USER MANUAL U436000GB Tripp Lite

Models: U436-000-GB (USB-C to Gigabit Ethernet),

U444-000-DP4K6B (USB-C to 4K DisplayPort),

U444-000-H4K6B (USB-C to 4K HDMI),

U444-000-VGA (USB-C to VGA)

USB Type-C and USB-C are trademarks of USB Implementers Forum

Espanol 11 • Français 20 • Pycckn 29

WARRANTY REGISTRATION

Register your product today and be automatically entered to win an ISOBAR surge protector in our monthly drawing!

www.triplite.com/warranty

Maunacturing

1111 W. 35th Street, Chicago, IL 60609 USA www.triplite.com/support

Copyright © 2019 Tripp Lite. All rights reserved.

All trademarks are the property of their owners.

Product Features

• Add a Gigabit Ethernet, DisplayPort, HDMI, or VGA port via the USB-C port on your laptop, tablet or other device
• Type-C input features a vertical molding to maximize space around your device's ports and prevent blockage of adjacent ports
• U444-000-DP4K6B supports DP 1.2 video resolutions up to 3840 x 2160 (4K x 2K) @ 60 Hz, DisplayPort Alternate Mode, 7.1 Channel Surround Sound, 4:4:4 Color Space, HDCP 2.2 and HDR compatibility
• U444-000-H4K6B supports HDMI 2.0 video resolutions up to 3840 x 2160 (4K x 2K) @ 60 Hz, 7.1 Channel Surround, 4:4:4 Color Space and HDCP 2.2 compatibility
• U444-000-VGA supports video resolutions up to 1920 x 1200 (1080p) @ 60 Hz and 1.62 / 2.7 Gbps over 4 lanes
• U436-000-GB supports full Gigabit Ethernet transmission speeds, Full-Duplex flow control (IEEE 802.3x), is compatible with IEEE 802.3, IEEE 802.3u, IEEE 802.1P Layer 2 priority encoding, IEEE 802.1Q VLAN tagging and IEEE 802.3az-2010 (EEE)

C

Optional Accessories

P580-Series DisplayPort Cables
- N201-Series Cat6 Gigabit Snagless Patch Cables
- P500-Series VGA Coax High-Resolution Cables
P569-Series HDMI High-Speed Cables

Installation

1. Connect the adapter's USB Type-C connector to the USB Type-C port on your smartphone, tablet, Ultrabook or computer.
2. Using a UTP cable (such as Tripp Lite N201-Series Cat6 cables), connect the adapter's RJ45 port to a network.

OR

Using a DisplayPort cable (such as Tripp Lite P580-Series DisplayPort cables), connect the adapter's DisplayPort port to a monitor.

OR

Installation

Using an HDMI cable(such as Tripp Lite P569-Series HDMI cables), connect the adapter's HDMI port to a monitor.

OR

Using a VGA cable (such as Tripp Lite P500-Series VGA cables), connect the adapter's VGA port to a monitor.

1. If using the U444-000-DP4K6B, U444-000-H4K6B or U444-000-VGA adapter, the video image will appear on the add-on monitor. Use your device's display settings to customize how video is displayed on the add-on monitor.

Specifications

Connector Input USB	Type-C (Male) (All models)
Connector Output Ethernet	Ethernet – RJ45 (Female) (U436-000-GB) DisplayPort – DisplayPort (Female) (U444-000-DP4K6B) HDMI – HDMI (Female) (U444-000-H4K6B) VGA – HD15 (Female) (U444-000-VGA)
Maximum Video Resolutions	3840 x 2160 @ 60 Hz (U444-000-DP4K6B, U444-000-H4K6B) 1920 x 1200 @ 60 Hz (U444-000-VGA)
Maximum Ethernet Transmission Speeds	10/100/1000 Mbps (U436-000-GB)

Specifications

Operating Temperature	32°F ~ 104°F / 0°C ~ 40°C (All models)
Storage Temperature	14°F ~ 122°F / -10°C ~ 50°C (U436-000-GB) 5°F ~ 122°F / -15°C ~ 50°C (U444-000-VGA, U444-000-DP4K6B and U444-000-H4K6B)
Relative Humidity 0% ~ 85% RH, Non-Condensing (All models)

Warranty and Product Registration

3-Year Limited Warranty

TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of three (3) years from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment, which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.

Warranty and

Product Registration

Product Registration

Visit www.triplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*

• No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

FCC Notice, Class B

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Warranty and Product Registration

• Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user's authority to operate this equipment.

WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste

Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended.

Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.

1111 W. 35th Street, Chicago, IL 60609 USA www.triplite.com/support

19-07-277 93-3998_RevB

1111 W. 35th Street, Chicago, IL 60609 USA www.triplite.com/support

WEEE Compliance Information for Tripp Lite Customers and Recyclers (Union Européenne)

1111 W. 35th Street, Chicago, IL 60609 USA www.triplite.com/support

PykoBoDCTBO NOIb30BaTeJa

BepTnKaJIbHbIe nepexOdHnKn

USB 3.1 / Type-C

Mодени: U436-000-GB (USB-C / Gigabit Ethernet), U444-000-DP4K6B (USB-C / 4K DisplayPort), U444-000-H4K6B (USB-C / 4K HDMI), U444-000-VGA (USB-C / VGA)

USB Type-C n USB-C yBnIOTcT toproBbIMn 3HaKaAMn KomnaHm USB Implementers Forum

English 1 • Espanol 11 • Français 20

EAC

1111 W. 35th Street, Chicago, IL 60609 USA www.triplite.com/support

OxpaHareTcA BToPcknmpaBOM © 2019 Tripp Lite. IepeneuataK3anpeueHa. BCE ToproBbIe 3NaKn ABnIoTc CO6CTBeHHoCTbIO CBOnx BnaJeNbceB.

XapakTepnCTnKn n3dJIIny

• • Ochactite cBoi Hoyt6yK, pHaHWeT nIu npyroe yctpoiCTBO dOIOHNHeBHyIM nopToM Gigabit Ethernet, DisplayPort, HDMI nIu VGA uepe3 nmeoucnS npT USB-C
    Bxodno pa3bem Type-C nmeet BepTKaIbHyIO opneHTaunIO, o6ecneuBaIOyIO MaKcMaIbHOe CBO6OJHOe IPOCTpaHCTBO BOKpyr NOpTOB yCTpoICTBa I NCKJIIOUaIOU IO BO3MOXHOCTb NepeKpbIBaHnA COSeDnHX NOPTOB
    MoIb U444-000-DP4K6B noIepeXnBaet BndeopazpeHnA cTaNapTa DP 1.2 do 3840 x 2160 (4K x 2K) npu 60 T, peXm DisplayPort Alternate, aynofoopmat 7.1 Channel Surround Sound, CBeTOByIO cy6DnCKpeTn3aunio 4:4:4, texnoIognIO HDCP 2.2 n COBMeCTNMOCTb C yHKnnei HDR
    MoIeIb U444-000-H4K6B noIepeKnBaet BnIeopa3peHnA CTaIapTa HDMI 2.0 do 3840 x 2160 (4K x 2K) npu 60 T, ayIIOΦopMaT 7.1 Channel Surround Sound, uBeToByIO cy6IusckpeTu3aunio 4:4:4 nTexHoIorMu HDCP 2.2
    MoIb U444-000-VGA noIeepKnBaet BndeopazpeHnra 1920x1200(1080p) npu 60Tn cKOpocn nepeaun daHbIX 1,62/2,7Γ6nt/cno 4 KaHaam
    MoIeIb U436-000-GB noIeepKuBaet ckopocn nepeaun BO Bcem dnaa3oHe Gigabit Ethernet, ynpabLeHne nToKamn B noIHOyPnEckHom peXmme (IEEE 802.3x), a taKxe coBMeCTIma co cTaHapTaMn IEEE 802.3, IEEE 802.3u, cTaHapTom npOpHTHO r KoDnpoBaHnra IEEE 802.1P Layer 2, cTaHapTom TerIpOBaHnra TpaΦnka BnptyaJIbHoJ loKaJIbHoJ cEtN IEEE 802.1Q n cTaHapTom IEEE 802.3az-2010 (EEE)

XapakTepnCTnKn n3dennia

• ABTomatnuecka NaCTPOkKa npi NODKJIuOeHnn NO TexHOJOrn Plug-and-play 6e3 Heo6xOIMocTn IcNoIb30BaHn nporpaMMHoro 06ecneueHn nn dpaBepOB
