USER MANUAL DPAC12010H DANBY

• Care and Maintenance

• Garantie KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE: If the unit changes ownership, be sure this manual accompanies the unit. CONSERVER CES INSTRUCTIONS POUR CONSULTATION ULTÉRIEURE: En cas de revente du l’appareil, ce manuel doit être inclus avec l’appareil. Danby Products Ltd, Guelph, Ontario Canada N1H 6Z9 Danby Products Inc, Findlay, Ohio USA 45840Thank you for choosing a Danby Premiere appliance to provide you and your family with all of the “Home Comfort” requirements of your home, cottage, or office. This Owner’s Use and Care Guide will provide you with valuable information necessary for the proper care and maintenance of your new appliance. If properly maintained, your Danby appliance will give you many years of trouble free operation. Please take a few moments to read the instructions thoroughly and familiarize yourself with all of the operational aspects of this appliance. Your Danby Portable Air-Conditioner is a multi-functional room air-exchanging, air-processing appliance, designed to offer you the functions of; Air Conditioning, Dehumidifying, and Independent Fan. Each individual mode is featured with “oscillating” air swing capabilities. This unit can be conveniently moved from room to room within your home and set up in just minutes. Imagine the convenience of 4 Season Home Comfort at your fingertips, anywhere, anytime. For easy reference, may we suggest you attach a copy of your sales slip/receipt to this page, along with the following information, located on the manufacturers nameplate on the rear panel of the unit. Model Number: Serial Number: Date of Purchase: This information will be necessary if your unit requires servicing and/or for general inquiries. To contact a Customer Service Representative, call Danby TOLL FREE: 1-800-26- (1-800-263-2629) WELCOME

1READ ALL SAFETY INFORMATION BEFORE USING

1) Check available power supply and resolve any wiring

problems BEFORE installation and operation of this unit. All wiring must comply with local and national electrical codes and be installed by a qualified electrician. If you have any questions regarding the following instructions, contact a qualified electrician.

2) This appliance draws 10.8 nameplate amps under Cooling

Mode and may be used in any properly wired, general purpose 15 amp household grounded receptacle.

3) For your safety and protection, this unit is grounded through

the power cord plug when plugged into a matching wall outlet. If you are not sure whether the wall outlets in your home are properly grounded, please consult a qualified electrician.

WARNING: Improper connection of the grounding plug can

result in risk of Fire, Electric Shock, and/or injury to Persons associated with the appliance. Check with a qualified service representative if in doubt that the appliance is properly grounded.

4) DO NOT USE PLUG ADAPTERS OR EXTENSION

CORDS WITH THIS UNIT. If it is necessary to use an extension cord with this unit, use an approved “air conditioner” extension cord only (available at most local hardware stores).

5) To avoid the possibility of personal injury, always

disconnect the power supply to the unit before installing and/or servicing. TABLE 1 Suggested Individual Branch Circuit Nameplate Amps *AWG Wire Size

AWG- American Wire Gauge *Based on copper wire at 105°C temperature rating. TABLE 2 Receptacle and Fuse Types Rated Volts 125 Amps 15 Wall Outlet Fuse Size 15 Time Delay Fuse Plug Type (or Circuit Breaker)Control PanelAir OutletSignal ReceptorCastorAir Intake(Evaporator)HandleAir Intake HoseAir Outlet HoseWater Outlet DrainPower Supply Cord

PART IDENTIFICATION CAUTION: Do not leave this unit unattended in a space where people or animals that cannot react to a failed unit are located. A failed unit can cause extreme overheating or death in such an enclosed, unattended space. ELECTRICAL SPECIFICATIONS IMPORTANT SAFETY INFORMATIONThe power cord supplied with this air conditioner contains a device that senses damage to the power cord. To test if your power cord is working properly, you must do the following: Your Kenmore appliance is designed to be highly efficient in energy savings. Follow these recommendations for greater efficiency.

1) Select a thermostat setting that suits your

comfort needs and leave at that chosen setting.

2) The air filter is very efficient in removing

airborne particles. Keep the air filter clean at all times.

3) Use drapes, curtains or shades to keep direct

sunlight from penetrating and heating room, but do not allow drapes or curtains to obstruct the air flow around the unit.

4) Start your air conditioner before the outdoor air

becomes hot and uncomfortable, to avoid an initial period of discomfort while the unit is cooling off the room. Use of the automatic start/stop programmable TIMER feature can be a major asset in this regard if utilized to the fullest extent.

5) When outdoor temperatures are cool enough, turn the

air conditioner off and use the FAN MODE on High, Medium or Low. This circulates indoor air,providing some cooling comfort while utilizing less electricity. NOTE: The power cord supplied with this air conditioner contains a current leakage detection device designed to reduce the risk of fire. In the event the power supply cord is damaged, it cannot be repaired and must be replaced with a new cord from the product manufacturer.

• Under no circumstances should this device be used to turn the unit on or off.

• The “RESET” button must always be pushed in (engaged) for correct operation.

• The power supply cord must be replaced if it fails to reset when the “TEST” button is pushed in.

1) Connect the power supply cord to an electrical outlet.

2) The power supply cord has two buttons located on

the head of the plug. One button is marked “TEST”, and the other is marked “RESET”. Press the “TEST” button; you will hear a click as the “RESET” button pops out.

3) Press the “RESET” button; you will hear a click

as the button engages.

4) The power supply cord is now energized and

supplying electricity to the air conditioner (on some products this is also indicated by a light on the plug head).

POWER SUPPLY CORD ENERGY- SAVING TIPSAir Conditioning Mode ONLY Your window kit has been designed to fit most standard “vertical”/”horizontal” windows up to a maximum height of 80” (203cm). For vertical window applications, multi lock positions are provided on the edge of each slider section to secure each sliding section together.

1) Select a suitable location, making sure you have

access to an electrical outlet.

2) Install the flexible hose to the rear side of the unit.

Insert the hose collar on top of the exhaust opening and twist to lock into position.

3) Install the adjustable Window Slider Kit as

required (see Fig. 3a & 3b).

4) Install the opposite end of the flexible exhaust

hose into the window exhaust adapter.

5) Install the window exhaust adapter into the

opening in the slider section, making sure the window slider sections are secure.

6) Plug the unit into a 115V/60Hz grounded electrical

/3” (72cm) Max.: 80” (203cm) Horizontal Window Vertical Window There should be at least 11.8” (30cm) clearance between the unit and any other objects or building structures, and should be installed on a level surface. The unit does not have to be vented outside during Dehumidifying or Fan Only mode operation. Flexible Exhaust Hose (13cm) & Exhaust nozzle connector (2 pcs) from 17

/6” (135cm) Adjustable window door slider kit (3 pcs) from 28

”(72cm) up to 80” (203cm) Fixture..... (2 pcs) Screws......(12 pcs) NOTE: The exhaust/window kit must be installed at all times when the unit is operating under AIR CONDITIONING mode. ELECTRIC SHOCK HAZARD: To avoid the possibility of personal injury, disconnect power to the unit before installing or servicing. Back of Window Pane Tube Adapters Fig. 2 Instructions for Assembling the Window Kit- Fig. 2

1) Insert tube adapters through the back of the window panel.

2) Secure each tube adapter with four screws through the front of the

3) Insert window panel extensions into window panel. Lightly tighten

the screws in the window panel to hold the extensions in place. Fig. 3a Fig. 3b

INSTALLATION WARNING WINDOW KIT Fig. 1 INSTALLATION ACCESSORIES Flexible Exhaust Hose Exhaust Nozzle Connector Fixture Adjustable Window Slider Kit: 28 1/3” (72cm)- 80” (203cm) Screws Water hose (79”/ 200cm)KEY PAD FUNCTIONS POWER SWITCH: Turns unit ON/OFF MODE: Allows you to scroll through and select desired operating mode. FAN: Select from three different fan settings; High, Medium, and Low. AUTO-TIMER AUTO-TIMER Adjust: Auto off- With machine in running mode, press timer button to set timer control. Press or buttons to select number of hours you would like the unit to run before it automatically shuts off. Auto on- With machine in stand by mode, press timer button to set timer control. Press or buttons to select number of hours before the unit automatically starts running in air conditionning mode. NOTE: The time is adjustable between 1-24 hours. TEMPERATURE Adjust:

• In cooling mode, when button is pressed, the set temperature is displayed and may be adjusted. After 15 seconds the display will revert back to room temperature. Temperature is only adjustable in cool mode. Timer & Temp. Display Room Temp. Temp. Set Timer Set

MODE INDICATOR LIGHTS

Cooling Mode When cool mode is selected, the indicator light will shine GREEN. During the cooling mode, the air is cooled and hot air is exhausted outside through the exhaust tube. Adjust fan speed to suit your desired comfort level. Note: The air exchange h ose must vent outside the room when using cool mode. Dehumidify Mode When dehumidify mode is selected, the indicator light will shine ORANGE. Air is dehumidified as it passes through the unit, without being in full cooling mode. The fan will operate on med. speed. If room temperature is >25°C (77°F), fan speed can be adjusted; otherwise fan speed is fixed to “low”. Note: The warm air exchange hose must vent inside the room when using Dehumidify Mode, not outside as it does when cooling. If the unit is vented outside, some cooling will occur. Fan Mode When fan mode is selected, the indicator will shine YELLOW. Air is circulated throughout the room with no cooling. Note: The unit does not need to be vented in Fan mode. Heating Mode When heating mode is selected the indicator will shine RED. Heating is activated only when the ambient temperature is below 25°C (77°F).

FAN SPEED INDICATOR LIGHTS

High Fan Medium Fan Low Fan NOTE: By pressing both buttons at the same time for more than 3 seconds, the display will toggle between Celsius and Fahrenheit. STATUS DISPLAY Warning Light Condensed water may accumulate in the unit. If the internal tank becomes full, the Warning signal in the LCD Display will light up and the unit will not operate until the unit has been drained. NOTE: After switching the air conditioner off, you must wait 3 minutes before switching it back on again.

OPERATION FEATURES OF THE CONTROL PANELAIR CONDITIONER Note: The exhaust hose must be properly vented (outdoors) during air conditioning mode.

1) Press the POWER SWITCH key (Fig. A) to switch on the unit, and the previous

set temperature will be shown in the temperature display area of the control panel.

2) Press the MODE key (Fig. B) until the COOL indicator light illuminates on the

suitable operating temperature setting. Temperature settings are adjustable between 16°C (61°F) to 32°C (89°F).

4) Press the FAN key (Fig. E) to select the desired fan speed setting (Auto-High-

Med.-Low). Your selection will appear on the control panel (each depression of the fan key will advance to a different setting).

• Cooling stops automatically when the set temperature is achieved. Cooling resumes when the room temperature rises above the “set” temperature level. DEHUMIDIFIER Note: During dehumidifier mode, the exhaust hose does not have to be vented outdoors.

1) Press the ON/OFF key pad to switch the unit on (Fig. A)

2) Press the MODE key (Fig. B) until the DRY indicator illuminates on the control

(Fig. E) to select the desired FAN SPEED setting. Your selection will appear on the control. Each depression of the fan key will advance to a different fan speed as shown in Fig. F. Otherwise fan speed is fixed to “low”. NOTE: The warm air exchange hoses must vent inside the room when using Dehumidifier Mode, not outside as in Cooling Mode. FAN Note: During Fan Mode, the exhaust hose does not have to be vented outdoors.

1) Press the POWER SWITCH key to turn the unit on (Fig. A).

2) Press the MODE key (Fig. B) until the FAN indicator illuminates on the control

panel (Fig. H). Each press of the MODE key will advance to a different mode setting (Cool-Dehumidifier-Fan-Heat-Auto).

3) Press the FAN Key (Fig. E) to select the desired FAN SPEED setting. Your

selection will appear on the control panel. Each press of the fan key will advance to a different fan speed (High- Med- Low) as shown in Fig. F. HEAT Note: During Heat Mode, the exhaust hose does not have to be vented outdoors.

1) Press the POWER SWITCH key (Fig. A) to switch on the unit, and the previous set

temperature will be shown in the temperature display area of the control panel.

2) Press the MODE key (Fig. B) until the Heat indicator light illuminates on the control

panel (Fig. I). Each depression of the MODE key will advance to a different mode setting (Cool- Dehumidifier- Fan- Heat).

3) Press the appropriate increase or decrease buttons (Fig D) to select a

suitable operating temperature setting. Temperature settings are adjustable between 16°C (61°F) to 27°C (80°F).

4) Press the FAN key (Fig. E) to select the desired fan speed setting (High- Med.-

Low). Your selection will appear on the control panel (each depression of the fan key will advance to a different setting)

• Heating stops automatically when the set temperature is achieved. Heating resumes when the room temperature rises above the “set” temperature level. Fig. A Fig. F Fig. G

OPERATION (cont’d) Fig. B Fig. C Fig. D Fig. E High Medium Low Orange Green Fig. H Yellow Fig. I RedThe AUTO-TIMER feature offers a unique selection of multiple choice, fully automatic on and/or off (start/stop) programs between 1-24 hours under any one mode of your Home Comfort unit. The programs are as follows: a) Auto-Off: Pre-select a time that will turn off the unit automatically (between 1-12hrs). b) Auto-On: Pre-select a time that will turn on the unit automatically (between 1-12hrs). c) Auto-On & Auto Off: Pre-select a time that will turn the unit ON / OFF automatically at specified times (between 1-12hrs). Note: These functions must be performed daily, as the program is automatically canceled/erased after the program has ended. Control Buttons:

• Used for adjusting the timer and temperature.

• The default display on control panel is room temperature.

• When or key is pressed in cool mode, the set temperature is displayed and may be adjusted. After 10 seconds, the display will revert back to room temperature.

• Timer setting is available from 1-24 hours by pressing or keys. To operate the hand held remote control you will require two “AAA” Alkaline batteries (included). Batteries should be replaced when: a) No signal (beep) is heard when attempting to program the main unit. b) The main unit does not respond to a command issued by the remote control. Battery replacement:

1) Slide the rear cover on the remote in the direction of the arrow. Continue pulling (gently) until the cover

separates completely from the unit.

2) Insert (2) batteries (AAA) following the same orientation (polarity) depicted inside the battery chamber (+ / -).

3) Re-install rear cover.

4) If the remote control will not be used for extended periods of time, batteries should be removed.

The remote operates within a range of 8 meters (26 ft.) from the receiver located inside the main unit. Any obstruction between the receiver and remote may cause signal interference, limiting the ability to program the unit. Notes:

1) Do not drop the remote control.

2) Do not place the remote control in a location exposed to direct sunlight.

3) The remote control should be placed about 1 meter or more away from TV, or any electrical appliances.

5CAUTION: Before cleaning or servicing this unit, disconnect from any electrical supply outlet.

1) DO NOT use gasoline, benzene, thinner, or any

other chemicals to clean this unit, as these substances may cause damage to the finish and deformation of plastic parts.

2) Never attempt to clean the unit by pouring water

directly over any of the surface areas, as this will cause deterioration of electrical components and wiring insulation.

4) Clean the unit by wiping off any dirt/dust with a

soft damp cloth or vacuum cleaner, then wipe dry with a dry soft cloth. CAUTION: Always store the unit in vertical position. DO NOT put heavy objects on top of the unit. If the air filter becomes clogged with dust/dirt, air flow is restricted, which reduces cooling efficiency. The air filter should be cleaned every two (2) weeks. More frequent cleaning may be necessary depending on indoor air quality. NOTE: The air filter is located at the upper rear side of the unit.

1) To remove the air filter: Pull the air filter cover upward in the direction of the

arrow (Fig. 4) and remove the air filter.

2) Dust/dirt clogged in the filter can be removed by vacuum cleaning the soiled

3) The filter can also be washed in lukewarm, soapy water while rubbing it lightly

with a brush. A mild detergent (diswashing liquid) is recommended.

4) Rinse the filter well using clean water. Allow time to dry before reinstalling

5) Replace the air filter and cover.

6) Replacement air filter information is available by contacting the Customer Service

Department at: 1-800-26- (1-800-263-2629). CAUTION: Never operate this unit without the air filter in place, as this may result in damage to the unit. Fig. 4

CARE AND MAINTENANCE

CLEANING THE UNIT CLEANING THE AIR FILTER 8TROUBLESHOOTING

PROBLEM POSSIBLE CAUSE SOLUTIONS

1) Unit does not work

• The plug is not plugged in properly.

• The full-tank indicator is ON; tank is full.

• Current leaking or pressing test button on LCDI plug.

• Wait for power to return.

• Remove drain water from the drain tank.

• Press the reset button after resolving problem.

2) Unit suddenly stops during operation.

• Indoor set temperature has been reached.

• The preset time is up.

• The full-tank indicator is ON; tank is full.

• Remove drain water from the drain tank.

3) Unit runs intermittently

• Surrounding temp. is too high/low.

• Exhaust duct hose is blocked.

• Contact your dealer.

• Check the duct hose.

4) Unit functions but the room is not

• Window or door is open in room.

• There is a heat source or too many people in the room.

• Air intake grill is clogged.

• Filter is too dirty.

• Temperature setting is too high.

• Close all windows/doors.

• Move any heat sources from room.

• Clean air intake grill.

• Lower temp. setting.

5) Condensed water spills out when

• The tank is nearly full.

The model number can be found on the serial plate located on the back panel of the unit. All repair parts are available for purchase or special order when you visit your nearest service depot. To request service and/or the location of the service depot nearest you, call the TOLL FREE NUMBER. When requesting service or ordering parts, always provide the following information:
