S671QM - Guitar IBANEZ - Free user manual and instructions
Find the device manual for free S671QM IBANEZ in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Solidbody Electric Guitar |
| Brand | Ibanez |
| Model | S671QM |
| Series | S |
| Body Shape | Double cutaway with quilted maple top |
| Body Material | Mahogany |
| Top | Quilted Maple (QM) |
| Neck | Maple, Wizard III |
| Fretboard | Rosewood, 22 jumbo frets |
| Scale Length | 648 mm (25.5 inches) |
| Pickups | 2 Ibanez humbuckers (neck and bridge) |
| Selector | 3-position selector |
| Controls | Volume, tone |
| Bridge | Fixed (Ibanez Gibraltar Standard) |
| Tuners | Ibanez die-cast |
| Dimensions (L x W x H) | Approximately 940 x 320 x 45 mm |
| Weight | Approximately 3.5 kg |
| Power | Passive (no battery required) |
| Maintenance and cleaning | Clean with a soft dry cloth. Oil the fretboard occasionally with lemon oil. Avoid excessive humidity. |
| Safety | Use a stable guitar stand. Protect from shocks and extreme temperatures. |
| Spare parts and repairability | Parts available through authorized Ibanez dealers. Repair by a qualified luthier recommended. |
| General information | Made in Indonesia. 2-year warranty (depending on country). |
Frequently Asked Questions - S671QM IBANEZ
How to change strings on my Ibanez S671QM?
Loosen the tuners, remove old strings, thread new strings through the bridge and tuners, then tune. Use a string winder for easier winding. Refer to a video tutorial if needed.
What type of strings to use for this guitar?
Strings of gauge 9-42 or 10-46 are recommended for standard play. Nickel-plated steel strings offer a good balance between sound and durability.
How to adjust the truss rod of the S671QM?
Use a 4 mm Allen wrench (often included). Turn clockwise to tighten (reduce relief) or counterclockwise to loosen. Make quarter turns and check the action. Be careful not to force it.
How to adjust the intonation of my guitar?
Tune the guitar, then compare the note at the 12th fret with the harmonic. If the fretted note is higher, lengthen the string by moving the bridge saddle backward with a screwdriver. Adjust until both notes are identical.
How to clean the rosewood fretboard?
Use a slightly damp cloth to remove dirt, then apply special lemon oil for fretboards. Let it sit for a few minutes, wipe off excess. Do not use alcohol or harsh detergents.
Are the pickups of the S671QM active or passive?
The pickups are passive, they do not require a battery. The sound is warm and dynamic, ideal for rock and metal.
How to adjust the pickup height?
Loosen the pickup mounting screws, then adjust the height by turning the side screws. Recommended distance is about 3 mm below the string at the last fret for the bridge pickup and 4 mm for the neck pickup. Re-tune after adjustment.
What to do if a fret is dead or volume drops?
If a fret is dead, check if the string touches a higher fret. Adjusting the truss rod or action may solve the problem. If volume drops, check the soldering and potentiometer. Consult a luthier if needed.
How to maintain the tuners?
Clean the tuners with a dry cloth. If they become stiff, apply a drop of light oil (like sewing machine oil) to the shaft. Avoid spray lubricants that can attract dust.
Where to find the serial number of my Ibanez S671QM?
The serial number is usually located on the back of the headstock or on the label inside the pickup cavity. It reveals the year and place of manufacture.
