USER MANUAL WM3460CW LG

OWNER'S MANUAL WASHING MACHINE Read this owner's manual thoroughly before operating the appliance and keep it handy for reference at all times. WM3500CW WM3505CW WM3095CW WM3460CW WM3460CV MFL68005567 Rev.08_090219 www.lg.com Copyright © 2018-2019 LG Electronics Inc. All Rights Reserved.2

3 PRODUCT FEATURES 4 SAFETY INSTRUCTIONS

4 IMPORTANT SAFETY INSTRUCTIONS

8 PRODUCT OVERVIEW 8 Parts 8 Accessories 9 INSTALLATION 9 Tools Needed 9 Installation Overview 10 Product Specifications 11 Choosing the Proper Location 12 Unpacking and Removing Shipping Bolts 13 Connecting the Water Lines 14 Connecting the Drain Hose 15 Leveling the Washer 16 Connecting to the Power Supply 16 Testing the Washer 17 OPERATION 17 Using the Washer 18 Sorting Laundry 19 Loading the Washer 19 Adding Cleaning Products 22 Control Panel 24 Wash Cycles 26 Cycle Guide 28 Cycle Modifier Buttons 29 Option Buttons 31 SMART FUNCTIONS 31 LG SmartThinQ Application 34 Smart Diagnosis™ Function 35 MAINTENANCE 35 Regular Cleaning 37 Cleaning the Door Seal 37 Cleaning the Water Inlet Filters 38 Cleaning the Drain Pump Filter 39 Care in Cold Climates 40 TROUBLESHOOTING 40 FAQs: Frequently Asked Questions 41 Before Calling for Service 49 LIMITED WARRANTY 49 FOR USA 52 FOR CANADA 56 Warranty Exceptions (U.S. and Canada)3PRODUCT FEATURES ENGLISH PRODUCT FEATURES Inverter Direct Drive Motor The inverter motor, which is directly connected to the tub, produces little noise and vibration and offers great durability and a long lifespan. Tub Clean Cleaning of the drum on a regular monthly basis using Tub Clean can help keep the drum clean and fresh. Large Capacity Stainless Steel Drum The large capacity stainless steel drum offers extreme durability and is tilted to improve efciency and allow easier access for large items. Control Lock Use this option to disable the controls during a wash cycle. This option can prevent children from changing cycles or operating the machine. Detergent Dispenser Drawer The four-compartment dispenser makes it easy to separate the pre-wash detergent, main laundry detergent, liquid bleach, and fabric softener into different compartments. High Temperature Steam Cycles (On Some Models) LG's unique, high-temperature steam cycles help to remove tough stains. Smart Diagnosis™ Should you experience any technical difculty with the appliance, it has the capability of transmitting data via your telephone to the Customer Information Center. The call center agent records the data transmitted from your machine and uses it to analyze the issue, providing a fast and effective diagnosis.4 SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS

READ ALL INSTRUCTIONS BEFORE USE

Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and follow all safety messages.This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or injure you and others. All safety messages will follow the safety alert symbol and either the word WARNING or CAUTION.These words mean: WARNING If you do not follow instructions, it could result in death or serious injury. CAUTION If you do not follow instructions, it could result in minor or moderate injury or damage to the product.All safety messages tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what may happen if the instructions are not followed.

IMPORTANT SAFETY INSTRUCTIONS

WARNING To reduce the risk of explosion, re, death, electric shock, scalding or injury to persons when using this product, follow basic precautions, including the following: INSTALLATION

• Adhere to all industry recommended safety procedures including the use of long-sleeved gloves and safety glasses.
• Never attempt to operate this appliance if it is damaged, malfunctioning, partially disassembled, or has missing or broken parts, including a damaged cord or plug.
• Before use, the appliance must be properly installed as described in this manual.

• To reduce the risk of severe injury or death, follow all installation instructions.

• Refer to the INSTALLATION INSTRUCTIONS for detailed grounding procedures. Installation instructions are packed with the appliance for the installer’s reference. If the appliance is moved to a new location, have it checked and reinstalled by qualied service personnel.
• Moving or installation of the appliance requires two or more people.
• Do not install the appliance in humid spaces.
• Store and install the appliance where it will not be exposed to temperatures below freezing or exposed to outdoor weather conditions.
• This appliance is not designed for maritime use or for mobile installations such as in RVs, trailers, or aircraft.5SAFETY INSTRUCTIONS ENGLISH

• Keep packing materials out of the reach of children. Packaging material can be dangerous for children. There is a risk of suffocation.

• Destroy the carton, plastic bag, and other packing materials after the appliance is unpacked. Children might use them for play. Cartons covered with rugs, bedspreads, or plastic sheets can become airtight chambers.

• The appliance must be installed and electrically grounded by qualied service personnel in accordance with local codes.

• Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.

• When installing or moving the appliance, be careful not to pinch, crush, or damage the power cord.

• Connect to a properly rated, protected, and sized power circuit to avoid electrical overload.

• This appliance must be positioned near to an electrical power supply.

• Disconnect the power cord, house fuse or circuit breaker before installing or servicing the appliance.

• The power cord of this appliance is equipped with a 3-prong (grounding) plug which mates with a standard 3-prong (grounding) wall outlet to minimize the possibility of electric shock from this appliance.

• Use new hoses when connecting the appliance to the water supply. Do not reuse old hoses. OPERATION

• Read all instructions before using the appliance and save these instructions.

• Use this appliance only for its intended purpose.

• If the product has been submerged, contact an LG Electronics customer information center for instructions before resuming use.

• If you detect a strange sound, a chemical or burning smell, or smoke coming from the appliance, unplug it immediately, and contact an LG Electronics customer information center.

• Under certain conditions, hydrogen gas may be produced in a hot-water system that has not been used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot-water system has not been used for such a period, before using the appliance turn on all hot water faucets and let the water ow from each for several minutes. This will release any accumulated hydrogen gas. As the gas is ammable, do not smoke or use an open ame during this time.

• Do not reach into the washer if the tub or drum, agitator, or any interior parts are moving. Before loading, unloading, or adding items, press Start/Pause and allow the tub or drum to coast to a complete stop before reaching inside.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety.

• Do not allow children or pets to play on, in or with the appliance. Close supervision is necessary when the appliance is used near children or pets.

• Keep laundry products out of children’s reach. To prevent injury to persons, observe all warnings on product labels.

• Repair or immediately replace all power cords that have become frayed or otherwise damaged. Do not use a cord that shows cracks or abrasion damage along its length or at either end.

• Never unplug the appliance by pulling on the power cord. Always grip the plug rmly and pull straight out from the outlet.

• Do not use an extension cord or adapter with this appliance.

• Do not grasp the power cord or touch the appliance controls with wet hands.

• Do not modify or extend the power cord.6 SAFETY INSTRUCTIONS

• If the electrical supply cord is damaged, it must only be replaced by the manufacturer or its service agent or a similar qualied person in order to avoid a hazard.

• Do not put oily or greasy clothing, candles or ammable materials on top of the appliance.

• Keep the area underneath and around your appliances free of combustible materials (lint, paper, rags, etc.), gasoline, chemicals and other ammable vapors and liquids.

• Do not store or use gasoline or other ammable vapors and liquids in the vicinity of this or any other appliance.

• Do not mix chlorine bleach with ammonia or acids such as vinegar. Follow package directions when using laundry products. Incorrect usage can produce poisonous gas, resulting in serious injury or death.

• Never use harsh chemicals, abrasive cleaners, or solvents to clean the washer. They will damage the nish.

• Do not wash articles that have been previously cleaned in, washed in, soaked in, or spotted with gasoline, dry-cleaning solvents, vegetable or cooking oil, or other ammable or explosive substances, as they give off vapors that could ignite or explode.

• Do not add gasoline, dry cleaning solvents, or other ammable or explosive substances to the wash water. These substances give off vapors that could ignite or explode.

• In the event of a gas leak (propane gas, LP gas, etc.) do not operate this or any other appliance. Open a window or door to ventilate the area immediately.

• Do not tamper with controls.

• Fix the drain hose securely in place to avoid ooding.

• Do not abuse, sit on, or stand on the door of the appliance.

• Do not allow water, bleach or other liquids to sit in the drum for extended periods. Doing so can corrode thedrum or cause mildew or odors. MAINTENANCE

• Do not repair or replace any part of the appliance. All repairs and servicing must be performed by qualied service personnel unless specically recommended in this owner’s manual. Use only authorized factory parts.

• Disconnect this appliance from the power supply before cleaning and attempting any user maintenance. Turning the controls to the OFF position does not disconnect this appliance from the power supply.

• Remove any dust or foreign matter from the power plug pins.

• Do not disassemble or repair the appliance by yourself.

• Remove the door before the appliance is removed from service or discarded to avoid the danger of children or small animals getting trapped inside.

• Make sure the dispenser drawer or lid is closed at all times when not being lled with laundry products. GROUNDING INSTRUCTIONS

• Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with a qualied electrician or service personnel if you are in doubt whether the appliance is properly grounded. Do not modify the plug provided with the appliance; if it will not t the outlet, have a proper outlet installed by a qualied electrician.

• The appliance must be grounded. In the event of a malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current. The appliance is equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is installed and grounded in accordance with all local codes and ordinances.7SAFETY INSTRUCTIONS ENGLISH CAUTION To reduce the risk of minor or moderate injury to persons, malfunction, or damage to the product or property when using this product, follow basic precautions, including the following: INSTALLATION
• Install the product on a rm and level oor. OPERATION
• Do not place objects on top of the appliance.
• Turn off the water faucets and unplug the appliance if the appliance is to be left for an extended period of time, such as during vacations.
• ALWAYS follow the fabric care instructions supplied by the garment manufacturer.

• Use fabric softeners or products to eliminate static only as recommended by the manufacturer.

• Do not combine laundry products for use in one load unless specied on the label.
• Do not touch draining water which may be hot.
• If the drain hose and the water supply hose are frozen in winter, defrost them before using the appliance.

• Do not store or spill liquid detergents, cleaners, or bleaches (chlorine bleach, oxygen bleach) on the appliance. Doing so may result in corrosion, discoloration or damage to the surface of the appliance.
• Clothing or articles that are waterproof or water resistant must be washed in the Waterproof cycle only. (e.g. water resistant clothing, mattress covers, outdoor clothes, plastic mats, etc.) Otherwise, it may result in personal injury or damage to the washer, clothes, walls, oor, and surrounding objects due to abnormal vibration.

SAVE THESE INSTRUCTIONS8 PRODUCT OVERVIEW

PRODUCT OVERVIEW Parts

Drain Pump Filter Cover Water Inlets Detergent Dispenser Drawer

Drain Pump Filter Shipping Bolts Door Seal Leveling Feet Drain Hose Power Cord Drain Hose Accessories Included Accessories Non-skid padsHole caps (4)WrenchTie strapElbow bracket (for securing drain hose) Required Accessories Hot/cold water hoses (sold separately) Optional Accessories Pedestal or Pedestal washer (sold separately)Stacking Kit (sold separately) NOTE

• The images in this guide may be different from the actual components and accessories, which are subject to change by the manufacturer without prior notice for product improvement purposes.
• For your safety and for extended product life, use only authorized components. The manufacturer is not responsible for product malfunction or accidents caused by the use of separately purchased unauthorized components or parts.9INSTALLATION ENGLISH INSTALLATION Tools Needed Pliers Level Installation Overview Please read the following installation instructions rst after purchasing this product or transporting it to another location. TEST! Choosing the proper location Unpacking and removing shipping boltsConnecting the water linesConnecting the drain line Leveling the washer Connecting to the power supplyTesting the washer10 PRODUCT OVERVIEW Product Specications The appearance and specications listed in this manual may vary due to constant product improvements. Electrical requirements 120 VAC @ 60 Hz Min. / Max. water pressure 20 – 120 psi (138–827 kPa) Dimensions 70 cm(W) X 77 cm(D) X 99 cm(H), 139.6 cm (D with door open) 27”(W) X 30 ¼”(D) X 39”(H), 55” (D with door open) Net weight 187.4 lb (85 kg) Max spin speed 1300 RPM WARNING

• Moving or installation of the appliance requires two or more people. Failure to follow these instructions may result in injury.

• Store and install the appliance where it will not be exposed to temperatures below freezing or exposed to outdoor weather conditions. Failure to follow this warning can cause product or part failure, serious injury, re, electric shock, or death.

• Properly ground the washer to conform with all governing codes and ordinances. Failure to follow this warning can cause serious injury, re, electric shock, or death.

• To reduce the risk of electric shock, do not install the appliance in humid spaces. Failure to follow this warning can cause serious injury, re, electric shock, or death.

• To ensure proper airow, do not block the large opening on the bottom of the washer with carpeting or other materials.

• Do not remove the ground prong. Do not use an adapter or extension cord. Plug into a grounded 3-prong outlet. Failure to follow this warning can cause serious injury, re, electric shock, or death.

• Certain internal parts are intentionally not grounded and may present a risk of electric shock only during servicing. Service personnel - Do not contact the following parts while the appliance is energized: pump, valve, motor, control board.11PRODUCT OVERVIEW ENGLISH Choosing the Proper Location Install the washer on a solid oor that is strong and rigid enough to support the weight of the washer, even when fully loaded, without exing or bouncing. If the oor has too much ex, you may need to reinforce it to make it more rigid. If the oor is not solid, it may cause severe vibration and noise. NOTE
• Before installing the washer, make sure the oor is clean, dry and free of dust, dirt, water and oil so the washer feet cannot slide easily. Leveling feet that can move or slide on the oor can contribute to excess vibration and noise due to poor contact with the oor. • If a drip pan must be used, take extra care to follow the instructions provided with the drip pan and make sure the leveling feet are adjusted for rm and even contact with the pan. Use of drip pans and failure to properly level the machine may result in increased vibration and noise during operation. • Allow for sufcient space between the walls and the washer for installation. Power Outlet
• The power outlet must be within 60 inches (1.5 m) of either side of the washer. • The appliance and outlet must be positioned so that the plug is easily accessible. • Do not overload the outlet with more than one appliance. • The outlet must be grounded in accordance with current electrical wiring codes and regulations. • Use a time-delay fuse or circuit breaker. NOTE
• It is the personal responsibility and obligation of the product owner to have a proper outlet installed by qualied service personnel. Flooring
• To minimize noise and vibration, the washer must be installed on a solidly constructed oor. • Allowable slope under the entire washer is a maximum 1 inch (2.5 cm) difference from side to side or from front to back. • Installing on carpeting and soft tile surfaces is not recommended. • Never install the washer on a platform or weakly supported structure. NOTE
• The washer must be installed on rm ooring to minimize vibration during the spin cycle. Concrete ooring is best, but a wood oor is sufcient, provided it is built to FHA standards. Floor Installation (70 cm)(2.5 cm) (2.5 cm) 27"1" 1"(0.5 cm

To ensure sufcient clearance for water lines, the drain line and airow, allow minimum clearances of at least 1 inch (2.5 cm) at the sides and 4 inches (10 cm) behind the unit. Be sure to allow for wall, door, or oor moldings that may increase the required clearances. Stacked or Pedestal Installation 30 ¼" (77 cm) (10 cm) 27" (70 cm) (2.5 cm) (2.5 cm) 77 ½" (196.8 cm) (0.5 cm)

• Refer to the instructions packaged with the optional pedestal kit before installing with a pedestal kit. • Do not use a drip pan with a pedestal or pedestal washer installation as it can block the drawer. Using a drip pan may result in increased vibration and noise during operation.12 PRODUCT OVERVIEW Unpacking and Removing Shipping Bolts Unpack all shipping materials from the washer for proper operation and inspect it for shipping damage. CAUTION

• Failure to remove shipping materials can cause excessive noise and vibration.

Lift the washer off the foam base. After removing the carton and shipping material, lift the washer off the foam base. Make sure the plastic tub support comes off with the base and is not stuck to the bottom of the washer. If you must lay the washer down to remove the base packaging materials, always protect the side of the washer and lay it carefully on its side. Do not lay the washer on its front or back. Foam tub supportCarton base

Remove the bolt assemblies. Starting with the bottom two shipping bolts, use the wrench (included) to fully loosen all four shipping bolts by turning them counterclockwise. Remove the bolt assemblies by wiggling them slightly while pulling them out. RetainerShipping bolt

Install the hole caps. Locate the four hole caps included in the accessory pack and install them in the shipping bolt holes. Cap NOTE

• Save the bolt assemblies for future use. To prevent damage to internal components, do not transport the washer without reinstalling the shipping bolts.

• Failure to remove shipping bolts and retainers may cause severe vibration and noise, which can lead to permanent damage to the washer. The cord is secured to the back of the washer with a shipping bolt to help prevent operation with shipping bolts in place.13PRODUCT OVERVIEW ENGLISH Connecting the Water Lines To avoid the risk of costly water damage, purchase and install new inlet hoses when installing the washer.

Check the ttings and seals. Inspect the threaded tting on each hose and make sure there is a rubber seal in place in both ends of each hose to prevent leaking. Rubber seal Rubber sealWater hose (to water inlet on washer)Water hose (to tap)

Connect the water supply hoses. Connect the water supply hoses to the hot and cold water faucets tightly by hand and then tighten another 2/3 turn with pliers. Connect the blue hose to a cold water faucet and the red hose to a hot water faucet.

Flush out the inlet hoses. After connecting the inlet hoses to the water faucets, turn on the water faucets to ush out foreign substances (dirt, sand or sawdust) in the water lines. Let water drain into a bucket, and check the water temperature to make sure you've connected the hoses to the correct faucets.

Attach the water lines to the back of the washer. Attach the hot water line to the hot water inlet on the back of the washer. Attach the cold water line to the cold water inlet on the back of the washer. Tighten the ttings securely. Turn ON both faucets all the way and check for leaks at both ends of the hoses.

Cold water inletHot water inlet WARNING

• Do not overtighten the hoses or cross-thread the hose ttings. Overtightening or cross-threading can damage the valves or couplings, resulting in leaking and property damage.

• Do not reuse old hoses. Use only new hoses when installing the washer. Old hoses could leak or burst causing ooding and property damage. Contact an LG Customer Information Center for assistance in buying hoses. NOTE

• Periodically check the hoses for cracks, leaks, and wear, and replace the hoses every ve years. Do not stretch the water hoses intentionally, and make sure that they are not pinched, crushed or kinked by other objects.

• Water supply pressure must be between 20 psi and 120 psi (138 – 827 kPa). If the water supply pressure is more than 120 psi, a pressure reducing valve must be installed.

• To provide optimum washing performance, the hot water temperature should be set at 120 – 130 °F (48 – 54 °C) and the cold at 60 °F (15 °C).

• The washer should never be installed or stored in a location subject to freezing temperatures. Damage to the water lines and internal mechanisms of the washer can result. If the washer was exposed to freezing temperatures prior to installation, allow it to stand at room temperature for several hours before use and check for leaks prior to operation.

• Do not use ood-preventing hoses with auto shutoff devices. The devices can be tripped during ll and prevent the machine from lling properly.14 PRODUCT OVERVIEW Connecting the Drain Hose Connect the drain hose to either a standpipe or laundry tub. NOTE
• The drain hose should always be properly secured. Failure to properly secure the drain hose can result in ooding and property damage. • The drain must be installed in accordance with any applicable local codes and regulations. • Make sure that the drain hose is not stretched, pinched, crushed, or kinked. • Do not install the drain hose with the end lower than 29.5 inches (0.7 m) or higher than 96 inches (2.4 m) above the bottom of the washer or more than 60 inches (1.5 m) away from the washer. • Never create an airtight seal between the hose and the drain with tape or other means. If no air gap is present, water can be siphoned out of the tub resulting in poor wash/rinse performance or clothing damage. Option 1: Standpipe

Clip the end of the hose into the elbow bracket.Connect the elbow bracket within 4 inches (10 cm) of the end of the drain hose. If the drain hose is extended more than 4 inches (10 cm) beyond the end of the elbow bracket, mold or microorganisms could spread to the inside of the washer. No more than 4 inches (10 cm)Elbow bracket Insert the end of the drain hose into the standpipe.Drain hoseElbow bracket Use a tie strap to secure the drain hose in place. Option 2: Laundry Tub

Clip the end of the hose into the elbow bracket.Connect the elbow bracket within 4 inches (10 cm) of the end of the drain hose. If the drain hose is extended more than 4 inches (10 cm) beyond the end of the elbow bracket, mold or microorganisms could spread to the inside of the washer. No more than 4 inches (10 cm)Elbow bracket Hang the end of the drain hose over the side of the laundry tub. Drain hoseElbow bracket Use a tie strap to secure the drain hose in place.15PRODUCT OVERVIEW ENGLISH Leveling the Washer The drum of your new washer spins at very high speeds. To minimize vibration, noise, and unwanted movement, the oor must be a level, solid surface. NOTE

• Adjust the leveling feet only as far as necessary to level the washer. Extending the leveling feet more than necessary can cause the washer to vibrate.

• Before installing the washer, make sure that the oor is clean, dry and free of dust, dirt, water and oil so the washer feet cannot slide easily. Feet that move or slide on the oor can contribute to excessive vibration and noise due to poor contact with the oor.

Position the washer in its nal location. Take special care not to pinch, strain, or crush the water and drain lines. If you have a carpenter's level, you can place it across the top of the washer. The slope beneath the washer should not exceed 1 inch, and all four leveling feet must rest rmly on the oor. Level1"

Adjust the lower leveling feet. Turn in one direction to raise the washer or the other direction to lower it. Raise Lower

Tighten the locknuts. Turn the locknuts counter-clockwise and tighten them when the washer is level. Lock nutTighten all 4 lock nuts securely

Recheck the washer’s levelness. Push or rock the top edges of the washer gently to make sure the washer does not rock. If the washer rocks, repeat steps 1-3. CAUTION

• Using the washer without leveling it may cause excess vibration and noise, leading to a machine malfunction.

• Extend the leveling feet only to level the washer. If you extend the leveling feet unnecessarily, it may cause abnormal vibration of the washer. Using Non-Skid Pads If you install the washer on a slippery surface, it may move because of excessive vibration. Incorrect leveling may cause malfunction through noise and vibration. If this occurs, install the non-skid pads under the leveling feet and adjust the level.

Clean the oor to attach the non-skid pads. Use a dry rag to remove and clean foreign objects or moisture. If moisture remains, the non-skid pads may slip.

Adjust the level after placing the washer in the installation area.

Place the adhesive side of the non-skid pad on the oor. It is most effective to install the non-skid pads under the front leveling feet. If it is hard to place the pads under the front leveling feet, place them under the back leveling feet. This side upAdhesive side Remove backing

Recheck the washer’s levelness. Push or rock the top edges of the washer gently to make sure that the washer does not rock. If the washer rocks, level the washer again.16 PRODUCT OVERVIEW Connecting to the Power Supply The washer should be plugged into a 120-VAC, 60 Hz grounded 3-prong outlet. Plug in the washer. WARNING

• Do not use a worn or damaged power cord or power plug. Replace or repair it immediately. Failure to do so may result in death, re, electric shock, or malfunction.

• Do not modify the power cord and plug provided with the appliance. Take care not to damage it when installing or moving the washer. Failure to do so may result in death, re, electric shock, or malfunction.

• Make sure that the washer is grounded.

• Connect this washer to a grounded outlet conforming to the rating prior to use. Failure to do so may result in re, electric shock, or malfunction.

• Do not damage or cut off the ground prong of the power cord. Doing so may cause death, re, electric shock, or product malfunction.

• Improper connection of the equipment-grounding conductor can result in risk of electric shock. Check with a qualied electrician or service technician if you are in doubt as to whether the appliance is properly grounded. If it does not t the outlet, have a proper outlet installed by a qualied electrician

• The appliance and outlet must be positioned so that the plug is easily accessible.

• Do not use adapters or extension cords. Doing so may result in serious injury, re, electric shock, or death.

• For best performance, plug the washer into its own individual outlet. This helps prevent overloading house wiring circuits which could cause a re hazard from overheated wires.

• If necessary, use a new, UL-listed 3-prong adapter or 3-wire extension cord with a 3-prong (grounding) plug rated at no less than the branch circuit. Do not use an extension cord longer than 3 feet. Failure to follow these warnings may result in serious injury, re, electric shock, or death. Testing the Washer Check if the washer is properly installed and run a test cycle.

Load the washer with 6 pounds of laundry (approximately 6 thick bath towels).

Check if water is supplied, that the machine does not rock or vibrate excessively, and that it drains well during the spin cycle. NOTE

• If water leaks during water supply, see Connecting the Water Lines to connect them properly.

• If the washer rocks and vibrates excessively, see Leveling the Washer to level it again.

• If the drain does not work, see Connecting the Drain Hose to install the hose properly.17OPERATION ENGLISH OPERATION Using the Washer WARNING

• To reduce the risk of re, electric shock, or injury to persons, read the SAFETY INSTRUCTIONS before operating this appliance. Sort Laundry and Load the WasherSort laundry by fabric type, soil level, color and load size, as needed. Open the door and load items into the washer.If using detergent pods, place pod in drum before loading laundry. Add Cleaning Products.Add the proper amount of HE (High-Efciency) detergent to the detergent dispenser. If desired, add bleach or fabric softener to the appropriate areas of the dispenser drawer. Do not place liquid or powdered detergent pods in the dispenser. Turn on the WasherPress the Power button to turn on the washer. The lights above the cycle buttons will illuminate and a chime will sound. Select a CycleTurn the Cycle Selector Knob until the desired cycle is selected. The preset Temp., Spin, Soil and option settings for that cycle will be shown. Pressing the Start/Pause button without selecting a cycle will cause the Normal cycle to begin immediately. Adjust SettingsDefault settings for the selected cycle can now be changed, if desired, using the cycle modier and option buttons.
• Not all modiers and options are available on all cycles. A different chime will sound and the LED will not come on if the selection is not allowed. Begin Cycle Press the Start/Pause button to begin the cycle. The washer will agitate briey without water to measure the weight of the load. If the Start/Pause button is not pressed within 60 minutes, the washer will shut off and all settings will be lost. End of CycleWhen the cycle is nished, a melody will sound. Immediately remove your clothing from the washer to reduce wrinkling. Check around the door seal when removing the load for small items that may be caught in the seal. NOTE

• The washer rotates the laundry in a way that allows it to use less water while still fully saturating your clothing. It is normal to not be able to see water during the wash cycle.
• If the temperature or the water level inside the machine is too high, the door will not unlock when the Start/ Pause button is pressed. To open the door in these circumstances, press Add Garments. To stop a cycle and drain the water completely, turn the power off, then on, and then press Rinse+Spin.18 OPERATION Sorting Laundry CAUTION

• The washer can be fully loaded, but the drum should not be tightly packed with items. The door of the washer should close easily.

• Use the Bedding cycle for buoyant or nonabsorbent items such as pillows or comforters. Failure to follow this caution can result in leakage.

• Clothing or articles that are waterproof or water resistant must be washed in the Bedding cycle only. (e.g. water resistant clothing, mattress covers, outdoor clothes, plastic mats, etc.) Otherwise, it may result in personal injury or damage to the washer, clothes, walls, oor, and surrounding objects due to abnormal vibration.

• Remove the stufng from pillows and cushions before washing the covers. Failure to do so can cause excessive vibration, resulting in damage to the washer, clothes, nearby objects, walls, and oor. Grouping Similar Items For the best washing results, and to reduce the possibility of damage to clothing, care should be taken to sort the clothing into loads that are made up of similar items. Mixing different fabric types and/or soil levels can result in poor wash performance, color transfer, discoloration, fabric damage or linting. Fabrics should be sorted into groups as described below. Colors Sort articles by color. Wash dark clothes together in a separate load from light colors or whites. Mixing dark clothes with light clothes can result in dye transfer or discoloration of the lighter clothes. Soil Level Wash heavily soiled clothing together. Washing lightly soiled clothing in the same load with heavily soiled clothing could result in poor wash performance for the lightly soiled clothing. Fabric Type Delicate articles should not be mixed with heavy or sturdy fabric types. Washing heavy fabrics in a delicate load can result in poor wash performance for the heavy fabrics and possible damage to the delicates. Lint Type Some fabrics attract and bind lint to them while others give off lint in the laundry process. Avoid mixing these lint collectors and lint producers in the same load. Mixing these fabrics will result in pilling and linting on the lint collectors. (For example, lint collector—knit sweater; lint producer—terry cloth towels.) Sort Laundry By colors By Soil By Fabric By Lint White Heavy DelicatesLint ProducerLights Normal Easy CareLint CollectorDarks Light Sturdy Fabric Care Labels Many articles of clothing include a fabric care label. Using the chart below, adjust the cycle and option selections to care for your clothing according to the manufacturer’s recommendations. Category Label Directions WashingHand washMachine wash, Normal cyclePerm Press/Wrinkle Resistant setting (which has a cool down or cold spray before the slower spin)Gentle/Delicate setting (slow agitation and/or reduced wash time)Do not washDo not wringWater Temperature Hot Warm Cold/CoolBleach SymbolsAny bleach (when needed)Only non-chlorine bleach (when needed)Do not bleach19OPERATION ENGLISH Loading the Washer

• Check and empty pockets. Paper clips, coins, matches, etc. can damage clothing and the washer.

• Close zippers and hooks, and tie drawstrings to prevent snagging or tangling of clothes.

• Pretreat heavily stained areas for best results.

• Combine large and small items in a load. Load large items rst. Large items should not be more than half of total load.

• The washer can be fully loaded, but the drum should not be tightly packed with items. The door of the washer must close easily.

• Do not wash single small items. Add 1-2 similar items to the load to prevent an out-of-balance load.

• Wash thick, bulky items individually. Heavy blankets, comforters, bedspreads, or pet beds can get tangled or cause an unbalanced load if combined with other items.

• Do not wash/spin waterproof items. Washing raincoats or sleeping bags may result in abnormal vibration or may cause the load to bounce, which could damage the drum.

• Wash small, light items in a mesh bag. Items like underwear can get caught in the door seal, and a brassiere hook may damage other items or the drum.

• Brush off heavy soil, dust, and hair from items before washing. Excess dirt or sand can abrade other fabrics and lead to poor wash performance.

• For best performance, load clothes as shown.

- Load clothes loosely, and do not overll the drum. Clothes need room to circulate in order to get clean. - Do not press down on items while stacking them in the drum. Adding Cleaning Products Loading the Dispenser To add detergent, bleach, and fabric softener to the automatic dispenser.

Open the detergent dispenser drawer.

Load the laundry products into the appropriate compartments.

• If using a liquid detergent, make sure the liquid detergent cup is in place.

• If using a powdered detergent, remove the liquid detergent cup and put the powder in the main wash detergent compartment.

• If using detergent pods, place the pod in the drum before loading the laundry. Do not place liquid or powdered detergent pods in the dispenser. Pre-washdetergentcompartmentLiquid detergent cup Liquid chlorine bleach compartmentMain wash detergent compartmentLiquid fabric softener compartment

Close the detergent dispenser drawer slowly before starting the cycle.

• Slamming the detergent dispenser drawer may result in the detergent overowing into another compartment or pouring into the tub earlier than programmed. NOTE

• It is normal for a small amount of water to remain in the dispenser compartments at the end of the cycle.20 OPERATION IMPORTANT:

• Do not place or store laundry products, such as detergent, bleach, or liquid fabric softener, on top of your washer or dryer. Wipe up any spills immediately. These products can damage the machine's nish and controls. Pre-Wash Detergent Compartment Add liquid or powdered detergent to this compartment when using the Pre-Wash option. Always use HE (High-Efciency) detergent with your washer.

• When using the Pre-Wash option, liquid detergent for the main wash needs to be loaded in the liquid detergent cup accessory in the main wash dispenser, to prevent it from being dispensed with the pre-wash detergent.

• The amount of detergent added for the Pre-Wash option is 1/2 the amount recommended for the main wash cycle. For example, if the main wash cycle requires one measure of detergent, add 1/2 measure for the Pre-Wash option. Main Wash Detergent Compartment This compartment holds laundry detergent for the main wash cycle. Either powdered or liquid detergent may be used in this compartment. The detergent is added to the load at the beginning of the cycle. Always use HE (High-Efciency) detergent with your washer. NOTE

• Never exceed the manufacturer’s recommendations when adding detergent. Using too much detergent can result in detergent buildup in clothing and the washer.

• Liquid or powdered color-safe bleach may be added to the main wash compartment with detergent of the same type.

• When using liquid detergent, make sure the liquid detergent cup and insert are in place. Do not exceed the maximum ll line.

• When using powdered detergent, remove the insert and liquid detergent cup from the compartment. Powdered detergent will not dispense with the liquid detergent cup and insert in place.

• If you use a detergent that does not dissolve easily or a detergent with high viscosity, it will leave a residue and may clog on the dispenser. Liquid Bleach Compartment This compartment holds liquid bleach, which is dispensed automatically at the proper time during the wash cycle. The dispenser is activated twice to ensure complete dispensing of the bleach. Any liquid remaining in the dispenser at the end of the cycle is water, not bleach.

• Do not add powdered bleach to this compartment. The bleach compartment is designed to dispense liquid chlorine bleach only. Powdered or liquid color- safe bleach will not dispense properly.

• Always follow the manufacturer's recommendations when adding bleach. Never add more than one cup and do not exceed the maximum ll line since this can cause the bleach to be dispensed immediately, resulting in damage to fabrics. Using too much bleach can damage fabrics.

• Never pour undiluted liquid chlorine bleach directly onto the load or into the drum. Fabric damage can occur.

• Do not use color-safe bleach or Oxi products in the same cycle with liquid chlorine bleach. WARNING

• Do NOT mix chlorine bleach with ammonia or acids such as vinegar or rust/scale remover. Mixing chemicals like these can produce a lethal gas, resulting in severe injury or death.21OPERATION ENGLISH Fabric Softener Compartment This compartment holds liquid fabric softener, which is automatically dispensed during the nal rinse cycle. Do not exceed the manufacturer’s recommendations when adding softener. Using too much fabric softener can result in buildup in clothing and the washer. Either powdered or liquid fabric softener may be used.

• Follow the manufacturer’s recommendations when adding fabric softener. Do not exceed the maximum ll line. Using too much fabric softener may stain clothes.

• Dilute concentrated fabric softeners with warm water. Do not exceed the maximum ll line.

• Never pour fabric softener directly onto the load or into the drum. Detergent Use This washer is designed for use with only HE (High- Efciency) detergents. HE detergents produce fewer suds, dissolve more efciently to improve washing and rinsing performance, and help to keep the interior of the washer clean. Using detergent that is not HE may cause oversudsing and unsatisfactory performance which could result in error codes, cycle failure, and machine damage. Designed specially to use only HE (High-Efciency) detergent

• For proper wash performance, always measure detergent using the measuring device provided by the detergent manufacturer. For an average load, use less than half of the recommended maximum. Use less detergent for soft water, light soil, or smaller loads.

• Never use more than the maximum amount of detergent recommended by the manufacturer. Using too much detergent can lead to oversudsing, poor rinsing, detergent buildup in clothing, and residue buildup that can contribute to odors in the machine.

• Use extra care when measuring 2X and 3X concentrated detergents because even a small amount extra can lead to problems.

• Detergents designated as HE-compatible may not provide optimal results.

• Do not use more than one detergent pod in the washer. Using too much detergent may cause oversudsing and unsatisfactory performance. Reduce detergent amount or add an extra rinse if detergent residue is left on fabrics. To add an extra rinse, press the Extra Rinse button.

Liquid detergent Maximum Normal Load Amount Powdered detergent Detergent Pods Place liquid or powdered detergent pods in the drum before loading laundry. Do not place pods in the dispenser.22 OPERATION Control Panel

Control Panel Features Power On/Off Button Press to turn the washer on. Press again to turn the washer off. Pressing the Power button during a cycle will cancel that cycle and any load settings will be lost. The door will unlock after a brief pause. Cycle Selector Knob Turn this knob to select the desired cycle. Once the desired cycle has been selected, the standard presets will be shown in the display. These settings can be adjusted using the cycle modier buttons any time before starting the cycle.

• To protect your clothing, not all settings are available on all cycle selections. Start/Pause Button Press this button to start the selected cycle. If the washer is running, use this button to pause the cycle without losing the current settings.

• If Start/Pause is not pressed within 60 minutes of selecting a cycle, the washer automatically turns off and all cycle settings are lost.

Cycle Modier Buttons Use these buttons to adjust the water temperature, spin speed and soil level settings for the selected cycle. The current settings are shown in the display. Press the button for that option to select other settings. Special Cycle and Option Buttons Press these buttons to select special cycles or additional cycle options. Certain buttons also allow you to activate special functions by pressing and holding the button for three seconds. Time and Status Display The display shows the settings, estimated time remaining, options, and status messages for your washer. When the washer is turned on, the default settings in the display will illuminate.

623OPERATION ENGLISH Time and Status Display Cycle Status Indicator These LEDs illuminates when a cycle is selected to indicate which stages runs. When a cycle is running, the LED for the active stage blinks, and the LEDs for the remaining stages remain steady. Once a stage is complete, the LED turns off. If a cycle is paused, the active stage LED stops blinking. Door Lock Indicator The Door Lock indicator will light up once a cycle has started. The indicator light will stay on until the cycle is paused, stopped or has nished. Control Lock Indicator When the control lock function is activated, the LED lights up. When the control lock function is set, all controls are disabled except for the Power button. Once the control lock function is disabled, the LED turns off. Estimated Time Remaining When a cycle is selected, the default time for that cycle is displayed. This time will change as modiers or options are selected. Once the Start/Pause button is pressed, the washer will measure the size of the load. The estimated time may change once the load size has been measured. If Delay Wash is set, the remaining delay time counts down until the cycle begins. NOTE

• The time shown is only an estimate. This time is based on normal operating conditions. Several external factors (load size, room temperature, incoming water temperature, etc.) can affect the actual time.

424 OPERATION Wash Cycles Wash cycles are designed for the best wash performance for each type of load. Select the cycle that best matches the load contents for maximum wash performance and fabric care. See the Sorting Laundry section for best results, follow the fabric care labels on your garments. For a guide to fabric care symbols, see the Sorting Laundry section. Press the button to select the desired cycle. When you select a wash cycle, the light for the corresponding wash cycle will turn on. NOTE

• Whenever load weights are mentioned, assume 1 lb (0.45 kg) = 1 thick bath towel (dry).

• For information on using LG SmartThinQ applications to save energy, see the SMART FUNCTIONS section. Choosing by Wash Cycle Description Fabric Type Normal Use this cycle to wash all normal items, except delicate fabrics such as wool or silk. NOTE: Pressing the Start/Pause button without selecting a cycle will cause the Normal cycle to begin immediately, using the default settings. Whites This cycle is for washing white items only. (less than 15 lb. (6.8 kg)) Perm.Press Use this cycle to wash wrinkle-free clothes or tablecloths, to minimize wrinkles. Delicates This cycle is for washing lingerie or sheer and lacy clothes which can easily be damaged. Towels Use this cycle for washing towels, shirts, jeans and mixed loads. Load Size Normal If you have a mixed load that is half-size, use the Normal cycle with default settings. For full-size loads, use the Normal cycle with the soil level set to heavy, and add an extra rinse. In both cases, the machine will automatically detect the load size and adjust accordingly. Bedding This cycle is for washing king or queen sized comforters. NOTE: Use the Bedding cycle with a low spin speed when washing waterproof or water-resistant items, to help protect the fabrics’ properties. If your washer does not function properly, manually redistribute the load or put one comforter in at a time. Speed Wash Use the Speed Wash cycle to quickly wash lightly soiled clothing and small loads. For high wash and rinse efciency, wash small loads of 2-3 lightly soiled garments(less than 3 lb. (1.36 kg)). NOTE:Use very little detergent in this cycle. To add an extra rinse, use the Extra Rinse button.25OPERATION ENGLISH Choosing by Wash Cycle Description Convenience Tub Clean Use this cycle to clean the drum of your washer. See the Maintenance section. Speed Wash Use the Speed Wash cycle to quickly wash lightly soiled clothing and small loads. For high wash and rinse efciency, wash small loads of 2-3 lightly soiled garments(less than 3 lb. (1.36 kg)). NOTE:Use very little detergent in this cycle. To add an extra rinse, use the Extra Rinse button. Downloaded If you download a cycle using the function, it will be placed in the Downloaded cycle position. Choose the Downloaded cycle to run the new cycle. NOTE: The default cycle for this position is Small Load, used for normally soiled loads with just a few items. The Small Load cycle is also available for download. Soil Level Normal For tough stains on children's clothes, use the Normal cycle with a hot Wash Temp. setting, plus the Pre Wash option and an Extra Rinse. Heavy Duty This cycle is for washing heavily soiled laundry using more powerful wash motions.26 OPERATION Cycle Guide Cycle Cycle Modiers Temp. Spin Soil Delay Wash Extra Rinse Fresh Care Normal Hot High Heavy Warm Cold Wash Semi Warm Medium Normal Pre Wash Cold Tap Cold Low Light Heavy Duty Hot High Heavy Warm Cold Wash Semi Warm Medium Normal Pre Wash Cold Tap Cold Low Light Bedding Hot Heavy Warm Cold Wash Semi Warm Medium Normal Pre Wash Cold Tap Cold Low Light Whites Hot High Heavy Warm Semi Warm Medium Normal Pre Wash Cold Tap Cold Low Light Tub Clean = available option, = default setting27OPERATION ENGLISH Cycle Cycle Modiers Temp. Spin Soil Delay Wash Extra Rinse Fresh Care Perm.Press Hot High Heavy Warm Cold Wash Semi Warm Medium Normal Pre Wash Cold Tap Cold Low Light Delicates Heavy Warm Cold Wash Semi Warm Medium Normal Pre Wash Cold Tap Cold Low Light Towels Hot High Heavy Warm Cold Wash Semi Warm Medium Normal Pre Wash Cold Tap Cold Low Light Speed Wash Hot High Heavy Warm Cold Wash Semi Warm Medium Normal Cold Tap Cold Low Light Downloaded Default: Small Load Hot High Heavy Warm Cold Wash Semi Warm Medium Normal Pre Wash Cold Tap Cold Low Light = available option, = default setting28 OPERATION Cycle Modier Buttons Each cycle has default settings that are selected automatically. Customize these settings using the cycle modier buttons. Press the button for the desired modier to toggle through the available settings. The washer automatically adjusts the water level for the type and size of wash load for best results and maximum efciency. Due to the high-efciency nature of this product, water levels may be much lower than expected. This is normal and cleaning/rinsing performance will not be compromised. Temp. Temp. selects the wash and rinse temperature combination for the selected cycle. Press the Temp. button until the indicator light for the desired setting is lit. All rinses use tap cold water . Cold rinses use less energy. The actual cold rinse temperature depends on the temperature of the cold water at the faucet.

• Select the water temperature suitable for the type of load you are washing. Follow the garment fabric care labels for best results. Spin Higher spin speeds extract more water from clothes, reducing drying time and saving energy. Press the Spin button until the desired speed is selected. Some fabrics, such as delicates, require a slower spin speed. To protect your clothing, not all spin speeds are available for all cycles.

• The Spin button also activates the Drain+Spin cycle to drain the tub and spin clothes; for example, if you want to remove clothes before the cycle has ended. To use Drain+Spin, press the Power button, then press the Spin button repeatedly to select a spin speed. Press the Start/Pause button to begin. Soil Adjusting the soil level setting will modify the cycle times and/or wash actions. Press the Soil button until the desired soil level is selected.

• This feature needs more time for heavily soiled loads or less time for lightly soiled loads. Signal The washer plays a melody when the wash cycle is nished. The buttons make a sound each time a button is pressed. Use this option to adjust the volume of the melody and button tones.29OPERATION ENGLISH Option Buttons Your washer features several additional cycle options that customize cycles to meet your individual needs. To use these options, select the desired option after selecting the desired cycle. After selecting the desired cycle and settings, press the cycle option button(s) for the option(s) you would like to add. The button will light when that option is selected. If the selected option is not allowed for the selected cycle, the chime will sound twice to alert you and the LED will not illuminate. NOTE

• To protect your garments, not every feature is available with every cycle.

• If the Start/Pause button is not pressed within 60 minutes to start the cycle, the control will shut off and all settings will be lost. Fresh Care Use this function when you won’t be able to unload your clothes immediately after the wash cycle ends. After the cycle ends, the drum will tumble periodically for up to 19 hours to prevent wrinkles.

Press the Start/Pause or Power button at any time to unload laundry. Pre Wash A 15-minute prewash for clothes that are covered in dirt or dust. This feature is suitable for heavily soiled items. Delay Wash Once you have selected the cycle and other settings, press this button to delay the start of the wash cycle. Each press of the button increases the delay time by 1 hour, for up to 19 hours. Once the desired delay time is set, press the Start/Pause button to start the delay time. NOTE

• If the Start/Pause button is not pressed to begin the delay time, the washer will automatically shut off after 60 minutes and all cycle settings will be lost. Add Garments Use this function to add garments or remove foreign objects like coins or keys after the cycle has started.

Press Add Garments. The cycle pauses and the door unlocks.

Open the door, add garments or remove foreign objects, and close the door.

Press the Start/Pause button to start the cycle. The cycle continues automatically. NOTE

• After checking the water level/temperature conditions for safety, the door unlocks once the wash movement has stopped. (Door Lock LED turns off.)

• If the water level is too high, the door will not unlock, and the Add Garments option cannot be used.

• If the temperature in the tub is higher than 113 °F (45 °C), a short warning chime sounds and Add Garments is not allowed for safety.

• Add Garments is disabled during the Tub Clean cycle or while a cycle is in Spin mode for safety.

• To preserve wash performance, wash time may be extended depending on when garments are added to a cycle. WARNING

• Be careful when opening the door as wet laundry may drip or fall out when the door is opened.

• Do not attempt to force the door to open when locked. Doing so could result in damage to the machine, malfunction, or personal injury.30 OPERATION Cold Wash This option saves energy by using cooler water while increasing the wash and rinse times to maintain wash performance. NOTE

• Wash time will increase up to several minutes with the Cold Wash option.

• For best wash results, only wash small loads (less than 8 lb) with the Cold Wash option. Extra Rinse This option will add an extra rinse to the selected cycle. Use this option to help ensure the removal of detergent or bleach residue from fabrics. Liquid fabric softener, if used, is always dispensed in the nal rinse. Pressing the Extra Rinse button twice will add two additional rinses to the cycle. Rinse+Spin Select this cycle to rinse and spin a load separately from a regular cycle. This can be helpful in preventing fresh stains from setting in fabrics. You can change the spin speed by pressing the Spin button.

Press the Power button to turn on the washer.

Press the Start/Pause button to start the cycle. Control Lock Use this option to disable the controls. This feature can prevent children from changing cycles or operating the machine. The feature does not lock the door. Once the Control Lock is set, it must be deactivated before any controls, except the Power button, can be used. Once the washer has shut off, the Power button will allow the machine to be turned on, but the controls will still be locked. When the controls are locked, will display alternately with the estimated time remaining. Locking/Unlocking the Control Panel Press and hold the Control Lock button for 3 seconds. NOTE

• Turning off the power will not reset the Control Lock function. You must deactivate Control Lock before you can access any other functions.

• When Control Lock is turned on, you cannot operate any buttons except the Power button.31SMART FUNCTIONS ENGLISH SMART FUNCTIONS LG SmartThinQ Application The LG SmartThinQ application allows you to communicate with the appliance using a smartphone. Before Using LG SmartThinQ

• For appliances with the or logo

Use a smartphone to check the strength of the wireless router (Wi-Fi network) near the appliance.

• If the distance between the appliance and the wireless router is too far, the signal strength becomes weak. It may take a long time to register or installation may fail.

Turn off the Mobile data or Cellular Data on your smartphone.

Connect your smartphone to the wireless router. NOTE

• To verify the Wi-Fi connection, check that Wi-Fi icon on the control panel is lit.

• The appliance supports 2.4 GHz Wi-Fi networks only. To check your network frequency, contact your Internet service provider or refer to your wireless router manual.

• LG SmartThinQ is not responsible for any network connection problems or any faults, malfunctions, or errors caused by network connection.

• The surrounding wireless environment can make the wireless network service run slowly.

• If the appliance is having trouble connecting to the Wi-Fi network, it may be too far from the router. Purchase a Wi-Fi repeater (range extender) to improve the Wi-Fi signal strength.

• The network connection may not work properly depending on the Internet service provider.

• The Wi-Fi connection may not connect or may be interrupted because of the home network environment.

• If the appliance cannot be registered due to problems with the wireless signal transmission, unplug the appliance and wait about a minute before trying again.

• If the rewall on your wireless router is enabled, disable the rewall or add an exception to it.

• The wireless network name (SSID) should be a combination of English letters and numbers. (Do not use special characters.)

• Smartphone user interface (UI) may vary depending on the mobile operating system (OS) and the manufacturer.

• If the security protocol of the router is set to WEP, network setup may fail. Change the security protocol (WPA2 is recommended), and register the product again. Installing the LG SmartThinQ Application Search for the LG SmartThinQ application from the Google Play Store or Apple App Store on a smart phone. Follow instructions to download and install the application.32 SMART FUNCTIONS LG SmartThinQ Application Features

• For appliances with the or logo Washer Cycle (Remote Start, Downloaded) Set or download any preferred cycle and operate by remote control. Tub Clean Coach This function shows how many cycles remain before it is time to run the Tub Clean cycle. Smart Diagnosis™ This function provides useful information for diagnosing and solving issues with the appliance based on the pattern of use. Energy Monitoring The washer energy usage is affected by the cycles and options so you may see some changes in energy usage from one cycle to another. Push Alerts When the cycle is complete or the appliance has problems, you have the option of receiving push notications on a smart phone. Settings Set the product nickname and delete product. NOTE

• If you change your wireless router, Internet service provider, or password, delete the registered appliance from the LG SmartThinQ application and register it again.

• This information is current at the time of publication. The application is subject to change for product improvement purposes without notice to users. Using Washer Cycle Remote Start Use a smart phone to control the appliance remotely or check to see how much time is left in the cycle. Using Remote Start

Press and hold Remote Start button for 3 seconds to enable the Remote Start function.

Start a cycle from the LG SmartThinQ application on your smart phone. NOTE

• Once the Remote Start mode is enabled, you can start a cycle from the LG SmartThinQ smartphone application. If the cycle is not started, the machine will wait to start the cycle until it is turned off remotely from the application or the Remote Start mode is disabled.

• When Remote Start is turned on, the door is automatically locked. Disabling Remote Start When the Remote Start is activated, press and hold the Remote Start button for 3 seconds. Downloaded Download new and specialized cycles that are not included in the standard cycles on the appliance. Appliances that have been successfully registered can download a variety of specialty cycles specic to the appliance. Only one cycle can be stored on the appliance at a time. Once cycle download is completed in the appliance, the appliance keeps the downloaded cycle until a new cycle is downloaded.33SMART FUNCTIONS ENGLISH Wireless LAN Module Specications Model LCW-007 Frequency Range 2412 - 2462 MHz Output Power (Max) < 30 dBm FCC Notice (For transmitter module contained in this product) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1) This device may not cause harmful interference

2) This device must accept any interference received,

including interference that may cause undesired operation of the device. Any changes or modications in construction of this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC RF Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with a minimum distance of 20 cm (7.8 inches) between the antenna and your body. Users must follow the specic operating instructions for satisfying RF exposure compliance. Industry Canada Statement (For transmitter module contained in this product) This device contains licence-exempt transmitter(s)/ receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:

1) This device may not cause interference.

2) This device must accept any interference,

including interference that may cause undesired operation of the device. IC Radiation Exposure Statement This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 cm (7.8 inches) between the antenna and your body. NOTE

• THE MANUFACTURER IS NOT RESPONSIBLE

COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. Open Source Software Notice Information To obtain the source code under GPL, LGPL, MPL, and other open source licenses, that is contained in this product, please visit http://opensource.lge.com. In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to [e-mail]. This offer is valid for a period of three years after our last shipment of this product. This offer is valid to anyone in receipt of this information.34 SMART FUNCTIONS Smart Diagnosis™ Function Should you experience any problems with the appliance, it has the capability of transmitting data via your telephone to the LG Customer Information Center. NFC or Wi-Fi equipped models can also transmit data to a smartphone using the LG SmartThinQ application. Smart Diagnosis™ through the Customer Information Center

• For appliances with the or logo This method allows you to speak directly to our trained specialists. The specialist records the data transmitted from the appliance and uses it to analyze the issue, providing a fast and effective diagnosis.

When instructed to do so by the call center, place the mouthpiece of the phone close to the Smart Diagnosis™ icon. Do not press any other buttons.

Press and hold Temp. button for three seconds.

Keep the phone in place until the tone transmission has nished.

• For best results, do not move the phone while the tones are being transmitted.

• If the call center agent is not able to get an accurate recording of the data, you may be asked to try again.

Once the countdown is over and the tones have stopped, resume your conversation with the call center agent, who will then be able to assist you using the information transmitted for analysis. NOTE

• Smart Diagnosis™ cannot be activated unless the appliance can be turned on using the Power button. If the appliance cannot be turned on, troubleshooting must be done without using Smart Diagnosis™.

• For best results, do not move the phone while the tones are being transmitted.

• If the call center agent is not able to get an accurate recording of the data, you may be asked to try again.

• The Smart Diagnosis™ function depends on the local call quality.

• Bad call quality may result in poor data transmission from your phone to the call center, which could cause Smart Diagnosis™ to malfunction. LG SmartThinQ Smart Diagnosis™

• For appliances with the or logo Use the Smart Diagnosis feature in the LG SmartThinQ application for help diagnosing issues with the appliance without the assistance of the LG Customer Information Center. Follow the instructions in the LG SmartThinQ application to perform a Smart Diagnosis using your smartphone. NOTE

• Smart Diagnosis™ cannot be activated unless the appliance can be turned on using the Power button. If the appliance cannot be turned on, troubleshooting must be done without using Smart Diagnosis™.35MAINTENANCE ENGLISH MAINTENANCE WARNING To reduce the risk of re, electric shock, or injury to persons, read this entire owner's manual, including the Important Safety Instructions, before operating this washer.
• Unplug the washer before cleaning to avoid the risk of electric shock. Failure to follow this warning can cause serious injury, re, electric shock, or death.
• Do not use volatile substances (benzene, paint thinner, alcohol, acetone, etc.), abrasive cleaners, or detergents with strong chemical components when cleaning the washer. Doing so may cause discoloration or damage to the machine, or may cause a re.
• Certain internal parts are intentionally not grounded and may present a risk of electric shock only during servicing. Service personnel - Do not contact the following parts while the appliance is energized: pump, valve, motor, control board. Regular Cleaning Care After Wash After the cycle is nished, wipe the door and the inside of the door seal to remove any moisture. • Leave the door open to dry the drum interior. • Wipe the body of the washer with a dry cloth to remove any moisture. Cleaning the Exterior Proper care of your washer can extend its life. Door: Wash with a damp cloth on the outside and inside and then dry with a soft cloth. Exterior:
• Immediately wipe off any spills. • Wipe with a damp cloth. • Do not touch the surface or the display with sharp objects. Care and Cleaning of the Interior
• Use a towel or soft cloth to wipe around the washer door opening and door glass. • Always remove items from the washer as soon as the cycle is complete. Leaving damp items in the washer can cause wrinkling, color transfer, and odor. • Run the Tub Clean cycle once a month, or more often if needed, to remove detergent buildup and other residue. Cleaning the Drum Over time, residue may build up in the drum, leading to mildew or a musty odor. Run the Tub Clean cycle monthly to remove residue and prevent odor. Run the cycle more often under heavy use conditions or if odor is already present. Remove any clothing from the drum. Add cleaning agents.Cleaner InstructionsDrum cleaner Add to main detergent compartment of detergent dispenserLime scale removerLiquid chlorine bleachAdd to bleach compartment of detergent dispenserPowdered cleanerPull out liquid detergent cup before adding to main detergent compartmentCleaning tablets Place directly into washer drum • For other drum cleaning products, follow the cleaner manufacturer’s instructions and recommendations. • Do not exceed the maximum ll line when adding bleach or powdered cleaners. Powdered detergent may remain in the drum after cleaning. Close the door and press the Power button to turn the washer on.36 MAINTENANCE

Turn the cycle selector to select the Tub Clean cycle.

Press the Start/Pause button to begin the cycle. Selecting any other cycle after Tub Clean has been selected will cause the Tub Clean cycle to be cancelled.

After the cycle ends, open the door and allow the drum interior to dry completely. NOTE

• Never load laundry while using Tub Clean. The laundry may be damaged or contaminated with cleaning products. Make sure to run the Tub Clean cycle only when the drum is empty.

• Leave the door open after nishing the laundry, to keep the drum clean.

• Tub Clean should be repeated monthly.

• If mildew or musty smell already exists, run Tub Clean once a week for three consecutive weeks. Automatic Alert for Tub Clean When the power is on and the message blinks on the display, it means the washer drum needs cleaning. Use the Tub Clean cycle to clean the washer drum. The frequency of the automatic alert's appearance depends on how often the washer is used, however the message will generally appear every one to two months. Removing Mineral Buildup In areas with hard water, mineral scale can form on internal components of the washer. Periodically clean the mineral buildup on the internal components to extend the lifespan of the washer. Use of a water softener is recommended in areas with hard water.

• Use a descaler to remove visible mineral buildup on the washer drum. After descaling, always run the Tub Clean cycle before washing clothing.

• Mineral scale and other spots may be removed from the stainless steel drum using a soft cloth soaked in stainless steel cleaner.

• Do not use steel wool or abrasive cleaners. NOTE

• If you use a descaler or tub cleaner during the Tub Clean cycle, use the Rinse+Spin cycle to rinse the washer drum before running your next wash cycle. Cleaning the Detergent Dispenser Drawer Leaving detergent in the detergent dispenser drawer for an extended period of time or using the washing machine for a long period of time may cause the build-up of scales in the detergent dispenser drawer. Pull out and clean the detergent dispenser drawer once a week.

Slide the detergent dispenser drawer out as far as it will go.

Press down hard on the disengage button and pull out the detergent dispenser drawer.

Remove the inserts from the drawer.

Clean the inserts with warm water.

• Use a soft cloth or brush to remove any residue.

• Use water only when cleaning the drawer and inserts.37MAINTENANCE ENGLISH

Wipe off any moisture with a dry towel or cloth after cleaning.

• Do not spray water inside the cabinet. Doing so may cause re or electric shock. Cleaning the Door Seal Clean the door seal once a month to prevent build-up of dirt.

Wear rubber gloves and protective goggles.

Dilute 3/4 cup (177 ml) of liquid chlorine bleach in 1 gallon (3.8 L) of water.

Wipe around the door seal. Soak a sponge or a soft cloth in this diluted solution and wipe all around the door seal.

Wipe dry. After cleaning, wipe up any moisture with a dry towel or cloth.

Leave the door open to allow the door seal to dry completely. CAUTION

• Cleaning the door seal with undiluted bleach may cause malfunction of the door seal and washer parts. You must add water to the bleach before using it. Cleaning the Water Inlet Filters If the washer does not ll properly, an error message will show on the display. The inlet valve lter screens could be plugged by hard water scale, sediment in the water supply, or other debris. CAUTION

• The inlet screens protect the delicate parts of the inlet valve from being damaged by particles that could enter the valves with the water supply. Operating the washer with these lters removed could cause a valve to stick open resulting in ooding and/or property damage

• If you use the washer in an area with hard water, the inlet lter may clog due to lime buildup.

Turn off both water faucets completely.

Unscrew the hot and cold water hoses from the back of the washer.

Carefully remove the lters from the water valves.

Remove foreign objects and soak the lters in white vinegar or a lime scale remover. If using a lime scale remover, follow the manufacturer’s instructions. Be careful not to damage the lters while cleaning them.

Rinse lters thoroughly and press them back into place.

Flush then reattach the water hoses. Before reattaching the hoses, ush the hoses and water lines by running several gallons of water into a bucket or drain, preferably with the faucets wide open for maximum ow. NOTE

• An message may blink on the display when the water pressure is weak or an inlet lter is clogged with dirt. Clean the inlet lter.38 MAINTENANCE Cleaning the Drain Pump Filter The washer fails to drain if the drain pump lter is clogged. Periodically clean the drain lter to prevent clogging with foreign objects. WARNING

• Opening the drain lter will result in water overowing if there is water in the washer drum. Use a bucket if the drum is not completely drained before you open the drain lter.

• Using the washer without the drain lter or with an incorrectly assembled drain lter may cause leaks or malfunctioning of the washer.

Turn off the machine and unplug it.

Open the drain pump lter cover.

Drain any remaining water. Unclip the drain hose and remove the plug from the drain hose to drain the remaining water.

Remove the pump lter. Twist the pump lter counterclockwise to remove.

Clean the pump lter and opening.

Recap the plug onto the drain hose and attach the drain hose.

Insert the drain pump lter.

Close the drain pump lter cover. NOTE

• An message blinks on the display when the drain pump lter is clogged with dirt. Clean the drain pump lter.39MAINTENANCE ENGLISH Care in Cold Climates Storing the Washer If the washer will not be used for an extended period of time and is in an area that could be exposed to freezing temperatures, perform the following steps to protect the washer from damage.

Turn off the water supply.

Disconnect the hoses from the water supply and drain any water from the hoses.

Plug the power cord into a properly grounded electrical outlet.

Add 1 gallon of nontoxic recreational vehicle (RV) antifreeze to the empty drum and close the door. Never use automotive antifreeze.

Press the Start/Pause button to start the drain pump.

Allow the drain pump to run for one minute, then press the Power button to shut off the washer. This will expel some of the antifreeze, leaving enough to protect the washer from damage.

Unplug the power cord, dry the drum interior with a soft cloth, and close the door.

Remove the inserts from the dispenser. Drain any water in the compartments and let them dry.

Store the washer in an upright position.

To remove the antifreeze from the washer after storage, run a complete Speed Wash cycle using detergent.

• Do not add laundry to this cycle. When the Water Line is Frozen

Turn off the faucets connected to the water lines.

Pour hot water on the frozen faucets to thaw the water lines and remove them.

Immerse the water lines in hot water to thaw them.

Connect the water lines with the water inlets of the washer and with the faucets. See Connecting the Water Lines for details.

Turn on the faucets.

Press the Start/Pause button. Verify the water lls properly. When the Drain Line is Frozen

Pour hot water in the washer drum and close the lid. Wait for 1-2 hours.

Press the Power button after thawing.

Press the Spin button to select draining and spinning.

Press the Start/Pause button. Check to make sure the water drains.40 TROUBLESHOOTING TROUBLESHOOTING FAQs: Frequently Asked Questions Q: Why does my washer make loud banging noises while it is lling with water? A: This is actually a problem with the plumbing in your home. When the water valve in the washer shuts off, it can cause pipes in your home to move, resulting in a loud banging noise. This effect, called water hammer, can be reduced by installing an item called a water hammer arrestor. Add-on arrestors can be purchased through your local hardware or home improvement store. Q: Why is there so little water in my washer? How can it clean the clothes? A: HE (High-Efciency) washers are designed to properly wash your laundry while using a minimum amount of water and energy. Because the water volume is low, the small amount of detergent used is more concentrated in the water, resulting in excellent cleaning performance. Q: When I press a button, why does my washer beep and then nothing happens? A: • The Control Lock feature is turned on. To turn off Control Lock, turn the washer on, then press and hold the button that has "*Control Lock" on or under it for three seconds.

• Power or Signal is off. Q: Where should I pour powdered laundry products when doing my laundry? A: If you are using powdered laundry detergent, load it in the main detergent dispenser after removing the liquid detergent insert. Powdered laundry agents or powdered color safe bleach should be put directly into the tub. These products can be put in the empty tub before loading or on top of the laundry after loading the machine.41TROUBLESHOOTING ENGLISH Before Calling for Service The washer is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If the washer does not function properly or does not function at all, check the following before you call for service. Noises You Might Hear Noise Possible Cause Solutions Spraying or Hissing Water spraying or circulating during the cycle.

• Normal Operation Humming or Gurgling Drain pump is pumping water from the washer at times during a cycle.

• Normal Operation Water sloshing A liquid in the balance ring around the wash basket helps the basket spin smoothly.

• Normal Operation Water being added after the washer has already begun to operate The washer adapts to the load size and type to add more water to the cycle as needed.

• Normal Operation The wash load may be unbalanced. If the washer senses that the load is unbalanced, it will stop and rell to redistribute the load. The washer may be diluting laundry additives to add to the wash load. Rattling and clanking noise Foreign objects, such as keys, coins, or safety pins may be in drum or pump.

• Stop washer, check drum and drain lter for foreign objects. If noise continues after washer is restarted, call for service. Thumping sound Heavy wash loads may produce a thumping sound.

• This is normal. If sound continues, washer is probably out of balance. Stop and redistribute wash load. Wash load may be out of balance. • Pause the cycle and redistribute the load. Vibrating noise Packaging materials were not removed.

• See the Unpacking and Removing Shipping Bolts information in the Installation section. Wash load may be unevenly distributed in the drum.

• Pause the cycle and redistribute the load. Not all leveling feet are resting rmly and evenly on the oor.

• See Leveling the Washer in the Installation section. Floor not rigid enough.

• Make sure that the oor is solid and does not ex. See the Flooring in the Installation section. Squeaking noise Packaging materials were not removed.

• See the Unpacking and Removing Shipping Bolts information in the Installation section. Banging noise when washer is lling with water (Water Hammer) Plumbing in the home moves or exes when the water valves in the washer shut off.

• Water hammer is not caused by a defect in the washer. Install water hammer arrestors (purchased separately at hardware or home improvement store) between the ll hose and the washer for best results. Household water supply pressure is very high.

• Adjust household water supply regulator to a lower pressure or contact a plumber.42 TROUBLESHOOTING Operation Problem Possible Cause Solutions Water leaking Inlet hose connection is loose at faucet or washer.

• Check hoses for leaks, cracks and splits.

• Check and tighten hose connections. House drain pipes are clogged.

• The washer pumps out water very rapidly. Check for water backing up out of the drain pipe during drain. If water is seen coming out of the drain, check for proper drain hose installation and check for restrictions in the drain. Contact a plumber to repair drain pipe. Drain hose has come out of drain or is not inserted far enough.

• Tie drain hose to inlet hose or standpipe to prevent it from coming out during drain. For smaller drain pipes, insert the drain hose into the pipe as far as the drain hose ange. For larger drain pipes, insert the drain hose into the pipe 1-2 inches past the ange. A large item such as a pillow or blanket is above the top of the drum.

• Use the Bedding cycle for large or bulky items. Use extra care and never wash more than half a load of items that oat, such as pillows.

• Stop the washer and check the load. Make sure the load does not crest above the top edge of the drum. Oversudsing of detergent.

• Oversudsing may create leaks, and may be caused by the type and amount of detergent used. High-Efciency detergent is the only detergent recommended. The normal amount of detergent to use is 1/4 to 1/2 of the maximum amount recommended by the detergent manufacturer. Water leaks every load Hoses not installed correctly.

• See Connecting the Water Lines to reinstall hoses. Replace damaged hoses. Washer will not drain water Kinked drain hose. • Ensure that the drain hose is not kinked. Drain located unproperly.

• Make sure that the drain hose is no more than 5 ft. (1.5 m) away from the washer. Excessive sudsing Too much detergent or incorrect detergent.

• HE detergents are formulated specically for High-Efciency washers and contain suds- reducing agents. Only use detergent with the High-Efciency (HE) logo. Washer will not turn on Power cord is not properly plugged in.

• Make sure that the plug is plugged securely into a grounded, 3-prong, 120 VAC, 60 Hz outlet. House fuse is blown, circuit breaker has tripped, or power outage has occurred.

• Reset circuit breaker or replace fuse. Do not increase fuse capacity. If the problem is a circuit overload, have it corrected by a qualied electrician.43TROUBLESHOOTING ENGLISH Problem Possible Cause Solutions Wash cycle time is longer than usual The washer automatically adjusts the wash time for the amount of laundry, water pressure and other operating conditions.

• This is normal. The washer adjusts cycle time automatically to provide optimal results for the selected cycle. The time remaining shown in the display is only an estimate. Actual time may vary. Bleach does not dispense Bleach dispenser cover is not properly installed.

• Make sure that the bleach cover is properly installed and snapped into place before the beginning of the cycle. Bleach dispenser is dirty or clogged.

• Lift out the bleach dispenser cover and clean out the reservoir. Lint and other foreign debris that collects inside the dispenser may prevent proper dispensing of the bleach. Premature dispensing of bleach Bleach dispenser lled for future load.

• You cannot store bleach in the dispenser for future use. The bleach will be dispensed every load. Incomplete or no dispensing of detergent Detergent compartments clogged from incorrect lling.

• Make sure that detergent and additives are put into the correct dispenser compartments. For all detergent types, always make sure that the dispenser drawer is fully closed before the start of the cycle. Too much detergent used.

• Make sure that the suggested amount of detergent is used per the manufacturer’s recommendations. You may also dilute the detergent with water to the maximum ll line on the compartment to avoid clogging. Use only HE (High-Efciency) detergent.

• NOTE: Always use as little detergent as possible. High-Efciency washers need very little detergent to achieve optimum results. Using too much detergent will cause poor wash and rinse performance and may contribute to odors in washer. Insufcient water supply.

• Make sure that both hot and cold water faucets are turned on all the way. Normal residue.

• It is normal for a small amount of detergent to remain in the dispenser. If this residue builds up it can interfere with normal dispensing of products. Refer to the cleaning instructions. Washer will not operate Control panel has powered off due to inactivity.

• This is normal. Press the Power button to turn the washer on. Washer is unplugged.

• Make sure cord is plugged securely into a working outlet. Water supply is turned off. • Turn both hot and cold faucets fully on. Controls are not set properly.

• Make sure the cycle was set correctly, close the lid and press the Start/Pause button.44 TROUBLESHOOTING Problem Possible Cause Solutions Washer will not operate Lid is open.

• The washer will not operate if the lid is open. Close the lid and make sure that nothing is caught under the lid preventing it from closing completely. Circuit breaker/fuse is tripped/ blown.

• Check house circuit breakers/fuses. Replace fuses or reset breaker. The washer should be on a dedicated branch circuit. Control needs to be reset.

• Press the Power button, then re-select the desired cycle and press the Start/Pause button. Start/Pause was not pressed after a cycle was set.

• Press the Power button then re-select the desired cycle and press the Start/Pause button. The washer will shut off if the Start/ Pause button is not pressed within 60 minutes. Extremely low water pressure.

• Check another faucet in the house to make sure that household water pressure is adequate. Washer is too cold.

• If the washer has been exposed to temperatures below freezing for an extended period of time, allow it to warm up before pressing the Power button.

• Otherwise, the display will not come on. Washer not lling properly Filter clogged.

• Make sure the inlet lters on the ll valves are not clogged. Refer to the lter cleaning instructions. Inlet hoses may be kinked.

• Check that inlet hoses are not kinked or clogged. Energy efciency.

• This is an High-Efciency (HE) washer. As a result, the water level settings for this washer may be different than for conventional washers. Insufcient water supply.

• Make sure that both hot and cold water faucets are turned on all the way. The washer lid is open.

• The washer will not operate if the lid is open. Close the lid and make sure that nothing is caught under the lid preventing it from closing completely. Water level is too low/ No water is visible in the drum Energy efciency

• This is an High-Efciency (HE) washer. As a result, the water level settings for this washer may be different than on your previous washer. The water will not normally cover the clothes. The ll level is optimized for the wash motion to achieve the best wash performance.45TROUBLESHOOTING ENGLISH Performance Problem Possible Cause Solutions Wrinkling Washer not unloaded promptly.

• Always remove items from the washer as soon as the cycle is complete. Washer overloaded.

• The washer can be fully loaded, but the drum should not be tightly packed with items. The lid of the washer should close easily. Hot and cold water inlet hoses are reversed.

• Hot water rinse can set wrinkles in garments. Check the inlet hose connections. Staining Bleach or softener dispensed too soon.

• Dispenser compartment is overlled causing bleach or softener to dispense immediately. Always measure bleach to prevent overlling - one cup maximum. Dispenser drawer closed too quickly causing softener to dispense immediately. Bleach or softener was added directly to the wash load in the drum.

• Always use the dispensers to ensure that laundry products are properly dispensed at the right time in the cycle. Washer was not unloaded promptly.

• Always remove items from the washer as soon as possible after the cycle is complete. Clothes were not properly sorted.

• Always wash dark colors separately from light colors and whites to prevent discoloration. Never wash heavily soiled items with lightly soiled items. Poor stain removal Proper options not selected.

• Heavier soils and tougher stains may require extra cleaning power. Select the Heavy feature to boost the cleaning power of the selected cycle. Previously set stains.

• Articles that have previously been washed may have stains that have been set. These stains may be difcult to remove and may require hand washing or pre-treating to aid in stain removal. Odor Some odor is caused by the rubber attached to the washing machine.

• This odor is normal for new rubber and will disappear after the machine has been run a few times. If the rubber door gasket and door seal area are not cleaned regularly, odors can occur from mold or foreign substances.

• Be sure to clean the gasket and door seal regularly and check under the door seal for small items when unloading the washer. Odors can occur if foreign substances are left in the drainage pump lter.

• Be sure to clean the drainage pump lter regularly.46 TROUBLESHOOTING Problem Possible Cause Solutions Odor Odors can occur if the drainage hose is not properly installed, causing siphoning (water owing back inside the washing machine).

• When installing the drainage hose, be sure that it doesn’t become kinked or blocked. Using the dry function, odors can occur from lint and other laundry matter sticking to the heater. (Dryer model only)

• This is not a malfunction. A particular odor can occur from drying wet clothes with hot air. (Dryer model only)

• The odor will disappear after a short while. Wi-Fi Problem Possible Cause Solutions Trouble connecting appliance and smartphone to Wi-Fi network The password for the Wi-Fi network was entered incorrectly.

• Delete your home Wi-Fi network and begin the registration process again. Mobile data for your smartphone is turned on.

• Turn off the Mobile data on your smartphone before registering the appliance. The wireless network name (SSID) is set incorrectly.

• The wireless network name (SSID) should be a combination of English letters and numbers. (Do not use special characters.) The router frequency is not 2.4 GHz.

• Only a 2.4 GHz router frequency is supported. Set the wireless router to 2.4 GHz and connect the appliance to the wireless router. To check the router frequency, check with your Internet service provider or the router manufacturer. The distance between the appliance and the router is too far.

• If the appliance is too far from the router, the signal may be weak and the connection may not be congured correctly. Move the router closer to the appliance or purchase and install a Wi-Fi repeater.47TROUBLESHOOTING ENGLISH Error Codes Problem Possible Cause Solutions Washer lls with water slowly or not at all, or Water supply faucets are not fully open.

• Make sure that the water faucets are fully open. Water line hoses are kinked, pinched, or crushed.

• Make sure that the hoses are not kinked or pinched. Be careful when moving the washer during cleaning and maintenance. Water inlet lters are clogged.

• Clean the inlet lters. See the Maintenance section. Water supply pressure to faucet or house is too low.

• Check another faucet in the house to make sure that household water pressure is adequate and ow is not restricted. Disconnect the inlet hose from the washer and run a few gallons of water through the hose to ush the water supply lines. If ow is too low, contact a plumber to have the water lines repaired. Water supply connected with leaklimiting hoses.

• Hoses designed to limit leaks can trip falsely and prevent the washer from lling. The use of leaklimiting hoses is not recommended. If the balance is not successful, this error will be displayed.

• The automatic attempt to rebalance the load was not successful. The cycle has been paused to allow the load to be manually adjusted. The load is too small.

• Small loads may need additional items to be added to allow the washer to balance the loads. Heavy articles are mixed with lighter items.

• The load may have heavy items loaded with lighter items. Always try to wash articles of somewhat similar weight to allow the washer to evenly distribute the weight of the load for spinning. The load is out of balance.

• Manually redistribute the load if articles have become tangled, preventing the automatic distribution from working properly. The load contains pillows or cushions.

• Wash the covers only. Remove the stufng from the pillows or cushions before washing the covers. The tub does not rotate

The door is not secured.

• Close and secure the door. If the message keeps appearing, unplug the power cord and call for service.48 TROUBLESHOOTING Problem Possible Cause Solutions Water in the washer drains slowly or not at all and Drain hose is kinked, pinched, or clogged

• Make sure the drain hose is free of clogs or kinks, and is not pinched behind or under the washer. Drain discharge is more than 96 inches (2.4 m) above bottom of washer.

• The end of the drain hose should be no more than 96 inches (2.4 m) above the bottom of the washer. Control error.

• Unplug the washer and wait 60 seconds. Reconnect power and try again. If the error reappears, call for service. Water level is too high due to a faulty water valve.

• Close the water faucets, unplug the washer, and call for service. The water level sensor is not working correctly.

• Close the water faucets, unplug the washer, and call for service. A motor error has occurred.

• Allow the washer to stand for 30 minutes and then restart the cycle. If the LE error code persists, call for service. If the washing machine detects too many suds, it displays this error code and adds a Suds Reducing cycle. This adds about 2 hours to the cycle time. If too many suds are detected during spinning, the washing machine stops to help prevent leaking.

• Do not add more than the manufacturer's recommended amount of detergent. The water level too low or high compared to the size of the load.

• The water level sensor ir not working correctly. Unplug the power cord and call for service. Inlet hose, drain hose or drain pump frozen.

• See the Care in Cold Climates section for instructions. Control Lock is activated.

• This is not an error code. This code indicates that the Control Lock is activated. Press and hold Control Lock for 3 seconds. Tub Clean is activated or the washer drum needs cleaning.

• This is not an error code. This code indicates that the Tub Clean is activated or needed. Use the Tub Clean cycle to clean the washer drum.49LIMITED WARRANTY ENGLISH LIMITED WARRANTY FOR USA ARBITRATION NOTICE: THIS LIMITED WARRANTY CONTAINS AN ARBITRATION PROVISION THAT REQUIRES YOU AND LG TO RESOLVE DISPUTES BY BINDING ARBITRATION INSTEAD OF IN COURT, UNLESS YOU CHOOSE TO OPT OUT. IN ARBITRATION, CLASS ACTIONS AND JURY TRIALS ARE NOT PERMITTED. PLEASE SEE THE SECTION TITLED “PROCEDURE FOR RESOLVING DISPUTES” BELOW. Should your LG Washer fail due to a defect in materials or workmanship under normal home use, during the warranty period set forth below, LG will at its option repair or replace the product. This limited warranty is valid only to the original retail purchaser of the product and applies only when purchased and used within the United States, including U.S. Territories. Proof of original retail purchase is required to obtain warranty service under this limited warranty. Warranty Period Scope of Warranty Remark One (1) year from date of original retail purchase Any internal /functional Parts and Labor LG will provide parts and labor to repair or replace defective parts. Three (3) years from date of original retail purchase Stainless Steel Drum Parts only. Customer will be responsible for any labor or in-home service to replace defective parts. Ten (10) years from date of original retail purchase DD Motor (Stator, Rotor, Hall Sensor)

• Replacement products and parts are warranted for the remaining portion of the original warranty period or ninety (90) days, whichever is greater.

• Replacement products and parts may be new or remanufactured. THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TO THE EXTENT ANY IMPLIED WARRANTY IS REQUIRED BY LAW, IT IS LIMITED IN DURATION TO THE EXPRESS WARRANTY PERIOD ABOVE. NEITHER THE MANUFACTURER NOR ITS U.S. DISTRIBUTOR SHALL BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY NATURE, INCLUDING WITHOUT LIMITATION, LOST REVENUES OR PROFITS, OR ANY OTHER DAMAGE WHETHER BASED IN CONTRACT, TORT, OR OTHERWISE. Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long an implied warranty lasts, so the above exclusion or limitation may not apply to you. This warranty gives you specic legal rights and you may also have other rights that vary from state to state. THIS LIMITED WARRANTY DOES NOT COVER:

• Service trips to deliver, pick up, or install or repair the product; instruction to the customer on operation of the product; repair or replacement of fuses or correction of wiring or plumbing, or correction of unauthorized repairs/installation.

• Failure of the product to perform during power failures and interrupted or inadequate electrical service.

• Damage caused by leaky or broken water pipes, frozen water pipes, restricted drain lines, inadequate or interrupted water supply or inadequate supply of air.

• Damage resulting from operating the product in a corrosive atmosphere or contrary to the instructions outlined in the product’s owner’s manual.

• Damage to the product caused by accidents, pests and vermin, lightning, wind, re, oods, or acts of God.

• Damage or failure caused by unauthorized modication or alteration, or if it is used for other than the intended purpose, or any water leakage where the unit was not properly installed.50 LIMITED WARRANTY

• Damage or failure caused by incorrect electrical current, voltage, or plumbing codes, commercial or industrial use, or use of accessories, components, or consumable cleaning products that are not approved by LG.

• Damage caused by transportation and handling, including scratches, dents, chips, and/or other damage to the nish of your product, unless such damage results from defects in materials or workmanship and is reported within one (1) week of delivery.

• Damage or missing items to any display, open box, discounted, or refurbished product.

• Products with original serial numbers that have been removed, altered, or cannot be readily determined. Model and serial numbers, along with original retail sales receipts, are required for warranty validation.

• Increases in utility costs and additional utility expenses.

• Repairs when your product is used for other than normal and usual household use (e.g. commercial use, in ofces and recreational facilities) or contrary to the instructions outlined in the product’s owner’s manual.

• Costs associated with removal of your product from your home for repairs.

• The removal and reinstallation of the product if it is installed in an inaccessible location or is not installed in accordance with published installation instructions, including LG’s owner’s and installation manuals.

• Damage resulting from misuse, abuse, improper installation, repair, or maintenance. Improper repair includes use of parts not approved or specied by LG. The cost of repair or replacement under these excluded circumstances shall be borne by the consumer. TO OBTAIN WARRANTY SERVICE AND ADDITIONAL INFORMATION For additional product information, visit the LG website at http://www.lg.com For assistance using this product or to schedule service, contact LG Electronics at 1-800-243-0000. For further assistance, write: LG Electronics, 201 James Record Road, Huntsville, Alabama 35813 PROCEDURE FOR RESOLVING DISPUTES: ALL DISPUTES BETWEEN YOU AND LG ARISING OUT OF OR RELATING IN ANY WAY TO THIS LIMITED WARRANTY OR THE PRODUCT SHALL BE RESOLVED EXCLUSIVELY THROUGH BINDING ARBITRATION, AND NOT IN A COURT OF GENERAL JURISDICTION. BINDING ARBITRATION MEANS THAT YOU AND LG ARE EACH WAIVING THE RIGHT TO A JURY TRIAL AND TO BRING OR PARTICIPATE IN A CLASS ACTION. Denitions. For the purposes of this section, references to “LG” mean LG Electronics U.S.A., Inc., its parents, subsidiaries and afliates, and each of their ofcers, directors, employees, agents, beneciaries, predecessors in interest, successors, assigns and suppliers; references to “dispute” or “claim” shall include any dispute, claim or controversy of any kind whatsoever (whether based in contract, tort, statute, regulation, ordinance, fraud, misrepresentation or any other legal or equitable theory) arising out of or relating in any way to the sale, condition or performance of the product or this Limited Warranty. Notice of Dispute. In the event you intend to commence an arbitration proceeding, you must rst notify LG in writing at least 30 days in advance of initiating the arbitration by sending a letter to LG at LG Electronics, USA, Inc. Attn: Legal Department- Arbitration 1000 Sylvan Ave, Englewood Cliffs 07632. You and LG agree to engage in good faith discussions in an attempt to amicably resolve your claim. The notice must provide your name, address, and telephone number; identify the product that is the subject of the claim; and describe the nature of the claim and the relief being sought. If you and LG are unable to resolve the dispute within 30 days, either party may proceed to le a claim for arbitration.51LIMITED WARRANTY ENGLISH Agreement to Binding Arbitration and Class Action Waiver. Upon failure to resolve the dispute during the 30 day period after sending written notice to LG, you and LG agree to resolve any claims between us only by binding arbitration on an individual basis, unless you opt out as provided below. Any dispute between you and LG shall not be combined or consolidated with a dispute involving any other person’s or entity’s product or claim. More specically, without limitation of the foregoing, any dispute between you and LG shall not under any circumstances proceed as part of a class or representative action. Instead of arbitration, either party may bring an individual action in small claims court, but that small claims court action may not be brought on a class or representative basis. Arbitration Rules and Procedures. To begin arbitration of a claim, either you or LG must make a written demand for arbitration. The arbitration will be administered by the American Arbitration Association (“AAA”) and will be conducted before a single arbitrator under the AAA’s Consumer Arbitration Rules that are in effect at the time the arbitration is initiated (referred to as the “AAA Rules”) and under the procedures set forth in this section. The AAA Rules are available online at www.adr.org/consumer. Send a copy of your written demand for arbitration, as well as a copy of this provision, to the AAA in the manner described in the AAA Rules. You must also send a copy of your written demand to LG at LG Electronics, USA, Inc. Attn: Legal Department- Arbitration 1000 Sylvan Avenue Englewood Cliffs, NJ 07632. If there is a conict between the AAA Rules and the rules set forth in this section, the rules set forth in this section will govern. This arbitration provision is governed by the Federal Arbitration Act. Judgment may be entered on the arbitrator’s award in any court of competent jurisdiction. All issues are for the arbitrator to decide, except that issues relating to the scope and enforceability of the arbitration provision and to the arbitrability of the dispute are for the court to decide. The arbitrator is bound by the terms of this provision. Governing Law. The law of the state of your residence shall govern this Limited Warranty and any disputes between us except to the extent that such law is preempted by or inconsistent with applicable federal law. Fees/Costs. You do not need to pay any fee to begin an arbitration. Upon receipt of your written demand for arbitration, LG will promptly pay all arbitration ling fees to the AAA unless you seek more than $25,000 in damages, in which case the payment of these fees will be governed by the AAA Rules. Except as otherwise provided for herein, LG will pay all AAA ling, administration and arbitrator fees for any arbitration initiated in accordance with the AAA Rules and this arbitration provision. If you prevail in the arbitration, LG will pay your attorneys’ fees and expenses as long as they are reasonable, by considering factors including, but not limited to, the purchase amount and claim amount. Notwithstanding the foregoing, if applicable law allows for an award of reasonable attorneys’ fees and expenses, an arbitrator can award them to the same extent that a court would. If the arbitrator nds either the substance of your claim or the relief sought in the demand is frivolous or brought for an improper purpose (as measured by the standards set forth in Federal Rule of Civil Procedure 11(b)), then the payment of all arbitration fees will be governed by the AAA Rules. In such a situation, you agree to reimburse LG for all monies previously disbursed by it that are otherwise your obligation to pay under the AAA Rules. Except as otherwise provided for, LG waives any rights it may have to seek attorneys’ fees and expenses from you if LG prevails in the arbitration. Hearings and Location. If your claim is for $25,000 or less, you may choose to have the arbitration conducted solely on the basis of (1) documents submitted to the arbitrator, (2) through a telephonic hearing, or (3) by an in-person hearing as established by the AAA Rules. If your claim exceeds $25,000, the right to a hearing will be determined by the AAA Rules. Any in-person arbitration hearings will be held at a location within the federal judicial district in which you reside unless we both agree to another location or we agree to a telephonic arbitration. Opt Out. You may opt out of this dispute resolution procedure. If you opt out, neither you nor LG can require the other to participate in an arbitration proceeding. To opt out, you must send notice to LG no later than 30 calendar days from the date of the rst consumer purchaser’s purchase of the product by either: (i) sending an e-mail to [e-mail], with the subject line: “Arbitration Opt Out” or (ii) calling 1-800-980-2973. You must include in the opt out e-mail or provide by telephone: (a) your name and address; (b) the date on which the product was purchased; (c) the product model name or model number; and (d) the serial number (the serial number can be found (i) on the product; or (ii) online by accessing https://www.lg.com/us/support/repair-service/schedule-repair- continued and clicking on “Find My Model & Serial Number”). You may only opt out of the dispute resolution procedure in the manner described above (that is, by e-mail or telephone); no other form of notice will be effective to opt out of this dispute resolution procedure. Opting out of this dispute resolution procedure will not affect the coverage of the Limited Warranty in any way, and you will continue to enjoy the full benets of the Limited Warranty. If you keep this product and do not opt out, then you accept all terms and conditions of the arbitration provision described above.52 LIMITED WARRANTY LIMITED WARRANTY FOR CANADA ARBITRATION NOTICE: THIS LIMITED WARRANTY CONTAINS AN ARBITRATION PROVISION THAT REQUIRES YOU AND LG TO RESOLVE DISPUTES BY BINDING ARBITRATION INSTEAD OF IN COURT, UNLESS THE LAWS OF YOUR PROVINCE OR TERRITORY DO NOT PERMIT THAT, OR, IN OTHER JURISDICTIONS, IF YOU CHOOSE TO OPT OUT. IN ARBITRATION, CLASS ACTIONS AND JURY TRIALS ARE NOT PERMITTED. PLEASE SEE THE SECTION TITLED “PROCEDURE FOR RESOLVING DISPUTES” BELOW. Should your LG Washer (“Product”) fail due to a defect in material or workmanship under normal home use during the warranty period set forth below, LG Canada will at its option repair or replace the product upon receipt of proof of original retail purchase. This warranty is valid only to the original retail purchaser of the product and applies only to a product distributed in Canada by LG Canada or an authorized Canadian distributor thereof. The warranty only applies to Products located and used within Canada. WARRANTY PERIOD : (Note : If the original date of purchase can not be veried, the warranty will begin sixty(60) days from the date of manufacture). Period One (1) year from date of original retail purchase Ten (10) years from the date of original retail purchase Three (3) years from the date of original retail purchase Scope of Warranty Parts and Labor (internal/ functional parts only) DD Motor (Stator, Rotor, Hall Sensor) Stainless Steel Drum Remark LG will provide parts & labor to repair or replace defective parts. Extended Component Warranty (Parts Only) (Consumer will be charged for Labor after one (1) year from the date of purchase) Noises associated with normal operation and failure to follow instructions found in the use and care and installation guides or operating the unit in an unsuitable environment will not be covered under this warranty.

• Replacement products and parts are warranted for the remaining portion of the original warranty period or ninety (90) days, whichever is greater.

• Replacement products and parts may be new or remanufactured.

• Proof of original retail purchase specifying the Product model and date of purchase is required to obtain warranty service under this Limited Warranty. LG CANADA’S SOLE LIABILITY IS LIMITED TO THE WARRANTY SET OUT ABOVE. EXCEPT AS EXPRESSLY PROVIDED ABOVE, LG CANADA MAKES NO AND HEREBY DISCLAIMS ALL OTHER WARRANTIES AND CONDITIONS RESPECTING THE PRODUCT, WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OR CONDITION OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, AND NO REPRESENTATIONS SHALL BE BINDING ON LG CANADA. LG CANADA DOES NOT AUTHORIZE ANY PERSON TO CREATE OR ASSUME FOR IT ANY OTHER WARRANTY OBLIGATION OR LIABILITY IN CONNECTION WITH THE PRODUCT. TO THE EXTENT THAT ANY WARRANTY OR CONDITION IS IMPLIED BY LAW, IT IS LIMITED TO THE EXPRESS WARRANTY PERIOD ABOVE. LG CANADA, THE MANUFACTURER OR DISTRIBUTOR SHALL NOT BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL, DIRECT OR INDIRECT DAMAGES, LOSS OF GOODWILL, LOST PROFITS, PUNITIVE OR EXEMPLARY DAMAGES OR ANY OTHER DAMAGE, WHETHER ARISING DIRECTLY OR INDIRECTLY FROM ANY CONTRACTUAL BREACH, FUNDAMENTAL OR OTHERWISE, OR FROM ANY ACTS OR OMISSIONS, TORT, OR OTHERWISE. This warranty gives you specic legal rights. You may have other rights which may vary from province to province depending on applicable provincial laws. Any term of this warranty that negates or varies any implied condition or warranty under provincial law is severable where it conicts with provincial law without affecting the remainder of this warranty’s terms.53LIMITED WARRANTY ENGLISH THIS LIMITED WARRANTY DOES NOT COVER:

• Service trips to deliver, pick up, or install the product; instructing a customer on operation of the product; repair or replacement of fuses or correction of wiring or plumbing, or correction of unauthorized repairs/installation.

• Failure of the product to perform during power failures and interruptions or inadequate electrical service.

• Damage caused by leaky or broken water pipes, frozen water pipes, restricted drain lines, inadequate or interrupted water supply or inadequate supply of air.

• Damage resulting from operating the Product in a corrosive atmosphere or contrary to the instructions outlined in the Product owner’s manual.

• Damage to the Product caused by accidents, pests and vermin, lightning, wind, re, oods, or acts of God.

• Damage or product failure caused by unauthorized modication or alteration, or use for other than its intended purpose, or resulting from any water leakage due to improper installation.

• Damage or Product failure caused by incorrect electrical current, voltage, or plumbing codes, commercial or industrial use, or use of accessories, components, or cleaning products that are not approved by LG Canada.

• Damage caused by transportation and handling, including scratches, dents, chips, and/or other damage to the nish of your product, unless such damage results from defects in materials or workmanship and is reported within one (1) week of delivery.

• Damage or missing items to any display, open box, discounted, or refurbished Product.

• Products with original serial numbers that have been removed, altered, or cannot be readily determined. Model and Serial numbers, along with original retail sales receipt, are required for warranty validation.

• Increases in utility costs and additional utility expenses.

• Replacement of light bulbs, lters, or any consumable parts.

• Repairs when your Product is used in other than normal and usual household use (including, without limitation, commercial use, in ofces or recreational facilities) or contrary to the instructions outlined in the Product owner’s manual.

• Costs associated with removal of the Product from your home for repairs.

• The removal and reinstallation of the Product if it is installed in an inaccessible location or is not installed in accordance with published installation instructions, including the Product owner’s and installation manuals.

• Accessories to the Product such as door bins, drawers, handles, shelves, etc.. Also excluded are parts besides those that were originally included with the Product.

• Damage resulting from the misuse, abuse, improper installation, repair, or maintenance of the Product. Improper repair includes use of parts not approved or specied by LG Canada.

• Coverage for "in Home" repairs, for products in-warranty, will be provided if the Product is within a 150 km radius from the nearest authorized service center (ASC), as determined by LG Canada. If your Product is located outside a 150 km radius from a ASC, as determined by LG Canada, it will be your responsibility to bring the Product, at your sole expense, to the ASC for in-warranty repair. All costs and expenses associated with the above excluded circumstances, listed under the heading, This Limited Warranty Does Not Cover, shall be borne by the consumer. TO OBTAIN WARRANTY SERVICE AND ADDITIONAL INFORMATION, PLEASE CALL OR VISIT OUR WEBSITE: Call 1-888-542-2623 (7 A.M. to 12 A.M., 365 days a year) and select the appropriate option from the menu, or visit our website at http://www.lg.com54 LIMITED WARRANTY PROCEDURE FOR RESOLVING DISPUTES: EXCEPT WHERE PROHIBITED AT LAW, ALL DISPUTES BETWEEN YOU AND LG ARISING OUT OF OR RELATING IN ANY WAY TO THIS LIMITED WARRANTY OR THE PRODUCT SHALL BE RESOLVED EXCLUSIVELY THROUGH BINDING ARBITRATION, AND NOT IN A COURT OF GENERAL JURISDICTION. EXCEPT WHERE PROHIBITED AT LAW, YOU AND LG BOTH IRREVOCABLY AGREE TO WAIVE THE RIGHT TO A JURY TRIAL AND TO BRING OR PARTICIPATE IN A CLASS ACTION. Denitions. For the purposes of this section, references to “LG” mean LG Electronics Canada, Inc., its parents, subsidiaries and afliates, and each of their ofcers, directors, employees, agents, beneciaries, predecessors in interest, successors, assigns and suppliers; references to “dispute” or “claim” shall include any dispute, claim or controversy of any kind whatsoever (whether based in contract, tort, statute, regulation, ordinance, fraud, misrepresentation or any other legal or equitable theory) arising out of or relating in any way to the sale, condition or performance of the product or this Limited Warranty. Notice of Dispute. In the event you intend to commence an arbitration proceeding, you must rst notify LG in writing at least 30 days in advance of initiating the arbitration by sending a letter to LGECI Legal Team at 20 Norelco Drive, North York, Ontario, Canada M9L 2X6 (the “Notice of Dispute”). You and LG agree to engage in good faith discussions in an attempt to amicably resolve your claim. The notice must provide your name, address, and telephone number; identify the product that is the subject of the claim; and describe the nature of the claim and the relief being sought. If you and LG are unable to resolve the dispute within 30 days of LG’s receipt of the Notice of Dispute, the dispute shall be resolved by binding arbitration in accordance with the procedure set out herein. You and LG both agree that, during the arbitration proceeding, the terms (including any amount) of any settlement offer made by either you or LG will not be disclosed to the arbitrator until the arbitrator determines the dispute. Agreement to Binding Arbitration and Class Action Waiver. Upon failure to resolve the dispute during the 30 day period after LG’s receipt of the Notice of Dispute, you and LG agree to resolve any claims between you and LG only by binding arbitration on an individual basis, unless you opt out as provided below, or you reside in a jurisdiction that prevents full application of this clause in the circumstances of the claims at issue (in which case if you are a consumer, this clause will only apply if you expressly agree to the arbitration). To the extent permitted by applicable law, any dispute between you and LG shall not be combined or consolidated with a dispute involving any other person’s or entity’s product or claim. More specically, without limitation of the foregoing, except to the extent such a prohibition is not permitted at law, any dispute between you and LG shall not under any circumstances proceed as part of a class or representative action. Instead of arbitration, either party may bring an individual action in small claims court, but that small claims court action may not be brought on a class or representative basis except to the extent this prohibition is not permitted at law in your province or territory of jurisdiction as it relates to the claims at issue between you and LG. Arbitration Rules and Procedures. To begin arbitration of a claim, either you or LG must make a written demand for arbitration. The arbitration will be private and condential, and conducted on a simplied and expedited basis before a single arbitrator chosen by the parties under the provincial or territorial commercial arbitration law and rules of the province or territory of your residence. You must also send a copy of your written demand to LG at LG Electronics, Canada, Inc., Attn: Legal Department- Arbitration, 20 Norelco Drive, North York, Ontario M9L 2X6. This arbitration provision is governed by your applicable provincial or territorial commercial arbitration legislation. Judgment may be entered on the arbitrator’s award in any court of competent jurisdiction. All issues are for the arbitrator to decide, except that, issues relating to the scope and enforceability of the arbitration provision and to the arbitrability of the dispute are for the court to decide. The arbitrator is bound by the terms of this provision. Governing Law. The law of the province or territory of your purchase shall govern this Limited Warranty and any disputes between you and LG except to the extent that such law is preempted by or inconsistent with applicable federal or provincial/territorial law. Should arbitration not be permitted for any claim, action, dispute or controversy between you and LG, you and LG attorn to the exclusive jurisdiction of the courts of the province or territory of your purchase for the resolution of the claim, action, dispute or controversy between you and LG.55LIMITED WARRANTY ENGLISH Fees/Costs. You do not need to pay any fee to begin an arbitration. Upon receipt of your written demand for arbitration, LG will promptly pay all arbitration ling fees unless you seek more than $25,000 in damages, in which case the payment of these fees will be governed by the applicable arbitration rules. Except as otherwise provided for herein, LG will pay all ling, administration and arbitrator fees for any arbitration initiated in accordance with the applicable arbitration rules and this arbitration provision. If you prevail in the arbitration, LG will pay your attorneys’ fees and expenses as long as they are reasonable, by considering factors including, but not limited to, the purchase amount and claim amount. Notwithstanding the foregoing, if applicable law allows for an award of reasonable attorneys’ fees and expenses, an arbitrator can award them to the same extent that a court would. If the arbitrator nds either the substance of your claim or the relief sought in the demand is frivolous or brought for an improper purpose (as measured by the applicable laws), then the payment of all arbitration fees will be governed by the applicable arbitration rules. In such a situation, you agree to reimburse LG for all monies previously disbursed by it that are otherwise your obligation to pay under the applicable arbitration rules. Except as otherwise provided for, LG waives any rights it may have to seek attorneys’ fees and expenses from you if LG prevails in the arbitration. Hearings and Location. If your claim is for $25,000 or less, you may choose to have the arbitration conducted solely (1) on the basis of documents submitted to the arbitrator, (2) through a telephonic hearing, or (3) by an in-person hearing as established by the applicable arbitration rules. If your claim exceeds $25,000, the right to a hearing will be determined by the applicable arbitration rules. Any in-person arbitration hearings will be held at the nearest, most mutually-convenient arbitration location available within the province or territory in which you reside unless you and LG both agree to another location or agree to a telephonic arbitration. Severability and Waiver. If any portion of this Limited Warranty (including these arbitration procedures) is unenforceable, the remaining provisions will continue in full force and effect to the maximum extent permitted by applicable law. Should LG fail to enforce strict performance of any provision of this Limited Warranty (including these arbitration procedures), it does not mean that LG intends to waive or has waived any provision or part of this Limited Warranty. Opt Out. You may opt out of this dispute resolution procedure. If you opt out, neither you nor LG can require the other to participate in an arbitration proceeding. To opt out, you must send notice to LG no later than 30 calendar days from the date of the rst consumer purchaser’s purchase of the product by either (i) sending an e-mail to [e-mail], with the subject line: “Arbitration Opt Out;” or (ii) calling 1-800-980-2973. You must include in the opt out e-mail or provide by telephone: (a) your name and address; (b) the date on which the product was purchased; (c) the product model name or model number; and (d) the serial number (the serial number can be found (i) on the product; or (ii) online by accessing https://www.lg.com/ca_en/support/repair-service/schedule- repair and clicking on “Find My Model & Serial Number”). In the event that you “Opt Out”, the law of the province or territory of your residence shall govern this Limited Warranty and any disputes between you and LG except to the extent that such law is preempted by or inconsistent with applicable federal or provincial/territorial law. Should arbitration not be permitted for any claim, action, dispute or controversy between you and LG, you and LG agree to attorn to the exclusive jurisdiction of the courts of the province or territory of your residence for the resolution of the claim, action, dispute or controversy between you and LG. You may only opt out of the dispute resolution procedure in the manner described above (that is, by e-mail or telephone); no other form of notice will be effective to opt out of this dispute resolution procedure. Opting out of this dispute resolution procedure will not affect the coverage of the Limited Warranty in any way, and you will continue to enjoy the full benets of the Limited Warranty. If you keep this product and do not opt out, then you accept all terms and conditions of the arbitration provision described above. Conict of Terms. In the event of a conict or inconsistency between the terms of this Limited Warranty and the End User License Agreement (“EULA”) in regards to dispute resolution, the terms of this Limited Warranty shall control and govern the rights and obligations of the parties and shall take precedence over the EULA.56 LIMITED WARRANTY Strange vibration or noise caused by not removing shipping bolts or tub support. Tub support Carton base Shipping bolt Remove the shipping bolts & tub support. Leakage caused by dirt (hair, lint) on seal and door glass. Clean the seal & door glass. Not draining caused by clogging of pump lter. Clean the pump lter. Water is not supplied because water inlet valve lters are clogged or water inlet hoses are kinked. Inlet lter Clean the inlet valve lter or reinstall the water inlet hoses. Water is not supplied because too much detergent is used. Dispenser Clean the detergent dispenser drawer. Laundry is hot or warm after washing because the inlet hoses are installed in reverse. Cold water inlet Hot water inlet Reinstall the inlet hoses. Water is not supplied because the water tap is not turned on. Water tap Turn on the water tap. Leakage caused by improper installation of drain hose or clogged drain hose. Elbow bracket Tie strap Reinstall the drain hose.57LIMITED WARRANTY ENGLISH Leakage caused by improper installation of water inlet hose or using non-LG inlet hoses. Reinstall the inlet hose. Power not supplied because of loose connection of power cord or electrical outlet problem. Reconnect the power cord or change the electrical outlet. Service trips to deliver, pick up, install the product or for instruction on product use. The removal and reinstallation of the Product. Level The warranty covers manufacturing defects only. Service resulting from improper Installation is not covered. If all screws are not installed properly, it may cause excessive vibration (Pedestal model only). Install 4 screws at each corner (Total 16EA). Water hammering (banging) noise when washing machine is lling with water. High pressure water Hit!! Loud noise Natural water ow Sudden stopping water ow Adjust the water pressure by turning down the water valve or water tap in the home.58 MEMOESPAÑOL
