U44406NH3UC2 - Interface Tripp Lite - Free user manual and instructions

Product Type	USB-C Multiport Hub Adapter
Brand	Tripp Lite
Model	U444-06N-H3UC2
Color	Black
Input Connector	USB-C (integrated male)
Output Connectors	1x HDMI 4K (female), 3x USB-A 3.1 Gen 1 (5 Gbps) (female), 1x USB-C PD (female)
Maximum Video Resolution	3840 x 2160 @ 60 Hz (DP 1.4 host) / 3840 x 2160 @ 30 Hz (DP 1.2 host)
HDR Support	Yes, HDR10
HDCP	HDCP 2.2 and backward compatible
USB-A Transfer Speed	Up to 5 Gbps (USB 3.1 Gen 1)
USB-C PD Power	Input charging up to 100 W (20 V, 5 A) and output up to 100 W (pass-through)
USB-A Charging (1 port)	Up to 7.5 W (5 V, 1.5 A)
Total Hub USB-A Ports Power	Shared, up to 8 W (5 V, 1.6 A)
Operating Temperature	0 to 45 °C
Storage Temperature	-10 to 70 °C
Relative Humidity	10 to 90 % RH
Compatibility	Laptops, tablets, and other devices with a USB-C or Thunderbolt 3 port
Required Software	None, Plug and Play
External Power Required	No (bus-powered by host, or via PD port if charging)
Warranty	3-year limited warranty
Care and Cleaning	Wipe with a soft, dry cloth. Do not use liquids or aerosols.
Safety	Use only with compatible devices. Avoid exposure to moisture or extreme temperatures.
Spare Parts and Repairability	No user-serviceable parts. In case of failure, contact Tripp Lite support.

Frequently Asked Questions - U44406NH3UC2 Tripp Lite

Is this USB-C hub compatible with my MacBook Pro?

Yes, the Tripp Lite U444-06N-H3UC2 is compatible with any device that has a USB-C or Thunderbolt 3 port, including MacBook Pro, Windows, Chromebooks, and tablets. It works Plug and Play without drivers.

What is the maximum resolution it can display via HDMI?

The maximum resolution is 3840 x 2160 (4K) at 60 Hz if your host supports DisplayPort 1.4. With a DP 1.2 host, the resolution is limited to 3840 x 2160 at 30 Hz.

Can I charge my laptop via the USB-C PD port?

Yes, the USB-C PD port supports 100 W charging (20 V, 5 A) compatible with Power Delivery 3.0. Plug a wall charger into the hub to recharge your host device.

How many USB devices can I connect simultaneously?

You can connect up to three USB-A devices (thumb drives, mouse, etc.) at USB 3.1 Gen 1 speed (5 Gbps). The fourth USB-A port provides charging (7.5 W). The USB-C PD port is reserved for charging.

Can I use an existing HDMI cable?

Yes, you need to use a standard HDMI cable (sold separately). For best quality at 4K @ 60 Hz, it is recommended to use a high-speed HDMI cable (like Tripp Lite's P568 series).

Does the hub work without an external power supply?

Yes, the hub is bus-powered by the host via the USB-C port. No external power is needed for basic functions (HDMI, USB-A). However, for PD (Power Delivery) charging, a wall charger must be plugged into the hub's USB-C port.

Does the hub support HDR or HDCP?

Yes, it supports HDR10 for better contrast and HDCP 2.2 (backward compatible with earlier versions). It is therefore suitable for streaming protected 4K content.

What is the built-in USB-C cable? Is it replaceable?

The USB-C cable is fixed and about 15 cm long. It is not user-replaceable. If the cable is damaged, the hub must be replaced. Take care not to bend it excessively.

Can I connect a 4K monitor and USB devices at the same time?

Yes, the hub allows simultaneous 4K HDMI output and up to three USB-A devices. The USB-C bandwidth is shared, but for normal use (office, multimedia) this is not an issue.

What to do if my monitor does not display?

Check that your host supports USB-C Alternate Mode (DP Alt Mode). Try a different HDMI cable, and ensure the USB-C port is properly inserted. On some PCs, you may need to enable external display in display settings.

USER MANUAL U44406NH3UC2 Tripp Lite

USB-C Multiport Hub Adapter with 4K HDMI and USB-A Hub Ports, 100W PD 3.0 Charging, Black

Model: U444-06N-H3UC2

USB Type- C^TM and USB- C^TM are trademarks of USB Implementers Forum

Espanol 7 • Français 13 Pycckn 19 • Deutsch 25

WARRANTY REGISTRATION

Register your product today and be automatically entered to win an ISOBAR® surge protector in our monthly drawing! tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support

Copyright © 2020 Tripp Lite. All rights reserved.

Package Contents

• USB-C Multiport Hub Adapter, Black
• Owner's Manual

Optional Accessories

P568-Series High-Speed HDMI Cables
U322-Series USB 3.0 A/B Cables
U420-Series USB-C Cables

Product Features

Supports USB-C DisplayPort 1.4 Alternate Mode for connecting a 4K HDMI display via a USB-C port
Supports Ultra High Definition (UHD) resolutions up to 3840 x 2160 @ 60 Hz (4:4:4) when plugged into a DP 1.4 host
Supports UHD resolutions up to 3840 x 2160 @ 30 Hz when plugged into a DP 1.2 host
Supports High Dynamic Range (HDR) for richer contrast and expanded color accuracy
- 3 USB-A ports support USB 3.1 Gen 1 data transfer speeds up to 5 Gbps
- 1 USB-A port supports charging up to 7.5W (5V 1.5A)

Product Features

• USB-C port supports 100W PD 3.0 charging
  Supports HDCP 2.2 and is backward compatible with previous generations
• Plug-and-play operation with no software or external power required

Installation

1. Connect the built-in USB-C cable to the USB-C or Thunderbolt™ 3 port on your laptop, tablet or other compatible device.
2. Connect the HDMI port to your display with a user-supplied HDMI cable.
3. Connect up to three USB peripherals, such as thumb drives or MP3 players, to the USB-A ports.
4. Connect the host device's AC wall charger to the USB-C port for 100W PD Charging.

Specifications

Input Connector
USB USB-C (Male)
Output Connectors
4K Video HDMI (Female)
USB 3.1 Gen 1(5 Gbps)	(x3) USB-A (Female)
Display
HDMI(with DP 1.4 Host)	3840 x 2160 (4K x 2K) @60 Hz
HDMI(with DP 1.2 Host)	3840 x 2160 (4K x 2K) @30 Hz
Environmental
Operating Temperature	32° to 113°F (0° to 45°C)
Storage Temperature 14	4° to 158°F (-10° to 70°C)
Relative Humidity 10%	to 90% RH
Power Requirements
USB-C PowerDelivery Port	PD 3.0 charging up to100W (20V 5A)
USB-A Port Supports ch	arging up to7.5W (5V 1.5A)
USB-A Hub Ports(Combined)	Shared 8W (5V 1.6A)

Warranty and Product Registration

3-Year Limited Warranty

Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship for a period of 3 years from the date of initial purchase. If the product should prove defective in material or workmanship within that period, Seller will repair or replace the product, at its sole discretion.

THIS WARRANTY DOES NOT APPLY TO NORMAL WEAR OR TO DAMAGE RESULTING FROM ACCIDENT, MISUSE, ABUSE OR NEGLECT. SELLER MAKES NO EXPRESS WARRANTY OTHER THAN THE WARRANTY EXPRESSLY SET FORTH HEREIN. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ALL IMPLIED WARRANTYES, INCLUDING ALL WARRANTYES OF MERCHANTABILITY OR FITNESS, ARE LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE; AND THIS WARRANTY EXPRESSLY EXCUSES ALL INCIDENTAL AND CONSEQUENTIAL DAMAGES. (Some states do not allow limitations on how long an implied warranty lasts, and some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may have other rights which vary from jurisdiction to jurisdiction.)

Warranty and Product Registration

WARNING: The individual user should take care to determine prior to use whether this device is suitable, adequate or safe for the use intended. Since individual applications are subject to great variation, the manufacturer makes no representation or warranty as to the suitability or fitness of these devices for any specific application.

Product Registration

Visit triplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*

• No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
