MP2868BT - Media player RIPTUNES - Free user manual and instructions

Product type	Portable media player
Brand	RIPTUNES
Model	MP2868BT
Screen	2.8-inch color touchscreen (320x240 pixels)
Audio formats	MP3, WMA, WAV
Video formats	AMV
Connectivity	Bluetooth, USB 2.0
FM radio	Yes, 87-108 MHz
Voice recording	Yes, built-in microphone
Camera	Yes, resolution up to 2048x1536 pixels
Internal storage	4 GB
Memory extension	MicroSD card
Battery	Lithium-ion 3.7 V / 180 mAh
Output power	10 mW + 10 mW (32 Ω)
Signal-to-noise ratio	85 dB
Dimensions (estimated)	Approx. 100 x 50 x 10 mm
Weight (estimated)	Approx. 60 g
Included accessories	Earphones, USB cable, user manual
Care and cleaning	Clean with a soft, dry cloth. Do not use abrasive products.
Safety	Avoid moisture, shocks, and extreme temperatures. Do not disassemble.
Spare parts and repairability	Contact customer service for any repairs. Parts not available for self-service.
General information	Portable media player with Bluetooth, FM radio, camera, and voice recorder.

Frequently Asked Questions - MP2868BT RIPTUNES

Why won't my player turn on?

Check that the battery is charged. Connect the player via USB for at least 30 minutes. If the problem persists, hold the power button for 10 seconds for a forced reset.

How to transfer files to the player?

Connect the player to a computer using the USB cable. Use Windows Explorer or Mac Finder to drag and drop music, video, or photo files to the internal memory or MicroSD card. Make sure the files are in a supported format (MP3, WMA, WAV, AMV).

What audio and video formats are supported?

The player supports audio formats MP3, WMA, and WAV, as well as video format AMV. Other formats cannot be played.

How to use Bluetooth with headphones?

Go to the Bluetooth menu, enable it, then start device search. Select your headphones from the list and press 'Connect Bluetooth'. Maximum range is 30 meters.

How to save an FM radio station?

Plug in earphones (acting as an antenna), then select Radio from the menu. Press the ≡ icon to access options and choose 'Save station'. You can also start an automatic search.

How to take a photo with the built-in camera?

Select Camera from the main menu. Press the shutter button on the screen or the home button to take a photo. Photos are saved by default in internal memory.

Battery drains quickly, what to do?

Reduce screen brightness in display settings and decrease the auto sleep time. Avoid leaving Bluetooth or radio on unnecessarily. If the problem persists, contact customer service.

The screen shows strange characters, how to fix?

Check the language setting in the Settings menu. The device offers English, French, and Spanish. Select the desired language for correct display.

How to adjust the sound equalizer?

In Music mode, press the ≡ icon during playback. Choose 'Select equalizer' and opt for a preset (Normal, Pop, Classic, etc.) or customize it in 'Equalizer settings'.

Can I use a MicroSD card to increase capacity?

Yes, insert a MicroSD card into the designated slot. The player will automatically recognize the card. You can copy files to the card via computer or choose the save path in settings.

USER MANUAL MP2868BT RIPTUNES

Digital Music Player (MP3/MP4)

User Manuel

Manuel d'usario

Mode d'emploi

Model: MP2868BT

INTRODUCTION

Thank you for purchasing this quality RipTunes digital music player. Please read all the operating instructions before operating the unit and keep this manual in a safe place for later consultation.

UNIT SPECIFICATIONS

• 2.8" 320x240 color touchscreen
- Bluetooth headphone and speaker support
- MicroSD card expansion slot
• MP3/WMA/WAV audio format support
• AMV video format support
- ID3 tag support
- Lyric file support
- FM radio built-in
• EQ modes and repeat functions
- Integrated microphone for audio recordings
- Digital photo album
- Multi-lingual menus

UNIT OVERVIEW

1. Home/select (≡) (also power on/off)
2. Vol +/-: Press to increase (+) or decrease (-) playback volume
3. MicroSD card slot
4. Camera
5. Headphone jack
6. Micro-USB port
7. Reset button

Note: press & hold implies keeping the button depressed for more than 2 seconds.

BASIC OPERATION

Power on/off

1. Press and hold the home/select button to turn the player on or off. Note: The player standby time setting will automatically turn off your player after a certain lapse of inactivity. You can modify this setting. While the music player is connected to a PC, the standby function is temporarily disabled. As well, if the player is currently in "Hold" mode, the home/power button will not be responsive.

Low battery

1. The player display will show a low battery alert.
2. Plug in your player to recharge as soon as possible.

Note: If your digital music player has insufficient power it will automatically turn off to prevent damage to the electronics.

EXPANSION CARD

1. Gently insert a MicroSD card by lightly pressing on the rear edge of the card.
2. To remove the MicroSD card, lightly press on the card and the card will come out partially. Gently pinch the card and pull away from the player to remove it completely.

PLAYER FUNCTIONS

Main menu

1. Use your fingertip to select between the following menu options

- Music

- Bluetooth

- Photos

- Videos

- Recorder

- Browser

- Camera

- Radio

- Settings

MUSIC MODE

1. Select music in the main menu.
2. Select the song you'd like to play by selecting it from among the categories on the screen.

Playback settings

During music playback, press the ⚪ icon to adjust the following playback settings:

• Select EQ: Choose between Normal, Pop, Classic, Soft, Jazz, Rock, DBB and User equalizer settings.
• Play mode: Choose Sequence (normal playback), Repeat One (repeating a single track), Repeat All, Shuffle, Shuffle and Repeat, and intro (plays the first several seconds of every song).

• Screen Size (allows display of audio Spectrum or Lyrics)

• Add to My Playlist: Add a song to the current playlist

• Set rating: rate your favorite songs
• AB Replay: Select a point A and a point B in a specific song; the track will play back from point A to point B.
• Delete: Delete the file
• Advanced: Advanced file settings
• EQ Settings: Modify User EQ for use in "Select EQ" above.
  • Information: View song file information

Press the 🔗 icon to return to the main menu.

Lyric files

Your music player can display lyrics during MP3 playback. Ensure that the LRC lyric file and the MP3 file have the exact same name and are in the same folder.

Example: "My Moon My Man.mp3" and "My Moon My Man.lrc".

VIDEO MODE

1. Select videos in the main menu.
2. Choose the video you'd like to watch from among the folders listed by touching on the screen.

Managing video files

Press the Ⓧ icon to manage your videos and select the following settings

• Now playing: View file information for the video currently playing
• Play modes: Choose normal playback, repeating a single video, folder playback, repeat all videos in a folder, repeat all videos, shuffle, and intro (plays the first several seconds of every video).

- Add Tag: Add a Tag to the video file

- Resume: Resume video playback

- Delete: Delete the file

• Information: View song file information

Press the 🔊 icon to return to the main menu.

CAMERA: PHOTO MODE

1. Select the camera in the main menu.
2. Press the shutter button on the screen or press the select/home button to take photos.

Camera options

With the camera activated, press the ⚪icon to enter the camera settings sub-menu.

• Picture playback: Shows photos already taken with the camera
- White balance: Alter the camera's white balance
- Brightness: Increase or decrease the brightness of photos (-3 to +3)
- Exposure mode: Adjust the camera exposure settings

• Face detection: Activate face detection

• Photo Stickers: Add photo stickers/backgrounds.

- Special effects: Add special effects to your photos.

- Save path: Choose between Internal Memory or Card Memory storage.

- Resolution: Increase or decrease the file size and quality of photos (640x480 up to 2048x1536)

• Available Memory Space: Displays available memory storage space

- Self-timer: Delay taking photos from 5 to 20 seconds after pressing the shutter button

- Continuous shooting: Allow continuous picture shooting for action photos (5 to 30 seconds).

- Date stamp: Add the date or date and time on new camera photos.

CAMERA: VIDEO MODE

1. Select the camera in the main menu.
2. Press the swap arrow icon to enter video recording; press the home/select button to begin recording or stop recording.

Camera options

With the camera activated, press the :≡ icon to enter the camera settings sub-menu.

• Video Playback: View videos already saved.
- White balance: Alter the camera's white balance
- Brightness: Increase the brightness of videos
- Exposure mode: Adjust the camera exposure settings
• Special effects: Add special effects to your videos
• Available memory space: Displays available memory storage space.

- Save path: Choose between Internal Memory or Card Memory storage.

- Resolution: Increase or decrease the file size and quality of videos (from 176x144 up to 640x480). Default is 320x240

BLUETOOTH

1. Select Bluetooth in the main menu
2. Turn Bluetooth on or off

Pairing

1. Ensure your Bluetooth headphones' or speakers' detection mode is activated.
2. Tap on "Search for Devices" to view Bluetooth devices within range (30 feet maximum distance).
3. Tap "Device List"
4. Find your device in the list and tap the device's name
5. Tap "Connect Bluetooth"
6. To disconnect from a device:
7. Select Bluetooth in the main menu
8. Choose Device List
9. Find the name of your device
10. Choose Disconnect Bluetooth

VOICE RECORDER

1. Select Recorder in the main menu.
2. Press the home/select button to begin or end recording.

Recording options

Press the :≡ icon to enter the voice recorder configuration sub-menu.
- Recording format: Choose the recording format (WAV, MP3 or WMA)
- Recording quality: Choose the recording quality (low, medium, high).
- Save path: Choose between Internal Memory or Card Memory storage.

FM RADIO

1. Plug in wired earphones or headphones.
2. Start the FM tuner by selecting Radio in the main menu.

Radio settings

Press the □ icon while in the FM Radio mode to access the following settings:

• Save Channel: Save the current frequency for quick access.
• Auto search: Press to scan all frequencies and detect all broadcast channels.
• Channel list: Lists all broadcast frequencies detected.
• FM Record: Record the current radio broadcast; press the red dot or home/select key to start and stop recording.
• Recording quality: Choose the quality of the recording; (low, medium, high).
• Save path: Choose between Internal Memory or Card Memory storage.
• FM Sensitivity: Choose how sensitive the unit is in picking up remote stations (low, medium, high).
• User Channel List: Choose from among custom programmed channels.
• Tuner region: Select your geographical region.
• Mute: Cut radio sound playback
• Delete: Removes a frequency from the saved list

PHOTOS

1. Select Photos in the main menu.
2. Browse through your photos
3. Tap on a photo you would like to view on screen

Managing photos

Press the :≡ icon while viewing a photo to manage that picture.

• Rotate: Change the orientation of a photo
• Zoom: Zoom in or out of a photo to appreciate details
• Slide interval: Change the time between photos during a slideshow.
• Slide effect: Change the transition effect when changing photos in a slide-show
• Delete: Delete a particular file
  • Information: View file details.

SETTINGS

1. Select settings in the main menu.

2. Bluetooth: Access the Bluetooth settings of your device
   • Display: Change the brightness and backlight shut-off.
   • Power Saving: Adjust Idle time and Sleep time.

3. Date & Time: Configure the current date and time

• Language: Choose between English, Spanish, and French
- Advanced: Use to adjust menu effects, format the unit (erasing all data) and more.

CONNECTING YOUR PLAYER TO A COMPUTER

1. Plug the USB cable in to your computer
2. Use a file browser (Windows Explorer, Mac OS Finder) to move files to and from your portable music player.

Note: only supported file formats can be read by the portable music player, but you may copy any file to and from the device. Consult the technical specifications for readable formats.

TECHNICAL SPECIFICATIONS

Supported file formats: Music: MP3, WMA, WAV • Video: AMV

Device connectivity: USB 2.0

PC compatibility: Windows 2000, XP, Vista, 7, 8, Mac OS X

FM tuner range: 87MHz - 108MHz

Signal-to-noise ratio: 85dB

Max output power: 10mW + (R) 10mW (32 Ω)

Internal storage capacity: 8GB

Battery rating: 3.7 volts/500 mAh

Operating temperature: -5°C to 40°C

Included accessories: User manual, earbuds, USB-A to micro-USB cable

TROUBLESHOOTING

The player does not work

• Check if the battery is charged
• Check that the power button is on
• Check the volume and that your headphones are properly connected
• Check the music file format
• Check the disk format. Should be FAT32

I can't transfer files to/from the player

- Check the USB cable connection

The player does not make voice recordings

• Check the available memory space
• Check if the battery is charged

Strange characters appear on the screen

- Check the display language in the device settings

FM radio plays static or distortion

- Adjust the position of the headphone wires; they are the antenna.

CONTACT TECHNICAL SUPPORT

If you have additional questions, experience any issue that are not listed within this manual, or if you are unable to resolve your issue after trying the methods and solutions described within this manual, please contact our technical support team via:

E-mail: [e-mail]

Phone: [phone]

Online: www.rip-tunes.com
