USER MANUAL Muskoka 7x50 BRESSER

List of Parts B Centre axle C Rubber eyecups D Dioptre adjustment E Body of the binoculars F Lens tube G Central focussing wheel H Eyepiece I Objective lens J Threaded tripod connection

1) Image circle with correctly set eye dis-

tance Eyepieces for spectacle wearers To use the binoculars while wearing glass- es, turn the rubber eyecups (2) towards the sides and down. If you are not wearing glasses, leave the eyecups in the upright position to achieve the required distance from the pupils. Adjusting the eyepiece distance The distance between the eyes diers be- tween individuals. To achieve perfect inter- action between your eyes and the eyepiec- es of your binoculars set the angle at the centre of the binoculars (1) so that you see a circular image (10). Note this setting for later use. Adjusting the focus Look through your binoculars with your right eye closed. Now adjust the image for your left eye using the centre wheel (6) un- til it is sharp and clear. Close your left eye and adjust the image for your right eye us- ing the dioptre ring (3) until it too is sharp and clear. Mounting the binoculars on a tripod Your binoculars have a threaded tripod connection (9) built in. The required tripod adapter is available as an optional acces-10 sory (Art. No. 1916001). With this accessory, you are able to mount your binoculars on all BRESSER tripods with a DIN mounting thread (e.g. Art. No. 4922100). TIPS on cleaning Lenses (eyepieces and/or object lenses) should be cleaned with a soft, lint-free cloth (e.g. microbre) only. Do not use excessive pressure - this may scratch the lens. Dampen the cleaning cloth with a spectacle cleaning uid and use it on very dirty lenses. Protect the device against dirt and dust. Leave it to dry properly after use at room temperature. Then put the dust caps on and store the device in the case provided. Disposal Dispose of the packaging materials pro- perly, according to their type, such as paper or cardboard. Contact your local waste-disposal service or environmental authority for information on the proper dis- posal. Please take the current legal regulations into account when disposing of your device. You can get more information on the pro- per disposal from your local waste-disposal service or environmental authority.11
