USER MANUAL Punch P2D212 Rockford Fosgate

12/06 B.M. 1230-53314-01 Printed in China Installation & Operation

DVC - DUAL VOICE COIL SUBWOOFERS

Serial Number: Date of Purchase: Rockford Corporation offers a limited warranty on Rockford Fosgate products on the following terms: Length of Warranty Speakers – 1 Year. Any Factory Refurbished Product – 90 days (receipt required) What is Covered This warranty applies only to Rockford Fosgate products sold to consumers by Authorized Rockford FosgateDealers in the United States of America or its possessions. Product purchased by consumers from anAuthorized Rockford Fosgate Dealer in another country are covered only by that country’s Distributor andnot by Rockford Corporation. Who is Covered This warranty covers only the original purchaser of Rockford product purchased from an AuthorizedRockford Fosgate Dealer in the United States. In order to receive service, the purchaser must provideRockford with a copy of the receipt stating the customer name, dealer name, product purchased and date ofpurchase. Products found to be defective during the warranty period will be repaired or replaced (with a product deemed to be equivalent) at Rockford's discretion. What is Not Covered 1. Damage caused by accident, abuse, improper operations, water, theft, shipping2.Any cost or expense related to the removal or reinstallation of product3. Service performed by anyone other than Rockford or an Authorized Rockford Fosgate Service Center4.Any product which has had the serial number defaced, altered, or removed5. Subsequent damage to other components6.Any product purchased outside the U.S.7.Any product not purchased from an Authorized Rockford Fosgate Dealer Limit on Implied Warranties Any implied warranties including warranties of fitness for use and merchantability are limited in duration to theperiod of the express warranty set forth above. Some states do not allow limitations on the length of an impliedwarranty, so this limitation may not apply. No person is authorized to assume for Rockford Fosgate any other liability in connection with the sale of the product. How to Obtain Service Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service.You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate.You are responsible for shipment of product to Rockford. EU Warranty This product meets the current EU warranty requirements, see your Authorized dealer for details.2006 Rockford Corporation.All rights reserved.Rockford Fosgate, the Rockford Fosgate logo, and the PUNCH logo are either registered trademarks or trademarks of Rockford Corporation.

LIMITED WARRANTY STATEMENT

Check our website for additional information and updates on these products. www.RockfordFosgate.com 8" 10" 12" 15" Dual 2-Ohm P2D28 P2D210 P2D212 P2D215 Dual 4-Ohm P2D48 P2D410 P2D412 P2D4152 This manual outlines two specific types of enclosures that provide distinctly different performance.This section is to help you decide which type is best for your application. SEALED ENCLOSURES Sealed enclosures are the simplest to build.The most important part ofbuilding a sealed enclosure is to make sure that the enclosure is airtight.Using glue and some type of sealant on all seams will ensure solid construction and prevent air leaks.The box volume will directly impactthe performance of the speaker. Larger enclosures will provide flatterresponse and deeper bass where smaller boxes will provide a bump inthe response curve and generally higher output for greater SPL.Advantages of sealed enclosures:• Small enclosures• Linear (Flat) response• No port noise• High power handling at all frequencies• Excellent for sound quality• Extended low frequency output when compared to vented enclosures VENTED ENCLOSURES Vented enclosures vary only from the sealed enclosure in that a vent orport is added to “tune” the enclosure.The enclosures recommended aredesigned for great overall performance. Larger boxes tend to be easy totune to lower frequencies while medium and small boxes are easierto tune to higher frequencies.The vented design is less linear inresponse than the sealed box but with noticeably more output atthe tuning frequency.Advantages of vented enclosures:• Higher average output than sealed• Tuning frequency can be easily adjusted by changing port length• Deep bass response with lower power requirements• Great for high output with limited power The graph shown here is a sample of how the F3 drop-off point differs between sealed and vented enclosures.

BUILDING AN ENCLOSURE

To work properly, the walls of the enclosure must be rigid and not flexwhen subjected to the high pressures generated by the speaker's operation. For optimum performance, we recommend using 3/4" MDF(Medium Density Fiberboard) and internal bracing.The enclosure shouldbe glued together and secured with nails or screws. CALCULATING VOLUME Calculating volume is merely a matter of measuring the dimensions ininches and using the formula: H x W x D divided by 1728 (cubic feet).See block below.If two facing sides are of uneven length, add them together and divide bytwo to take the average. Using this number will give you the volume without the necessity of calculating the box in sections and adding thesections together.The thickness of the baffle material reduces the internalvolume so this must be subtracted from the outside dimensions to determine the internal volume.The speaker itself also reduces the internal volume.The amount of air displaced by each model is listed onthe specification sheet and should also be subtracted from the gross volume calculation. SAFETY CARTON CONTENTS CAUTION: Before installation, disconnect the battery negative (-) terminal to prevent damage to the unit, fire and/or possible injury.

PRACTICE SAFE SOUND™

Continuous exposure to sound pressure levels over 100dB maycause permanent hearing loss. High powered auto sound systemsmay produce sound pressure levels well over 130dB. Use commonsense and practice safe sound.• (1) Punch P2 Series Subwoofer• (1) Painted PVC decorative trim ring• (8) Socket head wood screws• (1) Socket head driver bit RECOMMENDED ENCLOSURES

100.0110.0120.0130.010.0 20.0 40.0 60.0 80.0100.0 200.01000.0Frequency, HzSealed BoxVented Box Box Volume Height

Divided by (cubic feet) 17283 NOTE: Vb is the gross volume, which is the TOTAL internal volume, before any speaker and/or port displacement. All external dimensions were based on the use of 3/4" (1.90cm) materials. NOTE: When using enclosures other than recommended, call Technical Support for correct application. NOTE: Vb is the gross volume, which is the TOTAL internal volume, before any speaker and/or port displacement. All external dimensions were based on the use of 3/4" (1.90cm) materials. NOTE: When using enclosures other than recommended, call Technical Support for correct application. SEALED ENCLOSURES VENTED ENCLOSURES Specifications subject to change without notice Optimum Sealed Enclosure Recommendation Recommended Sealed Enclosure Volume Range SEALDED ENCLOSURES 8" 10" 12" 15" P2D28 / P2D48 P2D210 / P2D410 P2D212 / P2D412 P2D215 / P2D415

- Volume Range cu. ft. 0.20 to 0.30 0.50 to 0.85 0.70 to 1.80 1.30 to 3.50 (Liter) (5.66 to 8.50) (14.16 to 24.07) (19.82 to 50.97) (36.81 to 99.10)

- Tuning Frequency (Hz) 38.5 40.1 39.5 32.0

NOTE: The port shown can be placed on any face of the enclosure as long as the port ends are not obstructed.4 Specifications subject to change without notice

• High modulus closed conical polypropylene cone and ABS/Acrylic dustcap assembly geometry.

• Tear & fatigue resistant poly-cotton spider.

• High density compressed half-roll sealed poly-foam surround.

• High temp voice coil with spun-laced Nomex™ insulating re-inforcment collar.

• Optimized motor magnetics with extended pole and bumped backplate.

• Double stack ferrite magnet structure.

• Fatigue resistant and reduced strain "stitched on" flexible lead wire design.

• Multi-point high-temp/high-strength neck joint bonding technique.

• Sturdy 16 guage compound bend frame geometry.

• Semi-flexible PVC removable protective motor cover.

• Custom insulated/isolated compression input terminal assembly.

• Proprietary spider venting/cooling technique.

• Diamond cut cast aluminum motor cover for improved heat dissipation. Protective PVC textured magnet cover. Double stack ferrite magnet structure. High-temp voice coil with spun-laced Nomex™ re-inforcment collar. Vented spider cavity. Tear and fatigue resistant poly-cotton spider. High density compressed half-roll sealed poly-foam surround Optimized motor magnetics with extended pole piece and bumped backplate. Sturdy 16 gauge compound bend frame. Custom insulated 10-AWG nickel plated push terminals. High Modulus Polypropylene Cone/Acrylic dustcap assembly. Decorative ABS Trim Ring.
