Product type	Decorative light string (EL wire)
Brand	Eurolite
Model	EL Wire (2m and 10m versions)
Light cable dimensions	2m: Ø2mm or Ø4mm × 2m; 10m: Ø2mm or Ø5mm × 10m
Weight	2m: 120g (Ø2mm) or 210g (Ø4mm); 10m: 180g (Ø2mm) or 720g (Ø5mm)
Power supply	2m: 3 V DC via 2 AA batteries (1.5 V); 10m: 230 V AC, 50 Hz via supplied 12 V DC transformer
Max power consumption	2m: 1 W; 10m: 12 W (Ø2mm) or 8 W (Ø5mm)
Lifespan	3000 – 5000 hours
Max ambient temperature	45 °C
Max housing temperature	60 °C
Min. distance to flammable surfaces	0.5 m
Min. distance to illuminated object	0.1 m
Color temperature (white)	6400 K
Available functions	Steady on, Off, Flashing (mode selector on the controller)
Installation	Draw or wrap the cord, fix with glue or adhesive tape
Cleaning	Damp lint-free cloth; no alcohol or detergent
Protection class	10m: transformer class 2, cord class 3; 2m: class 3
Maintenance	No internal parts requiring maintenance
Batteries (2m version)	2 AA 1.5 V batteries, alkaline type recommended
Warranty	Void if modified or used improperly

Frequently Asked Questions - EL Wire Eurolite

What is the difference between the EL Wire 2M and 10M?

The EL Wire 2M runs on batteries (2× AA) and measures 2 meters, while the EL Wire 10M is powered by a mains transformer (230 V) and measures 10 meters. The 2M is more portable, the 10M offers a longer reach.

How to install the EL Wire?

Draw your pattern or wrap the cord around the desired object. Fix it with glue or adhesive tape. For the 10M version, plug the transformer into a dry mains socket. For the 2M version, insert the batteries respecting polarity.

What are the available modes on the controller?

The controller has three positions: ON (steady light), OFF (off) and BL (flashing).

Can I connect multiple EL wires together?

No, it is forbidden to electrically connect this string to another. This could cause an overload or short circuit.

How to replace the batteries of the EL Wire 2M?

Open the battery cover under the housing, remove the used batteries (wear gloves if corroded), insert two new AA batteries respecting polarity, then close the cover.

What is the lifespan of the EL wire?

The lifespan is between 3000 and 5000 hours of use.

How to clean the EL Wire?

Use a slightly damp lint-free cloth. Never use alcohol or harsh detergents. Always unplug before cleaning.

What to do in case of malfunction?

Check the power supply (batteries or transformer), the connections and the condition of the cord. If the device is damaged or does not work, do not use it and consult your dealer.

Is the EL Wire waterproof?

No, the device is not waterproof. It must be protected from moisture and used only in dry places.

What are the important safety instructions?

Never use the device wound in its packaging, do not exceed the indicated voltage, unplug when not in use, keep away from children, and do not modify the device. Respect the safety distances (0.5 m from flammable surfaces, 0.1 m from illuminated objects).

USER MANUAL EL Wire Eurolite

eurolite® EUROLTE 10m High voltage Cable Emissions 200V CE

eurolite® EUROLITE® MODIENUNGSAM USER MANUAL MODE D'EMIN MANUAL DEL US

MULTI-LANGUAGE-INSTRUCTIONS

Inhaltsverzeichnis / Table of contents Sommaire / Contenido

Deutsch

EINFÜHRUNG 3

SAFETY INSTRUCTIONS....7

OPERATING DETERMINATIONS....8

OPERATION: EL Wire 10m 8

OPERATION: EL Wire 2m 8

CLEANING AND MAINTENANCE 9

TECHNICAL SPECIFICATIONS....9

Français

INTRODUCTION....11

INSTRUCTIONS DE SÉCURITÉ 11

EMPLOI SELON LES PRESCRIPTIONS....12

MANIEMENT: Cordon EL 10m....12

MANIEMENT: Cordon EL 2m....12

NETTOYAGE ET MAINTENANCE....13

CARACTÉRISTIQUES TECHNIQUES 13

Español

INTRODUCCIÓN 15

You can find the latest update of this user manual in the Internet under:

Keep this device away from rain and moisture!

For your own safety, please read this user manual carefully before you initially start-up.

Every person involved with the installation, operation and maintenance of this device has to

• be qualified
• follow the instructions of this manual
• consider this manual to be part of the total product
• keep this manual for the entire service life of the product
• pass this manual on to every further owner or user of the product
• download the latest version of the user manual from the Internet

INTRODUCTION

Thank you for having chosen an EL Wire. If you follow the instructions given in this manual, we are sure that you will enjoy this device for a long period of time.

Unpack your EL Wire.

SAFETY INSTRUCTIONS

CAUTION!

Be careful with your operations. With a dangerous voltage you can suffer a dangerous electric shock when touching the wires!

This device has left our premises in absolutely perfect condition. In order to maintain this condition and to ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes written in this user manual.

Important:

Damages caused by the disregard of this user manual are not subject to warranty. The dealer will not accept liability for any resulting defects or problems.

Never hit the lighting chain with a hammer or other tools, as this may lead to damaged lamps.

Never operate the device in the packaging or wrapped in order to avoid heating-up.

Make sure that the available voltage is not higher than stated on the technical sticker.

English

This device falls under protection-class III. The device always has to be operated with an appropriate transformer (EL Wire 10m) or with a suitable set of batteries (EL Wire 2m).

Always disconnect from the mains or remove the batteries, when the device is not in use or before cleaning it.

If there are reasons for supposing that risk-free operation is no longer possible, the lighting chain must be deactivated and protected against accidental operation. Risk-free operation can no longer be supposed when the lighting chain

• no longer functions
  • is visibly damaged
• has been stored long-term under adverse conditions, or
  • has been exposed to stress during transport.

Please consider that damages caused by manual modifications to the device are not subject to warranty.

Keep away children and amateurs!

OPERATING DETERMINATIONS

This device is a lighting chain for creating decorative effects.

The EL Wire 10m is only allowed to be operated with an alternating voltage of 230 V, 50 Hz and may only be operated with the included power unit. The power unit falls under protection-class 2 and the lighting chain under protection-class 3.

The EL Wire 2m is allowed to be operated with a direct current of 3 V and may only be operated with a suitable set of batteries.

Do not shake the device. Avoid brute force when installing or operating the device.

Operate the device only after having familiarized with its functions. Do not permit operation by persons not qualified for operating the device. Most damages are the result of unprofessional operation!

Please use the original packaging if the device is to be transported.

Please consider that unauthorized modifications on the device are forbidden due to safety reasons!

This lighting chain must never be electrically connected with another chain.

If this device will be operated in any way different to the one described in this manual, the product may suffer damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-circuit, burns, electric shock, etc.

OPERATION: EL Wire 10m

In order to design the desired patterns, draw the form onto the surface or wrap the EL Wire around the desired form and attach the EL Wire with adhesive tape or a few drops of glue.

Connect the power cable of the EL Wire to the transformer. Connect the transformer to the mains. Make sure that the outlet is in a dry area.

On the controller of the EL Wire, you can find a 3-step switch with the following functions:

On Static light Off Off BI Blinking light

OPERATION: EL Wire 2m

In order to design the desired patterns, draw the form onto the surface or wrap the EL Wire around the desired form and attach the EL Wire with adhesive tape or a few drops of glue.

Open the battery cover and remove it. If replacing the batteries, remove the old batteries from the battery compartment. Only replace complete battery-sets.

English

Leaky or damaged batteries might cause cauterisation when in contact with the skin; therefore, use suitable protective gloves.

Caution!

Danger of explosion when battery is replaced improperly.

Only replace by the same type or similar types recommended by the manufacturer.

Remove empty batteries in accordance with the instructions of the manufacturer.

Insert the batteries and make sure that the poles are correct. Replace the battery cover and close it.

Via the controller with the 3-step button, you can switch between blinking-mode, on and off.

If the device will not be used for a longer period of time, remove the batteries in order to avoid battery leakage.

In order to have a long battery life, you should only use alcaline batteries.

BATTERY DISPOSAL NOTICE

Please dispose of old and used batteries properly.

Batteries are hazardous waste and should not be disposed of with regular domestic waste!

Please take old and used batteries to a collection center near you.

CLEANING AND MAINTENANCE

DANGER TO LIFE!

Disconnect from mains before starting maintenance operation!

We recommend a frequent cleaning of the device. Please use a moist, lint-free cloth. Never use alcohol or solvents!

There are no serviceable parts inside the device. If defective, please dispose of the unusable lighting chain in accordance with the current legal regulations.

Should you have further questions, please contact your dealer.

TECHNICAL SPECIFICATIONS

Version: EL Wire 2m 50520300 - 50520310 50520320 - 50520330
Power supply:	3 V DC 3 V DC
	via 2 x 1.5V Mignon Batteries (Type AA)	via 2 x 1.5V Mignon Batteries (Type AA)
Power consumption: max. 1 W max. 1 W
Lifetime: 3000 – 5000 h 3000 – 5000 h
Maximum ambient temperature T_a : 45°C 45°C
Max. housing temperature T_c (steady state): 60°C 60°C
Min. distance from flammable surfaces: 0.5 m	0.5 m
Min. distance to lighted object:	0.1 m 0.1 m
Color temperature:for article no:. 50520310/50520330, white	6400K	6400K
Diameter x Length:	2mm x 2m	4mm x 2m
Weight:	120g	210g
Version: EL Wire 10m 50520340 - 50520350	50520360 - 50520370
	230 V/50 Hz 230 V AC, 50 Hz ~Power supply:
	via 12V DC transformer via 12V DC transformer
Power consumption: max.12 W 8 W
Lifetime: 3000 – 5000 h 3000 – 5000 h
Maximum ambient temperature T_a : 45°C 45°C
Max. housing temperature T_c (steady state): 60°C 60°C
Min. distance from flammable surfaces: 0.5 m 0.5 m
Min. distance to lighted object:	0.1 m 0.1 m
Color temperature:for article no:. 50520350/50520370, white	6400K	6400K
Diameter x Length:	2mm x 10m	5mm x 10m
Weight:	180g	720g

Please note: Every information is subject to change without prior notice. 23.01.2012 ©
