Product Type	Connected bracelet (smartwatch)
Brand	Xiaomi
Model	Smart Band 8 Pro
Dimensions	46.09 × 33.39 × 9.99 mm
Net weight	38.5 g (with strap)
Strap material	TPU (thermoplastic polyurethane)
Adjustable strap length	135 to 205 mm
Battery type	Lithium-ion polymer, non-removable
Water resistance	5 ATM (50 meters) - swimming in pool, sea; not hot shower, sauna, diving
Main functions	Heart rate monitoring, touch screen, Bluetooth, activity tracking
Care and cleaning	Clean regularly with water, wipe with a soft cloth; avoid wetting the contact area
Safety	Not a medical device; non-removable battery, do not expose to extreme temperatures
Spare parts and repairability	Battery not user-replaceable; contact authorized Xiaomi after-sales service
General information	Manufacturer: Xiaomi Communications Co., Ltd.; Compliant with European directive 2014/53/EU

Frequently Asked Questions - Smart Band 8 Pro Xiaomi

What is the water resistance of the Xiaomi Smart Band 8 Pro?

The bracelet offers water resistance of 5 ATM (50 meters). It can be worn during swimming in pools or at the sea, but not under a hot shower, in a sauna, or while diving.

Can I use the bracelet to measure my heart rate?

Yes, the bracelet has a heart rate monitoring function. For accurate measurements, keep your wrist still and wear the bracelet at the correct tightness (about one finger between the bone and the bracelet).

How do I clean the bracelet?

Clean the bracelet regularly with water and wipe it with a soft cloth. Avoid overtightening the bracelet and wetting the area in contact with the skin.

What is the battery type and how do I charge it?

The battery is a lithium-ion polymer non-removable battery. Charge it with the provided charger. If you do not use it for a long time, recharge it fully every 6 months.

Is the Smart Band 8 Pro a medical device?

No, this bracelet is not a medical device. The provided data should not be used for diagnosis, treatment, or prevention of diseases.

Can I replace the battery myself?

No, the battery is not removable. Do not attempt to replace it yourself to avoid damaging the device or risk of explosion. Contact the authorized after-sales service.

What are the dimensions and weight of the bracelet?

Dimensions are 46.09 × 33.39 × 9.99 mm and net weight is 38.5 g (with strap).

Is the bracelet compatible with Bluetooth?

Yes, it uses Bluetooth technology to connect to your smartphone. The Bluetooth® word mark is a registered trademark of Bluetooth SIG, Inc.

What to do in case of redness or swelling on the wrist?

If the contact area shows redness or swelling, stop using the bracelet immediately and consult a doctor.

How to dispose of the bracelet at the end of its life?

Do not throw the bracelet in household waste. Dispose of it at an approved collection point for waste electrical and electronic equipment (WEEE).

USER MANUAL Smart Band 8 Pro Xiaomi

Line drawing of a device with a cable and connector, no text or symbols present

Specifications

Product: Smart Band

Model:M2333B1

Battery Capacity:289mAh

Input: 5.0V

Net Weight:38.5g (including strap)

Water Resistance: 5 ATM

Item Dimensions:46.09x33.39x9.99mm

2023.12 on the product indicates that this product will be launched after 2023.12

For product certifications related to this band, please go to Settings > About band > Regulatory Bluetooth® The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Xiaomi Inc. is under licence. Other trademarks and trade names are property of their respective owners.

Precautions

1. Wear the band around your wrist about one-finger's width away from your wrist bone. Wearing the band too loosely may affect the accuracy of the heart rate monitoring data.
2. When using the band to measure your heart rate, please keep your wrist still.
3. The band has a water resistance rating of 5 ATM (50 metres depth). It can be worn in the swimming pool, while swimming near the shore, or during other shallow-water activities. However, it cannot be used in hot showers or saunas, or when diving. Furthermore, remember to avoid the band being directly impacted by swift currents during water sports. The water resistance function is not permanent and may diminish over time.
4. The touchscreen of the band does not support underwater operation. When the band comes into contact with water, use a soft cloth to wipe away excess water from its surface before use.
5. During daily use, avoid wearing the band too tightly and try to keep its contact area dry. Please clean the wristband regularly with water.
6. If the contact area on your skin shows signs of redness or swelling, stop using the product immediately and seek medical assistance.
7. This band is not a medical device. Any data or information provided by the band should not be used

Operating Temperature: 0°C to 43°C

Wristband Material: TPU

Bluetooth Frequency: 2402–2480 MHz

Adjustable Length: 135–205 mm

Maximum Output: < 11 dBm

Battery Type: Lithium-ion polymer battery

Wireless Connectivity: Bluetooth® 5.3

as a basis for diagnosis, treatment, or prevention of diseases.

1. This product is not a toy and contains small parts. Please keep it out of reach of children to prevent choking or other injuries caused by accidental swallowing of small parts.
2. The lithium battery in this band cannot be removed. To avoid damage to the battery or the band, do not replace the battery by yourself. There is a risk of explosion if the wrong type of battery is used. Do not dispose of used batteries with household waste. Dispose of this band and used batteries in accordance with local laws and regulations.
3. Do not disassemble, strike, crush or throw the battery into fire. Stop using the product immediately if there is any swelling. Do not expose it to sunlight, fire or environments where the ambient temperature is extreme.
4. When planning not to use the band for a long period of time, it is advisable to turn off the band and store it away. To avoid damage caused by the over-discharge of the battery, fully charge the band every 6 months.
5. The lithium battery in this band cannot be removed. Do not replace the battery by yourself.
6. Do not put the battery into a fire or a hot oven, or mechanically crush or cut the battery, which could cause it to explode.
7. Leaving the battery in an extremely high temperature environment may result in an explosion or the leakage of flammable liquid or gas.
8. Subjecting the battery to extremely low air pressure may result in an explosion or the leakage of flammable liquid or gas.
9. Keep the product's indicator away from the eyes of children and animals while the product is in use.

WEEE Disposal and Recycling Information

All products bearing this symbol are waste electrical and electronic equipment which should not be mixed with unsorted household waste. Instead, you should protect human health and the environment by handing over your waste equipment to a designated collection point for the recycling of waste electrical and electronic equipment, appointed by the government or local authorities. Correct disposal and recycling will help prevent potential negative consequences to the environment and human health. Please contact the installer or local authorities for more information about the location as well as terms

and conditions of such collection points.

EU Declaration of Conformity

CE UK CA Hereby, Xiaomi Communications Co., Ltd. declares that the radio equipment type M2333B1 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://www.mi.com/global/service/support/declaration.html Hereby, Xiaomi Communications Co., Ltd. declares that the radio equipment type M2333B1 is in compliance with Radio Equipment Regulations 2017. The full text of the UKCA declaration of conformity is available at the following internet address: https://www.mi.com/uk/service/support/declaration.html

Warranty Notice

As a Xiaomi consumer, you benefit under certain conditions from additional warranties. Xiaomi offers specific consumer warranty benefits which are in addition to, and not instead of, any legal warranties provided by your national consumer law. The duration and conditions related to the legal warranties are provided by respective local laws. For more information about the consumer warranty benefits, please refer to Xiaomi's official website https://www.mi.com/en/service/warranty/. Except as prohibited by laws otherwise promised by Xiaomi, the after-sales services shall be limited to the country or region of the original purchase. Under the consumer warranty, to the fullest extent permitted by law, Xiaomi will, at its discretion, repair, replace or refund your product. Normal wear and tear, force majeure, abuse or damage caused by the user's negligence or fault are not warranted. The contact person for the after-sale service may be any person in Xiaomi's authorised service network, Xiaomi's authorised distributors or the final vendor who sold the products to you. If in doubt please contact the relevant person as Xiaomi may identify. The present warranties do not apply in Hong Kong and Taiwan. Products which were not duly imported and/or were not duly manufactured by Xiaomi and/or were not duly acquired from Xiaomi or a Xiaomi official seller are not covered by the present warranties. As per applicable laws you may benefit from warranties from the non-official retailer who sold the product. Therefore, Xiaomi invites you to contact the retailer from whom you purchased the product. Disclaimer: The illustrations of the product, accessories, user interfaces, and other elements in the user manual are schematic diagrams for reference only, and may differ slightly from the actual product.

This manual is published by Xiaomi or an enterprise in Xiaomi's ecosystem. Typographical errors and inaccurate information in this manual or the related programs and/or equipment may change without prior notice. Such changes will be indicated in the latest version of the manual. Manufactured by: Xiaomi Communications Co., Ltd. Address: #019, 9th Floor, Building 6, 33 X'perqi Middle Road, Haidian District, Beijing, China, 100085 For further information, please go to www.mi.com
