USER MANUAL RL313D4AW1 HISENSE

~14 What to do if... 17WARNING—Food needs to be packed in bags before putting into the refrigerator, and liquids need to be packed in bottles or capped containers to avoid the problem that the product design structure is not easy to clean.-Avoid opening flames and sources of ignition. -Thoroughly ventilate the room in which the appliance is situated1.Controller box and LED light 2.Refrigerator shelf 3.Vegetable drawer cover 4.Vegetable drawer 5.Adjustable bottom feet 6.Handles 7.Upper door shelf 8.Lower door shelf 9.Refrigerator door5. Remove the door from the lower hinge . NOTE: When removing the door, watch for washer(s) between the lower hinge and the bottom of the lower door that may stick to the door. Do not lose.6. Place it on a smooth surface with its panel upwards. Loose screw ②

tighten securely. and pard then install them to the left side and 7.Lay the refrigerator on soft foam

9. Transfer the door to the property

door. 10.Transfer the upper hinge part and make the upper hinge axis into the upper hole of the door, and adjust the position of the door (please support the door with your hand when doing it), fixing the upper hinge part with the special flange self-tapping screws.12. Move the handle from the left side of door to the right side .

Noises during Operation The following noises are characteristic of refrigeration appliances: Clicks Whenever the compressor switches on or off, a click can be heard. Humming As soon as the compressor is in operation, you can hear it humming. Bubbling When refrigerant flows into thin tubes, you can hear bubbling or splashing noises. Splashing Even after the compressor has been switched off, this noise can be heard for a short time. Energy saving tips Do not install the appliance near cookers, radiators or other sources of warmth. Do not open the door too often or leave the door open any longer than necessary. Do not set temperature colder than necessary. Make sure the side plates and back plate of the appliance are with some distance from the wall, follow the instructions relevant to installation. I f s k e t c h m a p s h o w s t h e r i g h t combination of the drawers, crisper and shelves, do not adjust the com -bination, it would result in more energy-consuming. Hints for refrigeration Meat(all types): wrap in polythene bags and place on the glass shelf above the vegetable drawer.For safety, store in this way only one or two days at the most. Cooked foods, cold dishes, etc…: these should be covered and may be placed on any shelf.Fruit and vegetables: these should be thoroughly cleaned and placed in the special draw(s) provided. Butter and cheese: these should be placed in aluminum foil or polythene bags to exclude as much air as possible . Milk bottles: these should have a cap and should be stored in the bottle rack on the door has a strong flavor. Position food so that air can circulate freely around. Hints for fresh food refrigeration To obtain the best performances: Do not store warm foods or evaporating liquids in the appliance. Do cover or wrap the food, particularly if itCleaning and Care Cleaning and Care For hygienic reasons the appliance interior, including interior accessories, should be cleaned regularly. The fridge should be cleaned and maintained at least every two months. Warning! Danger of electrical shock! The appliance should not be connected to the mains during cleaning. Before cleaning switch the appliance off and remove the plug from the mains, or switch off or turn out the circuit breaker or fuse. Important! Never clean the appliance with a steam cleaner. Moisture could accumulate in electrical components, Hot vapors can lead to the damage of plastic parts. Ethereal oils and organic solvents can attack plastic parts, e.g. lemon juice or the juice from orange peel, butyric acid, cleanser that contain acetic acid.Do not allow such substances to come into contact with appliance parts. Do not use any abrasive cleansers. Clean the appliance and the interior accessories with a cloth and lukewarm water. Commercially available dish washing detergents may also be used. After cleaning wipe with fresh water and clean dish cloth. Accumulation of dust at the condenser increases energy consumption, clean the condenser at the back of the appliance once a year with a soft brush or a vacuum cleaner. Check the water drain hole on the rear wall of the refrigerator compartment. Clear a blocked drain hole with the aid of something like soft green peg, be careful not to make any damage to the cabinet by sharp things. After everything is dry place appliance back into service. Remove the food from the appliance before cleaning. Store them in a cool place, well covered. Defrosting Why defrosting Water contained in food or getting into air inside the fridge be opening doors may form a frost layer inside. It will weaken the refrigeration when the frost is thick. While it is more than 10mm thick, you should defrost. Defrosting in fresh food storage compartment It is automatically controlled by switching the temperature regulator on or off so that there is no need of operation of defrosting. Water from defrosting will be drained into an drip tray through a drain pipe at the back of the fridge automatically. Go out of use for a long time Remove all refrigerated packages. Switch off the appliance by turning the temperature regulator to position “0”. Remove the mains plug or switch off or disconnect the electricity supply. Clean thoroughly (see section: Cleaning and Care) Leave the door open to avoid the build up of odors. Note:If the appliance contains freezer compartmentWhat to do if… Warning! Before trouble shooting, disconnect the power supply. Only a qualified electrician of competent person must carry out the trouble shooting that is not in the manual. Important! There are some sounds during normal use(compressor, refrigerant circulation) Important! Repairs to refrigerators/freezers may only be performed by competent service engineers. Improper repairs can give rise to significant hazards for the user. If your appliance needs repairing, please contact your specialist dealer or your local Service Force Center. Problem Possible cause Solution Appliance does not work. Appliance cools too much. Appliance is not switched on. Mains plug is not plugged in or is loose. Fuse has blown or is defective. Socket is defective. Temperature is set too cold. Switch on the appliance. Insert mains plug. Check fuse, replace if necessary. Mains malfunctions are to be corrected by an electrician. Turn the temperature regulator to a warmer setting temporarily. The food is too warm. Interior lighting does not work. Unusual noises. The compressor does not start immediately after changing the temperature setting. Water on the floor or storage shelves. Temperature is not properly adjusted. Door was open for an extended period. A large quantity of warm food was placed in the appliance within the last 24 hours. The appliance is near a heat source. Light bulb is defective. Door seal is not air-tight (possibly after reversing the door). Appliance is not level. The appliance is touching the wall or other objects. A component, e.g. a pipe, on the rear of the appliance is touching another part of the appliance or the wall. This is normal, no error has occurred. Water drain hole is blocked. Please look in the “initial Start Up” section. Open the door only as long as necessary. Turn the temperature regulation to a colder setting temporarily. Please look in the “installation location” section. Please look in the “changing the Light Bulb “section. Carefully warm the leaking sections of the door seal with a hair dryer(on a cool setting). At the same time shape the warmed door seal by hand such that it sits correctly. Readjust the feet. Move the appliance slightly. If necessary, carefully bend the component out of the way. The compressor starts after a period of time. See the “cleaning and care” section. Heavy build-up of frost, possibly also on the door seal.Disposal of the appliance Correct Disposal of this product It is prohibited to dispose of this appliance in domestic household waste. Packaging materials Packaging materials with the recycle symbol are recyclable. Dispose the packaging in a suitable collector container to recycle it. Before disposal of appliance.

1. Disconnect the mains plug from the mains socket.

2. Cut off the mains cable and discard it.

This symbol on the product or in its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local council, your household waste disposal service or the shop where you purchased the product.~

9. Transfer the door to the property

1. Disconnect the mains plug from the mains socket.

2. Cut off the mains cable and discard it.

This symbol on the product or in its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local council, your household waste disposal service or the shop where you purchased the product.~
