USER MANUAL AR5EA50PB ARDES
3. Safety screw of the fan
5. Lock ring of the back grille
(see image at last page)
A-B. Locking pin for the rear grille Place the fan on a at, dry and stable surface, and insert the plug of the fan in a socket. Select the desired speed by pressing the buttons on the control panel (10): 0=o 1=minimum speed 2=medium speed 3=maximum speed OSCILLATION: For the automatic oscillation from right to left press the knob (8) placed on top of the motor. To disable it, pull up the knob. VERTICAL SLOPE: You can vertically point the front of the fan choosing the desired angle. It is sucient to move the front of the fan up or down according to the desired slope. ADJUSTMENT HEIGHT Loosen the height adjustment knob (13), then set the desired height for the fan. Tighten rmly the knob after adjusting the rod. N.B: this operation must always be carried out while the fan is turned o.
