USER MANUAL Cecojuicer Zitrus CECOTEC

Turboexprimidor/Turbo-juicer

Cecotec® water heater with orange juice being placed beside it, accompanied by fresh oranges (no text or symbols visible on the device itself)

Abstract geometric design with overlapping light blue triangles (no text or symbols)

ÍNDICE

1. Parts and components
2. Safety instructions
3. Setup and configuration
4. Operation
5. Cleaning and maintenance
6. Technical specifications
7. Disposal of old electrical appliances
8. Technical support service and warranty

INDICE

Exploded view diagram of a microwave oven with numbered parts for identification

ES

1. Cover with citrus cutter
2. Removable squeezer cones
3. Base of the squeezer cones
4. On/Off switch
5. Main body
6. Compartment for storing the power cord
7. Juice container
8. Removable base
9. Filter
10. Transmission axis

FR

Read these instructions carefully before using the appliance. Keep this instruction manual for future reference or new users.

2. SAFETY INSTRUCTIONS

• All safety instructions should be closely followed when using the appliance.
• Make sure that the mains voltage matches the voltage stated on the rating label of the appliance and that the outlet is grounded.
• Do not immerse the cord, plug, or any non-removable part of the appliance in water or any other liquid, nor expose the electrical connections to water. Make sure your hands are dry before handling the plug or switching on the appliance.
• Unplug Cecojuicer Zitrus from the main power supply when not in use.

WARNING: if the appliance falls accidentally in water, unplug it immediately. Do not reach into the water!

- Check the power cord regularly for visible damage. If the cord is damaged, it must be replaced by the official Technical Support Service of Cecotec, in order to avoid any type of danger.

WARNING: do not use the appliance if its cord, plug, or housing is damaged, nor after it malfunctions or has been dropped or damaged in any way.

• Do not twist, bend, strain, or damage the power cord in any way. Protect it from sharp edges and heat sources. Do not let it touch hot surfaces. Do not let the cord hang over the edge of the working surface or countertop.
• The appliance is not intended to be operated by means of an external timer or separate remote-control system.
• Turn off and unplug the appliance from the mains supply when not in use and before cleaning it. Pull from the plug, not the cord, to disconnect it from the outlet.
• This appliance is intended for domestic use only. It is not suitable for commercial or industrial use. Do not use it outdoors.
• Do not use any accessory that has not been recommended by the manufacturer, as they might cause injuries or damage.
• The appliance is not intended to be used by children under the age of 8. It can be used by children over the age of 8, as long as they are given continuous supervision.
• This appliance is not intended to be used by persons with reduced physical, sensory, or mental capabilities, or lack of experience or knowledge, unless they have been given supervision or instruction concerning the use of the appliance in a safe way by a person responsible for their safety, and understand the hazards involved.
• Supervise young children to make sure that they do not play with the appliance. Close supervision is necessary when the appliance is being used by or near children.
• Keep the appliance and its cord out of reach of children under the age of 8.
• Place the appliance on a dry, stable, flat, heat-resistant surface.

- Do not use the appliance under the following circumstances:

• On or near a gas or electric hob, in heated ovens, or near open flames.
• On soft surfaces (such as carpets) or where it may tip over during use.

• Outdoors or in areas with high humidity levels.

• The temperature of accessible surfaces may be high while in use and could cause burns. Do not touch hot surfaces while in use or immediately after.

• Do not cover the appliance while in use.
• Do not leave the appliance unattended while in use. Unplug it from the mains supply when you finish using it or when you leave the room.
• Do not try to repair the appliance by yourself. Contac the official Technical Support Service of Cecotec for advice.
• Cleaning and maintenance must be carried out according to this instruction manual to make sure the appliance functions properly. Turn off and unplug the appliance before moving and cleaning it.
• Cleaning and maintenance tasks must not be carried out by children.
• Do not wash the appliance in dishwashers.
• Store the appliance and its instruction manual in a safe and dry place when not in use.
  • No liability is accepted for any eventual damage or personal injuries derived from misuse or non-compliance with this instruction manual.

3. SETUP AND CONFIGURATION OF YOUR CECOJUICER ZITRUS

1. Place the main body on a clean, stable, and dry surface.
2. Place the base of the squeezer cones onto the main body using the slots at the back of the main body. Then press gently until it clicks.
3. Insert the squeezer cones on the axis.
4. Insert the lock cones in the slots at the back of the base of the squeezer cones.
5. Insert the juice container in the guides of the main body. Slide it until it locks.
6. Fit the citrus cutter on the top of the base of the squeezer cones.
7. Plug in the appliance. Your Cecojuicer Zitrus is now ready for use!

4. OPERATION

Make sure to clean your Cecojuicer Zitrus thoroughly before use.

1. Plug in the device into an electrical socket.
2. Place the lateral power button in the ON position.
3. Place an orange on the cutting compartment.

4. Lower the lid to cut the fruit in half.

5. Place each half of the orange in each one of the squeezer heads.

6. Lower the lid pressing firmly with both hands. You will notice how the juice is deposited in the container. Important: Cecojuicer Zitrus will not work until pressure is applied with both hands.

7. Once all the juice from both halves of the orange has been extracted, remove the oranges and discard the shells.
8. Repeat steps 5 and 6 until the juice container is full.
9. Remove the juice container and start enjoying your freshly made juice.

WARNING: if your Cecojuicer Zitrus stops unexpectedly, the squeezer cones could be blocked by an excess of pulp. Remove the pulp stuck under the squeezer cones.

5. CLEANING AND MAINTENANCE

After each use, Cecojuicer Zitrus should be cleaned properly. Keep your Cecojuicer Zitrus in a dry, well-ventilated place. If not used for more than 3 days, make sure to wash the parts before the next use.

DISASSEMBLY OF YOUR CECOJUICER ZITRUS

1. Turn off and unplug your Cecojuicer Zitrus from the power supply before changing accessories.
2. Remove the juice container.
3. Open the top cover completely with both hands placed on each side. Slide the locking rods of the slots in the back of the base of the squeezer heads.
4. Hold the main body with one hand and gently push up the front lever with the other hand until it opens. Slide the base of the squeezer cones off the main body.
5. The squeezer cones can also be extracted by simply sliding them off the drive shafts.
6. Remove the tray from the main body.

IMPORTANT: do not immerse the main body in water or any other liquid. Instead, use a damp cloth to clean it. Always switch off and unplug the appliance before assembling, disassembling, or cleaning it. Use warm water and soap to wash all non-electrical parts. Never use abrasive cleaning agents, as they may cause damage to your Cecojuicer Zitrus. Non-electric parts can be washed in the dishwasher.

6. TECHNICAL SPECIFICATIONS

Product reference: 04039

Power: 90 W

Voltage and frequency: 220-240 V /50 Hz

Made in P.R.C. | Designed in Spain

7. DISPOSAL OF OLD ELECTRICAL APPLIANCES

The European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), specifies that old household electrical appliances must not be disposed of with the normal unsorted municipal waste. Old appliances must be collected separately, in order to optimize the recovery and recycling of the materials they contain, and reduce the impact on human health and the environment.

The crossed out "wheeled bin" symbol on the product reminds you of your obligation to dispose of the appliance correctly. If the product has a built-in battery or uses batteries, they should be removed from the appliance and disposed of appropriately.

Consumers must contact their local authorities or retailer for information concerning the correct disposal of old appliances and/or their batteries.

8. TECHNICAL SUPPORT SERVICE

This product is under warranty for 2 years from the date of purchase, as long as the proof of purchase is submitted, the product is in perfect physical condition, and it has been given proper use, as explained in this instruction manual.

The warranty will not cover the following situations:

• The product has been used for purposes other than those intended for it, misused, beaten, exposed to moisture, immersed in liquid or corrosive substances, as well as any other fault attributable to the customer.
• The product has been disassembled, modified, or repaired by persons, not authorised by the official Technical Support Service of Cecotec.
• Faults deriving from the normal wear and tear of its parts, due to use.

The warranty service covers every manufacturing defects of your appliance for 2 years, based on current legislation, except consumable parts. In the event of misuse, the warranty will not apply. If at any point, a fault is detected, contact the official Technical Support Service of Cecotec and send us your proof of purchase via e-mail at:

[e-mail]

Made in P.R.C. | Designed in Spanien
