USER MANUAL DVG55M9600 SAMSUNG

FlexDry™ User manual DV*55M9600** FlexDry_DM9600M-DC68-03381H-03_EN.indd 1 2017-06-01 3:27:41Contents English2 Contents Safety information 4 What you need to know about the safety instructions 4 Important safety symbols 4 Important safety precautions 6 Warnings 8 Cautions 8 Regulatory notice 10 Installation 13 What’s included 13 Installation requirements 15 Step-by-step installation 23 Vent blockage test 30 Exhaust ducting guide 31 Door reversal 32 Before you start 35 Sort and load 35 Lint lter 35 Drying guidelines 36 Rack guidelines 37 Operations 39 Delicate Dryer 39 Tumble Dryer 43 Simple steps to start 47 Samsung Smart Home 48 Special features 50 Maintenance 52 General cleaning and maintenance instructions 52 Delicate Dryer 54 Tumble Dryer 55 FlexDry_DM9600M-DC68-03381H-03_EN.indd 2 2017-06-01 3:27:41Contents English 3 Troubleshooting 56 Checkpoints 56 Samsung Smart Home 59 Information codes 60 Specications 62 Fabric care chart 62 Protecting the environment 63 Specication sheet 64 Cycle chart 65 FlexDry_DM9600M-DC68-03381H-03_EN.indd 3 2017-06-01 3:27:41SAVE THESE INSTRUCTIONS Safety information English4 Safety information Congratulations on your new Samsung dryer. This manual contains important information on the installation, use and care of your appliance. Please take some time to read this manual to take full advantage of your dryer’s many benets and features. What you need to know about the safety instructions Please read this manual thoroughly to ensure that you know how to safely and efciently operate the extensive features and functions of your new appliance. Please store the manual in a safe location close to the appliance for future reference. Use this appliance only for its intended purpose as described in this instruction manual. Warnings and Important Safety Instructions in this manual do not cover all possible conditions and situations that may occur. It is your responsibility to use common sense, caution and care when installing, maintaining and operating your dryer. Because the following operating instructions cover various models, the characteristics of your dryer may differ slightly from those described in this manual and not all warning signs may be applicable. If you have any questions or concerns, contact your nearest service center or nd help and information online at www.samsung.com. Important safety symbols What the icons and signs in this user manual mean: WARNING Hazards or unsafe practices that may result in severe personal injury, death and/or property damage. CAUTION Hazards or unsafe practices that may result in personal injury and/or property damage. NOTE Indicates that a risk of personal injury or material damage exists. These warning signs are here to prevent injury to yourself and others. Please follow them explicitly. After reading this manual, store it in a safe place for future reference. Read all instructions before using the appliance. As with any equipment that uses electricity and moving parts, potential hazards exist. To safely operate this appliance, familiarize yourself with its operation and exercise care when using it. FlexDry_DM9600M-DC68-03381H-03_EN.indd 4 2017-06-01 3:27:41SAVE THESE INSTRUCTIONS Safety information

SAVE THESE INSTRUCTIONS

English 5 WARNING - Gas Appliances:

• State of California Proposition 65 Warning (US only) This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

• Gas appliances can cause low-level exposure to Proposition 65 listed substances, including but not limited to, benzene, carbon monoxide, formaldehyde and soot, substances resulting from the incomplete combustion of natural gas or LP fuels. WARNING - Risk of Fire

• Clothes dryer installation must be performed by a qualied installer.

• Install the clothes dryer according to the manufacturer’s instructions and local codes.

• Do not install a clothes dryer with exible plastic venting materials. If exible metal (foil type) duct is installed, it must be of a specic type identied by the appliance manufacturer as suitable for use with clothes dryers. Flexible venting materials are known to collapse, be easily crushed, and trap lint. These conditions will obstruct clothes dryer airow and increase the risk of re.

• To reduce the risk of severe injury or death, follow all installation instructions.

• Save these instructions. FlexDry_DM9600M-DC68-03381H-03_EN.indd 5 2017-06-01 3:27:41SAVE THESE INSTRUCTIONS Safety information Safety information

SAVE THESE INSTRUCTIONS

English6 Important safety precautions WARNING To reduce the risk of re, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following:

1. Read all instructions before using this appliance.

2. Do not dry articles that have been previously cleaned in, washed in, soaked in,

or spotted with gasoline, dry-cleaning solvents, or other ammable or explosive substances, as they give off vapors that could ignite or explode.

3. Do not use the dryer to dry clothes which have traces of any ammable substance,

such as vegetable oil, cooking oil, machine oil, ammable chemicals, paint thinner, etc., or anything containing wax or chemicals, such as mops and cleaning cloths. Flammable substances may cause the fabric to catch re by itself.

4. Do not store or use gasoline or other ammable vapors and liquids near this or any

5. Do not allow children to play on or in the appliance. Close supervision of children is

necessary when the appliance is used near children.

6. Before the appliance is removed from service or discarded, remove the door to the

7. Do not reach into the appliance if the drum is moving.

8. Do not install or store this appliance where it will be exposed to the weather.

9. Do not tamper with internal controls.

10. Do not repair or replace any part of the appliance or attempt any service unless

specically recommended in the user-maintenance instructions or in published user repair instructions that you understand and have the skills to carry out.

11. Do not use fabric softeners or products to eliminate static unless recommended by the

manufacturer of the fabric softener or product.

12. Clean the lint screen before or after each load.

13. Do not use heat to dry articles containing foam rubber or similarly textured rubber-

14. Keep area around the exhaust opening and adjacent surrounding areas free from the

accumulation of lint, dust, and dirt.

15. The interior of the appliance and exhaust duct should be cleaned periodically by

qualied service personnel. FlexDry_DM9600M-DC68-03381H-03_EN.indd 6 2017-06-01 3:27:41SAVE THESE INSTRUCTIONS Safety information

SAVE THESE INSTRUCTIONS

16. Do not place items exposed to cooking oils in your dryer. Items contaminated with

cooking oils may contribute to a chemical reaction that could cause a load to catch re.

17. This appliance must be grounded. See Electrical requirements and Grounding in

Installation section.

18. Do not allow children to play on or in the appliance. Close supervision of children is

necessary when the appliance is used near children.

19. Do not insert your hand under the dryer.

• This may result in injury.

20. Take care that children’s ngers are not caught in the door when closing it.

• This may result in injury.

21. The control board and inlet valve are intentionally not grounded and may present a

risk of electric shock only during servicing.

• Do not contact these parts while the appliance is energized. WARNING - To reduce the risk of re or explosion:

• Do not dry items that have been previously cleaned, washed, soaked, or spotted with gasoline, dry cleaning solvents, or other ammable or explosive substances. They emit vapors that could ignite or explode. Any material that has been in contact with a cleaning solvent or ammable liquids or solids should not be placed in the dryer until all traces of these ammable liquids or solids and their fumes have been removed. There are many highly ammable items used in homes, such as acetone, denatured alcohol, gasoline, kerosene, some liquid household cleaners, some spot removers, turpentine, waxes, and wax removers.

• Items containing foam rubber (which may be labeled latex foam) or similarly textured rubberlike materials must not be dried on a heat setting. Heated foam rubber materials can, under certain circumstances, ignite spontaneously. FlexDry_DM9600M-DC68-03381H-03_EN.indd 7 2017-06-01 3:27:41SAVE THESE INSTRUCTIONS Safety information Safety information

SAVE THESE INSTRUCTIONS

English8 WARNING - What to do if you smell gas:

• Do not try to light any appliance.

• Do not turn on the appliance.

• Do not touch any electrical switch.

• Do not use any phone in your building.

• Clear the room, building or area of all occupants.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the re department. Important: Installation and service must be performed by a qualied installer, service agency, or your gas supplier. Warnings WARNING

• Ensure pockets are free of small, irregularly shaped hard objects and foreign material, i.e. coins, knives, pins, etc. These objects could damage your dryer.

• Gas leaks may occur in your system, resulting in a dangerous situation. Cautions CAUTION

• Do not allow children or pets to play on, in, or in front of the appliance. Close supervision is necessary when the appliance is used near children and pets.

• Before discarding or removing your dryer from service, remove the door to the drying compartment to prevent children or animals from becoming trapped inside.

• Do not reach into the appliance when the drum is moving.

• Do not install or store this appliance where it will be exposed to the weather.

• Do not tamper with the controls.

• Do not repair, replace, or attempt to service any part of the appliance unless specically instructed to in the user repair instructions and you have the understanding and skills to carry out the procedure. FlexDry_DM9600M-DC68-03381H-03_EN.indd 8 2017-06-01 3:27:41SAVE THESE INSTRUCTIONS Safety information

SAVE THESE INSTRUCTIONS

• Do not use fabric softeners or products to eliminate static unless the softener or product is recommended for dryer use by the manufacturer of the fabric softener or product.

• Clean the lint screen before or after each load.

• Keep the area around the exhaust opening and surrounding areas free from lint, dust, and dirt.

• The interior of the dryer and exhaust duct should be cleaned periodically by qualied service personnel.

• This appliance must be properly grounded. Never plug the power cord into a receptacle that is not grounded adequately or not in accordance with local and national codes. See the installation instructions for information about grounding this appliance.

• Do not sit on top of the dryer.

• Do not dry clothing with large buckles, buttons, or other heavy metal or solid objects.

• Gas leaks may not be detected by smell alone.

• Gas suppliers recommend you purchase and install a UL-approved gas detector.

• Install and use in accordance with the manufacturer’s instructions.

• Do not place items in your dryer that have been spotted or soaked with vegetable oil or cooking oil. Even after being washed, these items may contain signicant amounts of these oils.

• Residual oil on clothing can ignite spontaneoulsy. The potential for spontaneous combustion increases when items containing vegetable oil or cooking oil are exposed to heat. Heat sources such as your dryer can warm these items, allowing an oxidation reaction in the oil to occur. Oxidation creates heat. If this heat cannot escape, the items can become hot enough to catch re. Piling, stacking, or storing these kinds of items may prevent heat from escaping and can create a re hazard.

• All washed and unwashed fabrics that contain vegetable oil or cooking oil can be dangerous. Washing these items in hot water with extra detergent will reduce, but not eliminate, the hazard. Always use the Cool Down cycle for these items to reduce their temperature. Never remove these items from the dryer hot or interrupt the drying cycle until the items have run through the Cool Down cycle. Never pile or stack these items when they are hot. FlexDry_DM9600M-DC68-03381H-03_EN.indd 9 2017-06-01 3:27:41Regulatory notice English10 Regulatory notice FCC Notice CAUTION Any changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of FCC Rules. Operation is Subject to following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received including interference that cause

undesired operation. For products sold in the US and Canadian markets, only channels 1

11 are available. You cannot select any other channels. FCC STATEMENT: This equipment has been tested and found to comply within the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorienting or relocating the receiving antenna

• Increasing the separation between the equipment and receiver

• Connecting the equipment to an outlet that is on a different circuit than the radio or TV.

• Consulting the dealer or an experienced radio/TV technician for help. FCC RADIATION EXPOSURE STATEMENT: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated so there is at least 8 inches (20 cm) between the radiator and your body. This device and its antenna(s) must not be colocated or operated in conjunction with any other antenna or transmitter. FlexDry_DM9600M-DC68-03381H-03_EN.indd 10 2017-06-01 3:27:41Regulatory notice English 11 IC Notice The term “IC” before the radio certication number only signies that Industry Canada technical specications were met. Operation is subject to the following two conditions:

1. This device may not cause interference, and

2. This device must accept any interference, including interference that may cause

undesired operation of the device. This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme á la norme NMB-003 du Canada. For products sold in the US and Canadian markets, only channels 1

11 are available. You cannot select any other channels. IC RADIATION EXPOSURE STATEMENT: This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated so there is at least 8 inches (20 cm) between the radiator and your body. This device and its antenna(s) must not be colocated or operated in conjunction with any other antenna or transmitter. FlexDry_DM9600M-DC68-03381H-03_EN.indd 11 2017-06-01 3:27:41Regulatory notice Regulatory notice English12 Open Source License Notice The software included in this product contains open source software. You may obtain the complete corresponding source code for a period of three years after the last shipment of this product by sending an email to mailto:oss.request@samsung.com. It is also possible to obtain the complete corresponding source code in a physical medium such as a CD-ROM; a minimal charge will be required. The following URL http://opensource.samsung.com/opensource/SimpleConnectTP/seq/0 leads to the download page of the source code made available and open source license information as related to this product. This offer is valid to anyone in receipt of this information. FlexDry_DM9600M-DC68-03381H-03_EN.indd 12 2017-06-01 3:27:42Installation English 13 Installation This FlexDry™ dryer must be installed by a qualied technician. The installer is responsible for connecting the dryer to the main power while observing the relevant safety regulations of your area. What’s included Make sure all the supplied parts and accessories are included in the product package (see page 14). If you have a question about the dryer or the accessories, contact a local Samsung service center or the retailer. Dryer at a glance

01 Top door 02 Main panel 03 Front door 04 Lint lter 05 Exhaust duct FlexDry_DM9600M-DC68-03381H-03_EN.indd 13 2017-06-01 3:27:42Installation Installation English14 Accessories (supplied) Y connector Water hose (Canadian elec. models only) Short water hose Flexible rack Dryer-sheet case Accessories (not supplied) You must purchase these items at a local service center. Pedestal WARNING Packing materials can be dangerous to children. Keep all packing materials (plastic bags, polystyrene, etc.) out of children’s reach. Tools required (not supplied) Pliers Cutting knife Pipe wrench (gas models only) Nut screwdriver Level Philips screwdriver Duct tape Wrench FlexDry_DM9600M-DC68-03381H-03_EN.indd 14 2017-06-01 3:27:43Installation English 15 Installation requirements Read through the following instructions before installing the dryer and keep this manual for future reference. WARNING The control board and inlet valve are intentionally not grounded and may present a risk of electric shock only during servicing. Service personnel: Do not contact these parts while the appliance is energized. Key installation requirements

• A grounded electrical outlet.

• A power cord for electric dryers (except in Canada).

• Gas lines (for gas models) that must meet national and local regulations.

• An exhaust system made of rigid metal or exible stiff-walled metal exhaust ducting. WARNING Remove the door from all discarded appliances to prevent a child from suffocating. Location considerations The dryer should be located where there is enough space at the front for loading the dryer, and enough space behind for the exhaust system. This dryer is factory- ready for the rear exhaust option. To exhaust out the bottom, right or the left, use the accessory exhaust kit. Instructions are included with the kit. Make sure the room in which the dryer is located has enough fresh air. The dryer must be located where there are no air-ow obstructions. For gas dryers, adequate clearance must be maintained as noted on the data plate to ensure adequate air for combustion and proper dryer operation. The dryer must not be installed or stored in an area where it will be exposed to water and/or weather. The dryer area must be kept clear of combustible materials, gasoline, and other ammable vapors and liquids. A dryer produces combustible lint. The area around the dryer should be kept lint-free. FlexDry_DM9600M-DC68-03381H-03_EN.indd 15 2017-06-01 3:27:44Installation Installation English16 Alcove or closet installations WARNING

• The dryer must be exhausted to the outside to reduce the risk of re when installed in an alcove or closet.

• No other fuel-burning appliance should be installed in the same closet as the dryer. Minimum clearances between the dryer and adjacent walls or other surfaces: Sides 1 in. (25 mm) Rear 6 in. (152 mm) Top 21 in. (533 mm) Closet front 2 in. (51 mm) Installation with pedestal

A 53.7 in. (1365 mm) D 27 in. (686 mm) B 32.5 in. (825 mm) E 46.9 in. (1192 mm) C 6 in. (152 mm) F 52.2 in. (1326 mm) FlexDry_DM9600M-DC68-03381H-03_EN.indd 16 2017-06-01 3:27:44Installation English 17 Side by side installation

A 1 in. (25 mm) D 32.5 in. (825 mm) B 27 in. (686 mm) E 2 in. (50 mm) C 21 in. (533 mm) F 6 in. (152 mm)

• Use a 4-inch (10.2 cm) diameter rigid aluminum or galvanized steel duct. If you integrate the dryer’s vent system with an existing exhaust system:

• Make sure the exhaust system meets all applicable local, state, and national regulations.

• Verify you are not using exible plastic duct.

• Make sure to check for and remove all lint buildup from inside the existing ducts.

• Conrm the duct is not kinked or crushed.

• Make sure the exhaust hood damper opens and closes freely. Manometer measurements The static pressure in any exhaust system must not exceed 0.83 inches of water column or be less than 0. Note that these values are measured with the dryer running with a manometer presented to the exhaust duct that connects to the dryer. The dryer drum must be empty and lint lter clean. FlexDry_DM9600M-DC68-03381H-03_EN.indd 18 2017-06-01 3:27:45Installation English 19 Exhausting requirements The dryer must not be exhausted into a chimney, a wall, a ceiling, an attic, a crawl space, or a concealed space of a building. Exhausting the dryer to the outside will prevent large amounts of lint and moisture from being blown into the room. In the United States and Canada

• All dryers must be exhausted to the outside.

• The required exhaust duct is 4 inches (10.2 cm) in diameter.

• See Ducting requirements in the Installation section for the maximum duct length and number of bends that can be used.

• The total length of exible metal duct must not exceed 7’ 10½” (2.4 m).

• Do not assemble the duct with screws or other fasteners that extend into the duct and catch lint.

• For the United States only: Use only those foil-type exible ducts, if any, specically identied for use with the appliance by the manufacturer and that comply with the Outline for Clothes Dryer Transition Duct. Use Subject 2158A. Outside the United States and Canada

• Refer to the local codes. WARNING

• You must exhaust the dryer to the outside to reduce the risk of re when you install the dryer in an alcove or closet.

• Do not use a plastic or non-metal exible duct.

• If your existing ductwork is plastic, non- metal, or combustible, replace it with metal.

• Use only a metal exhaust duct that is non-ammable to ensure containment of exhaust air, heat, and lint. FlexDry_DM9600M-DC68-03381H-03_EN.indd 19 2017-06-01 3:27:45Installation Installation English20 Gas requirements WARNING

Z223.1, LATEST REVISION (FOR THE

UNITED STATES), OR WITH THE CAN /

CGA-B149 INSTALLATION CODES (FOR

• Gas dryers are equipped with a burner vent for use with natural gas. If you plan to use your dryer with LP (liquid propane) gas, it must be converted for safe and proper performance by a qualied service technician.

• A 1/2” (1.27 cm) gas supply line is recommended and must be reduced to connect to the 3/8” (1 cm) gas line on your dryer. The National Fuel Gas Code requires that an accessible, approved manual gas shut-off valve be installed within 6” of your dryer.

• Gas dryers installed in residential garages must be raised 18 inches (46 cm) above the oor.

• Additionally, a 1/8” (0.3 cm) N.P.T. (National Pipe Thread) plugged tapping, accessible for test gauge connection, must be installed immediately upstream of your dryer’s gas supply connection.

• Your dryer must be disconnected from the gas supply pipe system during any pressure testing of the system.

• Do not reuse old exible metal gas lines. Flexible gas lines must be design certied by the American Gas Association (CGA in Canada). NOTE

• Your dryer uses an automatic ignition system to ignite the burner. There is no constant burning pilot.

• Any pipe joint compound used must be resistant to the action of any liqueed petroleum gas.

• As a courtesy, most local gas utilities will inspect a gas appliance installation. Commonwealth of Massachusetts installation instructions Your dryer must be installed by a licensed plumber or gas tter. A “T” handle manual gas valve must be installed in the gas supply line to your dryer. If a exible gas connector is used to install your dryer, the connector can be no longer than 3’ (36”). WARNING

• Gas leaks may occur in your system, creating a dangerous situation.

• Gas leaks may not be detected by smell alone.

• Gas suppliers recommend you purchase and install a UL-approved gas detector.

• Install and use in accordance with the manufacturer’s instructions. FlexDry_DM9600M-DC68-03381H-03_EN.indd 20 2017-06-01 3:27:45Installation English 21 Electrical requirements The wiring diagram is located on the plate under the control panel or rear frame. WARNING

• Improperly connecting the equipment grounding conductor can result in a risk of electric shock. Check with a qualied electrician or serviceman if you are in doubt as to whether your dryer is properly grounded. Do not modify the plug provided with your dryer – if it doesn’t t the outlet, have a proper outlet installed by a qualied electrician.

• To prevent unnecessary risk of re, electrical shock, or personal injury, all wiring and grounding must be done in accordance with local codes, or in the absence of local codes, in accordance with the National Electrical Code, ANSI/ NFPA No. 70-Latest Revision (for the U.S.) or the Canadian Electrical Code CSA C22.1 – Latest Revisions and local codes and ordinances. It is your responsibility to provide adequate electrical service for your dryer.

• All gas installations must be done in accordance with the national Fuel Code ANSI/Z2231 – Latest Revision (for the U.S.) or CAN/CGA – B149 Installation Codes – Latest Revision (for Canada) and local codes and ordinances. Grounding This dryer must be grounded. In the event of a malfunction or breakdown, the ground will reduce the risk of electrical shock by providing a path of least resistance for the electrical current. Gas models WARNING

• Your dryer has a cord with an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.

• Do not modify the plug provided with your dryer – if it doesn’t’t t the outlet, have a proper outlet installed by a qualied electrician.

• Do not connect the ground wire to plastic plumbing lines, gas lines, or hot water pipes. Electric models WARNING

• Your dryer has an optional cord with an equipment-grounding conductor and a grounding plug. This cord is sold separately.

• The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.

• Do not modify the plug provided with your dryer – if it doesn’t’t t the outlet, have a proper outlet installed by a qualied electrician. FlexDry_DM9600M-DC68-03381H-03_EN.indd 21 2017-06-01 3:27:45Installation Installation English22

• If a power cord is not used and the electric dryer is to be permanently wired, the dryer must be connected to a permanently grounded metal wiring system, or an equipment grounding conductor must be run with the circuit conductors and connected to the equipment grounding terminal or lead on the dryer. Electrical connections Before operating or testing, follow all grounding instructions in the Grounding section. An individual branch (or separate) circuit serving only your dryer is recommended. Do not use an extension cord. Gas models – U.S. and Canada A 120 volt, 60 Hz AC approved electrical service with a 15-ampere fuse or circuit breaker is required. Electric models – U.S. only Most U.S. dryers require a 120 / 240 volt, 60 Hz AC approved electrical service. Some require 120 / 208 volt, 60 Hz approved electrical service. The electric service requirements can be found on the data label located behind the door. A 30-ampere fuse or circuit breaker on both sides of the line is required.

• If a power cord is used, the cord should be plugged into a 30-ampere receptacle.

• The power cord is not provided with U.S. electric model dryers. This cord is sold separately. WARNING Risk of Electric Shock When local codes allow, you can connect the dryer’s electrical supply with a new power supply cord kit, marked for use with a dryer, that is U.L. listed and rated at a minimum of 120 / 240 volts, 30-amperes with three No. 10 copper wire conductors terminated with closed loop terminals, open-end spade lugs with turned up ends, or with tinned leads.

• Do not reuse a power supply cord from an old dryer. The power cord electric supply wiring must be supported at the dryer cabinet by a suitable UL-listed strain relief.

• Grounding through the neutral conductor is prohibited for (1) new branch-circuit installations, (2) mobile homes, (3) recreational vehicles, and (4) areas where local codes prohibit grounding through the neutral conductor. (Use a 4-prong plug for a 4 wire receptacle, NEMA type 14-30R.) Electric models – Canada Only

• A 120 / 240 volt, 60 Hz AC approved electrical service fused through a 30-ampere fuse or circuit breaker on both sides of the line is required.

• All Canadian models are shipped with the power cord attached. The power cord should be plugged into a 30-ampere receptacle. NOTE In Canada, you may not convert a dryer to 208 volts. FlexDry_DM9600M-DC68-03381H-03_EN.indd 22 2017-06-01 3:27:45Installation English 23 Step-by-step installation Make sure you have a qualied technician install the dryer. Step by step installation instructions start below. STEP 1 Install the exhaust system

1. Select a location and move the dryer to the site. For easy access, we recommend you

install the dryer in the same location as your washer.

2. To change the door direction, see Door reversal.

3. Install the exhaust system as instructed in the Exhaust ducting guide section.

• To move the dryer easily, lay two of the carton cushions from the packaging on the oor. Tip the dryer on its side so it lies across both cushion-tops. Push the dryer so that it is near its nal location, and then set the dryer upright.

• Secure room around the dryer to facilitate ducting and wiring. STEP 2 Connect the gas line First, read through the Gas requirements section, and follow these steps.

1. Remove the protective cap from the gas pipe.

2. Apply a LPG (Liqueed Petroleum Gas)-safe compound or 1.5 wraps of Teon tape to

all threaded connections.

3. Connect the gas supply to the dryer. An additional tting is required to connect

the 3/4” (1.9 cm) female thread end of a exible connector to the 3/8” (1 cm) male threaded end on the dryer. Tighten up the tting over all threads.

4. Turn on the gas supply, and check for any leaks using a soap solution. If a leak is

found, tighten the connections and try again. DO NOT use an open ame to check for gas leaks. FlexDry_DM9600M-DC68-03381H-03_EN.indd 23 2017-06-01 3:27:45Installation Installation English24 STEP 3 Connect the electrical wiring First, read through the Electrical requirements section, and then follow these steps. 3-wire system A. External ground connector B. Neutral grounding wire (white) C. Center silver-colored terminal block screw D. Neutral wire (white or center wire) E. ¾” (1.9 cm) UL-listed strain relief

2. Connect the neutral wire (white or

center wire) of the power cable to the center, silver-colored terminal screw of the terminal block. Tighten the screws.

3. Connect the other wires to outer

terminal block screws. Tighten the screws.

4. Tighten the strain relief screws.

5. Insert the terminal block cover into the

rear panel of the dryer. Then, secure the cover with a hold-down screw. CAUTION

• To convert from the 4-wire system to 3-wire system, connect the ground strap to the terminal block support to ground the dryer frame to the neutral conductor.

• Ring-type terminals are recommended. If using strap terminals, make sure they are tightened. FlexDry_DM9600M-DC68-03381H-03_EN.indd 24 2017-06-01 3:27:46Installation English 25 4-wire system A. External ground connector B. Green or bare copper wire of power cord C. ¾” (1.9 cm) UL-listed strain relief D. Center silver-colored terminal block screw E. Neutral grounding wire (white) F. Neutral wire (white or center wire)

1. Remove the external ground

connector’s screw, and connect the ground wire (green or unwrapped) of the power cable to the screw. CAUTION

• To connect the ground wire to the neutral position without through contact A (cabinet ground), contact a technician. This is not user serviceable.

• Ring-type terminals are recommended. If using strap terminals, make sure they are tightened.

2. Loosen or remove the screws from the

center terminal block.

3. Connect the neutral wire (white or

center wire) and ground wire (white) to the center screw of the terminal block. Tighten the screw.

4. Connect the other wires to the outer

terminal block screws. Tighten the screws.

5. Tighten the strain relief screws.

6. Insert the tab of the terminal block

cover into the rear slot of the dryer. Secure the cover with a hold-down screw. WARNING

• All U.S. models are designed for a 3-wire system connection. The dryer frame is grounded to the neutral conductor at the terminal block. A 4-wire system connection is required for new or remodeled construction, mobile homes, or if local codes do not permit grounding through neutral. If you use the 4-wire system, you cannot ground the dryer frame to the neutral conductor at the terminal block.

• Remove the terminal block cover plate. Insert the power cord with a UL-listed strain relief through the hole provided in the cabinet near the terminal block. FlexDry_DM9600M-DC68-03381H-03_EN.indd 25 2017-06-01 3:27:46Installation Installation English26

• A strain relief must be used. Do not loosen the nuts already installed on the terminal block. Be sure they are tight. Use a 3/8” (1 cm) deep well socket. STEP 4 Connect the water hose (applicable models only) The dryer must be connected to a cold water tap using the provided water hoses.

1. Close the cold water tap. If you have

a washer cold water hose attached to the cold water faucet, unscrew and remove the hose. Then, connect the female end of the Y connector to the cold water tap.

2. Connect the straight end of the water

hose to the Y connector. Tighten the hose coupling by hand.

3. Using pliers, tighten the coupling an

additional two-thirds turn. Do not overtighten. You can damage the coupling.

4. Connect the angled end of the water

hose to the lling valve at the bottom rear of the dryer. Turn the coupling by hand until it is tight.

5. Using pliers, tighten the coupling an

additional two-thirds turn. Do not overtighten. You can damage the coupling.

6. If you detached the cold water hose

from your washer, attach the hose to the open end of the Y connector, tighten the coupling by hand until it is tight, and then, using a pliers, tighten an additional two-thirds turn.

7. Open the cold water tap, and then

check for any leaks. If the Y connector cannot be directly connected to the cold water tap, use the short hose as shown on the following page. FlexDry_DM9600M-DC68-03381H-03_EN.indd 26 2017-06-01 3:27:46Installation English 27 Using the short hose as an extension

1. Close the cold water tap. If you have

a washer cold water hose attached to the cold water faucet, unscrew and remove the hose. Then, connect the short hose (B) to the cold water tap. Turn the coupling by hand until it is tight.

2. Using pliers, tighten the coupling an

additional two-thirds turn. Do not overtighten. You can damage the coupling.

3. Connect the Y connector (A) to the

brass male end of the short hose. Turn the coupling by hand until it is tight.

4. Using pliers, tighten the coupling an

additional two-thirds turn. Do not overtighten. You can damage the coupling.

5. Connect the angled end of the water

hoses (C) to the lling valve at the bottom rear of the dryer. Turn the coupling by hand until it is tight.

6. Using pliers, tighten the coupling an

additional two-thirds turn. Do not overtighten. You can damage the coupling.

7. If you detached the cold water hose

from your washer, attach the hose to the free end of the Y connector, tighten the coupling by hand until it is tight, and then, using a pliers, tighten an additional two-thirds turn.

8. Open the cold water tap, and then

is level side to side and then front to back. If the dryer is not level, adjust the leveling feet (B) at the bottom of the dryer. Then, check if the dryer is level again. A B NOTE

• To set the dryer to the same height as your washer, fully retract (A) the leveling feet by turning them counterclockwise, then loosen (B) the feet by turning them clockwise. Once the dryer is the same height as the washer, follow the directions above to level the dryer.

• Adjust the leveling feet only as much as necessary to level the dryer. Extending the leveling feet more than necessary can cause the dryer to vibrate. FlexDry_DM9600M-DC68-03381H-03_EN.indd 28 2017-06-01 3:27:47Installation English 29 STEP 6 Power on (Gas models) Make sure all gas connections, the exhaust line, and all wiring is connected correctly. Then, plug the power cord into a power source and check the dryer’s installation and operation using the nal checklist in Step 7 below. STEP 7 Final check When installation is complete, conrm that:

• The dryer is plugged into an electrical outlet and grounded properly.

• The exhaust ductwork is connected and the joints are taped.

• You have used rigid or stiff-walled exible metal duct material, not plastic exible duct.

• The dryer is level and is sitting rmly on the oor.

• The dryer starts, runs, heats, and shuts off properly. For gas models:

• Gas is supplied properly with no leaks. CAUTION The burner may not ignite initially due to air in the gas line. Allowing your dryer to operate on a heat setting will purge the line. If the gas does not ignite within 5 minutes, turn your dryer off and wait 5 minutes. Be sure the gas supply to your dryer has been turned on. To conrm gas ignition, check the exhaust for heat. FlexDry_DM9600M-DC68-03381H-03_EN.indd 29 2017-06-01 3:27:47Installation Installation English30 Vent blockage test After the dryer is installed, start the Vent Blockage Test to check if the duct system is properly installed. The Vent Blockage Test automatically detects the status of the ducts and reports any blockage or problems. Proper ducting can reduce drying time and save energy. NOTE The Vent Blockage Test must run with the dryer in a cool state. If the dryer warms up after the installation check, run the AIR FLUFF cycle for several minutes to reduce its internal temperature. Running the vent blockage test

1. Make sure the drum is empty, and then close the door.

(If there are any clothes or other items in the drum, the test will not give accurate results.)

2. Press POWER to turn the dryer on, then simultaneously press and hold the Adjust

Time and Dry level buttons for 3 seconds. “InS” appears in the dryer’s display. (If you have started other procedures before the Vent Blockage Test, the dryer will not enter the Vent Blockage Test mode.)

3. Press START/PAUSE. The Vent Blockage Test starts immediately. During the test, the

number indicator makes a circle in 6 clockwise steps. The test takes about 2 minutes. Do not open the door during the test.

4. After 2 minutes, when the test is complete, the results is displayed and the dryer

sounds a tone. If status of the duct system is normal, “0” appears and the dryer sounds a completion tone. If the duct system can not exhaust properly, “CLg” appears and the dryer sounds an alarm tone. If there are any other problems, an information code appears in the display. For information about the code, see Information codes section on page 60.

• To stop or cancel the Vent Blockage Test, press POWER to turn off your dryer.

• During the test, if “dc” appears in the display, make sure the door is closed. If “C1” is displayed, see if there is laundry inside drum. If there is, stop the test and remove it. Then, start the test again.

• The results remain on the display for about 5 minutes and then automatically turn off. You can turn the result off immediately by pressing POWER. FlexDry_DM9600M-DC68-03381H-03_EN.indd 30 2017-06-01 3:27:47Installation English 31 NOTE

• During or after the test, the internal drum is hot. Use caution to prevent burns. The Vent Blockage Test is used to check for problems to the current duct system when the dryer is installed for the rst time.

• If the test result displays “CLg” (the duct system is blocked ), refer to the Ducting requirements section on page 18 and the Exhaust ducting guide section below, and then take proper measures to correct any problems. If the test is suspended, it could result in incorrect results. Follow the proper procedures when testing the dryer.

• Even if the test result is normal (“0”), the duct system could be blocked slightly. Properly install all duct work according to the installation instructions in this manual. Exhaust ducting guide Ducting

1. Make sure the dryer is installed properly so the air exhausts freely.

2. Use 4-inch rigid metal ducts. Tape all joints including the dryer connection.

Never use lint-trapping screws.

3. To facilitate the exhaust, keep the ducts as straight as possible.

Cleaning Clean all old ducts before installing the dryer, and make sure the vent ap opens and closes freely. We recommend that you clean the exhaust system annually or on a regular basis. WARNING

• To prevent re, do not use plastic, thin-foil, or non-metal exible ducts of any kind.

• Do not use a poor exhaust system because it slows down the dryer’s performance.

• Do not use excessively long ducts that have multiple elbows.

• Do not use crushed or clogged venting or ducts. FlexDry_DM9600M-DC68-03381H-03_EN.indd 31 2017-06-01 3:27:47Installation Installation English32 Door reversal

1. Unplug the power cord.

2. Remove two door hinge screws.

3. Lift the door and remove it.

NOTE There is a screw on the back side of the hinge that will support the door as you unscrew the hinge screws.

4. Remove the two screws that are

above and below the cut-out in the frame front.

5. Remove the two screws above and

below the lever holder on the opposite side of the door opening.

6. Remove the two screws that hold the

lever holder in place, and then remove the lever holder. FlexDry_DM9600M-DC68-03381H-03_EN.indd 32 2017-06-01 3:27:47Installation English 33

7. Re-insert the two screws that held

the lever holder into the same screw holes, and then tighten.

8. Remove the single screw from the

back of the door hinge. NOTE This is the screw that supports the door against the frame so you can unscrew or screw in the hinge without needing to support the door yourself.

9. Insert the screw you just removed into

the other screw hole on the back of the door hinge, and then tighten.

10. Place the door on the other side, and

then reattach it to the dryer. NOTE Insert the head of the screw on the back of the hinge into the hole above the cut out in the frame, and then slide the door hinge down until it stops. Make sure the protrusion on the back of the hinge is pressed into the cut out before you tighten the hinge screws. FlexDry_DM9600M-DC68-03381H-03_EN.indd 33 2017-06-01 3:27:47Installation Installation English34

11. Push the lever holder into the cut out

on the other side of the door opening. Insert screws, and then tighten as shown.

12. Re-attach the remaining screws to the

remaining holes above and below the lever holder, and then tighten. FlexDry_DM9600M-DC68-03381H-03_EN.indd 34 2017-06-01 3:27:48Before you start English 35 Before you start Here are a few things you should know before starting your dryer. Sort and load

• Put one wash load in the dryer at a time.

• Do not mix heavy and lightweight items together.

• To improve drying efciency for one or two items, add a dry towel to the load.

• For best results, untangle items before inserting them into the dryer.

• Overloading causes uneven drying and wrinkling.

• Unless recommended on the care label, do not dry woolens or berglass items.

• Avoid drying unwashed items.

• Do not dry items soiled with oil, alcohol, gasoline, or other ammable materials. Lint lter

To prevent a risk of re, make sure to clean the lint lter before or after every load.

1. Turn the dryer off.

2. Open the door, and then pull out the

lint lter (A) from inside the drum.

3. Open the lint lter by separating it at

the top. Remove the lint and any other debris that has accumulated in the lter.

4. Close the lint lter, reinsert the lint

lter into the dryer, and then close the dryer door. CAUTION

• Do not operate the dryer without the lint lter in place.

• Do not use a damaged or broken lint lter. This may reduce performance and/or cause a re. FlexDry_DM9600M-DC68-03381H-03_EN.indd 35 2017-06-01 3:27:48Before you start Before you start English36 Drying guidelines The best way to dry items is to follow the instructions on the care label. If no drying instructions are provided, see the following table for reference. Cycle Description Bedspreads & Comforters Follow the care label instructions or dry using NORMAL.

• Make sure the item is thoroughly dry before using or storing.

• May require repositioning in the drum to ensure even drying. Blankets Use NORMAL and dry only one blanket at a time for best tumbling action.

• Make sure blankets are thoroughly dry before using or storing. Curtains & Draperies Use PERM PRESS and the Medium temperature setting to help minimize wrinkling.

• Dry curtains and draperies in small loads for best results and remove as soon as possible after the cycle is complete. Cloth Diapers Use NORMAL and the Medium temperature setting for soft, uffy diapers. Down–lled Items (jackets, sleeping bags, comforters, etc.) Use NORMAL and the Medium temperature setting.

• Add a couple of dry towels to absorb moisture and shorten drying time. Foam Rubber (rug backs, stuffed toys, shoulder pads, etc.) Do not dry on a heat setting. Use AIR FLUFF. WARNING Drying a rubber item with heat may damage it or cause a re. Pillows Use NORMAL.

• Add a couple of dry towels and a pair of clean sneakers to help the tumbling action and to uff the pillows.

• Do not dry kapok or foam pillows using a heated drying cycle. You can dry these items in the dryer only if you use AIR FLUFF. Plastics (shower curtains, outdoor furniture covers, etc.) Use AIR FLUFF or TIME DRY and the Low or Extra Low temperature settings depending on the care label instructions. FlexDry_DM9600M-DC68-03381H-03_EN.indd 36 2017-06-01 3:27:48Before you start English 37 WARNING Do not dry:

• Fiberglass items (curtains, draperies, etc.)

• Wool, silk items, unless recommended on the label

• Items spotted or soaked with vegetable or cooking oils Rack guidelines Flexible rack The exible rack is designed to dry delicate items that are not suitable for or cannot be dried in the Tumble Dryer.

To use the exible rack

1. Locate the rack supports (x4) in each

corner of the Delicate Dryer. Push down the lower area of the front 2 supports to unfold. The rear 2 supports are xed.

2. Insert the exible rack (A) inside the

Delicate Dryer. Make sure all 4 corners of the rack sit on the rack supports properly. NOTE You don’t have to use the drying rack. Put bulky items below the rack and put any additional items on the rack. FlexDry_DM9600M-DC68-03381H-03_EN.indd 37 2017-06-01 3:27:48Before you start Before you start English38

3. Insert a folded dryer sheet in dryer-

sheet case (B), and then put the case at the top center of the rack. Make sure the dryer-sheet case faces the triangle mark on the Delicate Dryer because only the arrow area has the built-in magnet to secure the lter. NOTE If using a large-sized dryer sheet, the dryer-sheet case may not close normally. However, this does not affect the drying performance. Bulky items are easily wrinkled in the Delicate Dryer. Do not dry bulky items in the Delicate Dryer. Please see the Recommended for the Delicate Dryer section for reference. WARNING Do not dry animals, plants, food items, or anything else but clothing. FlexDry_DM9600M-DC68-03381H-03_EN.indd 38 2017-06-01 3:27:49Operations English 39 Operations This FlexDry™ dryer features the Delicate Dryer and the Tumble Dryer for your convenience. The Delicate Dryer is a top load dryer that is designed to dry relatively small loads while the Tumble Dryer is a drum loader you can use to dry normal or relatively heavy loads. The main panel is divided into 2 independent control panels. WARNING To reduce the risk of re, electric shock, or injury, read the Safety information section before operating this dryer. CAUTION Do not spray water onto the main panel . This may cause a system failure. Delicate Dryer Control panel

01 Cycle bar Press to select a cycle. 02 POWER Press to turn the Delicate Dryer on or off. 03 START/PAUSE Press to start operation, or press to stop operation temporarily. 04 Status bar The status bar shows current cycle information and estimated time remaining or an information code if the Delicate Dryer needs to be checked. 05 Time+ Press to increase the drying time in 20-minute increments. You can adjust the drying time up to 100 minutes according to the type and amount of the clothing. 06 Air Dry You can dry heat-sensitive clothing without heat, in room temperature air. Such clothing may require more time to dry. To extend the drying time, use Time+. This option is for the “shirt/ blouse”, “undergarment” and “accessory” cycle. 07 Smart Care The Smart Care function helps you diagnose and troubleshoot your dryer if it has an issue. 08 Smart Control (Elec.) / Smart Monitor (Gas) Press to turn the Smart Control function on or off. You can control or monitor the dryer remotely. When started, the Smart Control (Smart Monitor) indicator blinks. For details, see the Samsung Smart Home section later in this manual. FlexDry_DM9600M-DC68-03381H-03_EN.indd 39 2017-06-01 3:27:49Operations Operations English40 Cycle overview Each cycle of the Delicate Dryer has a predened drying time. You must adjust the drying time manually if necessary. To extend the drying time, use Time+. Cycle Description SHIRT/BLOUSE • For synthetic blouses and blouses with accessories (ornaments) UNDERGARMENT

• For synthetic reshaping innerwear, innerwear with laces, spandex fabrics for Pilates or Yoga, and leggings SWEATER

• For washable wool or wool-blended sweaters, cotton or cotton- blended sweaters, and knitted cardigans ACCESSORY • For scarfs, mufers, gloves, and stockings NOTE

• Make sure you input items appropriate to the selected cycle. Overloads may delay the drying time. To extend the drying time, use Time+.

• Stretch out the items as straight as possible. Overlapping items may not dry well.

• Use the Tumble Dryer for blue jeans, thick clothing, or towels.

• The drying time may depend on the load conditions. To shorten, use a higher spinning speed.

• For manual-wash items, use a towel to remove moisture from the items before drying. FlexDry_DM9600M-DC68-03381H-03_EN.indd 40 2017-06-01 3:27:49Operations English 41 Recommended for the Delicate Dryer

• The drying time depends on the load and the item type. To shorten the drying time, use Super Speed.

• Overloads may delay the drying time. To extend the drying time, use Time+.

• For manual-wash items, use a towel to remove moisture from the items before drying.

• For machine-washable items, you can reduce the drying time by choosing a higher spinning rate.

• Arrange items as even and straight as possible. Overlapped items may not be dried well. Available or recommended items for a specic cycle are as below: Cycle Picture Load Item SWEATER 1 EA (max. 2 EA) Wool or wool-blended sweaters, cotton or cotton-blended sweaters, knitted cardigans SHIRT/BLOUSE 1 EA (max. 2 EA) Synthetic blouses, blouses with accessories (ornaments) UNDERGARMENT 3 EA (max. 6 EA) Synthetic reshaping innerwear, innerwear with laces, spandex fabrics for Pilates or Yoga, leggings ACCESSORY 2 EA (max. 4 EA) Scarfs, mufers, gloves, stockings The max load is calculated on the condition of using the drying rack. FlexDry_DM9600M-DC68-03381H-03_EN.indd 41 2017-06-01 3:27:49Operations Operations English42 Caution Clothing with accessories or hooks may get stuck in the mesh of the rack.

• Clothing with accessories must face upwards.

• Clothing with hooks must be hooked up before being placed. Not Recommended for the Delicate Dryer Do not dry shoes, bags, down/fur products, rugs, carpets, or bulky items in the Delicate Dryer. Use the Tumble Dryer for normal items (ex: blue jeans, bulky cotton items, towels, etc.) FlexDry_DM9600M-DC68-03381H-03_EN.indd 42 2017-06-01 3:27:50Operations English 43 Tumble Dryer Control panel

01 Cycle buttons Each Cycle button activates three separate cycles. Press the button that activates the cycle you want repeatedly until the LED for that cycle illuminates. For more information, see the Cycle overview starting on page 45.

• CYCLE 3: PERM PRESS, TIME DRY, AIR FLUFF 02 POWER Press to turn the Tumble Dryer on or off. 03 START/PAUSE Press to start operation or press to stop operation temporarily. 04 Status bar The status bar shows current cycle information and estimated time remaining or an information code if the Tumble Dryer needs to be checked. 05 Dry Level Press Dry Level to select a dry level.

• Larger or bulkier loads may require Very or More for complete dryness.

• The Damp dry level is designed to partially dry items. Use for items that lay at or hang to dry. NOTE This option is not available with: REFRESH, WRINKLE AWAY, STEAM SANITIZE, ACTIVE WEAR, TIME DRY, and AIR FLUFF. FlexDry_DM9600M-DC68-03381H-03_EN.indd 43 2017-06-01 3:27:50Operations Operations English44 06 Temp. Press Temp. to change the temperature of the current cycle. High: For sturdy cottons or those labeled Tumble Dry. Medium: For permanent press, synthetics, lightweight cottons, or items labeled Tumble Dry Medium. Low: For heat sensitive items labeled Tumble Dry Low or Tumble Dry Warm. Extra Low: Provides the lowest heated drying temperature possible. 07 Time Press Time to select a drying time for the selected cycle. This is available only with TIME DRY, AIR FLUFF, and WRINKLE AWAY. This button is not available for Sensor Dry cycles because exact drying times are determined by uctuating humidity levels. 08 Eco Dry This function is available with NORMAL and TIME DRY. With the Eco Dry activated, drying takes a longer time but power consumption is reduced. The drying time can be extended by up to 3 times normal depending on the temperature and load. The Eco Dry function is enabled by default. 09 Anti Static Anti Static reduces static electricity that occurs from clothing friction. This is done by spraying steam into the drum in a later stage of the drying cycle. NOTE The Anti Static function is only available with NORMAL, HEAVY DUTY, PERM PRESS, DELICATES, and TIME DRY. 10 Wrinkle Prevent Wrinkle Prevent provides approximately 180 minutes of intermittent tumbling in unheated air at the end of the cycle to reduce wrinkling. Press Wrinkle Prevent to activate this feature. The load is dry and can be removed at any time during the Wrinkle Prevent cycle. 11 Adjust Time You can change the set time for the selected cycle. This is available only with TIME DRY, AIR FLUFF, and WRINKLE AWAY. To change the cycle time, press Adjust Time or Adjust Time until the desired time is displayed. FlexDry_DM9600M-DC68-03381H-03_EN.indd 44 2017-06-01 3:27:50Operations English 45 12 Smart Control (Elec.) / Smart Monitor (Gas) After connecting the Tumble Dryer to your home network using the Samsung Smart Home app, you can control or monitor the dryer remotely. When started, the Smart Control (Smart Monitor) indicator blinks. The dryer enters waiting mode and waits for remote commands. Cycle overview Sensor Dry Cycle Description NORMAL

• For most fabrics including cottons and linens.

• If NORMAL is selected, the Eco Dry function is enabled by default. For more information, see Eco Dry in the Control panel section. HEAVY DUTY

• For drying items made out of heavy fabrics, such as jeans, corduroys, or work clothes, with high temperature heat. DELICATES • For heat-sensitive items at a low drying temperature. PERM PRESS

• Use to dry wrinkle-free cottons, synthetic fabrics, knits, and permanent press fabrics automatically. FlexDry_DM9600M-DC68-03381H-03_EN.indd 45 2017-06-01 3:27:50Operations Operations English46 Steam Cycles Cycle Description REFRESH

• Use to smooth out wrinkles and reduce odors in loads of one to four items. With this cycle selected, a small amount of water is sprayed into the dryer drum after several minutes of tumbling with heat. Before removing the laundry, conrm that the laundry load is dry. WRINKLE AWAY

• For best results, load 2-3 items at once. You can extend the drying time by a minimum of 20 minutes, depending on the item type or load. Before removing the laundry, conrm that the laundry load is dry. STEAM SANITIZE

• Use to sanitize items by applying steam and high-temperature heat to the fabric. This cycle can make items soft and reduce smells. Conrm that the laundry load is wet or partially wet before starting this cycle. Manual Dry Cycle Description TIME DRY

• You can specify a cycle time in minutes.

• If TIME DRY is selected, the Eco Dry function is enabled by default. For more information, see Eco Dry in the Control panel section. AIR FLUFF • Tumbles the load in room temperature air. FlexDry_DM9600M-DC68-03381H-03_EN.indd 46 2017-06-01 3:27:50Operations English 47 Simple steps to start

1. Press POWER on the control panel of a desired dryer (Delicate, Tumble) to turn the

2. Put the items you want to dry into the dryer.

4. Change the cycle settings (temperature and/or dry level) as appropriate to the items.

5. Select cycle options as needed.

6. Press START/PAUSE.

To change the cycle during operation

1. Press START/PAUSE to stop operation temporarily.

2. Select a different cycle.

3. Press START/PAUSE again to start the new cycle.

WARNING Do not put anything on top of your dryer while it is running. FlexDry_DM9600M-DC68-03381H-03_EN.indd 47 2017-06-01 3:27:50Operations Operations English48 This product is a smart dryer that supports the Samsung Smart Home service. The amount of time the EZ setup function (for connecting the dryer to your network) can take to complete the network connection varies, depending on your network conditions. Samsung Smart Home Installation Visit the Google Play Store, Galaxy Apps, or Apple App Store and search for “Samsung Smart Home”. Download and install the Samsung Smart Home app provided by Samsung Electronics to your smart device. NOTE

• The Samsung Smart Home app is designed for Android 4.0 (ICS) or higher, or iOS 8.0 or higher, and is optimized for Samsung smartphones (Galaxy S and Galaxy Note series).

• On other devices, some functions may operate differently.

• For improved performance, the Samsung Smart Home app is subject to change without notice. Registering a Samsung account To use the Samsung Smart Home app, you must rst sign in to your Samsung account. If you don’t have a Samsung account, select Register in the app, and then follow the on- screen instructions to create an account. NOTE

• If you have a registered Samsung account, log into your Samsung account. If you have a Samsung smartphone, you can go to the Settings menu on your smartphone, select Accounts, and then sign in to your Samsung account. This will allow you to log in without additional authentication.

• For third-party smart phones, the app account must be the same as the EZ Setup account. FlexDry_DM9600M-DC68-03381H-03_EN.indd 48 2017-06-01 3:27:51Operations English 49 Getting started Using Samsung Smart Home, you can control your dryer from your smart device remotely. For improved performance, the content and design of the app is subject to change without notice.

1. Launch the Samsung Smart Home App on your smartphone.

2. If ‘Dryer’ is not listed, tap Add Device > Select other device > Dryer on the app screen.

3. Press and hold Smart Control on your dryer’s control panel for more than 5 seconds

until the ‘AP’ message appears on the display.

4. When the device registration is complete, turn on the Smart Control function on

your dryer and you can monitor (gas models) or control (electric models) your dryer remotely.

• For gas models, the Dryer app only serves as a monitoring device. You cannot use any of the controls available on the app. FlexDry_DM9600M-DC68-03381H-03_EN.indd 49 2017-06-01 3:27:51Operations Operations English50 Special features Child Lock To prevent children or infants from accidently starting the dryer or setting any of the dryer’s functions, Child Lock locks all buttons except for the POWER button. Note that each dryer operates independently and has its own Child Lock function. To activate the Child Lock

• Press and hold Dry Level and Temp. (or Time+ and Air Dry for the Delicate Dryer) simultaneously for 3 seconds. Then, press START/PAUSE to activate. The door locks and the Child Lock indicator turns on. To deactivate Child Lock temporarily

• You can deactivate Child Lock temporarily for 1 minute. To do this, press and hold Dry Level and Temp. (or Time+ and Air Dry for the Delicate Dryer) simultaneously for 3 seconds. The door is unlocked for 1 minute and the Child Lock indicator blinks. NOTE

• If you open the door 1 minute or more after deactivating Child Lock, an alarm sounds for up to 2 minutes.

• If you close the door within 2 minutes, the door locks and Child Lock is reactivated. If you do not close the door or the door is not properly closed within two minutes, an alarm sounds and the door will not lock.

• To add laundry after activating Child Lock, rst deactivate Child Lock or restart the dryer. To cancel Child Lock

• Press and hold Dry Level and Temp. (or Time+ and Air Dry for the Delicate Dryer) for 3 seconds to deactivate, and then press and hold the buttons again for 3 seconds to release Child Lock. The door unlocks and the Child Lock indicator turns off. FlexDry_DM9600M-DC68-03381H-03_EN.indd 50 2017-06-01 3:27:51Operations English 51 Smart Care The Smart Care function helps you diagnose and troubleshoot your dryer if it has a problem. To enable this function, you must rst download the Samsung Smart Dryer app from the Play Store or the Apple Store, and then install it on a mobile device that has a built-in camera. The Smart Care function has been optimized for Galaxy and iPhone series devices. (It is not supported by some models.) As the dryer operates, it runs a self-diagnosis function in the background. If it senses a problem, it displays an information code on the display which you can scan using the app’s Smart Care function. The Smart Care function will then display detailed information about the code.

1. Press and hold Wrinkle Prevent (or Smart Care for the Delicate Dryer) on the dryer

for 3 seconds to enter the Smart Care mode.

2. Run the Samsung Smart Dryer app on your mobile device, and then tap Smart Care.

3. Hold the mobile device so that the mobile device and the dryer’s status bar face each

other. The app will recognize the information code automatically.

4. When the information code is recognized correctly, the app provides detailed

information about the symptom and recommends further action. NOTE

• The function name, Smart Care, may differ depending on your language.

• If the dryer display is reecting light, the app may fail to recognize the information code.

• If the app fails to recognize the information code a number of times consecutively, enter the information code manually into the app screen.

• The information code history will be deleted after you use this function. Sound Mute or unmute the sound (button beeps, indicator beeps and chimes, etc.) Delicate Dryer

• To mute the dryer’s alarm sound or beeps, press and hold Air Dry and Smart Care for 3 seconds. To unmute, press and hold the same buttons for 3 seconds again. Tumble Dryer

• To mute the dryer’s alarm sound or beeps, press and hold Anti Static for 3 seconds. To unmute, press and hold the same button again for 3 seconds. Drum Light (Tumble Dryer only) The drum light turns on when the door is opened and turns off after 2 minutes. To manually turn the drum light on or off, press and hold Time for 3 seconds. FlexDry_DM9600M-DC68-03381H-03_EN.indd 51 2017-06-01 3:27:51Maintenance English52 Maintenance Keep this your FlexDry™ dryer clean to prevent decreased performance and to lengthen its life. WARNING

• The control board and inlet valve are intentionally not grounded and may present a risk of electric shock only during servicing.

• Service personnel: Do not contact these parts while the appliance is energized. General cleaning and maintenance instructions Main panel

• Clean with a soft, damp cloth. Do not use abrasive substances.

• Do not spray liquid cleaning agents directly on the display of the dryer.

• Some laundry pre-treatment soil and stain removers may damage the main panel.

• When using liquid cleaning agents, apply them to the cleaning cloth. Do not apply them directly to the dryer. Wipe up any spills or overspray immediately. Exterior

• Clean with a soft, damp cloth. Do not use abrasive substances.

• Protect the surface from sharp objects.

• Do not place heavy or sharp objects or a detergent container on the dryer. They can scratch or damage the top cover of the dryer.

• The dryer has a high-gloss nish on its entire surface. Be careful not to scratch or damage the surface. Exhaust system

• Check and clean the exhaust system on a yearly or regular basis to maintain optimum performance.

• The external exhaust hood must be cleaned more frequently to ensure proper air ow. FlexDry_DM9600M-DC68-03381H-03_EN.indd 52 2017-06-01 3:27:51Maintenance English 53 Vent sensor The dryer features a vent sensor that detects and noties you when it is time to clean the ductwork. The indicator lets you know the status of the duct. Level Indicator Status Action 0 Off The ductwork is not clogged. - 1 On

• The duct or lint lter is clogged.

• High pressure being applied to the duct because the duct is too long or bent.

• Check the lint lter or duct and clean if necessary.

• Check the duct connections and shorten or straighten the duct if necessary. 2 Blinking

• The duct or lint lter is severely clogged.

• The pressure applied to the duct is very high because the duct is too long or bent.

• Check and clean the lint lter or duct and make sure they are not clogged.

• Check the duct connections and shorten or straighten the duct work. If the dryer is in the Level 2 state, the indicator blinks for 3 hours after the completion of the current cycle. If you press POWER or open the door, the dryer powers off immediately. NOTE

• For duct installation, see Exhaust ducting guide on page 31 and Ducting requirements on page 18.

• The dryer may keep running even if the duct is clogged, but the drying time will be extended.

• If the indicator turns on for the rst time and is solid (not blinking), check and clean the lint lter and/or duct.

• If the indicator turns on again later, it is because the duct is installed or connected with some restrictions (it’s too long or has too many bends). This is not a system failure. However, drying time may be extended or the drying performance may be degraded. FlexDry_DM9600M-DC68-03381H-03_EN.indd 53 2017-06-01 3:27:51Maintenance Maintenance English54 Delicate Dryer Flexible rack

• If you use the exible rack, make sure to clean the rack after every use so that it is readily available for future use.

• Clean the rack with neutral cleaning agents and running water. Upper recesses

• Clean the left and right rear recesses of the Delicate Dryer after every use.

• Locate the recesses in the rear corners of the Delicate Dryer, and then remove the recess covers on both sides.

• The Delicate Dryer may have collected water while it is operating. After every use or while the Delicate Dryer is operating, remove the covers of the rear recesses, and then clean the recesses using a soft dry cloth.

• By design, the surface of the Delicate Dryer is slanted to facilitate collection of water. Dryer-sheet case

• Clean the Dryer-sheet case with neutral cleaning agents and running water. FlexDry_DM9600M-DC68-03381H-03_EN.indd 54 2017-06-01 3:27:51Maintenance English 55 Tumble Dryer Stainless steel drum

• Clean the drum after every use.

• To clean the stainless steel drum, use a damp cloth with a mild, non-abrasive cleaner suitable for easily marred surfaces. Remove cleaner residue and dry with a clean cloth. Drying rack

• If you used the lower drying rack, make sure to clean the rack after every use so that it will be readily available for future use.

• Clean the drying rack with neutral cleaning agents and running water. FlexDry_DM9600M-DC68-03381H-03_EN.indd 55 2017-06-01 3:27:51Troubleshooting English56 Troubleshooting Checkpoints If the dryer operates abnormally, rst check the list of problems in the table below and try the suggested actions. Symptom Action Does not run.

• Make sure the door is latched shut.

• Make sure the power cord is plugged into a live electrical outlet.

• Check your home’s circuit breakers or fuses.

• Press START/PAUSE again if the door was opened during a cycle.

• Clean the lint lter.

• If you are using the Delicate Dryer but it does not operate properly, you can turn the Tumble Dryer on and see if an information code appears. Does not heat.

• Check your home’s circuit breakers or fuses.

• Some cycles do not require heat. Check the selected cycle again.

• For a gas dryer, make sure the gas supply is on.

• Clean the lint lter and exhaust duct.

• The dryer may have moved into the cool-down phase of the cycle. Does not dry.

• Check all of the above, plus...

• Make sure the exhaust hood outside your home can open and close freely.

• Check the exhaust system for lint buildup. Ducting should be inspected and cleaned annually.

• Use a 4” rigid metal exhaust duct.

• Do not overload. 1 wash load = 1 dryer load.

• Dry heavy items and light weight items separately.

• Large, bulky items, such as blankets or comforters, may require repositioning to ensure even drying.

• The load may be too small to tumble properly. Add a few towels and restart the dryer.

• The load may be too large to tumble properly. Remove some items and restart the dryer.

• Clean the lint lter. FlexDry_DM9600M-DC68-03381H-03_EN.indd 56 2017-06-01 3:27:52Troubleshooting English 57 Symptom Action Is noisy.

• Check the load for objects such as coins, loose buttons, nails, etc. Remove promptly.

• It is normal to hear the dryer gas valve or heating element cycle on and off during the drying cycle.

• Make sure the dryer is leveled properly as outlined in the installation instructions.

• It is normal for the dryer to hum due to the high velocity of air moving through the dryer drum, fan, or exhaust system. Dries unevenly.

• Seams, pockets, and other similarly heavy areas may not be completely dry when the rest of the load has reached the selected dryness level. This is normal. You can choose a higher dryness level or a cycle that involves a higher dryness level.

• If one heavy item is dried with a light weight load, such as one towel with sheets, it is possible that the heavy item will not be completely dry when the rest of the load has reached the selected dryness level.

• For the best drying results, dry heavy items and light weight items separately. Has odors.

• Household odors from paint, varnish, strong cleaners, etc. may enter the dryer with the surrounding room air. This is normal as the dryer draws the air from the room, heats it, pulls it through the drum, and exhausts it outside.

• When these odors linger in the air, completely ventilate the room before using the dryer. Lint on clothes.

• Make sure the lint lter is cleaned before every load. For clothes that naturally build up lint, clean the lter during the cycle.

• Some fabrics are lint producers (for example, a fuzzy white cotton towel) and they must be dried separately from clothes that are lint trappers (for example, a pair of black linen pants).

• Divide larger loads into smaller loads for drying.

• Check pockets thoroughly before drying, then dry clothes.

• Remove lint inside the drum before drying a load. FlexDry_DM9600M-DC68-03381H-03_EN.indd 57 2017-06-01 3:27:52Troubleshooting Troubleshooting English58 Symptom Action Items still wrinkled after Wrinkle Prevent (Wrinkle Away, Wrinkle Release).

• Small loads of 1 to 4 items work best.

• Load fewer items. Load similar-type items.

• Take out the items immediately after drying is complete. Water drips from the nozzle when the Steam cycles starts.

• This is steam condensation. The dripping water will stop after a short time. Sprayed water is not visible during Steam cycles.

• Sprayed water is difcult to see when the door is closed. Extended time.

• Sensor Dry automatically senses the moisture in the load and shuts the dryer off when the selected dryness level is reached. The drying time can change according to the type and amount of laundry. See the cycle chart for reference. If a problem persists, contact a local Samsung service center. FlexDry_DM9600M-DC68-03381H-03_EN.indd 58 2017-06-01 3:27:52Troubleshooting English 59 Samsung Smart Home Symptom Action I could not nd “Samsung Smart Home” in the app market.

• The Samsung Smart Home app is available for smartphones that run Android 4.0 (ICS) or higher, or iOS 8.0 or higher. The Samsung Smart Home app fails to operate.

• The Samsung Smart Home app is available for applicable models only.

• The old Samsung Smart Dryer app cannot connect with Samsung Smart Home models. The Samsung Smart Home app is installed but is not connected to my dryer.

• You must log into your Samsung account to use the app.

• Use the Samsung Smart Home app to connect and register the dryer with your home network access point (AP).

• Make sure that your router is operating normally. Could not log into the app.

• You must log into your Samsung account to use the app.

• If you don’t have a Samsung account, follow the app’s onscreen instructions to create one. An error message appears when I try to register my dryer.

• The connection may fail due to the distance from your access point (AP) or electrical interference from the surrounding environment. Wait a moment and try again. The Samsung Smart Home app is successfully connected to my dryer but does not run.

• Exit and restart the Samsung Smart Home app or unplug your router and then reconnect it. FlexDry_DM9600M-DC68-03381H-03_EN.indd 59 2017-06-01 3:27:52Troubleshooting Troubleshooting English60 Information codes If the dryer fails to operate, you may see an information code on the control panel. To determine what you should do, check the list of codes in the table below, and then try the suggested actions. Code Action Delicate Dryer Tumble Dryer 1 dC dC Operating the dryer with the door open.

• Make sure the door is properly closed.

• Make sure laundry is not caught in the door. 1 FC FC Invalid power source frequency.

• Try restarting the cycle.

• If this information code remains, contact a Samsung service center. 1 AC AC Electronic control problem [Invalid Communication (SUB PBA <-> MAIN PBA)].

• Contact a Samsung service center. 1 HC HC High temperature heating check.

• Clean the lint lter.

• If this information code remains, contact a Samsung service center. - 9C1 The electronic control needs to be checked.

• Check if power is supplied properly.

• If the information code remains, contact a Samsung service center. 1 tC tC The Thermistor1 resistance is very low or high.

• Check for a clogged lint screen .

• Check if the vent system is restricted.

• If this information code remains, contact a Samsung service center. 1tC5 tC5 The Thermistor2 resistance is very low or high.

• Check for a clogged lint screen.

• Check if the vent system is restricted.

• If this information code remains, contact a Samsung service center. - dF Incorrect door switch.

• Contact a Samsung service center. FlexDry_DM9600M-DC68-03381H-03_EN.indd 60 2017-06-01 3:27:52Troubleshooting English 61 Code Action Delicate Dryer Tumble Dryer 1 AC7 - Electronic Control Problem [Invalid Communication (Delicate Dryer MAIN <-> Tumble MAIN PBA)]. If any information code keeps appearing on the screen, contact a Samsung service center. FlexDry_DM9600M-DC68-03381H-03_EN.indd 61 2017-06-01 3:27:52Specications English62 Specications Fabric care chart The following symbols provide garment care direction. The clothing care labels include symbols for drying, bleaching, ironing, and dry cleaning. The use of symbols ensures consistency among garment manufacturers of domestic and imported items. Follow care label directions to optimize garment life and reduce laundering problems. Wash cycle Normal Permanent press / Wrinkle resistant / Wrinkle control Gentle / Delicates Hand wash Water temperature Hot Warm Cold NOTE The Water Temperature table lists appropriate wash water temperatures for various items. The temperature range is 106-126 °F (41-52 °C) for Hot, 84-106 °F (29-41 °C) for Warm, and 61-84 °F (16- 29 °C) for Cold. (Wash water temperature must be a minimum of 61 °F (16 °C) for detergent activation and effective cleaning.) Bleach Any bleach (when needed) Only non-chlorine (color-safe) bleach (when needed) Tumble dry Normal Permanent press / Wrinkle resistant / Wrinkle control Gentle / Delicates Special instructions Line dry / Hang to dry Drip dry Dry at Heat setting High Medium Low Any heat No heat / Air FlexDry_DM9600M-DC68-03381H-03_EN.indd 62 2017-06-01 3:27:54Specications English 63 Iron dry or steam temperatures High Medium Low Warning symbols for laundering Do not wash Do not wring Do not bleach Do not tumble dry No steam (added to iron) Do not iron Dry-clean Dry-clean Do not dry-clean Line dry / Hang to dry Drip dry Dry at Protecting the environment This appliance is manufactured from recyclable materials. If you decide to dispose of this appliance, please observe local waste disposal regulations. Cut off the power cord so that the appliance cannot be connected to a power source. Remove the door so that animals and small children cannot get trapped inside the appliance. FlexDry_DM9600M-DC68-03381H-03_EN.indd 63 2017-06-01 3:27:55Specications Specications English64 Specication sheet

Large load: Fill the drum to about ¾ full. Do not add items over this level as they need to tumble freely.

Medium load : Fill the drum to about ½ full.

Small load : Fill the drum with 3-5 items, not more than ¼ full. Cycle Recommended items Load size Dry Level NORMAL Cottons, work clothes, linens, mixed loads Normal Dry (Adjustable) HEAVY DUTY Heavy Fabrics such as jeans, corduroys, heavy work clothes Normal Dry (Adjustable) BEDDING Bulky items such as blankets, sheets, comforters, pillows Normal Dry (Adjustable) PERM PRESS Shirts, synthetic fabrics, knits, wrinkle-free cottons, permanent press Normal Dry (Adjustable) DELICATES Underwear, blouses, lingerie Normal Dry (Adjustable) ACTIVE WEAR Water-repellent wear, performance clothes, sports wear (Maximum: 4 lbs) Normal Dry (Not adjustable) TIME DRY Any load

AIR FLUFF Foam, rubber, plastic

REFRESH Shirts, trousers, comforters, pillows

• : factory setting, : can be selected Cycle Temperature setting Time setting High Medium Low Extra Low NORMAL

This SAMSUNG brand product, as supplied and distributed by SAMSUNG ELECTRONICS AMERICA, INC. (SAMSUNG) and delivered new, in the original carton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in materials and workmanship for a limited warranty period of:

• One (1) Year All Parts and Labor This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in the United States. To receive warranty service, the purchaser must contact SAMSUNG for problem determination and service procedures. Warranty service can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG’s authorized service center. SAMSUNG will provide in-home service during the warranty period at no charge, subject to availability within the contiguous United States. In-home service is not available in all areas. To receive in-home service, product must be unobstructed and accessible to the service agent. If service is not available, SAMSUNG may elect to provide transportation of the product to and from an authorized service center. SAMSUNG will repair, replace, or refund this product at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specied above. All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG. Replacement parts and products assume the remaining original warranty, or ninety (90) days, whichever is longer. FlexDry_DM9600M-DC68-03381H-03_EN.indd 67 2017-06-01 3:27:55Warranty (U.S.A) English68 This limited warranty covers manufacturing defects in materials and workmanship encountered in normal, noncommercial use of this product and shall not apply to the following: damage that occurs in shipment; delivery and installation; applications and uses for which this product was not intended; altered product or serial numbers; cosmetic damage or exterior nish; accidents, abuse, neglect, re, water, lightning, or other acts of nature or God; use of products, equipment, systems, utilities, services, parts, supplies, accessories, applications, installations, repairs, external wiring or connectors not supplied or authorized by SAMSUNG that damage this product or result in service problems; incorrect electrical line voltage, uctuations and surges; customer adjustments and failure to follow operating instructions, maintenance and environmental instructions that are covered and prescribed in the instruction book; product removal and reinstallation; problems caused by pest infestations. This limited warranty does not cover problems resulting from incorrect electric current, voltage or supply, light bulbs, house fuses, house wiring, cost of a service call for instructions, or xing installation errors. SAMSUNG does not warrant uninterrupted or error-free operation of the product. EXCEPT AS SET FORTH HEREIN, THERE ARE NO WARRANTIES ON THIS PRODUCT EITHER EXPRESS OR IMPLIED, AND SAMSUNG DISCLAIMS ALL WARRANTIES INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANTABILITY, INFRINGEMENT OR FITNESS FOR A PARTICULAR PURPOSE. NO WARRANTY OR GUARANTEE GIVEN BY ANY PERSON, FIRM, OR CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE, OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS, DAMAGE, OR INJURY TO PURCHASER AND PURCHASER’S PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING OUT OF THE USE, MISUSE, OR INABILITY TO USE THIS PRODUCT. THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT, IS NONTRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY. FlexDry_DM9600M-DC68-03381H-03_EN.indd 68 2017-06-01 3:27:55English 69 Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specic rights, and you may also have other rights, which vary from state to state. To obtain warranty service, please contact SAMSUNG at: Samsung Electronics America, Inc. 85 Challenger Road Ridgeeld Park, NJ 07660 1-800-SAMSUNG (726-7864) www.samsung.com/us/support Visits by a Service Engineer to explain functions, maintenance, or installation is not covered by warranty. Please contact the Samsung call center at the number above for help with any of these issues. FlexDry_DM9600M-DC68-03381H-03_EN.indd 69 2017-06-01 3:27:56English70 Warranty (CANADA) SAMSUNG DRYER

LIMITED WARRANTY TO ORIGINAL PURCHASER

This SAMSUNG brand product, as supplied and distributed by SAMSUNG ELECTRONICS CANADA, INC. (SAMSUNG) and delivered new, in the original carton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in materials and workmanship for a limited warranty period of:
