Product type	Hi-Fi System
Brand	Panasonic
Model	SC-HC212
Dimensions (W x H x D)	400 mm x 197 mm x 107 mm
Weight	1.9 kg
Power source	AC 220-240 V, 50 Hz
Power consumption	14 W (operation), 0.2 W (standby), 0.3 W (Bluetooth standby)
Output power	10 W per channel (8 Ω), total 20 W RMS
Speakers	2 x 8 cm cone speakers
Playback formats	CD, CD-R/RW (CD-DA, MP3), USB (MP3), Bluetooth, FM/DAB+ radio
Bluetooth	Version 4.2, class 2, profiles A2DP/AVRCP, range 10 m
USB port	USB 2.0 full speed, 5 V / 500 mA, FAT12/16/32, up to 32 GB
Radio	FM (87.5-108 MHz, 30 presets) and DAB/DAB+ (Band III, 20 presets)
Sound effects	MY SOUND, preset EQ (Heavy, Soft, Clear, Vocal, Flat), Bass, Treble, D.BASS, Surround
Timers	Sleep timer (30-120 min), Play timer (alarm)
Other functions	24-hour clock, auto power off, Bluetooth standby, software update
Supplied accessories	Power cord, indoor DAB antenna, remote control (battery included)
Safety	Do not expose to moisture, do not obstruct ventilation openings, use only recommended accessories
Care and cleaning	Unplug before cleaning; use a soft, dry cloth; do not use alcohol, thinner or benzene
Repairability	Do not repair yourself; contact qualified technician; reset possible by unplugging and holding power button

Frequently Asked Questions - SCHC212 PANASONIC

How to pair a Bluetooth device?

Select the BLUETOOTH source on the device. If 'PAIRING' does not appear, press [PLAY MENU] and choose 'PAIRING', or hold the [✗-PAIRING] button on the device. On your device, select 'SC-HC212' in the Bluetooth list. If a code is requested, enter 0000.

What to do if the remote control does not work?

First check that the battery is correctly installed (+ and - poles aligned). If the problem persists, a code change may be necessary: if the display shows 'REMOTE 1', hold [OK] and [✗] for 4 seconds; if 'REMOTE 2', hold [OK] and [USB/CD] for 4 seconds.

How to set the clock?

Press [SETUP] several times to select 'CLOCK'. Set the hour with the [▲, ▼] keys and confirm with [OK]. The clock operates on a 24-hour cycle. You can also activate automatic setting via DAB+ by selecting 'AUTO CLOCK ADJ' in the menu.

Can I play MP3 files from a disc or USB flash drive?

Yes. For CDs, use CD-R/RW recorded in CD-DA or MP3 format. For USB, connect a USB device (up to 32 GB, formatted in FAT12/16/32) containing .mp3 files. The device can play up to 999 tracks per CD and 8000 tracks on USB.

How to preset radio stations?

For FM, select 'FM' then press [PLAY MENU] to choose 'A.PRESET' (auto preset) or manually tune the frequency and press [OK] to save. For DAB+, use 'AUTOSCAN' or manually tune, then press [OK] and choose a preset number. Up to 30 FM stations and 20 DAB+ stations can be stored.

Why is the sound distorted or absent?

Check the device volume. Turn it off, correct the cause (e.g., excessive volume, too powerful speakers) and turn on again. If humming occurs, move power cords or fluorescent lights away. For radio, adjust the antenna or switch to mono mode via 'FM MODE'.

How to use the play timer (alarm)?

First set the clock. Press [SETUP] to select 'TIMER ADJ', set the start and end time, then choose the source (CD, USB, DAB+ or FM). Activate the timer by selecting 'TIMER SET' then 'SET'. The device must be in standby for the timer to work.

What do error codes like 'F61' or 'F77' mean?

'F61' and 'F77' indicate an internal problem. Unplug the power cord and contact your dealer. For 'F703', check the Bluetooth connection and restart the system. 'F76' indicates a power problem; unplug and consult a technician.

How to reset the system?

Unplug the power cord. While holding the [∅/l] button on the main unit, reconnect the power cord. Continue holding until '----' appears, then release. All settings will return to factory defaults.

Can I connect a USB device via an extension cable?

No, using a USB extension cable is not recommended. The device may not recognize the device. Connect the USB device directly to the front port of the unit.

USER MANUAL SCHC212 PANASONIC

Simple line drawing of a monitor setup with a control panel and a remote control unit (no text or symbols)

Panasonic®

Bedienungsanleitung

Mode d'emploi

Hand inserting a circular component into a rectangular device (no text or symbols visible)

Hand pressing a circular button on a device (no text or symbols visible)

Condition minimum -98 dBm

Antenne externe DAB

32 kHz, 44, 1 kHz, 48 kHz

Taille du mot audio 16 bits

Hand holding a circular mechanical component, no text or symbols visible

① Stand-by/Aan-schakelaar [⏻], [⏻/ı]

Hand pressing a circular button on a device (no text or symbols visible)

• 8000 tracks
• 999 tracks per album

Radio

Voorbereiding

PRESET EQ "HEAVY", "SOFT", "CLEAR", "VOCAL" of "FLAT"

BASS -4 tot +4

TREBLE -4 tot +4

D.BASS "ON D.BASS" of "OFF D.BASS"

To set the code to "REMOTE 1"
