USER MANUAL Peter little STADLER FORM

2. Connection for network adapter

5. Button for the selection of the speed level: 1–4

9. Air inlet with washable air filter

Important safety instructions Please read through the operating instructions carefully before you use the appliance for the first time and keep them safely for later reference; if nec- essary pass them on to the next owner.

• Never insert objects into the grille of the fan. Do not cover the appliance during operation.

• Always disconnect the power cord from the socket before removing the protection grille.

• Only connect the cable to alternating current. Observe the voltage infor- mation given on the appliance.

• Do not use damaged extension cords. English

• Stadler Form refuses all liability for loss or damage which arises as a result of failure to follow these operating instructions.

• The appliance is only to be used in the home for the purposes described in these instructions. Unauthorised use and technical modifications to the appliance can lead to danger to life and health.

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or in- struction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

• Never leave any parts of the packing within the reach of children.

• If the supply cord is damaged, it must be replaced by the manufacturer, or its service agent, or a qualified person in order to avoid a hazard.• Do not run the power cord over sharp edges and make sure that it does not get trapped.

• Do not pull the plug from the socket with wet hands or by holding on to the power cord.

• Do not use the appliance in immediate vicinity of a bath tub, a shower or a swimming pool (observe a minimum distance of 3 m). Place the appliance such that a person in the bath tub cannot touch the appliance.

• Do not place the appliance near a heat source. Do not subject the power cord to direct heat (such as a heated hotplate, open flames, hot iron sole plates or heaters for example). Protect power cords from oil.

• See to it that the appliance is properly positioned to ensure a high stability during its operation and make sure that no one can trip over the power cord.

• The appliance is not splash-proof.

• For indoor use only.

• Do not store the appliance outdoors.

• Store the appliance in a dry place inaccessible to children (pack the ap- pliance).

• Prior to any maintenance, cleaning and after each use, switch off the ap- pliance and unplug the mains cable from the socket.

• Repairs to electrical appliances must only be carried out by a qualified electrical technician.

• Only use the adapter provided by the manufacturer. Setting up / operation

1. Place Peter little in the desired location on a flat surface. Connect the

power adapter (1) to the appliance (2) and insert the adapter into a suit- able mains socket.

2. Switch on the appliance by pressing the On/Off button (3). The appliance

gives an audible signal when a setting is changed via the control panel (4).

3. Press the button for the selection of the speed level (5) to change the

fan speed (levels 1–4). Pressing once increases the speed by one level. If you would like to increase the speed by another level, press again.

4. Activate swing mode by pressing the swing mode button (6). The appli-

ance now swings at an angle of approx. 70° to ensure optimum distribu- tion of cooling air throughout the room. Press the swing mode button (6) again if the appliance is to remain at a certain angle.

5. Press the button for the selection of “Natural Breeze” mode (7) for natu-

ral wind conditions. The blue LED beneath the button (7) will now light up. This mode provides an even more pleasant cooling effect, simulat- ing a natural breeze. The fan speed of this breeze automatically varies depending on the selected speed level.

6. Switch off the appliance by pressing the on/off button (3).

7. If you find the lamps too bright (in a bedroom for example), you may

reduce the light intensity by pressing the “Natural Breeze” button (7). You can choose between three different modes:

• Normal mode (default mode)

• Dimmed mode (push once for 3 seconds)

• Lights-out mode (push twice for 3 seconds)

• By pushing the “Natural Breeze” button once more for 3 seconds, you can go back into normal mode.Cleaning Prior to any maintenance, cleaning and after each use, switch off the appli- ance and unplug the mains cable (1) from the socket. Attention: Never submerge the appliance in water (danger of short-circuit).

• For external cleaning, rub with a damp cloth and then dry thoroughly.

• Make sure that the air inlet (9) and air outlet (8) are cleaned regularly to prevent the build-up of dust. The air outlet (8) can be cleaned with a dry brush or a vacuum cleaner. The air inlet screen (9) is fitted with an air filter which can be removed and cleaned with a damp cloth. Remove the filter by removing the screw on the air inlet screen (9). After cleaning, ensure that the air filter is completely dry and that the screw is firmly tightened again. Repairs

• Repairs to electrical appliances must only be carried out by a qualified electrical technician. If improper repairs are carried out, the warranty lapses and all liability is refused.

• Never operate the appliance if the adaptor or plug is damaged, after it has malfunctioned, if it has been dropped or has been damaged in any other way (cracks/breaks in the casing).

• Do not push any object into the appliance.
