Product Features

• Add an additional 4K HDMI monitor via the USB-C or Thunderbolt™ 3 port on your laptop, tablet or other device
  Supports USB DisplayPort Alternate Mode, allowing you to transmit an audio/video signal via the USB Type-C port on your smartphone, tablet, Ultrabook or computer
• U444-06N-HD4K6W supports HDMI 2.0 video resolutions up to 3840 x 2160 (4K x 2K) @ 60 Hz as well as HDCP 2.2 compatibility
  Supports 24-bit Deep Color (8 bits per channel) max
  Supports max data transfer rates of 5.5 Gbps
  Supports 7.1 surround sound audio
  Thunderbolt 3 port compatible
• Specifically designed for use with the MacBook®, Google Chromebook Pixel™ and USB Type-C supported computers
• Slim design is perfect for travel and stores easily in your laptop bag when not in use
• Plug-and-Play; no software or drivers required

Package Contents

U444-06N-HD4K6W
- Owner's Manual

System Requirements

• USB Type-C or Thunderbolt 3 device that supports USB DisplayPort Alternate Mode
  HDMI monitor

Optional Accessories

P568-Series High-Speed HDMI Cables
- P569-XXX-CERT Premium High-Speed Cables with Gripping Connectors

Installation

1. Connect the USB Type-C connector on the adapter to the USB Type-C port on your smartphone, tablet, Ultrabook or computer.
2. Connect the HDMI port on the adapter to a monitor using an HDMI cable (such as Tripp Lite's P568-Series HDMI cables).
3. The video image will appear on the add-on monitor. Customize how video is displayed on the add-on monitor using your device's display settings.

Specifications

Connectors
Input USB-C (Male)
Output HDMI (Female)
Video
Maximum Resolution 38	40 x 2160, UHD 4K, @ 60 Hz
Color Depth 24-bit Deep	Color (8 bits per channel)
Environmental
Operating Temperature	32° to 113°F (0° to 45°C)
Storage Temperature 14	to 158°F (-10° to 70°C)
Relative Humidity 5% to	90% RH, Non-Condensing
