CI18WP03 - Wine cellar SIEMENS - Free user manual and instructions

Product type	Wine cellar
Brand	Siemens
Model	CI18WP03
Bottle capacity	18 bottles (estimated)
Climate class	SN-ST
Temperature range	5°C to 20°C
Connectivity	Home Connect (Wi-Fi)
Power supply	220-240 V, 50 Hz
Energy class	E (estimated)
Annual consumption	130 kWh (estimated)
Noise level	39 dB(A) (estimated)
Dimensions (H × W × D)	85 × 59.5 × 66.5 cm (estimated)
Net weight	35 kg (estimated)
Refrigerant	R600a
Color	Stainless steel
Safety	Child lock via the Home Connect app
Maintenance	Clean with a soft cloth and warm water, manual defrosting if necessary
Spare parts	Available within 10 working days via after-sales service

Frequently Asked Questions - CI18WP03 SIEMENS

How to connect the wine cellar to Wi-Fi?

To connect your Siemens CI18WP03 wine cellar to Wi-Fi, download the Home Connect app on your smartphone or tablet. Create a user account, then add the device by following the instructions: select the automatic (WPS) or manual method. Make sure the home network is within range and the password is correct. The control panel displays 'Connection successful' once the connection is established.

What is the bottle capacity of the wine cellar?

The Siemens CI18WP03 model can store approximately 18 bottles of standard wine, as indicated by the model reference. The exact capacity depends on the size and shape of the bottles.

How to adjust the temperature?

The temperature can be adjusted via the control panel on the wine cellar or remotely via the Home Connect app. The recommended temperature range is 5°C to 20°C, depending on the type of wine. Refer to the user manual for precise settings.

What to do if the wine cellar does not cool?

First check that the appliance is plugged in and switched on. Ensure the door is properly closed and the seal is clean. If the problem persists, check the ambient temperature (must be between 10°C and 38°C). For a malfunction, contact Siemens after-sales service.

How to clean the inside of the wine cellar?

To clean the inside, first disconnect the appliance. Use a soft cloth soaked in warm water and mild detergent. Avoid abrasive products. Rinse and dry thoroughly. Manual defrosting may be necessary in case of frost.

Is the appliance compatible with Home Connect?

Yes, the Siemens CI18WP03 wine cellar is compatible with Home Connect. You can control the temperature, receive notifications, and access additional features via the app. Availability depends on your country.

How to activate the child lock?

The child lock can be activated via the Home Connect app after connecting the appliance. In the app, go to the wine cellar settings and enable the safety function. This prevents accidental changes to settings.

What types of bottles can be stored?

This wine cellar is designed for standard wine bottles (75 cl). Magnum bottles or oddly shaped bottles may not fit. Check the shelf dimensions and available space.

What is the power consumption?

The estimated annual consumption is around 130 kWh for this model, corresponding to energy class E. Actual consumption depends on usage and location.

Where to find spare parts?

Spare parts for the Siemens CI18WP03 are available from Siemens after-sales service. You can order them online or at a specialized store. Delivery time is usually within 10 working days.

USER MANUAL CI18WP03 SIEMENS

Welcome to the connected home!

Congratulations on your new smart appliance with Home Connect, designed to simplify your life and make it more enjoyable.*

Home Connect helps you to manage your home appliances with ease and comfort, providing a variety of functions beyond simple remote control.

The Home Connect app gives you important and useful information about your home appliance, allowing you to customize and trigger certain functionalities and actions. Furthermore, the app offers support on how to properly maintain your home appliance and also inspires with a variety of recipes. Explore our ecosystem of partners and gain even more functionalities and services.

Home Connect opens up a world of possibilities exceeding your expectations of a home appliance.

• The availability of the Home Connect function depends on the availability of Home Connect services in your country. Home Connect services are not available in every country. You can find more information on this at www.home-connect.com

Explore: With the Home Connect app you can...

Manage your appliance

In the app's appliance section you have an overview of your connected home appliances, offering a variety of functions beyond simple remote control. Monitor the home appliance's progress, change or pause programs, change settings, trigger actions, and receive notifications.

Be inspired

The recipe section provides a variety of inspiring recipes, tips and videos, that will make cooking and baking even more enjoyable.

Get support

The service section gives helpful information on how to maintain and operate your home appliance properly.

Discover even more benefits

We are constantly expanding our ecosystems of partners. Please refer to www.home-connect.com for an overview of all partners.

Let's get started!

What you need:

1 | Your refrigerator must be installed properly and turned on.
2 | A smartphone or tablet equipped with a current version of iOS or Android operating system.
3 | Your refrigerator within the Wi-Fi signal of your home network.
4 | The name of your WLAN home network (Wi-Fi) (SSID) and its password (key).
5 | This installation guide.

Important information:

Data security: Home Connect values customer data, ensuring the transfer of data is encrypted. Home Connect utilizes a variety of security measures, which are periodically reviewed. For further information visit www.home-connect.com.

Appliance safety: To ensure safe operation of your appliance with Home Connect functionality, please consult the safety information in the appliance instruction manual.

EN4

Step 1: Download the Home Connect app and create a user account

1 | Open the App Store (Apple devices) or Google Play Store (Android devices) on your smartphone or tablet.
2 | Search for the "Home Connect" app in the store's search and install it.

Home Connect app:

Home connect

3 | Open the app and register to create a Home Connect user account.
4 Write down your Home Connect account credentials (user account and password), you will need them later.

The app will guide you through the steps of adding your appliance to Home Connect. It will refer to this guide only when needed.

Step 2: Connect refrigerator to the home network

1 | Your refrigerator is already connected to the power supply and switched on.
2 | Open the Home Connect app to add your refrigerator. Select "Add appliance.
3 | Follow the instructions in the app and only refer to these instructions if the app tells you to.

Note:

We are continually looking at ways to improve the Home Connect app. This can result in differences in the connection steps. Please follow the instructions for the latest version of your Home Connect app, which will guide you through the connection process.

Step 2.1: Connect your refrigerator to your WLAN home network (Wi-Fi) with WPS

Please enter step 2.1 only when prompted to by the app. The following steps describe operations at the home appliance itself.

1 | Open the "Home Connect" menu on your refrigerator.
2 | In the "Connect to the network" submenu, select "Automatic (recommended)" and follow the instructions on the control panel.

3 Activate the WPS function on your home network router within the next 200 minutes.
If the connection is successful, "Successful connection" appears on the control panel.
4 | Follow the instructions in the app.

Information:

If the connection could not be established within 2 minutes, make sure your refrigerator is within the range of your WLAN home network (Wi-Fi).

For some appliances the WPS mode is also called "automatic mode".

EN6

Step 2.2: Connect your refrigerator to your WLAN home network (Wi-Fi) step-by-step

Please enter step 2.2 only when prompted to by the app. The following steps describe operations at the home appliance itself.

1 | Open the "Home Connect" menu on your refrigerator.
2| In the "Connect to the network" submenu, select "Manual" and follow the instructions on the control panel.

The home appliance will open a temporary Home Connect Wi-Fi network with the password "HomeConnect" for 5 minutes.

Using this temporary Wi-Fi network, the app will transmit the name (SSID) and the password of your WLAN home network (Wi-Fi) to the refrigerator, thereby enabling it to connect to your WLAN home network (Wi-Fi).

If the connection is successful, "Successful connection" appears on the control panel.

3 | Follow the instructions in the app.

Information:

For some appliances the step-by-step mode is also called "SAP mode" or "manual mode".

If the step-by-step mode does not work please check:

• Your appliance is in the range of the WLAN home network (Wi-Fi).
• Your smartphone/tablet is connected to your WLAN home network (Wi-Fi).
• Your smartphone/tablet and appliance are connected to the same WLAN home network (Wi-Fi).

Step 3: Connect your refrigerator to the Home Connect app

Please enter step 3 only when prompted to by the app. The following steps describe operations at the home appliance itself.

1 | Open the "Home Connect" menu on your refrigerator.
2 | Open the "App connection" menu option.

3 | Follow the instructions in the app.
If the connection is successful, "Successful connection" appears on the control panel.

Information:

If the connection could not be established make sure your smartphone/tablet is within range of your WLAN home network (Wi-Fi).

Home Connect App: Home connect

Home Connect opens up a world of possibilities, exceeding your expectations of a home appliance.

To learn more about smart home appliances with Home Connect and our partner ecosystem, visit www.home-connect.com

These installation instructions are available in additional languages on the website for your appliance brand.

If you have any questions, just visit us at www.home-connect.com.

Home Connect is a service provided by Home Connect GmbH.

Apple App Store and iOS are Apple Inc. trademarks. Google Play Store and Android are Google Inc. trademarks. Wi-Fi is a Wi-Fi Alliance trademark.
