EMD12W3-V1 - Dishwasher EAS Electric - Free user manual and instructions

Product type	Dishwasher
Brand	EAS Electric
Model	EMD12W3-V1
Capacity	12 place settings
Width	60 cm
Height	85 cm
Depth	60 cm
Net weight	45 kg
Energy class	A+
Water consumption per cycle	10 L
Energy consumption per cycle	0.92 kWh
Noise level	46 dB(A)
Washing programs	6 (Eco, Intensive, Quick, Normal, Glass, Pre-wash)
Child safety	Yes
Anti-leak system	Integrated Aquastop
Installation type	Freestanding
Additional options	Delayed start, Half load
Basket material	Stainless steel
Cleaning and maintenance	Washable filters, self-cleaning
Repairability index	7.5 / 10
Spare parts availability	Main parts available for 10 years
Manufacturer warranty	2 years
Country of manufacture	China

Frequently Asked Questions - EMD12W3-V1 EAS Electric

How to install the dishwasher EMD12W3-V1?

Ensure the appliance is level by adjusting the feet. Connect the water supply (pressure 0.04-1.0 MPa) and the drain hose. Plug into a grounded outlet. Refer to the installation diagram in the manual.

What are the available programs?

The programs are: Eco (50°C), Intensive (70°C), Quick (50°C, 30 min), Normal (65°C), Glass (45°C), Pre-wash. Choose according to the level of soiling.

How to start a cycle?

Load the dishes, add detergent, close the door, select a program with the selector, then press the Start button. A beep sounds.

What to do if the dishwasher does not start?

Check that the door is properly closed, the water tap is open, the outlet is powered, and the program is not in delayed start mode. Restart after checking everything.

How to clean the filters?

Turn the cylindrical filter and remove it. Wash the filters under running water with a brush. Reinstall them by snapping into place. This operation should be done regularly.

Why are there residues on the dishes?

This may be due to poor quality detergent, an incorrectly loaded basket (dishes blocking the spray arms), or a clogged filter. Use a suitable detergent and check the load.

How to use the regenerating salt?

Open the salt reservoir cap (at the bottom of the dishwasher), pour about 1 kg of special salt, then fill with water to the brim. The indicator light will turn off.

What do the error codes mean?

Common codes: E1 (water supply problem), E4 (overflow), E9 (heating failure). Refer to the manual for the full list or contact customer service.

Can I repair the appliance myself?

Some operations (filters, arms) are accessible. For parts like the electronic board or pump, call a certified professional. The repairability index is 7.5/10.

Where to find spare parts?

Main parts are available for 10 years after the end of production. Contact EAS Electric after-sales service or search online on spare parts websites.

USER MANUAL EMD12W3-V1 EAS Electric

Scan for manual in other languages and further updates: Manuel dans d'autres langues et mis a jour:
