USER MANUAL Spuma G10146 G3 Ferrari

Technical model: MF-3150

Exterior view of a modern stainless steel French water heater with black handle and control buttons (no text or symbols on body)

Montalatte - Milk Frother

SPUMA

ITA: INDICE

Simbologia.... p. 2

Waste of electric and electronic equipment (WEEE

Directive)....p. 24

PORTUGUESE...... p. 11

ESPAÑOL......p. 15

FRANCAIS p. 19

CLASSI DI PROTEZIONE / PROTECTION CLASSES

ATTENZIONE RISCHIO DI SCOSSE ELETTRICHE NON ESPORRE A PIOGGIA E UMIDITA'

WARNING ELECTRIC SHOCK RISK DO NOT EXPOSE TO RAIN OR MOISTURE

ATTENZIONE: NON APRITE L'APPARECCHIO. ALL'INTERNO NON VI SONO COMANDI MANIPOLABILI DALL'UTENTE NE' PARTI DI RICAMBIO. PER TUTTE LE OPERAZIONI DI SERVIZIO RIVOLGERSI AD UN CENTRO DI ASSISTENZA AUTORIZZATO.

This symbol warns the user that un-insulated dangerous voltage inside the system may cause an electrical shock. Do not open the case.

Class I Appliance symbol. This means the appliance must have the chassis connected to electrical earth/ground by an earth conductor.

Caution: this symbol reminds the user to read carefully the important operations and maintenance instructions in this owner's guide.

AVVERTENZE DI SICUREZZA

Labeled diagram of a kitchen appliance showing five parts with Chinese annotations

ENGLISH: SAFETY INSTRUCTIONS

The following are important notes on the installation, use and maintenance; save this instruction manual for future reference; use the equipment only as specified in this guide; any other use is considered improper and dangerous; therefore, the manufacturer cannot be held responsible in the event of damages caused by improper, incorrect or unreasonable use.

Before use, ensure the equipment is undamaged; if in doubt, do not attempt to use it and contact the authorized service center; do not leave packing materials (i.e. plastic bags, polystyrene foam, nails, staples, etc.) within the reach of children as they are potential sources of danger; always remember that they must be separately collected. Make sure that the rating information given on the technical label are compatible with those of the electricity grid; the installation must be performed according to the manufacturer's instructions considering the maximum power of the appliance as shown on the label; an incorrect installation may cause damage to people, animals or things, for which the manufacturer cannot be considered responsible thereof.

If it is necessary to use adapters, multiple sockets or electrical extensions, use only those that comply with current safety standards; in any case do not exceed the power consumption limits indicated on the electrical

adapter and / or extensions, as well as the maximum power shown on multiple adaptor.

Do not leave the unit plugged; better to remove the plug from the mains when the device is not in use. Always disconnect from power supply if you leave it unattended.

Cleaning operations should be carried out after unplugging the unit.

If the unit is out of order and you do not want to fix it, it must be made inoperable by cutting power cord.

- Do not allow the power cord to get closer to sharp objects or in contact with hot surfaces; do not pull it to disconnect the plug.

- Do not use the appliance in the event of damage to the power cord, plug, or in case of short circuits; to repair the product only address an authorized service center.

- Do not handle or touch the appliance with wet hands or bare feet. Do not expose the appliance to harmful weather conditions such as rain, moisture, frost, etc.. Always store it in a dry place.

- This appliance can be used by children of 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they received supervision or instruction concerning use of the appliance in a safe way and understand hazards involved; children shall not play with the appliance; cleaning and user maintenance shall not be made by children without supervision.

- Children must not play with the appliance.

- Keep the appliance and its cord out of reach of children less than 8 years.

If the power cord is damaged, or in case of failure and / or malfunction do not tamper with the unit. The reparation must be done by manufacturer or by service center authorized by the manufacturer in order to prevent any risk. Failure to comply with the above may compromise

the unit safety and invalidate the warranty.

WARNING: This appliance includes heating function. Surfaces, other than functional surfaces may develop high temperatures. Since temperatures are perceived differently by different people, this device should be used with CAUTION. Hold the appliance exclusively to grip surfaces intended to be touched.

• This appliance is intended to be used in household and similar applications such as: staff kitchen areas in shops, offices and other working environments; by clients in hotels, motels and other residential type environments; farm houses, bed and breakfast type environments.
• The appliance is not intended to be operated by means of an external timer or separate remote-control system.
• Before every use, unroll the power cord.
• Use original spare parts and accessories only.
• Do not subject the product to strong impacts, serious damages may result.
• Do not use near or under flammable materials (like curtains), heat, cold spots and steam.

GENERAL INFORMATION

Never leave the appliance unattended while it is running. Before using for the first time, carefully wash all parts that will come in touch with food such as container. Fill the appliance with cold milk, being careful to stay within the limits indicated inside the tank.

Always pour milk before turning on the kettle. Never pour liquids after switching on.

If the appliance operates when empty, the safety device shuts it down automatically to prevent any damage.

Once finished, unplug unit and wait for cooling of each part before storing or cleaning.

Don't immerse appliance in water or liquids. In any case, avoid splashing of water or liquids.

Always close the lid before each operation Put the appliance on stable shelves and floors.

Do not insert any metal object into the product. Remove the whisk, only after having turned off the appliance and unplugged it from the main power outlet.

To avoid milk to stuck on container, at the end of each use, immediately rinse the container with water.

DESCRIPTION G10146

1 Lid 2 Whisk

3 Handle and Main body 4 Operation buttons 5 Electric base

OPERATING THE UNIT

• Pour the milk into the container, making sure to stay within the limits of the capacity which is indicated on the appliance itself (MIN - MAX). There are 2 MAX indications inside the container: the lower one indicates the maximum level if you want to froth milk (200 ml); the upper one shows the maximum operation level if you just want to heat milk (350 ml).
• WARNING: if you exceed the maximum specified levels, the milk will spill out during use.
• Press 2 times the button to heat and froth milk. The light of the button will turn on red, and the whisk will begin to rotate. Once finished, the appliance will turn off automatically.
• Press the button ✪ to froth fresh milk, without heating it. The light of the button will turn on in blue, and the whisk will begin to rotate. Once finished, the product will automatically turn off.
• If you only want to heat the milk, remove the whisk from the base of the container. WARNING: this operation can be performed only if the product is switched off and unplugged from the power supply and

when all the parts are completely cold. To heat the milk, press one time the button appliance turns off automatically. The light of the button will turn on in red.

wait until the

- You can stop the machine anytime, by simply pressing again the operation button (4).

To avoid milk to stuck on container, at the end of each use, immediately rinse the container with water.

CLEANING - Unplug the unit and wait until the complete cooling down of each part before starting cleaning operations.

Do not immerse the base of the vessel and into the water. In any case, avoid splashing water or other liquids from reaching those parts. Do not use abrasive cleaners, solvents, or strong detergents to clean the exterior and the base of the product, but clean with a cloth dampened with warm water. To clean the inside of the appliance, wait for the cooling and rinse with cold water to remove residues and impurities.

To avoid the milk to stuck on container, at the end of each use, immediately rinse container with water.

SAFETY SWITCH-OFF

The safety device is triggered if the appliance operates without any milk inside the container. To avoid overheating, the unit is automatically turned off after a few seconds and it cannot be activated until the complete cooling of the electric resistance.

TECHNICAL FEATURES

• Power supply: AC 230V\~50/60Hz. Power 500W
• Max. capacity 350 ml
• Control button with function lights
- Removable whisk for an easy cleaning

PORTUGUES: ADVERTÊNCIAS

The product is made of non-biodegradable and potentially polluting substances if not properly disposed of; other parts can be recycled. It’s our duty to contribute to the ecological health of the environment following the correct procedures for disposal. The crossed out wheelie bin symbol indicates the product complies with the requirements of the new directives introduced to protect the environment (2002/96/EC, 2003/108/EC, 2002/95/EC, 2012/19/EC) and must be properly disposed at the end of its lifetime. If you need further information, ask for the dedicated waste disposal areas at your place of residence. Who does not dispose of the product as specified in this section shall be liable according to the law.

To find the nearest service center, please call the telephone number 0541 694246, fax number 0541 756430 or contact us at [e-mail] asking for the service centers supervisor.

Appliance is conform to the pertinent European regulation and is therefore marked with the CE mark.

www.g3ferrari.it TREVIDEA S.r.l.

TREVIDEA S.R.L. – Strada Consolare Rimini – San Marino n. 62 – 47924 – RIMINI (RN) - ITALY

MADE IN CHINA
