USER MANUAL BSGA971ANT Pelgrim

OPERATION Control panel The additional AutoAir functions that are available if a connection has been made with a hob, are described in a separate chapter (see ‘Operation with a connected hob’).

4. Speed setting 3 and intensive setting (Boost)

6. Switching on/off and dimming the lighting

Note! If you have a cooker hood with a odor/fine dust filter, you should activate the odor/fine dust filter indicator as described in the ‘Cleaning the filters’ paragraph. Operation Switching extraction on and off

1. Select the desired extraction setting by touching the corresponding

key. The cooker hood switches on. The on/off key and speed setting key are illuminated.

2. Shortly touch and release the on/off key.

The cooker hood switches off.EN 6 OPERATION Switching on the intensive setting (Boost) The cooker hood is switched on.

1. Touch and hold speed key 3 for approximately 3 seconds.

The intensive setting (boost setting ‘B’) is switched on for six minutes. The on/off key is iluminated and speed key 3 will flash during this period. The original extraction setting will be reactivated after this period.

2. Touch the on/off key or any other speed key to stop the intensive

setting at any time. Switching the lighting on and off

1. Shortly touch and release the lighting key.

The lighting key is iluminated. The light switches on at maximum strength.

2. Touch and hold the lighting key for approximately 3 seconds to dim

the lighting strength.

3. To set the lighting back to maximum strength, shortly touch and

release the lighting key.

4. To turn off the lighting when the light is dimmed, touch and hold the

lighting key for approximately 3 seconds.

5. To turn off the lighting when the light is at maximum strength,

shortly touch and release the lighting key. When a connected hob is switched on, the lighting of the cooker hood always switches on automatically. You can continuously adjust the brightness of the hood via the hob. When switching off a connected hob, the lighting remains on. Manually switch off the lighting with the lighting key on your AutoAir hob or via your hood.EN 7 Switching on the timer

1. Shortly touch and release the timer key.

The timer key will light up. The cooker hood will switch off automatically after 15 minutes. If the lighting is lit, it switches off automatically once the timer isfinished.

2. Switch off the timer function in the meantime by touching the timer

key again. The timer function cannot be activated when the intensive setting isswitched on. Clean Air function: The Clean Air function allows you to freshen the air in your kitchen for amaximum of 24 hours.

1. Switch off the cooker hood by touching the on/off key.

2. Switch off the lighting by touching the lighting key.

3. Touch and hold the timer key for approximately 3 seconds.

The cooker hood switches on automatically for 10 minutes every hour at the lowest speed setting. During this period, the on/off key will be lit continuously while the speed setting 1 key and the timer key will flash.

4. Switch off the Clean Air function in the meantime by touching the

timer key, or by switching off the cooker hood by touching the on/ off key. Note! The Clean Air function cannot be activated when the intensive setting or the timer function is switched on. Key lock function The key lock function allows you to lock the keys for cleaning purposes or for child safety.

1. Switch off the cooker hood by touching the on/off key.

2. Touch and hold the on/off key for approximately three seconds until

all keys will flash from the right to the left. All keys are locked.

3. To unlock the keys, touch and hold the on/off key again for

approximately three seconds. OPERATIONEN 8 Cleaning the filters Saturation grease and odor/fine dust filters The filters should be replaced or cleaned when the filter indicator key is flashing. Grease filter The filter indicator key and speed key 1 will flash after 100 operating hours.

• The grease filters should then be cleaned. Odor/fine dust filter The filter indicator key and speed key 2 will flash after 200 operating hours.

• The odor/fine dust filter should then be replaced. Reset the filter indicator

1. Switch off the cooker hood by touching the on/off key.

2. Switch off the lighting by touching the lighting key.

3. Reset the memory: touch and hold speed key 1 for approximately

three seconds. All keys will flash three times. If you have a cooker hood with a odor/fine dust filter, you should activate the odor/fine dust filter indicator. Switching on the odor/fine dust filter indicator (if necessary)

1. Switch off the cooker hood by touching the on/off key.

2. Switch off the lighting by touching the lighting key.

3. Touch and hold speed key 2 for approximately three seconds until

all keys flash twice. The odor/fine dust filter indicator is activated. Switching off the odor/fine dust filter indicator

1. Switch off the cooker hood by touching the on/off key.

2. Switch off the lighting by touching the lighting key.

3. Touch and hold speed key 2 for approximately three seconds until

all keys flash once. The odor/fine dust filter indicator is deactivated. OPERATIONEN 9 Making the connection between cooker hood and hob The connection to an AutoAir hob is not active by default. First the connection to the hob must be activated. At the same time, a setting must also be made on the hob; see the hob manual for this. Check our website for the full range of hobs that can be connected to your cooker hood. Making a connection

1. Turn off the hood and the lighting.

2. Touch and hold the automatic mode key 3 for three seconds.

The automatic mode key, the lighting key, the timer key and the filter indicator key will flash simultaneously for a maximum of two minutes. On your hob, activate the pairing mode in the user menu (see the hob manual). The connection to the hob is established.

3. The connection is successful when the automatic mode key, the

lighting key, the timer key and the filter indicator key are illuminated continuously for two seconds. If the automatic mode key, the lighting key, the timer key and the filter indicator key are no longer illuminated within two minutes, the connection was not successful. Repeat the procedure. If necessary, clear the hood’s memory (see “Disconnecting”). Disconnecting

1. Turn off the hood and the lighting.

2. Touch and hold the filter indicator key 3 for three seconds.

The automatic mode key, the lighting key, the timer key and the filter indicator key will blink five times simultaneously. The hob is no longer connected.

OPERATION WITH A CONNECTED HOBEN 10

Automatic mode The hob can control the extraction of the cooker hood in 3 different ways: manually, semi-automatically, and fully automatically. The automatic mode is for the user who wants the extraction level to be automatically adjusted to the cooking intensity. Extraction starts automatically as soon as a cooking zone is active and the extraction level depends on how the hob is used. When the hob is switched off, the extraction continues for 10 minutes and then stops automatically. In automatic mode, the hob can only switch on speed 1 or 2 for this hood. Switching on/off the automatic mode on the cooker hood The key for the automatic mode on the cooker hood only lights up when the hob is active and set to automatic mode. The hood is switched on and on the hob the automatic mode is active.

1. Shortly touch and release the automatic mode key.

The automatic mode key iluminates; the automatic mode on your cooker hood is now switched on.

2. Shortly touch and release the automatic mode key.

The automatic mode key is no longer iluminated; the automatic mode on your cooker hood is switched off. Activated intensive setting on the hob If the intensive setting for the hood has been set on the hob, it will automatically switch back to speed 3 after six minutes. Activated timer function on the hob If the timer for the hood is set on the hob, the hood will continue to operate at speed 1 (according to the countdown time that is displayed) after switching off the hob until the set time has elapsed.

OPERATION WITH A CONNECTED HOBEN 11

Lighting When a connected hob is switched on, the lighting of the cooker hood always switches on automatically. You can continuously adjust the brightness of the hood via the hob. When you use the hob again (after you have switched the hob off) , the lighting comes on at the preset brightness. When switching off a connected hob, the lighting remains on. Manually switch off the lighting with the lighting key on your AutoAir hob or via your hood.

OPERATION WITH A CONNECTED HOBEN 12

Cleaning Important! For all maintenance first switch off the mains power to the cooker hood by pulling the plug out of the socket or by turning off the home’s master switch. The hood needs to be cleaned regularly, both inside as well as outside (at least in the same frequency as the grease filter cleaning). Do not use abrasive cleaning products. Do not use alcohol! Important! If the instructions regarding cleaning the appliance or replacing the filters are not followed, this can cause a fire. These instructions should be followed! The manufacturer is not liable for damage to the hood or fire damage resulting from incompetent maintenance or from non- adherence to the above safety instructions. Cooker hood Clean the cooker hood with soapy water and a soft cloth. Then wash off with clean water. Do not use aggressive cleaning agents such as caustic soda. The cooker hood finish stays in good condition if it is buffed periodically following the application of wax. Stainless steel cooker hoods Do not use scouring pads or other abrasive cleaners on stainless steel cooker hoods. Finish with a non-abrasive, non-polishing agent and buff the stainless steel in the direction of the grain. Metal grease filters Metal grease filters should be cleaned once a month (or when indicated by the filter cleaning indicator – if present on the model) using a neutral cleaning agent, either by hand or in the dishwasher on a short, low- temperature program. Place the grease filters with the openings facing downwards in the dishwasher so the water can drain out of the filter. Aluminium grease filters become dull as a result of dishwasher cleaning agents. This is normal and does not effect the working. MAINTENANCEEN 13 Grease filters Removing the grease filters

1. Switch off the motor and lighting.

2. Remove the grease filters from the hood by pulling the

specialhandle. Replacing the odor/fine dust filter

1. Remove the grease filters.

2. Fit the odor/fine dust filter. Slot the notches of the odor/fine dust

filter in the specially designed opening.

3. Fit the grease filters.

• The odor/fine dust filter must always be used if the cooker hood is not ducted.

• Using a odor/fine dust filter creates more sound than when using the cooker hood with an outlet.

• The odor/fine dust filter’s operation is optimal at a lower motor speed. You should, therefore, avoid using the intensive setting.

• Saturation of the odor/fine dust filter will eventually occur after more or less prolonged use, depending on the type of cooking and how frequently the grease filter is cleaned.

• It is necessary to replace the odor/fine dust filter when indicated by the filter indicator.

• The odor/fine dust filter must be replaced at least every year.

• DO NOT wash or reuse the odor/fine dust filter. Saturated carbon is not environmentally friendly, change the filter regularly. Lighting This hood is fitted with a light system. This light system has to be replaced by an authorized technician. Do not attempt to replace it by yourself. The lamp in this household appliance is only suitable for illumination of this appliance. The lamp is not suitable for household room illumination. MAINTENANCEEN 14 ENVIRONMENTAL ASPECTS Disposal of packaging and appliance This appliance is made from sustainable materials. This appliance must be disposed of in a responsible manner at the end of its service life. Contact the local authorities for information about the method. The packaging of the appliance is recyclable. The following materials may have been used:

• CFC-free polystyrene (hard PS foam). These materials must be disposed of in a responsible manner and in accordance with government regulations. The appliance is marked with a crossed out wheeled bin symbol to draw your attention to the requirement for the separate disposal of domestic electrical appliances. This means that the appliance may not be disposed of in unsorted household waste at the end of its service life. The appliance must be taken to a special municipal waste processing location for separated waste or to a dealer who provides this service. Collecting and disposing of domestic appliances separately avoids detrimental consequences for humans and the environment. This ensures that the materials used to make the appliance can be recovered and that substantial savings in the use of energy and raw materials can be achieved. Declaration of conformity We hereby declare that our products conform to the applicable European Directives, Regulations and requirements, as well as all requirements in the standards to which reference is made.EN 15844172 / VER 3 / 27-06-2023
