USER MANUAL NK30K7000WG SAMSUNG

APPROVED FOR RESIDENTIAL APPLIANCES

FOR RESIDENTIAL USE ONLY

READ AND SAVE THESE INSTRUCTIONS

PLEASE READ ENTIRE INSTALLATION GUIDE BEFORE PROCEEDING. INSTALLATION MUST COMPLY WITH ALL LOCAL CODES. IMPORTANT: Save these Instructions for the Local Electrical Inspector’s use. INSTALLER: Please leave these Instructions with this unit for the owner. OWNER: Please retain these instructions for future reference. Symbols used in this manual WARNING Hazards or unsafe practices that may result in severe personal injury or death. CAUTION Hazards or unsafe practices that may result in electric shock, personal injury, or property damage. NOTE Useful tips and instructions These warning icons and symbols are here to prevent injury to you and others. Please follow them explicitly. After reading this section, keep it in a safe place for future reference. WARNING Turn off power circuit at service panel and lock out panel before wiring this appliance. Requirement 120 VAC, 60 Hz. 15 or 20 A Branch Circuit State of California Proposition 65 warning (US only) WARNING This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

CAUTION FCC CAUTION: Any changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of FCC Rules. Operation is Subject to following two conditions:

1) This device may not cause harmful interference, and

2) This device must accept any interference received including

interference that cause undesired operation. For products sold in the US and Canadian markets, only channels 1~11 are available. You cannot select any other channels. Important Safety Instructions Important Safety Instructions FCC STATEMENT: This equipment has been tested and found to comply within the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorienting or relocating the receiving antenna

• Increasing the separation between the equipment and receiver

• Connecting the equipment to an outlet that is on a different circuit than the radio or TV

• Consulting the dealer or an experienced radio/TV technician for help. FCC RADIATION EXPOSURE STATEMENT: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated so there is at least 8 inches (20 cm) between the radiator and your body. This device and its antenna(s) must not be co-located or operated in conjunction with any other antenna or transmitter.

The term “IC” before the radio certication number only signies that Industry Canada technical specications were met. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. This Class B digital apparatus complies with Canadian ICES-003. For products sold in the US and Canadian markets, only channels 1~11 are available. You cannot select any other channels. IC RADIATION EXPOSURE STATEMENT: This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated so there is at least 8 inches (20 cm) between the radiator and your body. This device and its antenna(s) must not be co-located or operated in conjunction with any other antenna or transmitter.4 English Important Safety Instructions WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING PRECAUTIONS: ■ Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer. ■ Before servicing or cleaning the unit, switch the power off at the service panel and lock the service panel to prevent power from being switched on accidentally. If the service panel cannot be locked, securely fasten a prominent warning device, such as a tag to the service panel. ■ Installation work and electrical wiring must be done by qualied person(s) in accordance with all applicable codes and standards, including re-rated construction. ■ Sufcient air is needed for proper combustion and exhausting of gases through the ue (chimney) of fuel burning equipment to prevent backdrafting. Follow the heating equipment manufacturer’s guideline and safety standards such as those published by the National Fire Protection Association (NFPA), the American Society for Heating, Refrigeration and Air Conditioning Engineers (ASHRAE), and the local code authorities. ■ When cutting or drilling into the wall or ceiling; do not damage electrical wiring and other hidden utilities. ■ Ducted fans must always be vented outdoors. CAUTION For general ventilating use only. Do not use to exhaust hazardous or explosive materials and vapors. CAUTION To reduce risk of re and to properly exhaust air, be sure to duct air out- side - do not vent exhaust air into spaces within walls or ceilings, attics or into crawl spaces, or garages.

WARNING TO REDUCE THE RISK OF FIRE, USE ONLY METAL DUCTWORK WARNING TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE: ■ Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may ignite. Heat oils slowly on low or medium settings. ■ Always turn the hood ON when cooking at high heat or when ambeing food (i.e. Crepes Suzette, Cherries Jubilee, Peppercorn Beef Flambé). ■ Clean ventilating fans frequently. Grease should not be allowed to accumulate on the fan or lter. ■ Use proper pan sizes. Always use cookware appropriate for the size of the surface element. WARNING TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A RANGE TOP GREASE FIRE, OBSERVE THE FOLLOWING PRECAUTIONS:

■ SMOTHER FLAMES with a close tting lid, cookie sheet, or metal tray, then turn off the burner. BE CAREFUL TO PREVENT BURNS. If the ames do not go out immediately, EVACUATE AND CALL THE FIRE DEPARTMENT. ■ NEVER PICK UP A FLAMING PAN - you may get burned. ■ DO NOT USE WATER, including wet dishcloths or towels - a violent steam explosion will result. ■ Use an extinguisher ONLY if: -You know you have a class ABC extinguisher, and you already know how to operate it. – The re is small and contained in the area where it started. – The re department is being called. – You can ght the re with your back to an exit.

Based on “Kitchen Fire Safety Tips” published by NFPA.

WARNING To reduce the risk of re or electrical shock, do not use this fan with any solid-state speed control device. This hood is suitable for mounting over gas ranges with a maximum power of 59,000 BTU’s only. WARNING Do not let children near this appliance. Do not let children play with this appliance. Keep all packaging materials out of children’s reach. Properly dispose the packaging materials after this appliance is unpacked. Important Safety Instructions Read and save these InstructionsEnglish 5 Electrical Requirements IMPORTANT Observe all governing codes and ordinances. It is the customer’s responsibility: To contact a qualied electrical installer. To assure that the electrical installation is adequate and in conformance with National Electrical Code, ANSI/NFPA 70 — latest edition*, or CSA Standards C22.1-94, Canadian Electrical Code, Part 1 and C22.2 No.0-M91 - latest edition** and all local codes and ordinances. If codes permit and a separate ground wire is used, it is recommended that a qualied electrician determine that the ground path is adequate. A copy of the above code standards can be obtained from: National Fire Protection Association 1 Batterymarch Park Quincy, MA 02169-7471 CSA International 8501 East Pleasant Valley Road Cleveland, OH 44131-5575 ■ A 120 volt, 60 Hz., AC only, 15-amp, fused electrical circuit is required. ■ If the house has aluminum wiring, follow the procedure below:

1. Connect a section of solid copper wire to the pigtail leads.

2. Connect the aluminum wiring to the added section of

copper wire using special connectors and/or tools designed and UL listed for joining copper to aluminum. ■ Follow the electrical connector manufacturer’s recommended procedure. Aluminum/copper connection must conform with local codes and industry accepted wiring practices. ■ Wire sizes and connections must conform with the rating of the appliance as specied on the model/serial rating plate. The model/serial plate is located behind the lter on the rear wall of the range hood. ■ Wire sizes must conform to the requirements of the National Electrical Code, ANSI/NFPA 70 (latest edition), or CSA Standards C22. 1-94, Canadian Electrical Code, Part 1 and C22.2 No. 0-M91 (latest edition and all local codes and ordinances. Venting Requirements

• Vent system must terminate outdoors.

• Do not terminate the vent system in an attic or other enclosed area.

• Do not use a 4” (10.2 cm) laundry-type wall cap.

• Use metal vent only. Rigid metal vent is recommended. Plastic or metal foil vent is not recommended.

• The length of the vent system and the number of elbows should be kept to a minimum to provide efcient performance. For the most efcient and quiet operation:

• Use no more than three 90° elbows.

• Make sure there is a minimum of 24” (61 cm) of straight vent between the elbows if more than 1 elbow is used.

• Do not install 2 elbows together.

• Use clamps to seal all joints in the vent system.

• The vent system must have a damper. If the roof or wall cap has a damper, do not use the damper supplied with the range hood.

• Use caulking to seal the exterior wall or roof opening around the cap.

• The size of the vent should be uniform. Venting Methods This canopy hood is factory set for venting through the roof or wall. A 6” (15.2 cm) round vent system is needed for installation (not included). The hood exhaust opening is 6” (15.2 cm) round. NOTE Flexible vent is not recommended. Flexible vent creates back pressure and air turbulence that greatly reduce performance. The vent system can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed. Mounting Height Select a mounting height between a minimum of 24” (61 cm) for an electric cooking surface, a minimum of 30” (76.2 cm) for a gas cooking surface, and a suggested maximum of 36” (91.4 cm) above the range to the bottom of the hood. Rear discharge A 90° elbow may be installed immediately above the hood. Roof Venting Wall Venting

A. Roof capB. 6” (15.2 cm) round ventA.Wall capB. 6” (15.2 cm) round vent Installation Requirements Installation Requirements6 English Tools and Parts Parts supplied Removing the packaging CAUTION Remove the carton carefully. Wear gloves to protect against sharp edges. WARNING Remove the protective lm covering the product before putting into operation.

• Hood canopy assembly with blower and LED lamps already installed.

• Hardware bag with: Part Qty Part Qty 5x45 mm 5.4x75 mm screws (for 10x60 mm wall anchors) 8x40 mm

Tools/Materials required

• Drill with 1¼” (3.2 cm),

• Wire stripper or utility knife

• Tape measure or ruler

• Caulking gun and weatherproof caulking compound

• Jigsaw or keyhole saw

• Flat-blade screwdriver

• Phillips & Torx 20 screwdrive

• Home power supply cable

• ½” (12.7 mm) UL listed or CSA approved strain relief

• 3 UL listed wire connectors

• Metal vent system Dimensions and Clearances

⁄64” (64.5 cm) D 6” (15.24 cm) E 10

⁄64” (6 cm) *For vented installations Installation Requirements Installation RequirementsEnglish 7 Installation Installation Instructions Preparing the Location

• We recommend you install the vent system before you install the hood.

• Before making cutouts, make sure there is proper clearance within the ceiling or wall for the exhaust vent.

• Check your ceiling height and the hood height maximum before you select your hood.

1. Disconnect power.

2. Determine which venting method to use: roof or wall.

3. Select a at surface for assembling the range hood.

Place a covering over that surface. WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO

PERSONS, OBSERVE THE FOLLOWING

4. Using 2 or more people, lift the range hood onto covered surface.

Range hood mountig screws installation

1. Determine and mark the centerline on the wall where the

canopy hood will be installed. Disconnect power.

2. Select a mounting height between a minimum of 24” (60.9 cm)

for an electric cooking surface, a minimum of 30” (76.2 cm) for a gas cooking surface, and a suggested maximum of 36” (91.4 cm) above the range to the bottom of the hood. Mark a reference line on the wall.

3. Tape the template in place, aligning the template centerline and the

bottom of the template with the hood bottom line and with the centerline marked on the wall.

A. Centerline B. Fastener locationsC. Mounting height reference (hood bottom line)

4. Mark the fastener locations by pushing a pen or pencil tip through the

template into the wall. IMPORTANT: All screws must be installed into wood. If there is no wood to screw into, additional wall framing supports may be required.

⁄16” (4.8 mm) pilot holes at all locations where screws are being installed into wood.

7. Install the 2 - 5 x 45 mm mounting screws. Leave a

⁄4”(6.4 mm) gap between the wall and the back of the screw head so you can slide the range hood into place. 1⁄4” (6.4 mm) Vent cover bracket installation

1. Attach the vent cover bracket to the wall ush to the ceiling using

2 - 5 x 45 mm screws.

A. 8 x 40 mm drywall anchorsB. Centerline on wallC. Vent cover support bracketD. 5 x 45 mm screws Complete Preparation

1. Determine and make all necessary cuts in the wall for the

vent system. Install the vent system before installing the hood. See the “Venting Requirements” section.

2. Determine the required height for the home power supply

cable and drill a 1¼” (3.2 cm) hole at this location.

3. Run the home power supply cable according to the National

Electrical Code or CSA Standards and local codes and ordinances. There must be enough wire from the fused disconnect (or circuit breaker) box to make the connection in the hood’s electrical terminal box. NOTE Do not reconnect power until installation is complete.

4. Use caulk to seal all openings.

Installing the range hood

1. Using 2 or more people, hang the range hood on 2 mounting

screws by inserting the mounting screws through the mounting slots on the back of the hood.

A. Mounting screws B. Mounting slots C. Lower mounting screws

2. Mark the lower mounting hole’s location with a pencil.

3. Remove the hood assembly from the wall, and then drill

⁄16” (4.8 mm) pilot holes at the marked locations.

4. Hang the range hood again on the 2 upper mounting screws.

5. Level the range hood and tighten the upper mounting screws.

6. Install the 2 - 5 x 45 mm lower mounting screws and tighten.

Use the optional wall anchors if needed. Installation8 English Connecting the Vent System This hood is compatible with vented installations only.

1. Install the transition on the top of the hood (if removed for shipping)

A. Vent transition B. 3.5 x 9.5 mm screw

2. Fit the vent system over the exhaust outlet.

3. Measure from the bottom of the air deector to the bottom of the

hood outlet. Cut the ductwork at the measured lenght. Dimensionto measure Roof outlet Wall outlet

4. Seal the connection with clamps.

5. Check that the back draft dampers work properly.

Electrical Connection

WARNING Electrical Shock Hazard Disconnect power before servicing. Replace all parts and panels before operating. Failure to do so can result in death or electrical shock.

1. Disconnect power.

2. Remove the terminal box cover.

3. Remove the knockout in the terminal box cover and install

a UL listed or CSA approved

4. Run the home power supply cable through the strain relief into the

A. Home power supply cableB. UL listed or CSA approved strain reliefC. Black wires (Normally L1. Conrm before connecting.)D. UL listed wire connectorsE. White wires (Normally neutral. Conrm before connecting.)F. Green (or bare) and yellow-green ground wires

5. Use UL listed wire connectors and connect the black wires

6. Use UL listed wire connectors and connect the white wires (E)

WARNING Electrical Shock Hazard Electrically ground blower. Connect the ground wire to the green and yellow ground wire in the terminal box. Failure to do so can result in death or electrical shock.

7. Connect the green (or bare) ground wire from the home power

supply to the yellow-green ground wire (F) in the terminal box using UL listed wire connectors.

8. Tighten the strain relief screw.

9. Install the terminal box cover.

10. Reconnect the power.

Installation InstallationEnglish 9 Installation Installing the duct covers When using both upper and lower vent covers, push the lower cover down onto hood and lift the upper cover to the ceiling and install with two mounting screws. NOTE The upper vent cover may be reversed to hide the slots.

A. Upper vent coverB. Lower vent coverC. 4.2 x 8 mm screwsD. Bracket Secure the bottom of the duct with 2 - 4.2 x 8 mm screws. Completing the Installation

1. Install the metal bafe lters. See the “Range Hood Care” section.

2. Check the operation of the range hood blower and light.

See the “Range Hood Use” section. NOTE To get the most efcient use from your new range hood, read the “Range Hood Use” section.

Range Hood Description The range hood is designed to remove smoke, cooking vapors, and odors from the cooktop area. For best results, start the hood before cooking and allow it to operate several minutes after cooking is complete to clear all smoke and odors from the kitchen. The hood controls are located on the front side.

• Press again and the hood will return to sleep mode. LOW

• Press the LOW button and the hood will be activated at Low speed. MED

• Press the MED button and the hood will be activated at Medium speed. HIGH

• Press the HIGH button and the hood will be activated at High speed. BOOST

• Press the BOOST button and the hood will be activated at Maximum speed for 10 minutes.

• After 10 minutes, the hood will slow to High speed. Timer Display

• Shows the timer settings. Timer Setting the timer ON

• Press the Timer button to set the working time.

• Each time you press the Timer, you add 10 minutes to the displayed time, up to a maximum of 99 minutes. The hood will stay on for the amount of time you have set.

• After the Timer counts down to zero, the Timer LED light will start to blink.

• The Timer LED will blink for 5 seconds, and then the hood will turn off automatically. Setting the timer OFF

• Press the Timer button for 3 seconds and the Timer function will turn off. Light

• Press the Light button and the lamps will turn on.

• Press the Light button again and the lamps will turn off. Sound Muting / Unmuting the hood.

• Press and hold the Light button for 3 seconds to turn off the hood sounds.

• Press and hold again to turn on the sounds.

COOKTOP AND RANGE HOOD CONNECTIVITY

This appliance has a feature which allows you to pair compatible Sam- sung cooktops and your hood via Bluetooth. After you enable this function and pair your hood and a compatible cook- top, the hood fan will automatically come on at Low speed when you turn on a cooktop element. The hood fan will also shut off automatically when you turn off the cooktop elements. In addition, after the hood and compatible cooktop are paired, you can download the Samsung Smart Home app to a mobile device, and then use the Samsung Smart Home app to:

• Monitor and control the On/Off status of the hood.

• Monitor and control the fan speed.

• Monitor and control the lights.

• Set the hood shut-off timer with the time-up alarm. For more information about downloading the Samsung Smart Home app to your mobile device and using it to control your hood, visit:

activated and the indicator on the Bluetooth button will blink.

2. Press the Bluetooth button on cooktop.

NOTE For a detailed description of the pairing method, see the user manual of a compatible Samsung cooktop.

3. After the pairing proccess nishes, the Bluetooth light will stay lit

and appears in the display. Bluetooth disconnection (Pairing reset)

1. Press and hold the Bluetooth button on the hood for 3 seconds.

2. The Bluetooth connection disconnects.

Auto Connectivity The Auto Connectivity function lets you quickly connect the hood via Bluetooth with a compatible Samsung cooktop after the hood and cook- top have been paired. To turn the function on, press the Auto Connectivity button. To turn the function off and disconnect the hood and cooktop, press the Auto Connectivity button again. While the hood and cooktop are connected, the hood fan will automat- ically come on at Low speed when you turn on a cooktop element. The hood fan will also shut off automatically when you turn off the cooktop elements. You will also be able to control the hood with the Samsung Smart Home app as described above.

1. Press the Auto Connectivity button to activate the function.

2. The hood will turn on/off automatically following the cooktop.

3. Press again to deactivate the function.

ImageRemote Control by Samsung Smart Home AppAuto ConnectivityHood Function X X O O X O O O O NOTE These functions are only available if you have installed a compatible Samsung Bluetooth cooktop. Range Hood UseEnglish 11 Range Hood Care Range Hood Care Range Hood Care Cleaning IMPORTANT: Clean the hood and bafe lters frequently according to the following instructions. Replace the bafe lters before operating the hood. Exterior Surfaces: To avoid damage to the exterior surface, do not use steel wool or soap- lled scouring pads to clean the hood. Always wipe dry to avoid water marks. Cleaning Method:

• Liquid detergent soap and water or all-purpose cleanser

• Wipe with a damp soft cloth or nonabrasive sponge, then rinse with clean water and wipe dry.

• Do not use cleaning agents containing bleach. Stainless Steel Bafe Filter:

1. Remove the lter by pulling the spring release handle, and

then pulling down the lter.

A. Spring release handle

2. Wash the stainless steel bafe lter as needed in your dishwasher

or a hot detergent solution.

3. To reinstall the lter, rst make sure the spring release handles are

toward the front. Insert the stainless steel lter into the upper track.

4. Push in the spring release handle.

5. Push up on the stainless steel lter, and then release the handle to

latch the lter into place. WARNING When removing the lter, please hold it with both hands to make sure it does not fall. Replacing an LED Lamp The LED lights are replaceable by a service technician only. See the support contact information in the Warranty section.warranty (USA)

Limited warranty to original purchaser This SAMSUNG brand product, as supplied and distributed by Samsung Electronics America, Inc. (SAMSUNG) and delivered new, in the original carton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in mate- rials and workmanship for a limited warranty period of:

ONE (1) YEAR PARTS AND LABOR

This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in the United States. To receive warranty service, the purchaser must contact SAMSUNG for problem determination and service procedures. Warranty service can only be performed by a SAMSUNG au- thorized service center. The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG’s authorized service center. SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specied above. All replaced parts and prod- ucts become the property of SAMSUNG and must be returned to SAMSUNG. Replacement parts and products assume the remaining original warranty, or ninety (90) days, whichever is longer. In-home service will be provided during the warranty labor period subject to availability within the contiguous United States. In-home service is not available in all areas. To receive in-home service, the product must be unobstructed and accessible to service personnel. If during in-home service repair can not be completed, it may be necessary to remove, repair and return the product. This limited warranty covers manufacturing defects in materials and workmanship encountered in normal, noncommercial use of this product and shall not apply to the following, including, but not limited to: damage which occurs in shipment; delivery and installation; applications and uses for which this product was not intended; altered product or serial numbers; cosmetic damage or exterior nish; accidents, abuse, neglect, re, water, lightning or other acts of nature; use of products, equipment, systems, utilities, services, parts, supplies, accessories, applications, installations, repairs, external wiring or connectors not supplied or authorized by SAMSUNG which damage this product or result in service problems; incorrect electrical line voltage, uctuations and surges; customer adjustments and failure to follow operating instructions, cleaning, maintenance and environmental instruc- tions that are covered and prescribed in the instruction book; problems caused by pest infestations, and overheating by user. THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED AND DESCRIBED ABOVE, AND NO WARRANTIES WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANT- ABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL APPLY AFTER THE EXPRESS WARRANTY PERIODS STATED ABOVE, AND NO OTHER EXPRESS WARRANTY OR GUAR- ANTY GIVEN BY ANY PERSON, FIRM OR CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO PURCHASER AND PURCHASER’S PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING OUT OF THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT SOLD BY SAMSUNG NOT CAUSED DIRECTLY BY THE NEGLIGENCE OF SAMSUNG. THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT IS NON- TRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY. Some provinces or territories may or may not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specic legal rights, and you may also have other rights which vary from state to state. To obtain warranty service, please contact SAMSUNG at: 1-800-SAMSUNG (726-7864) or www.samsung.com/us/supportwarranty (Canada)

Limited warranty to original purchaser This SAMSUNG brand product, as supplied and distributed by Samsung Electronics Canada, Inc. (SAMSUNG) and delivered new, in the original carton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in mate- rials and workmanship for a limited warranty period of:

ONE (1) YEAR PARTS AND LABOR

This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in Canada. To receive warranty service, the purchaser must contact SAMSUNG for problem determination and service procedures. Warranty ser- vice can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG’s authorized service center. SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specied above. All replaced parts and prod- ucts become the property of SAMSUNG and must be returned to SAMSUNG. Replacement parts and products assume the remaining original warranty, or ninety (90) days, whichever is longer. In-home service will be provided during the warranty labor period subject to availability within the contiguous Canada. In-home service is not available in all areas. To receive in-home service, the product must be unobstructed and accessible to service personnel. If during in-home service repair can not be completed, it may be necessary to remove, repair and return the product. This limited warranty covers manufacturing defects in materials and workmanship encountered in normal, noncommercial use of this product and shall not apply to the following, including, but not limited to: damage which occurs in shipment; delivery and installation; applications and uses for which this product was not intended; altered product or serial numbers; cosmetic damage or exterior nish; accidents, abuse, neglect, re, water, lightning or other acts of nature; use of products, equipment, systems, utilities, services, parts, supplies, accessories, applications, installations, repairs, external wiring or connectors not supplied or authorized by SAMSUNG which damage this product or result in service problems; incorrect electrical line voltage, uctuations and surges; customer adjustments and failure to follow oper- ating instructions, cleaning, maintenance and environmental instructions that are covered and prescribed in the instruction book; problems caused by pest infestations, and overheating by user. SAMSUNG does not warrant uninterrupted or error-free operation of the product. THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED AND DESCRIBED ABOVE, AND NO WARRANTIES WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANT- ABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL APPLY AFTER THE EXPRESS WARRANTY PERIODS STATED ABOVE, AND NO OTHER EXPRESS WARRANTY OR GUAR- ANTY GIVEN BY ANY PERSON, FIRM OR CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO PURCHASER AND PURCHASER’S PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING OUT OF THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT SOLD BY SAMSUNG NOT CAUSED DIRECTLY BY THE NEGLIGENCE OF SAMSUNG. THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT IS NON- TRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY. Some provinces or territories may or may not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specic legal rights, and you may also have other rights which vary from state to state. To obtain warranty service, please contact SAMSUNG at: 1-800-SAMSUNG (726-7864) or www.samsung.com/ca/support (English), www.samsung.com/ca_fr/support (French)14 Français Importantes Consignes de Sécurité 15 Exigences d’Installation 17 Spécications Électriques 17 Exigences Concernant l’évacuation 17 Méthodes d’évacuation 17 Outils et Pièces 18 Dimensions et Espaces 18 Installation de la Hotte 19 Préparation de l’emplacement 19 Installation de la bride de cache-conduit 19 Installation de la Hotte 19 Raccordement du circuit d’évacuation 20 Connexion Électrique 20 Installation des Cache-conduits 21 Achever l’installation 21 Utilisation de la Hotte 21 Description de la Hotte 21 Commandes de la Hotte de Cuisinière 22 Connectivity Cooktop / Hood Range 22 Entretien de la Hotte 23 Acier inoxydable Bafe Filtre 23 Nettoyage 23 Remplacement de la Lampe à DEL 23 Garantie (USA) 24 Garantie (Canada) 25 Sommaire SommaireFrançais 15 APPROUVÉ POUR LES APPAREILS DE TYPE RÉSIDENTIEL POUR UNE UTILISATION RÉSIDENTIELLE SEULEMENT LISEZ CES
