DSCSVIDEOHDMI - Audio/video converter Gembird - Free user manual and instructions

Product type	Audio/video converter
Brand	Gembird
Model	DSCSVIDEOHDMI
Input format	HDMI
Output format	Composite (CVBS) + Stereo audio (RCA)
Maximum input resolution	1080p
Output resolution	480i / 576i (PAL/NTSC)
Input connectors	1x HDMI female
Output connectors	1x composite RCA yellow, 2x RCA audio (white/red)
Power supply	5V DC via USB cable (micro-USB or USB-A)
Power consumption	~2 W
Dimensions (W x D x H)	Approximately 10 x 6 x 2 cm
Weight	Approximately 150 g
Operating temperature	0 °C to 40 °C
Operating humidity	10 % to 85 % RH
Material	ABS plastic
Color	Black
Compatibility	Devices with HDMI output (PC, console, set-top box) and TV/monitor with composite input
Package contents	Converter, USB power cable, user manual
Warranty	36 months
Manufacturer	Gembird Europe B.V.
Care and cleaning	Clean with a dry, non-abrasive cloth. Disconnect before cleaning.
Safety	Do not expose to moisture, shocks or extreme temperatures. Use only with the provided power supply.
Spare parts and repairability	No user-serviceable parts. Contact after-sales service in case of failure.

Frequently Asked Questions - DSCSVIDEOHDMI Gembird

How to connect the DSCSVIDEOHDMI converter?

Connect the HDMI cable from your source (PC, console) to the HDMI input of the converter. Connect the RCA outputs (yellow for video, red/white for audio) to your TV or monitor. Then connect the power supply via the micro-USB port using a USB power adapter or a USB port on a TV.

Why is there no image?

Check that the converter is powered (the indicator should light up). Make sure the HDMI source is turned on and working. Select the correct input on your display (AV/Composite). If the image remains black, test with another cable or source.

Does the converter support 1080p?

Yes, it accepts a resolution up to 1080p (HDMI) as input. The output signal is converted to SD (480i or 576i) suitable for composite inputs.

Can I connect a 4K source?

The converter accepts 4K signals (HDMI) but converts them to standard SD resolution. Make sure the source is set to a compatible output (e.g. 1080p) to avoid compatibility issues.

What is the difference between PAL and NTSC?

PAL (Phase Alternating Line) is used in Europe, Africa and Asia, while NTSC (National Television System Committee) is common in North America and Japan. The converter automatically detects the standard of your source and outputs the corresponding signal.

Does sound work with this converter?

Yes, the converter extracts stereo audio from the HDMI stream and outputs it via the white and red audio (RCA) jacks. Connect these cables to the audio inputs of your TV.

Can I use a different power supply?

Use exclusively a 5V DC power supply with a micro-USB connector. A different voltage could damage the device.

Does the converter get hot?

Slight warmth is normal. If the device becomes very hot, ensure it is in a well-ventilated area away from heat sources. In case of overheating, unplug it and contact support.

What to do if the image is black and white?

This may be due to a mismatch between the video standard of the source and that of the TV. Check that your TV supports NTSC or PAL depending on the source. Try changing the video output in your source settings (e.g. switch from NTSC to PAL).

How to get a sharper image?

Composite output is limited to SD resolution (480i/576i). To improve quality, use a direct HDMI cable if your display allows it. Otherwise, ensure connections are secure and cables are of good quality.

USER MANUAL DSCSVIDEOHDMI Gembird

• Converts analog S-Video/Composite Video and audio (L/R) input into a digital 720p/1080p HDMI and extra 3.5 mm audio
• Selection switch for video input type (S-Video/CVBS) and video output quality (720p/1080p)

Specifications

Input: 1 x S-Video, 1 x Composite Video, 2 x audio (L/R)
Output: 1 x HDMI, 1x 3.5 mm stereo audio connector
Power supply: 5 ~V DC up to 2 A

All brands and logos are registered trademarks of their respective owners

energenie

DSC-SVIDEO-HDMI S-VIDEO TO HDMI CONVERTER

All brands and logos are registered trademarks of their respective owners

energenie

DSC-SVIDEO-HDMI S-VIDEO TO HDMI CONVERTER

All brands and logos are registered trademarks of their respective owners

EC Declaration of Conformity

We hereby certify that the following product complies with all the relevant Safety Requirements of 4 EMVG and of the Directives 2006/95/EC; 93/68/EEC and 2004/108/EC.

Applicant :	Gembird Europe BV
	Wittevrouwen 56,
	1358CD, Almere, The Netherlands
Equipment :	Computer parts
Model Nos. :	DSC-SVIDEO-HDMI
Product description :	DSC-SVIDEO-HDMI S-VIDEO to HDMI Converter

European standards

EN65022:1998+A1:2000+A2:2003; EN55024:1998+A1:2001+A2:2003; EN61000-3-2:2000; EN61000-3-3:1995+A1:2001; EN60950-1:2001

The following manufacturerWITIN Europe is responsible for this declaration:

Gembird Europe BV Wittevrouwen 56,1358CD,Almere,The Netherlands Tel:[phone].Fax:[phone]

The Netherlands / Jan. 31, 2011 Place and Date

All brands and logos are registered trademarks of their respective owners

energenie

DSC-SVIDEO-HDMI S-VIDEO TO HDMI CONVERTER

Waste disposal:

Do not deposit this equipment with the household waste. Improper disposal can harm both the environment and human health. For Information about waste collection facilities for used electrical and electronic devices, please contact your city council or an authorized company for the disposal of electrical and electronic equipment.
