RF50K5960S8 - Fridge SAMSUNG - Free user manual and instructions

Features	Details
Type of refrigerator	Combined refrigerator
Total capacity	500 liters
Dimensions (HxWxD)	1780 x 912 x 734 mm
Weight	100 kg
Energy class	A+
Cooling system	Multi-Flow
Additional features	Water dispenser, ventilated freezer
Temperature control	Electronic
Noise level	39 dB
Maintenance	Automatic defrosting of the refrigerator
Warranty	2 years
Annual energy consumption	350 kWh
Safety	Door locking system
Color	Stainless steel

Frequently Asked Questions - RF50K5960S8 SAMSUNG

My SAMSUNG RF50K5960S8 refrigerator is not cooling properly. What should I do?

Check that the temperature is set correctly. Make sure the doors close properly and there is no obstruction to air circulation inside. If the problem persists, unplug it for 10 minutes before plugging it back in.

There is water accumulating inside my refrigerator. What should I do?

Check the defrost drain to ensure it is not blocked. Clean it if necessary. Also, make sure that food is not blocking the airflow.

The refrigerator is making strange noises. Is this normal?

It is normal to hear operating noises, such as the compressor motor or the sound of water circulating. However, if the noise is excessive or unusual, check that the refrigerator is level and that no objects are touching the walls.

How do I set the temperature on my SAMSUNG RF50K5960S8 refrigerator?

Press the temperature setting button on the control panel. Use the arrows to select the desired temperature. For a refrigerator, a temperature of 4°C is generally recommended.

My refrigerator emits an unpleasant odor. What can I do?

Check the food to ensure none of it is expired. Clean the inside of the refrigerator with a mixture of baking soda and water. Place an open box of baking soda inside to help neutralize odors.

How do I clean the water filter of my refrigerator?

Consult the user manual to locate the water filter. Replace it every six months or according to your model's recommendations. Follow the instructions for replacement and system flushing.

My refrigerator does not dispense water. What should I do?

Check that the refrigerator is properly plugged in and that the water valve is open. Make sure the water filter is not clogged and has been installed correctly.

How do I activate vacation mode on my refrigerator?

Access the control panel and look for the "Vacation Mode" option. Select it to activate this mode, which will save energy while keeping food in the freezer.

USER MANUAL RF50K5960S8 SAMSUNG

• For the most efficient use of energy, please keep the all inner fittings such as baskets, drawers, shelves and ice cube tray on the position supplied by manufacturer.
• This refrigerating appliance is not intended to be used as a built-in appliance.

Install Instruction

For refrigerating appliances with climate class

Depending on the climate class, This refrigerating appliance is intended to be used at ambient temperatures range as specified following table.

The climate class can be found on the rating plate. The product may not operate properly at temperatures outside of the specific range.

You can find climate class on label inside of your refrigerator

Effective temperature range

The refrigerator is designed to operate normally in the temperature range specified by its class rating.

Class Symbol		Ambient Temperature range (°C)
		IEC 62552 (ISO 15502) ISO 8561
Extended Temperate SN	+10 to +32 +10	to +32
Temperate N +16 to	+32 +16 to +32
Subtropical ST +16 to	+38 +18 to +38
Tropical T +16 to +43 +18 to +43

NOTE

The cooling performance and power consumption of the refrigerator may be affected by the ambient temperature, the door-opening frequency, and the location of the refrigerator. We recommend adjusting the temperature settings as appropriate.

Temperature Instruction

Recommended Temperature

The optimal temperature setting for food storage:

Fridge: 3^
Freezer: -19 °C
Freezer of Cool Select+ : -19 °C
- Chill of Cool Select+: -1 °C
Cool of Cool Select+: 3 °C
- Soft Freezing of Cool Select+ : -5 ℃

The optimal temperature setting of each compartment depends on the ambient temperature. Above optimal temperature is based on the ambient temperature of 25^ .

Power Cool

Power Cool speeds up the cooling process at maximum fan speed. The fridge keeps running at full speed for two and a half hours and then returns to the previous temperature.

Power Freeze

Power Freeze speeds up the freezing process at maximum fan speed. The freezer keeps running at full speed for 50 hours and then returns to the previous temperature. To freeze large amounts of food, activate Power Freeze for at least 20 hours before putting food in the freezer.

When you use this function the energy consumption of the refrigerator will increase. Remember to turn it off when you don't need it and return the freezer to your original temperature setting.

How to store for best preservation (applicable models only)

Cover foods to retain moisture and prevent them from picking up odors from other foods. A large pot of food like soup or stew should be divided into small portions and put in shallow containers before being refrigerated. A large cut of meat or whole poultry should be divided into smaller pieces or placed in shallow containers before refrigerating.

Placement of Foods

Shelves Shelves should be adjustable to accommodate a variety of packages.
Specialized compartment (applicable models only)	Sealed risper drawers provide an optimal storage environment for fruits and vegetables. Vegetables require higher humidity conditions while fruits require lower humidity conditions.Crispers are equipped with controls devices to control the humidity level. (‘Depending on model and options’) An adjustable temperature meat drawer maximizes the storage time of meats and cheeses.
Stored on the door	Don’t store perishable foods in the door. Eggs should be stored in the carton on a shelf. The temperature of the storage bins in the door fluctuate more than the temperature in the cabinet. Keep the door closed as much as possible.
Freezer Compartment	You can store frozen food, make ice cubes and freeze fresh food in the freezer compartment.

Freeze fresh, undamaged food only. Keep food which is to be frozen away from food which is already frozen. To prevent food from losing its flavour or drying out, place in airtight containers.

Refrigerator & Freezer Storage Chart

The freshness longevity depends on temperature and exposure to moisture. Since product dates aren't a guide for safe use of a product, consult this chart and follow these tips.

Milk products

Product Refrigerator Freezer
Milk 1 week 1 month
Butter 2 weeks 12 months
Ice cream - 2-3 weeks
Natural cheese 1 month 4-6 months
Cream cheese 2 weeks Not recommended
Yogurt 1 month -

Meat

Product Refrigerator Freezer
Fresh roasts, steaks, chops	3-4 days	2-3 months
Fresh ground meat, stew meat	1-2 days	3-4 months
Bacon	7 days	1 month
Sausage, Raw from pork, beef, turkey	1-2 days	1-2 months

Poultry / Eggs

Product Refrigerator Freezer
Fresh poultry	2 days	6-8 months
Poultry salad	1 day	-
Eggs, Fresh in shell	2-4 weeks	Not recommended

Fish / Seafood

Product Refrigerator Freezer
Fresh fish	1-2 days	3-6 months
Cooked fish	3-4 days	1 month
Fish salad	1 day	Not recommended
Dried or pickled fish	3-4 weeks -

Fruits

Product Refrigerator Freezer
Apples 1 month -
Peaches 2-3 weeks -
Pineapple 1 week -
Other fresh fruit 3-5 days 9-12 months

Vegetables

Product Refrigerator Freezer
Asparagus 2-3 days -
Broccoli, Brussels sprouts, green peas, mushrooms	3-5 days -
Cabbage, cauliflower, celery, cucumbers, lettuce	1 week -
Carrots, beets, radishes 2 weeks -

Information for model and ordering spare parts

Model information

To access the EPREL registration of the model :

1. Go to https://eprel.ec.europa.eu.
2. Get the model identifier from the energy label of the product and type it in the search box.
3. Energy Labelling information of the model is shown.

Part information

The minimum period during which spare parts, necessary for the repair of the appliance, are available
- 7 Years thermostats, temperature sensors, printed circuit boards and light sources, door handles, door hinges, trays, baskets (boxes or drawers)
10 Years door gaskets
- The minimum duration of the guarantee of the refrigerating appliance offered by the manufacturer 24 Months.
- Relevant information for ordering spare parts, directly or through other channels provided by the manufacturer, importer or authorized representative
- You can find professional repair information on http://samsung.com/support.
You can find user servicing manual on http://samsung.com/support.
