NV7B6695ACK - Oven SAMSUNG - Free user manual and instructions

Product type	Built-in oven
Brand	Samsung
Model	NV7B6695ACK
Dimensions (W x H x D)	595 x 596 x 570 mm
Installation dimensions (W x H x D)	560 x 579 x 549 mm
Weight (depending on model)	Approx. 40.6 kg
Capacity	76 L
Power supply	230-240 V ~ 50 Hz
Maximum power	3650-3950 W
Energy efficiency class	A+
Energy consumption (convection)	0.71 kWh/cycle
Energy consumption (fan oven)	1.05 kWh/cycle
Cooking modes	Convection, Classic, Eco Convection, Large grill, Eco grill, Grill with fan, Top heat + Convection, Bottom heat + Convection, Bottom heat, Professional cooking, Air Fry, Sous-vide, Steam cooking, Steam convection, Steam top heat + Convection, Steam bottom heat + Convection, Dual cooking
Special functions	Keep warm, Warm plate, Defrost, Dough proof, Pizza cooking, Slow cooking, Drying, Healthy cooking, Auto cooking
Cleaning	Pyrolysis, Steam cleaning, Descaling, Drainage
Connectivity	Wi-Fi, SmartThings, Smart control
Safety	Child lock, Smart safety mechanism (elements stop when door opens), Soft-close door
Supplied accessories	Metal rack, Metal rack for tray, Baking sheet, Universal tray, Very deep tray, Separator plate, Temperature probe, Steam container, Air Fry basket, Water tank, 2 screws
Interior light	Yes, with auto-off function
Door	Flexible (dual hinge), soft-close
Repairability	Replaceable bulbs (25-40 W, 220-240 V, heat-resistant to 300 °C), Removable side racks, Removable door glass

Frequently Asked Questions - NV7B6695ACK SAMSUNG

How to use the Air Fry function on the Samsung NV7B6695ACK oven?

Place the separator plate and Air Fry basket on level 4. Select Air Fry mode on the screen, set the temperature (usually 210-220 °C) and cooking time. Turn the food halfway through for a crispy and healthy result.

What to do if the oven door does not close properly?

Check that no food residue is blocking the door. Make sure the hinges are properly in place. If the problem persists, contact a Samsung service center.

How to activate child lock on the oven?

Press the On/Off button, then the Options button. Select Lock and confirm. A message appears. To deactivate, hold the button until the unlock notification.

Can I use the temperature probe with all cooking modes?

No. The temperature probe is compatible with Convection, Classic, Steam Convection, Top/Bottom heat + Convection, and a few others. If used with an incompatible mode, an error message appears. Please refer to the manual.

How to clean the oven after steam use?

Use the Steam Cleaning function for light soiling. For a deep clean, run a Pyrolysis cycle (remove all accessories). After steam modes, remember to empty the water tank with the Drainage function.

What does the error code C-d1 on the screen mean?

The code C-d1 indicates a door lock malfunction. Turn off the oven and restart. If the problem persists, cut the power for 30 seconds. Contact an authorized service if the error returns.

How to replace the oven bulb?

First unplug the appliance. Remove the glass cover by turning counterclockwise. Replace with a 25-40 W, 220-240 V bulb resistant to 300 °C. Use a dry cloth to handle it. Replace the cover.

Can the oven be used simultaneously in both zones?

Yes, thanks to the separator plate. Insert it at level 3 to divide the cavity. You can then cook simultaneously in the upper and lower zones with different modes (e.g., Air Fry on top and Convection on bottom). Some combinations may be restricted.

How to set water hardness for steam modes?

Go to Settings > Water hardness. Choose the level corresponding to your water: Soft (up to 120 ppm), Medium (120-240), Medium-Hard (240-350), or Hard (over 350). This setting optimizes descaling frequency.

Why does smoke come out of the oven during first use?

It is normal. Manufacturing residues are burning off. Run the oven empty in Convection mode at 200 °C for 1 hour. Ventilate the kitchen. Once cool, wipe the interior. The smell will disappear after a few uses.

USER MANUAL NV7B6695ACK SAMSUNG

Line drawing of a rectangular tray with ribbed pattern and two circular ends (no text or symbols)

Horna (mm)

A 560 G 503
B 166 H 481
C 383 I 21
D 45 J 549
E 596 K 579
F 595 L 559

Armario empotrado (mm)

A M in. 550

B M in. 560

C M in. 50

D M in. 590 - Máx. 600

E M in. 460 x M in. 50

NOTA

Pure technical diagram of a mechanical assembly without any text, numbers, or symbols

Pure geometric diagram showing a circle inscribed in a rectangular frame with diagonal lines, no text or symbols present.

Architectural line drawing of a window frame structure with an inset showing a mechanical component (no text or symbols)

Illustration of four different electronic components or devices, including a rectangular tray, a rounded rectangle, a rectangular panel, and a control panel with circular buttons (no text or symbols)

Technical diagram showing a mechanical component with a magnified inset highlighting a specific feature (no text or symbols present)

Illustration of a rectangular container with internal compartments and a grid pattern (no text or symbols)

Line drawing of a hand inserting a small component into a door (no text or symbols)

1. Presione completamente la palanca del tirador.

Diagram of a kitchen appliance with a handle and arrow indicating rotation (no text or symbols)

1. Tire de la palanca.

Architectural line drawing of a rectangular building facade with internal horizontal panels (no text or symbols)

Line drawing of a hand using a tool to clean or install a door panel (no text or symbols)

Line drawing of a rectangular panel or tray with internal compartments, no text or symbols present

PRECAUCIÓN

Illustration of a hand inserting a device into a door, with an inset showing the internal components (no text or symbols)

Illustration of a hand pouring liquid into a container with a ring (no text or symbols)

Technical diagram of a mechanical component with labeled section A and internal circular feature (no readable text or symbols)

NOTA

Simple line drawing of a cabinet with doors and an arrow indicating upward motion (no text or symbols)

Diagram of a two-tiered dormer or bench structure with no text or symbols

Illustration of a raw steak inside a bag (no text or symbols)

Simple line drawing of a rectangular enclosure with a central platform and surrounding shelves (no text or symbols)

Diagram showing a hand pressing down on a chair inside a vehicle cabin (no text or symbols present)

Diagram of a kitchen appliance with directional arrows indicating motion (no text or symbols)

Diagram of a car's seatbelt mechanism showing rotation and adjustment (no text or labels)

Diagram of a folded paper or sheet with an inset showing a magnified view of the edge detail (no text or symbols present)

Diagram of a layered electronic device with a ruler and a curved component labeled '01' (no text or symbols beyond labels)

3D diagram of a square frame with an arrow and label '02' (no text or symbols beyond labels)

Diagram of a mechanical or architectural component with labeled points and a central circular feature (no readable text or symbols)

Technical line drawing of a mechanical assembly with a circular component and mounting base (no text or symbols)

Illustration of a cylindrical object with a central rod, resembling a battery or tube (no text or symbols)

Technical diagram of a door or panel corner with a labeled component '01' (no text or symbols beyond label)

01 Colector de agua

Technical line drawing of a mechanical assembly with an inset showing a bracket detail (no text or symbols)

Diagram of a mechanical ladder inside a rectangular frame, with an arrow indicating rotational motion (no text or symbols)

Simple line drawing of a hand holding a small object inside a circular frame (no text or symbols)

Illustration of a hand using a tool inside a circular frame (no text or symbols)

Simple line drawing of a rectangular tray with two circular ends, no text or symbols present.

www.samsung.com/uk/aboutsamsung/sustainability/environment/our-commitment/data/

FR

Courant nominal (A) Section minimale

10 < A ≤ 16.5 mm^2

16 < A ≤ 25.25 mm^2

Four (mm)

A 560 G 503
B 166 H 481
C 383 I 21
D 45 J 549
E 506 K 579
F 595 L 559

Meuble encastré (mm)

A 550 minimum

B 560 minimum

C 50 minimum

D 590 minimum - 600 maximum

E 460 minimum x 50 minimum

REMARQUE

Pure technical diagram of a rectangular frame with a small circular component and dimension line (no text or symbols)

Pure geometric diagram showing a circle intersected by two diagonal lines, with a labeled point A inside (no text or symbols beyond the label)

Architectural line drawing of a window frame structure with an inset showing a mechanical component (no text or symbols)

Illustration of four electronic components: a square container, a rectangular box, a keypad, and a small battery (no text or symbols)

Close-up of a mechanical component with a magnified inset showing a threaded fastener (no text or symbols visible)

Illustration of a rectangular container with internal mesh and circular patterns (no text or symbols)

Line drawing of a hand inserting a small object into a device (no text or symbols)

Diagram of a kitchen appliance with a handle and arrow indicating rotation (no text or symbols)

1. Tirez la poignée,

Architectural or engineering diagram showing layered rectangular structure with no visible text or symbols

Line drawing of a hand holding a tool near a window (no text or symbols)

Line drawing of a door frame with no text or symbols

Illustration of a hand holding a clipboard next to stacked documents with a prohibition symbol (no text or labels)

ATTENTION

Illustration of a hand inserting a device into a door, with an inset showing the insertion (no text or symbols)

Illustration of a hand pouring liquid into a container with a spoon (no text or symbols)

Technical line drawing of a mechanical component with a circular feature and an arrow indicating direction (no text or symbols)

REMARQUE

Simple line drawing of a cabinet with doors and a central shelf, no text or symbols present

Diagram of a two-tier dormitory cabinet with shelves and railings (no text or labels)

Illustration of a loaf of bread inside a bag (no text or symbols)

Simple line drawing of a rectangular enclosure with a central platform and surrounding shelves (no text or symbols)

Diagram showing two connected cables with a cross symbol and circle, no text or labels present

Diagram showing a hand pressing down on a car seatbelt, with an inset circular view highlighting the mechanism (no text or symbols present)

Diagram of an oven with a door and drawer, showing airflow direction (no text or symbols)

Diagram of a car's seatbelt mechanism showing rotation and adjustment (no text or labels)

Technical line drawing of a mechanical component with an inset close-up showing a hand holding a tool (no text or symbols present)

Diagram of a mechanical assembly with a ruler and a flat plate, no visible text or symbols

3D diagram of a square frame with an arrow and label '02' (no text or symbols beyond labels)

Pure diagram of a rectangular frame with a circular label '03' and directional arrows, no text or symbols present.

Technical line drawing of a mechanical assembly with a circular component and mounting base (no text or symbols)

Illustration of a cylindrical object with a central rod, resembling a battery or plug (no text or symbols)

Simple line drawing of a refrigerator with a drawer and drawer holder (no text or symbols)

Diagram of a door frame with a labeled component '01' (no text or symbols beyond label)

01 Collecteur d'eau

Technical line drawing of a mechanical assembly with an inset showing a bracket detail (no text or symbols)

Diagram of a mechanical structure with a rotating component, no text or symbols present

Diagram of a hand holding a small object inside a circular frame (no text or symbols)

Illustration of a hand holding a tool inside a circular frame (no text or symbols)

UNE QUESTION ? DES COMMENTAIRES ?

PAYS APPELEZ LE OU	CONTACTEZ-NOUS EN LIGNE SUR
AUSTRIA 0800 72 67 864 (0800 SAMSUNG) www.samsung.com/at/support
BELGIUM 02-201-24-18		www.samsung.com/be/support (Dutch)www.samsung.com/be_fr/support (French)
DENMARK 707 019 70	www.samsung.com/dk/support
FINLAND 030-6227 515	www.samsung.com/fi/support
FRANCE 01 48 63 00 00	www.samsung.com/fr/support
GERMANY 06196 77 555 77	www.samsung.com/de/support
ITALIA 800-SAMSUNG	(800.7267864) www.samsung.com/it/support
CYPRUS	8009 4000 only from landline, toll free www.samsung.com/gr/support
GREECE	80111 SAMSUNG (80111 726 7864) only from land line([phone] from mobile and land line	www.samsung.com/gr/support
LUXEMBURG	261 03 710	www.samsung.com/be_fr/support
NETHERLANDS	088 90 90 100	www.samsung.com/nl/support
NORWAY	21629099	www.samsung.com/no/support
PORTUGAL	210 608 098Chamada para a rede fixa nacional Dias úteis das 9h às 20h	www.samsung.com/pt/support
SPAIN	91 175 00 15	www.samsung.com/cs/support
SWEDEN	0771-400 300	www.samsung.com/se/support
SWITZERLAND	0800 726 786	www.samsung.com/ch/support (German)www.samsung.com/ch_fr/support (French)
UK	0333 000 0333	www.samsung.com/uk/support
IRELAND (EIRE)	0818 717100	www.samsung.com/ie/support

DG68-01411A-04

Inbouwoven

Simple line drawing of a rectangular tray with two circular ends, no text or symbols present.

www.samsung.com/uk/aboutsamsung/sustainability/environment/our-commitment/data/

Oven (mm)

A 560 G 503
B 166 H 481
C 383 I 21
D 46 J 549
E 596 K 579
F 595 L 559

Inbouwkast (mm)

A M in. 550

B M in. 560

C M in. 50

D M in. 590 - max. 600

E M in. 460 x min. 50

OPMERKING

Pure technical diagram of a rectangular frame with a small circular component and dimension line (no text or symbols)

Pure geometric diagram showing a circle intersected by two diagonal lines, with a labeled point A inside (no text or symbols beyond the label)

Architectural line drawing of a window frame structure with an inset showing a mechanical component (no text or symbols)

Illustration of four electronic components: a rectangular container, a rounded rectangle, a rectangular tray, and a control panel with buttons (no text or symbols)

Diagram of a mechanical component with a magnified inset showing a threaded rod inserted into a liquid (no text or symbols present)

Illustration of a transparent container with internal compartments and a central grid pattern (no text or symbols)

Line drawing of a hand inserting a small component into a door (no text or symbols)

Diagram of a kitchen appliance with a handle and arrow indicating rotation (no text or symbols)

Technical line drawing of a rectangular electronic component or panel assembly (no text or symbols)

Line drawing of a hand holding a tool near a window (no text or symbols)

Line drawing of a folded paper or panel with layered structure (no text or symbols)

Illustration of a hand holding a document with a prohibition symbol (no text or labels present)

LET OP

Illustration of a hand inserting a component into a device (no text or symbols present)

Illustration of a hand pouring liquid into a container with a spoon (no text or symbols)

Technical line drawing of a mechanical component with a circular feature and labeled point A (no text or symbols beyond labels)

Gebruik

Ovenstanden

Simple line drawing of a cabinet with doors open, featuring a black arrow pointing upward (no text or symbols)

12:00

Bovenste oven

Onderste oven

12:00

Boven

Hete lucht

160°C

Bereidingstijd

Diagram of a two-tiered bench structure with no text or symbols

Illustration of a raw steak inside a bag (no text or symbols)

Simple line drawing of a rectangular storage or rack system with no text or symbols

Diagram showing two connectors with a circle highlighting a cross symbol, no text or labels present
