| Product Type | USB 3.2 Gen. 1 Hub with Cable Pass-Through for Desk |
| Brand | CSL |
| Model | 306563 |
| Power Supply | Via USB bus |
| Number of USB A Female Ports | 2 |
| Number of USB C Female Ports | 1 |
| Upstream USB Connector | 1 x USB 3.2 Gen. 1 Type A Male |
| Audio Jack | 1 x 3.5 mm 4-pole jack (headset) |
| Diameter | 60 mm |
| Operating Temperature | 0-40 °C |
| Compatibility | Windows, Mac, Linux (Plug & Play) |
| Installation | No driver required, automatic recognition |
| Mounting | Requires drilling a hole (hole saw recommended) |
| Package Contents | Cable pass-through for desk, user manual |
| Material | Plastic |
| Recycling | WEEE compliant, eco-participation included |
| Safety | Use in dry indoor environments, do not expose to moisture, do not open |
| Care and Cleaning | Clean with a dry cloth, do not use abrasive products |
| Spare Parts and Repairability | Not user-serviceable, contact after-sales service |
Frequently Asked Questions - 306563 CSL
User questions about 306563 CSL
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your USB hub in PDF format for free! Find your manual 306563 - CSL and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. 306563 by CSL.
USER MANUAL 306563 CSL
USB 3.2 Gen. 1 In-Desk Hub, ø 60 mm
Mod.-Nr.: 306563
Table of contents
- Deutsch....3
- English 6
- Italiano 9
- Français.... 12
- Español....16
ENG: Current drivers, user manuals and other relevant documents for this product can be found on our homepage.
Thank you for having chosen this CSL product and for placing your trust in our company. Please read this manual carefully before installation to ensure your long-term enjoyment of this product. For future reference, please keep this manual. Before using the delivered product, check that it is complete, faultless and undamaged.
1. Scope of delivery
• USB 3.2 Gen. 1 In-Desk hub
- User manual
2. Technical specifications
| Power supply via USB | |
| Port | 1x audio connection, 3.5 mm jack; 4-pin (headset)1 x USB 3.2 Gen. 1 type A plug2x USB 3.2 Gen. 1 type A socket1x USB 3.2 Gen. 1 Type C socket |
| Diameter 60 mm | |
| Ambient temperature | 0-40°C |
3. Functions
The In-Desk HUB allows you to mount a USB 3.2 Gen. 1 Hub, a card reader and audio ports directly into your desk in order to easily connect your devices to it.
4. Assembly
Please remove the in-desk hub from its packaging and unwrap it. Drill or saw a hole of the matching size into your desk at the desired place. Maybe do some testing beforehand where you want to put it. If you are unsure how to prepare the desk, please contact an expert before. Once the hole of the matching size has been drilled, you just have to insert the In-Desk Hub carefully until it is positioned flat on the table.
6 English
5. Getting started
When the device is put into operation for the first time, check the intactness of the product or components and their function again.
Please connect the USB-cable to a free USB 3.2 Gen. 1 port of your PC.
Afterwards you should start your PC. It will detect the new hardware automatically and will install the drivers as well. Eventually the installation will be finalized and the In-Desk Hub is ready to use.
6. Safety instructions and liability disclaimer
Never try to open the device to carry out repairs or conversions. Avoid contact with mains voltages. Do not short-circuit the product. The device is not certified for use in the open air; only use it in dry conditions. Protect it from high humidity, water and snow. Keep it away from high temperatures. Do not subject the device to sudden changes in temperature or heavy vibration as this might damage electronic components.
Examine the device for damage before using it. The unit should not be used if it has received an impact or has been damaged in any other way. Please observe national regulations and restrictions. Do not use the device for purposes other than those described in the instructions. This product is not a toy. Keep it out of the reach of children or mentally impaired persons. Any repair or alteration to the device not carried out by the original supplier, will invalidate the warranty or guarantee. The product may only be used by persons who have read and understood these instructions. The device specifications may change without any separate prior notice to this effect.
7. Disposal instructions
Electrical and electronic devices may only be disposed of in accordance with the European WEEE Directive and not with household rubbish. Components must be disposed of or recycled separately as dangerous, toxic elements can inflict sustained damage on the environment if they are disposed of incorrectly. As a consumer, you are bound by the Electrical and Electronic Devices Act (ElektroG) to return electrical and electronic goods free of charge at the end of their useful life to the manufacturer, the place of purchase or to specially set up, public collection points. The details in each case are governed by national law. The symbol on the product, the operating instructions and/or the packaging refers to these regulations. By separating materials in this way, recycling and disposing of old devices, you are making an important contribution towards protecting our environment. For information on authorised collection points in your area, please contact your local city or municipal administration.
WEEE guideline: 2012/19/EU
WEEE register number: DE 67896761
WD Plus GmbH, herewith declares that this product 306563 conforms to the principle requirements and other relevant stipulations. The complete Declaration of Conformity can be obtained from: WD Plus GmbH, Wohlenbergstraße 16, 30179 Hanover
MO-FR 9:30am - 18pm CET
