KM 3869 - Coffee grinder SEVERIN - Free user manual and instructions

USER MANUAL KM 3869 SEVERIN

Before using the appliance, the user should read the following instructions carefully.

Connection to the mains supply

Make sure that the supply voltage corresponds with the voltage marked on the rating label. This product complies with all binding CE labelling directives.

Familiarisation

1. Bean container lid
2. Bean container
3. Timer
4. Collection container lid
5. Power cord
6. Collection container
7. Upper grinding assembly
8. Ground coffee outlet
9. Rating label
10. On/Off switch

11. Housing

12. Adjustment for coarse/fine grind

Important safety instructions

- Before the appliance is used, the main body including the power cord as well as any attachment fitted should be checked thoroughly for any defects. Should the appliance, for instance, have been dropped onto a hard surface, it must no longer be used: even invisible damage may have adverse effects on the operational safety of the appliance.

- Do not allow the appliance to touch hot surfaces (e.g. oven-plates) or to come into contact with any open heat sources.

● Always remove the plug from the wall socket

• after use,
• in case of any malfunction, and also
• before opening the bean or collection container, and also before removing either from the housing,

- before cleaning the appliance.

• Do not let the power cord hang free.
• When removing the plug from the wall socket, never pull on the power cord. Do not let the power cord hang free.
• Do not leave the appliance unattended while in use.
  ● This appliance is not intended for use by any person (including children) with reduced physical, sensory or mental capabilities, or lacking experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety.
  ● Children should be supervised to ensure that they do not play with the appliance.
• Caution: Keep any packaging materials well away from children: there is a risk of suffocation.
• No responsibility will be accepted if damage results from improper use, or if these instructions are not complied with.
  ● This appliance is intended for domestic use only and not for commercial applications.
• In order to comply with safety regulations and to avoid hazards, repairs of electrical appliances must be carried out by qualified personnel, including the replacement of the power cord. If repairs are needed, please send the appliance to one of our customer service departments. The address can be found in the appendix to this manual.

Short-time operation

The appliance has been designed for short-term operation only, i.e. it should not be operated continuously for more than 60 seconds. Switch off the appliance afterwards and allow the motor to cool down (10 Min.) before switching it on again.

Operation

- Remove the bean container lid and fill the container with the desired quantity of coffee beans (max. 250 g) before

replacing the lid.

- The quality of the ground coffee can be adjusted with several settings from fine to coarse by means of the adjustment control.

Adjustable grind settings:

• 1-3 for fine coffee
• 4-6 for automatic coffee makers
• 7-9 for brewing when no machine is used
• Make sure that the collection container lid is properly fitted before attaching the container itself to the main unit.
• Insert the plug into a suitable wall socket.
• Press the On/Off switch.
• Use the timer to select the desired grinding time. The scale allows for any amount between 1 and 12 cups. However, the grinding time largely depends on the fineness selected and on your personal taste, and is therefore only an approximation. With a medium setting, around 6 g per cup will be ground.
• The grinding process begins and will stop automatically once the selected amount of ground coffee has been produced.
• The process can be stopped at any time by pressing the On/Off switch.
• After grinding, press the On/Off switch and remove the plug from the wall socket before the collection container is removed and opened.
  ● Note: to ensure optimum coffee flavour, only the required quantity of beans should be ground immediately prior to brewing. Should another grinding cycle become necessary, however, the maximum operating time of 60 seconds must not be exceeded.

General care and cleaning

• Before cleaning the appliance, always remove the plug from the wall socket and wait until the motor has come to a complete standstill.
  ● To avoid the risk of electric shock, do not clean the housing or the power cord with

water, and do not immerse them in water. The housing may be wiped with a slightly damp, lint-free cloth. Wipe thoroughly dry afterwards.

• Do not use abrasives, harsh cleaning solutions or hard brushes for cleaning.

• The grinding mechanism may be opened up for cleaning, and also in case of a malfunction.

• Turn clockwise to open the grinding mechanism

• Turn anti-clockwise to close the grinding mechanism.

A small, soft brush is suitable for cleaning the grinding mechanism and the outlet opening.

• Caution: the grinding assembly has sharp elements and care should therefore be taken to avoid injury.
• The collection container and the lids may be cleaned using hot water and a mild detergent. Wipe thoroughly dry afterwards. These parts are not dish-washer safe.

Disposal

Do not dispose of old or defective appliances in domestic garbage; this should only be done through public collection points.

Guarantee

This product is guaranteed against defects in materials and workmanship for a period of two years from the date of purchase. Under this guarantee the manufacturer undertakes to repair or replace any parts found to be defective, providing the product is returned to one of our authorised service centres. This guarantee is only valid if the appliance has been used in accordance with the instructions, and provided that it has not been modified, repaired or interfered with by any unauthorised person, or damaged through misuse.

This guarantee naturally does not cover wear and tear, nor breakables such as glass and ceramic items, bulbs etc. This guarantee

does not affect your statutory rights, nor any legal rights you may have as a consumer under applicable national legislation governing the purchase of goods. If the product fails to operate and needs to be returned, pack it carefully, enclosing your name and address and the reason for return. If within the guarantee period, please also provide the guarantee card and proof of purchase.
