Solution EX6190 - Citrus juicers SOLAC - Free user manual and instructions

Product type	Juice extractor
Brand	Solac
Model	Solution EX6190
Dimensions (approx.)	20 x 15 x 30 cm
Weight (approx.)	1.5 kg
Power supply	220-240 V ~ 50/60 Hz, 200 W
Cable length	0.8 m (approx.)
Materials	Plastic body, stainless steel filter
Pressing cones	Large cone (oranges) and small cone (lemons)
Pulp regulation filter	Yes, adjustable (removable and dismountable)
Anti-drip valve	Yes, with open/close position
Juice container	Integrated, capacity approx. 1 L
Pressing arm	Yes, for large cone; manual pressing for small cone
On/off function	By pressing on the cone (automatic stop)
Cleaning	Removable parts dishwasher safe; body to clean with a damp cloth
Safety	Do not immerse motor body; unplug before cleaning; keep out of reach of children
Spare parts	Cones, filter, lid, container available through authorized service
Warranty	Meets legal requirements; requires service through authorized technical service

Frequently Asked Questions - Solution EX6190 SOLAC

How to use the Solac Solution EX6190 juice extractor?

Cut the citrus fruits in half, place a container under the anti-drip valve, then press the half fruit onto the cone by applying pressure with the arm or hand. The appliance stops as soon as pressure is released.

How to adjust the amount of pulp in the juice?

Use the pulp regulation filter: remove the stainless steel filter, place the plastic regulation filter between the two limiting walls and press to snap it back. This allows you to get more or less pulp.

Are the parts dishwasher safe?

Yes, the pressing cone lid, both cones, the stainless steel filter and the juice container can go in the dishwasher. The motor body should only be cleaned with a damp cloth.

How to clean the motor body?

Unplug the appliance, then clean the body with a damp cloth moistened with a few drops of mild detergent. Do not use solvents, bleach or abrasive products. Never immerse the body in water.

Why is my juice extractor not working?

Check that the cable is fully unwound and plugged in. Make sure the accessories are properly assembled and that you are applying sufficient pressure on the cone. If nothing happens, contact the authorized technical service.

Can I press lemons and oranges with the same cone?

No, use the large cone for oranges and the small cone for lemons. The large cone is used with the pressing arm, the small cone by hand.

How to use the anti-drip valve?

The anti-drip valve can be opened or closed according to your needs. Open it to let the juice flow, close it to prevent drips after use.

Where can I find spare parts?

Spare parts are available from authorized Solac technical services. Check the website www.solac.com to find the nearest center.

How to disassemble the pulp regulation filter for cleaning?

The filter consists of two parts. To disassemble it, separate the two parts. To reassemble, place the regulator between the two limiting walls and apply pressure.

What is the warranty for this appliance?

The warranty is established in accordance with current legislation. To assert your rights, contact one of the authorized Solac technical assistance services.

USER MANUAL Solution EX6190 SOLAC

A Press cone cover
B Big cone
C Small cone
D Stainless steel filter
E Housing
F Lever
G Juice deposit
H Anti-drip valve

USE AND CARE:

• Fully unroll the appliance's power cable before each use.
• Do not use the appliance if its accessories are not properly fitted.
• Do not move the appliance while in use.
• Do not use the appliance if it is tipped up and do not turn it over.
• Do not turn the appliance over while it is in use or connected to the mains.
• Store this appliance out of the reach of children and/or those with reduced physical, sensory or mental abilities or those unfamiliar with its use
• Any misuse or failure to follow the instructions for use renders the guarantee and the manufacturer's liability null and void.

INSTRUCTIONS FOR USE BEFORE USE:

• Make sure that all the product's packaging has been removed.
• Before using the product for the first time, clean the parts that will come into contact with food in the manner described in the cleaning section.

USE:

• Unroll the cable completely before plugging it in.
• Connect the appliance to the mains.
• Cut the citrus fruit/s to be squeezed in half.
• Place a glass under the anti-drip valve.
• NOTE: The anti-drip valve can be opened or closed as required (Fig.1).
• Turn on the appliance by pushing down with the pressing handle on the piece of citrus fruit, once

it has been placed on the juicing cone.

• To stop the appliance, simply stop applying pressure to the cone.
• Remove the cone and strainer assembly in order to empty the jar.
• NOTE: If you process large quantities of fruit, you will need to clean the filter and remove the residual pulp on a regular basis.
• NOTE: The bigger cone is for bigger citrus like oranges, and you can press with the lever; the smaller cone is for small citrus like lemon, and you have to press with your hand directly on the cone.

- Pulp regulation filter

• This juicer includes a filter that allows you to adjust the pulp to your liking, to use this filter you must follow these steps:
• Remove the stainless steel filter
• Place the plastic pulp regulation filter correctly.
• NOTE: To make cleaning process easier, the pulp filter, which is composed of two pieces, can be disassembled. To reassemble-it must be taken into account that the regulator must be between the two limiting walls and exert pressure between the two pieces.

- Once you have finished using the appliance:

• Unplug the appliance from the mains.
• Clean the appliance.

CLEANING

• Disconnect the appliance from the mains before undertaking any cleaning task.
• Clean the motor base with a damp cloth with a few drops of washing-up liquid and then dry.
• Do not use solvents, or products with an acid or base pH such as bleach, or abrasive products, for cleaning the appliance.
• Never submerge the motor base in water or any other liquid or place it under running water.
• It is advisable to clean the appliance regularly and remove any food remains.
• If the appliance is not in good condition of cleanliness, its surface may degrade and inexorably affect the duration of the appliance's useful life and could become unsafe to use.
• The following pieces may be washed in a dishwasher (using a soft cleaning program):
• Press cone cover
• Big cone

• Small cone

• Stainless steel filter

• Juice deposit

François

Presse-agrumes SOLAC SOLUTION EX6190

DESCRIPTION

NAPATHPHSEIEI PINTH XPHSH:

-BeBaiWtheOToEExTe aapieoeI Oa Ta uikaokeuaiaocou TpoiovtoC.
- PivxpoiOIOINOeTo TPOiov yia Tpwn
opa, KaapoiTe Ta eepn Tou epoxovta o
ETApn Me TpOPIa OTwC TEPiypaPcEta OTNV
TAPyapoYia Tnv KAthetaTna.

XPHSH:

gjdsblabaiy,slbldeqal j0s aol 15

.111 1

aalaa aai jgag gagaaal aagaaal agagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagagag

( 0 > 0) ( 1 - 1) ( 2 - 1)

山

aayaaag aaiyaaal yaa jay aaiy aaiy ayaaay yaaay aaiy ayaaay ayaaay ayaaay ayaaay ayaaay ayaaay ayaaay ayaaay ayaaay ayaaay ayaaay ayaaay ayaaay ayaaay ayaaay ayaaay ayaaay ayaaay ayaaay ayaaay ayaaay ayaaay ayaaay

jglglll jolal jao glll l

jglg jglg

:Jgai

Espanol

GARANTÍA Y ASISTENCIA TÉCNICA

This product enjoys the recognition and protection of the legal guarantee in accordance with current legislation. To enforce your rights or interests you must go to any of our official technical assistance services.

You can find the closest one by accessing the following web link: http://www.solac.com/

You can also request related information by contacting us.

You can download this instruction manual and its updates at http://www.solac.com/

François

GARANTIE ET ASSISTANCE TECHNIQUE

TAPAHNTN I TEXHnueCKA NOIDEPKKA

3TOT npOdyKT 3aunuHOpnUHeCKo rapaHTneB COOTBETCTBUN C DeIcTByIOUIM3aKoHOdaTeNbCTBOM. UTo6bl oBeCneuNTbco6nOHeH Bawux npab nINn INTepecoB, Bbl DOJXHbI OpaNTbcra B IIO6yIO N3 HaWIXOphiuaNbHbIX cnyx6 no TexHuecko nOndepkKe KJIeHTOB.

Bb mokeTe haTn 6nkaunne n3 ueHTpoB, npoia no cneyuoue Be6-cbInke: http:// www.solac.com/

BbI TaKKe MoXeTe 3anPoCnTb COOTBETCTByIOUyIO HOpMaUHO, CB3aBUncB C HamN (CM. IocNeHIO CTpaHNU pyKOBOdCTBa).

BblMOxTe ckaaTb 3To pykoBoDCTBO n
6HOBHeHn K HEmy No aDpeCy http://
www.solac.com/

Romána

GARANTIE SI ASISTENTÄ TEHNICA

COUNTRY ADDRESS PHONE

Algeria Zone d'Activite, N° 62, Constantine 213770777756
Argentina Av. del Libertador 1298,(B1638BEY), Vicente López (Pcia. Buenos Aires)		541153685223
Belgium Mariëndonkstraat 5, 5154 EG, Elshout 31620401500
Benin 359 Av. Steinmetz, 1930, Cotonou 0299-21313798
Bulgaria	265,Okolovrasten Pat, Mladost 4, 1766, Sofia	35929211120 / 35929211193
Burkina Faso Avenue Bassawarga, 01 BP915, Ouagadougou 226 25301038
Congo (Republic of) 98 Blvd General Charles de Gaulle, Pointe Noire 242066776656
Cyprus	20, Bethlehem Str. / P.O.Box 20430, 2033, Strovolos	35722711300
Czech Republic	Milady Horakove 357/4, 568 02, Svitavy	420 461 540 130
Democratic Republic of the Congo	AV. Pont Canale N° 3440, Kinshasa	00243-991223232
Equatorial Guinea	SN Av Patricio Lumumba y C/ Jesus B, Bata	00240 333 082958 / 00240 333 082453
Equatorial Guinea	Calle de las Naciones Unidas, PO box 762, Malabo	240333082958 / 240333082453
Espana	C/ Avenida de los Olmos 1, Edificio D IV, Oficina 142, 01013, Vitoria-Gasteiz, Álava	94 5030528
Ethiopia Lideta Sub City Kebele 10 H.NO 124, Addis Ababa	[phone]
France	Za les bas musats 18, 89100, Malay-le-Grand	03 86 83 90 90
Gabon	BP 574, Port-Gentil Centre-ville	24101552689 / 24101560698
Ghana	Ederick Place, Accra-Ghana	302682448 / 302682404
Gibraltar 11 Horse Barrack Lane, 54000, Gibraltar 00350 200 75397 / 00350 200 41023
Greece Sapfous 7-9, 10553, Athens [phone]
Guinea BP 206, GN, Conakry (224) 622204545
Hong Kong	Unit H,13/F., World Tech Centre, Hong kong	(852) 2448 0116 / 9197 3519
Hungary Keszthmárk utca 11-13, 1158, Budapest [phone]
India C-175, Sector-63, Noida, Gautam Budh Nagar - 201301, Delhi		([phone]
Ivory Coast 01 Rue Des Carrossiers-Zone 3, B.P 3747, Abidjan 01 (RCI)		22521251820 / 225 21 353494
Jordan 28 Basman St Down town, Amman [phone]
Kuwait	P.O. BOX 3379 hawally, 32034, Hawally	[phone]
Lebanon Damascus Highway; Sciale Building, Jamhour 9615922963
Luxembourg	Mariëndonkstraat 5, 5154 EG, Elshout 31620401500
Mali	BP E2900, Dravela Bolibana	223227216 / 223227259
Marruecos	Avenue 2 Mars, Résidence Nassrallah, Appt n° 2 1er, Casablanca	([phone]
Mauritania	134 Avenue Gamal Abdener Ilot D, Nouakhchott	2225254469 / 2225251258
Mexico Rosas Moreno N° 4-203 Colonia de San Rafael C.P. 06470 – Delegación Cuauhtémoc, Ciudad de México		([phone]
Montenegro	Rastovac bb, 81400, Niksic	[phone]
Netherlands	Mariëndonkstraat 5, 5154 EG, Elshout 31620401500
Nigeria 8, Isaac; John Str, G.R.A Ikeja Lagos 23408023360099
Paraguay	Denis Roa 155 c/ Guido Spano, Asunción	21665100
Peru	Calle los Negocios 428, Surquillo, Lima	[phone]
Portugal Avenida Rainha D. Amélia, n°12-B, 1600-677, Lisboa		[phone]
Romania	Dudesti Pantelimon 23, 410554, Bucharest	031.805.49.58
Serbia	Rastovac bb, 81400, Niksic	[phone]
Slovakia Milady Horakove 357/4, 568 02, Svitavy 420 461 540 130
Southafrica	Unit 25 & 26, San Croy Office Park, Die Agora Road, Croydon, Kempton Park, 1619, Johannesburg	([phone]
Tunisia	2, Rue de Turquie, Tunis	21671333066
Ukraine	Block 6, Ap Housing Estate Topol-2, B, 49000, Dnepropetrovsk	380563704161 / 380563704161
United Arab Emirates	P.O.BOX 8543, Dubai	14506246200
Uruguay	Luis Alberto de Herrera 3468, 11600, Montevideo	598 2209 28 00
Vietnam Lot 7 Ind. Zone for, Ha Noi 84437658111 / 84437658110
