USER MANUAL NK36R9600CM SAMSUNG

APPROVED FOR RESIDENTIAL APPLIANCES

FOR RESIDENTIAL USE ONLY

READ AND SAVE THESE INSTRUCTIONS

PLEASE READ ENTIRE INSTALLATION GUIDE BEFORE PROCEEDING. INSTALLATION MUST COMPLY WITH ALL LOCAL CODES. IMPORTANT: Save these Instructions for the Local Electrical Inspector’s use. INSTALLER: Please leave these Instructions with this unit for the owner. OWNER: Please retain these instructions for future reference. Symbols used in this manual WARNING Hazards or unsafe practices that may result in severe personal injury or death. CAUTION Hazards or unsafe practices that may result in electric shock, personal injury, or property damage. NOTE Useful tips and instructions These warning icons and symbols are here to prevent injury to you and others. Please follow them explicitly. After reading this section, keep it in a safe place for future reference. WARNING Turn off power circuit at service panel and lock out panel before wiring this appliance. Requirement 120 VAC, 60 Hz. 15 or 20 A Branch Circuit

WARNING Cancer and Reproductive Harm - www.P65Warnings.ca.gov

CAUTION FCC CAUTION: Any changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of FCC Rules. Operation is Subject to following two conditions:

1) This device may not cause harmful interference, and

2) This device must accept any interference received including

interference that cause undesired operation. For products sold in the US and Canadian markets, only channels 1~11 are available. You cannot select any other channels. Important Safety Instructions Important Safety Instructions FCC STATEMENT: This equipment has been tested and found to comply within the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorienting or relocating the receiving antenna

• Increasing the separation between the equipment and receiver

• Connecting the equipment to an outlet that is on a different circuit than the radio or TV.

• Consulting the dealer or an experienced radio/TV technician for help. FCC RADIATION EXPOSURE STATEMENT: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated so there is at least 8 inches (20 cm) between the radiator and your body. This device and its antenna(s) must not be co-located or operated in conjunction with any other antenna or transmitter.

The term “IC” before the radio certication number only signies that Industry Canada technical specications were met. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. This Class B digital apparatus complies with Canadian ICES-003. For products sold in the US and Canadian markets, only channels 1~11 are available. You cannot select any other channels. IC RADIATION EXPOSURE STATEMENT: This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated so there is at least 8 inches (20 cm) between the radiator and your body. This device and its antenna(s) must not be co-located or operated in conjunction with any other antenna or transmitter.4 English Important Safety Instructions WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING PRECAUTIONS: ■ Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer. ■ Before servicing or cleaning the unit, switch the power off at the service panel and lock the service panel to prevent power from being switched on accidentally. If the service panel cannot be locked, securely fasten a prominent warning device, such as a tag to the service panel. ■ Installation work and electrical wiring must be done by qualied person(s) in accordance with all applicable codes and standards, including re-rated construction. ■ Sufcient air is needed for proper combustion and exhausting of gases through the ue (chimney) of fuel burning equipment to prevent backdrafting. Follow the heating equipment manufacturer’s guideline and safety standards such as those published by the National Fire Protection Association (NFPA), the American Society for Heating, Refrigeration and Air Conditioning Engineers (ASHRAE), and the local code authorities. ■ When cutting or drilling into the wall or ceiling; do not damage electrical wiring and other hidden utilities. ■ Ducted fans must always be vented outdoors. CAUTION For general ventilating use only. Do not use to exhaust hazardous or explosive materials and vapors. CAUTION To reduce the risk of re and to properly exhaust air, be sure to duct air outside - do not vent exhaust air into spaces within walls or ceilings, attics or into crawl spaces, or garages.

WARNING TO REDUCE THE RISK OF FIRE, USE ONLY METAL DUCTWORK. WARNING TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE: ■ Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may ignite. Heat oils slowly on low or medium settings. ■ Always turn the hood ON when cooking at high heat or when ambeing food (i.e. Crepes Suzette, Cherries Jubilee, Peppercorn Beef Flambé). ■ Clean ventilating fans frequently. Grease should not be allowed to accumulate on the fan or lter. ■ Use proper pan sizes. Always use cookware appropriate for the size of the surface element. WARNING TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A RANGE TOP GREASE FIRE, OBSERVE THE FOLLOWING PRECAUTIONS:

■ SMOTHER FLAMES with a close tting lid, cookie sheet, or metal tray, then turn off the burner. BE CAREFUL TO PREVENT BURNS. If the ames do not go out immediately, EVACUATE AND CALL THE FIRE DEPARTMENT. ■ NEVER PICK UP A FLAMING PAN - you may get burned. ■ DO NOT USE WATER, including wet dishcloths or towels - a violent steam explosion can result. ■ Use an extinguisher ONLY if: - You know you have a class ABC extinguisher, and you already know how to operate it. – The re is small and contained in the area where it started. – The re department is being called. – You can ght the re with your back to an exit.

Based on “Kitchen Fire Safety Tips” published by NFPA.

WARNING To reduce the risk of re or electrical shock, do not use this fan with any solid-state speed control device.

WARNING Do not let children near this appliance. Do not let children play with this appliance. Keep all packaging materials out of children’s reach. Properly dispose the packaging materials after this appliance is unpacked. Important Safety Instructions Read and save these instructionsEnglish 5 Electrical Requirements IMPORTANT Observe all governing codes and ordinances. It is the customer’s responsibility: To contact a qualied electrical installer. If codes permit and a separate ground wire is used, it is recommended that a qualied electrician determine that the ground path is adequate. A copy of the above code standards can be obtained from: National Fire Protection Association 1 Batterymarch Park Quincy, MA 02169-7471 CSA International 8501 East Pleasant Valley Road Cleveland, OH 44131-5575 ■ A 120 volt, 60 Hz., AC only, 15-amp, fused electrical circuit is required. ■ If the house has aluminum wiring, follow the procedure below:

1. Connect a section of solid copper wire to the pigtail leads.

2. Connect the aluminum wiring to the added section of

copper wire using special connectors and/or tools designed and UL listed for joining copper to aluminum. ■ Follow the electrical connector manufacturer’s recommended procedure. Aluminum/copper connection must conform with local codes and industry accepted wiring practices. ■ Wire sizes and connections must conform with the rating of the appliance as specied on the model/serial rating plate. The model serial plate is located behind the lter on the rear wall of the range hood. ■ Wire sizes must conform to the requirements of the National Electrical Code, ANSI/NFPA 70 (latest edition), or CSA Standards C22. 1-94, Canadian Electrical Code, Part 1 and C22.2 No. 0-M91 (latest edition) and all local codes and ordinances. Venting Requirements (ducted models only)

• Vent system must terminate outdoors.

• Do not terminate the vent system in an attic or other enclosed area.

• Do not use a 4” (10.2 cm) laundry-type wall cap.

• Use metal vent only. Rigid metal vent is recommended. Plastic or metal foil vent is not recommended.

• The length of the vent system and the number of elbows should be kept to a minimum to provide efcient performance. For the most efcient and quiet operation:

• Use no more than three 90° elbows.

• Make sure there is a minimum of 30” (76.2 cm) of straight vent between the elbows if more than 1 elbow is used.

• Do not install 2 elbows together.

• Use clamps to seal all joints in the vent system.

• The vent system must have a damper. If the roof or wall cap has a damper, do not use the damper supplied with the range hood.

• Use caulking to seal the exterior wall or roof opening around the cap.

• The size of the vent should be uniform. Venting Methods To use the hood’s top outlet to vent your hood, a 10” (25.4 cm) round vent system is required.This vent systems are not included and must be purchased separately. NOTE Flexible vent is not recommended. Flexible vent creates back pressure and air turbulence that greatly reduce performance. The vent system can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed. Mounting Height Mount the hood no less than 30” (76.2 cm) above an electric cooking surface, no less than 32” (81.2 cm) above a gas cooking surface, and no higher than 36” (91.4 cm) above either surface. Horizontal discharge A 90° elbow may be installed immediately above the hood. Horizontal Discharge Vertical Discharge

A. 10” (25.4 cm) round ventB. 10” (25.4 cm) round transition C. 90º elbowA. 10” (25.4 cm) round transitionB. 10” (25.4 cm) duct C. Cabinet Installation Requirements Installation Requirements6 English Tools and Parts Removing the packaging CAUTION Remove the carton carefully. Wear gloves to protect against sharp edges. WARNING Remove the protective lm covering the product before putting into operation. Parts supplied

• Hood assembly with blower and LED lamps already installed.

Tools/Materials required

• Drill with 1¼” (3.0 cm),

• Wire stripper or utility knife

• Tape measure or ruler

• Caulking gun and weatherproof caulking compound

• Saber or keyshole saw

• Flat-blade screwdriver

• Home power supply cable

• ½” (12.7 mm) UL listed or CSA approved strain relief

• 3 UL listed wire connectors

• Metal vent system Dimensions and Clearances

⁄8″ (1 cm) Optional accessories and consumables MODEL NK36R9600CS NK36R9600CM Duct Cover Kit NK-AE907LCS/AA NK-AE907LCM/AA Installation Requirements Installation RequirementsEnglish 7 Installation Installation Instructions We recommend that a qualied technician install the range hood. It is the installer’s responsibility to ensure the range hood complies with the instal- lation clearances specied for the product.

• It is recommended that the vent system be installed before the hood is installed.

• If possible, disconnect and move freestanding or slide-in ranges from cabinet openings to provide easier access to the rear wall.

• Before making cutouts, make sure there is proper clearance within the ceiling or wall for the exhaust vent.

• Conrm that all installation parts have been removed from the shipping carton.

1. Turn off the power at the circuit breaker panel or fuse box.

2. Determine which venting method to use: roof or wall exhaust.

NOTE: This hood is factory set to vent through the top air exit.

3. Select a at surface for assembling the range hood.

Place a covering over that surface. Venting Methods Outside Top exhaust Vertical Duct Ø 10″ (25.4 cm) Use the diagram or the hood as a template and mark the locations for the door ductwork, electrical wiring and keyhole screw slots.

⁄2″ (19 cm) Rear Installation Diagram Use the diagram or the hood as a template and mark the locations on the wall for electrical wiring and keyhole screws slots. Ø 1”

⁄16″ (32 cm) Installation8 English Wall Installation WARNING USE TWO OR MORE PEOPLE TO MOVE AND INSTALL THE RANGE HOOD. FAILURE TO DO SO CAN RESULT IN BACK OR OTHER INJURY. The hood is attached to the wall with a wood support that is attached to the inside back of the hood. To support the hood safely, the wood support must be xed rmly to at least 2 vertical wooden studs that are located behind the sheetrock that makes up the wall. NOTE: These instructions are not applicable to masonary (brick, concrete, etc.) walls. If you have a masonary wall, consult a professional installer. IMPORTANT: The studs (or wall if you have a masonary wall) must be capable of supporting up to 150 lbs. NOTE: If your kitchen has wood framing, at least 2 screws provided for mounting this range hood must be fastened into solid wood studs. Do not fasten into sheetrock only. NOTE: Mark the Range Hood knockouts on the wall and make the necessary cutouts before installing the hood. Installation Instructions if you have wood framing:

1. Determine and mark the centerline on the wall where the hood will

2. Select a mounting height “X” (See D below).

• For gas cooktop & range installations: Mount the hood so the bottom is at least 32” (81.2 cm) above the cooking surface.

• For electric/induction cooktop & range installations: Mount the hood so the bottom is at least 30” (76.2 cm) above the cooking surface.

3. Mark a horizontal reference line on the wall (B below) for the bottom

of the hood. Use a level to conrm that the line is level.

4. Find and mark the location of the wood studs or wood supports

5. Draw a line 15 3⁄8” (39.1cm) above the reference line for the bottom

of the hood to mark the wood support location on the wall. Use a level to conrm that the line is level.

⁄8” (39 cm) Ø 1”2.5 cmA. Wood supportB.Bottom of range hoodC. Center Line D. Dimension “x” = range hood mounting heightE. Knockout wiring holes

6. Remove the wood support from the back of the hood by loosening

the 2 screws from the inside.

7. Line the top of the wood support up with the wood support location

line on the wall, and then center it on the center line.

8. Locate the marks for the studs, and then draw two vertical lines

on the wood support marking where the studs intersect with the wood support.

9. Mark the center of each line, remove the wood support from the

wall, and then drill a pilot hole at each mark.

10. Again, line the top of the wood support up with the wood support

location line, and then center it on the center line.

11. Push a pencil point or awl through the holes you just drilled in the

wood support (A) to mark the location of the pilot holes for two screws that will go into the studs.

12. Also mark the locations of two additional pilot holes (B) by pushing a

pencil point or awl through pre-drilled holes in the center of the wood support. These holes are for the supplied wall anchors. See the diagram below.

13. Remove the wood support, and then drill four pilot holes into the wall.

14. Push two of the supplied wall anchors into the two pilot holes at the

15. Fasten the wood support to the wall by screwing 2 xing screws

6 x 80 mm (.25 x 3.15 in) through the wood support into the pilot holes you drilled in the studs.

16. Using the rear installation diagram as a guide (See page 7), cut the

knockout wiring holes in the wall.

17. Screw two 6 x 80 mm (.25 x 3.15 in) screws screws into the holes (B)

in the center of the wood support. Screw them through the support into the anchors underneath. Leave a 1⁄4”(6.4mm) gap between the wall and the back of the screw head to slide range the hood into place.

⁄16” (38.5 cm) NOTE: Once the hood is mounted you must tighten these screws. Complete Preparation

1. Determine and make all necessary cuts in the wall or roof for the vent

system. Install the vent system before installing the range hood. See the “Venting Methods” section.

2. Determine the location where the power supply cable will be run

through the wall. Installation InstallationEnglish 9

⁄4” (3.2 cm) hole at this location.

4. Pull enough power supply cable through the wall to allow for easy

connection to the terminal box.

5. Remove the terminal box cover and set aside.

6. Install the 10” (25.4 cm) square x 10” (25.4 cm) round vent transition

with damper to the top of the range hood (depending on your installation), using 4- 3.5 x 9.5 (.15 x.37 in) mm screws.

7. Remove the knockout from the back of the range hood and install a

UL listed or CSA approved

⁄2” (1.3 cm) strain relief.

A. 4 - 3.5x9.5 mm screwsB. Knockout NOTE: The exhaust adaptor/damper can be installed up to 1 inch on either side of the hood center to accomodate off-center ductwork. In extreme off-center installations, one end of the duct connector may need to be trimmed to clear the electrical cable clamp.

8. Place the range hood near its mounting position and run the power

supply cable through the strain relief into the terminal box (enough to make connection).

9. Tighten the strain relief screws.

10. Make the electrical connection. See the “Electrical connection”

section. Mounting the hood NOTE: Mark the Range Hood knockouts on the wall, and then make the necessary cutouts before the installation. NOTE: The range hood attaches to the wall by the 6 mounting screws in the wood support mounted to the wall. To mount the hood, follow these steps:

1. Using 2 or more people, hang the range hood on the wall by placing

the 2 screws mounted in the wood support attached to the wall through the wide portion of the slotted holes in the back of the range hood. NOTE: If your installation uses the optional duct cover, the vent system needs to be connected to the range hood and the duct cover mounted to the top of the range hood before you tighten the mounting screws.

2. Pull the range hood down so the screws protrude through the narrow

portions of the slots, align the bottom of the hood with the horizontal line marking the hood bottom, level the hood, and then tighten the 2 mounting screws.

3. Mark 2 lower mounting hole locations. Drill

⁄8” (0.32 cm) pilot holes if the holes will be drilled into wood studs or framing. If the holes will not be drilled into wood, drill two

⁄8” (0.95 cm) pilot holes and insert 10 x 50 mm (.4 x 2 in) wall anchors. Install 2 - 6 x 80 mm (.25 x 3.15 in) screws with 5.3 x 20 mm (.21 x .8 in) washers (D and C) into the lower mounting holes, and then tighten.

A. Mounting screws B. 4 screws - 4.2 x19 mmC. 2 D5.3 x 20 mm washersD. 2 screws - 6 x 80 mm

4. Install the 4 - 4.2 x 19 mm (.17 x .75 in) screws (B) through the back

of the hood into the wood support, and then tighten.

5. Connect the vent system to the hood. Seal all joint with clamps.

A. Wiring connection

2. Slide the left mounting plate ange under the motor mounting

A. Motor mounting bracketB. Mounting plate left ange Installation Installation10 English

3. Push the right end of the motor mounting plate up, and then snap it

into the spring tab. NOTE: The spring tab should be outside the slot in the mounting plate.

A. Motor mounting plate B. Spring clip

4. Align the mounting holes and then install 6 x 16 mm screws and 6.4 x

A. Screw with lock washer B. Mounting hole

5. Make the connection between the blower and the junction box with

1. Remove the knockout and the Junction box cover, and then install

the conduit connector (cULus listed) in the junction box. A. Junction box cover B. Knockout C. Power supply wire connector

2. Run 3 wires - black, white, and green - according to the National

Electrical Code and local codes and ordinances, in

⁄2″ conduit from the service panel to the junction box.

A. White wires B. Black wires C.UL listed wire connector D. Green (or bare) and yellow-green ground wire E. Homepower supply cable F. UL listed or CSA approved

• Connect the black wire from the service panel to the black or the red in the junction box. Connect the white to white and green to green-yellow.

• Close and secure the junction box cover. Completing the installation Replace the lters and check the operation of the hood. If the range hood does not operate:

• Conrm that the circuit breaker is not tripped or the house fuse blown.

• Disconnect the power supply, and then check if the wiring is correct.

• To get the most efcient use from your new range hood, read the “Range Hood Use” section.

• Keep these Installation Instructions and Use and Care Guide close to range hood for easy reference. Installation InstallationEnglish 11 Range Hood Use Range Hood Description

• Press the POWER button and the hood will turn on at the default speed (Default Speed: Low).

• Press again and the hood fan will return to sleep mode. B. LOW

• Press the LOW button and the hood will be turn on at Low speed. C. MED

• Press the MED button and the hood will be turn on at Medium speed. D. HIGH

• Press the HIGH button and the hood will be turn on at High speed. E. BOOST

• Press the BOOST button and the hood will be activated at Maximum speed for 10 minutes. After 10 minutes, the hood fan will slow to High speed. F. AUTO

• Press the Auto button to activate the Auto Heat-Sensing feature. When Auto is activated, the fan speed will increase as the cooktop heat increases and decrease as the cooktop heat decreases.

• To turn off Auto Heat-Sensing, press one of the hood speed buttons (Low, Medium, High or Boost). This will disable the Auto Heat-Sensing feature. To re-enable Auto Heat-Sensing feature, press the Auto button. If there is minimal heat produced from the cooktop (even when the cooktop is off or not connected via Bluetooth), the hood will operate at low speed until heat is no longer sensed by the hood. The Auto Heat-Sensing feature does not require the hood to be con- nected via Bluetooth with a compatible Samsung cooktop. G. Timer Display Shows the timer settings. H. Timer Setting the timer ON

• Press the Timer button to set the working time.

• Each time you press the Timer, you add 10 minutes to the displayed time, up to a maximum of 99 minutes. The hood fan will stay on for the amount of time you have set. After the Timer counts down to zero, the Timer LED light will start to blink. The Timer LED will blink for 5 seconds, and then the hood fan will turn off automatically.

• Press the Light button. The lights comes on at the high setting.

• Press the Light button a second time. The lights become dimmer.

• Press the Light button a third time, The lights turn off. Sound Muting / Unmuting the hood.

• Press and hold the Light button for 3 seconds to turn off the hood sounds.

• Press and hold again to turn on the sounds. Range Hood Use12 English Range Hood Use

COOKTOP AND RANGE HOOD CONNECTIVITY

This appliance has a feature which allows you to pair compatible Samsung cooktops and your hood via Bluetooth. After you enable this function and pair your hood and a compatible cooktop, the hood fan will automatically come on at Low speed when you turn on a cooktop element. The hood fan will also shut off automatically when you turn off the cooktop elements. In addition, after the hood and compatible cooktop are paired, you can download the Smart Things app to a mobile device, and then use the Smart Things app to:

• Monitor and control the On/Off status of the hood.

• Monitor and control the fan speed.

• Monitor and control the lights.

• Set the hood shut-off timer with the time-up alarm. For more information about downloading the Smart Thing app to your mobile device and using it to control your hood, visit: www.samsung.com. Bluetooth connection (Pairing)

1. Press the Auto Connectivity button on the hood for 3 seconds. The

pairing mode will be activated and the Bluetooth icon will blink.

2. Press the Auto Connectivity button on the cooktop.

NOTE For a detailed description of the pairing method, see the user manual of a compatible Samsung cooktop.

3. After the pairing process nishes, the Bluetooth light will stay lit and

appears in the display. Bluetooth disconnection (pairing reset)

1. Press and hold the Auto Connectivity button and Light button on the

2. The Bluetooth connection disconnects.

J. Auto Connectivity The Auto Connectivity function lets you quickly connect the hood via Bluetooth with a compatible Samsung cooktop after the hood and cooktop have been paired. To turn the function on, press the Auto Connectivity button. To turn the function off and disconnect the hood and cooktop, press the Auto Connectivity button again. While the hood and cooktop are connected, the hood fan will automatically turn on when you turn on the cooktop. The hood fan will also turn off automatically when you turn off the cooktop You will also be able to control the hood with the Smart Things app as described above. Note that the hood fan speed will turn on at:

• Auto speed (if the Auto button was last enabled)

• Low speed (if the Auto button was last disabled)

1. Press the Auto Connectivity button to activate the function.

2. The hood will turn on/off automatically when you turn cooktop

3. Press again to deactivate the function.

Image Remote Control by Smart Things App Auto Connectivity Hood Function O X O O O O NOTE These functions are only available if you have installed a compatible Samsung Bluetooth cooktop. Reset the lter alarm

• Press the POWER button for 3 seconds to reset the lter alarm. NOTE Every 50 hours of fan use, the lter alarm light (low button) will blink, indicating the lters may need to be cleaned. CAUTION

• Do not activate the Boost function unless your hood’s ventilation system has been designed to handle the increased airow created by the Boost function and has been installed by a qualied technician. We recommend that a qualied technician install the range hood. It is the installer’s responsibility to ensure the range hood complies with the installation specications for the product. To activate Power mode, a professionally installed Make-up air system is required. Makeup Air

• When using ventilation systems with greater than specied CFM of air movement, review local building codes as they may require makeup air systems. Consult a HVAC professional for specic requirements for your area as CFM requirements can vary between locales.

• Consult an HVAC professional to select the correct CFM capacity range hood for your application. The CFM capacity depends on the range or cooktop BTU rating, size and location, size of the kitchen and the range hood ductwork in the kitchen. Range Hood UseEnglish 13 Range Hood Care Cleaning Exterior surfaces: To avoid damage to the exterior surface, do not use steel wool or soap- lled scouring pads. Do not use chlorine based cleaners. Rub in the direction of the grain line to avoid scratching the surface.

• For a thorough cleaning, us Stainless Steel Cleaner and Polish.

• For everyday cleaning, use a mild liquid detergent and water. Dry thoroughly.

• For a quick cleaning, wipe with a damp soft cloth or nonabrasive sponge, then rinse with clean water and wipe dry. NOTE: Always wipe dry to avoid water marks. Metal lters and drip tray:

1. Use 2 hands to remove the lters. Grasp the lter handles, pull to-

ward the front of the range hood, and then pull down on rear handle to remove. Repeat for each lter.

2. Remove the grease drip tray.

3. Remove the drip tray from the drip tray bracket.

A. Drip tray B. Drip tray bracket C. Drip tray bracket screws

4. Wash metal lters and grease trays as needed in a dishwasher or hot

detergent solution to clean.

5. Replace the grease drip tray.

6. To reinstall the lters, grasp the lter handles with both hands and

then place the front edge of the lter into the hood.

7. Push up on the back the handle, and then set rear of lter into the

drip tray to secure. Repeat for each lter

A. Bafe lter Replacing the LED Lamp LED lights are replaceable by a service technician only. See the contact information in the Warranty section.warranty (USA)

Limited warranty to original purchaser This SAMSUNG brand product, as supplied and distributed by Samsung Electronics America, Inc. (SAMSUNG) and delivered new, in the original carton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in mate- rials and workmanship for a limited warranty period of:

ONE (1) YEAR PARTS AND LABOR

This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in the United States. To receive warranty service, the purchaser must contact SAMSUNG for problem determination and service procedures. Warranty service can only be performed by a SAMSUNG au- thorized service center. The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG’s authorized service center. SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specied above. All replaced parts and prod- ucts become the property of SAMSUNG and must be returned to SAMSUNG. Replacement parts and products assume the remaining original warranty, or ninety (90) days, whichever is longer. In-home service will be provided during the warranty labor period subject to availability within the contiguous United States. In-home service is not available in all areas. To receive in-home service, the product must be unobstructed and accessible to service personnel. If during in-home service repair can not be completed, it may be necessary to remove, repair and return the product. This limited warranty covers manufacturing defects in materials and workmanship encountered in normal, noncommercial use of this product and shall not apply to the following, including, but not limited to: damage which occurs in shipment; delivery and installation; applications and uses for which this product was not intended; altered product or serial numbers; cosmetic damage or exterior nish; accidents, abuse, neglect, re, water, lightning or other acts of nature; use of products, equipment, systems, utilities, services, parts, supplies, accessories, applications, installations, repairs, external wiring or connectors not supplied or authorized by SAMSUNG which damage this product or result in service problems; incorrect electrical line voltage, uctuations and surges; customer adjustments and failure to follow operating instructions, cleaning, maintenance and environmental instruc- tions that are covered and prescribed in the instruction book; problems caused by pest infestations, and overheating by user. THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED AND DESCRIBED ABOVE, AND NO WARRANTIES WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANT- ABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL APPLY AFTER THE EXPRESS WARRANTY PERIODS STATED ABOVE, AND NO OTHER EXPRESS WARRANTY OR GUAR- ANTY GIVEN BY ANY PERSON, FIRM OR CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO PURCHASER AND PURCHASER’S PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING OUT OF THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT SOLD BY SAMSUNG NOT CAUSED DIRECTLY BY THE NEGLIGENCE OF SAMSUNG. THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT IS NON- TRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY. Some provinces or territories may or may not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specic legal rights, and you may also have other rights which vary from state to state. To obtain warranty service, please contact SAMSUNG at: 1-800-SAMSUNG (726-7864) or www.samsung.com/us/supportwarranty (Canada)

Limited warranty to original purchaser This SAMSUNG brand product, as supplied and distributed by Samsung Electronics Canada, Inc. (SAMSUNG) and delivered new, in the original carton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in mate- rials and workmanship for a limited warranty period of:

ONE (1) YEAR PARTS AND LABOR

This limited warranty begins on the original date of purchase, and is valid only on products purchased and used in Canada. To receive warranty service, the purchaser must contact SAMSUNG for problem determination and service procedures. Warranty ser- vice can only be performed by a SAMSUNG authorized service center. The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG or SAMSUNG’s authorized service center. SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or reconditioned parts or products if found to be defective during the limited warranty period specied above. All replaced parts and prod- ucts become the property of SAMSUNG and must be returned to SAMSUNG. Replacement parts and products assume the remaining original warranty, or ninety (90) days, whichever is longer. In-home service will be provided during the warranty labor period subject to availability within the contiguous Canada. In-home service is not available in all areas. To receive in-home service, the product must be unobstructed and accessible to service personnel. If during in-home service repair can not be completed, it may be necessary to remove, repair and return the product. This limited warranty covers manufacturing defects in materials and workmanship encountered in normal, noncommercial use of this product and shall not apply to the following, including, but not limited to: damage which occurs in shipment; delivery and installation; applications and uses for which this product was not intended; altered product or serial numbers; cosmetic damage or exterior nish; accidents, abuse, neglect, re, water, lightning or other acts of nature; use of products, equipment, systems, utilities, services, parts, supplies, accessories, applications, installations, repairs, external wiring or connectors not supplied or authorized by SAMSUNG which damage this product or result in service problems; incorrect electrical line voltage, uctuations and surges; customer adjustments and failure to follow operating instructions, cleaning, maintenance and environmental instruc- tions that are covered and prescribed in the instruction book; problems caused by pest infestations, and overheating by user. SAMSUNG does not warrant uninterrupted or error-free opera- tion of the product. THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED AND DESCRIBED ABOVE, AND NO WARRANTIES WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES OF MERCHANT- ABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL APPLY AFTER THE EXPRESS WARRANTY PERIODS STATED ABOVE, AND NO OTHER EXPRESS WARRANTY OR GUAR- ANTY GIVEN BY ANY PERSON, FIRM OR CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG. SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE FOREGOING, PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO PURCHASER AND PURCHASER’S PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING OUT OF THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT SOLD BY SAMSUNG NOT CAUSED DIRECTLY BY THE NEGLIGENCE OF SAMSUNG. THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT IS NON- TRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY. Some provinces or territories may or may not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty gives you specic legal rights, and you may also have other rights which vary from state to state. To obtain warranty service, please contact SAMSUNG at: 1-800-SAMSUNG (726-7864) or www.samsung.com/ca/support (English), www.samsung.com/ca_fr/support (French)16 Français Sommaire Sommaire Importantes Consignes de Sécurité 17 Exigences d’Installation 19 Spécications Électriques 19 Exigences Concernant l’évacuation 19 Méthodes d’évacuation 19 Outils et Pièces 20 Dimensions et Espaces 20 Installation de la Hotte 21 Instructions d´installation 21 Installation sur le mur 22 Montage de la hotte 23 Installation du moteur interne de la hotte 23 Utilisation de la hotte 24 Conexion Électrique 24 Achever l`ínstallation 24 Description de la hotte 25 Commandes de la hotte 25 Entretien de la hotte 27 Nettoyage 27 Filtres meétalliques et plateaux d´egouttement 27 Remplacement de la Lampe à DEL 27 Garantie (USA) 28 Garantie (Canada) 29Français 17 APPROUVÉ POUR LES APPAREILS DE TYPE RÉSIDENTIEL POUR UNE UTILISATION RÉSIDENTIELLE SEULEMENT LISEZ CES
