Product type Cordless angle grinder
Brand Metabo
Model WB 18 LT BL 11125 Q SE
Power supply Li-Ion battery 18 V (CAS series)
Max. accessory diameter 125 mm (D_max)
Adjustable no-load speed Yes, via thumbwheel
Spindle lock Yes, for accessory change
Additional handle Removable, with vibration damping
Protective guard Interchangeable according to use (sanding, cutting)
Dust filter Removable and cleanable
Weight Approx. 2.2 kg (with light battery)
Sound pressure level (LpA) 82 dB(A) (typical)
Vibration (surface sanding) 5.5 m/s² (typical value)
Main functions Grinding, sanding, cutting, brushing
Anti-restart safety Present on trigger version
Maintenance and cleaning Regularly dust the ventilation slots and filter
Spare parts and repairability Metabo after-sales service, lists at www.metabo.com
General information Only use original Metabo or CAS accessories and batteries

Frequently Asked Questions - WB 18 LT BL 11125 Q SE METABO

How to change the sanding disc?
First remove the battery. Lock the spindle using the lock button (4). Loosen the Quick clamping nut by hand or use the pin spanner for the two-hole nut. Replace the disc, then firmly retighten the nut.
What types of accessories can I use?
Use only compatible Metabo or CAS accessories: cutting wheels, grinding wheels, wire brushes, abrasive discs, etc. Observe the diameters and thicknesses specified in the technical data.
How to clean the dust filter?
Remove the filter (12) by lifting it at the upper edges. Clean it with compressed air or soapy water, then let it dry completely before reinstalling.
The machine stopped suddenly, what should I do?
This is probably the electronic safety shutdown due to a jam or kickback. Release the switch, then restart the machine normally. Avoid jams by working with appropriate feed rate.
Which battery to use with this model?
Use Metabo or CAS 18 V Li-Ion batteries, e.g., 5.5 Ah (624990000) or 10.0 Ah (624991000). Charge them with a suitable charger such as the ASC 55.
How to adjust the rotation speed?
Turn the thumbwheel (14) to select the speed. A low number corresponds to low speed (for sanding), a high number to high speed (for cutting).
Can I use the grinder for cutting?
Yes, provided you use a suitable protective guard (type C for combination or specific type) and an appropriate cutting wheel. Never use a cutting wheel for side grinding.
How to install the additional handle?
Screw the additional handle (19) onto the left or right side of the gear housing. Tighten it firmly. Always use it for better control and to reduce vibrations.
What to do if the battery does not stay in place?
Clean the battery and machine contacts with a dry cloth. Check that the locking tabs are not damaged. If the problem persists, contact Metabo service.
How to dispose of the machine at end of life?
Do not dispose of it with household waste. In accordance with the WEEE directive, take it to a collection point. Remove and discharge the battery first. Used batteries must be returned to a Metabo dealer.
