Product type Electric high-pressure cleaner
Brand Kärcher
Model HD 13/18-4 S Classic
Power supply 400 V / 50 Hz / three-phase / 8.8 kW
Operating pressure 180 bar (18 MPa) with standard nozzle
Maximum pressure 240 bar (24 MPa)
Water flow rate 21.7 l/min
Maximum inlet temperature 60 °C
Weight 67 kg
Dimensions (L x W x H) 720 x 637 x 1080 mm
Protection type IPX5
Water connection 3/4" (1 inch) connection, max pressure 10 bar
Sound level (LpA) 74 dB(A)
Lance system EASY!Lock Classic with 075 nozzle
Features Pressure switch, recycling valve, motor thermal protection, pressure/flow regulation
Detergent use Yes, via optional foam lance
Maintenance Oil change every 500 h, clean fine filter every week
Pump oil type 15W40, capacity 0.65 l
Warranty According to country conditions, with invoice

Frequently Asked Questions - HD 13184 S Classic Kärcher

What is the operating pressure of the Kärcher HD 13/18-4 S Classic?
The operating pressure with the standard nozzle (size 075) is 18 MPa (180 bar). The maximum overpressure reaches 24 MPa (240 bar).
What type of power supply does this high-pressure cleaner require?
The device operates on a three-phase 400 V / 50 Hz supply with a power of 8.8 kW. Use a 16 A fuse and an extension cable of suitable cross-section.
Can I use detergent with this cleaner?
Yes, with the optional bucket foam lance accessory. Use only KÄRCHER detergents and follow the dosages. After use, rinse the lance with clean water.
How to bleed the device before first use?
Unscrew the high-pressure nozzle from the lance, let water run until bubbles disappear, then retighten the nozzle. If necessary, repeat several times.
How often should the pump oil be changed?
Every 500 operating hours or at least once a year. Use 15W40 oil (quantity: 0.65 l). Refer to the manual for the drain procedure.
What to do if the device does not build up pressure?
Check the nozzle (size and cleanliness), bleed the device, clean the fine filter, and check the water supply flow rate (min 25 l/min). If the problem persists, contact customer service.
How to protect the device from frost?
Completely drain the water from the device. Store it in a frost-free location. Alternatively, use a glycol-based antifreeze and run the device for 1 minute to drain the lines.
Does the high-pressure cleaner have a safety device?
Yes, it is equipped with a pressure switch (pump stop when trigger is released), a recycling valve, and a motor thermal protection.
What is the weight of the Kärcher HD 13/18-4 S Classic?
The typical operating weight is 67 kg. Dimensions are 720 x 637 x 1080 mm.
Where to find spare parts and accessories?
Use only genuine KÄRCHER parts. Visit www.kaercher.com or your authorized dealer.
