USER MANUAL Powersocket 908 Oehlbach

User manual | Warranty information

Thank you for choosing this high quality product from Oehlbach®. Oehlbach® products are characterised by high quality workmanship and first class materials. Please read the following information carefully before starting to use your new multi-socket outlet.

Instruction manual for Oehlbach XXL Powersocket 908 „State of the art“ multi-socket outlet with power switch

IMPORTANT SAFETY INSTRUCTIONS:

This manual contains important information concerning operation and safety. It is imperative you observe all of the information. Keep the manual in a safe place for future reference.

According to DIN VDE 0620 portable multiple socket outlets should not be

• connected in a row,
  · operated under a cover,
• used as a substitute for fixed installations

The Powersocket should only be connected to a mains socket which has the required connection values.

The Powersocket should not be used if there is any liquid in or on the device.

The Powersocket should not be used in areas where there is a very high degree of humidity.

Do not touch or connect the mains cable with damp hands.

Keep the Powersocket and mains cable away from heating appliances.

The device should no longer be operated if there is visible damage to the Powersocket or mains cable.

A damaged Powersocket should not be repaired, but replaced.

No heavy objects should be placed on the Powersocket or the mains cable.

The mains plug should be easily accessible at all times.

If the devices that are connected to the Powersocket are not going to be used for a pronged period (e.g. while on holiday), the Powersocket should be disconnected from the mains by removing the plug.

Do not use any cleaning agents or chemical solvents when cleaning, as these could damage the surface.

Repairs must always be conducted by qualified specialists, as you might otherwise be exposed to dangerous high voltage levels or other hazards.

During a thunderstorm we always recommend disconnecting the Powersocket from the mains.

Cleaning

Before cleaning the Powersocket disconnect the mains plug. The Powersocket should only be dusted. Do not use any liquid cleaners or sprays.

Initial operation

Connect the supplied power cord to the Oehlbach XXL Powersocket 908 and insert the mains plug into a wall outlet. The multi-socket outlet can now be activated via the power switch. The XXL Powersocket 908 is provided with four unfiltered „analogue“ and four filtered digital sockets. The unfiltered sockets are designated with „Analog Sockets“ and the filtered sockets are designated with „Digital Sockets“.

Connecting digital devices

Digital devices can react extremely sensitively to disturbing pulses and sometimes even produce high-frequency interfering signals. Therefore, make sure you connect all digital devices (e.g. DVD/BluRay player, HDD recorder, PC, etc.) to the digital sockets on the power strip. These sockets are black. Devices connected to these sockets are protected by an efficient filter against all disturbing pulses that arrive via the mains supply. This switching circuit also eliminates interference caused by the connected devices themselves.

Connecting analogue devices

Connect all analogue devices such as a tuner, record player, tape deck or amplifier to the grey „analogue“ sockets. The XXL Powersocket 908 uses these sockets to provide unfiltered current for all analogue devices and sufficient reserves for a permanent, stable power supply at all times, even in the event of high power requirements.

Polarity control

An in-phase connection of all devices will guarantee the best possible, unadulterated sound. This is the only way to ensure that potential equalisation currents, which have a negative impact on the sound, are effectively avoided. The POLARITY light indicates that the red sockets are connected in-phase (L). If the polarity light does not illuminate, switch off the power supply, remove the mains plug from the wall socket, turn it around around 180° and plug it in again. The polarity LED now illuminates and the phase designation on the individual sockets correctly designates the phase. To proof the correct in-phase connection of your HIFI-device, you should use the Oehlbach Phaser (Art.No. 17017). All end devices can now be connected in-phase accordingly.

Surge protection

If the surge protection function of the XXL Powersocket 908 is triggered as a result of extreme voltage peaks, the eight sockets (and all of the connected devices) are disconnected from the mains. The Powersocket can be used again by pressing the RESET button.

Correct operation of the active surge protection function is indicated by the PROTECTED light.

Features

• 8 individual sockets
• 4 digital (filtered) sockets / 4 analogue (unfiltered) sockets
  • Power switch for switching the entire strip on/off
• Solid high quality aluminium housing with side caps
• Correct phase connection ensured by an indicator light and phase marking on the individual socket
• Integrated sheath current filter protects against ground loops and high-frequency transients
• Surge protection with LED indicator light
  • 24 carat gold-plated plug contacts
• Extremely high-quality internal wiring: High-purity and oxygen-free copper inner conductor 3.3 mm ^2 inner conductor cross-section
• external power cable with IEC connector: Oxygen-free copper inner conductor 1.5mm^2 inner conductor cross-section 1.5m cable length

Technical specifications

Ambient temperature: -5^ to +35^

Mains voltage: 230V / 50Hz

Rated current: 10 A

Clamping voltage: < 0,91 kV

EMI/RFI filter: Bandwidth: 100 kHz to 50 MHz Attenuation: 50 dB max.

Warranty

Congratulations! Thanks to your intelligent choice you are now the proud owner of an OEHLBACH ^® multi-socket outlet. OEHLBACH ^® multi-socket outlets enjoy an excellent reputation around the world due to their high quality. This high quality standard allows us to provide a 2 year warranty for OEHLBACH ^® multi-socket outlets. The products are continuously inspected and checked throughout the entire manufacturing process. If service is necessary, however, please observe the following:

1. The warranty period starts with the purchase of the product and only applies to the original owner.

2. During the warranty period we will rectify any defects that are due to faulty material or workmanship by replacing or repairing the defective part at our discretion. Further claims, and in particular those for price reduction, cancellation of sale, compensation for damage or subsequent damage, are excluded. The warranty period is not affected by any work we provide under the warranty.

3. The product should not be tampered with.

4. In the event of a warranty claim please contact your authorised dealer first. Should it prove necessary to return the product to us, please ensure that

5. the product is sent in its original factory packaging in good condition,

6. your proof of purchase is enclosed.

7. The following are excluded from the warranty:

8. Illuminants

9. Wear parts
10. Shipping damages, either readily apparent or concealed (Claims for such damages must be lodged immediately with the shipping agent, the railway express office or the post office).
11. Scratches in metal components, front panels, etc. (You must notify your authorised dealer directly of such defects within 5 days of purchase).
12. Defects caused as a result of incorrect installation, faulty connection, improper operation (see user manual), overloading or external force.
13. Improperly repaired or modified devices that have been opened by a party other than us.
14. Subsequent damage to other devices
15. Reimbursement of costs for repairing damage that has been caused by a third party without our prior consent.
