

43.17. igmp-snooping querier-vlan

Command function

(no)igmp-snooping querier-vlan vlan-id

Command to configure (delete) VLAN for general query messages

Command format

igmp-snooping querier-vlan 2

no igmp-snooping querier-vlan 2

Parameter Description

Parameter	Parameter description	Value range
vlan-id	VLAN list	1-128 character

43.18. igmp-snooping query-interval

Command function

(no)igmp-snooping query-interval value

Command to configure (restore) the interval that general query

message is sent

Command format

igmp-snooping query-interval 2

no igmp-snooping query-interval

Parameter Description

Parameter	Parameter description	Value range
value	Query message sending interval (seconds)	1-30000s

43.19. igmp-snooping query-source

Command function

(no)igmp-snooping query-source ipaddress

Command to configure (cancel) the source IP address that sends

the general query message

Command format

igmp-snooping query-source 1.1.1.1

no igmp-snooping query-source

Parameter Description

Parameter	Parameter description	Value range
ipaddress	Configurable valid multicast IP address	32 bit binary number in format of X:X:X:X

43.20. igmp-snooping router-port forward

Command function

(no)igmp-snooping router-port forward

Command to configure ( Cancel ) Mixed Routing Port Features

Command format

igmp-snooping router-port forward no igmp-snooping router-port forward

Parameter Description

None

43.21. igmp-snooping router-aging-time

Command function

(no)igmp-snooping router-aging-time value Command to configure (restore) the aging time of dynamic route ports

Command format

igmp-snooping router-aging-time 10 no igmp-snooping router-aging-time

Parameter Description

Parameter	Parameter description	Value range
value	Router port aging time range (seconds)	10-1000000s

43.22. igmp-snooping router-port vlan

Command function

(no)igmp-snooping router-port vlan vid interface [all | ethernet port-id] Command to configure (cancel) static router ports

Command format

igmp-snooping router-port vlan 10 interface ethernet 0/0/1 no igmp-snooping router-port vlan 10 interface ethernet 0/0/1

Parameter Description

Parameter	Parameter description	Value range
vid	VLAN id	1-4094
port-id	Port-id	Depend on the physical port of the switch, for example, 28- port- switch: 0 / 0 / 1 - 0 / 1 / 4

43.23. igmp-snooping multicast vlan

Command function

(no)igmp-snooping multicast vlan vid Command to configure (cancel) multicast vlan of port.

Command format

igmp-snooping multicast vlan 1

no igmp-snooping multicast vlan

Parameter Description

Parameter	Parameter description	Value range
vid	VLAN id	1-4094

43.24. igmp-snooping proxy

Command function

(no)igmp-snooping proxy

Command to configure (cancel) Multicast message proxy

Command format

igmp-snooping proxy

no igmp-snooping proxy

Parameter Description

None

43.25. igmp-snooping proxy-source

Command function

(no)igmp-snooping proxy-source ipaddress

Command to configure (cancel)proxy source ip

Command format

igmp-snooping proxy-source 1.1.1.1

no igmp-snooping proxy-source

Parameter Description

Parameter	Parameter description	Value range
ipaddress	Configurable valid multicast IP address	32 bit binary number in format of X:X:X:X

43.26. igmp-snooping query-proxy

Command function

(no)igmp-snooping query-proxy

Command to configure (cancel)query proxy

Command format

igmp-snooping query-proxy

no igmp-snooping query-proxy

Parameter Description

none

43.27. igmp-snooping source-learning

Command function

(no)igmp-snooping source-learning

Command on and off source address learning

Command format

igmp-snooping source-learning

Parameter Description

none

43.28. igmp-snooping static-group

Command function

(no)igmp-snooping static-group address [source-ip address|vlan vlan-id]

[all|ethernet port-id]

The command configures add(delete) the static multicast address

Command format

igmp-snooping static-group 224.1.1.1 source-ip 3.3.3.3 vlan 1 ethernet

0/0/1

no igmp-snooping static-group 224.1.1.1 source-ip 3.3.3.3 vlan 1

ethernet 0/0/1

Parameter Description

Parameter	Parameter Description	Value range
address	multicast ip address	32 bit binary number in format of X:X:X:X
vlan-id	VLAN ID	1-4094
port-id	Port ID	Depend on the physical port of the switch, for example, 28- port- switch: 0/0/1-0/1/4

43.29. igmp-snooping static-group proxy

Command function

(no)igmp-snooping static-group proxy [interval time]

The command configures (delete) the static multicast proxy and proxy interval time

Command format

igmp-snooping static-group proxy

igmp-snooping static-group proxy interval 50

no igmp-snooping static-group proxy

Parameter Description

Parameter	Parameter Description	Value range
time	Interval time	30-300s

43.30. igmp-snooping drop

Command function

(no)igmp-snooping drop [query|report]

Command to configure port (receive) discard query / report

message

Command format

igmp-snooping drop report

igmp-snooping drop query

no igmp-snooping drop report

no igmp-snooping drop query

Parameter Description

None

43.31. igmp-snooping preview

Command function

(no)igmp-snooping preview

Command to configure (disable) Multicast Preview function

Command format

igmp-snooping preview

no igmp-snooping preview

Parameter Description

None

43.32. igmp-snooping preview group-ip

Command function

(no)igmp-snooping preview group-ip ipaddress vlan vid interface ethernet

port-id

Command to configure(cancel) Multicast Preview function

Command format

igmp-snooping preview group-ip 224.0.1.1 vlan 2 interface ethernet 0/0/1

no igmp-snooping preview group-ip 224.0.1.1 vlan 2 interface ethernet 0/0/1

Parameter Description

Parameter	Parameter description	Value range
ipaddress	Multicast IP address	32 bit binary number in format of X:X:X:X
vid	VLAN	1-4094
port-id	Port id	Depend on the physical port of the switch, for example, 28- port- switch: 0 / 0 / 1 - 0 / 1 / 4

43.33. igmp-snooping preview times

Command function

(no)igmp-snooping preview [time-once time-once time-interval time-interval

time-reset time-reset permit-times permit-times }

Command to configure (cancel) single preview duration, preview

interval, preview reset duration and allowed preview times.

Command format

igmp-snooping preview permit-times 1 time-interval 190 time-once 233

time-reset 1800

no igmp-snooping preview permit-times time-interval time-once time-reset

Parameter Description

Parameter	Parameter description	Value range
time-once	time-once	60-300s
time-interval	time-interval	180-600s
time-reset	time-reset	1800-7200s
permit-times	permit-times	1-10

43.34. igmp-snooping profile

Command function

(no)igmp-snooping profile profile-id

Command to create (cancel) profile and enter profile

configuration mode

Command format

igmp-snooping profile 1

no igmp-snooping profile 1

Parameter Description

Parameter	Parameter description	Value range
profile-id	profile-id	1-128

43.35. profile limit

Command function

profile limit [ permit | deny ]

Command to configure the profile type in igmp-profile mode

Command format

profile limit permit

Parameter Description

Parameter	Parameter description	Value range
permit	Configure the multicast list allowed in the rules	None
deny	Configure a deny list of multicast in a rule	None

43.36. ip range

Command function

(no)ip range start-ip end-ip [vlan vlan-id]

Command to configure (delete) profile TP address range in TGMP-

Profile mode

Command format

ip range 224.0.1.1 224.0.1.2 vlan 1

no ip range 224.0.1.1 224.0.1.2 vlan 1

Parameter Description

Parameter	Parameter description	Value range
start-ip	Start group IP address	224.0.0.1-239.255.255.254
end-ip	End group IP address	224.0.0.1-239.255.255.254
vlan-id	VLAN ID	1-4094

43.37. mac range

Command function

(no)mac range start-mac end-mac [vlan vlan-id]

Command to configure (delete) profile MAC address range in TGMP-

Profile mode

Command format

mac range 01:00:5e:1:1:1 01:00:5e:1:1:2 vlan 1

no mac range 01:00:5e:1:1:1 01:00:5e:1:1:2 vlan 1

Parameter Description

Parameter	ParameterDescription	Value range
start-mac	Start group MAC address	48 bit binary number in format of X:X:X:X:X:X
end-mac	End group MAC address	48 bit binary number in format of X:X:X:X:X:X
vlan-id	VLAN ID	1-4094

43.38. description

Command function

(no"description string

command to configure policy description in IGMP-Profile mode

Command format

description string

no description

Parameter Description

Parameter	Parameter Description	Value range
string	Profile description	STRING<1-32>

43.39. igmp-snooping profile refer

Command function

(no)igmp-snooping profile refer profile-list

Command to configure (deselect) the port Profile reference range in port mode

Command format

igmp-snooping profile refer 1

no igmp-snooping profile refer 1

Parameter Description

Parameter	ParameterDescription	Value range
profile-list	Profile identifier	1-128character

43.40. show igmp-snooping

Command function

show igmp-snooping

Command to view the associated configuration of IGMP Snooping

Command format

show igmp-snooping

Parameter Description

none

43.41. show igmp-snooping router-dynamic

Command function

show igmp-snooping router-dynamic

Command to view the dynamic routing port

Command format

show igmp-snooping router-dynamic

Parameter Description

none

43.42. show igmp-snooping router-static

Command function

show igmp-snooping router-static

Command to view the static routing port

Command format

show igmp-snooping router-static

Parameter Description

none

43.43. show igmp-snooping preview

Command function

show igmp-snooping preview

Command to view multicast preview information

Command format

show igmp-snooping preview

Parameter Description

none

43.44. show igmp-snooping preview status

Command function

show igmp-snooping preview status

Command to view the current status of the multicast preview channel

Command format

show igmp-snooping preview status

Parameter Description

none

43.45. show igmp-snooping profile

Command function

show igmp-snooping profile [string | ethernet port-id | vlan vlan-id]

Command to view profile information

Command format

show igmp-snooping profile ethernet 0/0/1

Parameter Description

Parameter	Parameter Description	Value range
string	Profile name	128character
port-id	Port id	According to the physical port of the switch, such as 28 port switch: 0/0/1-0/1/4
vlan-id	VLAN id	1-4094

43.46. show multicast

Command function

show multicast [ mac-address mac]

Command to view multicast table (simple) information

Command format

show multicast mac-address 01:00:5e:00:01:01

Parameter Description

Parameter	ParameterDescription	Value range
mac	multicast MAC address	48 bit binary number in format of X:X:X:X:X:X

44. Static multicast configuration command

44.1. multicast

Command function

(no) multicast mac-address mac vlan vlan-id [interface [ all | ethernet port-id ]

Command to add (delete) member ports to a static multicast group

Command format

multicast mac-address 01:00:5e:01:01:01 vlan 2 interface ethernet 0/0/1

no multicast mac-address 01:00:5e:01:01:01 vlan 2 interface ethernet 0/0/1

Parameter Description

Parameter	Parameter Description	Value range
mac	Multicast mac address	48 bit binary number in format of X:X:X:X:X:X
vlan-id	VLAN ID	1-4094
port-id	Port id	Depend on the physical port of the switch, for example, 28- port- switch: 0/0/1-0/1/4

44.2. multicast proxy

Command function

(no) multicast mac-address mac vlan vlan-id proxy-port ethernet port-id

The command creates a proxy port for a static multicast group

Command format

multicast mac-address 01:00:5e:01:01:01 vlan 2 proxy-port ethernet 0/0/1

no multicast mac-address 01:00:5e:01:01:01 vlan 2 proxy-port ethernet

0/0/1

Parameter Description

Parameter	Parameter Description	Value range
mac	Multicast mac address	48 bit binary number in format of X:X:X:X:X:X
vlan-id	VLAN ID	1-4094
port-id	Port id	Depend on the physical port of the switch, for example, 28- port- switch: 0/0/1-0/1/4

44.3. multicast proxy-interval

Command function

(no)multicast proxy-interval value

Command to configure (restore) the interval at which the proxy port sends a report to the multicast source

Command format

multicast proxy-interval 10

no multicast proxy-interval

Parameter Description

Parameter	Parameter Description	Value range
value	Time interval (seconds), default 10 seconds	1-300s

44.4. show multicast

Command function

show multicast

Command to view multicast table information

Command format

show multicast

Parameter Description

none

45. MLD-Snooping Configuration command

45.1. mld-snooping

Command function

(no)mld-snooping

Command switches the multicast listener discovery protocol

Command format

mld-snooping

no mld-snooping

Parameter Description

none

45.2. mld-snooping host-aging-time time

Command function

(no)mld-snooping host-aging-time time

Command to configure (restore) dynamic multicast port member

aging time

Command format

mld-snooping host-aging-time 10

no mld-snooping host-aging-time

Parameter Description

Parameter	Parameter Description	Value range
time	aging-time (s)	10-1000000

45.3. mld-snooping max-response-time

Command function

(no)mld-snooping max-response-time time

Command configuration (restore) leaves the maximum response time

Command format

mld-snooping max-response-time 1

no mld-snooping max-response-time

Parameter Description

Parameter	Parameter Description	Value range
time	max response time	1-100s

45.4. mld-snooping fast-leave

Command function

(no)mld-snooping fast-leave

Command to configure (delete) port fast leave in port mode

Command format

mld-snooping fast-leave

no mld-snooping fast-leave

Parameter Description

none

45.5. mld-snooping group-limit

Command function

(no)mld-snooping group-limit number

Command to configure (delete) the maximum number of multicast ports that can be learned in port mode

Command format

mld-snooping group-limit 1

no mld-snooping group-limit

Parameter Description

Parameter	Parameter Description	Value range
number	maximum number of multicast	0-1020

45.6. mld-snooping [permit | deny]

Command function

mld-snooping [permit | deny] group all

The command configures default learning rules for multicast groups that are not in the black and white list

Command format

mld-snooping permit group all

Parameter Description

none

45.7. mld-snooping

Command function

mld-snooping [permit | deny] group-range mac multi-count num vlan vid (no)mld-snooping [permit | deny] group mac vlan vid

Command to configure a multicast black and white list of ports

Command format

mld-snooping permit group-range 33:33:33:1:1:1 multi-count 2 vlan 1

mld-snooping permit group 33:33:33:1:1:1 vlan 1

no mld-snooping permit group 33:33:33:1:1:1 vlan 1

Parameter Description

Parameter	Parameter Description	Value range
mac	Multicast MAC address	33:33:XX:XX:XX:XX
num	MAC address number	1-64
vid	VLAN ID	1-4094

45.8. mld-snooping querier

Command function

(no)mld-snooping querier

Command to turn on or off the query

Command format

mld-snooping querier no mld-snooping querier

Parameter Description

none

45.9. mld-snooping query-interval

Command function

(no)mld-snooping query-interval value

Command configuration (restore) Generally queries the time interval of a message

Command format

mld-snooping query-interval 2

no mld-snooping query-interval

Parameter Description

Parameter	Parameter Description	Value range
value	Query message sending interval (seconds)	1-30000

45.10. mld-snooping query-max-respond

Command function

(no)mld-snooping query-max-respond value

Command configuration (restore) maximum response time for general query packets

Command format

mld-snooping query-max-respond 2

no mld-snooping query-max-respond

Parameter Description

Parameter	Parameter Description	Value range
value	Maximum response time (seconds)	1-25

45.11. mld-snooping router-port forward

Command function

(no)mld-snooping router-port forward

Command to configure (cancel) routing port forwarding

Command format

mld-snooping router-port forward

no mld-snooping router-port forward

Parameter Description

none

45.12. mld-snooping router-port-age

Command function

(no)mld-snooping router-port-age [ on | off | age-time ]

Command to configure (cancel) the aging time of the dynamic routing port

Command format

mld-snooping router-port-age 10

no mld-snooping router-port-age

Parameter Description

Parameter	Parameter Description	Value range
age-time	Aging time	10-1000000s

45.13. mld-snooping router-port vlan

Command function

(no)mld-snooping router-port vlan vid [ all | ethernet port-id ]

Command to configure (delete) the static routing port

Command format

mld-snooping router-port vlan 1 all no mld-snooping router-port vlan 1 all

Parameter Description

Parameter	Parameter Description	Value range
vid	VLAN ID	1-4094
port-id	Port ID	Depend on the physical port of the switch, for example, 28- port- switch: 0/0/1-0/1/4

45.14. mld-snooping multicast vlan

Command function

(no)mld-snooping multicast vlan vid

Command to configure (cancel) a multicast VLAN for a port

Command format

mld-snooping multicast vlan 1

no mld-snooping multicast vlan

Parameter Description

Parameter	Parameter Description	Value range
vid	VLAN id	1-4094

45.15. show mld-snooping

Command function

show mld-snooping

Command to view the configuration of the multicast listener discovery protocol

Command format

show mld-snooping

Parameter Description

none

45.16. show mld-snooping router-dynamic

Command function

show mld-snooping router-dynamic

Command to view the dynamic routing port

Command format

show mld-snooping router-dynamic

Parameter Description

none

45.17. show mld-snooping router-static

Command function

show mld-snooping router-static

Command to view the static routing port

Command format

show mld-snooping router-static

Parameter Description

none

45.18. show multicast mld-snooping

Command function

show multicast mld-snooping

Command to view a multicast group

Command format

show multicast mld-snooping

Parameter Description

none

46. I2protocol-tunnel Configuration command

46.1. l2protocol-tunnel

Command function

Configuration protocol transmission under port

Command format

l2protocol-tunnel [cdp | lacp | pagp | stp | udld | vtp | dtp | gvrp | lldp |

pvst [user-protocol]

Parameter Description

Parameter	Parameter description	Value range
cdp	cpd Protocol message
lacp	Lacp Protocol message
pagp	Pag Protocol message
stp	Stp Protocol message
udld	Udld Protocol message
vtp	Vtp Protocol message
dtp	Dtp Protocol message
gvrp	Gvrp Protocol message
lldp	Lldp Protocol message
pvst	Pvst Protocol message
user-protocol	User defined protocol	1-16

46.2. l2protocol-tunnel user-protocol

Command function

Command to configure custom protocol transmission

Command format

|2protocol-tunnel user-protocol protocol-mac

encap-type [ethernet2 | llc | snap] protocol-type

l2protocol-tunnel user-protocol name protocol-mac 00:00:22:22:2

2:22 encap-type ethernet2 protocol-type 1800

Parameter Description

Parameter	Parameter description	Value range
name	User defined protocol name	1-16
Mac address	Protocol multicast MAC
type	Ethernet type or DSAP/SSAP	1-ffff

46.3. l2protocol-tunnel drop-threshold

Command function

Limit Protocol transmission rate globally

Command format

l2protocol-tunnel [cdp | lacp | pagp | stp | udld | vtp | dtp | gvrp | lldp |

pvst | drop-threshold

l2protocol-tunnel drop-threshold

Parameter Description

Parameter	Parameter description	Value range
cdp	Cpd Protocol message
lacp	Lacp Protocol message
pagp	Pagp Protocol message
stp	Stp Protocol message
udld	Udld Protocol message
vtp	Vtp Protocol message
dtp	Dtp Protocol message
gvrp	Gvrp Protocol message
lldp	Lldp Protocol message
pvst	Pvst Protocol message
value	Limit value	1-200 pps

46.4. show l2protocol-tunne interface

Command function

View port run protocol status

Command format

show l2protocol-tunne interface [ethernet [list] ]

Parameter Description

Parameter	Parameter description	Value range
list	Port list

46.5. show l2protocol-tunnel drop-threshold

Command function

Check each protocol speed limit

Command format

show l2protocol-tunnel drop-threshold

Parameter Description

None

46.6. show l2protocol-tunnel tunnel-mac

Command function

View the mac address of the protocol

Command format

show l2protocol-tunnel drop-threshold

Parameter Description

None

47. LLDP Configuration Commands

47.1. lldp

Command Function
[no] lldp
Command for link discovery protocol functional switches

Command Format
no lldp
lldp

Parameter Declaration
/

47.2. lldp rx | tx | rxtx

Command Function
lldp [ rxtx | tx | rx ]
Configuration Commands Work Pattern in port mode

Command Format

lldp rxtx

Parameter Declaration

Parameter	Parameter Declaration	Values
rxtx	Both send and receive LLDP messages, ports work in the default mode.	/
tx	Only send LLDP message	/
rx	Only receive LLDP message	/

47.3. lldp hello-time

Command Function

[no] lldp hello-time value

Command configuration (delete) HELLO time

Command Format

Ildp hello-time 5

no lldp hello-time

Parameter Declaration

Parameter	Parameter Declaration	Values
value	Link discovery protocol HELLO time: (second)	5-32768

47.4. Ildp hold-times

Command Function

[no] lldp hold-times value

Command configuration (delete) timeout times

Command Format

Ildp hold-times 5

no lldp hold-times

Parameter Declaration

Parameter	Parameter Declaration	Values
value	Link discovery protocol timeout times	2-10

47.5. lldp trap

Command Function

Ildp trap enable | disable

Console Reference Guide Intellinet Network Solutions

Command enable lldp trap or disable lldp trap

Command Format

Ildp trap enable

Ildp trap disable

Parameter Declaration

none

47.6. lldp management-address

Command Function

[no] lldp management-address [supervlan-interface value1 | vlan-interface value2]

Command configuration LLDP (delete) management address in port mode

Command Format

Ildp management-address supervlan-interface 1 no lldp management-address

Parameter Declaration

Parameter	Parameter Declaration	Values
value1	Super VLAN ID Range	1-128
value2	VLAN Interface ID	1-4094

47.7. show lldp

Command Function

show lldp [ ethernet port-id]

Command view link discovery configuration information display

Command Format

show lldp ethernet 0/0/1

Parameter Declaration

Parameter	Parameter Declaration	Values
port-id	Port number	Based on the physical port of the switch, for example,28 ports switch: 0/0/1-0/1/4

48. UDLD Configuration Command

48.1. udld

Command Function

[no] udld

Command for unidirectional link detection functional switch

Command Format

no udd

udld

Parameter Declaration

/

48.2. udld error-down

Command Function

[no] udd error-down [recover | recover-time times]

command for configuring (delete) one-way link detection error

status processing

Command Format

udld error-down recover-time 30

no udd error-down recover-time

Parameter Declaration

Parameter	Parameter Declaration	Values
recover	Configuring unidirectional link detection error state recovery enabling	/
recover-time times	Configuring one-way link detection error status recovery time (seconds), default 30 seconds.	30-86400

48.3. udld message-interval

Command Function

udld message-interval time

command configuration unidirectional link

detection'hello'message sending time interval

Command Format

udld message-interval

Parameter Declaration

Parameter	Parameter Declaration	Values
time	Message sending time interval (second), default 15 seconds	7-90

48.4. udld reset

Command Function

udld reset

Command to reset one-way link detection in port or global mode

Command Format

udld reset

Parameter Declaration /

48.5. udld port shutdown

Command Function

[no]udd port shutdown

Command to configure (delete) one-way link detection close port in port mode.

Command Format

udld port shutdown no udld port shutdown

Parameter Declaration /

48.6. udld unidirectional-shutdown

Command Function

udld unidirectional-shutdown [auto | manual]

The command configures one-way port detection in port mode and detects the closing mode of single port, and automatically closes by default.

Command Format

udld unidirectional-shutdown auto

Parameter Declaration

Parameter	Parameter Declaration	Values
auto	Automatic closing the port	/
manual	Manually closing the port	/

48.7. udld work-mode

Command Function

udld work-mode [aggressive| normal]

Command configures one-way link detection mode in port mode, default to normal mode.

Command Format

udld work-mode aggressive

Parameter Declaration

Parameter	Parameter Declaration	Values
aggressive	Unidirectional link detection work mode is radical model	/
normal	One way link detection mode is normal mode	/

48.8. show uld

Command Function

show udd [ ethernet port-id]

command to view unidirectional link detection configuration information display

Command Format

show udld ethernet 0/0/1

Parameter Declaration

Parameter	Parameter Declaration	Values
port-id	Port number	Based on the physical port of the switch, for example,28 ports switch: 0/0/1-0/1/4: 0/0/1-0/1/4

49. Managing IP restricted configuration commands

49.1. login-access-list

Command Function

Configure the network addresses that the protocols allow to access

Command Format

login-access-list no login-access-list dcard>

Parameter Declaration

Parameter	Parameter Declaration	Values
ip-address	Access network
wildcard	Network inverse mask

49.2. login-access-list privilege-limit

Command Function

Configure Max privilege manage users

Command Format

login-access-list privilege-limit

no login-access-list privilege-limit

Parameter Declaration

Parameter		Values
	Parameter Declaration
num		0-5

49.3. show login-access-list

Command Function

View the restricted state of the run

Command Format

show login-access-list

Parameter Declaration

/

50. Managing timeout configuration command

50.1. timeout

Command Function

Configure access timeout in privileged mode

Command Format

timeout

no timeout

Parameter Declaration

Parameter	Parameter Declaration	Values
num		1-480 min

51. SSH configuration command

51.1. ssh

Command Function
Functional switch
Command Format
ssh
no ssh
Parameter Declaration
/

51.2. ssh limit

Command Function
Configuring SSH user number constraints

Command Format
ssh limit <num>
no ssh limit

Parameter Declaration

Parameter	Parameter Declaration	Values
num		0-5

51.3. ssh port

Command Function
Configuring SSH port number

Command Format
ssh port <num>
no ssh

Parameter Declaration

Parameter	Parameter	Values
	Declaration
num	Port number	1024-65535

51.4. stop vty

Command Function

Mandatory vty user downline in privileged mode

Command Format

stop vty

Parameter Declaration

Parameter	Parameter Declaration	Values
all	All users
vty-list	Vty List users

51.5. crypto key zeroize rsa

Command Function

Privileged pattern deleting key

Command Format

crypto key zeroize rsa

Parameter Declaration

/

51.6. crypto key refresh

Command Function

Privileged mode activation key

Command Format

crypto key refresh

Parameter Declaration

/

51.7. crypto key generate rsa

Command Function

The privileged mode configures the default key

Command Format

crypto key generate rsa

Parameter Declaration

/

51.8. load keyfile

Command Function

Privileged mode import key

Command Format

load keyfile

Parameter Declaration

Parameter	Parameter Declaration	Values
private	private key
public	public key
inet	ipv4 server address
inet6	ipv6 server address
address	address
filename	file name
ftp-username	Username used in FTP
ftp-pass	Password used in FTP

51.9. upload keyfile

Command Function

Privileged mode export key

Command Format

upload keyfile

Parameter Declaration

Parameter	Parameter Declaration	Values
private	private key
public	public key
inet	ipv4 server address
inet6	ipv6 server address
address	address
filename	file name
ftp-username	Username used in FTP
ftp-pass	Password used in FTP

51.10. show keyfile

Command Function

View key

Command Format

show keyfile

Parameter Declaration

Parameter	Parameter Declaration	Values
private	private key
public	public key

52. Telnet-Client Configuration command

52.1. telnet

Command Function

Access to other devices as clients in privileged mode

Command Format

telnet [tcp-port]

Parameter Declaration

Parameter	Parameter Declaration	Values
ip	ip address
tcp-port	Port number

53. Telnet-Server/Telnetv6- ServerConfiguration Command

53.1. telnet enable

Command Function Enabling function

Command Format
telnet enable

Parameter Declaration
/

53.2. telnet disable

Command Function Delete Enabling function

Command Format
telnet disable

Parameter Declaration
/

53.3. telnet limit

Command Function
Configuring Telnet user number constraints

Command Format
telnet limit <num>
no telnet limit

Parameter Declaration

Parameter	Parameter Declaration	Values
num		0-5

53.4. telnet port

Command Function

Configure the service port number

Command Format

telnet port

no telnet port

Parameter Declaration

Parameter	Parameter Declaration	Values
num		1024-65535

53.5. stop telnet client

Command Function

Mandatory user downline in privileged mode

Command Format

stop telnet client

Parameter Declaration

Parameter	Parameter Declaration	Values
all	All users
id	User id

53.6. show telnet client

Command Function

View online users

Command Format

show telnet client

Parameter Declaration

/

53.7. show telnet

Command Function

Look at the telnet service running state

Command Format

show telnet

Parameter Declaration

/

54. Web Management configuration command

54.1. http enable

Command Function

Enabling function

Command Format

http enable[port ]

Parameter Declaration

Parameter	Parameter Declaration	Values
num		1024-65535

54.2. http disable

Command Function

Delete Enabling function

Command Format

http disable

Console Reference Guide Intellinet Network Solutions

Parameter Declaration

/

54.3. http timeout

Command Function

Configure the HTTP timeout

Command Format

http timeout

Parameter Declaration

Parameter	Parameter Declaration	Values
time	unit: second, default: 1200s	60-36000

54.4. show http

Command Function

Look at the HTTP service running state

Command Format

show http

Parameter Declaration

/

55. SNMP Management configuration command

55.1. snmp-server enable

Command Function Enabling function

Command Format
snmp-server enable
Parameter Declaration
/

55.2. snmp-server disable

Command Function
Delete Enabling function

Command Format
snmp-server disable
Parameter Declaration
/

55.3. snmp-server contact

Command Function Configuration system contact

Command Format
snmp-server contact <text>
no snmp-server contact

Parameter Declaration

Parameter	Parameter Declaration	Values
text		STRING<1-255>

55.4. snmp-server location

Command Function

Configuration system location

Command Format

snmp-server location

no snmp-server location

Parameter Declaration

Parameter	Parameter Declaration	Values
text		STRING<1-255>

55.5. snmp-server name

Command Function

Configuration system name

Command Format

snmp-server name

no snmp-server name

Parameter Declaration

Parameter	Parameter Declaration	Values
text		STRING<1-255>

55.6. snmp-server max-packet-length

Command Function

Configuration max-packet-length

Command Format

snmp-server max-packet-length

no snmp-server max-packet-length

Parameter Declaration

Parameter	Parameter Declaration	Values
len		484-8000

55.7. snmp-server trap-source

Command Function

Configuring the source three layer interface for sending trap messages

Command Format

snmp-server trap-source <vlan-interface |supervlan-interface

|loopback-interface >

no snmp-server trap-source

Parameter Declaration

Parameter	Parameter Declaration	Values
id	Vlan number	1-4094
su-id	Supervlna number	1-128
lo-id	Ring back id	0-1

55.8. snmp-server encrypt

Command Function

SNMP user password whether encrypted display

Command Format

snmp-server encrypt

Parameter Declaration

Parameter	Parameter Declaration	Values
enable	encryption
disable	Unencrypted

55.9. snmp-server view

Command Function

Configuration attempt

Command Format

snmp-server view

no snmp-server view

Parameter Declaration

Parameter	Parameter Declaration	Values
view-name	View name	STRING<1-32>
oid	Mib tree oid	STRING<1-64>
exclude	Not containing configuration oid
incline	Only configuration oid

55.10. snmp-server community encrypt

Command Function

Whether the group name is encrypted or not

Command Format

snmp-server community encrypt

Parameter Declaration

Parameter	Parameter Declaration	Values
enable	encryption
disable	Unencrypted

55.11. snmp-server community md5 encrypt-communityname

Command Function

Configure the name of the ciphertext group

Command Format

snmp-server community md5 encrypt-communityname <text>
    <rw|ro> <deny|permit> [view<view-name>]
no snmp-server community <index>

Parameter Declaration

Parameter	Parameter Declaration	Values
text	The group name of the ciphertext	STRING<32-32>
rw	read-write
view-name	View name
index	The serial number of a group	1-8

55.12. snmp-server community

Command Function

Configuration group name

Command Format

snmp-server community <text> <rw|ro> <deny|permit> [view <view-name>]
no snmp-server community <index>

Parameter Declaration

Parameter	Parameter Declaration	Values
text	The group name of the ciphertext	STRING<1-64>
rw	read-write
view-name	View name
index	The serial number of a group	1-8

55.13. snmp-server group

Command Function

Configuring a group of V3

Command Format

snmp-server group <group-name> 3 [auth | noauthpriv| priv] [context <context-text>] [read <read-view>][write <write-view>][notify <notify-view>]
no snmp-server group <group-name> 3 [auth | noauthpriv| priv] [context <context-text>]

Parameter Declaration

Parameter	Parameter Declaration	Values
group-name	Group name	STRING<1-32>
auth	Authentication
noauthpriv	Unauthenticated and unencrypted
priv	encryption
context-text	Configured context
read-view	Read view
write-view	Written view
notify-view	Message view

55.14. snmp-server user

Command Function

Configuring V3 users

Command Format

snmp-server user <username> <groupname> [ remote <ip-address>
    [ udp-port <port-num>| | | auth | md5 |
    sha | ||auth-password
    <authpassword>| encrypt-authpassword
    encrypt-authpassword ]|[ auth-key
    <authkey> | encrypt-authkey encrypt-
    authkey] ][ priv des [priv-password priv-
    password | encrypt-privpassword encrypt-
    privatpassword] ||priv-key Priv-key | encrypt-
    privatkey encrypt-privkey ]]

no snmp-server user

Parameter Declaration

Parameter	Parameter Declaration	Values
groupname	Group name	STRING<1-32>
username	User name	STRING<1-32>
ip-address	Remote address	32 bit binary number in format of X:X:X:X
port-num	UDP port number	1-65535
auth	Authentication
md5	MD5 encryption
sha	Sha encryption
authpassword	Auth password	STRING<1-32>
encrypt-authpassword	Encrypt auth password	STRING<48-48>
authkey	Auth key	STRING<40-40>
encrypt-authkey	Encrypt auth key	STRING<48-48>
priv-password	Priv password	STRING<1-32>
encrypt-privpassword	Encrypt priv password	STRING<32-32>
Priv-key	Priv key	STRING<32-32>
encrypt-privkey	Encrypt priv key	STRING<32-32>

55.15. snmp-server enable

Command Function

Enabling function traps/informs

Command Format

snmp-server enable <traps|informs> [bridge] [gbn] [gbnsavecfg]
[interfaces] [rmon] [snmp]
no snmp-server enable <traps/informs> [bridge] [gbn] [gbnsavecfg]
[interfaces] [rmon] [snmp]

Parameter Declaration

Parameter	Parameter Declaration	Values
traps	Trap message
informs	Informs message
bridge	Bridge related message
gbn	Gbn related message
bgnsavecfg	Gbnsavecfg related message
interface	Interface related messages
rmon	Rmon message
snmp	Snmp message

55.16. snmp-server host

Command Function

Notice to the destination host

Command Format

snmp-server host <ipaddress> [version [1 | 2c | 3 [auth | noauthpriv | priv] ]<security-name> [udp-port <port-number> ] [notify-type [bridge | gbn | gbnsavecfg | interfaces | rmon | snmp] ]

no snmp-server host <ipaddress> <security-name> <1 | 2c | 3>

Parameter Declaration

Parameter	Parameter Declaration	Values
ipaddress	Destination host ip
security-name	Security name
bridge	Bridge related message
gbn	Gbn related message
bgnsavecfg	Gbnsavecfg related message
interface	Interface related messages
rmon	Rmon message
snmp	Snmp message

55.17. show snmp-server community

Command Function

View community massage

Command Format

show snmp-server community

Parameter Declaration

/

55.18. show snmp-server contact

Command Function

View contact massage

Command Format

show snmp-server contact

Parameter Declaration

/

55.19. show snmp-server engineid

Command Function

View engineid massage

Command Format

show snmp-server engineid

Parameter Declaration

Parameter	Parameter Declaration	Values
text		STRING<1-24>

55.20. show snmp-server group

Command Function

View Group massage

Command Format

show snmp-server group

Parameter Declaration

Parameter	Parameter Declaration	Values
groupname		STRING<1-32>

55.21. show snmp-server host

Command Function

View the notification information host

Command Format

show snmp-server host

Parameter Declaration

/

55.22. show snmp-server location

Command Function View location massage

Command Format show snmp-server location

Parameter Declaration /

55.23. show snmp-server max-packet-length

Command Function View the maximum length of a message

Command Format show snmp-server max-packet-length

Parameter Declaration /

55.24. show snmp-server mib

Command Function View mib massage

Command Format show snmp-server mib

Parameter Declaration /

55.25. show snmp-server name

Command Function View snmp name

Command Format show snmp-server name

Console Reference Guide Intellinet Network Solutions

Parameter Declaration

/

55.26. show snmp-server notify

Command Function

View notify

Command Format

show snmp-server notify

Parameter Declaration

/

55.27. show snmp-server user

Command Function

View v3 User massage

Command Format

show snmp-server user

Parameter Declaration

Parameter	Parameter Declaration	Values
User-name	username	STRING<1-32>

55.28. show snmp-server view

Command Function

View the view corresponding to oid

Command Format

show snmp-server view

Parameter Declaration

/

56. User management configuration command

56.1. username <>

Command Function Creating a user

Command Format username privilege password <0|7> no username

Parameter Declaration

Parameter	Parameter Declaration	Values
name	User name	STRING<1-32>
privilege	privilcgc	0-15
pass		STRING<1-32>

56.2. username change-password

Command Function Modify the password

Command Format username change-password Parameter Declaration /

56.3. username failmax

Command Function User maximum login failure number

Command Format

username failmax [name] <times>
no username failmax <name> <times>

Parameter Declaration

Parameter	Parameter Declaration	Values
name	User name	STRING<1-32>
times	Times	1-100

56.4. username online-max

Command Function

The number of the users at the same time at the same time

Command Format

username online-max <name> <num>
no username online-max <name >

Parameter Declaration

Parameter	Parameter Declaration	Values
name	User name	STRING<1-32>
num	Number	1-100

56.5. username silent-time

Command Function

Configuring silent time, which user can not try to log in

Command Format

username silent-time <min>

Parameter Declaration

Parameter	Parameter	Values
	Declaration
min		2-1440min

56.6. stop <>

Command Function

Privileged mode force user Downline

Command Format

stop

Parameter Declaration

Parameter	Parameter Declaration	Values
name	User name	STRING<1-32>

56.7. show users

Command Function

View online users

Command Format

show users

Parameter Declaration

/

56.8. show username silent

Command Function

View silent users

Command Format

show username silent

Parameter Declaration

/

56.9. show username

Command Function

View user information

Command Format

show username

Parameter Declaration

Parameter	Parameter Declaration	Values
name	User name	STRING<1-32>

57. Auto-Reboot Configuration command

57.1. auto-reboot

Command Function

Automatic reboot configuration

Command Format

auto-reboot [in hours minutes | at

[YYYY/MM/DD|daily|fri|mon|sat|sun|thu|tue|wed]]

no auto-reboot

Parameter Declaration

Parameter	Parameter Declaration	Values
hour	hour
min	minute
hh:mm:ss	llour minute sencond
yyyy/mm/dd	Year month date
daily	Every day

58. System debug configuration command

58.1. ping

Command Function

Check whether the IPv4 host is reachable

Command Format

ping [-i ttl][-l len][-n count][-s sourceip][-t timeout]

Parameter Declaration

Parameter	Parameter Declaration	Values
ttl	Hopping number	1-255
len	Packet length	0-4064 byte
count	Number of packets	1-2147483647
sourceip	Source IP
timeout	timeout	1-60s
host-ip	Destination host IP

58.2. ping ipv6

Command Function

Check whether the IPv6 host is reachable

Command Format

ping ipv6 [-h hop]|-s len||-c count ||-a sourceip ||-w timeout| [-t]

Parameter Declaration

Parameter	Parameter Declaration	Values
hop	Hopping number	1-255
len	Packet length	20-8100byte
count	Number of packets	1-2147483647
sourceip	Source IP	X:X::X:X
timeout	timeout	1-60s
host-ipv6	Destination host ipv6	X:X::X:X or X:X::X:X%ifname

58.3. tracert

Command Function

The path that has been detected by the destination host

Command Format

tracert [-s sourceip][-c] [-u][-f fttl] [-h httl] [-w timeout]

Parameter Declaration

Parameter	Parameter Declaration	Values
httI	Hopping number	1-255
fttl	First ttl	1-255
Sourceip	Source ip	32 bit binary number in format of X:X:X:X
-c	lcmp mode
-u	Udp mode
timeout	timeout	1-60s
host-ip	Destination host ip	32 bit binary number in format of X:X:X:X

58.4. tracert ipv6

Command Function

The path that has been detected by the IPv6 destination host

Command Format

tracert ipv6 [-c num][-h hop] [-w timeout]

Parameter Declaration

Parameter	Parameter Declaration	Values
num	Set number of probes per hop limit	1-65535
hop	Hopping number	1-255
timeout	timeout	1-60s
host-ipv6	Destination host ipv6

59. System information configuration and display command

59.1. show version

Command Function
View version information

Command Format
show version
Parameter Declaration
/

59.2. show system

Command Function View the system information

Command Format
show system
Parameter Declaration
/

59.3. show memory

Command Function View memory information

Command Format
show memory
Parameter Declaration
/

59.4. show clock

Command Function
View the current time
Command Format

show clock

Parameter Declaration

/

59.5. hostname

Command Function

Configure the host name

Command Format

hostname

Parameter Declaration

Parameter	Parameter Declaration	Values
name	Host name	STRING<1-128>

60. Bootrom Configuration command

60.1. Ctrl-B

Command Function

When restarting, press Ctrl and B keys to enter bootrom mode

Command Format

Press Ctrl-B to enter Boot Menu... 3

Main Menu

1. Running OS image from Flash
2. Running secondary OS image file

3. Advanced menu

4. Download via serial

5. Display the boot configuration
6. Set the factory-default license
7. Set the factory-default MAC address
8. Set the product serial number
   Please enter your choice :

Parameter Declaration

/

61. Telnetv6-Client Configuration command

61.1. telnet6

Command Function

Access to other devices as clients in privileged mode

Command Format

telnet [tcp-port]

Parameter Declaration

Parameter	Parameter Declaration	Values
ip	ip address	X:X::X:X or X:X::X:X%ifname
tcp-port	Port number	1-65535

62. EFM Configuration command

62.1. efm

Command function

(no)efm

Command to configure the switch in port mode and disable by default

Command format

efm

Parameter Description

None

62.2. efm mode

Command function

efm mode [ passive | active ]

Command to configure work mode in port mode

Command format

efm mode passive

Parameter Description

Parameter	Parameter description	Value range
passive	passive mode	none
active	active mode	none

62.3. efm pdu-timeout

Command function

(no)efm pdu-timeout value

Command to configure (restore) handshake message sending interval

in port mode.

Command format

efm pdu-timeout 1

no efm pdu-timeout

Parameter Description

Parameter	Parameter description	Value range
value	The sending period of OAMPDU (in seconds, the default value is 1s)	1-60

62.4. efm link-timeout

Command function

(no)efm link-timeout value

Command to configure (restore) the timeout of the connection in port

mode

Command format

efm link-timeout 10

no efm link-timeout

Parameter Description

Parameter	Parameter description	Value range
value	efm link-timeout (second),the default value is 5s	3-300

62.5. efm remote-response-timeout

Command function

(no)efm remote-response-timeout value

Command to configure (restore) response timeout in port mode

Command format

efm remote-response-timeout 10

Parameter Description

Parameter	Parameter descriptio	Value range
value		1-10

62.6. efm remote-failure

Command function

(no)efm remote-failure [link-fault | dying-gasp | critical-event]

Command to enable(disable) remote failure detection function in port mode

Command format

efm remote-failure link-fault

no efm remote-failure link-fault

Parameter Description

none

62.7. efm link-monitor

Command function

(no)efm link-monitor [ errored-symbol-period | errored-frame |

errored-frame-

period |

errored-frame-seconds ]

Command to enable (disable) efm link-monitor function in port mode

Command format

efm link-monitor errored-frame-period

no efm link-monitor errored-frame-period

Parameter Description

None

62.8. efm link-monitor errored-symbol-period window

Command function

(no)efm link-monitor errored-symbol-period window high win-

value1 low win-

value2

Command to configure (restore) the detection window for events during

error symbols in

port mode

Command format

efm link-monitor errored-symbol-period window high 2 low 2

no efm link-monitor errored-symbol-period window

Parameter Description

Parameter	Parameter description	Value range
win-value1	Configure error symbol duration event parameters (4 bytes high)	0-4294967295
win-value2	Configure error symbol duration event parameters (4 bytes low)	0-4294967295

62.9. efm link-monitor errored-symbol-period threshold

Command function

(no)efm link-monitor errored-symbol-period threshold high th-

value1 low th-

value2

Command to configure (restore) the detection threshold for events

during error

symbols in port mode

Command format

efm link-monitor errored-symbol-period threshold high 2 low 2

no efm link-monitor errored-symbol-period threshold

Parameter Description

Parameter	Parameter description	Value range
th-value1	Configure error symbol durationevent parameters(4 bytes high)	0-4294967295
th-value2	Configure error symbol duration event parameters(4 bytes low)	0-4294967295

62.10. efm link-monitor errored-frame window

Command function

(no)efm link-monitor errored-frame window win-value

Command is configured in port mode to recover the detection window

for error frame events

Command format

efm link-monitor errored-frame window 10

no efm link-monitor errored-frame window

Parameter Description

Parameter	Parameter description	Value range
win-value	Configure the window generated by the error frame event (in ms)	10-600

62.11. efm link-monitor errored-frame threshold

Command function

(no)efm link-monitor errored-frame threshold th-value

Command to configure (recover) the detection threshold for error frame

events in port mode

Command format

efm link-monitor errored-frame threshold 1

no efm link-monitor errored-frame threshold

Parameter Description

Parameter	Parameter description	Value range
th-value	Configure the threshold generated by the error frame event (number of error frames)	1-4294967295

62.12. efm link-monitor errored-frame-period window

Command function

(no)efm link-monitor errored-frame-period window win-value

Command to configure (recover) event detection window during the wrong frame in port mode.

Command format

efm link-monitor errored-frame-period window 10 no efm link-monitor errored-frame-period window

Parameter Description

Parameter	Parameter description	Value range
win-value	Configure windows (frames) generated by events during error frames	1-4294967295

62.13. efm link-monitor errored-frame-period threshold

Command function

(no)efm link-monitor errored-frame-period threshold th-value

Command to configure (restore) detection threshold for event during error frame in port mode.

Command format

efm link-monitor errored-frame-period threshold 1 no efm link-monitor errored-frame-period threshold

Parameter Description

Parameter	Parameter description	Value range
th-value	Configure threshold generated by event during Error frame period.(Number of error frames)	1-4294967295

62.14. efm link-monitor errored-frame-seconds window

Command function

(no)efm link-monitor errored-frame-seconds window win-value

Command to configure (restore) the detection window for error frame-second profile events in port mode.

Command format

efm link-monitor errored-frame-seconds window 100

no efm link-monitor errored-frame-seconds window

Parameter Description

Parameter	Parameter description	Value range
win-value		100-9000

62.15. efm link-monitor errored-frame-seconds threshold

Command function

(no)efm link-monitor errored-frame-seconds threshold th-value

Command to configure (recover) the efm link-monitor errored-frame-seconds threshold in port mode.

Command format

efm link-monitor errored-frame-seconds threshold 1

no efm link-monitor errored-frame-seconds threshold

Parameter Description

Parameter	Parameter description	Value range
th-value	Configure efm link-monitor errored-frame-seconds threshold(error seconds)	1-900

62.16. efm remote-loopback

Command function

(no)efm remote-loopback

Command to enable (disable) the remote-loopback function in port

mode

Command format

efm remote-loopback

no efm remote-loopback

Parameter Description

None

62.17. efm remote-loopback ignore

Command function

efm remote-loopback ignore

Command to efm remote-loopback ignore in port mode

Command format

efm remote-loopback ignore

Parameter Description

None

62.18. efm remote-loopback process

Command function

efm remote-loopback process

Command to process remote loopback requests initiated by the remote

in port mode

Command format

efm remote-loopback process

Parameter Description

None

62.19. efm remote-loopback start|stop

Command function

efm remote-loopback [start | stop ]

Command to start (stop) remote loopback requests in port mode

Command format

efm remote-loopback start

Parameter Description

None

62.20. efm variable-retrieval

Command function

(no)efm variable-retrieval

Command to enable (disable) remote MIB variable acquisition function

in port mode

Command format

efm variable-retrieval

no variable-retrieval

Parameter Description

None

62.21. show efm port

Command function

show efm port port-id-list remote-mib [ phyadminstate |

autonegadminsta

te ]

Command to get the port MIB variable value of the remote device in

port mode.

Command format

show efm port 1 remote-mib autonegadminstate

Parameter Description

Parameter	Parameter description	Value range
port-id-list	Port Number List ( Port Range : 1 - 254 )	1-64 characters

62.22. show efm remote-mib

Command function

show efm remote-mib [ fecability | fecmode ]

Command to get the global MIB variable value of the remote device in

port mode

Command format

show efm remote-mib fecability

Parameter Description

None

62.23. show efm status interface

Command function

show efm status interface [ ethernet port-id ]

Command to show EFM protocol run status

Command format

show efm statistics interface ethernet 0/0/1

Parameter Description

Parameter	Parameter description	Value range
port-id	port id	Depending on the physical port of the switch, for example, 28 port switch: 0 / 0 / 1 / 0 / 1 / 4

62.24. show efm summary

Command function

show efm summary

Command to show EFM profile information

Command format

show efm summary

Parameter Description

None

62.25. show efm discovery interface

Command function

show efm discovery interface [ ethernet port-id ]

Command to show EFM discovery information

Command format

show efm discovery interface ethernet 0/0/1

Parameter Description

Parameter	Parameter description	Value range
port-id	port id	Depending on the physical port of the switch, for example, 28 -port -switch: 0 / 0 / 1 / - 0 / 1 / 4

62.26. show efm statistics interface

Command function

show efm statistics interface [ ethernet port-id ]

Command to show EFM protocol message statistics

Command format

show efm statistics interface ethernet 0/0/1

Parameter Description

Parameter	Parameter description	Value range
port-id	Port id	Depending on the physical port of the switch, for example, 28-port-switches: 0 / 0 / 1 - 0 / 1 / 4

62.27. clear efm statistics interface

Command function

clear efm statistics interface [ ethernet port-id ]

Command to clear EFM protocol message statistics

Command format

clear efm statistics interface ethernet 0/0/1

Parameter Description

Parameter	Parameter description	Value range
port-id	Port id	Depending on the physical port of the switch, for example, 28-port-switch: 0 / 0 / 1 -0 / 1 / 4

63. CFM Configuration command

63.1. cfm md

Command function

cfm md md-index

Command enter Maintenance domain configuration mode

Command format

cfm md 1

Parameter Description

Parameter	Parameter description	Value range
md-index	Maintain domain index	1-4294967295

63.2. no cfm md

Command function

no cfm md md-index

Command deletes the maintenance domain

Command format

no cfm md 1

Parameter Description

Parameter	Parameter description	Value range
md-index	Maintain domain index	1-4294967295

63.3. cfm md format none level

Command function

cfm md format none level md-level

Command to configure an unnamed maintenance domain in cfm-md

mode, only specify the level of the maintenance domain

Command format

cfm md format none level 2

Parameter Description

Parameter	Parameter description	Value range
md-level	Maintain the level of the domain	0-7

63.4. cfm md format

Command function

cfm md format [ dns-name name dns-name | mac-uint name mac-

name | string

name string-name ] level md-level

Configure a nameless maintenance domain in mode, only specify the

level of the maintenance domain

Command format

cfm md format mac-uint name 00:0a:5a:00:00:01-12 level 2

Parameter Description

Parameter	Parameter description	Value range
dns-name	The domain name of the string, following the syntax of the RFC1035 DNS name	1-43 Character
mac-name	MAC address + 2-byte unsigned integer value	13-23 Character
string-name	Any string	1-43 Character
md-level	Maintain the level of the domain	0-7

63.5. cfm ma

Command function

cfm ma ma-index

Command creates the maintenance set in cfm-md mode and enters

the maintenance set configuration mode

Command format

cfm ma 1

Parameter Description

Parameter	Parameter description	Value range
ma-index	Maintain set index	1-4294967295

63.6. no cfm ma

Command function

no cfm ma ma-index

Command to delete the maintenance set configuration in cfm-md mode

Command format

no cfm ma 1

Parameter Description

Parameter	Parameter description	Value range
ma-index	Maintain set index	1-4294967295

63.7. cfm ma format

Command function

cfm ma format [ primary-vid name vlan-name| string name string|

uint16

name uint16-name| vpn-id name vpn-name ] primary-vlan vlan-id

Command format

cfm ma format string name df primary-vlan 2

Parameter Description

Parameter	Parameter description	Value range
vlan-name	Main vlan identification (1-4094)	1-4094
string	Any string	1-45 Character
uint16-name	2-byte unsigned integer value (0-65535)	0-65535
vpn-name	RFC2685 VPN ID (3 byte VPN OUI + 4 byte VPN index)	3-17 Character
vlan-id	Vlan-id	1-4094

63.8. cfm mep direction

Command function

cfm mep mep-id direction [ up | down ] primary-vlan vlan-id

interface

[ethernet port-id|eth-trunk trunk-id]

Command creates the maintenance endpoint in cfm-md-ma mode and specify its associated port.

Command format

cfm mep 1 direction down interface ethernet 0/0/1

Parameter Description

Parameter	Parameter description	Value range
mep-id	MEP id	1-8191
vlan-id	Main vlan id	1-4094
port-id	Port id	Depend on the physical port of the switch, for example, 28 port switch: 0 / 0 / 1- 0 / 1 / 4
trunk-id	trunk id	1-31

63.9. cfm mep state

Command function

cfm mep mep-id state [enable | disable]

Command to enable (disable) the maintenance state of the endpoint in

cfm-md-ma mode.

Command format

cfm mep 1 state disable

Parameter Description

Parameter	Parameter description	Value range
mep-id	MEP identification	1-8191

63.10. cfm mep priority

Command function

(no)cfm mep mep-id priority priority-id

Command to configure (delete) the priority used by the endpoint to

send CCM and LTM in cfm-md-ma mode.

Command format

cfm mep 1 priority 1

no cfm mep 1 priority

Parameter Description

Parameter	Parameter description	Value range
mep-id	MEP id	1-8191
priority-id	Priority identification	0-7

63.11. cfm rmep

Command function

(no)cfm rmep rmep-id mep mep-id

Command creates (deletes) a remote maintenance endpoint in cfm-

md-ma mode and specify its peer native maintenance endpoint

Command format

cfm rmep 1 mep 1

no cfm rmep 1

Parameter Description

Parameter	Parameter description	Value range
rmep-id	RMEP id	1-8191
mep-id	MEP id	1-8191

63.12. cfm mip

Command function

(no)cfm mip mip-id interface [ethernet port-id] eth-trunk trunk-id]

Command to create (delete) maintain intermediate point in cfm-md-ma

mode and specify its associated port

Command format

cfm mip 1 interface ethernet 0/0/1

no cfm mip 1

Parameter Description

Parameter	Parameter description	Value range
mip-id	MIP identification	1-8191
port-id	Port identification	Depend on the physical port of the switch, for example, 28 port switches: 0 / 0 / 1 / 0 / 1 / 4
trunk-id	trunk id	1-31

63.13. cfm cc interval

Command function

(no)cfm cc interval [1 | 10 | 60 | 600]

Command to create (delete) the interval that maintenance endpoint

sends the CCM in cfm-md-ma mode

Command format

cfm cc interval 1

no cfm cc interval

Parameter Description

None

63.14. cfm mep

Command function

cfm mep mep-id cc [enable | disable]

Command enables (disable) to maintain the ccm sending function of

the endpoint in cfm-md-ma mode.

Command format

cfm mep 1 cc enable
Parameter Description

Parameter	Parameter description	Value range
mep-id	MEP identification	1-8191

63.15. cfm loopback mep

Command function

cfm loopback mep mep-id [ dst-mac mac-address | dst-mep rmep-

id]

[ priority pri-id | count pkt-num | length data-len | data pkt-data ]

Command to enable loopback function in cfm-md-ma mode

Command format

cfm loopback mep 1 dst-mep 2 count 1 data 2 priority 2 length 2

Parameter Description

Parameter	Parameter description	Value range
mep-id	MEP identification	1-8191
mac-address	Destination MAC address	48-bit binary in X:X:X:X:X:X format
rmep-id	RMEP identification	1-8191
pri-id	message priority	0-7
pkt-num	Number of messages	1-1024
data-len	Length of data carried in a message	1-1500
pkt-data	Contents of data carried in a message	1-400

63.16. cfm linktrace mep

Command function

cfm linktrace mep mep-id [ dst-mac mac-address | dst-mep rmep-id ]

[ timeout pkt-time | ttl pkt-ttl | flag [ use-mpdb | unuse-mpdb ] ]

Command to enable linktrace function in cfm-md-ma mode

Command format

cfm linktrace mep 1 dst-mep 1 timeout 3 ttl 1 flag unuse-mpdb

Parameter Description

Parameter	Parameter description	Value range
mep-id	MEP identification	1-8191
mac-address	Destination MAC address	48-bit binary in X:X:X:X:X:X format
rmep-id	RMEP identification	1-8191
pkt-time	Timeout < 3-60 > seconds	3-60
pkt-ttl	Initial TTL value	1-255

63.17. cfm eth-slm mep

Command function

cfm eth-slm mep mep-id [ dst-mac mac-address | dst-mep rmep-id ]

[timeout pkt-time | priority priority-id| interval second |count packet-num]

Command performs frame loss rate detection function in cfm-md-ma mode

Command format

cfm eth-slm mep 1 dst-mep 1 timeout 3 priority 3 interval 2 count

3

Parameter Description

Parameter	Parameter description	Value range
mep-id	MEP identification	1-8191
mac-address	Destination MAC address	48-bit binary in X:X:X:X:X:X format
rmep-id	RMEP identification	1-8191
pkt-time	Timeout < 3-60 > seconds	3-60
pri-id	message priority	0-7
second	Interval time (seconds)	1-30
pkt-num	Number of messages	1-1024

63.18. cfm eth-2dm mep

Command function

cfm eth-2dm mep mep-id [ dst-mac mac-address | dst-mep rmep-id ]

[ timeout pkt-time | priority priority-id| interval second |count

packet-num]

Command to perform frame delay measurement in cfm-md-ma mode

Command format

cfm eth-2dm mep 1 dst-mep 1 timeout 3 priority 3 interval 2 count

3

Parameter Description

Parameter	Parameter description	Value range
mep-id	MEP identification	1-8191
mac-address	Destination MAC address	48-bit binary in X:X:X:X:X:X format
rmep-id	RMEP identification	1-8191
pkt-time	Timeout time<3-60>s	3-60
pri-id	message priority	0-7
second	Interval time (s)	1-30
pkt-num	Number of messages	1-1024

63.19. clear cfm cc

Command function

clear cfm cc

Command clears CCM statistics information

Command format

clear cfm cc

Parameter Description

None

63.20. clear cfm cc database

Command function

clear cfm cc database

Command to clear the CCM database information

Command format

clear cfm cc database

Parameter Description

None

63.21. show cfm md

Command function

show cfm md [md-index]

Command to show maintenance domain information

Command format

show cfm md 1

Parameter Description

Parameter	Parameter description	Value range
md-index	Maintain domain index	1-4294967295

63.22. show cfm ma

Command function

show cfm ma

Command format

show cfm ma

Parameter Description

None

63.23. show cfm mp local

Command function

show cfm mp local

Command to show local maintenance point information

Command format

show cfm mp local

Parameter Description

None

63.24. show cfm mp remote

Command function

show cfm mp remote

Command to show remote maintenance point information

Command format

show cfm mp remote

Parameter Description

None

63.25. show cfm cc

Command function

show cfm cc

Command to show CCM statistics information

Command format

show cfm cc

Parameter Description

None

63.26. show cfm cc database

Command function

show cfm cc database

Command to show CCM database information

Command format

show cfm cc database

Parameter Description

None

63.27. show cfm errors

Command function

show cfm errors

Command to show CFM alarm information

Command format

show cfm errors

Parameter Description

None

64. POE Power supply configuration command

64.1. poe

Command function

(no) poe

Command to configure the POE switch in port mode

Command format

poe

no poe

Parameter Description

None

64.2. poe max-power

Command function

(no) poe max-power value

Command to configure (restore) the maximum output power of the switch in

global mode

Command format

poe max-power 20

no poe max-power

Parameter Description

Parameter	Parameter description	Value range
value	Power of Switch(Unit:W)	1-400

64.3. poe max-power

Command function

(no) poe max-power value

Command to configure (restore) maximum output power in port mode

Command format

poe max-power 20

no poe max-power
Parameter Description

Parameter	Parameter description	Value range
value	Port Power, Unit: W	1-32

64.4. poe standard

Command function

poe standard [ieee802.3af | ieee802.3at]

Command to configure usage standards in port mode

Command format

poe standard ieee802.3af

Parameter Description

None

64.5. poe priority

Command function

poe priority [ low | high | critical ]

Command to configure priority in port mode

Command format

poe priority low

Parameter Description

Parameter	Parameter description	Value range
low	Minimum port priority (default)	None
high	Intermediate port priorit	None
critical	Maximum port priority	None

64.6. poe status poll

Command function

(no) poe status poll

Command to open (close) Poll port status

Command format

poe status poll

no poe status poll

Parameter Description

None

64.7. poe traps

Command function

poe traps

Poe trap reporting threshold configuration

Command format

poe traps 50

no poe traps

Parameter Description

Parameter	Parameter description	Value range
value	Power consumption percent	1-99

64.8. poe force power on

Command function

(no) poe force power on

Open (close) forced power supply under command port

Command format

poe force power on

no poe force power on

Parameter Description

None

64.9. show poe

Command function

show poe [ interface [ ethernet ] ]

Command to show port or device POE information

Command format

show poe interface ethernet 0/0/1

Parameter Description

Parameter	Parameter description	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28 port switches:0 / 0 / 1 - 0 / 1 / 4

64.10. show poe auto-check

Command function

show poe auto-check [ethernet port-id]

Command to display POE auto-check information of port or device

Command format

show poe auto-check ethernet 0/0/1

Parameter Description

Parameter	Parameter description	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28 port switches: 0 / 0 / 1 - 0 / 1 / 4

64.11. show poe power-on time-range

Command function

show poe power-on time-range [ethernet port-id]

Command to display POE power-on information of port or device

Command format

show poe power-on time-range ethernet 0/0/1

Parameter Description

Parameter	Parameter description	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28 port switches: 0 / 0 / 1 - 0 / 1 / 4

65. Statistics configuration command

65.1. show statistics interface ethernet

Command function

show statistics interface [ethernet port-id]

Command to view all or single port statistics

Command format

show statistics interface ethernet 0/0/1

show statistics interface

Parameter description

Parameter	Parameter description	Value
port-id	The port number	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4

65.2. clear interface

Command function

clear interface [ethernet port-id]

command to clear all or single port statistics

Command format

clear interface

clear interface ethernet 0/0/1

Parameter description

Parameter	Parameter description	Value
port-id	The port number	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4

65.3. clear cpu-statistics

Command function

clear cpu-statistics

command to clear CPU port statistics

Command format

clear cpu-statistics

Parameter description

None

65.4. clear cpu-classification

Command function

clear cpu-statistics [interface ethernet port-id]

command to clear CPU port classification statistics

Command format

clear cpu-statistics

clear cpu-statistics interface ethernet 0/0/1

Parameter description

Parameter	Parameter description	Value
port-id	The port number	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4

65.5. port-rate-statistics interval

Command function

(no)port-rate-statistics interval value

Command to configure or delete rate statistics interval. The default value is 5

minutes.

Command format

port-rate-statistics interval 1

no port-rate-statistics interval

Parameter description

Parameter	Parameter description	Value
value	Statistical interval	1-5

65.6. show statistics interface brief

Command function

show statistics interface brief [ethernet port-id]

command to view all port statistics

Command format

show statistics interface

Parameter description

Parameter	Parameter description	Value
port-id	The port number	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4

65.7. show statistics dynamic

Command function

show statistics dynamic [interface|eth-trunk]

Command to view all port real-time statistics

Command format

show statistics dynamic interface

show statistics dynamic eth-trunk

Parameter description

None

65.8. show utilization

Command function

show utilization [interface | eth-trunk]

command to see real-time utilization of all ports

Command format

show utilization interface

show utilization eth-trunk

Parameter description

None

65.9. show interface

Command function

show interface [ ethernet port-id]

Command to view port information

Command format

show interface

show interface ethernet 0/0/1

Parameter description

Parameter	Parameter description	Value
port-id	The port number	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4

65.10. show cpu-utilization

Command function

show cpu-utilization

Command to view switch CPU utilization

Command format

show cpu-utilization

Parameter description

None

65.11. show cpu-statistic

Command function

show cpu-statistic [ ethernet port-id]

Command to view CPU port statistics

Command format

show cpu-statistic

show cpu-statistic ethernet 0/0/1

Parameter description

Parameter	Parameter description	Value
port-id	The port number	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4

65.12. show cpu-classification

Command function

show cpu-classification [ interface ethernet port-id]

Command to view CPU port classification statistics

Command format

show cpu-classification

show cpu-classification interface ethernet

Parameter description

Parameter	Parameter description	Value
port-id	The port number	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4

65.13. show statistics eth-trunk

Command function

show statistics eth-trunk id

Command to view eth-trunk port statistics

Command format

show statistics eth-trunk 1

Parameter description

Parameter	Parameter description	Value
id	Aggregation group id	1-31

66. Port loopback detection configuration command

66.1. loopback

Command function

Loopback [internal|external]

The command executes inner loop or loop detection. It can be executed on a single port or globally.

Command format

loopback internal

loopback internal

Parameter description

Parameter	Parameter description	Value
internal	internal detection	None
external	external detection	None

66.2. loopback-detection action

Command function

loopback-detection action [discarding | shutdown|none]

command to configure the loop processing mode

Command format

show vct auto-run shutdown

Parameter description

Parameter	Parameter description	Value
discarding	Set the loopback port to discarding state (default mode)	None
shutdown	Disable the loopback port	None
none	Just send log and trap

66.3. loopback-detection interface

Command function

(no)loopback-detection interface [ethernet port-id]

Command to configure or delete the loop processing port

Command format

loopback-detection interface ethernet 0/0/1

Parameter description

Parameter	Parameter description	Value
port-id	The port number	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4

66.4. loopback-detection interval-time

Command function

loopback-detection interval-time time

command to configure the loop processing interval

Command format

loopback-detection interval-time 5

Parameter description

Parameter	Parameter description	Value
time	Interval (unit: seconds, default: 5 seconds	5-300

66.5. loopback-detection recover-time

Command function

loopback-detection recover-time [0|time]

Command configure loop processing auto recovery time

Command format

loopback-detection recover-time 5

Parameter description

Parameter	Parameter description	Value
time	Recovery time (unit: seconds, default: 60 seconds, 0 means manual recovery)	10-600

66.6. loopback-detection address-type

Command function

loopback-detection address-type [broadcast|multicast]

Command configure LBD packet's destination MAC is broadcast or multicast

Command format

loopback-detection address-type broadcast

loopback-detection address-type multicast

Parameter description

none

66.7. oopback-detection log

Command function

loopback-detection log [enable|disable]

Command configure enable or disable Log notification

Command format

loopback-detection log enable

Parameter description

None

66.8. loopback-detection mode

Command function

loopback-detection mode [port-based|vlan-based]

Command configure loopback-detection mode is port or vlan

Command format

loopback-detection mode port-based

Parameter description

None

66.9. loopback-detection trap

Command function

loopback-detection trap [enable|disable]

Command to configure whether trap messages when a loop occurs

or recover

Command format

loopback-detection trap enable

Parameter description

None

66.10. loopback-detection vlan

Command function

loopback-detection vlan vlan-id

Command to configure which vlans to enable loopback-detection

Command format

loopback-detection vlan 10

Parameter description

Parameter	Parameter description	Value
vlan-id	Vlan id	STRING<1-128>

66.11. show loopback-detection

Command function

show loopback-detection [ethernet port-id]

Command configure loop processing auto recovery time

Command format

show loopback-detection ethernet 0/0/1

Parameter description

Parameter	Parameter description	Value
port-id	The port number	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4

67. VCT detection configuration command

67.1. vct run

Command function

vct run

Command to perform vct detection under the global or port

Command format

vct run

Parameter description

none

68. Port configuration commands

68.1. interface ethernet

Command function

interface ethernet port-id

command to enter port configuration mode

Command format

interface ethernet 0/0/1

Parameter description

Parameter	Parameter description	Value
port-id	The port number	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4

68.2. duplex

Command function

(no) duplex [auto | full | half]

The command is used to configure or delete the port duplex mode in

the port mode. The default is auto.

Command format

duplex auto

no duplex

Parameter description

Parameter	Parameter description	Value
auto	Auto-negotiation	None
full	Full duplex	None
half	Half duplex	None

68.3. speed

Command function

(no) speed [100| 1000| 10000| auto]

The command is used to configure or delete the port rate in port mode.

The default is auto

Command format

speed 1000

no speed

Parameter description

Parameter	Parameter description	Value
100	100M	None
1000	1000M	None
10000	10G	None
auto	Auto negotiation	None

68.4. priority

Command function

(no)priority value

Command to add or delete port priority in port mode

Command format

(no)priority 1

Parameter description

Parameter	Parameter description	Value
value	Priority	0-7

68.5. shutdown

Command function

(no) shutdown

The command is used to linkdown port or linkup port in port mode

Command format

(no) shutdown

Parameter description

None

68.6. description

Command function

(no)description string

Command to add or delete interface description information in port mode

Command format

(no)description vlan1

Parameter description

Parameter	Parameter description	Value
string	Description	STRING<1-128>

68.7. switchport

Command function

(no) switchport [ethernet port-id|all]

Command to add or delete ports in vlan mode

Command format

(no) switchport ethernet 0/0/1

Parameter description

Parameter	Parameter description	Value
port-id	Port id	Numeric string, case-insensitive, space-free, length range 5-6. The port range is equal to the switch physical port
all	All ports	None

68.8. ingress filtering

Command function

(no) ingress filtering

Command to add or delete port packet filtering in port mode

Command format

(no) ingress filtering

Parameter description

None

68.9. switchport pvid

Command function

(no) switchport pvid vlan-id

Command to add or delete port pvid in port mode

Command format

(no) switchport pvid 1

Parameter description

Parameter	Parameter description	Value
vlan-id	vlan id	1-4094

68.10. ingress acceptable-frame

Command function

(no)ingress acceptable-frame [tagged|untagged|all]

Command to add or delete the port receive frame type in port mode

Command format

(no)ingress acceptable-frame tagged

Parameter description

Parameter	Parameter description	Value
tagged	Only receive tagged packets	None
untagged	Only receive untagged packets	none
all	All message are received	None

68.11. switchport trunk allowed vlan

Command function

(no) switchport trunk allowed vlan [vlan-list|all]

Command to add or delete the vlan under the trunk port in port mode

Command format

(no) switchport trunk allowed vlan 1

Parameter description

Parameter	Parameter description	Value
vlan-list	VLAN id	Numeric string, case insensitive, space not supported, length range 1-128. String range 1-4094
all	All configured vlan	None

68.12. switchport hybrid untagged vlan

Command function

(no)switchport hybrid untagged vlan [vlan-list|all]

Command to add or delete the vlan of the hybrid untagged port in port

mode

Command format

(no)switchport hybrid untagged vlan 1

Parameter description

Parameter	Parameter description	Value
vlan-list	VLAN id	Numeric string, case insensitive, space not supported, length range 1-128. String range 1-4094
all	All configured vlan	None

68.13. switchport hybrid tagged vlan

Command function

(no)switchport hybrid tagged vlan [vlan-list|all]

Command to add or delete the VLAN under the hybrid tagged port in

port mode

Command format

(no)switchport hybrid tagged vlan 1

Parameter description

Parameter	Parameter description	Value
vlan-list	VLAN id	Numeric string, case insensitive, space not supported, length range 1-128. String range 1-4094
all	All configured vlan	None

68.14. switchport link-type

Command function

(no) switchport link-type [access | hybrid | trunk]

Command to change the port link type

Command format

(no)switchport link-type access

Parameter description

Parameter	Parameter description	Value
access	Can configure a vlan	None
hybrid	Multiple vlan can be configured	None
trunk	Multiple vlans can be configured	None

68.15. show interface ethernet

Command function

show interface [ethernet port-id]

command to view port information

Command format

show interface ethernet 0/0/1

Parameter description

Console Reference Guide Intellinet Network Solutions

Parameter	Parameter description	Value
port-id	The port number	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4

68.16. show interface brief ethernet

Command function

show interface brief ethernet port-id command to view port brief information

Command format

show interface brief ethernet 0/0/1

Parameter description

Parameter	Parameter description	Value
port id	The port number	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4

68.17. show interface brief vlan-intf 1

Command function

show description ethernet port-id

The command is used to view single port description information

show description

The command is used to view all port description information of the

switch

Command format

show description ethernet 0/0/1

show description

Parameter description

Parameter	Parameter description	Value
port-id	The port number	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4

68.19. show ingress ethernet

Command function

show ingress ethernet port-id

The command is used to view the port receive frame type and filter

switch status.

show ingress

The command is used to view all port receive frame types

Command format

show ingress ethernet 0/0/1

show ingress

Parameter description

Parameter	Parameter description	Value
port-id	The port number	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4

69. DDM detection

69.1. show sfp

Command function

show sfp [ethernet port-id]

Commands to view optical module device information

Command format

show sfp ethernet 0/1/1

Parameter description

Parameter	Parameter description	Value
port-id	Fiber interface port number	0/1/1-0/1/4

70. Flow control

70.1. flow-control

Command function

(no)flow-control

Command to switch flow control function in port mode

Command format

flow-control

no flow-control

Parameter description

None

70.2. show flow-control

Command function

Show flow-control interface [ ethernet port-id]

Command to view the port flow control configuration

Command format

Show flow-control interface

Show flow-control interface ethernet 0/0/1

Parameter description

Parameter	Parameter description	Value
port-id	The port number	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4

71. Storm-Control Configuration Command

71.1. storm-suppression

Command function

storm-suppression [broadcast | multicast | unicast ] [ kbps kbps-value

| pct pct-value | pps pps-value]

Command to configure storm suppression message types and

suppression thresholds in port mode.

Command format

storm-suppression broadcast pct 1

Parameter Description

Parameter	Parameter Description	Value range
kbps-value	Based on the number of bytes in kbp	64-10240000
pct-value	Based on the percentage of port bandwidth	1-99%
pps-value	Based on message number	64-14881000

71.2. storm-suppression mode

Command function

storm-suppression mode [byte | pct| pkt]

Command to configure storm suppression mode in global mode

Command format

storm-suppression mode byte

Parameter Description

Parameter	Parameter Description	Value range
byte	Based on the number of bytes	None
pct	Based on the percentage of port bandwidth	None
pkt	Based on message number	None

71.3. no storm-suppression

Command function

no storm-suppression [broadcast | multicast | unicast ]

Command to delete storm suppression in interface mode

Command format

no storm-suppression broadcast

Parameter Description

None

71.4. show storm-suppression

Command function

show storm-suppression [ethernet port-id]

Command to show storm suppression message types and suppression

thresholds for ports

Command format

storm-suppression ethernet 0/0/1

Parameter Description

Parameter	Parameter Description	Value range
port-id	Port id	According to the physical port of the switch, for example, the 28 switch: 0/0/1-0/1/4

72. isolate-port Configuration command

72.1. no isolate-port uplink

Command function

no isolate-port uplink [all | ethernet port-id]

Command to delete the uplink port in port mode

Command format

no isolate-port uplink all

Parameter Description

Parameter	Parameter Description	Value range
port-id	Port id	According to the physical port of the switch, for example, the 28-port-switch: 0/0/1-0/1/4

72.2. isolate-port uplink ethernet

Command function

isolate-port uplink ethernet port-id

Command to specify specific uplink port in port mode

Command format

isolate-port uplink ethernet 0/0/1

Parameter Description

Parameter	Parameter Description	Value range
port-id	Port id	According to the physical port of the switch, for example, the 28-port- switch: 0/0/1-0/1/4

72.3. show isolate-port

Command function

show isolate-port

Command to view configured isolation ports

Command format

show isolate-port

Parameter Description

None

73. Port-security Configuration command

73.1. port-security enable|disable

Command function

port-security [enable|disable]

Command to configure port security

Command format

port-security enable

port-security disable

Parameter Description

None

73.2. port-security permit|deny mac-address

Command function

[no] port-security [ permit | deny ] mac-address mac-address

[ vlan-id vlan-id | ip-address ip-address ]

Command to configure (delete) MAC rules

Command format

port-security permit mac-address 2:2:2:2:2:2 ip-address 2.2.2.2

no port-security permit mac-address 2:2:2:2:2:2 ip-address 2.2.2.2

Parameter Description

Parameter	Parameter Description	Value range
mac-address	Unicast MAC address	128-bit binary in X:X:X:X:X:X format
vlan-id	VLAN id	1-4094
ip-address	Configurable valid IP address	32-bit binary in X:X:X:X format

73.3. show port-security mac-address

Command function

show port-security mac-address [ ethernet port-id]

Command to view the MAC rule configuration

Command format

show port-security mac-address ethernet 0/0/1

Parameter Description

Parameter	Parameter Description	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28- port- switch: 0 / 0 / 1 -0 / 1 / 4

73.4. port-security permit|deny ip-address

Command function

[no] port-security [ permit | deny ] ip-address start-ip [ to end-ip ]

Command to configure (delete) IP rules.

Command format

port-security permit ip-address 1.1.1.1 to 2.2.2.2

no port-security permit ip-address 1.1.1.1 to 2.2.2.2

Parameter Description

Parameter	Parameter Description	Value range
start-ip	Configurable valid IP address	32-bit binary in X.X.X.X format
end-ip	Configurable valid IP address	32-bit binary in X.X.X.X format

73.5. show port-security ip-address

Command function

show port-security ip-address [ interface ethernet port-id]

Command to view IP rule configuration

Command format

show port-security ip-address interface ethernet 0/0/1

Parameter Description

Parameter	Parameter Description	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28- port- switch: 0 / 0 / 1 - 0 / 1 / 4

73.6. port-security maximum

Command function

[no] port-security maximum value

Command to configure (delete) maximum number of addresses value rule

Command format

port-security maximum 2

no port-security maximum

Parameter Description

Parameter	Parameter Description	Value range
value	Maximum number of addresses	0-4000

73.7. port-security permit mac-address sticky

Command function

[no] port-security permit mac-address sticky

Command to switch STICKY function

Command format

no port-security permit mac-address sticky

Parameter Description

None

73.8. port-security permit mac-address sticky

Command function

[no] port-security permit mac-address sticky mac-address [vlan-id vlan-id]

Command to configure (delete) MAC STICKY rule.

Command format

port-security permit mac-address sticky 2:2:2:2:2:2

no port-security permit mac-address sticky 2:2:2:2:2:2

Parameter Description

Parameter	Parameter Description	Value range
mac-address	Unicast MAC address	128-bit binary in X:X:X:X:X:X format
vlan-id	VLAN id	1-4094

73.9. show port-security

Command function

show port-security [interface ethernet port-id]

Command to show security configuration

Command format

show port-security interface ethernet 0/0/1

Parameter Description

Parameter	Parameter Description	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28-port-switch: 0 / 0 / 1 - 0 / 1 / 4

73.10. no port-security all

Command function

no port-security all

Command to delete all port security-related configurations

Command format

no port-security all

Parameter Description

None

73.11. show port-security active-address

Command function

show port-security active-address [ configured | learned | ethernet

port-id]

Command to view the activation table entries sent down

Command format

show port-security active-address ethernet 0/0/1

Parameter Description

Parameter	Parameter Description	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28-port-switch: 0 / 0 / 1 - 0 / 1 / 4

73.12. no port-security active-address

Command function

no port-security active-address [ configured | learned | all ]

Command to delete the current activation table item

Command format

no port-security active-address all

Command format

Parameter	Parameter Description	Value range
configured	Active configuration address	None
learned	Active learning address	None
all	All active addresses	None

73.13. port-security aging static

Command function

[no]port-security aging static

Command to configure static address aging switch

Command format

port-security aging static

Command format

None

73.14. port-security aging time

Command function

[no]port-security aging time time

Vlaue command to configure (delete) port address aging time

Command format

port-security aging time 3

Command format

Parameter	Parameter Description	Value range
time	Aging time	1-1440

73.15. port-security violation

Command function

[no]port-security violation [protect | restrict | shutdown ]

Command to configure (delete) processing strategy for receiving illegal

messages

Command format

port-security violation protect

Command format

Parameter	ParameterDescription	Value range
protect	Discard message	None
restrict	Discard messages and alert	None
shutdown	Discard messages and alarms and disable ports	None

73.16. port-security recovery

Command function

[no]port-security recovery

Command to configure automatic recovery function after shutdown

Command format

port-security recovery

Command format

None

73.17. port-security recovery time

Command function

[no]port-security recovery time value

Command to configure auto recovery time after shutdown

Command format

port-security recovery time 1

Parameter Description

Parameter	Parameter Description	Value range
value	Automatic recovery time value (minutes)	1-3660

73.18. show port-security recovery

Command function

show port-security recovery [ ethernet port-id]

Command to view the configuration for automatic recovery after

shutdown

Command format

show port-security recovery ethernet 0/0/1

Parameter Description

Parameter	Parameter Description	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28-port-switch: 0 / 0 / 1 - 0 / 1 / 4

73.19. port-security violation log-interval

Command function

[no]port-security violation log-interval value

Command to configure (delete) the value of the processing time

interval between receiving illegal messages and violating the log

Command format

port-security violation log-interval 20

Parameter Description

Parameter	Parameter Description	Value range
value	Log interval time	0-86400

74. PPPoE+ Configuration command

74.1. pppoeplus

Command function

[no] pppoeplus

Command switches in port mode

Command format

pppoeplus

Parameter Description

None

74.2. pppoeplus trust

Command function

[no] pppoeplus trust

Command to configure (delete) the uplink port as a trusted port in port mode

Command format

pppoeplus trust

Parameter Description

None

74.3. show pppoeplus interface

Command function

show pppoeplus interface [ethernet port-id]

Command to configure Information View

Command format

show pppoeplus interface ethernet 0/0/1

Parameter Description

Parameter	Parameter Description	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28-port-switch: 0 / 0 / 1 - 0 / 1 / 4

74.4. pppoeplus strategy

Command function

[no] pppoeplus strategy [drop | keep | replace ]

Command to configure (delete) options processing policy in port mode

Command format

pppoeplus strategy drop

Parameter Description

Command	ParameterDescription	Value range
drop	Discard messages with vendor-specific options	None
keep	Keep messages with vendor-specific options	None
replace	Replace the vendor-specific option content of a message	None

74.5. pppoeplus drop

Command function

[no] pppoeplus drop [padi | pado]

Command to configure (delete) discard options processing policy in port mode

Command format

pppoeplus drop padi

Parameter Description

Command	Parameter Description	Value range
padi	Discard PADI and PADR messages	None
pado	Discard PADO and PADS messages	None

74.6. pppoeplus type

Command function

[no] pppoeplus type [huawei | standard | self-defined [ circuit-id { [ circuit-string ] [ vlan ] [ port ] [ switch-mac ] [ hostname ] [ client-mac ] } | remote-id { [ remote-string ] [ switch-mac ] [ hostname ] [ client-mac ] } ] Command configuration (change) message type

Command format

pppoeplus type self-defined circuit-id vlan port switch-mac hostname client-mac string no pppoeplus type

Parameter Description

Command	Parameter Description	Value range
circuit-string	Define alphabetic string	1--63 characters
remote-string	Define alphabetic string	1--63 characters

74.7. pppoeplus format

Command function

[no] pppoeplus format [ binary | ascii ]

Command to configure (Modify) format

Command format

pppoeplus format binary
Parameter Description

Command	ParameterDescription	Value range
ascii	Use ascii code format	None
binary	Use binary format	None

74.8. pppoeplus delimiter

Command function

[no] pppoeplus delimiter [ colon | dot | pound | slash | space ]

Command to configure (modify) joint mark

Command format

pppoeplus delimiter colon

Parameter Description

Command	Parameter Description	Value range
colon	:	None
dot	.	None
pound	#	None
slash	/	None
space		None

74.9. pppoeplus circuit-id

Command function

[no] pppoeplus circuit-id circuit-string

Command configuration (modify) virtual circuit ID in port mode

Command format

pppoeplus circuit-id string

Parameter Description

Command	Parameter Description	Value range
circuit-string	Custom string	1--63 Characters

75. IP-Source Configuration command

75.1. ip source

Command function

[no] ip source [ip | ip-mac | ip-mac-vlan]

Command to configure (delete) filtering ways in port mode

Command format

ip source ip

Parameter Description

Command	ParameterDescription	Value range
ip	The port filters messages only according to the source IP address of the IP message	None
ip-mac	The port filters messages according to source ip and mac	None
ip-mac-vlan	The port filters messages according to source ip, mac and vlan	None

75.2. show ip source

Command function

show ip source

Command to configure Information View

Command format

show ip source

Parameter Description

None

75.3. ip source binding

Command function

[no] ip source binding ip-address [ mac-address [ interface ethernet port-id vlan vlan-id ] ]

Command to configure (delete) bound table items

Command format

ip source binding 1.1.1.1 2:2:2:2:2 interface ethernet 0/0/1 v 1

Parameter Description

Command	Parameter Description	Value range
ip-address	Configurable valid IP address	32-bit binary in X.X.X.X format
mac-address	Configurable port mac address	48-bit binary in X:X:X:X:X:X format
port-id	Port id	Depend on the physical port of the switch, for example, 28-port-switch: 0 / 0 / 1 - 0 / 1 / 4
vlan-id	VLAN id	1-4094

75.4. show ip source binding

Command function

show ip source binding [ip-address]

Command to configure (delete) bound table items

Command format

show ip source binding 1.1.1.1

Parameter Description

Command	Parameter Description	Value range
ip-address	Configure valid IP addresses	32-bit binary in X.X.X.X format

75.5. ip source vlan

Command function

[no] ip source vlan vlan-id

Command to enable (disable) filtering function of vlan

Command format

ip source vlan 1

Parameter Description

Command	Parameter Description	Value range
vlan-id	VLAN id	STRING<1-128>

75.6. show ip source vlan

Command function

show ip source vlan

Command to view configuration information

Command format

show ip source vlan

Parameter Description

None

75.7. ip source permit-igmp

Command function

[no] ip source permit-igmp

Command to configure (delete) whether filter igmp

Command format

ip source vlan permit-igmp

Parameter Description

None

75.8. show ip source permit-igmp

Command function

show ip source permit-igmp

Command to view configuration information

Command format

show ip source vlan permit-igmp

Parameter Description

None

76. IPv6-Source Configuration Command

76.1. ipv6-source-guard

Command function

[no] ipv6-source-guard

Command to configure (delete) filtering way in port mode

Command format

ipv6-source-guard

Parameter Description

None

76.2. show ipv6-source-guard

Command function

show ipv6-source-guard

Command to configure (delete) filtering in port mode

Command format

show ipv6-source-guard

Parameter Description

None

76.3. ipv6-source-guard bind ip

Command function

ipv6-source-guard bind ip ipv6-address [[mac mac-address]

interface ethernet port-id ] vlan vlan-id ]

Command to configure (delete) bind table items in global mode

Command format

ipv6-source-guard bind ip 2::1 mac 2:2:2:2:2:2 interface ethernet

0/0/1 v 1

Parameter Description

Command	Parameter Description	Value range
ipv6-address	Configurable valid ipv6 address	128-digit binary in the form of X: X: X: X: X: X:X format
mac-address	Configurable port mac address	48-digit binary in the form of X: X: X: X: X format
port-id	Port id	Depend on the physical port of the switch, for example, 28-port-switch 0 / 0 / 1 - 0 / 1 / 4
vlan-id	VLAN id	1-4094

76.4. show ipv6-source-guard bind

Command function

show ipv6-source-guard bind [ip ipv6-address]

Command to configure (delete) bound table items in global mode

Command format

show ipv6-source-guard bind ip 2::1

Parameter Description

Command	Parameter	Value range
	Description
ipv6-address	Configurable valid ipv6 address	128-digit binary in the form of X: X: X: X: X: X:X format

76.5. ipv6-source-guard vlan

Command function

[no]ipv6-source-guard vlan vlan-id

Command to enable or disable filter function of vlan

Command format

ipv6-source-guard vlan 1

Parameter Description

Command	Parameter Description	Value range
vlan-id	VLAN id	1-4094

76.6. show ipv6-source-guard vlan

Command function

show ipv6-source-guard vlan

Command to view configuration information

Command format

show ipv6-source-guard vlan

Parameter Description

None

77. 802.1X Configuration command

77.1. dot1x

Command function

dot1x enable | disable

Command to enable or disable global 802.1x in global mode

Command format

dot1x enable

Parameter Description

none

77.2. dot1x eap-relay enable|disable

Command function

dot1x eap-relay enable|disable

Command sets the protocol interaction between the system and the

RADIUS server in global mode

Command format

dot1x eap-relay enable

Parameter Description

Command	Parameter Description	Value range
disable	disable	none
enable	enable	none

77.3. dot1x port-method

Command function

dot1x port-method [ macbased | portbased ]

Command to enable port 802.1X authentication in port mode

Command format

dot1x port-method portbased

Parameter Description

none

77.4. dot1x port-control

Command function

[no]dot1x port-control [auto | forceauthorized | forceunauthorized]

Command to set (delete) port control mode in port mode

Command format

dot1x port-control auto

Parameter Description

none

77.5. dot1x re-authenticate

Command function

dot1x re-authenticate

The command is configured in port mode to reauthenticate

immediately

Command format

dot1x re-authenticate

Parameter Description

none

77.6. dot1x re-authentication

Command function

[no]dot1x re-authentication

Command to open (close) port periodic reauthentication in port

mode

Command format

dot1x re-authentication

Parameter Description

none

77.7. dot1x timeout re-authperiod

Command function

[no]dot1x timeout re-authperiod time

Command to configure (delete) port periodic reauthentication time

in port mode

Command format

dot1x timeout re-authperiod 10

Parameter Description

Command	ParameterDescription	Value range
time	Reauthentication time	10-3600

77.8. dot1x multicast-trigger

Command function

[no]dot1x multicast-trigger ]

Command to turn the Multicast trigger function on (off) in port

mode

Command format

dot1x multicast-trigger

Parameter Description

none

77.9. dot1x multicast-period

Command function

[no]dot1x multicast-period

Command to open (restore) multicast-period interval in port mode

Command format

dot1x multicast-period 30

Parameter Description

Command	ParameterDescription	Value range
time	Multicat period interval,unit is second;default is 60s	10-600

77.10. dot1x max-user-num

Command function

[no]dot1x max-user-num user-num

The command opens (removes) in port mode to allow the maximum number of authenticated users

Command format

dot1x max-user-num 1

Parameter Description

Command	Parameter Description	Value range
user-num	User number	1-100

77.11. dot1x user cut

Command function

dot1x user cut [ username user-name | mac-address mac-address ]

The command deletes the specified online user

Command format

dot1x user cut mac-address 2:2:2:2:2:2

Parameter Description

Command	ParameterDescription	Value range
user-name	Delete user name	1-32 chars
mac-address	Mac address	48 bit binary number in format of X:X:X:X:X:X

77.12. dot1x keepalive

Command function

[no]dot1x keepalive

Command to turn on (off) heartbeat detection in port mode

Command format

dot1x keepalive

Parameter Description

none

77.13. dot1x keepalive period

Command function

[no]dot1x keepalive period time

Command to configure (restore) heartbeat detection time in global

mode

Command format

dot1x keepalive period 2

Parameter Description

Command	ParameterDescription	Value range
time	Unit issecond,default is25s	1-3600

77.14. dot1x timeout quiet-period

Command function

[no]dot1x timeout quiet-period time

Command to configure (restore) the silence time in global mode

Command format

dot1x timeout quiet-period 2

Parameter Description

Command	ParameterDescription	Value range
time	Unit issecond,default isOs	0-600

77.15. dot1x timeout server-timeout

Command function

[no]dot1x timeout server-timeout time

Command to configure (restore) the server timeout in global mode

Command format

dot1x timeout server-timeout 20

Parameter Description

Command	ParameterDescription	Value range
time	Unit issecond,default is30s	15-3600

77.16. dot1x timeout supp-timeout

Command function

[no]dot1x timeout supp-timeout time

Command to configure (restore) client timeout in global mode

Command format

dot1x timeout supp-timeout 20

Parameter Description

Command	ParameterDescription	Value range
time	Unit issecond,default is30s	15-3600

77.17. dot1x portbased host-mode

Command function

[no]dot1x portbased host-mode [multi-hosts | single-host]

Command to configure (delete) host mode in port mode based on

port authentication mode

Command format

dot1x portbased host-mode single-host

Parameter Description

none

77.18. dot1x guest-vlan

Command function

[no]dot1x guest-vlan

Command to configure (delete) the guest VLAN to configure the port

in port mode

Command format

dot1x guest-vlan 10

Parameter Description

Command	Parameter Description	Value range
vlan-id	VLAN ID	1-4094

77.19. dot1x guest-acl

Command function

[no]dot1x guest-acl

Command to configure (delete) the guest ACL to configure the port

in port mode

Command format

dot1x guest-acl 10

Parameter Description

Command	ParameterDescription	Value range
number	acl number	STRING<1-64>

77.20. dot1x max-authfail

Command function

[no]dot1x max-authfail

Command to configure (delete) number of authentication failures in

port mode

Command format

dot1x max-authfail 10

Parameter Description

Command	ParameterDescription	Value range
times	Max authfail times	1-10

77.21. dot1x default-active-vlan

Command function

[no]dot1x default-active-vlan

The command is configured (deleted) in port mode, default-active-VLAN is the Default active VLAN, used when 802.1x user passes authentication on the Radius server, but no Radius VLAN is issued, at this time the user can only access the resources in default-active-VLAN.

Command format

dot1x default-active-vlan 10

Parameter Description

Command	Parameter Description	Value range
vlan-id	VLAN ID	1-4094

77.22. dot1x eapol-relay

Command function

[no]dot1x eapol-relay

Command to configure enable or disable EAPOL messaging in port

mode

Command format

dot1x eapol-relay

Parameter Description

none

77.23. dot1x eapol-relay uplink

Command function

[no]dot1x eapol-relay uplink

Command to configure (remove) the uplink port function for EAPOL messaging in port mode

Command format

dot1x eapol-relay uplink

Parameter Description

none

77.24. dot1x max-req

Command function

[no]dot1x max-req

Command configuration (restore) The number of times the client resend the request EAP-Request/Identity message when it responds to the EAP-Response/Identity message

Command format

dot1x max-req 2

Parameter Description

Command	ParameterDescription	Value range
timers	Max send message times	1-10

77.25. dot1x max-reauth

Command function

[no]dot1x max-reauth

Command configuration (restore) The number of times the client

resends the request EP-Request/MD5 Challenge message when it responds to THE EP-Response/MD5 Challenge message

Command format

dot1x max-reauth 2

Parameter Description

Command	Parameter Description	Value range
timers	Max send times	1-10

77.26. dot1x critical-vlan

Command function

[no]dot1x critical-vlan

Command to configure (delete) this VLAN feature in port mode when authentication fails due to server unreachable

Command format

dot1x critical-vlan 10

Parameter Description

Command	Parameter Description	Value range
vlan-id	VLAN ID	1-4094

77.27. dot1x radius-acl-format

Command function

dot1x radius-acl-format string | integer

The command configure radius acl format type

Command format

dot1x radius-acl-format string

Parameter Description

none

77.28. dot1x native-vlan-free

Command function

[no]dot1x native-vlan-free

The command turns on and off in port mode to allow unauthenticated users to communicate within the PVID's VLAN

Command format

dot1x native-vlan-free

Parameter Description

none

77.29. dot1x station-move

Command function

dot1x station-move enable | disable

Command to turn on and off the authentication port migration function in port mode; After enabling migration, users who have been authenticated on one port can be migrated to another port for authentication, and the authentication results on the original port will be deleted before being authenticated on the new port.

With migration disabled, a user who has been authenticated on one port cannot be migrated to another port for authentication unless the user has been offline on the original port.

Command format

dot1x station-move enable

Parameter Description

none

77.30. dot1x syslog

Command function

dot1x syslog enable | disable

Command to enable/disable failure notifications in global mode

Command format

dot1x syslog enable

Parameter Description

none

77.31. show dot1x multicast-trigger

Command function

show dot1x multicast-trigger [ interface ethernet port-id]

The command displays the multicast-trigger of the 802.1X authenticated port

Command format

show dot1x multicast-trigger interface ethernet 0/0/1

Parameter Description

Command	ParameterDescription	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28- port- switch: 0/0/1-0/1/4

77.32. show dot1x interface

Command function

show dot1x interface [ interface ethernet port-id]

Command displays switch port configuration information

Command format

show dot1x interface ethernet 0/0/1

Parameter Description

Command	ParameterDescription	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28- port- switch: 0/0/1-0/1/4

77.33. show dot1x users

Command function

show dot1x users [ { interface ethernet port-id } | { mac-address mac-

address} ]

The command displays the 802.1x session

Command format

show dot1x users interface ethernet 0/0/1

Parameter Description

Command	Parameter Description	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28- port- switch: 0/0/1-0/1/4
mac-address	Mac address	48 bit binary number in format of X:X:X:X:X:X

77.34. show dot1x eapol-relay

Command function

show dot1x eapol-relay [ interface ethernet port-id ]

Command to view the EAPOL passthrough configuration

Command format

show dot1x eapol-relay interface ethernet 0/0/1

Parameter Description

Command	ParameterDescription	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28- port- switch: 0/0/1-0/1/4

77.35. show dot1x keepalive

Command function

show dot1x keepalive [ interface ethernet port-id ]

The command displays the heartbeat detection function configuration

Command format

show dot1x keepalive interface ethernet 0/0/1

Parameter Description

Command	ParameterDescription	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28- port- switch: 0/0/1-0/1/4

77.36. show dot1x config-vlan

Command function

show dot1x config-vlan[ interface ethernet port-id ]

The command displays visitor VLAN information

Command format

show dot1x config-vlan interface ethernet 0/0/1

Parameter Description

Command	ParameterDescription	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28- port- switch: 0/0/1-0/1/4

77.37. show dot1x port-auth

Command function

show dot1x port-auth

Command to see if the port is currently authenticated

Command format

show dot1x port-auth

Parameter Description

none

77.38. show dot1x timeout

Command function

show dot1x timeout

The command displays the silent time, client timeout, and server timeout

Command format

show dot1x timeout

Parameter Description

none

77.39. show dot1x

Command function

show dot1x

Command to see if the authentication system is on and the authentication type

Command format

show dot1x

Parameter Description

None

77.40. show dot1x guest-acl

Command function

show dot1x guest-acl

Command to view guest acl information

Command format

show dot1x guest-acl

Parameter Description

none

77.41. show dot1x radius-acl

Command function

show dot1x radius-acl

Command to view radius acl information

Command format

show dot1x radius-acl

Parameter Description

none

78. Radius Configuration command

78.1. radius host

Command function

[no]radius host name

Command to create(delete) RADIUS configuration scheme in AAA mode.

Parameter Description

Parameter	Parameter Description	Value range
name	Configuration scheme name	1-32 Character

78.2. primary-auth-ip

Command function

[no]primary-auth-ip ipaddr port

Command to configure (delete) the primary authentication server in radius mode

Command format

primary-auth-ip 1.1.1.1 2

Parameter Description

Parameter	Parameter Description	Value range
ipaddr	Configurable valid IP address	32-bit binary in X.X.X.X format
port	Master server authentication port	1-65535

78.3. second-auth-ip

Command function

[no]second-auth-ip ipaddr port

Command to configure (delete) secondary authentication server in radius mode.

Command format

second-auth-ip 1.1.1.1 2
Parameter Description

Parameter	Parameter Description	Value range
ipaddr	Configurable valid IP address	32-bit binary in X.X.X.X format
port	Backup server authentication port	1-65535

78.4. primary-acct-ip

Command function

[no]primary-acct-ip ipaddr port

Command to configure (delete) the primary billing server in radius

mode

Command format

primary-acct-ip 1.1.1.1 2

Parameter Description

Parameter	Parameter Description	Value range
ipaddr	Configurable valid IP address	32-bit binary in X.X.X.X format
port	Master server authentication port	1-65535

78.5. second-acct-ip

Command function

[no]second-acct-ip ipaddr port

Command to configure (delete) the billing server in radius mode

Command format

second-acct-ip 1.1.1.1 2

Parameter Description

Parameter	Parameter Description	Value range
ipaddr	Configurable valid IP address	32-bit binary in X.X.X.X format.
port	Backup server authentication port	1-65535

78.6. auth-secret-key

Command function

[no]auth-secret-key keystring

Command to configure (delete) the authentication server shared key in radius mode

Command format

auth-secret-key keystring

Parameter Description

Parameter	Parameter Description	Value range
keystring	shared key	1-16 character

78.7. acct-secret-key

Command function

[no]acct-secret-key keystring

Command to configure (delete) the shared key for the billing server in radius mode

Command format

acct-secret-key keystring

Parameter Description

Parameter	Parameter Description	Value range
keystring	shared key	1-16 Character

78.8. nas-ipaddress

Command function

[no]nas-ipaddress ipaddr

Command to configure the IP address of the radius client in radius mode

Command format

nas-ipaddress 1.1.1.1

Parameter Description

Parameter	Parameter Description	Value range
ipaddr	Configurable valid IP address	32-bit binary in X.X.X.X format

78.9. username-format

Command function

username-format [ with-domain | without-domain]

Command in radius mode to set whether the user name should have a domain name when the message is delivered to the current radius server

Command format

username-format without-domain

Parameter Description

Parameter	Parameter Description	Value range
with-domain	User name with domain name	None
without-domain	User name without domain name	None

78.10. realtime-account

Command function

[no]realtime-account

Command to configure (delete) real-time account in radius mode

Command format

realtime-account

Parameter Description

None

78.11. realtime-account interval

Command function

realtime-account interval time

Command to configure the real-time account send interval in radius mode

Command format

realtime-account interval 3

Parameter Description

Parameter	Parameter Description	Value range
time	Radius server real-time account interval, unit is minute	1-255

78.12. preemption-time

Command function

preemption-time Preemption-time

Command to configure preemption-time in radius mode

Command format

preemption-time 1

Parameter Description

Parameter	Parameter Description	Value range
Preemption-time	Preemption time (unit is minute), 0 by default(It indicates unpreemption)	0-1440

78.13. local-user username

Command function

[no]local-user username name [password pwd|encrypt password

encrypt-pwd [vlan vid]]

Command to configure (delete) local user information in AAA mode

Command format

local-user username usernamepassword pass vlan 1

Parameter Description

Parameter	Parameter Description	Value range
name	Local user name	1-64 characters, any character available
pwd	Local user password	1-64 characters, any character available
Encrypt-pwd	Local user encrypt password	STRING<2-130>
vid	VLAN id	1-4094

78.14. default domain-name

Command function

default domain-name [ enable domain-name | disable ]

Command to configure or disable the default domain in AAA mode

Command format

default domain-name disable

Parameter Description

Parameter	Parameter	Value range
	Description
domain-name	Default domain name	1-24 Character

78.15. domain

Command function

[no]Idomain domain-name

Command to create (delete) a domain scheme in AAA mode

Command format

domain domain1

Parameter Description

Parameter	Parameter Description	Value range
domain-name	domain name	1-24 Character

78.16. scheme

Command function

scheme [local | radius [none] ]

Command to configure authentication using radius server or local user

information in domain mode

Command format

scheme local

Parameter Description

None

78.17. radius host binding

Command function

[no]radius host binding radius-name

Command to select (delete the radius server) for the current domain in

domain mode

Command format

radius host binding 1

Parameter Description

Parameter	Parameter Description	Value range
radius-name	RADIUS Configuration scheme name	1-32 character

78.18. access-limit

Command function

access-limit [ enable number | disable ]

Command to configure (disable) the maximum number of

authenticated users of current domain in domain mode

Command format

access-limit enable 3

Parameter Description

Parameter	Parameter Description	Value range
number	Number of connections allowed in the domain	1-640

78.19. state

Command function

state [ active | block ]

The command activates (blocks) the current domain in domain mode

Command format

state active

Parameter Description

None

78.20. accounting-on

Command function

accounting-on [ enable num | disable ]

Command to configure accounting-on times in AAA mode

Command format

accounting-on enable 33

Parameter Description

Parameter	Parameter Description	Value range
num	Configure the number of times of account-on sent	1-255

78.21. h3c-cams

Command function

h3c-cams [ enable | disable ]

Command to configure the H3C Cams compatibility feature in AAA mode

Command format

h3c-cams enable

Parameter Description

None

78.22. radius accounting

Command function

[no]radius accounting

Command to enable(disable) accounting function in AAA mode.

Command format

radius accounting

Parameter Description

None

78.23. radius server-disconnect drop 1x

Command function

[no]radius server-disconnect drop 1x

Command to enable (disable) disconnect user while account message has no respond in AAA mode.

Command format

radius server-disconnect drop 1x

Parameter Description

None

78.24. radius 8021p

Command function

radius 8021p enable |disable

Command to enable (delete) RADIUS down port priority in AAA mode.

Command format

radius 8021p enable

Parameter Description

None

78.25. radius password-encryption

Command function

[no]radius password-encryption

Command to enable (delete) Encryption the secret key and the radius

local password

Command format

radius password-encryption

Parameter Description

None

78.26. radius vlan enable

Command function

radius vlan enable|disable

Command to enable (delete) RADIUS down port PVID in AAA mode.

Command format

radius vlan enable

Parameter Description

None

78.27. radius vlan-format

Command function

radius vlan-format[ integer |string2decimal|string2hex|vlanname ]

Command to configure vlan format type in AAA mode.

Command format

radius vlan-format integer

Parameter Description

none

78.28. radius mac-address-number

Command function

[no]radius mac-address-number enable|disable

Command to enable (delete) MAC address number limits of d RADIUS

down port

in AAA mode.

Command format

radius mac-address-number enable

Parameter Description

None

78.29. radius config-attribute

Command function

Modify the radius property number in AAA Mode

Command format

radius config-attribute access-bandwidth[[downlink vendor-

type][unit bps|kbps][uplink vendor-type]]

Parameter Description

Parameter	Parameter Description	Value range
vendor-type	Property id	1-500

78.30. radius attribute

Command function

Configure the version information of the sending client to the radius server in AAA mode

Command format

radius attribute client-version

no radius attribute client-version

Parameter Description

None

78.31. dnrate-value

Command function

Command to configure uplink rate property value while enable h3c-cams enable function in AAA mode

Command format

dnrate-value

Parameter Description

Parameter	Parameter Description	Value range
value	Default is 5	1-32

78.32. uprate-value

Command function

Command to configure uplink rate property value while enable h3c-cam enable function in AAA mode.

Command format

uprate-value

Parameter Description

Parameter	Parameter Description	Value range
value	Default is 2	1-32

78.33. radius bandwidth-limit

Command function

[no]radius bandwidth-limit enable|disable

Command to enable (delete) RADIUS downlink port bandwidth control in AAA mode.

Command format

Radius bandwidth-limit enable

Parameter Description None

78.34. show radius attribute

Command function

show radius attribute

Command to view the version information from the sending client to the radius server information

Command format

show radius attribute

Parameter Description

None

78.35. show radius config-attribute

Command function

show radius config-attribute

Command to view and show the radius property

Command format

show radius config-attribute

Parameter Description

None

78.36. show radius host

Command function

show radius host [hostname]

Command to show radius service configuration information

Command format

show radius host

Parameter Description

Parameter	Parameter Description	Value range
hostname	Radius server name	1-32 Character

78.37. show rate-attribute-value

Command function

View the rate property run information

Command format

show rate-attribute-value

Parameter Description

None

78.38. show domain

Command function

show domain [domain-name]

Command to view domain configuration.

Command format

show domain

Parameter Description

Parameter	Parameter Description	Value range
domain-name	RadiusServer domain name	STRING<1-24>

79. Pvlan Configuration command

79.1. private-vlan primary

Command function

[no]private-vlan primary

Command is used to configure (delete) the primary VLAN in vlan mode

Command format

private-vlan primary

Parameter Description

None

79.2. private-vlan isolated

Command function

private-vlan isolated

Command is used to configure isolated VLANs in vlan mode

Command format

private-vlan isolated

Parameter Description

None

79.3. private-vlan community

Command function

private-vlan community

Command is used in vlan mode to configure private-vlan community

Command format

private-vlan community

Parameter Description

None

79.4. private-vlan association

Command function

private-vlan association vlan-list

Command to configure (delete) Primary VLAN associate isolated vlan

and private-vlan community

Command format

private-vlan association 2-100
Parameter Description

Parameter	Parameter Description	Value range
vlan-list	Vlan id, for example: 1-100	1-4094

79.5. switchport private-vlan

Command function

[no]switchport private-vlan[ trunk | promiscuous[vlan-id]]

host[vlan-id]]

Command is used in port mode to configure (delete) ports for

promiscuous \ trunk\ host ports

Command format

switchport private-vlan host

switchport private-vlan promiscuous 2

Parameter Description

Parameter	Parameter Description	Value range
vlan-id	Vlan id	1-4094

79.6. show private-vlan

Command function

show private-vlan[vlan-id]

Command format

show private-vlan

Parameter Description

Parameter	Parameter Description	Value range
vlan-id	Vlan id	1-4094

79.7. show private-vlan interface

Command function

show private-vlan interface [ethernet port-id]

Command format

show private-vlan interface ethernet 0/0/1

Parameter Description

Parameter	Parameter Description	Value range
port-id	Port id	Depend on physical port of Switch, for example, 28-Port Switch:0/0/1-0/1/4.

80. Muser Configuration command

80.1. muser local

Command function

muser local

Command to configure use muser local.

Command format

muser local

Parameter Description

None

80.2. muser radius

Command function

muser radius radius-name [pap | chap] [account |local | none]

Command to configure muser radius

Command format

muser radius admin chap account local

Parameter Description

Parameter	Parameter Description	Value range
radius-name	Radius server name	STRING<1-32>

80.3. aaa

Command function

aaa

Command to enter AAA configuration mode.

Command format

aaa

Parameter Description

None

80.4. muser tacacs+

Command function

muser tacacs+ [ [author] [account] [command-account][command-author] [local][none]]

Command to configure muser tacacs+.

Command format

user tacacs+ account command-author command-account local

Parameter Description

None

80.5. show muser

Command function

show muser

Command format

show muser

Parameter Description

None

80.6. tacacs+ encrypt-key

Command function

[no] tacacs+ encrypt-key

Command password encryption display function

Command format

tacacs+ encrypt-key

Parameter Description

None

80.7. tacacs+ authentication-type

Command function

tacacs+ authentication-type [ascii | chap | pap]

Command configuration authentication type

Command format

tacacs+ authentication-type chap

Parameter Description

None

80.8. tacacs+ primary server

Command function

tacacs+ primary server ip-address [[encrypt-key | key] value] [port

port-num] [timeout time-value]

Command to configure the tacacs master server

Command format

tacacs+ primary server 1.1.1.1 encrypt-key 1 port 1 timeout 1

Parameter Description

Parameter	Parameter Description	Value range
ip-address	Tacacs+ authentication from the main server IP address	32-bit binary in X.X.X.X format
value	Key ID	Key:1-32 Character Encrypted key: 1-66 character
port-num	Port number	1-65535
time-value	Connection timeout (seconds)	1-70

80.9. tacacs+ secondary server

Command function

tacacs+ secondary server ip-address [[encrypt-key | key] value]

[port port-num] [timeout time-value]

Command to configure tacasc+ server

Command format

tacacs+ secondary server 1.1.1.1 encrypt-key 1 port 1 timeout 1

Parameter Description

Parameter	Parameter Description	Value range
ip-address	Tacacsauthentication secondary IP address	32-bit binary in X.X.X.X format
value	Key ID	Key:1-32 characterEncryptionkey: 1-66 Character
port-num	Port id	1-65535
time-value	Connection time out (s)	1-70

80.10. tacacs+ preemption-time

Command function

tacacs+ preemption-time value

Command to configure the master server to switch after recovery

Command format

tacacs+ preemption-time 2

Parameter Description

Parameter	Parameter Description	Value range
value	Preemption time (unit : min), 0 by default (indicates no preemption)	0-1440

80.11. show tacacs+

Command function

show tacacs+

Command format

show tacacs+

Parameter Description

None

81. Cpu-Alarm Command Manual

81.1. alarm cpu

Command function

(no) alarm cpu

Command switch CPU alarm

Command format

alarm cpu

Parameter description

None

81.2. alarm cpu threshold

Command function

(no)alarm cpu threshold busy value | unbusy value

Command configuration (remove) threshold information

Command format

alarm cpu threshold busy 21 unbusy 2

no alarm cpu threshold

Parameter description

Parameter	Parameter description	Value
value	Threshold (%)	0-100

81.3. show alarm cpu

Command function

show alarm cpu

command to view alarm information

Command format

show alarm cpu

Parameter description

None

82. Port-Alarm configuration manual

82.1. alarm all-packets

Command function

(no) alarm all-packets

Global alarms are configured on the global switch and port alarms are configured on the port switch.

Command format

alarm all-packets

Parameter description

None

82.2. show alarm all-packets

Command function

show alarm all-packets [interface [ ethernet port-id ]]

Command to view alarm information

Command format

show alarm all-packets

show alarm all-packets interface ethernet 0/0/1

Parameter description

Parameter	Parameter description	Value
port-id	The port number	According to the physical port of the switch, for example, 28-port switch: 0/0/1-0/1/4

83. Sylsog configuration manual

83.1. logging

Command function

(no) logging

Command switch log switch

Command format

logging

Parameter description

None

83.2. show logging

Command function

Show logging

Command to view configuration information

Command format

Show logging

Parameter description

None

83.3. logging sequence-numbers

Command function

(no)logging sequence-numbers

Command switch log sequence-numbers

Command format

logging sequence-numbers

Parameter description

None

83.4. logging timestamps

Command function

(no)logging timestamps [ notime | uptime | datetime | rfc5424]

Command configuration (restoration) timestamp type

Command format

logging timestamps notime

no logging timestamps

Parameter description

Parameter	Parameter description	Value
notime	Don't show timestamps	None
uptime	Boot time display timestamp	None
datetime	Display timestamps in absolute time	None
rfc5424	rfc5424 display timestamps	None

83.5. logging monitor all | monitor-num

Command function

(no) logging monitor [all | monitor-num]

Command to open (close) output to terminal switch

Command format

no logging monitor all

Parameter description

Parameter	Parameter description	Value
monitor-num	Monitor number	0-5

83.6. logging monitor all | monitor-num level-value | none | level-list

Command function

logging monitor all | monitor-num level-value | none | level-list [start-level to end-level] | level-value ] [ module module-name ] command to configuration log filtering rules

Command format

logging monitor 3 level-lis 2 module igmp

Parameter description

Parameter	Parameter description	Value
monitor-num	Monitor number	0-5
level-value	Information level	0-7
start-leve	Information level	0-7
end-level	Information level	0-7
module-name	Module name	Switch feature module

83.7. show logging filter monitor

Command function

show logging filter monitor monitor-num

Command to view filter rules

Command format

show logging filter monitor 5

Parameter description

Parameter	Parameter description	Value
monitor-num	Monitor number	0-5

83.8. no logging monitor all | monitor-num filter

Command function

no logging monitor [ all | monitor-num ] filter

Command to delete the filter rule

Command format

no logging monitor 5 filter

Parameter description

Parameter	Parameter description	Value
monitor-num	Monitor number	0-5

83.9. logging buffered

Command function

(no)logging buffered

Command switch output to buffer

Command format

logging buffered

no logging buffered

Parameter description

None

83.10. logging buffered level-value | none | level-list

Command function

logging buffered level-value | none | level-list [[start-level to end-level]]

level-value ] [ module module-name ]

command to configure log filtering rules

Command format

logging buffered level-list 2 3 module rip

Parameter description

Parameter	Parameter description	Value
level-value	Information level	0-7
start-level	Information level	0-7
end-level	Information level	0-7
module-name	Module name	Switch feature module

83.11. show logging filter buffered

Command function

show logging filter buffered command to view filter rules

Command format

show logging filter buffered

Parameter description

None

83.12. no logging buffered filter

Command function

no logging buffered filter Command to delete the filter rule

Command format

no logging buffered filter

Parameter description

None

83.13. show logging buffered

Command function

Show logging buffered [ level-value | count | level-list [ start-level to end-

level | value ]] [ module module-name ]

Command to delete the filter rule

Command format

show logging buffered 3 module rip

Parameter description

Parameter	Parameter description	Value
level-value	Information level	0-7
start-leve	Information level	0-7
end-level	Information level	0-7
module-name	Module name	Switch feature module

83.14. logging flash

Command function

(no) logging flash

Command turns on (off) the output to memory switch

Command format

logging flash

no logging flash

Parameter description

None

83.15. logging flash level-value | none | level-list

Command function

logging flash level-value | none | level-list [start-level to end-level | level-value] [module module-name]

Command to configure log filtering rules

Command format

logging flash level-list 2 3 module rip

Parameter description

Parameter	Parameter description	Value
level-value	Information level	0-7
start-level	Information level	0-7
end-level	Information level	0-7
module-name	Module name	Switch feature module

83.16. show logging filter flash

Command function

show logging filter flash

Console Reference Guide Intellinet Network Solutions

Command to view filter rules

Command format

show logging filter flash

Parameter description

None

83.17. no logging flash filter

Command function

no logging flash filter

command to delete the filter rule

Command format

no logging flash filter

Parameter description

None

83.18. logging flash interval

Command function

[no] logging flash interval value

Command configuration (remove) save cycle

Command format

logging flash interval 30

no logging flash interval

Parameter description

Parameter	Parameter description	Value
value	Write flash time interval (time)	30-180

83.19. logging flash msg-number

Command function

[no] logging flash msg-number value

Command configuration (remove) saves log specifications each time

Command format

logging flash msg-number 100

no logging flash msg-number

Parameter description

Parameter	Parameter description	Value
value	Write flash number	100-500

83.20. show logging flash

Command function

Show logging flash [ level-value | count | level-list [ start-level to end-level ]

value ]] [ module module-name]

Command to view log information in flash

Command format

show logging flash 3 module rip

Parameter description

Parameter	Parameter description	Value
level-value	Information level	0-7
start-level	Information level	0-7
end-level	Information level	0-7
module-name	Module name	Switch feature module

83.21. logging ip-address

Command function

(no) logging ip-address [port-num]

Command to configure (delete) log server

Command format

logging 1.1.1.1 25

no logging 1.1.1.1 25

Parameter description

Parameter	Parameter description	Value
ip-address	Syslog server IP address	32-bit binary number in the format X:X:X:X
port-num	Port number, default is 514	1-65535

83.22. logging host all | ip-address

Command function

(no) logging host all | ip-address

Command to open (close) log server

Command format

logging host 1.1.1.1

no logging host 1.1.1.1

Parameter description

Parameter	Parameter description	Value
ip-address	Syslog server IP address	32-bit binary number in the format X:X:X:X

83.23. logging host all | ip-address level-value | none | level-list

Command function

logging host all | ip-address level-value | none | level-list [ start-level to

end-level | level-value] [module module-name]

Command to configure filtering rules

Command format

logging host 1.1.1.1 3 module ospf

Parameter description

Parameter	Parameter description	Value
ip-address	Syslog server IP address	32-bit binary number in the format X:X:X:X
level-value	Information level	0-7
start-level	Information level	0-7
end-level	Information level	0-7
module-name	Module name	Switch feature module

83.24. no logging host all | ip-address filter

Command function

no logging host [all | ip-address] filter

command to restore the default rule

Command format

no logging host all filter

Parameter description

Parameter	Parameter description	Value
ip-address	Syslog server IP address	32-bit binary number in the format X:X:X:X

83.25. logging facility

Command function

(no) logging facility [ clock1 | clock2 | ftp | kernel | lineprinter | localuse0 | localuse1 | localuse2 | localuse3 | localuse4 | localuse5 | localuse6 | localuse6 | localuse7 | logalert | logaudit | mail | networkknews | ntp | security1 | security2 | syslogd | system | userlevel | uucp ]
Command configuration (delete) logging tool name

Command format

no logging facility

Parameter description

None

83.26. logging source

Command function

(no)logging source ip-address | loopback-interface if-id
Command to configure (remove) the source IP address of log packets

Command format

no logging source

Parameter description

Parameter	Parameter description	Value
ip-address	Configure and valid IP address	32-bit binary number in the format X:X:X:X
if-id	Lookback interface id	0-1

83.27. logging snmp-agent

Command function

logging snmp-agent

Command to turn on(off) output log to SNMP agent

Command format

no logging snmp-agent

Parameter description

None

83.28. logging snmp-agent level-value | none | level-list

Command function

logging snmp-agent level-value | none | level-list [ start-level to end-level |

level-value ] [ module module-name ]

Command to configure filtering rules

Command format

no logging snmp-agent

Parameter description

Parameter	Parameter description	Value
level-value	Information level	0-7
start-level	Information level	0-7
end-level	Information level	0-7
module-name	Module name	Switch feature module

83.29. show logging filter snmp-agent

Command function

show logging filter snmp-agent

Command to view filter rules

Command format

show logging filter snmp-agent

Parameter description

None

83.30. no logging snmp-agent filter

Command function

no logging snmp-agent filter

Command to restore the default filter rule

Command format

no logging snmp-agent filter

Parameter description

None

83.31. debug

Command function

(no) debug all | module-name

Command to enable (disable) the debugging function of the module

Command format

debug all

Parameter description

Parameter	Parameter description	Value
module-name	Module name	Switch feature module

83.32. show debug

Command function

show debug

Command to view the configuration information of the debugging

function

Command format

show debug

Parameter description

None

84. STP/RSTP configuration command

84.1. stp

Command function

Global or physical interface enables stp

Command format

stp

no stp

Parameter description

None

84.2. stp mode

Command function

Modify the stp mode

Command format

stp mode

no stp mode

Parameter description

None

84.3. stp hello-time

Command function

Configuration the interval for sending bpdu packets

Command format

stp hello-time

no stp hello-time

Parameter description

Parameter	Parameter description	Value
seconds		1-10 s, the default is 2s

84.4. stp forward-time

Command function

Configuration the forward-delay time

Command format

stp forward-time

no stp forward-time

Parameter description

Parameter	Parameter description	Value
seconds		4-30 s, the default 15s

84.5. stp max-age

Command function

Set the maximum time interval for aging STP packets

Command format

stp max-age

no stp max-age

Parameter description

Parameter	Parameter description	Value
num		6-40 s, 20s

84.6. stp pathcost-standard

Command function

Modify the stp cost calculation method

Command format

stp pathcost-standard

no stp pathcost-standard

Parameter description

Parameter	Parameter description	Value
dot1d-1998	Old way of calculation
dot1t

84.7. stp priority

Command function

Modify stp priority

Command format

stp priority

no stp priority

Parameter description

Parameter	Parameter description	Value
num	Priority size	0-61440 and 4094 multiples, default 32768

84.8. stp root-guard action

Command function

stp root-guard

Command format

stp root-guard action

Parameter description

Parameter	Parameter description	Value
drop-packets	Drop messages
block-port	Blocked port	Defaults

84.9. stp tc-protection

Command function

Enable tc protection

Command format

stp tc-protection

no stp tc-protection

Parameter description

None

84.10. stp tc-protection interval

Command function

Enable tc protection period

Command format

stp tc-protection interval

no stp tc-protection interval

Parameter description

Parameter	Parameter description	Value
seconds		1-255, the default 10s

84.11. stp tc-protection threshold

Command function

Maximum number of tc packets processed during tc protection period

Command format

stp tc-protection threshold

no stp tc-protection threshold

Parameter description

Parameter	Parameter description	Value
num		1-255, the default 6

Enable or disable send trap when discovery new root bridge

Command format

stp new-root-trap enable

stp new-root-trap disable

Parameter description

None

84.14. stp topo-change-trap

Command function

Enable or disable send trap when topology change

Command format

stp topo-change-trap enable

stp topo-change-trap disable

Parameter description

None

84.15. stp bpdu-guard

Command function

Enable the bpdu-guard function globally or on a physical interface

Command format

stp bpdu-guard

no stp bpdu-guard

Parameter description

None

84.16. stp bpdu-filter

Command function

Filtering bpdu packets globally or on physical interfaces

Command format

stp bpdu-filter

no stp bpdu-filter

Parameter description

None

84.17. stp cost

Command function

Configure the cost of the physical interface

Command format

stp cost

no stp time-factor

Parameter description

Parameter	Parameter description	Value
num		1-200000000

84.18. stp portfast

Command function

Physical interface configured as an edge port

Command format

stp portfast |autoedge | disable |edgeport|

no stp portfast

Parameter description

Parameter	Parameter description		Value
autoedge	port-fast state automatically
disable	Port can’t change to port-fast state
edgeport	Port change to port-fast state directly

84.19. stp link-type

Command function

Configure the physical interface link type

Command format

stp link-type

no stp link-type

Parameter description

Parameter	Parameter description	Value
auto	Automatic detection
point-to-point	Point to point
shared	Non-point to point

84.20. stp loop-guard

Command function

Physical interface configuration loop-guard function

Command format

stp loop-guard

no stp loop-guard

Parameter description

None

84.21. stp mcheck

Command function

Perform mcheck function

Command format

stp mcheck

Parameter description

None

84.22. stp port-priority

Command function

Modify the priority of the physical interface stp

Command format

stp port-priority

no stp port-priority

Parameter description

Parameter	Parameter description	Value
num	Priority size	0-240 and 16 multiple, default 128

84.23. stp root-guard

Command function

Configure the root-guard function on the physical interface

Command format

stp root-guard

no stp root-guard

Parameter description

None

84.24. stp tcn-restricted

Command function

Physical interface configuration tcn propagation limit function

Command format

stp ten-restricted

no stp tcn-restricted

Parameter description

None

84.25. stp transmit-limit

Command function

Configure the physical interface to process the maximum number of bpdu

packets

Command format

stp transmit-limit

no stp transmit-limit

Parameter description

Parameter	Parameter description	Value
num		1-255, default 3

84.26. show stp interface

Command function

Display interface stp information

Command format

show stp interface [brief] ethernet ]

Parameter description

Parameter	Parameter description	Value
brief	Brief information
interface-list	Port list

None

85. MSTP configuration manual

85.1. stp

Command function

Global or physical interface enables stp

Command format

stp

no stp

Parameter description

None

85.2. stp mode

Command function

Modify stp mode

Command format

stp mode

no stp mode

Parameter description

None

85.3. mstp hello-time

Command function

Configure the interbal for sending bpdu packets

Command format

mstp hello-time

no mstp hello-time

Parameter description

Parameter	Parameter description	Value
seconds		1-10s, default 2s

85.4. mstp forward-time

Command function

Configure forward-delay time

Command format

mstp forward-time

no mstp forward-time

Parameter description

Parameter	Parameter description	Value
seconds		4-30 s, default 15s

85.5. mstp max-age

Command function

Interval for aging the inter-zone STP packets

Command format

mstp max-age

no mstp max-age

Parameter description

Parameter	Parameter description	Value
num		6-40 s, default 20s

85.6. mstp max-hops

Command function

STP maximum number of hops in the domain

Command format

mstp max-hops

no mstp max-hops

Parameter description

Parameter	Parameter description	Value
num		1-255 s, default 20

85.7. mstp instance priority

Command function

Modify the priority of the instance

Command format

mstp instance priority

no mstp instance 0 priority

Parameter description

Parameter	Parameter	Value
	description
id	Instance number	0-15
num2	priority	0-61440 and 4096 multiples, default 32768

85.8. mstp root-guard action

Command function

mstp root-guard

Command format

mstp root-guard action

Parameter description

Parameter	Parameter description	Value
drop-packets	Drop message
block-port	Blocked port	default

85.9. mstp tc-protection

Command function

Enable tc protection

Command format

mstp tc-protection

no mstp tc-protection

Parameter description

None

85.10. mstp tc-protection interval

Command function

Enable tc protection period

Command format

mstp tc-protection interval

no mstp tc-protection interval

Parameter description

Parameter	Parameter description	Value
seconds		1-255, 默认 10s

85.11. mstp tc-protection threshold

Command function

Maximum number of tc packets processed during tc protection period

Command format

mstp tc-protection threshold

no mstp tc-protection threshold

Parameter description

Parameter	Parameter description	Value
num		1-255, default 6

85.12. mstp time-factor

Command function

Configure the timeout factor

Command format

mstp time-factor

no mstp time-factor

Parameter description

Parameter	Parameter description	Value
num		1-10, default 3

85.13. mstp bpdu-guard

Command function

Enable the bpdu-guard function globally or on a physical interface

Command format

mstp bpdu-guard

no mstp bpdu-guard

Parameter description

None

85.14. mstp bpdu-filter

Command function

Filtering bpdu packets globally or on physical interfaces

Command format

mstp bpdu-filter

no mstp bpdu-filter

Parameter description

None

85.15. mstp instance vlan

Command function

Configure the mapping between the instance and the vlan

Command format

mstp instance vlan

no mstp instance vlan

Parameter description

Parameter	Parameter description	Value
id	Instance number	0-15
vlan-list	Vlan list

85.16. mstp region-name

Command function

Configure the domain name

Command format

mstp region-name

no mstp region-name

Parameter description

Parameter	Parameter description	Value
name		STRING<1-32>

85.17. mstp enable instance

Command function

Enable instance

Command format

mstp enable instance

Parameter description

Parameter	Parameter description	Value
id		1-15

85.18. mstp disable instance

Command function

Disable instance

Command format

mstp disable instance

Parameter description

Parameter	Parameter description	Value
id		1-15

85.19. mstp revision

Command function

Configure revision

Command format

mstp revision

no mstp region-name

Parameter description

Parameter	Parameter description	Value
level		0-65535

85.20. mstp flap-guard

Command function

flap-guard configuration

Command format

mstp flap-guard |recovery-time \>

no mstp flap-guard

Parameter description

Parameter	Parameter description	Value
enabel	Enable function
num	Shocks	1-100, default 5
seconds	Recovery time	30-1000, default 30s

85.21. mstp external cost

Command function

Configure the cost of the physical interface mstp domain

Command format

mstp external cost

no mstp external cost

Parameter description

Parameter	Parameter description	Value
num		1-200000000

85.22. mstp instance cost

Command function

Configure the cost in the physical interface domain

Command format

mstp instance cost

no mstp instance cost

Parameter description

Parameter	Parameter description	Value
num		1-200000000
id	Instance number

85.23. mstp portfast

Command function

Physical interface configured as an edge port

Command format

mstp portfast [autoedge | disable | edgeport]

no mstp portfast

Parameter description

Parameter	Parameter description		Value
autoedge	port-fast state automatically
disable	Port can’t change to port-fast state
edgeport	Port change to port-fast state directly

85.24. mstp link-type

Command function

Configure the physical interface link type

Command format

mstp link-type

no mstp link-type

Parameter description

Parameter	Parameter description	Value
auto	Automatic detection
point-to-point	Point to point
shared	Non-point to point

85.25. mstp loop-guard

Command function

Physical interface configuration loop-guard function in port mode

Command format

mstp loop-guard

no mstp loop-guard

Parameter description

None

85.26. mstp root-guard

Command function

Physical interface configuration root-guard function in port mode

Command format

mstp root-guard

no mstp root-guard

Parameter description

None

85.27. mstp mcheck

Command function

Perform mcheck function

Command format

mstp mcheck

Parameter description

None

85.28. mstp instance port-priority

Command function

Modify the instance priority of physical interface mstp

Command format

mstp instance port-priority

no mstp instance port-priority

Parameter description

Parameter	Parameter description	Value
num	Priority sise	0-240 and 16 multiple, default128
id	Instance number	0-15

85.29. mstp config-digest-snooping

Command function

Compatible with Cisco

Command format

mstp config-digest-snooping

no mstp config-digest-snooping

Parameter description

None

85.30. show mstp instance

Command function

View mstp instance information

Command format

show mstp instance [id | brief]

Parameter description

None

85.31. show mstp disabled-instance

Command function

View disabled-instance

Command format

show mstp instance

Parameter description

None

85.32. show mstp config-id

Command function

View the domain configuration of mstp

Command format

show mstp config-id

Parameter description

None

86. EAPS configuration manual

86.1. eaps

Command function

Global enable eaps

Command format

eaps

no eaps

Parameter description

None

86.2. eaps domain

Command function

Create and enter eaps domain

Command format

eaps domain

no eaps domain

Parameter description

Parameter	Parameter description	Value
id	domain id	0-15

86.3. control-vlan

Command function

Configuring timeout timers for eaps domain

Command format

fail-timer

no fail-timer

Parameter description

Parameter	Parameter description	Value
seconds		3-30s, default: 6s

86.5. hello-timer

Command function

Eaps domain configuration health message timer

Command format

hello-timer

no hello-timer

Parameter description

Parameter	Parameter description	Value
seconds		1-10s default: 1s

86.6. preup-timer

Command function

Configuration recovery timer under eaps domain

Command format

preup-timer

no preup-timer

Parameter description

Parameter	Parameter description	Value
seconds		0-30 default: 0

86.7. ring

Command function

Eaps domain ring role and port role configuration

Command format

ring <id> role <assistant-edge | edge > <eth-trunk | ethernet >
<interface>
ring <id> role <master| transmit > primary-port <interface>
secondary-port <interface> level <num>
no ring <id>

Parameter description

Parameter	Parameter description	Value
id	Ring id	0-15
master	Master node
assistant-edge	assistant edge node
edge	Edge node
transmit	Transmission node
interface	Interface
num	Ring level	0-1

86.8. topo-collect

Command function

Configure topology discovery in the eaps domain

Command format

topo-collect

no topo-collect

Parameter description

None

86.9. work-mode

Command function

eaps domain configuration mode

Command format

work-mode [rrpp|standard|eips-subring]

Parameter description

Parameter	Parameter description	Value
rrpp	Compatible with Huawei
eips-subring	Compatible with Maipu
standard	Standard mode

86.10. show eaps

Command function

Display eaps ring information

Command format

show eaps

Parameter description

None

86.11. show eaps control-vlan

Command function

Display eaps control-vlan and ring port information

Command format

show eaps control-vlan [vlan-id]

Parameter description

Parameter	Parameter description	Value
vlan-id	vlan

86.12. show eaps domain

Command function

Display eaps ring information based on domain

Command format

show eaps domain

Parameter description

Parameter	Parameter description	Value
domain-id	domain	0-15

86.13. show eaps statistics

Command function

Display eaps message count

Command format

show caps statistics [domain ]

Parameter description

Parameter	Parameter description	Value
domain-id	domain

86.14. show eaps topology

Command function

Display eaps topology

Command format

show eaps topology [brief|domain ]

Parameter description

Parameter	Parameter description	Value
domain-id	domain
brief	brief

86.15. clear eaps

Command function

Clear eaps message statistics

Command format

clear eaps [ domain [ ring ] ]

Parameter description

Parameter	Parameter description	Value
domain-id	domain
ring-id	Ring id

87. ERPS configuration manual

87.1. erps

Command function

Global enable erps

Command format

erps

no erps

Parameter description

None

87.2. erps instance

Command function

Create and enter erps instance

Command format

erps instance

no erps instance

Parameter description

Parameter	Parameter description	Value
id	instance id	0-15

87.3. control-vlan

Command function

erps instance configuration control vlan

Command format

control-vlan

no control-vlan

Parameter description

Parameter	Parameter description	Value
vlan-id		1-4094

87.4. guard-timer

Command function

erps instance configuration guard-timer

Command format

guard-timer

no guard-timer

Parameter description

Parameter	Parameter description	Value
seconds		100-2000ms, default: 500ms

87.5. wtr-timer

Command function

erps instance configuration recovery timeout timer

Command format

wtr-timer < seconds>

no wtr-timer

Parameter description

Parameter	Parameter description	Value
seconds		1-12min, 1 default: 5min

87.6. mel

Command function

erps instance associated cfm level

Command format

mel < level>

no mel

Parameter description

Parameter	Parameter description	Value
level		0-7, default: 0

87.7. protected-instance

Command function

List of protected mstp instances under erps instance

Command format

protected-instance

Parameter description

Parameter	Parameter description	Value
id-list		STRING<1-64>

87.8. port0 ethernet

Command function

erps instance configure port0

Command format

port0 ethernet [owner|next-neighbour|neighbour]

Parameter description

Parameter	Parameter description	Value
neighbour	rpl neighbour
owner	rpl-owner
next-neighbour	Next neighbor
port-number	The port number

87.9. port1 ethernet

Command function

erps instance configure port1

Command format

port1 ethernet [owner|next-neighbour|neighbour]

Parameter description

Parameter	Parameter description	Value
neighbour	rpl neighbour
owner	rpl-owner
next-neighbour	Next neighbor
port-number	The port number

87.10. ring

Command function

erps instance ring configuration

Command format

ring <id|enable|disable|level]

Parameter description

Parameter	Parameter description	Value
id	Ring id	1-239
enable	Enable ring
disable	Disable ring
level	Ring level	0-1

87.11. show erps

Command function

Display erps ring information

Command format

show erps

Parameter description

None

87.12. show erps control-vlan

Command function

Display erps control-vlan and ring port information

Command format

show erps control-vlan [vlan-id]

Parameter description

Parameter	Parameter description	Value
vlan-id	vlan	1-4094

87.13. show erps instance

Command function

Display erps ring information based on instance

Command format

show caps domain

Parameter description

Parameter	Parameter description	Value
instance-id	instance 号	0-15

87.14. show erps instance statistics

Command function

Count packets based on instance

Command format

show erps instance statistics

Parameter description

Parameter	Parameter description	Value
instance-id	instance	0-15

87.15. show erps statistics

Command function

Display erps packet count

Command format

show erps statistics

Parameter description

None

88. PVST/Rapid-PVST configuration manual

88.1. stp

Command function

Global or physical interface enables stp

Command format

stp

no stp

Parameter description

None

88.2. stp mode

Command function

Modify pvst mode

Command format

stp mode

no stp mode

Parameter description

None

88.3. pvst hello-time

Command function

Configure the interval for sending bpdu packets

Command format

pvst hello-time

no pvst hello-time

Parameter description

Parameter	Parameter description	Value
seconds		1-10 s

88.4. pvst forward-time

Command function

Configure forward-delay time

Command format

pvst forward-time

no pvst forward-time

Parameter description

Parameter	Parameter description	Value
seconds		4-30 s

88.5. pvst max-age

Command function

Interval for aging the interzone pvst protocol packets

Command format

pvst max-age

no pvst max-age

Parameter description

Parameter	Parameter description	Value
num		6-40 s

88.6. pvst instance vlan

Command function

Configure the mapping between the instance and the vlan and conflict

with mstp

Command format

pvst instance vlan

no pvst instance vlan

Parameter description

Parameter	Parameter description	Value
id	Instance number	0-15
vlan-list	Vlan list

88.7. pvst instance priority

Command function

Modify the priority of the instance

Command format

pvst instance priority

no pvst instance priority

Parameter description

Parameter	Parameter description	Value
id	Instance number	0-15
num2	priority	0-61440 and 4096 multiples, default 32768

88.8. pvst bpdu-guard

Command function

Enable bpdu-guard on physical interfaces

Command format

pvst bpdu-guard

no pvst bpdu-guard

Parameter description

None

88.9. pvst bpdu-filter

Command function

The physical interface filters bpdu packets

Command format

pvst bpdu-filter

no pvst bpdu-filter

Parameter description

None

Physical interface configured as an edge port

Command format

pvst edge-port

no pvst edge-port

Parameter description

None

88.12. pvst instance cost

Command function

Configure the cost of the physical interface

Command format

pvst instance cost

no pvst instance cost

Parameter description

Parameter	Parameter description	Value
num		1-200000000
id	Instance number

88.13. pvst instance port-priority

Command function

Modify the priority of the physical interface

Command format

pvst instance port-priority

no pvst instance port-priority

Parameter description

Parameter	Parameter description	Value
num	Priority size	0-240 and 16 multiple, default 128
id	Instance number	0-15

88.14. show pvst instance brief

Command function

Check pvst information

Command format

show pvst instance brief [instance-list]

Parameter description

Parameter	Parameter description	Value
instance-list	Instance list	STRING<1-128>

89. Eth-Trunk 配置命令

89.1. interface eth-trunk

Command function

Add and enter or enter aggregates groups

Command format

interface eth-trunk

no interface eth-trunk

Parameter description

Parameter	Parameter description	Value
id	Aggregation group number	1-31

89.2. link-aggregation load-balance

Command function

Configure link-aggregation load-balance

Command format

link-aggregation load-balance <dst-ip |dst-mac|src-dst-ip|src-dst-

mac|src-ip|src-mac>

no link-aggregation load-balance

Parameter description

Parameter	Parameter description	Value
dst-ip	Destination ip
dst-mac	Destination mac
src-dst-ip	Source purpose ip
src-dst-mac	Source purpose mac
src-ip	Source ip
src-mac	Source mac	default

89.3. link-aggregation mode

Command function

Configure the aggregation mode

Command format

link-aggregation mode

no link-aggregation mode

Parameter description

Parameter	Parameter description	Value
dynamic	Dynamic
static	Static

89.4. link-aggregation members ethernet

Command function

Adding member ports to an aggregation group

Command format

link-aggregation members ethernet

no link-aggregation members ethernet

Parameter description

Parameter	Parameter description	Value
interface-list	Port list

89.5. link-aggregation eth-trunk

Command function

Add an aggregation group to a physical interface

Command format

link-aggregation eth-trunk

no link-aggregation eth-trunk

Parameter description

Parameter	Parameter description	Value
num	Aggregation group number	1-31

89.6. lacp mode

Command function

Configure the interface mode on the physical interface

Command format

lacp mode

no lacp mode

Parameter description

Parameter	Parameter description	Value
passive	Passive
active	Active

89.7. lacp period

Command function

Configure the interface timeout mode on the physical interface

Command format

lacp period

Parameter description

Parameter	Parameter description	Value
short	Short time
long	Long time

89.8. lacp port-priority

Command function

Configure the interface priority on the physical interface

Command format

lacp port-priority

no lacp port-priority

Parameter description

Parameter	Parameter description	Value
num	Priority	1-65535

89.9. lacp system-priority

Command function

Configure global priority

Command format

lacp system-priority

no lacp system-priority

Parameter description

Parameter	Parameter description	Value
num	Priority	1-65535

Display the status of the local aggregation group

Command format

show lacp local [eth-trunk ]

Parameter description

Parameter	Parameter description	Value
num	Aggregation group number	1-31

89.11. show lacp sys-id

Command function

Display the aggregation group system ID

Command format

show lacp sys-id

Parameter description

None

89.12. show lacp neighbor

Command function

Display aggregation group neighbors

Command format

show lacp neighbor [eth-trunk ]

Parameter description

Parameter	Parameter description	Value
num	Aggregation group number	1-31

90. FlexLink configuration manual

90.1. flex-link group

Command function

Add and enter or enter FlexLink

Command format

flex-link group

no flex-link group

Parameter description

Parameter	Parameter description	Value
id	Aggregation group number	0-15

90.2. master-port

Command function

Configure the master port in flex-link group mode

Command format

master-port |ethernet \>

no master-port <eth-trunk |ethernet <ethernet-

num>>

Parameter description

Parameter	Parameter description	Value
eth-trunk-num	Aggregation group number	1-31
ethernet-num	Physical port number

90.3. slave-port

Command function

Configure the slave port in flex-link group mode

Command format

slave-port <eth-trunk <eth-trunk-num>|ethernet <ethernet-num>>

no slave-port <eth-trunk <eth-trunk-num>|ethernet <ethernet-num>>

Parameter description

Parameter	Parameter description	Value
eth-trunk-num	Aggregation group number	1-31
ethernet-num	Physical port number

90.4. preemption mode

Command function

Configure preemption mode in flex-link group mode

Command format

preemption mode <bandwidth|off|role>

no preemption mode

Parameter description

Parameter	Parameter description	Value
bandwidth	Bandwidth preemption
off	Don’t preempt
role	Role preemption

90.5. preemption delay

Command function

Configure preemption delay in flex-link group mode

Command format

preemption delay < seconds>

no preemption delay

Parameter description

Parameter	Parameter description	Value
seconds		1-60s

90.6. flex-link flush send

Command function

Enable sending mac table flush function

Command format

flex-link flush send

no flex-link flush send

Parameter description

None

90.7. flex-link flush receive

Command function

Enable receiving mac table flush function

Command format

flex-link flush receive

no flex-link flush receive

Parameter description

None

90.8. show flex-link group

Command function

Display FlexLink group information

Command format

show flex-link group []

Parameter description

Parameter	Parameter description	Value
id	Aggregation group number	0-30

90.9. show flex-link flush

Command function

Display receive, send flush statistics and configuration information

Command format

show flex-link flush

Parameter description

None

91. MonitorLink configuration manual

91.1. monitor-link-group

Command function

Add and enter or enter monitor-link-group

Command format

monitor-link-group <id>
no monitor-link-group <id>

Parameter description

Parameter	Parameter description	Value
id	Aggregation group number	0-4

91.2. uplink interface

Command function

Configure the uplink port

Command format

uplink interface <eth-trunk <eth-trunk-num>|ethernet <ethernet-num>>
no uplink interface <eth-trunk <eth-trunk-num>|ethernet <ethernet-num>>

Parameter description

Parameter	Parameter description	Value
eth-trunk-num	Aggregation group number	1-31
ethernet-num	Physical port number

91.3. downlink interface

Command function

Configure the downlink port

Command format

downlink interface <eth-trunk <eth-trunk-num>|ethernet <ethernet-num>>
no downlink interface <eth-trunk <eth-trunk-num>|ethernet

>

Parameter description

Parameter	Parameter description	Value
eth-trunk-num	Aggregation group number	1-31
ethernet-num	Physical port number

91.4. show monitor-link-group

Command function

Display monitor-link-group group information

Command format

show monitor-link-group [id]

Parameter description

Parameter	Parameter description	Value
id	Aggregation group number	0-4

92. Sntp-Client Configuration command

92.1. sntp client

Command function

Sntp client enable switch.

Command format

sntp client

no sntp client

Parameter Description

none

92.2. sntp client mode

Command function

Sntp client mode.

Command format

sntp client mode [anycast|broadcast|multicast|unicast]

Parameter Description

Parameter	Parameter Description	Value range
anycast		anycast
broadcast		broadcast
multicast		multicast
unicast		unicast

92.3. sntp client authenticate

Command function

Sntp client authentication function switch.

Command format

sntp client authenticate

no sntp client authenticate

Parameter Description

92.4. sntp client authentication-key encrypt

Command function

Sntp client password is encrypted to show

Command format

sntp client authentication-key encrypt [enable|disable

no sntp client

Parameter Description

Parameter	Parameter Description	Value range
enable		Encrypted display
disable		Unencrypted display

92.5. sntp client authentication-key

Command function

Sntp client password

Command format

sntp client authentication-key [id] [encrypt-key |md5 ] no sntp client

Parameter Description

Parameter	Parameter Description	Value range
id		Key id
key		password
md5-key		md5 password

92.6. sntp client broadcastdelay

Command function

Modify broadcast delay

Command format

sntp client broadcastdelay [seconds]

no sntp client broadcastdelay

Parameter Description

Parameter	Parameter Description	Value range
seconds		1-9999ms

92.7. sntp client poll-interval

Command function

Configure poll-interval

Command format

sntp client poll-interval [seconds]

no sntp client poll-interval

Parameter Description

Parameter	Parameter Description	Value range
seconds		30-99999s, default 1000s

92.8. sntp client retransmit

Command function

Configure retransmission times

Command format

sntp client retransmit [times]

no sntp client retransmit

Parameter Description

Parameter	Parameter Description	Value range
times		1-10

92.9. sntp client retransmit-interval

Command function

Configure retransmission interval

Command format

sntp client retransmit-interval [seconds]

no sntp client retransmit-interval

Parameter Description

Parameter	Parameter Description	Value range
seconds		3-30s

92.10. sntp client summer-time dayly

Command function

Configure daylight saving time

Command format

sntp client summer-time dayly <start-month start-day start-time

end-month end-day end-time >

no sntp client summer-time

Parameter Description

Parameter	Parameter Description	Value range
start-month	start-month
start-day	start-day
start-time	start-time
end-month	end-month
end-day	end-day
end-time	end-time

92.11. sntp client summer-time weekly

Command function

Configure sntp daylight saving time

Command format

sntp client summer-time weekly <start-month start-week [ Fri

|mon| sat | sun | thu | tue | wed ] start-time end-month end-week

[ Fri | mon | sat | sun | thu | tue | wed ] end-time >

no sntp client summer-time

Parameter Description

Parameter	Parameter Description	Value range
start-month	start-month
start-week	start-week
start-time	start-time
end-month	end-month
end-day	end-day
end-time	end-time

92.12. sntp client valid-server

Command function

Configure legitimate servers

Command format

sntp client valid-server

no sntp client valid-server [all|ip wmask]

Parameter Description

Parameter	Parameter Description	Value range
ip	Server IP
wmask	wmask

92.13. sntp trusted-key

Command function

Configure trust password id

Command format

sntp trusted-key < id>

no sntp trusted-key < id>

Parameter Description

Parameter	Parameter Description	Value range
id	Key id	1-4294967295

92.14. sntp server key

Command function

Configure trust password id

Command format

sntp server key < id>

no sntp server key < id>

Parameter Description

Parameter	Parameter Description	Value range
id	Key id	1-4294967295

92.15. sntp server backup

Command function

Configure the backup server IP

Command format

sntp server backup

no sntp server backup

Parameter Description

Parameter	Parameter Description	Value range
ip	Ip address

92.16. sntp server

Command function

Configure the master server IP

Command format

sntp server

no sntp server

Parameter Description

Parameter	Parameter Description	Value range
ip	Ip address

92.17. show sntp client

Command function

View the customer's run information

Command format

show sntp client

Parameter Description

None

92.18. show sntp client summer-time

Command function

View daylight saving time

Command format

show sntp client summer-time

Parameter Description

None

93. System time configuration command

93.1. clock set

Command function

Configure system time in privileged Mode

Command format

clock set

Parameter Description

Parameter	Parameter Description	Value range
HH:MM:SS	HH:MM:SS
YYYY/MM/DD	YYYY/MM/DD

93.2. clock timezone

Command function

Configure time zone

Command format

clock timezone

no clock timezone

Parameter Description

Parameter	Parameter Description	Value range
zone-name	zone-name	STRING<1-16>
hours-offset	hours-offset
minutes-offset	minutes-offset

93.3. clock summer-time dayly

Command function

Configure daylight saving time

Command format

clock summer-time dayly <start-time start-date end-time end-

date >

no clock summer-time

Parameter Description

Parameter	Parameter Description	Value range
start-date	start-date
start-time	start-time
end-date	end-date
end-time	end-time

93.4. clock summer-time weekly

Command function

Configure system time daylight saving time

Command format

clock summer-time weekly <start-time start-month start-week

[ Fri | mon | sat | sun | thu | tue | wed ] end-time end-month end-week

[ Fri | mon | sat | sun | thu | tue | wed ] >

no clock summer-time

Parameter Description

Parameter	Parameter	Value range
	Description
start-month	start-month
start-week	start-week
start-time	start-time
end-month	end-month
end-day	end-day
end-time	end-time

93.5. show clock

Command function

View system current time, time zone information

Command format

show clock

Parameter Description

None

94. 1. Static route configuration commands

94.1. 1.1 ip route

Command function

ip route dst-net mask next-hop

IP route add static routing entries

Command format

ip route 192.168.2.0 255.255.255.0 192.168.1.2

no ip route 192.168.2.0 255.255.255.0 192.168.1.2

no ip route static all

Parameter description

Parameter	Parameter description	Value
dst-net	Destination network address	0.0.0.0-223.255.255.254
mask	Destination network mask	0.0.0.0-255.255.255.255
next-hope	Next ip address	You must configure the subnet vlan address on the Layer 3 interface.

94.2. 1.2 show ip route

Command function

show ip route

Check routing table entries

Command format

show ip route [ip-address [mask] | static]

Parameter description

Parameter	Parameter description	Value
ip-address	Route entry network	0.0.0.0-255.255.255.255
mask	Route entry mask	0.0.0.0-255.255.255.255
static	Check static routes

95. 2 IPv6 static route configuration command

95.1. 2.1 ipv6 route

Command function

Add static routing entries

Command format

ipv6 route [dst-net/len| dst-net mask] next-hop

no ip route dst-net mask [ next-hop]

Parameter description

Parameter	Parameter description	Value
dst-net	Destination network address
len	Mask length
mask	mask
next-hope	Next ip address	You must configure the subnet vlan address on the Layer 3 interface.

95.2. 2.2 show ipv6 route

Command function

Check routing table entries

Command format

show ipv6 route

Parameter description

None

96. 802.1Q Configuration command

96.1. vlan

Command function

vlan vlan-list

Command is used to create vlan globally

no vlan [all|vlan-list]

Command is used to perform vlan deletion globally

Command format

vlan 2,4,6,7-20

no vlan 2,4,6,7-20

no vlan all

Parameter Description

Parameter	Parameter description	Value range
vlan-list	Get VLAN id	Numeric string, case-insensitive, not support spaces, the length range is 1-128. String range 1-4094
all	All configured vlan	None

96.2. switchport

Command function

(no) switchport [ethernet|all]

Command to add or delete ports in vlan mode

Command format

(no) switchport ethernet 0/0/1

Parameter Description

Parameter	Parameter Description	Value range
ethernet	Get port id	Numeric string, case insensitive, not support spaces, length range is 5-6. The port range is equal to the physical port of the switch
all	All port	None

96.3.

switchport pvid

Command function

(no) switchport pvid vlan-id

Command to add or delete the port PVID in port mode

Command format

(no) switchport pvid 1

Parameter Description

Parameter	Parameter Description	Value range
vlan-id	Get vlan id	1-4094

96.4. switchport link-type

Command function

(no) switchport link-type [access | hybrid | trunk]

The link type of the command to change the port

Command format

(no)switchport link-type access

Parameter Description

None

96.5. switchport trunk allowed vlan

Command function

(no) switchport trunk allowed vlan [vlan-list|all]

Commanad to add or delete vlan that trunk port belong to

Command format

(no) switchport trunk allowed vlan 1

Parameter Description

Parameter	Parameter Description	Value range
vlan-list	Get VLAN id	Numeric string, case-insensitive, not support space, the length range is 1-128. String range 1-4094
all	All configured vlan	none

96.6. switchport trunk tagged pvid

Command function

(no) switchport trunk tagged pvid

Command to add or remove the vlan under the trunk tagged port

Command format

switchport trunk tagged pvid

no switchport trunk tagged pvid

Parameter Description

none

96.7. switchport hybrid untagged vlan

Command function

(no)switchport hybrid untagged vlan [vlan-list|all]

Command to add or remove VLAN under hybrid untagged port

Command format

(no)switchport hybrid untagged vlan 1

Parameter Description

Parameter	Parameter Description	Value range
vlan-list	Get VLAN id	Numeric string, case-insensitive, not support space, the length range is 1-128. String range is 1-4094.
all	All configured vlan	None

96.8. switchport hybrid tagged vlan

Command function

(no)switchport hybrid tagged vlan [vlan-list|all]

Command to add or remove the vlan under the hybrid tagged port

Command format

(no)switchport hybrid tagged vlan 1

Parameter Description

Parameter	Parameter Description	Value range
vlan-list	Get VLAN id	Numeric string, case-insensitive, not support space, the length range is 1-128. String range is 1-4094.
all	All configured vlan	None

96.9. priority

Command function

(no)priority value

Command to add or remove the priority below the port

Command format

(no)priority 1
Parameter Description

Parameter	Parameter Description	Value range
value	Get priority	0-7

96.10. ingress acceptable-frame

Command function

(no)ingress acceptable-frame [tagged|all]

Command to add or remove the ingress frame type under the port

Command format

(no)ingress acceptable-frame tagged

Parameter Description

Parameter	Parameter Description	Value range
tagged	Only receive tag message	None
all	All messages are received	None

96.11. ingress filtering

Command function

(no) ingress filtering

Command to enable or delete port message filtering

Command format

(no) ingress filtering

Parameter Description

None

96.12. interface vlan-interface

Command function

(no)interface vlan-interface vlan-id

Command to add or remove the vlan L3 interface

Command format

(no) interface vlan-interface 2

Parameter Description

Parameter	Parameter Description	Value range
vlan-id	vlan id	1-4094

96.13. description

Command function

(no"description string

Command to add or remove vlan names

Command format

(no"description vlan1

Parameter Description

Parameter	Parameter Description	Value range
string	Vlan name	Any character except ?,Space need add double quotes

96.14. show interface vlan brief

Command function

show interface vlan brief

The command view the VLAN information under all the interfaces of the switch.

show interface vlan brief ethernet port-id

Command to view the vlan information of the switch under a single port

Command format

show interface vlan brief

show interface vlan brief ethernet 0/0/1

Parameter Description

Parameter	Parameter Description	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28 port switch: 0 / 0 / 1 - 0 / 1 / 4

97. QINQ Configuration

97.1. qinq

Command function

(no)qinq

Command is used to switch qinq and the qinq function is disable by

default

Command format

(no)qinq

Parameter Description

None

97.2. qinq inner-tpid

Command function

(no)qinq inner-tpid protocol-number

Command inserts or deletes the qinq internal protocol number

Command format

(no)qinq inner-tpid 0001

Parameter Description

Parameter	Parameter Description	Value range
protocol-number	protocol-number	1-ffff

97.3. qinq mode

Command function

(no)qinq mode [customer|uplink]

Command to configure or delete qinq mode on the port, uplink by default

Command format

qing mode customer

qinq mode uplink

no qing mode

Parameter Description

None

97.4. qinq outer-tpid

Command function

(no)qinq outer-tpid protocol-number

The command configures or removes the VLAN protocol number under

the port, and the default is 0x8100.

Command format

qinq outer-tpid 9100

no qinq outer-tpid

Parameter Description

Parameter	Parameter	Value range
	Description
protocol-number	protocol-number	1-ffff

97.5. vlan pass-through

Command function

vlan pass-through start-vlan end-vlan

Command to configure the qinq passthrough vlan under the port,

Command format

vlan pass-through 23

Parameter Description

Parameter	Parameter Description	Value range
start-vlan	Start vlan	1-4094
end-vlan	End vlan	1-4094

97.6. no vlan pass-through

Command function

no vlan pass-through [all|start-vlan end-vlan]

Command to delete the qinq passthrough under the port

Command format

no vlan pass-through all

no vlan pass-through 2 3

Parameter Description

Parameter	Parameter Description	Value range
start-vlan	Start vlan	1-4094
end-vlan	End vlan	1-4094
all	All configuration	None

97.7. show qinq

Command function

show qinq

Command to view qinq configuration information

Command format

show qinq

Parameter Description

None

97.8. show vlan pass-through

Command function

show vlan pass-through

Command to view qinq configuration passthrough information

Command format

show vlan pass-through

Parameter Description

None

97.9. no vlan insert

Command function

no vlan insert [all|start-vlan end-vlan service-vlan]

Command to delete the dynamic qinq configuration under the port

Command format

no vlan insert 123

no vlan insert all

Parameter Description

Parameter	Parameter Description	Value range
start-vlan	Start vlan	1-4094
end-vlan	End vlan	1-4094
all	All configurations	无

97.10. vlan insert

Command function

vlan insert start-vlan end-vlan service-vlan

Command to configure dynamic qinq under port

Command format

vlan insert 123

Parameter Description

Parameter	Parameter Description	Value range
start-vlan	Start vlan	1-4094
end-vlan	End vlan	1-4094

98. GVRP Configuration

98.1. gvrp

Command function

(no)gvrp

Command to switch GVRP function, disable by default.

Command format

(no)gvrp

Parameter Description

None

98.2. garp permit vlan

Command function

(no)garp permit vlan vlan-list

Command to configure or delete vlan that garp could publish

Command format

garp permit vlan 2-100

no garp permit vlan 2-100

Parameter Description

Parameter	Parameter Description	Value range
vlan-list	VLAN id	Numeric form strings, case insensitive, not support spaces, length range is 1-128. string range is 1-4094

98.3. garp forbid vlan

Command function

(no)garp forbid vlan vlan-list

Command to configure or delete prohibited propagating vlans in port mode, not prohibit by default.

Command format

garp forbid vlan 2-100

no garp forbid vlan 2-100

Parameter Description

Parameter	Parameter Description	Value range
vlan-list	VLAN id	Numeric form strings, case insensitive, not support spaces, length range is 1-128. string range is 1-4094

98.4. show gvrp

Command function

show gvrp

Command to view if the gvrp function is enabled, disable by default

Command format

show gvrp

Parameter Description

none

98.5. show gvrp interface

Command function

show gvrp interface

Command to view the gvrp configuration on all ports.

Command format

show gvrp interface

Parameter Description

None

98.6. show gvrp interface ethernet

Command function

show gvrp interface ethernet port-id

Command to view the gvrp configuration on a single port.

Command format

show gvrp interface ethernet 0/0/1

Parameter Description

Parameter	Parameter Description	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28-port-switch: 0 / 0 / 1 - 0 / 1 / 4

99. Vlan Swap Command

99.1. vlan swap

Command function

vlan wap start-vlan end-vlan swap-vlan pri

Command to configure vlan swap in port mode

Command format

vlan swap 1 2 2 0

Parameter Description

Parameter	Parameter Description	Value range
start-vlan	Start vlan	1-4094
end-vlan	End vlan	1-4094
swap-vlan	Swap vlan	1-4094
pri	Priority	0-7

99.2. show vlan-swap

Command function

show vlan swap [ethernet port-id]

Command to view the exchange information

Command format

show vlan swap [ethernet port-id]

Parameter Description

None

100. Protocol-VLAN Configuration Command

100.1. vlan-protocol

Command function

(no)vlan-protocol profile < index> frametype

Command format

vlan-protocol profile 1 frame-type ethernet2 ether-type 0800

no vlan-protocol profile 1

Parameter Description

Parameter	Parameter Description	Value range
index	Profile index	1-16
frametype	Frame type	8023-llc-snap|8023-llc|ethernet2
ethertype	Ethertype id	1-FFFF

100.2. vlan-protocol profile

Command function

(no) vlan-protocol profile vlan I

Command to configure or delete protocol-based VLAN on the port

Command format

vlan-protocol profile 1 vlan 100

no vlan-protocol profile 1

Parameter Description

Parameter	Parameter Description	Value range
index	Profile index	1-16
Vlan-id	Vlan id	1-4094

100.3. show vlan-protocol interface

Command function

show vlan-protocol interface [ethernet port id]

Command to view all configurations of a protocol-based vlan

Command format

show vlan-protocol interface ethernet 0/0/1

Parameter Description

Parameter	Parameter Description	Value range
port-id	Port id	Depend on the physical port of the switch, for example, 28-port-switch: 0 / 0 / 1 - 0 / 1 / 4

100.4. show vlan-protocol profile

Command function

show vlan-protocol profile [index]

Command to view all configurations of a protocol-based vlan

Command format

show vlan-protocol profile 1

Parameter Description

Parameter	Parameter Description	Value range
index	Profile index	1-16

101. vlan-subnet Configuration command

101.1. vlan-subnet

Command function

(no)vlan-subnet ipv4 mask vlan priority Command to configure or delete vlan based on IP subnet

Command format

vlan-subnet ipv4 192.168.100 mask 255.255.255.255 vlan 10 priority 5 no vlan-subnet ipv4 192.168.100 mask 255.255.255.255

Parameter Description

Parameter	Parameter Description	Value range
ipadd	Ip Address	Available IP address
mask	mask	0.0.0.0-255.255.255.255
vlan-id	Vlan id	1-4094
pri	priority	0-7

101.2. no vlan-subnet

Command function

no vlan-subnet

Command to delete all configuration based on IP subnet vlan

Command format

no vlan-subnet

Parameter Description

None

101.3. vlan-subnet precede

Command function

vlan-subnet precede

Command to configure vlan-subnet precede matching based on IP subnets

Command format

vlan-subnet precede

Parameter Description

None

101.4. show vlan-subnet

Command function

show vlan-subnet [ipadd mask]

Command to view all configurations based on subnet vlan

Command format

show vlan-subnet 1 255.255.0.0

Parameter Description

Parameter	Parameter Description	Value range
ipadd	Ip address	Available IP address
mask	mask	0.0.0.0-255.255.255.255

102. Mac-vlan Configuration

Command

102.1. vlan-mac-table

Command function

(no)vlan-mac-table mac-address vlan priority

$$ < p r i > $$

Command to configure or delete vlan based on MAC address

Command format

vlan-mac-table mac-address 00:00:00:11:11:11 vlan 100 priority 7

no vlan-mac-table mac-address 00:00:00:11:11:11

Parameter Description

Parameter	Parameter Description	Value range
Mac-add	Mac Address	Available mac address
vlan-id	Vlan id	1-4094
pri	priority	0-7

102.2. no vlan-mac-table

Command function

no vlan-mac-table

Command is used to delete all MAC-based vlan configurations

Command format

no vlan-mac-table

Parameter Description

None

102.3. show vlan-mac-table

Command function

show vlan-mac-table [mac-address]

Command is used to delete all MAC-based vlan configurations

Command format

show vlan-mac-table 2:2:2:2:2:2

Parameter Description

Parameter	Parameter Description	Value range
mac-address	Mac address	Available mac address

103. Vlan-trunking Configuration

Commands

103.1. vlan-trunking

Command function

[no] vlan-trunking

Command to configure VLAN passthrough in port mode

Command format

[no] vlan-trunking

Parameter Description

None

103.2. vlan-trunk mode

Command function

vlan-trunk mode [auto|manual]

Command to configure VLAN passthrough mode globally

Command format

vlan-trunk mode auto

vlan-trunk mode manual

Parameter Description

Parameter	Parameter Description	Value range
auto	Automatic mode, in which there is no need to create a vlan	None
manual	Manual mode, under which vlan is created	None

103.3. show vlan-trunking

Command function

show vlan-trunking

Command to view configuration exchange VLAN passthrough

information

Command format

show vlan-trunking

Parameter Description

None

104. Voice vlanConfiguration Commands

104.1. voice vlan

Command function

voice vlan voice vlan id cos value

Commands are used to configure voice vlan id and vlan priority

globally

voice vlan voice vlan id

Command is used to configure voice vlan id under port

no voice vlan

Command is used to delete voice vlan configuration

globally/port

Command format

voice vlan 100 cos 2

voice vlan 100

no voice vlan

Parameter Description

Parameter	Parameter Description	value
voice vlan id	voice vlan	2-4094, Is the created vlan
value	priority	0-7

104.2. voice vlan aging

Command function

voice vlan aging minute Command to configure voice vlan aging time

no voice vlan aging Command to restore the default voice vlan aging time

Command format

voice vlan aging 10

no voice vlan aging

Parameter Description

Parameter	ParameterDescription	value
minute	Voice vlanaddress agingtime, in minutes.The default is720mins	1-65535

104.3. voice vlan oui-mac

Command function

voice vlan oui-mac mac-add mask oui- mask name description

Command is used to configure the oui address of voice vlan

no voice vlan oui-mac mac-add mask oui-mask

Command is used to delete the configured voice vlan oui address

Command format

voice vlan oui-mac 00:00:00:11:11:11 mask ff:ff:ff:00:00:00 name aa

no voice vlan oui-mac 00:00:00:11:11:11 mask ff:ff:ff:00:00:00

Parameter Description

Parameter	ParameterDescription	value
Mac-add	Specify the oui of the voice vlan	A valid mac address is available, and it cannot be set to all zeros, multicast address or broadcast address.
oui-mask	Specify the mask address of oui
description	Specify the description information of oui	String format, the length ranges from 1 to 32, case sensitive

104.4. voice vlan security

Command function

voice vlan security enable | disable

The command is used to turn on/off the safe mode of voice vlan, which is enabled

by default

Command format

voice vlan security enable

voice vlan security disable

Parameter Description

none

104.5. voice vlan enable | disable

Command function

voice vlan enable | disable

Command to enable/disable the voice vlan function under global/port, it is

disabled by default

Command format

voice vlan enable

voice vlan disable

Parameter Description

none

104.6. voice vlan mode

Command function

voice vlan mode[auto-tagged| auto-untagged| manual]

The command configures or deletes the voice vlan mode under the port, which is auto-untagged by default

Command format

voice vlan mode auto-tagged

voice vlan mode auto-untagged

voice vlan mode manual

Parameter Description

none

104.7. voice vlan qos

Command function

(no) voice vlan qos value

Command to configure or delete voice vlan priority under the port

Command format

voice vlan qos 4

no voice vlan qos

Parameter Description

Parameter	Parameter Description	value
value	priority	0~7

104.8. show voice vlan

Command function

show voice vlan Command to view the configuration information of voice vlan

Command format

show voice vlan

Parameter Description

none

104.9. show voice vlan device

Command function

show voice vlan device Command to view voice vlan device information

Command format

show voice vlan device

Parameter Description

none

104.10. show voice vlan oui-mac

Command function

show voice vlan oui-mac

Command to view the voice vlan oui-mac list, the list has 8 entries by default

Command format

show voice vlan oui-mac

Parameter Description

none
