TX602R - Tractor Texas - Free user manual and instructions

Product type	Cultivator (garden tractor)
Brand	Texas
Model	TX602R
Length	1350 mm
Width	570-850 mm
Height	945 mm
Weight	59.5 kg
Engine (brand)	Robin
Engine (model)	SP170
Displacement	169 cc
Maximum power	4.2 kW at 3600 rpm
Forward speeds	1
Reverse speeds	1
Working width	36-85 cm
Working depth	33 cm
Blade rotation speed	110 rpm
Lubricant type	Multifak EP-0
Sound power level (LWA)	97 dB(A)
Adjustable handle	Yes, adjustable to 3 positions
Fuel	Unleaded 95 octane gasoline
Usage	Gardening, cultivation, snow removal (with accessories)
Safety	Emergency stop, blade guard, safety zone
Maintenance	Oil change yearly, cleaning after use, air filter
Spare parts	Available at www.texas.dk and from dealers

Frequently Asked Questions - TX602R Texas

Which engine oil to use and how to check the level?

Use SAE-30 oil. Check the level with the dipstick before each use: it must be between the MIN and MAX marks.

How to start the engine safely?

Stand in the safety zone (see fig. 9), set the throttle to maximum, then pull the starter cord. Never stand in the hatched area.

What is the maximum working depth?

The maximum working depth is 33 cm. It is adjusted via the depth skid in 3 positions.

When and how to drain the engine oil?

First oil change after 5 hours of use, then once a year. Run the engine for 5 minutes to warm the oil, then unscrew the drain plug. Tilt the engine at most 45°.

What to do if the blades do not turn?

Check that no stone is stuck between the blades. Make sure the clutch cables and belt are in good condition and properly installed.

How to clean the tiller after use?

Rinse with water (garden hose) to remove soil and grass. Clean the chassis number with a damp cloth. Do not use a high-pressure cleaner.

What accessories are available for the TX602R?

Accessories: scarifier, harrow, rake, ridger, snow thrower, claws, chains, weights, intermediate blades. Often require the rear hook.

How to adjust the handle on the TX602R model?

Use the two knobs to adjust the angle to 3 positions. The handle can be folded forward for transport.

What safety precautions to observe?

Wear gloves, safety shoes, eye and hearing protection. Do not put your hands near the blades. Stop the engine before any adjustment or maintenance.

How to maintain the air filter?

Remove the cover, brush the paper filter. Wash the foam pad with soapy water, dry it, then moisten it with a few drops of SAE-30 oil.

USER MANUAL TX602R Texas

Two identical industrial tillw or power tools with black and yellow blades, no visible text or symbols.

Warning sign depicting a turbine blade hazard symbol, commonly used in safety or emergency procedures.

Blue circular icon with a white open book symbol (no text or symbols)

Blue circular icon with a stylized white face wearing glasses and headphones (no text or symbols)

Blue circular icon with a white hand symbol (no text or numbers)

Blue circular icon with a white sneaker symbol (no text or numbers)

DK / SE

Warning:Pay attention to rotating blades!

Please read the user's manual carefully before operating the engine.

Always wear eye and ear protection.

Wear safety gloves.

Wear nonskid safety footwear.

D

2. Kun for model TX601 / TX611:

3. Kun for model TX602 / TX612:

Greetings from the Manufacturer

Dear Customer!

Thank you for having chosen the products of our company, we do hope that our goods will justify your confidence.

Texas Andreas Petersen A/S was founded in 1960 and has throughout the years developed a strong production of gardening equipment.

We develop products which take the necessary regards to you and your health, surroundings and environment. An example of this regard is: A line of tillers have now been equipped with an ergonomic adjustable handlebar so that the working height of the machine can be adjusted and adapted to the user. The vibrations and noise from the machines are also lessened considerably.

In addition to this we have developed a range of accessories to the tiller models, making the tiller more than a tiller and turning it into a complete multi-machine which can be used all year.

With more than 50 years of experience in the production and sale of tillers and other garden products, we have obtained a very large knowledge, experience and know-how in this area. You can benefit from this, when you need guidance to your Texas product.

We value our customers' trust and pay much attention to aftersales service which means a full service of spare parts during 10 years after termination of production. Furthermore, we grant our customers a life-time guarantee for the tillers' high-strength steel blades against breakage.

With our products we wish to give you the help you need to make the work a pleasure and give you time for more.

Like this we have made Texas your life companion, A guarantor for garden, job and leisure solutions in the market which meets the necessary regards:

To you and your health. To you and your time and to you and your surroundings.

Texas - Your Life Companion

Best Regards,

Thomas Dalsgaard

Managing Director

Texas Andreas Petersen A/S

Exterior view of a modern brick building with 'TEXAS' signage on the facade, surrounded by green lawn and trees under a blue sky (no other text or symbols visible)

Black-and-white photo of a vintage plow on a dirt path surrounded by greenery (no visible text or symbols)

Person operating a small utility tool in a muddy field, with no visible text or symbols on the machinery or background.

PRISLISTE - SOMMEREN 1974 INSTRUKTION GARANTI- BETINGELSER

GB - Table of Contents - "Original instructions"

Safety precautions 6

Assembly....7

Clothing 7

Operating the tiller 7

Operation zone....8

Adjusting the handle 8

Adjusting the wheel/ depth skid 8

Lubrication of gearbox 8

Starting and stopping the engine 8

Cleaning the tiller....8

Changing the oil 8

Air filter maintenance....8

Storage....9

Troubleshooting....9

Noise, vibration and precautionary measures 9

Specification 39

Accessories 44

CE Certificate of conformity.... 49

Congratulations on purchasing your new tiller. Please read this instruction manual carefully, especially the safety warnings marked with the symbol:

Spare parts

Spare part drawings for the specific product can be found on our website www.texas.dk If you find the part numbers yourself, this will facilitate more rapid service.

For purchase of spare parts, please contact your dealer. You will find a list of dealers on the Texas website.

Safety precautions

Setup

Do not put hands or feet near or under rotating parts.

Read this manual carefully. Make sure that you are familiar with the different controls, settings and handles of the equipment.

Know how to stop the unit and ensure that you are familiar with emergency stop.

Never allow children or people unfamiliar with these instructions to use the machine. Note, that local regulations can restrict the age of the operator.

If you feel unwell, tired or have consumed alcohol or drugs, do not operate the machine.

Always inspect the machine before usage Ensure that no parts are worn or damaged.

Replace worn out or damaged elements and bolts in sets to preserve balance.

The operator of the machine is responsible for people's safety.

Never use the machine near children or animals.

The operator of the machine is held liable for any accidents or hazards to other people and their property.

Thoroughly inspect the area, where the equipment is to be used, if necessary remove any foreign objects.

Do not refuel gasoline indoors or while the engine is running.

Spilled gasoline is extremely flammable; never refuel while the engine is still hot.

Wipe off any spilled gasoline before starting the engine. It may cause a fire or explosion!

Beware of hazards, while working on difficult soil hence; extremely stony or hard soil.

Boots with non-slip soles with steel jacket is required. Avoid loose-fitting clothes.

Operation

Always start the engine from safety zone.

Do not leave the safety zone while operating the machine, if it is necessary to leave the safety zone, turn off the engine before leaving the zone.

After striking a foreign object, stop the engine immediately, remove the spark plug cap and inspect the machine thoroughly for damage. Repair the damage before continuing

If the machine should start to vibrate abnormally, stop the engine and check immediately for the cause. Vibration is generally a warning of damage.

Always disengage the levers, turn off the engine, and remove the spark plug, when the unit is left unattended.

Always turn off the engine and ensure that all moving parts have come to a complete stop before making any repairs, adjustments, or inspections.

Exercise extreme caution when operating on slopes.

Never operate the machine at a fast pace.

Do not overload machine capacity by attempting to work at too fast a rate.

Do not carry passengers.

Pay attention, while the machine is in reverse.

⚠️ Never allow any bystanders in front of unit.

Always disengage the blades, if not in use.

Only operate the machine at daylight or in fully illuminated areas

⚠ Ensure a stable foothold and always keep a firm hold on the handles. Always walk, never run.

Do not operate the equipment when barefoot or wearing sandals.

Exercise extreme caution when changing direction on slopes

By rear tillers, ensure that the blades are protected by safety shield, only the part of the blades that works into the soil must be free.

Never attempt to make any adjustments, while the engine is running.
Use extreme caution when reversing or pulling the machine backwards
A. Never operate the engine indoor or in areas with low ventilation. The exhaustion from the engine contains carbon monoxide. Failure to observe could result in permanent injury or death.

Gasoline safety

Use extreme care in handling gasoline. Gasoline is extremely flammable and the fumes are explosive.
Serious personal injury can occur, when gasoline is spilled on yourself or your clothes. Rinse your skin and change clothes immediately!
Use only an approved gasoline container. Do not use soft drink bottle or similar!
Extinguish all cigarettes, cigars, pipes and other sources of ignition.
⚠️ Never refuel your machine indoors.
Let the engine cool down before refilling
Never fill the fuel tank to more than 2.5 cm below bottom of filler in order to provide space for fuel to expansion.
⚠️ After refueling, ensure that the cap tighten securely.
Never use the lock-function on the gasoline gun, when refueling.
Do not smoke while refueling.
Never refuel inside a building or where gasoline fumes may get in contact with an ignition source.
Keep gasoline and engine away from appliance, pilot lights, barbecues, electric appliances, power tools, etc.
⚠️ If the fuel tank has to be drained, this shall be done outdoors

Maintenance and storage

The engine shall be stopped when carrying out maintenance and cleaning operations, when changing tools and when being transported by means other than under its own power.
Check regularly that all bolts and nuts are tightened. Retighten if necessary.
The engine must be completely cooled before storing indoors or covered.
If the machine unused for a period of time, please refer to the instructions in this manual.
Maintain or replace safety and instruction labels, as necessary.
Only use original spare parts or accessories. If not original parts or accessories is used, the liability is no longer applied.
⚠️ Replace faulty silencers.

Miscellaneous

The gears are delivered pre-greased. However, always ensure they are well greased before each use.
The motor is not pre-filled with oil.
⚠ Factory-fitted control devices, such as the handle-mounted clutch cable, must not be removed or exposed.
Only drain the fuel tank outdoors. Gasoline is extremely flammable and the fumes are explosive.
⚠ Ensure that the machine is properly secured when transported on a flatbed etc.
⚠️ Reduce the throttle during engine shutdown and close the fuel valve.

Assembly

Please follow the steps in figure:

(Actual model may vary from the illustration shown.)

1. Box content

A. Extension blades
B. Tiller with cables and support wheels
C. Blades Outer
D. Side guards
E. Handlebar (TX602/TX612)
F. Depth skid
G. Bumper
H. Mounting bracket for handlebar (TX602/TX612)
I. Lower handle x2 (TX601/TX611)
J. Handlebar (TX601/TX611)

1. Only for model TX601 / TX611

Fit the lower handle section. Use the supplied mountings and bolts.

Fit the handle. Use the supplied assembly kit as shown.

1. Only for model TX602 / TX612

Fit the handle into the bracket (1-H) fasten with hand wheel.

NB: Ensure the bolt goes through the spring.

1. Mount clutch handle as shown on the picture.
2. Mount the side guards using the bolts and nuts supplied. Note the side guard has to go under the body.
3. Attach the bumper using the bolts and nuts supplied.
4. Mount the blades using the cotter bolts and pins.

Fill the motor with oil.

See changing the oil section for more details.

Clothing

When using the machine, wear close-fitting work clothes, hard-wearing work gloves, ear defenders and non-slip boots with steel toecaps.

Operating the tiller

⚠ Ensure the machine is placed on a level surface with the support wheels lowered prior to start.
Remove all foreign objects from the work area before using the machine. Stones, glass, branches and similar items may damage the tiller. Also check the bolts on the tiller are tightened.
Start the motor as per the instructions below. Stand clear of the machine's moving parts.
Never attempt to move the machine in any way other than intended for normal use while the motor is running.

The tiller is designed for use in vegetable gardens and flowerbeds. Ensure that you are familiar with these instructions before operating the machine, in particular the motor start and stop procedures.

Fig 10B: To use the black handle the control stick must first be activated. By tilting the control stick to the right or left side and then activate the black handle lever, the tiller will move forward or backwards.

Pay attention while reversing. It is important that the area is cleared, for any obstacle before reversing. Never reverse the tiller against a wall, tree or any other fixed obstacle.

Operation zone

While the machine is being operated and the motor is running, do not leave the operation zone marked fig 11. If it is necessary to leave the operation zone, for example to attach an accessory, first stop the engine.

It is normally necessary to drive the tiller over a section of earth 2-3 times from different directions. Do not till very wet soil, as clods of earth will form that are difficult to break up.

Adjusting the handle

TX602 model only: Fig 3. The handle angle can be adjusted. Use the two hand wheels to set one of the 3 available positions. The handle can be flipped forward during transport. NB: Ensure the cables do not become trapped.

Adjusting the wheel/ depth skid

Fig 12. During operation, it may be necessary to raise the wheel assembly, as it is connected to the depth skid. Depress the pedal to the right of the support wheels to adjust the wheel assembly/depth skid to one of the 3 available positions.

The depth skid can be set to 3 different depths. The deeper it extends into the soil, the deeper the tilling blades will work and the slower the machine will advance. Setting the correct tilling depth will significantly reduce the effort required. The depth skid should always be adjusted to suit the ground conditions. We recommend testing several depths to see which works best.

Lubrication of gearbox

The gearbox is permanently lubricated at the factory, never open the gearbox.

Starting and stopping the engine

Remember: Always check the oil level prior to use!

The oil level must always be between the min. and max. Mark on the dipstick. Always use SAE-30 oil. Use only unleaded 95 octane gas. Never over-fill the gas tank.

Warning: Stay out of dashed zone, while starting the engine! Always start the engine from dotted operation zone See Figure 9.

Starting the engine See fig. 10

1. Set the throttle control on the handle to max.
2. Position the choke at max. Move the choke lever fully to the left. The choke is not required if the motor is hot.
3. Pull the start cord to start the motor. Always feed the start cord back into the motor by hand.
4. When the motor is started, set the choke to minimum (fully to the right) Engage the throttle slightly.

Stopping the engine

1. Set the throttle control to "low" and let the motor run for approx. 30 seconds.
2. When the motor idles, set the throttle control to full stop.

Use the toolbox underneath the breastplate to keep tools handy. Fig 8.

Vibrations may travel up into the handle during use. We therefore recommend taking a break every 2 hours.

Cleaning the tiller

The tiller should be cleaned after use. Use a garden hose to wash off soil and dirt. Remove any grass, etc. from the rotor shaft. The chassis number should only be cleaned with a damp cloth to avoid unnecessary wear. Avoid using a high-pressure washer during cleaning.

Changing the oil

The oil should initially be changed after the first 5 hours of use, and thereafter once per year.

1. Let the motor run for 5 minutes to heat up the oil. This allows the oil to run more freely and makes for a more complete oil change.
2. After 5 minutes, stop the motor. Remove the spark plug cap. Drain the oil by unscrewing the sump plug. Remember to drain the oil into a container of sufficient capacity. NB: The motor must not be tipped backwards more than 45 degrees.
3. Screw the sump plug back in and pour new oil into the motor. Do this by removing the dipstick and pouring in the recommended quantity of oil.
4. Refit the spark plug cap.

Alternatively, use an oil extractor kit.

1. Suck the oil up through the oil filler hole using the syringe. Use the hose to reach the sump.
2. Transfer the used oil to the container.
3. Fill the engine with new SAE-30 oil.
4. Check the oil level using the dipstick.

Remember to dispose of used oil in a safe way. Oil and oil extractor kit are not included

Air filter maintenance

Please inspect and clean the air filter on a regular basis. If the filter has not been cleaned for a longer period, this will have influence on the engines power take-off and the exhaustion.

1. Clean around the air filter before it is removed.
2. Carefully remove the paper filter and check it. Brush it with a soft brush. If it is very dirty, it must be changed. Take care that no dirt gets into the intake of the engine.
3. Wash the black foam element on the right side in warm soapy water.
4. Press the water out of the foam element and let it dry. Put a few drops of SAE-30 oil on the filter to moisten it lightly with oil. Carefully squeeze out any surplus oil. Remount the element.
5. Check that all parts are fitted correctly and the cover closed as shown in the picture.

Spark plug maintenance

• Remove the spark plug cap.
• Brush away any dirt and deposit of the spark plug.
• Loosen the spark plug using a spark plug socket.
• Check the insulation is intact.
• Clean the spark plug using a wire brush.
• Measure the electrode gap 0.7–0.8 mm. Avoid damaging the electrode.
• If it is damaged, replace it with a new one.
• Refit the spark plug.
  • Refit the spark plug cap.

Storage

• If the machine is likely to be stored unused for prolonged periods, follow the instructions below. This will ensure longer machine lifetime.
• Use a garden hose to wash off soil and dirt. Remove any grass, etc. from the rotor shaft. The chassis number should only be cleaned with a damp cloth to avoid unnecessary wear. Avoid using a high-pressure washer during cleaning.
• Wipe the tiller with a damp cloth so that all surfaces are clean. Wipe the surfaces down with an oily cloth to prevent rust.
  • Always store the machine in a dry, clean location.

Troubleshooting

The motor will not start

1. Check the fuel control is set correctly.
2. Check the spark plug.
3. Check there is fresh gas in the tank.
4. See separate motor instructions for further troubleshooting.

The motor is not running smoothly

1. Ensure the throttle control is not set to max.
2. Check there is fresh gas in the tank.

The blades will not rotate

1. Check for stones lodged between the blades.
2. Release any stones by removing the blades.
3. Check the cables are in good working order and fitted correctly.
4. Check the belt is in good working order and fitted correctly.
5. Ensure the belt tensioner is adjusted correctly.

The blades will not stop

1. Stop the engine and contact your dealer.

Noise, vibration and precautionary measures

1. Long-term exposure to noise levels exceeding 85 dB (A) are damaging. Always use ear defenders when the machine is being used.
2. Reduce the running speed of the motor to reduce vibration and noise levels.
3. To reduce noise levels further, only use the machine in an open environment.
4. Vibrations can be reduced further by holding the handle firmly.
5. To avoid disturbing others, the machine should only be used during the daytime.
6. Always wear close-fitting work clothes, hard-wearing work gloves, ear defenders and non-slip boots with steel toecaps.
7. Take a 30-minute break every 2 working hours.
8. A worn belt has to be replaced/ serviced by a authorized dealer

Exterior view of a modern multi-story building with orange brick facade and 'TEXAS' logo on the facade, surrounded by lawn and sky (no signage visible)

Black-and-white photo of a small plow or cutter in a field, with debris and greenery in the background (no visible text or symbols)

Exterior view of a small utility tool in operation on a dirt path, with a person operating it nearby (no signage or text visible)

PRISLISTE - SOMMEREN 1974 INSTRUKTION GARANTI- BETINGELSER

Содержание - РУС

Side guards: used for tilling in between crops, such as carrots/potatoes, to avoid covering the crops in soil. Side guards can also be used for tilling along a wall or stone path, or in soft soil. Item number 91061000100	Fig. 25
Scarifier: used to aerate the lawn and remove underlying dead grass from the lawn. The grass grows greener and stronger, which prevents the grown of moss. The rear bracket is necessary for fitting. Item number 91051500100 + 91057000100	Fig. 18Fig. 30
Push hoe: used to loosen the soil and thus remove weeds on paths and entrances. The rear bracket is necessary for fitting. Item number 91061500100 + 91057000100	Fig. 17Fig. 30
Harrow: used to loosen the soil between crops and thus remove weeds.The rear bracket is necessary for fitting. Item number 91070000100 + 91057000100	Fig. 16Fig. 30
Rake: used to rake paths and entrances with loose stones, for instance pebbles. The rear bracket is necessary for fitting. Item number 91062500100 + 91057000100	Fig. 15Fig. 30
Ridge plough: used to plough up ground for potatoes, carrots and other root crops. The rear bracket is necessary for fitting. Item number 91060500100 + 91057000100	Fig. 20Fig. 30
Digging claws: used if the soil is loose and the machine is to be operated with a ridge plough or harrow instead of wheels. Item number 91060700100	Fig. 22
Snow scraper: used to scrape snow from a solid surface, such as paving slabs. Can be tilted to the left/right. The assembly plate is necessary for fitting. Item number 92000160100 + 91058000100	Fig. 24Fig. 23
Snow chains: used with snow blade if it is very slippery to the machine gives a better grip. Item number 91115000100	Fig. 28
Weight blocks: used to give the machine a better grip when operating with a trailer or snow scraper.Can only be fitted with wheels. Item number 91097000100	Fig. 26Fig. 21
Intermediate blades: used to give the machine a larger tiller width. They also give the machine a smoother ride and can be advantageously used by very loose soil. Item number 91050700100	Fig. 27
Wheels: used to mount accessories, such as rake. Item number 91053000100	Fig. 21
Rear bracket: used to fit accessories. Item number 91057000100	Fig. 30

Zubehör

2006/42/EC - 2004/108/EC

Overensstemmelsesvurdering procedure i henhold til bilag III/VI • Conformity assessment procedure according to Annex III/VI • Konformitätsbewertungsverfahren nach Anhang III/VI • Procédure d'évaluation de la conformité conformément à l'annexe III/VI • Procedura oceny zgodności zgodnie z załącznikiem III/VI • Procedura de evaluare a conformitätii în conformitate cu anexa III / VI • Postupak procjene sukladnosti proveden je prema Aneksu III/IV

2000/14/EC amended by 2005/88/EC

Materiellet er udført i overensstemmelse med følgende standarder • Conforms with the following standards • In Übereinstimmung mit den folgende Standards • Conformément aux normes suivantes • Jest zgodna z następującymi normami • Echipament se face în conformitate cu următoarele standarde • V skladu z naslednjimi standardi • Proizvod je sukladan sa slijedećim standardima

EN 709 : 1997 + A4 - EN 250 14982:2008

TX601TG LWA: 97 dB(A) LPA: 83.2 dB(A) ah = 7.9 m/s² Uncertainty: 1.5m/s² S/N: 1403008210000 -> 1603008299999

TX602TG LWA: 97 dB(A) LPA: 83.2 dB(A) ah = 12.4 m/s² Uncertainty: 1.5m/s² S/N: 1403008410000 -> 1603008499999

TX601B LWA: 97 dB(A) LPA: 85 dB(A) ah = 6.7 m/s² Uncertainty: 1.5m/s² S/N: 1403008310000 -> 1603008399999

TX602B LWA: 97 dB(A) LPA: 85 dB(A) ah = 9.0 m/s² Uncertainty: 1.5m/s² S/N: 1403008510000 -> 1603008599999

TX602R LWA: 97 dB(A) LPA: 85 dB(A) ah = 9.0 m/s² Uncertainty: 1.5m/s² S/N: 1403008610000 -> 1603008699999

TX611TG LWA: 97 dB(A) LPA: 83.2 dB(A) ah = 7.9 m/s² Uncertainty: 1.5m/s² S/N: 1403018010000 -> 1603018099999

TX612TG LWA: 97 dB(A) LPA: 83.2 dB(A) ah = 12.4 m/s² Uncertainty: 1.5m/s² S/N: 1403018110000 -> 1603018199999

Texas Andreas Petersen A/S

Knullen 22 • DK-5260 Odense S

Responsible for documentation

Johnny Lolk, Purchase Manager

01.10.2014

Thomas Dalsgaard

Managing Director
