| Product type | Industrial floor scrubber |
| Brand | Kärcher |
| Model | B 150 R |
| Working width | 1500 mm |
| Solution tank capacity | 200 L |
| Recovery tank capacity | 200 L |
| Weight (with battery) | 1200 kg |
| Dimensions (L x W x H) | 2200 x 1500 x 1500 mm |
| Power supply | Battery 24 V, 500 Ah (lead-acid or lithium) |
| Average runtime | 4 to 6 hours |
| Cleaning system | Rotating brushes, pre-brush, suction |
| Main functions | Simultaneous cleaning and drying, pressure adjustment, detergent dosing |
| Maintenance and cleaning | Regular rinsing of tanks, cleaning of filters, checking of brushes |
| Safety | Emergency stop, indicator lights, low level alarm |
| Spare parts and repairability | Available from Kärcher service, repairability ensured |
Frequently Asked Questions - B 150 R Kärcher
How to start the Kärcher B 150 R?
Check that the battery is charged. Sit on the seat, the safety engages. Turn the ignition key to the on position. Use the steering and brush controls to start cleaning.
What type of battery to use?
The B 150 R uses a 24 V battery, in lead-acid or lithium technology. The recommended capacity is 500 Ah. Use only original Kärcher batteries.
How to clean the tanks?
After each use, empty the solution and recovery tanks. Rinse with clean water, especially the recovery tank to avoid bad odors. Clean the filters regularly.
How often to replace the brushes?
The brushes should be checked every 50 hours of use. Replace them when the bristles are worn or no longer clean effectively. Use original Kärcher brushes.
What to do in case of malfunction?
Refer to the user manual for error codes. Check fuses and connections. If the problem persists, contact Kärcher after-sales service.
How to adjust the brush pressure?
Use the pressure adjustment located on the control panel. Adjust according to floor type: hard floors require lower pressure, heavily soiled floors higher pressure. Do not exceed the indicated maximum pressure.
Can I use detergents?
Yes, you can use detergents suitable for scrubbers. Use foaming products with caution. Follow the dosages recommended by Kärcher to avoid damaging the machine.
What daily maintenance to perform?
Clean the brushes and squeegee blades. Check the battery level and recharge if necessary. Inspect the condition of the filters and hoses.
Where to find spare parts?
Spare parts are available from authorized Kärcher dealers. You can also order online on the official website or via the parts service at 0800 000 000 (example number).
How to store the machine in case of prolonged inactivity?
Thoroughly clean the machine, empty the tanks, and disconnect the battery. Store it in a dry and frost-free place. Recharge the battery every month to maintain its capacity.
