LayZSpa 60117 - Pool BESTWAY - Free user manual and instructions
Find the device manual for free LayZSpa 60117 BESTWAY in PDF.
📄
Document temporarily unavailable
The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product type | Inflatable spa |
| Brand | Bestway |
| Model | LayZSpa 60117 |
| Category | Pool / Spa |
| Power supply | 220-240 V AC, 50 Hz, single-phase |
| Total power | 2050 W at 20 °C |
| Heating power | 2000 W |
| Massage system power | 800 W |
| Main functions | Heating, filtration, massage, energy-saving timer, Freeze Shield™ |
| Adjustable temperature range | 20 °C (68 °F) to 40 °C (104 °F) |
| Filtration type | Filter cartridge (weekly replacement recommended) |
| Freeze protection system | Freeze Shield™ keeps water between 6 °C and 10 °C |
| Electrical safety device | PRCD (10 mA residual current device) integrated in the power cord |
| Equipotential bonding | Terminal for copper conductor 2.5 mm² minimum |
| Material | TriTech PVC or standard PVC depending on version |
| Color | Gray / white (depending on model) |
| Spare parts available | Filter cartridges, patches, gaskets, plugs, pump |
| Repairability | PVC repair patch; support via bestwaycorp.com/support |
| Water maintenance | pH 7.4-7.6; free chlorine 2-4 ppm; water change every 3 days without chemicals |
| Winter use | Possible down to -10 °C with active heating and Freeze Shield™ |
Frequently Asked Questions - LayZSpa 60117 BESTWAY
How to install the LayZSpa 60117?
Choose a flat, smooth, and solid surface. Unpack the spa, inflate it using the provided pump (ambient temperature >15 °C recommended). Connect the pump to the spa, plug it into a grounded outlet. Fill with water to the indicated level. Follow detailed instructions in the manual.
What is the heating time to reach 40 °C?
The time varies depending on initial water and ambient temperature. For example: from 10 °C to 40 °C: about 18.5 h; from 20 °C to 40 °C: 11.5 h. Always use the cover to reduce heating time.
How to maintain the spa water?
Regularly test pH (7.4-7.6) and free chlorine (2-4 ppm). Use chlorine or bromine tablets in the provided dispenser. Change water every 3 days if no treatment is applied. Clean filter cartridges daily and replace them weekly.
What to do if the spa displays an error code?
Error codes indicate issues with water flow, temperature, or thermostat. Refer to the 'Error codes' table in the manual. Solutions include: check the sealing plugs, clean filters, unplug/replug, or contact support via bestwaycorp.com/support.
How to use the Freeze Shield™ system in winter?
Keep the heating on continuously when the outside temperature drops below 6 °C. Freeze Shield™ automatically keeps water between 6 °C and 10 °C. Do not cut off power. If you are away for a long time, disassemble and store the spa.
Can I use the spa during a storm or in the rain?
No, to avoid any risk of electrocution, never use the spa in rain, storm, or lightning. Unplug it and cover it.
How to clean the spa and filter cartridges?
For cartridges, remove and rinse with clean water (do not put in dishwasher). For the spa, use a soft cloth and mild soap, rinse thoroughly. Do not use abrasive products. Dry completely before storage.
What to do if the pump does not heat?
Check that the set temperature is higher than the water temperature, the filter cartridge is clean, the spa is covered, and the pump hasn't triggered the thermal cutoff. Perform a reset (Reset button) if necessary.
How to repair a tear in the spa?
Use the provided patch. For standard PVC: clean, peel the patch, apply on the area, wait 30 seconds. For TriTech PVC: use additional glue. Wait 30 minutes before reinflating.
Can the spa be used by children?
Yes, but under constant adult supervision. Children under 5 are most at risk of drowning. Set temperature to max 38 °C for young children. Never leave children unattended.
