USER MANUAL JE2 Duronic

7. Juice-extracting spout

I. Remove all packaging and check that all parts are included.

II. Wash all removable parts and accessories in warm water and dry them

thoroughly. To prevent electric shock and damage, do not immerse the main machine in water.

III. Before assembling the machine, make sure that the plug has inserted into

the socket and that the switch at the back is in the ‘O’-Assembly. Make sure that all parts are installed correctly as follows:

1. Place the juicing bowl into the machine and make sure it cannot

move sideways (fig. 1)

2. Push the screening cylinder all the way into the spinning brush

locked into place (fig. 2

3. Align the spinning brush inside juicing bowl by matching the triangles

the top front (fig. 3

4. Push the rotor into the screening cylinder until it sits on the bottom

and only the little metal top sticks out of the cylinder (fig 4)

5. Insert the pusher into the feed inlet (fig 5)

6. Align the unlock-mark on feed inlet with the triangle on the juicing (fig 6)

7. A subtle rotation clockwise will close the cover (fig 7)

8. Attach the spout to the juicing bowl (fig 8)

Operation instruction

1. Once all parts are correctly installed, place the juice and pulp container

under the outlets of the juicing bowl and put the plug into the socket.

2. Prepare the fruit and vegetables:

A. Remove all non-edible parts: stones (e.g. cherry stone), cores (e.g. of a pineapple), pits (of lemon and grapes) as well as solid skins (e.g. from an orange). B. If the ingredient is too large cut it into chunks. C. Avoid fruits with little juice, rich in fibre, nuts, cocoa beans, as they will cause damage to the machine.

3. Turn the machine into the ‘ON’-Position and insert ingredients into the feed

inlet. Move the pusher down slowly and evenly to extract the maximum juice. In case food gets stuck in the feed inlet, stop the machine and empty the channel of any pulp before continuing. If too many ingredients have been inserted, push the ‘REV’-button and the rotor will operate in the reversed direction to clear the excess food.

4. Empty the juice container and remove the pulp before it is filled u

completely to prevent overflowing, as well as after each cycle. Operatio time should not exceed 20 minutes or 2-3 cycles, afterwards the machine will need to cool down before the next use.

1. Extracts the juice from fruits and vegetables, such as apple, carrots,

cucumber, celery, orange, and many more.

2. Separates the pulp from the juice, so both can be used for different

3. Includes transparent accessories to view the process throughout.

4. Easy cleaning thanks to removable accessories.

5. Large containers for big batches of juice.

6. Easy to pour spout.

7. Adjustable juicing direction.

8. Juicing efficiency though low rate spinning prevents oxidization and keeps

the juice fresh and tasty.

9. DC motor drive, low output rotational speed;

10. Rated voltage: 220-240V; frequency: 50Hz; rated power: 220W;

5. Turn the machine off by selecting the ‘O’-Position at the back

6. After juicing, turn switch to the ‘O’-position. Wait until the motor stopped

spinning completely before removing any parts.

7. The product is not intended for a person with disability, or sense, or mental

disorder or those without relevant experience and knowledge (including children).

8. This product has been designed for household use only and not suitable

for commercial purposes.

9. Do not leave the machine unattended whilst in use.

10. To prevent damage to the product do not insert hard foods, eg. fiber-rich

foods, eg. sugar cane, little-juice foods, such as banana food objects. If foods get stuck use the pushing rod and not your hands to prevent injury and damage.10 Precautions: Pay attention to the following whilst using the electric appliance:

1. Read the instruction carefully before use and keep them for future

2. Before use, ensure the local power voltage is consistent with the rated

voltage indicated on the product.

3. Before dismantle or installing any part of the product, disconnect it from

4. Before use, check the cable, plug and all loose parts for damage. Should

there be any damage or deformation, do not use the product. Contact the customer service department for a repair or replacement.

5. To prevent damage or the cause of fire, do not use this product with a

6. To prevent the risk of electric shock and damage do not immerse the

machine in water. Use a soft cloth for cleaning.

7. Keep all your body parts as well as hard objects out of the feed inlet during

the operation. Do not use any other objects instead of the pushing rod to push the food down. The contact with the rotor would cause injury and/or damage. Use only original parts provided by manufacturer.

1. After use, unplug the machine and wait

until it has cooled off completely.

2. Clean all removable parts in warm,

soapy water. Clean the main body with a soft wet cloth. Dry everything fully. Cleaning and maintenance11 Storage

1. The product should be kept away from children.

2. Store the product in a dry place away from direct irradiation

of ultraviolet light. Problem Solution Machine does not turn on. Check power plugs and that the product is correctly assembled. Failure to operate. Make sure the parts have been installed in the machine correctly. Operation stopped during use. Too much food has been inserted; remove some of it. Food has not been prepared correctly, e.g. not pitted, stoned, skinned; remove any non-edible, hard parts of the food. If the machine is blocked, use the reverse function to clear it, remove all food and pulp and clean the machine afterwards. Noise occurs during juicing. Squeezing ingredients can cause noise, which is normal condition. Do not use frozen ingredients, all food must be thawed before juicing. Description of parts: Product name: Slow Juicer Product model: JE2 Rated voltage: 220-240V~ Frequency: 50/60Hz Rated power: 200W12 Warranty 1 Year Guarantee from Shine-Mart Ltd, Trademark owners of Duronic Products. NOTE: THESE STATEMENTS DO NOT AFFECT YOUR STATUTORY RIGHTS AS A CONSUMER This product has been manufactured under the strictest or quality control procedures, and using the highest quality of materials, to ensure excellent performance and reliability. It will give very good and long lasting service, provided it is properly used and maintained. The product is guaranteed for 1 years from the date of original purchase. If any defect arises due to a faulty materials or poor workmanship, the faulty product must be returned to the original place of purchase. Refund or replacement is at the discretion of that company. Duronic Products are offered with a 1 year guarantee under the following conditions:

1. The product must be returned to the retailer with original proof of purchase.

. T he product must be installed and used in accordance with the instruction

ontained in this operating manual.

. I t must be used only for domestic purposes.

4. It does not cover wear and tear, malicious damage, misuse, neglect,

inexpert repairs or consumable parts.

. S hine-Mart Ltd has no responsibilities for accidental or consequential loss or damage.

. S hine-Mart Ltd are not liable to carry out any type of servicing work

. V alid in the UK only This product is tted with CE:1363 plug and fuse Imported by Shine-Mart Ltd, RM3 8SB Information on waste Disposal for Consumers of Electrical & Electronic Equipment. This mark on a product and/or accompanying documents indicates that when it is to be disposed of, it must be treated as Waste Electrical & Electronic Equipment, (WEEE). Any WEEE marked products must not be mixed with general household waste, but kept separate for the treatment, recovery and recycling of the materials used. For proper treatment, recovery and recycling; please take all WEEE marked waste to your Local Authority Civic waste site, where it will be accepted free of charge. If customers dispose of Waste Electrical & Electronic Equipment correctly, they will be helping to save valuable resources and preventing any potential negative effects upon human health and the environment, of any hazardous materials that the waste may contain.13 Manuel d’utilisation en français14 Aperçu du produit
