U280Q01STPBK - Wireless Charger Tripp Lite - Free user manual and instructions

Product Type	Induction wireless charger
Brand	Tripp Lite
Model	U280Q01STPBK (U280-Q01ST-P-BK)
Dimensions (L x W x H)	10.2 x 10.2 x 9.7 cm
Weight	90.7 g
Power Supply	International AC adapter 12 V 2 A included
Output Power	5 W (5 V 1 A) or 10 W (9 V 1.1 A)
Charging Standard	Qi
Fast Charging	Up to 7.5 W for Apple, 10 W for Samsung (with Quick Charge 2.0/3.0 adapter)
Compatibility	Qi-certified smartphones, including Apple iPhone XS Max/XR/XS/X/8/8 Plus and Samsung Galaxy S10/S10+/S10E/S9/S9+/S8/S8+/Note 9/Note 8/S7/S7 Edge/S6 Edge Plus/Note 5
Compatible Case Thickness	Up to 5 mm
LED Indicator	Solid blue: charging; flashing blue: charging error
Protection	Overheat and overcharge protection
Operating Temperature	0 to 35 °C
Storage Temperature	-20 to 70 °C
Operating Humidity	10 to 80% RH (non-condensing)
Storage Humidity	5 to 95% RH (non-condensing)
Care and Cleaning	Unplug before cleaning; wipe with a soft, dry cloth
Safety	Use only the supplied adapter; do not expose to water or extreme temperatures
Spare Parts and Repairability	Not user-serviceable; contact Tripp Lite support
Warranty	2 years (limited)
Package Contents	Charging base, international AC adapter, quick start guide
Color	Black

Frequently Asked Questions - U280Q01STPBK Tripp Lite

Which phones are compatible with the Tripp Lite U280Q01STPBK charger?

The charger is compatible with all Qi-certified smartphones, including Apple iPhone XS Max, XR, XS, X, 8, 8 Plus and Samsung Galaxy S10/S10+/S10E, S9/S9+, S8/S8+, Note 9/8, S7/S7 Edge, S6 Edge Plus and Note 5.

How do I know if charging is in progress?

A solid blue LED indicates that charging is active. If it flashes blue, it means a charging error (misalignment or foreign object).

Can I charge my phone with a case on?

Yes, as long as the case is no thicker than 5 mm and does not contain metal or magnetic elements (magnets, mounts).

What is the maximum charging power?

The charger can deliver up to 10 W (9 V 1.1 A) for compatible Samsung devices, and 7.5 W for iPhones, provided you use a Quick Charge 2.0/3.0 adapter (the supplied adapter is standard).

Is the charger supplied with a power adapter?

Yes, the package includes a multi-function international power supply of 12 V 2 A, with plugs that can be adapted to different countries.

How do I clean the wireless charger?

First unplug it. Use a soft, dry cloth to wipe the surface. Do not use liquid or abrasive cleaners.

What should I do if the LED flashes blue?

This indicates a charging error. Check that the phone is centered on the charging area and that there is no metal object between the base and the device. If the problem persists, try with another compatible phone.

Can I use the charger with a power bank?

The supplied adapter must be plugged into a wall outlet. You can use a power bank if it delivers at least 12 V 2 A and has a compatible plug.

Is the charger compatible with magnetic cases?

No, magnetic or metal accessories (mount magnets, metal plates) prevent charging. Remove them before placing the phone on the base.

What is the warranty for this product?

Tripp Lite offers a limited 2-year warranty against defects in materials and workmanship. It does not cover normal wear, misuse, or accidental damage.

USER MANUAL U280Q01STPBK Tripp Lite

10-Watt Wireless Fast-Charging Charging Stand with International AC Adapter, Black

Model: U280-Q01ST-P-BK

Español 7 • Français 13 • Русский 19 • Deutsch 25

WARRANTY REGISTRATION

Register your product today and be automatically entered to win an ISOBAR® surge protector in our monthly drawing!

tripplite.com/warranty

Manufacturing Excellence.

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

Copyright © 2021 Tripp Lite. All rights reserved. All trademarks are the property of their respective owners.

Product Features

• Universally compatible with all Qi-certified smartphones and other devices*
• Charges your smartphone through its protective case (up to 5 mm) to avoid the hassle of removing it
• Prevents overheating and overcharging to protect your device from damage
• Intelligent LED indicates charging status at a glance
• Slim, lightweight portable design saves space on your desk, bureau or bedside table
  * Compatible with Apple® iPhone® XS Max/XR/XS/X/8/8 Plus and Samsung Galaxy® S10/S10 Plus/S10E/S9/S9 Plus/S8/S8 Plus/Note 9/ Note 8/S7/S7 Edge/S6 Edge Plus/Note 5

Package Contents

• U280-Q01ST-P-BK Wireless Fast-Charging Stand
• Multi-Function International Power Supply (12V 2A)
- Quick Start Guide

Operation

Notes:

• To achieve high-speed charging capabilities (up to 7.5W for Apple devices and 10W for Samsung devices), Quick Charge (QC) 2.0/3.0 adapters are recommended
  • Phone cases thicker than 5 mm may result in slower charging speeds
• Magnetic or metal attachments will prevent charging

• Compatible with Apple iPhone XS Max/XR/XS/X/8/8 Plus and Samsung Galaxy S10/S10 Plus/S10E/S9/S9 Plus/S8/S8 Plus/Note 9/Note 8/S7/S7 Edge/S6 Edge Plus/Note 5

• Connect the included multi-function power supply to the Wireless Fast-Charging Stand.

• Connect the power supply to an available AC wall outlet.
• Place your Qi-compatible device on the wireless charging stand. The LED will turn blue to indicate charging is in progress.*
• Remove your device from the stand when it is fully charged.

* The LED will flash blue to indicate charging error.

Specifications

Input 12V 2A
Output 5V 1A (5W) or 9V 1.1A	(10W)
Qi Compatible Yes
Operating Temperature Range 3	2° to 95°F (0° to 35°C)
Storage Temperature Range -4°	to 158°F (-20° to 70°C)
Operating Humidity Range 10%	to 80% RH, Non-Condensing
Storage Humidity Range 5% to 9	95% RH, Non-Condensing
Size (H x W x D) 0.4 x 4.1 x 4.1	in. / 9.7 x 10.2 x 10.2 cm
Weight 0.2 lb. / 90.7 g
LED Colors/Functions Blue: Power	Flashing Blue: Error in Charging

Warranty and Product Registration

2-YEAR LIMITED WARRANTY

Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship for a period of two (2) years from the date of initial purchase. If the product should prove defective in material or workmanship within that period, Seller will repair or replace the product, at its sole discretion.

THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE OR NEGLECT. SELLER MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED WARRANTIES, INCLUDING ALL WARRANTIES OF MERCHANTABILITY OR FITNESS, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE; AND THIS WARRANTY EXPRESSLY EXCLUDES ALL INCIDENTAL AND CONSEQUENTIAL DAMAGES. (Some states do not allow limitations on how long an implied warranty lasts, and some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may have other rights which vary from jurisdiction to jurisdiction.)

WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate or safe for the use intended. Since individual applications are subject to great variation, the manufacturer makes no representation or warranty as to the suitability or fitness of these devices for any specific application.

PRODUCT REGISTRATION

Visit tripplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!* *No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

Warranty and Product Registration

WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite, they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste

Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended.

Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice. Photos and illustrations may differ slightly from actual products.
