MicroTech III ® Controller

Application Software name: ACZC-ACZH-ADZ-ATLAS-AWS-EWWD-MNG-PFS

III Chiller Unit Controller into a Building Automation System (BAS). Modbus terms and principles are not defined. Refer to the appropriate specifications for definitions and details. Revision History 1) D-EOMOC00011-14EN November 2014 Created 2) D-EOMOC002(17)12-14EN 17 December 2014 Improved Upgraded ADZ units ATLAS Holding Registers 40025, 40026 3) D-EOMOC002(19)12-14EN 19 December 2014 Improved Improved Upgraded Upgraded ATLAS Holding Registers 40900, 40901, 40902 Appendix B Holding Registers 40011, 40034 Revision History Reference Documents Ref.#1 www.Modbus.orgD-EOMOC002(19)12-14EN - 5/35 Basic Information Compatibility The MicroTech III Chiller Unit Controller conforms to the published Modbus standards. Controllers can communicate on standard Modbus networks using ASCII or RTU transmission mode. The MicroTech III Chiller Unit Controller uses the RTU mode only. Refer to Ref.#1 for more detailed information. Configuring the Microtech III for Modbus Network The MicroTech III Chiller Unit Controller can be configured in an interoperable Modbus network. The controller must have the corresponding Modbus Communication Module installed. The MicroTech III Chiller Unit Controller and the Modbus Communication Module are shipped with default parameter values. Default values may be changed with the unit keypad. Parameters must be adjusted to accommodate your particular network. See the appropriate Operation Manual for default values and keypad operating instructions. See the MicroTech III Modbus Communication Module Installation Manual for details regarding network parameters available via the unit controller keypad/display. Once communication module is set up and communication with network is established, in order to control the MicroTech III over the network, the Unit control source must be turned in “Network” (default is Local). From keypad/display set the Main Menu_View/Set Unit_Status/Settings_Control Source to “Network”. Modbus Registers Addressing The Modbus Communication Module supports zero-based addressing. For example, holding register 40002 is addressed as 0001 in a Modbus message. The following tables assume 4xxxx addressing.D-EOMOC002(19)12-14EN - 6/35 Minimum Integration This section describes the information that assure compliance of Microtech III to the integration criteria for a Modbus network integration. The data/alarm points that represent the minimum integration data points are listed in Table 1 below and in boldface in Table 2 to Table 5. Table 1. MicroTech III Chiller Unit Controller Registers for minimum integration Data/Alarm points Actual Capacity Chiller Enable Setpoint Chiller Mode Setpoint - Network Chiller Status Clear Alarms - Network Evaporator Entering Fluid Temperature Evaporator Leaving Fluid Temperature Capacity Limit Setpoint – Network Cool Setpoint – Network Problem Alarm Code Fault Alarm Code Warning Alarm CodeD-EOMOC002(19)12-14EN - 7/35 Data Points Data Points for Chiller Models Table 2 contains the list of Modbus data points available from the MicroTech III Chiller Unit Controller depending on the chiller model and corresponding unit controller application software. Application software name is available in the unit HMI: see in Main Menu, “About Chiller”. The data points in boldface represent the minimum integration data points listed in Table 1. Table 2. MicroTech III Unit Controller Data Points List for Chiller Model Data Point ACZC ACZH ADZ ATLAS AWS EWWD MNG PFS Active Capacity Limit Output X X X X X X X X Active Energy

Active Setpoint X X X X X X X X Actual Capacity X X X X X X X X Alarm Digital Output X X X X X X X X Application Software Version X X X X X X X X Capacity Limit Setpoint - Network X X X X X X X X Chiller Capacity Limited X X X X X X X X Chiller Current X X X X X X X X Chiller Enable Output X X X X X X X X Chiller Enable Setpoint X X X X X X X X Chiller Local/Remote X X X X X X X X Chiller Location X X X X X X X X Chiller Mode Output X X X X X X X X Chiller Mode Setpoint – Network X X X X X X X X Chiller Model X X X X X X X X Chiller On/Off X X X X X X X X Chiller Status (Chiller Run Mode) X X X X X X X X Chiller Tons X X X X X X X X Chiller Voltage X X Clear Alarms – Network X X X X X X X X Compressor Actual Capacity X X X X X X X X Compressor Current X X

Compressor Discharge Refrigerant Temperature X X X X X X X X Compressor Full Load X X X X X X X X Compressor Off Auto X X X X X X X

Compressor Oil Feed Pressure X X X X X X X X Compressor Oil Level Status X X X X X X X

Available only for AWS with InverterD-EOMOC002(19)12-14EN - 8/35 Data Point ACZC ACZH ADZ ATLAS AWS EWWD MNG PFS Compressor Percent RLA X X

Compressor Power X X

Compressor Run Hours X X X X X X X X Compressor Starts X X X X X X X X Compressor Status X X X X X X X

Compressor Suction Refrigerant Temperature X X X X X X X X Compressor VFD Output

Compressor Voltage X X

Condenser Approach Temperature X X X X X X X X Condenser Ent Water Temperature

Condenser Leaving Water Temperature

Condenser Refrigerant Pressure X X X X X X X X Condenser Saturated Refrigerant Temperature X X X X X X X X Cool Setpoint – Network X X X X X X X X Date X X X X X X X X Day of Week X X X X X X X X Evaporator Approach Temperature X X X X X X X X Evaporator Entering Water Temperature X X X X X X X X Evaporator Flow Switch Status X X X X X X X X Evaporator Leaving Water Temperature X X X X X X X X Evaporator Pump #2 Status X X X X X X X X Evaporator Refrigerant Pressure X X X X X X X X Evaporator Saturated Refrigerant Temperature X X X X X X X X Evaporator SuperHeat Setpoint X X X X X X X

Evaporator SuperHeat Temperature X X X X X X X X EXV Position X X X X X X X X Fault Alarm Code X X X X X X X X Fault Alarm Index X X X X X X X X Heat Recovery Enable - Network

Heat Recovery Ent Water Temperature

Heat Recovery Leaving Water Temperature

Heat Setpoint – Network

Hour X X X X X X X X Ice Setpoint - Network X X X X X X X X Liquid Temperature

Minute X X X X X X X X Month X X X X X X X X Noise Reduction Auto On X X X X X

Data Point ACZC ACZH ADZ ATLAS AWS EWWD MNG PFS Noise Reduction Status X X X X X

Number of Circuits X X X X X X X X Number of Compressors X X X X X X X X Outdoor Air Temperature X X X X X

Outdoor Fan Speed X X X X X X X

Outdoor Fan Status X X X X X X X

Problem Alarm Code X X X X X X X X Problem Alarm Index X X X X X X X X Refrigerant Type X X X X X X X X Run Enabled X X X X X X X X Second X X X X X X X X Units X X X X X X X X Warning Alarm Code X X X X X X X X Warning Alarm Index X X X X X X X X Year X X X X X X X X Comprehensive Data Points List Table 3 contains the complete list of Modbus data points available from the MicroTech III Chiller Unit Controller. The data points in boldface represent the minimum integration data points as identified in Table 1. Table 5 lists the available chiller alarm objects. Table 3. MicroTech III Unit Controller Modbus Comprehensive Data Point List Data Point Holding Register (4xxxx) R/W Range/Description Active Capacity Limit Output 14 R 0 - 100% Active Energy 1900 R Enabled whit Power meter optional Active Setpoint 12 R ACZC: 14.9° to 60.0 °F (-9.5 to 15.6°C) ACZH: 14.9° to 131.0 °F (-9.5 to 55.0°C) ADZ: 14.9° to 60.0 °F (-9.5 to 15.6°C) ATLAS: 17.6° to 122.0°F (-8.0 to 50.0°C) AWS: 17.6° to 122.0°F (-8.0 to 50.0°C) EWWD: 15.0° to 140.0°F (-9.4° to 60.0°C) MNG: 15.0° to 60.0 °F (-9.4° to 15.6°C) PFS: 15.0° to 149.0°F (-9.4° to 65.0°C) Actual Capacity 13 R 0 - 100% Alarm Digital Output 5 R 0=No Alarm, 1=AlarmD-EOMOC002(19)12-14EN - 10/35 Data Point Holding Register (4xxxx) R/W Range/Description Application Software Version

Circuit #1 Comp #1 - Off Auto 1841 R

These registers will be a numerical value and need to be translated to a string using ASCII Character on next page. This will translate into a 10-character string.

These registers will be a numerical value and need to be translated to a string using ASCII Character on next page. This will translate into a 20-character string. Unsupported characters are translated to a space.D-EOMOC002(19)12-14EN - 11/35 Data Point Holding Register (4xxxx) R/W Range/Description Circuit #1 Comp #1 - Oil Level Status 1851 R

Circuit #1 Comp #1 - Suction Refrigerant Temp 65 R -40°-110° C (-40-230° F) Circuit #1 Comp #1 - VFD Output 1845 R

Circuit #1 Comp #1 – Voltage 71 R 0 to 15.000 V Circuit #1 Comp #2 - Actual Capacity 1826 R

Circuit #1 Outdoor Fan Status 1997 R

Circuit #2 Comp #1 - Oil Feed Pressure 1809 R -5.801473 to 17.54946 psi(-40 to 121 kPA) Circuit #2 Comp #1 - Oil Level Status 1811 R

Circuit #2 Comp #1 - VFD Output 1805 R

Circuit #2 Outdoor Fan Speed 1970 R

Circuit #2 Outdoor Fan Status 1981 R

Circuit #3 Comp #1 - Oil Feed Pressure 1770 R -5.801473 to 17.54946 psi(-40 to 121 kPA) Circuit #3 Comp #1 - Oil Level Status 1772 R

X X X X X Bad demand limit input Warning X X X X X X X X Bad setpoint override input Warning X X X X X X X X Circuit Failed pumpdown Warning X X X X X X X

Circuit Fan Warning X Circuit INHIBIT LOAD - High Current Problem X X X X X X X

Circuit INHIBIT LOAD - High Pressure Problem X X X X X X X X Circuit INHIBIT LOAD - Low Pressure Problem

X X X X X Circuit SHUTDOWN – Evap Pressure Sensor Fault X X X X X X X

Circuit SHUTDOWN – Low Evap Pressure Fault X X X X X X X

Circuit SHUTDOWN – No Pressure at Startup Fault X X X X X X X

Circuit SHUTDOWN – No Pressure Change After Start X X X X X X X X Circuit SHUTDOWN – Phase Voltage Protection Fault X X X X X X X

Comp LOCKOUT - Allowed Re-Starts Exceeded Fault X X X X X X X

Comp SHUTDOWN - COM ERROR With VFD Fault X X X X X X X

Comp SHUTDOWN - Discharge Temp High Fault X X X X X X X X Comp SHUTDOWN - Discharge Temp Sensor Fault X X X X X X X X Comp SHUTDOWN - Low pressure ratio Fault X X X X X X X X Comp SHUTDOWN - Mechanical High Pressure Fault X X X X X X X X Comp SHUTDOWN - Mechanical Low Pressure Fault X X X X X X X X Comp SHUTDOWN – Motor Protector Fault X X X

Comp SHUTDOWN - Motor Temp High Fault X X X X X X X X Comp SHUTDOWN - Motor Temp Sensor Fault X X X X X X X X Comp SHUTDOWN - Oil Delta Pressure High Fault X X X X X X X X Comp SHUTDOWN - Oil Feed Pressure Sensor Fault X X X X X X X X Comp SHUTDOWN - Slide position Sensor Fault

X X X X X Comp SHUTDOWN - Starter Fault X X X X X X X X Comp SHUTDOWN - Suction Temp Sensor Fault X X X X X X X X Comp SHUTDOWN - VFD Fault X X X X X X X

Comp SHUTDOWN - VFD Over Heat Fault X X X X X X XD-EOMOC002(19)12-14EN - 19/35 Alarm Point ACZC ACZH ADZ ATLAS AWS EWWD MNG PFS Comp SHUTDOWN -Current Overload Fault X X X X X X X

X X X X X Condenser Ent Water Temp Sensor Fault

Controller board offline Fault X X X X X X X X Evap Ent Water Temp Sensor Fault X X X

Evap Leav Water Temp Sensor Fault X X X X X X X

Evap Pump #1 Failure - Pump #2 Start Attempted Problem X X X X X

Evap Pump #2 Failure - Pump #1 Start Attempted Problem X X X X X

External event Warning X X X X X X X X Option Fan Alarm Controller Communication Failed Warning X Option Controller Communication Failed Warning

X X X X X RESTART DELAYED - Power Loss While Running Problem X X X X X X X X SHUTDOWN – Condenser Pressure High Fault X X X X X X X X CIRCUIT SHUTDOWN – Condenser Pressure Sensor Fault X X X X X X X

START INHIBITED - Ambient Temp Low Problem X X X X X X X

X X X X X UNIT SHUTDOWN - Condenser Flow Loss

X X X X X UNIT SHUTDOWN - Evap Freeze Protection Fault X X X X X X X

UNIT SHUTDOWN - Evap Leav Water Temp Low X X X X X X X X UNIT SHUTDOWN - Evap Leav Water Temp Sensor Fault X X X X X X X X UNIT SHUTDOWN - Evap Low Pressure

UNIT SHUTDOWN - Evap Water Flow Loss X X X X X X X X UNIT SHUTDOWN - Outside Air Temp Sensor Fault X X X X X X X

UNIT SHUTDOWN – Phase Voltage Protection Fault X X X X X X X X UNIT STOP - Emergency Stop Alarm X X X X X X X X UNIT STOP - Evap Water Temps Inverted X X X X X X X X UNIT STOP - External Alarm X X X X X X X X UNIT UNLOAD - High Pressure Problem

UNIT UNLOAD - Hi Current Problem X X X X X X X

(4xxxx) R/W Circuit #2 EXV Position 1966 R Circuit #2 Outdoor Fan Speed 1970 R Circuit #2 Condenser Approach Temp 1971 R Circuit #2 Evaporator Approach Temp 1972 R Circuit #2 Outdoor Fan Status 1981 R Circuit #1 EXV Position 1982 R Liquid Temp 1984 R Circuit #1 Outdoor Fan Speed 1986 R Circuit #1 Condenser Approach Temp 1987 R Circuit #1 Evaporator Approach Temp 1988 R Circuit #1 Outdoor Fan Status 1997 R Noise Reduction Auto On 1998 RW Noise Reduction Status 2000 RD-EOMOC002(19)12-14EN - 34/35D-EOMOC002(19)12-14EN - 35/35 The present publication is drawn up by of information only and does not constitute an offer binding upon Daikin Applied Europe S.p.A.. Daikin Applied Europe S.p.A. has compiled the content of this publication to the best of its knowledge. No express or implied warranty is given for the completeness, accuracy, reliability or fitness for particular purpose of its content, and the products and services presented therein. Specification are subject to change without prior notice. Refer to the data communicated at the time of the order. Daikin Applied Europe S.p.A. explicitly rejects any liability for any direct or indirect damage, in the broadest sense, arising from or related to the use and/or interpretation of this publication. All content is copyrighted by Daikin Applied Europe S.p.A..
