USER MANUAL Multi 78515 UNOLD

Power: 350 watt, 220-240 V~, 50-60 Hz Dimensions: approx. 19.1 x 15.7 x 24.6 cm (L/W/H) Weight : approx. 1.6 kg Power cord: approx. 95 cm Degree of protection: II Container volume: approx. 1.2 l Material: Plastic/glass/stainless steel Features: Chops, mixes, and cuts food, such as vegetables, herbs, meat; chopping knife with two blades Accessories: Chopping knife, operating instructions with recipes Equipment features, technology, colours and design are subject to change without notice. Errors and omissions excepted

INSTRUCTIONS FOR USE MODEL 78515

TECHNICAL SPECIFICATIONS Please read the following instructions and keep them on hand for later reference. Instructions concerning the persons in the household

1. This appliance can be used by children 8 years and older, as well

as by persons with reduced physical, sensory or mental abilities or with lack of experience and/or knowledge, if they are supervised or if they have been instructed with regard to safe use of the appliance

EXPLANATION OF THE SYMBOLS

This symbol indicates potential hazards that may result in injury or damage to the appliance. SAFETY INFORMATION Copyright UNOLD AG | www.unold.de20 von 76 Stand 11.3.2020

and have understood the dangers that can result from use of the appliance.

2. Children must not play with the appliance.

3. Children are not allowed to perform cleaning and user maintenance,

unless they are 8 years of age or older and are supervised.

4. Keep the appliance and the power cord out of the reach of children

under 8 years of age. Electrical safety

5. This appliance must not be operated with an external timer or a

remote control system.

6. After use, before cleaning or if there are faults during operation,

always unplug the mains plug.

7. The power cord must be protected against moisture.

8. The motor block should never come into contact with water or other

liquids. If this should occur, the base must be completely dry before operating the appliance again.

9. The appliance is intended for household use only, or for similar

areas of use, such as, kitchenettes in businesses, offices or other workplaces, in agricultural enterprises, for use by guests in hotels, motels or other lodgings, in private guest houses or holiday homes.

10. The appliance is not dishwasher safe.

11. For safety reasons do not, under any circumstances, place or operate

the appliance and power cord on or in the vicinity of hot surfaces.

12. Completely unwind the power cord before use.

13. The power cord must not hang down over the edge of the work sur-

14. Do not place the appliance or power cord near open flames during

15. Do not, under any circumstances, leave the appliance unattended

when the mains plug is plugged in.

16. Check the power plug and the power cord regularly for wear or

damage. If the power cord or other parts are damaged, send the appliance to our customer service department for inspection and repair. Unauthorised repairs can result in serious risks for the user and void the warranty. Instructions for set-up and safe use of the appliance

17. Place the appliance on a free and level surface.

18. Only use the appliance indoors.

19. The blades of the chopping knife are very sharp. Handle the chop-

ping knife with appropriate caution and ensure that the other users of the appliance are also aware of the danger.

20. Keep the chopping knife away from children and animals.

21. For hygienic reasons clean the appliance immediately after prepa-

dients 0.3-0.5 l. If you overfill the container with ingredients, this could damage the appliance.

23. If you clean the chopping knife in rinsing water, do not let it sit in

the water for a longer period of time. Otherwise there is danger of injury.

24. Ensure that the appliance does not come into contact with hot sur-

25. Remove the cutting insert from the appliance when you move the

appliance or stow it for safekeeping.

26. Switch off the appliance via the ON/OFF switch and unplug the

mains plug, before changing the accessories or cleaning the appli- ance.

27. Do not open the appliance until after it has come to a standstill.

28. Likewise, always unplug the mains plug when you leave the appli-

29. Do not, under any circumstances, switch on the appliance if the

chopping knife is not attached or the glass container is empty.

30. The brief operating time is 2 minutes. Thereafter allow the appli-

ance to cool several minutes before placing it in service again.

31. Do not use the appliance with accessories of other manufacturers or

brands. Such use could damage the appliance.

32. Caution: Avoid contact with moving parts of the appliance when it is

in operation. Keep hands, hair or other objects away from the appli- ance: Danger of injury! The blades of the chopping knife are very sharp – danger of injury! Do not, under any circumstances, touch moving parts on the appliance and do not put objects or body parts into the appliance when it is running. Otherwise there is danger of injury. Never open the housing of the appliance. This can result in electric shock. The manufacturer will not be liable in the event of incorrect assembly, improper or incorrect use or if repairs are carried out by unauthorized third parties.

1. Remove all packaging materials and any transport safeguards. Keep packaging materials away

from children – danger of suffocation!

2. Clean the appliance as described in the section „Cleaning and care“ with a damp cloth and

3. Attach the supplied anti-slip ring on the outside of the glass container.

Chopping of vegetables, fruits, bread and rolls for making bread crumbs, meat, chocolate, nuts. You will get very good results if you first cut the ingredients into approx. 1-inch cubes.

1. Attention: Do not switch on the appliance without first putting ingredients in the mixing bowl,

since this can damage the motor.

2. Ensure that the appliance is switched off via the ON/OFF switch.

3. Remove the knife guard from the chopping knife.

Only grasp the knife on the upper pin, the blades of the knife are very sharp. Danger of injury.

4. Place the chopping knife on the shaft in the glass container. The

knife must be firmly seated.

5. Prepare the desired food. Cut meat, vegetables and fruit (it may

be necessary to peel the fruit beforehand) into small cubes.

6. Put the food in the glass container. Ensure that the MAX mark

on the glass container is not exceeded to prevent appliance damage. In this regard, bear in mind that many food items, such as meat, develop more volume through the chopping process.

7. Place the lid on the bowl

8. Fit on the motor block.

9. Plug the power cord into an electrical outlet.

10. Press the ON/OFF button. The appliance works in brief, forceful thrusts as long as you press

11. If ingredients adhere on the inside of the container, switch off the appliance unplug the power

cord, wait until the chopping knife has come to a standstill, and then remove the ingredients with a dough scraper.

12. When the ingredients have reached the desired consistency, release the ON/OFF button and

unplug the mains plug from the electrical outlet.

13. Wait until the chopping blade has come to a standstill.

14. Remove the motor block and the lid.

15. Carefully remove the chopping knife from the glass container. Only grasp the knife on the

upper pin, the blades of the knife are very sharp. Danger of injury.

16. Remove the ingredients from the glass container.

17. As soon as all parts have been cleaned, fasten the blade guard back onto the chopping blade

to prevent injuries. The chopping knife is very sharp – danger of injury! Food maximum capacity Operation cycles Operation time Preparation Meat 300g 3 15 seconds remove the bone,cut the fat and Piece of cartilage into 1 or 2 cm Parsley 80g 1 15 seconds Remove the rib Nut (almond,etc.) 300g 3 15 seconds Remove the rib Cheese 150g 2 10 seconds Cut into 1 to 2cm chunk Bread 120g 1 15 seconds Cut into 1 to 2cm chunk Boiled egg 300g 1 10 seconds a half or a quarter Carrot /onion 400g 3 15 seconds cut into 2cm size Biscuit 250g 2 10 seconds breaking into squares Berries 500g 3 15 seconds Remove the rib Copyright UNOLD AG | www.unold.deStand 11.3.2020 25 von 76

Release the ON/OFF button and unplug the plug from the electrical outlet. Do not, under any circumstances, immerse the appliance in water or other liquids in order to clean it.

1. Wipe off the motor block and the lid with a damp cloth, and then dry it thoroughly.

2. Rinse off the chopping knife under running water, to remove food residues. Attention: The

chopping knife is very sharp!

3. Ideally use a dish-washing brush to do this, to avoid injuries due to the blades.

4. Allow the chopping knife to dry completely before reusing it.

5. The glass container (without anti-slip ring) can also be cleaned in the dishwasher. Please use

a program with a low temperature, to avoid damaging.

6. Select a dry, dust-free location for storage. Tip: Keep the appliance packaging on hand and

store the appliance in this box when the appliance is not in use. RECIPES Minced meat (pork loin) 150 g pork schnitzel, 1/2 onion, 1 egg yolk, salt, pepper Finely chop all ingredients with the chopping knife. You can also use the chopping blade for chocolate, herbs, nuts, dry bread crumbs, cheese, hor- seradish, ginger, etc. Liver dumplings as soup garnish 150 g beef liver, 1/2 onion, 1 softened, breakfast bun (squeezed out), 2 TBSP breadcrumbs, 1 egg, salt, pepper, nutmeg Finely chop all ingredients with the chopping knife. Heat 1 litre beef broth. Using a small teaspoon, spoon small amounts of the mixture into the boiling liquid and let steep until done. Copyright UNOLD AG | www.unold.de26 von 76 Stand 11.3.2020

The authors have thoroughly considered and tested the recipes included in these operating instructions. Nevertheless, a guarantee cannot be accepted. The authors, respectively UNOLD AG and their assignees shall not be liable for personal injuries, material damages and financial loss. Basil pesto 2 TBSP pine nuts, 1-2 handfuls of basil leaves, 1 garlic clove, 2-3 TBSP olive oil, 1-2 TBSP grated Parmesan, salt and pepper to taste Roast the pine nuts in a pan (dry without adding oil) and then let them cool. Put the basil leaves, the pine nuts, the peeled garlic clove, the oil and the Parmesan cheese in the food chopper and purée the mixture to the desired consistency. Season with salt and pepper. Copyright UNOLD AG | www.unold.deStand 11.3.2020 27 von 76

Our appliances are produced on a high quality level for a long lifetime. Regular maintenance and expert repairs by our after-sales service can extend the useful life of the appliance. If an appliance is defective and repair is not possible we ask you to follow the following instructions for disposal. Do not dispose this appliance together with your standard house- hold waste. Please bring this product to an approved collection point for recycling of electric and electronic products. By separate collection and disposal of waste products you help to protect natural resources and ensure, that the product is disposed in an adequate way to protect health and environment. We grant a 24 months guarantee, and in case of commercial use a 12 months guarantee, starting from the date of purchase for any damage demonstrably due to manufacturing defects and when the appliance has been used according to its intended use. Within the warranty period we will remedy defective materials or workmanship through repair or replacement, at our option. Our warranty terms apply only to appliances sold in Germany and Austria. For other countries, please contact the responsible importer. In the event of a claim for remedy of defects, please send the appliance to our after sales service, properly packaged, together with a copy of the automatically generated sales receipt, which must show the date of purchase, and a description of the defect. You can print out a return receipt on our website www.unold.de/ruecksendung. (only for entries from Germany and Austria). The warranty does not cover damage from normal wear, improper handling and failure to comply with the maintenance and care instructions. The warranty is void if repairs or modifica- tions are made to the appliance by third parties. Any claims of the end consumer vis-à-vis the retailer are not limited by this warranty. GUARANTEE CONDITIONS The instruction booklet is also available for download: www.unold.de Copyright UNOLD AG | www.unold.de28 von 76 Stand 11.3.2020
