USER MANUAL RS58K6638SLWS SAMSUNG

Refrigerator User manual RS58K*/RS62K* Free Standing Appliance Untitled-74 1 7/18/2017 5:08:06 PMEnglish2 Contents Contents Safety information 3 Important safety symbols and precautions: 5 Severe warning signs for transportation and site 6 Critical installation warnings 7 Installation cautions 10 Critical usage warnings 11 Usage cautions 16 Cleaning cautions 19 Critical disposal warnings 21 Additional tips for proper usage 22 Saving Energy Tips 23 This appliance is intended to be used in household and similar applications such as 23 Instructions about the WEEE 24 Installation 25 Refrigerator at a glance 25 Step-by-step installation 27 Door removal for entrance 35 Operations 40 Feature panel 40 Temperature settings 44 Special features 45 Maintenance 52 Handle and care 52 Cleaning 56 Replacement 57 Troubleshooting 59 General 59 Untitled-74 2 7/18/2017 5:08:06 PMEnglish 3 Safety information

• Before using your new Samsung Refrigerator, please read this manual thoroughly to ensure that you know how to operate the features and functions that your new appliance offers safely and efciently.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or those who lack experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety.

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

• Warnings and Important Safety Instructions in this manual do not cover all possible conditions and situations that may occur. It is your responsibility to use common sense, caution, and care when installing, maintaining, and operating your appliance.

• Because these following operating instructions cover various models, the characteristics of your refrigerator may differ slightly from those described in this manual and not all warning signs may be applicable. If you have any questions or concerns, contact your nearest service center or nd help and information online at www. samsung.com.

• R-600a or R-134a is used as a refrigerant. Check the compressor label on the rear of the appliance or the rating label inside the fridge to see which refrigerant is used for your refrigerator. When this product contains ammable gas (Refrigerant R-600a), contact your local authority in regard to safe disposal of this product. Safety information Untitled-74 3 7/18/2017 5:08:06 PMSafety information English4 Safety information

• In order to avoid the creation of a ammable gas-air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance may be sited depends on the amount of refrigerant used.

• Never start up an appliance showing any signs of damage. If in doubt, consult your dealer. The room must be 1 m³ in size for every 8 g of R-600a refrigerant inside the appliance. The amount of refrigerant in your particular appliance is shown on the identication plate inside the appliance.

• Refrigerant squirting out of the pipes could ignite or cause an eye injury. When refrigerant leaks from the pipe, avoid any naked ames and move anything ammable away from the product and ventilate the room immediately. - Failing to do so may result in re or explosion. Untitled-74 4 7/18/2017 5:08:06 PMEnglish 5 Safety information Important safety symbols and precautions: Please follow all safety instructions in this manual. This manual uses the following safety symbols. WARNING Hazards or unsafe practices that may result in severe personal injury, property damage, and/or death. CAUTION Hazards or unsafe practices that may result in severe personal injury and/or property damage. NOTE Useful information that helps users understand or benet from the refrigerator. These warning signs are here to prevent injury to you and others. Please follow them carefully. After reading this section, keep it in a safe place for future reference. Untitled-74 5 7/18/2017 5:08:06 PMSafety information English6 Safety information Severe warning signs for transportation and site WARNING

• When transporting and installing the appliance,care should be taken to ensure that no parts of the refrigerating circuit are damaged. - Refrigerant leaking from the pipe work could ignite or cause an eye injury. If a leak is detected, avoid any naked ames or potential sources of ignition and air the room in which the appliance is standing for several minutes. - This appliance contains a small amount of isobutane refrigerant (R-600a), a natural gas with high environmental compatibility that is, however, also combustible. When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged.

• When transporting and installing the refrigerator, do not touch the water hose on the back side of the refrigerator. - This may damage the refrigerator and as a result the water dispenser can not be used. Untitled-74 6 7/18/2017 5:08:06 PMEnglish 7 Safety information Critical installation warnings WARNING

• Do not install the refrigerator in a damp location or place where it may come in contact with water. - Deteriorated insulation on electrical parts may cause an electric shock or re.

• Do not place this refrigerator in direct sunlight or expose it to the heat from stoves, room heaters, or other appliances.

• Do not plug several appliances into the same multiple power strip. The refrigerator should always be plugged into its own individual electrical outlet which has a voltage rating that matches the voltage listed on the refrigerator’s rating plate. - This provides the best performance and also prevents overloading of house wiring circuits, which could cause a re hazard from overheated wires.

• If the wall socket is loose, do not insert the power plug. - There is a risk of electric shock of re.

• Do not use a power cord that has cracks or abrasion damage along its length or at either end.

• Do not bend the power cord excessively or place heavy objects on it.

• Do not pull or excessively bend the power cord.

• Do not twist or tie the power cord.

• Do not hook the power cord over a metal object, place a heavy object on the power cord, insert the power cord between objects, or push the power cord into the space behind the appliance.

• When moving the refrigerator, be careful not to roll over or damage the power cord. - This may result in an electric shock or re. Untitled-74 7 7/18/2017 5:08:07 PMSafety information English8 Safety information

• Never unplug your refrigerator by pulling on the power cord. Always grip the plug rmly and pull straight out from the outlet. - Damage to the cord may cause a short-circuit, re, and/or electric shock.

• Do not use aerosols near the refrigerator. - Using aerosols near the refrigerator may cause an explosion or re.

• Do not install this appliance near a heater or inammable material.

• Do not install this appliance in a location where gas may leak. - This may result in an electric shock or re.

• This refrigerator must be properly located and installed in accordance with the instructions in this manual before you use it.

• Connect the power plug in the proper position with the cord hanging down. - If you connect the power plug upside down, the wire can get cut off and cause a re or electric shock.

• Make sure that the power plug is not crushed or damaged by the back of the refrigerator.

• Keep the packing materials out of reach of children. - There is a risk of death from suffocation if a child puts the packing materials on his or her head.

• The appliance must be positioned so that the plug is accessible after installation. - Failing to do so may result in an electric shock or re due to electric leakage.

• Do not install this appliance in a humid, oily or dusty location, in a location exposed to direct sunlight and water (rain drops). - Deteriorated insulation of electrical parts may cause an electric shock or re. Untitled-74 8 7/18/2017 5:08:07 PMEnglish 9 Safety information

• If any dust or water is in the refrigerator, pull out power plug and contact your Samsung Electronics service center. - Otherwise there is a risk of re.

• Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. - This may result in an electric shock, re, problems with the product, or injury.

• You need to remove all the protective plastic lm before you initially plug the product in.

• Children should be supervised to ensure that they do not play with the snap rings used for door adjustment or the water tube clips. - There is risk of death by suffocation if a child swallows a snap ring or water tube clip. Keep the snap rings and water tube clips out of children’s reach.

• The refrigerator must be safely grounded. - Always make sure that you have grounded the refrigerator before attempting to investigate or repair any part of the appliance. Power leakages can cause severe electric shock.

• Never use gas pipes, telephone lines, or other potential lightning attractors as an electrical ground. - You must ground the refrigerator to prevent any power leakages or electric shocks caused by current leakage from the refrigerator. - This may result in an electric shock, re, explosion, or problems with the product.

• Plug the power plug into the wall socket rmly. Do not use a damaged power plug, damaged power cord, or loose wall socket. - This may result in an electric shock or re. Untitled-74 9 7/18/2017 5:08:07 PMSafety information English10 Safety information

• If the power cord is damaged, have it replaced immediately by the manufacturer or one of its service agents.

• The fuse on the refrigerator must be changed by a qualied technician or service company. - Failing to do so may result in an electric shock or personal injury. Installation cautions CAUTION

• Allow sufcient space around the refrigerator and install it on a at surface. - If your refrigerator is not level, cooling efciency and durability can be declined. - Keep the ventilation space in the appliance enclosure or mounting structure clear of obstructions.

• Allow the appliance to stand for 2 hours before loading foods after installation and turning on.

• We strongly recommend you have a qualied technician or service company install the refrigerator. - Failing to do so may result in an electric shock, re, explosion, problems with the product, or injury. Untitled-74 10 7/18/2017 5:08:07 PMEnglish 11 Safety information Critical usage warnings WARNING

• Do not insert the power plug into a wall socket with wet hands. - This may result in an electric shock.

• Do not store articles on the top of the appliance. - When you open or close the door, the articles may fall and cause personal injury and/or material damage.

• Do not insert hands, feet or metal objects (such as chopsticks, etc.) into the bottom or the back of the refrigerator. - This may result in an electric shock or injury. - Any sharp edges may cause a personal injury.

• Do not touch the inside walls of the freezer or products stored in the freezer with wet hands. - This may cause frostbite.

• Do not put a container lled with water on the refrigerator. - If spilled, there is a risk of re or electric shock.

• Do not keep volatile or ammable objects or substances (benzene, thinner, propane gas, alcohol, ether, LP gas, and other such products) in the refrigerator. - This refrigerator is for storing food only. - This may result in re or explosion.

• Children should be supervised to ensure that they do not play with the appliance. - Keep ngers out of “pinch point” areas. Clearances between the doors and cabinet are necessarily small. Be careful when you open the doors if children are in the area.

• Do not let children hang on the door or door bins. A serious injury may occur.

• Do not let children go inside the refrigerator. They could become trapped. Untitled-74 11 7/18/2017 5:08:07 PMSafety information English12 Safety information

• Do not insert your hands into the bottom area under the appliance. - Any sharp edges may cause personal injury.

• Do not store pharmaceutical products, scientic materials, or temperature sensitive products in the refrigerator. - Products that require strict temperature controls must not be stored in the refrigerator.

• Do not place or use electrical appliance inside the refrigerator/ freezer, unless they are of a type recommended by the manufacturer.

• If you smell pharmaceutical or smoke, pull out power plug immediately and contact your Samsung Electronics service center.

• If any dust or water is in Refrigerator, pull out power plug and contact your Samsung Electronics service center. - Otherwise there is a risk of re.

• Do not let children step on a drawer. - The drawer may break and cause them to slip.

• Do not leave the doors of the refrigerator open while the refrigerator is unattended and do not let children enter inside the refrigerator.

• Do not allow babies or children go inside the drawer. - It can cause death from suffocation by entrapment or personal injury.

• Do not overll the refrigerator with food. - When you open the door, an item may fall out and cause personal injury or material damage.

• Do not spray volatile material such as insecticide onto the surface of the appliance. - As well as being harmful to humans, it may also result in an electric shock, re, or problems with the product. Untitled-74 12 7/18/2017 5:08:07 PMEnglish 13 Safety information

• Never put ngers or other objects into the water dispenser hole, ice chute and ice maker bucket. - It may cause a personal injury or material damage.

• Do not use or place any substances sensitive to temperature such as ammable sprays, ammable objects, dry ice, medicine, or chemicals near or inside of the refrigerator.

• Do not use a hair dryer to dry the inside of the refrigerator. Do not place a lighted candle in the refrigerator for removing bad odours. - This may result in an electric shock or re.

• Fill the water tank, ice tray and water cubes only with potable water (mineral water or puried water). - Do not ll the tank with tea, juice or sports drink, this may damage the refrigerator.

• Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. This may result in an electric shock, re, problems with the product, or injury. Do not put a container lled with water on the appliance. - If spilled, there is a risk of re or electric shock.

• Do not use mechanical devices or any other means to accelerate the defrosting process, other than those recommended by the manufacturer.

• Do not damage the refrigerant circuit.

• Never stare directly at the UV LED lamp for long periods of time. - This may result in eye strain due to the ultraviolet rays.

• Do not put fridge shelf in upside down. Shelf stopper could not work. - It may cause a personal injury because of glass shelf drop. Untitled-74 13 7/18/2017 5:08:07 PMSafety information English14 Safety information

• Keep ngers out of “pinch point” areas. Clearances between the doors and cabinet are necessarily small. Be careful when you open the doors if children are in the area.

• If a gas leak is detected, avoid any naked ames or potential sources of ignition, and air the room in which the appliance is standing for several minutes. - Do not touch the appliance or power cord. - Do not use a ventilating fan. - A spark may result in explosion or re.

• Use only the LED Lamps provided by the manufacturer or its service agents.

• Bottles should be stored tightly together so that they do not fall out.

• This product is intended only for the storage of food in a domestic environment.

• Never put ngers or other objects into the water dispenser hole, ice chute and ice maker bucket. - It may cause a personal injury or material damage.

• Do not attempt to repair, disassemble, or modify the refrigerator yourself.

• Do not use any fuse (such as cooper, steel wire, etc.) other than a standard fuse.

• If your refrigerator needs to be repaired or reinstalled, contact your nearest service center. - Failing to do so may result in an electric shock, re, problems with the product, or injury.

• If the interior or exterior LED lamp has gone out, contact your nearest service center. Untitled-74 14 7/18/2017 5:08:07 PMEnglish 15 Safety information

• If the refrigerator emits a burning smell or smoke, unplug the refrigerator immediately and contact your Samsung Electronics service center. - Failing to do so may result in an electric or re hazards.

• Pull the power plug out of the socket before changing the interior lamps of the refrigerator. - Otherwise, there is a risk of electric shock.

• If you experience difculty changing a non-LED light, contact a Samsung service center.

• If the product is equipped with LED lamps, do not disassemble the Lamp Covers and LED lamps yourself. - Contact a Samsung service center.

• Plug the power plug into the wall socket rmly.

• Do not use a damaged power plug, damaged power cord or loose wall socket. - This may result in an electric shock or re. Untitled-74 15 7/18/2017 5:08:07 PMSafety information English16 Safety information Usage cautions CAUTION

• Do not re-freeze frozen foods that have thawed completely. Do not place carbonated or zzy drinks in the freezer compartment. Do not put bottles or glass containers in the freezer. - When the contents freeze, the glass may break and cause personal injury.

• Use only the ice maker provided with the refrigerator.

• Have the refrigerator’s water supply connected only to a potable water supply. To operate the ice maker properly, water pressure of 20 ~ 125 psi (138 ~ 862 kPa) is required. If you will be away from home for a long period of time (on vacation, for example) and won’t be using the water or ice dispensers, close the water valve. - Otherwise, water leakage may occur.

• If you won’t be using the refrigerator for a very long period of time, (3 weeks or more) empty the refrigerator including the ice bucket, unplug it, close the water valve, wipe excess moisture from the inside walls, and leave the doors open to prevent odors and mold.

• To get the best performance from the product: - Do not place food too close to the vents at the rear of the refrigerator as this can obstruct free air circulation in the refrigerator compartment. - Wrap food up properly or place it in airtight containers before putting it into the refrigerator. - Do not place glass bottles or carbonated beverages into the freezer. They can freeze and break. Broken beverage containers can cause injury. - Please observe maximum storage times and expiration dates of frozen goods. Untitled-74 16 7/18/2017 5:08:07 PMEnglish 17 Safety information - There is no need to disconnect the refrigerator from the power supply if you will be away for less than three weeks. However, if you will be away for more than three weeks, remove all the food and ice in the ice bucket, unplug the refrigerator, close the water valve, wipe excess moisture from the inside walls, and leave the doors open to prevent odors and mold.

• Do not place glass or bottles or carbonated beverages into the freezer. - The container may freeze and break, and this may result in injury.

• Do not place carbonated or zzy drinks in the freezer compartment. Do not put bottles or glass containers in the freezer. - When the contents freeze, the glass may break and cause personal injury and property damage.

• Service Warranty and Modication. - Any changes or modications performed by a 3rd party on this nished appliance are not covered under Samsung warranty service, nor is Samsung responsible for safety issues that result from 3rd party modications.

• Do not block the air vents inside the refrigerator. - If the air vents are blocked, especially with a plastic bag, the refrigerator can be over cooled. If a cooling period lasts too long, the water lter may break and cause water leakage.

• Use only the ice-maker provided with the refrigerator.

• Wipe excess moisture from the inside and leave the doors open. - Otherwise, odor and mold may develop.

• If the refrigerator is disconnected from the power supply, you should wait for at least ve minutes before plugging it back in. Untitled-74 17 7/18/2017 5:08:07 PMSafety information English18 Safety information

• If you have a long vacation planned or do not intend to use the refrigerator for a long period of time, (3 weeks or more) empty the refrigerator including the ice bucket, pull out the power plug, close the water valve, wipe excess moisture from the inside walls, and leave the doors open to prevent odors and mold.

• When the refrigerator got wet by water, pull out the power plug and contact your Samsung Electronics service center.

• Do not strike or apply excessive force to any glass surface. - Broken glass may result in a personal injury and/or property damage.

• Fill the water tank and ice cube trays with potable water only (tap water, mineral water, or puried water). - Do not ll the tank with tea or a sports drink. This may damage the refrigerator.

• Be careful that your ngers are not caught in.

• If the refrigerator is ooded, make sure to contact your nearest service center. - There is a risk of electric shock or re.

• Do not keep vegetable oil in your refrigerator’s door bins. The oil can solidify, making it foul-tasting and difcult to use. In addition, the open container can leak and the leaked oil can cause the door bin to crack. After opening an oil container, it is best to keep the container in a cool and shaded place such as a cupboard or pantry. - Examples of vegetable oil: olive oil, corn oil, grape-seed oil, etc. Untitled-74 18 7/18/2017 5:08:07 PMEnglish 19 Safety information Cleaning cautions CAUTION

• Do not spray water directly on the inside or outside the refrigerator. - There is a risk of re or electric shock.

• Do not use a hair dryer to dry the inside of the refrigerator.

• Do not place a lighted candle in the refrigerator to remove bad odors. - This may result in an electric shock or re.

• Do not spray cleaning products directly on the display. - Printed letters on the display may come off.

• If any foreign substance such as water has entered the appliance, unplug the power plug and contact your nearest service center. - Failing to do so may result in an electric shock or re.

• Use a clean, dry cloth to remove any foreign matter or dust from the power plug blades. Do not use a wet or damp cloth when cleaning the plug. - Otherwise, there is a risk of re or electric shock.

• Do not clean the appliance by spraying water directly onto it.

• Do not use benzene, thinner, or Clorox, Chloride for cleaning. - They may damage the surface of the appliance and may cause a re.

• Never put ngers or other objects into the dispenser hole. - It may cause a personal injury or material damage.

• Before cleaning or performing maintenance, unplug the appliance from the wall socket. - Failing to do so may result in an electric shock or re.

• Use a clean sponge or soft cloth and a mild detergent in warm water to clean the refrigerator. Untitled-74 19 7/18/2017 5:08:07 PMSafety information English20 Safety information

• Do not use abrasive or harsh cleansers such as window sprays, scouring cleansers, ammable uids, muriatic acid, cleaning waxes, concentrated detergents, bleaches, or cleansers containing petroleum products on exterior surfaces (doors and cabinet), plastic parts, door and interior liners, and gaskets. - These can scratch or damage the material.

• Do not clean glass shelves or covers with warm water when they are cold. Glass shelves and covers may break if exposed to sudden temperature changes or impacts such as bumping or dropping. Untitled-74 20 7/18/2017 5:08:07 PMEnglish 21 Safety information Critical disposal warnings WARNING

• Please dispose of the packaging material from this product in an environmentally friendly manner.

• Ensure that none of the pipes on the back of the refrigerator are damaged prior to disposal.

• R-600a or R-134a is used as a refrigerant. Check the compressor label on the rear of the appliance or the rating label inside the fridge to see which refrigerant is used for your refrigerator. If this refrigerator contains ammable gas (Refrigerant R-600a), contact your local authority in regard to safe disposal of this product.

• When disposing of this refrigerator, remove the door/door seals and door latch so that small children or animals cannot become trapped inside. Children should be supervised to ensure that they do not play with the appliance. If trapped inside, a child may get hurt or suffocate to death. - If trapped inside, the child may become injury and suffocate to death.

• Cyclopentane is used in the insulation. The gases in the insulation material require a special disposal procedure. Please contact your local authorities in regard to the environmentally safe disposal of this product.

• Keep all packaging materials well out of the reach of children, as packaging materials can be dangerous to children. - If a child places a bag over his or her head, the child could suffocate. Untitled-74 21 7/18/2017 5:08:07 PMSafety information English22 Safety information Additional tips for proper usage

• In the event of a power failure, call the local ofce of your electric company and ask how long the failure is going to last. - Most power failures that are corrected in an hour or two will not affect your refrigerator temperatures. However, you should minimize the number of door openings while the power is off. - Should the power failure last more than 24 hours, remove and discard all frozen food.

• The refrigerator might not operate consistently (frozen contents can thaw or temperatures can become too warm in the frozen food compartment) if sited for an extended period of time in a location where ambient air temperatures are constantly below the temperatures for which the appliance is designed.

• In case of particular foods, keeping it under refrigeration can have a bad effect on preservation due to its properties.

• Your appliance is frost free, which means there is no need to manually defrost your appliance. This will be carried out automatically.

• Temperature rise during defrosting complies with ISO requirements. If you want to prevent an undue rise in the temperature of frozen food while the appliance defrosts, wrap the frozen food in several layers of newspaper.

• Do not re-freeze frozen foods that have thawed completely.

• The temperature of two star section (sections) or compartment (compartments) which have two star symbol ( ) is slightly higher than other freezer compartment (compartments). The two star section (sections) or compartment (compartments) is (are) based on the instruction and/or the condition as delivered. Untitled-74 22 7/18/2017 5:08:07 PMEnglish 23 Safety information Saving Energy Tips

• Install the appliance in a cool, dry room with adequate ventilation. Ensure that it is not exposed to direct sunlight and never put it near a direct source of heat (a radiator, for example).

• Not to block any vents and grilles is recommended for energy efciency.

• Allow warm food to cool down before placing it in the appliance.

• Put frozen food in the refrigerator to thaw. You can then use the low temperatures of the frozen products to cool food in the refrigerator.

• Do not keep the door of the refrigerator open for too long when putting food in or taking food out. The shorter the time the door is open, the less frost build-up you’ll have in the freezer.

• It is recommended to install the refrigerator with clearance to the back and sides. This will help reduce power consumption and keep your energy bills lower.

• For the most efcient use of energy, please keep the all inner ttings such as baskets, drawers, shelves on the position supplied by manufacturer. This appliance is intended to be used in household and similar applications such as

• staff kitchen areas in shops, ofces and other working environments;

• farm houses and by clients in hotels, motels and other residential type environments;

• bed and breakfast type environments;

• catering and similar non-retail applications. Untitled-74 23 7/18/2017 5:08:08 PMSafety information English24 Safety information Instructions about the WEEE Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or their local government ofce, for details of where and how they can take these items for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For information on Samsung’s environmental commitments and product specic regulatory obligations e.g. REACH visit: samsung. com/uk/aboutsamsung/samsungelectronics/corporatecitizenship/ data_corner.html (For products sold in European countries only) Untitled-74 24 7/18/2017 5:08:08 PMEnglish 25 Installation Follow these instructions carefully to ensure a proper installation of this refrigerator and to prevent accidents before using it. WARNING

• Use the refrigerator only for its intended purpose as described in this manual.

• Any servicing must be performed by a qualied technician.

• Dispose of the product packaging material in compliance with the local regulations.

• To prevent electric shock, unplug the power cord before servicing or replacements. Refrigerator at a glance The actual appearance of your refrigerator may differ, depending on the model and the country. RS58*

01 Freezer shelves 02 Multipurpose freezer guard 03 Dried food and meat storage bin 04 Refrigerator guard 05 Refrigerator shelves 06 Vegetable bin 07 Multipurpose bin 08 Egg container 09 Ice maker bucket ** 10 Moving tray * 11 Anti-bacteria lter * 12 Water lter ** 13 Ice tray

• Applicable models only ** Dispenser models only NOTE The design of the egg container may differ with the model. CAUTION

• Do not put the moving tray in the freezer when lled with water. Water freezes and the moving tray breaks. Untitled-74 26 7/18/2017 5:08:09 PMEnglish 27 Installation Step-by-step installation STEP 1 Select a site Site requirements:

• Solid, level surface without carpeting or ooring that may obstruct ventilation

• Away from direct sunlight

• Adequate room for opening and closing the door

• Away from a heat source

• Room for maintenance and servicing

• Temperature range: between 5 °C and 43 °C Effective temperature range The refrigerator is designed to operate normally in the temperature range specied by its class rating. Class Symbol Ambient Temperature range (°C)

IEC 62552 (ISO 15502) ISO 8561

Extended Temperate SN +10 to +32 +10 to +32 Temperate N +16 to +32 +16 to +32 Subtropical ST +16 to +38 +18 to +38 Tropical T +16 to +43 +18 to +43 NOTE The cooling performance and power consumption of the refrigerator may be affected by the ambient temperature, the door-opening frequency, and the location of the refrigerator. We recommend adjusting the temperature settings as appropriate. Untitled-74 27 7/18/2017 5:08:09 PMInstallation English28 Installation Clearance See the pictures and table below for space requirements for installation.

Depth “A” 721 Width “B” 908 Height “C” 1796 Overall Height “D” 1825 (unit: mm)

• The surface to install the refrigerator must support a fully loaded refrigerator.

• To protect the oor, put a large piece of cardboard on each leg of the refrigerator.

• Once the refrigerator is in its nal position, do not move it unless necessary to protect the oor. If you have to, use a thick paper or cloth such as old carpets along the movement path. NOTE If the refrigerator cannot pass through the entrance due to its size, see the Door removal for entrance section in the Installation chapter. Untitled-74 29 7/18/2017 5:08:10 PMInstallation English30 Installation STEP 3 Adjust the levelling feet CAUTION

• The refrigerator must be levelled on a at, solid oor. Failing to do so can cause damage to the refrigerator or physical injury.

• Levelling must be performed with an empty refrigerator. Make sure no food items remain inside the refrigerator.

• For safety reasons, adjust the front side a little higher than the rear side. The refrigerator can be levelled using the front legs that have a special screw (leveller) for levelling purposes. Use a at-head screwdriver for levelling. To adjust the height of the freezer side: Insert a at-head screwdriver into the leveller of the freezer-side front leg. Turn the leveller clockwise to raise, or turn it counter clockwise to lower. To adjust the height of the fridge side: Insert a at-head screwdriver into the leveller of the fridge-side front leg. Turn the leveller clockwise to raise, or turn it counter clockwise to lower. Untitled-74 30 7/18/2017 5:08:10 PMEnglish 31 Installation STEP 4 Adjust the door height as well as the door gap To adjust the height of a door The height of a door can be adjusted using the clamp nut and the height nut on the front bottom of each door.

1. Open the door to adjust, and locate the

two nuts (A) and (B) on the front bottom of the door.

2. With the provided spanner, turn the

clamp nut (A) clockwise to loosen. Then, open the door, and do the following inside the door. - To raise the door, turn the height nut (B) counter clockwise. - To lower the door, turn the height nut (B) clockwise.

(A) by turning it counter clockwise. Untitled-74 31 7/18/2017 5:08:11 PMInstallation English32 Installation To correct the gap between a door and the refrigerator unit The gap can be adjusted manually using the gap bolt on the top rear side of each door.

1. To adjust the gap, do the following:

- To widen the gap, turn the gap bolt (A) clockwise. - To narrow the gap, turn the gap bolt (A) counter clockwise.

2. When the gap is corrected, tighten the

locking nut (B) by turning it clockwise. Untitled-74 32 7/18/2017 5:08:11 PMEnglish 33 Installation STEP 5 Connect to a water source CAUTION

• The water line must be connected by a qualied technician.

• The warranty for your refrigerator does not cover the water line installation. The water line installation will be performed at your own costs unless the installation fee is included in the retailer’s price.

• Samsung takes no responsibility for the water line installation. If water leaks occur, contact the installer of the water line. To connect the cold water pipe to the water ltering hose CAUTION

• Make sure the water ltering hose is connected to a cold, potable water source pipe. Connecting to the hot water pipe may cause the purier to malfunction.

A. Close Main Water pipe B. No gap

1. Shut off the water supply by closing the

2. Locate the cold, potable water pipe (1).

3. Follow the Water Line Installation to

connect to the water pipe.

4. When connection is complete, open the

main water valve and dispense about 3 liters of water. This is to remove impurities inside the pipe. Untitled-74 33 7/18/2017 5:08:11 PMInstallation English34 Installation To connect the water ltering hose to the water line Remove cap

A. Water Line from unit B. Water Line from Kit

1. Loosen and remove the compression

nut (a) from the water line of the refrigerator, and insert it to the water ltering hose.

2. Tighten up the compression nut (a) to

connect the water ltering hose and the water line.

3. Open the main water valve and check

4. If there are no leaks, dispense about a

3 liters of water before actually using the refrigerator to remove impurities inside the water ltering system. To repair the water line CAUTION The waterline must be repaired by a qualied professional. If you encounter a water leak, contact a local Samsung service centre or the installer of the waterline. STEP 6 Initial settings By completing the following steps, the refrigerator should be fully functioning.

1. Plug the power cord into the wall socket to turn the refrigerator on.

2. Open the door, and check if the interior light lights up.

3. Set the temperature to the coldest, and wait for about an hour. Then, the freezer will be

slightly chilled, and the motor will run smoothly.

4. Wait until the refrigerator reaches the set temperature. Now the refrigerator is ready

for use. STEP 7 Final check When installation is complete, conrm that:

• The refrigerator is plugged into an electrical outlet and grounded properly.

• The refrigerator is installed on a at, level surface with a reasonable clearance from the wall or the cabinet.

• The refrigerator is level and is sitting rmly on the oor.

• The door opens and closes freely, and the interior light turns on automatically when you open the door. Untitled-74 34 7/18/2017 5:08:12 PMEnglish 35 Installation Door removal for entrance If the refrigerator cannot pass through the entrance due to its size, follow these instructions: Tools required (not provided) These tools are used for removing the doors. Phillips screwdriver Flat-heat screwdriver Socket spanner (10 mm) Allen spanner (5 mm) Disconnect the water line

1. From the bottom rear side of the

refrigerator, pull out the water line to the front. NOTE The refrigerator’s water line is a water circulation line that connects between the water pipe from the water source and the hoses from the water ltering system of the refrigerator.

2. To disconnect the hoses, press and hold

the transparent coupler (A) and detach the water hose (B). CAUTION Do not apply excessive force to the coupler. It may break. Untitled-74 35 7/18/2017 5:08:12 PMInstallation English36 Installation Detach the doors CAUTION The door may fall off or over and damage itself during any of these steps. To prevent an accident, use extreme caution when performing these steps.

1. Use a Phillips screwdriver to unscrew

the hinge covers (A) on the top of each door.

2. Open the doors to loosen the hinges

and remove the hinge covers. Once the covers are removed, close the doors.

3. Disconnect the electrical harness.

clockwise, and remove the upper hinge (C). Be careful as the door can fall on you, causing physical injury. Untitled-74 36 7/18/2017 5:08:13 PMEnglish 37 Installation

5. Remove the hinges (C) on both sides.

6. Gently lift up the doors one by one to

remove. Use caution as the door may fall off or over. Reconnect the water hoses Once the refrigerator has passed through the entrance, reconnect the water hoses and insert the provided clips (x2) to tighten the coupler.

• Make sure the water hoses are connected with matching colours.

• To prevent water leaks, each water hose must be inserted fully to the centre of the transparent coupler and then must be clipped. Untitled-74 37 7/18/2017 5:08:13 PMInstallation English38 Installation Reattach the doors CAUTION

• Before reattaching the doors, make sure all the electrical connectors are properly connected.

• The freezer door must be reattached before the fridge door.

1. Hold the freezer door and hook to the

hinge at the bottom of the refrigerator.

2. On the top side, insert the hinge (A) into

the hinge hole (C). Make sure the hinge shaft is straight so that all screw holes are fully revealed. Then, tighten the hinge screws (D) clockwise. Untitled-74 38 7/18/2017 5:08:14 PMEnglish 39 Installation

4. Connect the electrical harness.

5. Insert the hinge covers with the front

sides rst, and then tighten the screws. Use a Phillips screwdriver for this step. Untitled-74 39 7/18/2017 5:08:14 PMEnglish40 Operations Feature panel

• Applicable models only Operations Untitled-74 40 7/18/2017 5:08:14 PMEnglish 41 Operations 01 Freezer / Power Freeze (3 sec) Freezer The Freezer button can be used to set the freezer temperature, or to activate Power Freeze. Available temperatures are between -15 °C (5 °F) and -23 °C (-8 °F). Power Freeze Power Freeze speeds up the freezing process at maximum fan speed. The freezer keeps running at full speed for several hours and then returns to the previous temperature.

• To activate Power Freeze, press and hold Freezer for 3 seconds. The corresponding indicator ( ) lights up, and the refrigerator will speed up the freezing process for you.

• To deactivate, press and hold Freezer for 3 seconds again. The freezer returns to the previous temperature setting.

• To freeze large amounts of food, activate Power Freeze for at least 24 hours before putting food in the freezer. NOTE Using Power Freeze increases power consumption. Make sure you turn it off and return to the previous temperature if you do not intend to use it. 02 Lighting / °C °F (3 sec) The Lighting button can be used to switch the temperature scale between Celsius and Fahrenheit. To switch the temperature scale, press and hold Lighting for 3 seconds to change the current temperature scale. 03 Vacation Vacation The Vacation button can be used to activate/deactivate Vacation mode. If you are going on vacation or a business trip, or if you do not intend to use the refrigerator for an extended time, use the Vacation feature. Press and hold Vacation for 3 seconds to turn off the fridge operation with the Vacation indicator ( ) on. NOTE It is strongly recommended to empty the fridge compartment and make sure the door is closed. Untitled-74 41 7/18/2017 5:08:15 PMOperations English42 Operations 04 Fridge / Power Cool (3 sec) The Fridge button can be used to set the fridge temperature, or to activate/deactivate Power Cool. Fridge You can manually adjust the cooling temperature for the fridge. Keep pressing Fridge to cycle through the temperature bar, and select a desired temperature between 1 °C (34 °F) and 7 °C (44 °F). Power Cool Power Cool speeds up the cooling process at maximum fan speed. This is useful to quickly cool food that spoils quickly, or after the door is left open for some time. The fridge keeps running at full speed for several hours and then returns to the previous temperature. Press and hold Power Cool for 3 seconds. 05 Door Alarm Door Alarm You can set the alarm for a reminder. If the door is left open for more than 2 minutes, the alarm will sound with the alarm indicator ( ) blinking. The alarm is enabled by factory default. To disable the alarm, press Door Alarm. To enable, press Door Alarm again. 06 Filter The lter lifecycle will be reset and the lter indicator turns off. The icon will blink red for several seconds when you open or close the door. Untitled-74 42 7/18/2017 5:08:15 PMEnglish 43 Operations 07 Control Lock (3 sec) Control Lock To activate the Control Lock, press and hold Control Lock for 3 seconds. The controls on the display are disabled, and the dispenser does not operate even if you push the lever. To deactivate, press and hold again for 3 seconds. 08 Water / Filter Reset (3 sec) The Water button can be used to dispense water, or to reset the water lter. Dispensing Press Water to dispense water. In this mode, no ice will be dispensed. Filter Reset After about 6 months (approximately 300 gallons) of using the original water lter, the Filter indicator turns red to remind you that the lter needs to be replaced. If this happens, replace the lter, and press and hold Filter Reset for 3 seconds. NOTE Some regional areas have relatively large amounts of lime contained in the water. This may reduce the lifecycle of the lter. In these areas, you will have to replace the water lter more often than specied above. 09 Cubed/Crushed Ice / Ice Maker Off (3 sec) Cubed/Crushed Ice You can select an ice type. Press the button to toggle between the cubed and crushed ice types. The corresponding indicator turns on. Ice Maker Off To disable ice making, press and hold for 3 seconds. In this mode, ice making is disabled even if you press Cubed/Crushed Ice. Untitled-74 43 7/18/2017 5:08:15 PMOperations English44 Operations Temperature settings To ensure optimal performance, we recommend setting the temperature to -19 °C (-2 °F) for the freezer, and 3 °C (37 °F) for the fridge. Freezer The freezer temperature can be adjusted between -23 °C (-9 °F) and -15 °C (5 °F). To change the temperature, keep pressing Freezer until a desired temperature is selected. The temperature changes by 1 scale unit.

• Recommended: -19 °C (-2 °F) NOTE Ice cream may melt at -15 °C (5 °F). Fridge The fridge temperature can be adjusted between 1 °C (34 °F) and 7 °C (44 °F). To change the temperature, keep pressing Fridge until a desired temperature is selected. The temperature changes by 1 scale unit.

• Recommended: 3 °C (37 °F) The temperature of the freezer or fridge may rise if you open the door frequently, or a large amount of food is put in the refrigerator. If this happens, the temperature display blinks until the refrigerator returns to the specied temperature settings. NOTE If this blinking continues, disconnect the power cord and restart the refrigerator after 10 minutes. Untitled-74 44 7/18/2017 5:08:15 PMEnglish 45 Operations Special features The refrigerator features user-oriented devices that you can use to benet from. Water dispenser (applicable models only) With the water dispenser, you can dispense water without opening the fridge door. WaterCubed Crushed Ice Maker Off Basically, the water dispenser offers 3 options: chilled water, cubed ice, and crushed ice. If you do not want to dispense ice, press Ice Maker Off. With the Ice Maker enabled,

1. Press to select the ice type.

2. Put a water glass on the dispenser lever

and push it. Ice will be dispensed from the dispenser.

3. Press to select the water.

4. Then, put the glass on the dispenser

lever and push it. Water will be dispensed from the dispenser. NOTE

• To prevent spills, wait 2 seconds before removing the glass after dispensing.

• The dispenser will stop dispensing if you keep pushing the dispenser lever for about 1 minute. To dispense more water, release and push the lever again.

• Make sure the glass is in line with the dispenser to prevent the dispensed water from spilling out.

• If you do not use the water dispenser for 2-3 days, the dispensed water may have an abnormal smell or taste. This is not a system failure. Discard the rst 1-2 glasses of water. Untitled-74 45 7/18/2017 5:08:16 PMOperations English46 Operations To ll the water tank For rst-time use, clean the inner side of the water tank and dry well.

1. Hold both handgrips on the front of the

tank, and slide out as shown. A B

2. Open the front lid (A) of the cover or

the entire cover (B) and ll the tank with a max of 5 liters water. CAUTION Do not exceed the max line. Water overows.

3. Reinsert the water tank and t into the

dispenser mechanism. Make sure the front side (with the front lid) of the tank faces to the front. CAUTION

• Make sure the water tank ts into the shelf. Otherwise, the water tank may not operate properly.

• Do not use the refrigerator without inserting the water tank. This may decrease the cooling performance.

• Fill the tank only with potable water such as mineral or puried water. Do not use other liquid.

• Use caution when moving a lled tank. Physical injury may occur if the tank is dropped.

• Do not try to disassemble the internal pump yourself. If the internal pump is damaged or disconnected from the water tank, the dispenser does not operate. For rst-time use

• Push the dispenser lever for 10 seconds to emit air from the hoses of the water supply system.

• Discard the rst six glasses of water to remove impurities in the water supply system. Untitled-74 46 7/18/2017 5:08:16 PMEnglish 47 Operations To dispense water Put a glass under the water outlet, and gently push against the dispenser lever with the glass. CAUTION

• Make sure the glass is in line with the dispenser to prevent the dispensed water from spilling out.

• If you do not use the water dispenser for 2-3 days, the dispensed water may have an abnormal smell or taste. This is not a system failure. Discard the rst 1-2 glasses of water. Ice making (applicable models only) The refrigerator has a built-in ice maker that automatically dispenses ice so that you can enjoy ltered water with cubed or crushed ice to your preference.

If ice does not dispense, rst check the ice maker if it makes ice properly. To check the ice maker

1. Gently hold the icemaker bucket (B)

with both hands and remove it from the ice chute (A).

2. Check the icemaker bucket if it contains

3. Then, hold the icemaker cover (C) and

slightly lift up to remove.

4. Press Test (D) on the side of the ice

maker. You will hear a chime (ding- dong) at the press of the button.

5. You will hear another chime if the ice

maker operates properly. NOTE If this symptom continues, contact the waterline installer or a local Samsung service centre. CAUTION

• Do not press the button repeatedly after the ice tray is lled with ice or water. Water may overow or ice may be jammed. Untitled-74 47 7/18/2017 5:08:16 PMOperations English48 Operations

• When the refrigerator recovers power supply after a power failure, the icemaker bucket may contain a mix of melted and jammed ice cubes, resulting in a system failure. To prevent this, make sure to empty the icemaker bucket before using the refrigerator.

• To prevent dropping the icemaker bucket, make sure to use both hands when removing or reinserting the icemaker bucket.

• Do not let children hang on or play with the ice dispenser or the icemaker bucket. Children may get hurt.

• Do not put ngers or other objects into the dispenser hole or the ice chute. This may cause physical injury or property damage. NOTE

• If you remove the icemaker bucket, the Ice Maker Off indicator ( ) will blink.

• Removal of the icemaker bucket does not affect the thermal and mechanical performance of the refrigerator.

• The declared freezer volume is based on use of the freezer guide after the ice maker, snack bin, and upper drawer are removed. Untitled-74 48 7/18/2017 5:08:17 PMEnglish 49 Operations To secure more storage space (applicable models only)

If you do not use the ice maker and need more storage space, remove the icemaker bucket (A) and the snack bin. Then, insert the freezer guide (B) into the icemaker bucket’s place. To secure more room, remove the freezer’s upper drawer (C). Icemaker bucket If you do not dispense ice for an extended period, ice may form clumps inside the bucket. If this happens, remove and empty the icemaker bucket.

1. To remove the icemaker bucket, gently

lift it up and pull out slowly while holding the handgrips with both hands.

2. Remove and empty the icemaker

bucket. Untitled-74 49 7/18/2017 5:08:17 PMOperations English50 Operations

3. When done, turn the gear handle on the

rear of the bucket by 90°, and then put the bucket back into position. Make sure the bucket is inserted properly until you hear a clicking sound.

4. Press and hold Ice Maker Off for 3

seconds to reset the icemaker. CAUTION

• Do not apply excessive force to the bucket cover. The cover may break.

• Do not close the door hard. Water may spill over the ice maker.

• To prevent injury, make sure to clean up any ice or water that has fallen on the oor.

• To prevent accidents or injury, do not let children play with the water dispenser or the ice maker.

• Do not put your hand or an object into the ice chute. This may cause physical injury or product damage. NOTE

• If the Ice Maker Off indicator ( ) blinks, remove and reinsert the icemaker bucket. Make sure it is reinserted properly.

• Any sound from the ice maker is normal, which outputs during the ice making process.

• While the door is open, neither the ice maker nor the water dispenser operates. Untitled-74 50 7/18/2017 5:08:18 PMEnglish 51 Operations Water pressure If you want to check how much water ows into the ice tray, follow these steps.

1. Gently lift up the icemaker cover (A) to

2. Press Test (B) on the side of the

icemaker. Normally, the ice cube container lls with water in a few minutes.

3. If the water level is lower than

expected, check the water pressure of the water supply line from the water source. This is not a system failure. CAUTION

• Do not press Test repeatedly when the tray is lled with water. Water may overow or ice may be jammed.

• Make sure the icemaker bucket is inserted properly. Otherwise, the ice maker will not operate. Smart Eco (applicable models only)

The Smart Eco system intelligently controls the refrigerator according to the operating environment in order to keep food fresh using 4 sensors that are located on both the inner and outer sides of the refrigerator. This smart system also monitors usage patterns and the operating status to save power consumption. A. External temperature sensor B. External humidity sensor C. Internal temperature sensors Untitled-74 51 7/18/2017 5:08:18 PMEnglish52 Maintenance Handle and care Shelves (fridge/freezer) Rear

• To remove a shelf, fully open the corresponding door. Hold the front of the shelf and gently lift up and slide out.

• If the door cannot fully open, slide out the shelf half way to the front and turn it over to remove.

• The shelf must be inserted correctly. Do not insert upside down.

• Glass containers may scratch the surface of glass shelves. Moving tray shelf (fridge/freezer)

• To remove the shelf, hold the bottom side of the shelf and gently lift up and pull out. NOTE Do not hold the front side of the shelf to pull out. The shelf does not loosen on the front side. Maintenance Untitled-74 52 7/18/2017 5:08:18 PMEnglish 53 Maintenance Door guard To remove a door guard, hold the front sides of the bin and gently lift up to remove. Drawers Gently lift up the front of the drawer and slide out. Untitled-74 53 7/18/2017 5:08:19 PMMaintenance English54 Maintenance Vegetable bin / Dry bins To remove the vegetable bin from the fridge or the dry bin from the freezer.

1. First, remove surrounding multipurpose

2. If your refrigerator is provided with

a cover (A) for the vegetable/dry bin, remove the cover. For this, slide out the cover while holding down the clips on either side of the cover.

3. Gently pull out the vegetable/dry bin.

Untitled-74 54 7/18/2017 5:08:19 PMEnglish 55 Maintenance Sealing guard (applicable models only) To remove the sealing guard Gently lift up the guard, and then pull it to the front while holding the bottom side. To reinsert the sealing guard

1. Put the guard on the front of the

housing. And then, insert the guard by lowering it.

2. Press both hooks on the guard to lock

the guard. When the guard is locked properly, you will hear a clicking sound. CAUTION

• Make sure the sealing guard is locked rmly. Otherwise, the guard may cause noise when you open or close the door. Untitled-74 55 7/18/2017 5:08:20 PMMaintenance English56 Maintenance Icemaker bucket To remove the icemaker bucket, see the Diagnosis section on page 49. Cleaning Interior and exterior WARNING

• Do not use benzene, thinner, or home/car detergent such as Clorox™ for cleaning purposes. They may damage the surface of the refrigerator and cause a re.

• Do not spray water onto the refrigerator. This may cause electric shock.

• Do not put ngers or other objects into the dispenser hole. Regularly use a dry cloth to remove all foreign substances such as dust or water from the power plug terminals and contact points.

1. Unplug the power cord.

2. Use a moistened, soft, lint-free cloth or paper towel to clean the refrigerator’s interior

3. When done, use a dry cloth or paper towel to dry well.

4. Plug in the power cord.

Untitled-74 56 7/18/2017 5:08:20 PMEnglish 57 Maintenance Replacement Water lter (applicable models only) WARNING

• Do not use third-party water lters. Use only Samsung-provided or -approved lters.

• Unapproved lters may leak and damage the refrigerator, causing electric shock. Samsung holds no responsibility for any damage that may occur from use of third- party water lters. The lter indicator ( ) turns red as a reminder that lets you know it is time to replace the water lter.

1. Turn the knob of the lter cartridge

counter clockwise by 90 degrees. The lter cartridge will be unlocked.

2. Pull out the cartridge.

3. Insert a new lter cartridge. Use only

Samsung-provided or -approved lters. Untitled-74 57 7/18/2017 5:08:20 PMMaintenance English58 Maintenance

feature panel for 3 seconds to reset the lter lifecycle. The lter indicator (

6. When replacing is complete, ush 4

liters of water to remove impurities from the water line. See the Flushing section for more information. NOTE

• A newly installed lter may cause the water dispenser to spurt water briey. This is because air has entered the waterline.

• This replacement process may involve the refrigerator to drip water onto the oor. If this happens, wipe up with dry cloths. Reverse osmosis water ltration system The water pressure of the water supply system to a reverse osmosis water ltration system must be between 35 psi and 120 psi (241 kPa and 827 kPa). The water pressure of the reverse osmosis water ltration system to the refrigerator’s cold water line must be at least 40 psi (276 kPa). If the water pressure is below the specied:

• Check to see whether the sediment lter in the reverse osmosis system is blocked. Replace the lter if necessary.

• Rell the water tank in the reverse osmosis system with water.

• If your refrigerator has a water lter, it may further reduce the water pressure when used in conjunction with a reverse osmosis system. Remove the water lter. For more information or servicing, contact a licensed plumbing professional. Ordering a new lter To purchase a new water lter, contact a local Samsung service centre. Lamps and anti-bacteria lter Neither lamps nor the anti-bacteria lter are user-serviceable. Do not attempt to replace them yourself. To replace them, contact a local Samsung service centre. Untitled-74 58 7/18/2017 5:08:20 PMEnglish 59 Troubleshooting If you encounter an abnormal situation with the refrigerator, rst check the table below and try the suggestions. General Symptom Action Does not operate or cool.

• Make sure the power cord is connected properly.

• Make sure the temperature control is set correctly. Try setting to a lower temperature.

• Make sure to keep the refrigerator away from direct sunlight or a heat source. Failing to do so may affect the cooling performance.

• Make sure the refrigerator has enough room from the rear and side walls or the cabinet. Failing to do so may affect the cooling performance.

• Too much food may block the ventilation of the refrigerator. To keep the refrigerator in normal operation, do not put too much food inside. Food in the fridge freezes.

• Check if the temperature control is set to the lowest temperature. If so, change to a higher or the optimal temperature.

• This happens if the ambient temperature is too low. Set the temperature higher.

• Check if food containing a high portion of water is put in the coldest area of the fridge or near the cooling vent. If this happens, move the food to other shelves in the fridge. Emits noises.

• Make sure the refrigerator is installed on a stable, at surface.

• Make sure the refrigerator has enough room from the rear and side walls or the cabinet.

• Make sure to keep the refrigerator from impurities or foreign objects inside or underneath.

• The refrigerator may produce a ticking sound from inside, which occurs when the various accessories contract or expand. This is not a system failure. Troubleshooting Untitled-74 59 7/18/2017 5:08:20 PMTroubleshooting English60 Troubleshooting Symptom Action The front corners and sides become warm and form condensation.

• To prevent condensation from forming, the refrigerator has heat-proof piping in the front corners. If the ambient temperature rises, this equipment may not work effectively. This is not a system failure.

• Make sure the door is closed properly. Condensation may form if you leave the door open for some time.

• Condensation may form on the exterior surface of the refrigerator if humid air comes into contact with the cool surface of the refrigerator. The ice maker does not make ice.

• You must wait for 12 hours until the refrigerator makes ice.

• Make sure the ice maker is not stopped while making ice.

• Make sure the water tank is lled with water.

• Check if the icemaker bucket contains ice clumps. In this case, empty the icemaker bucket and try again. The water dispenser is not functioning.

• Check if the water tank is frozen. If so, select a higher fridge temperature.

• Make sure the water tank is lled with water.

• Make sure the water tank is installed properly.

• Make sure the water lter is installed properly. Produces a bubbling sound.

• The refrigerator makes this sound during the cooling process, which is normal. A bad smell comes from inside the refrigerator.

• Check for any spoiled food. We recommend cleaning the refrigerator on a regular basis and remove any spoiled or suspect food items.

• Make sure strong smelling food is wrapped up airtight. Frost forms on the interior walls.

• Make sure no food blocks the vents of the refrigerator. It is also important to arrange food items evenly for ventilation.

• Make sure the door is closed properly. Condensation forms on the interior walls or around vegetables.

• This happens when food containing a high portion of water is stored uncovered, or the door has been left open for a while.

• Make sure food is covered or put in sealed containers. Untitled-74 60 7/18/2017 5:08:21 PMEnglish 61 Troubleshooting Symptom Action Ice maker does not supply Ice cubes. Check the following:

• Push the water dispenser lever to check the water supply.

• Push the ice dispenser lever to check the operation of the auger motor in the ice maker assembly.

• Check if there are any objects that obstruct the auger motor from running. If found, remove the objects and clear the motor area.

• If the ice maker has not been used for an extended time, the icemaker bucket may contain ice chunk that obstructs the auger motor from running properly. In this case, remove and empty the icemaker bucket, and try dispensing ice. Untitled-74 61 7/18/2017 5:08:21 PMMemo Untitled-74 62 7/18/2017 5:08:21 PMMemo Untitled-74 63 7/18/2017 5:08:21 PMContact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Country Contact Center Web Site UK 0330 SAMSUNG (7267864) www.samsung.com/uk/support IRELAND (EIRE) 0818 717100 www.samsung.com/ie/support GERMANY
