USER MANUAL KHM926CU KITCHENAID

USA: 1.800.541.6390 Canada: 1.800.807.6777 WELCOME TO THE WORLD OF KITCHENAID. We’re committed to helping you create a lifetime of delicious meals for family and friends. To help ensure the longevity and performance of your appliance, keep this guide handy. It will empower you with the best way to use and care for your product. Your satisfaction is our #1 goal. Remember to register your product online at www.kitchenaid.com, or by mail using the enclosed Product Registration Card. KitchenAid.com KitchenAid.ca Join us in the kitchen at www.kitchenaid.com.

Model Number _____________________________________________________________________ Serial Number _____________________________________________________________________ Date Purchased ____________________________________________________________________ Store Name and Location ___________________________________________________________ Always keep a copy of the itemized sales receipt showing the date of purchase of your Hand Mixer. Proof of purchase will assure you of in-warranty service. Before you use your Hand Mixer, please ll out and mail your product registration card packed with the unit, or register on-line at www.kitchenaid.com. This card will enable us to contact you in the unlikely event of a product safety notication and assist us in complying with the provisions of the Consumer Product Safety Act. This card does not verify your warranty. Please complete the following for your personal records: W10434747C_FINAL.indd 3 5/12/15 1:26 PM4

HAND MIXER SAFETYHAND MIXER SAFETY

IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should always be followed, including the following:

1. Read all instructions.

2. To protect against risk of electrical shock, do not put Hand Mixer in water or other

3. Close supervision is necessary when any appliance is used by or near children.

4. Unplug Hand Mixer from the outlet when not in use, before putting on or taking off

parts, and before cleaning.

5. Avoid contacting moving parts. Keep hands, hair, clothing, as well as spatulas and other

utensils away from all accessories during operation to reduce the risk of injury to persons and/or damage to the Hand Mixer.

6. Do not operate the Hand Mixer with a damaged cord or plug, or after the Hand Mixer

malfunctions, or is dropped or damaged in any manner. Return the Hand Mixer to the nearest Authorized Service Center for examination, repair, or electrical or mechanical adjustment.

7. The use of attachments not recommended or sold by KitchenAid may cause re,

electric shock, or injury.

8. Do not use the Hand Mixer outdoors.

Electrical requirements

SAVE THESE INSTRUCTIONS

Volts: 120 A.C. only. Hertz: 60 Hz NOTE: This Hand Mixer has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not modify the plug in any way. This product is designed for household use only. TROUBLESHOOTING First try the solutions suggested here and possibly avoid the cost of service.

1. Is the Hand Mixer plugged in?

2. Is the fuse in the circuit to the Hand

Mixer in working order? If you have a circuit breaker box, make sure the circuit is closed.

3. Try unplugging the Hand Mixer, then

01-800-902-31-00 (Industrias Birtman) See the “Warranty” section for additional details. Do not return the Hand Mixer to the retailer – they do not provide service. If Hand Mixer malfunctions or fails to operate

10. Do not let cord contact hot surface, including the stove.

11. Remove any accessories from Hand Mixer before washing.

W10434747C_FINAL.indd 5 5/12/15 1:26 PM6

PARTS AND FEATURESPARTS AND FEATURES

Hand Mixer parts and accessories Liquid blender rod accessory (included with 9-Speed models) Artisan

Beater accessory (Included with Professional Models only) Turbo Beater

accessory Dough hooks accessory Swivel lock power cord Soft grip handle Oversized beater ejector button Digital speed control Air vents 16-Tine pro whisk accessory Non-tip heel rest Cord strap (included with 9-Speed models) Storage bag (included with exclusive models, see “Accessory guide” section) W10434747C_FINAL.indd 6 5/12/15 1:26 PM7 English

PARTS AND FEATURESPARTS AND FEATURES

To order these accessoriesIn USA: visit www.shopkitchenaid.com, or call 1-800-541-6390. In Canada: call 1-800-807-6777 Accessory Uses Included with Model KHM7210 KHM7211 KHM926 KHM929 KHM9212Turbo Beater™ cookie dough cake batter Turbo Beater™ II cookie dough cake batter Artisan™ Beater † cookie dough cake batter Liquid blender rod smoothies diet drink mixes chocolate milk iced tea milkshakes soups sauces Dough hooks yeast bread doughs 16-Tine pro whisk whipped cream whipped egg whites sauces puddings Storage bag† to store accessories

† Not sold as an accessory. †† Please note, the storage bag referenced is not included with model KHM926Q. Accessory guide W10434747C_FINAL.indd 7 5/12/15 1:26 PM8 SETTING UP YOUR HAND MIXERSETTING UP YOUR HAND MIXER Attaching the accessories

Unplug the Hand Mixer from the electrical outlet. IMPORTANT: Be sure to read and follow the specific instructions in this manual for proper use of the Hand Mixer. NOTE: An accessory shaft without a collar may be used in either opening (A or B). Those with a collar may only be used in the larger opening (B).

Insert the accessory shaft with the collar (D) into the larger opening (B) of the Hand Mixer. Align the flanges on the shaft with the slots in the opening. Push to lock into place.

Insert the accessory without a collar (C) into the smaller opening (A). Align and push to lock into place.

Paired accessories (beaters, optional dough hooks) include one accessory with a collar (D), and one without (C). Single accessories come with a collar (D) (liquid blending rod) or without (C) (whisk). W10434747C_FINAL.indd 8 5/12/15 1:26 PM9 English SETTING UP YOUR HAND MIXERSETTING UP YOUR HAND MIXER Removing the accessories

Press the Ejector Button to release the accessories from the Hand Mixer, then remove them.

If the Hand Mixer is running, stop the Hand Mixer by sliding the Power switch to the “O” (Off) position.

Slide the Power switch to the “I” (ON) position. The motor will automatically start at Speed 1, and the “1” on the speed indicator control will light up.

When mixing job is finished, slide the Power switch to the “O” (Off) position. Unplug the Hand Mixer before removing accessories.

Touch the “UP (arrow)” button to increase the mixing speed to the desired setting. If necessary, touch the “DOWN (arrow)” button to decrease the mixing speed. See the “Speed control guide” for more information. NOTE: The Hand Mixer automatically starts at Speed 1 every time it is turned on, regardless of the Speed setting at the time the Hand Mixer is shut off. Operating the Speed Control

Plug the Hand Mixer into an electrical outlet. This KitchenAid

Hand Mixer will beat faster and more thoroughly than most other electric hand mixers. Therefore, the beating time in most recipes must be adjusted to avoid over beating. Beating time is faster due to larger beater sizes. To help determine the ideal beating time, observe the batter or dough and beat only until it has the desired appearance described in your recipe, such as “smooth and creamy”. To select the best beating speeds, use the “Speed control guide” section. W10434747C_FINAL.indd 10 5/12/15 1:26 PM11 English USING YOUR HAND MIXERUSING YOUR HAND MIXER Speed control guide - 7-Speed Hand Mixers The 7-Speed Hand Mixer always starts on the lowest speed (Speed 1). Move to higher speeds as needed, the speed setting indicator control will light up with the corresponding number for each speed. Speed Attachment Description

For slow stirring, combining, and starting all mixing procedures. Use this speed to stir in nuts, chocolate chips, shredded cheese, onions, olives, and other chunky ingredients. Mix flour and other dry ingredients with liquids or other moist mixtures. Helps prevent ingredients from splashing out of bowl.

Combine heavy mixtures, such as cookie dough. Mix light cream cheese spreads. Stir batters and gelatin mixtures.

Combine heavy cream cheese mixtures. Mash potatoes or squash.

Mix muffins, quick breads, batter breads, cake batters, and frostings. Blend butter and sugar.

Whip heavy cream and mousse mixtures.

Beat egg whites and meringue mixtures. NOTE: Beater accessories are not designed for mixing and kneading bread dough. Special dough hook attachments are available. See “Accessories” section for details and ordering information. W10434747C_FINAL.indd 11 5/12/15 1:26 PM12 CMD + SHIFT CLICK TO CHANGE COPYCARE AND CLEANINGUSING YOUR HAND MIXER Speed control guide - 9-Speed Hand Mixers The 9-Speed Hand Mixer always starts on the lowest speed (Speed 1). Move to higher speeds as needed, the speed setting indicator control will light up with the corresponding number for each speed. NOTE: Beater accessories are not designed for mixing and kneading bread dough. Special dough hook attachments are available. See “Accessories” section for details and ordering information. Speed Attachment Description 1 For slow stirring, combining, and starting all mixing procedures. Use this speed to stir in nuts, chocolate chips, shredded cheese, onions, olives, and other chunky ingredients. Helps prevent ingredients from splashing out of bowl. 2 Mix flour and other dry ingredients with liquids or other moist mixtures. 3 Mix pancake batter. 4 Combine heavy mixtures, such as cookie dough. Mix light cream cheese spreads. Stir batters and gelatin mixtures. 5 Mix muffins and quick breads. Combine heavy cream cheese mixtures. Mash potatoes or squash. 6 Mix batter breads. Blend butter and sugar. Mix frostings. 7 Finish mixing cake and other batters. Whip heavy cream and mousse mixtures. 8 Beat egg whites. Whip heavy cream and mousse mixtures. 9 Beat meringue mixtures. W10434747C_FINAL.indd 12 5/12/15 1:26 PM13 English CMD + SHIFT CLICK TO CHANGE COPYCARE AND CLEANING Electrical Shock Hazard Do not put in water. Doing so can result in death or electrical shock. Cleaning the Hand Mixer body Cleaning the accessories Cleaning the storage bag Always remove accessories from Hand Mixer before cleaning. Wash in dishwasher, or by hand in warm, soapy water. Rinse and wipe dry. Machine wash warm, tumble dry low. Or wipe clean with a warm soapy cloth. NOTE: Do not immerse Hand Mixer in water.

Always unplug Hand Mixer before cleaning. Wipe power cord and cord strap with damp cloth. Dry with a soft cloth. Wipe Hand Mixer with a damp cloth. Dry with a soft cloth.

Hand Mixer Warranty for the 50 United States, the District of Columbia, Puerto Rico, and Canada This warranty extends to the purchaser and any succeeding owner for Hand Mixers operated in the 50 United States, the District of Columbia, Puerto Rico, and Canada. Length of Warranty: One Year Full Warranty from date of purchase. KitchenAid Will Pay Hassle-Free Replacement of your Hand Mixer. for Your Choice of: See the next page for details on how to arrange for service, or call the Customer Satisfaction Center toll-free at 1-800-541-6390.

The replacement parts and repair labor costs to correct defects in materials and workmanship. Service must be provided by an Authorized KitchenAid Service Center. KitchenAid Will A. Repairs when Hand Mixer is used in other than Not Pay for: normal single family home use. B. Damage resulting from accident, alteration, misuse or abuse. C. Any shipping or handling costs to deliver your Hand Mixer to an Authorized Service Center. D. Replacement parts or repair labor costs for Hand Mixers operated outside the 50 United States, District of Columbia, Puerto Rico, and Canada. DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES IMPLIED WARRANTIES, INCLUDING TO THE EXTENT APPLICABLE WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE EXCLUDED TO THE EXTENT LEGALLY PERMISSIBLE. ANY IMPLIED WARRANTIES THAT MAY BE IMPOSED BY LAW ARE LIMITED TO ONE YEAR, OR THE SHORTEST PERIOD ALLOWED BY LAW. SOME STATES AND PROVINCES DO NOT ALLOW LIMITATIONS OR EXCLUSIONS ON HOW LONG AN IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS LASTS, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. IF THIS PRODUCT FAILS TO WORK AS WARRANTED, CUSTOMER’S SOLE AND EXCLUSIVE REMEDY SHALL BE REPAIR OR REPLACEMENT ACCORDING TO THE TERMS OF THIS LIMITED WARRANTY. KITCHENAID AND KITCHENAID CANADA DO NOT ASSUME ANY RESPONSIBILITY FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. This warranty gives you specic legal rights and you may also have other rights which vary from state to state or province to province.
