USER MANUAL RF85A92FASL SAMSUNG

Refrigerator User manual Free Standing Appliance Untitled-23 1 2022-05-17 6:16:43English2 Contents Contents Safety information 3 What you need to know about the safety instructions 3 Important safety symbols and precautions: 5 Important safety precautions 6 Severe warning signs for transportation and site 9 Critical installation warnings 10 Installation cautions 13 Critical usage warnings 13 Usage cautions 18 Cleaning cautions 20 Critical disposal warnings 22 Additional tips for proper usage 23 Instructions about the WEEE 24 Installation 25 Refrigerator at a glance 26 Step-by-step installation 30 Operations 49 Control panel 49 SmartThings 53 Special features 56 Maintenance 70 Handling and care 70 Cleaning 78 Replacement 79 Troubleshooting 82 General 82 Do you hear abnormal sounds from the refrigerator? 86 SmartThings 88 Open Source Announcement 89 Untitled-23 2 2022-05-17 6:16:43English 3 Safety information Before using your new Samsung Refrigerator, please read this manual thoroughly to ensure that you know how to operate the features and functions that your new appliance offers safely and efciently. What you need to know about the safety instructions

• Warnings and Important Safety Instructions in this manual do not cover all possible conditions and situations that may occur. It is your responsibility to use common sense, caution, and care when installing, maintaining, and operating your appliance.

• Because these following operating instructions cover various models, the characteristics of your refrigerator may differ slightly from those described in this manual and not all warning signs may be applicable. If you have any questions or concerns, contact your nearest service center or nd help and information online at www. samsung.com.

• R-600a or R-134a is used as a refrigerant. Check the compressor label on the rear of the appliance or the rating label inside the fridge to see which refrigerant is used for your appliance. When this product contains ammable gas (Refrigerant R-600a), contact your local authority in regard to safe disposal of this product.

• In order to avoid the creation of a ammable gas-air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance may be sited depends on the amount of refrigerant used.

• Never start up an appliance showing any signs of damage. If in doubt, consult your dealer. The room must be 1 m

in size for every 8 g of R-600a refrigerant inside the appliance. The amount of refrigerant in your particular appliance is shown on the identication plate inside the appliance. Safety information Untitled-23 3 2022-05-17 6:16:43Safety information English4 Safety information

• Refrigerant squirting out of the pipes could ignite or cause an eye injury. When refrigerant leaks from the pipe, avoid any naked ames and move anything ammable away from the product and ventilate the room immediately. - Failing to do so may result in re or explosion.

• To avoid contamination of food, please respect the following instructions: - Opening the door for long periods can cause a signicant increase of the temperature in the compartments of the appliance. - Clean regularly surfaces that can come in contact with food and accessible drainage systems. - Clean water tanks if they have not been used for 48 h; ush the water system connected to a water supply if water has not been drawn for 5 days. - Store raw meat and sh in suitable containers in the refrigerator, so that it is not in contact with or drip onto other food. - Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or making icecream and making ice cubes. - One-, two- and three-star compartments are not suitable for the freezing of fresh food. - If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry, and leave the door open to prevent mould developing within the appliance. Untitled-23 4 2022-05-17 6:16:43English 5 Safety information Important safety symbols and precautions: Please follow all safety instructions in this manual. This manual uses the following safety symbols. WARNING Hazards or unsafe practices that may result in severe personal injury, property damage, and/or death. CAUTION Hazards or unsafe practices that may result in severe personal injury and/or property damage. NOTE Useful information that helps users understand or benet from the refrigerator. These warning signs are here to prevent injury to you and others. Please follow them carefully. After reading this section, keep it in a safe place for future reference. Untitled-23 5 2022-05-17 6:16:43Safety information English6 Safety information Important safety precautions Warning; Risk of re / ammable materials WARNING

• When positioning the appliance, ensure the supply cord is not trapped or damaged.

• Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.

• Fill with potable water only.

• Connect to potable water supply only.

• Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.

• Do not use mechanical devices or any other means to accelerate the defrosting process, other than those recommended by the manufacturer.

• Do not damage the refrigerant circuit.

• Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or those who lack experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety. Untitled-23 6 2022-05-17 6:16:43English 7 Safety information

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances.

• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied persons in order to avoid a hazard.

• The socket must be easily accessible so that the appliance can be quickly disconnected from the supply in an emergency. - It must be outside the area of the rear of the appliance.

• Do not store explosive substances such as aerosol cans with a ammable propellant in this appliance.

• If the product is equipped with LED lamps, do not disassemble the Lamp Covers and LED lamps yourself. - Contact a Samsung service center. - Use only the LED Lamps provided by the manufacturer or its service agents.

• New hose-sets supplied with the appliance are to be used and old hose-sets should not be reused.

• Have the refrigerator’s water supply connected only to a potable water supply. To operate the ice maker properly, water pressure of 206-861 kPa (30-125 psi) is required.

• For the most efcient use of energy, please keep the all inner ttings such as baskets, drawers, shelves on the position supplied by manufacturer. Untitled-23 7 2022-05-17 6:16:43Safety information English8 Safety information

• To get the best energy efciency of this product, please leave all shelves, drawers and baskets on their original position. How to minimize the energy consumption

• Install the appliance in a cool, dry room with adequate ventilation.

• Ensure that it is not exposed to direct sunlight and never put it near a direct source of heat (radiator, for example). - Not to block any vents or grilles is recommended for energy efciency. - Allow warm food to cool down before placing it in the appliance. - Put frozen food in the refrigerator to thaw. You can then use the low temperatures of the frozen products to cool food in the refrigerator. - Do not keep the door of the appliance open for too long when putting food in or taking food out. - The shorter time for which the door is open, the less ice will form in the freezer. - Clean the rear of the refrigerator regularly. Dust increases energy consumption. - Do not set temperature colder than necessary. - Ensure sufcient air exhaust at the refrigerator base and at the back wall of the refrigerator. Do not cover air vent openings. - Allow clearance to the right, left, back and top when installing. This will help reduce power consumption and keep your energy bills lower. Untitled-23 8 2022-05-17 6:16:43English 9 Safety information This appliance is intended to be used in household and similar applications such as - staff kitchen areas in shops, ofces and other working environments; - farm houses and by clients in hotels, motels and other residential type environments; - bed and breakfast type environments; - catering and similar non-retail applications. Severe warning signs for transportation and site WARNING

• When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged. - Refrigerant leaking from the pipe work could ignite or cause an eye injury. If a leak is detected, avoid any naked ames or potential sources of ignition and air the room in which the appliance is standing for several minutes. - This appliance contains a small amount of isobutane refrigerant (R-600a), a natural gas with high environmental compatibility that is, however, also combustible. When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged.

• When transporting and installing the refrigerator, do not touch the water hose on the back side of the refrigerator. - This may damage the refrigerator and as a result the water dispenser can not be used. Untitled-23 9 2022-05-17 6:16:43Safety information English10 Safety information Critical installation warnings WARNING

• Do not install the refrigerator in a damp location or place where it may come in contact with water. - Deteriorated insulation on electrical parts may cause an electric shock or re.

• Do not place this refrigerator in direct sunlight or expose it to the heat from stoves, room heaters, or other appliances.

• Do not plug several appliances into the same multiple power strip. The refrigerator should always be plugged into its own individual electrical outlet which has a voltage rating that matches the voltage listed on the refrigerator’s rating plate. - This provides the best performance and also prevents overloading of house wiring circuits, which could cause a re hazard from overheated wires.

• If the wall socket is loose, do not insert the power plug. - There is a risk of electric shock of re.

• Do not use a power cord that has cracks or abrasion damage along its length or at either end.

• Do not bend the power cord excessively or place heavy objects on it.

• Do not pull or excessively bend the power cord.

• Do not twist or tie the power cord.

• Do not hook the power cord over a metal object, place a heavy object on the power cord, insert the power cord between objects, or push the power cord into the space behind the appliance.

• When moving the refrigerator, be careful not to roll over or damage the power cord. - This may result in an electric shock or re. Untitled-23 10 2022-05-17 6:16:43English 11 Safety information

• Never unplug your refrigerator by pulling on the power cord. Always grip the plug rmly and pull straight out from the outlet. - Damage to the cord may cause a short-circuit, re, and/or electric shock.

• Do not use aerosols near the refrigerator. - Using aerosols near the refrigerator may cause an explosion or re.

• Do not install this appliance near a heater or inammable material.

• Do not install this appliance in a location where gas may leak. - This may result in an electric shock or re.

• This refrigerator must be properly located and installed in accordance with the instructions in this manual before you use it.

• Connect the power plug in the proper position with the cord hanging down. - If you connect the power plug upside down, the wire can get cut off and cause a re or electric shock.

• Make sure that the power plug is not crushed or damaged by the back of the refrigerator.

• Keep the packing materials out of reach of children. - There is a risk of death from suffocation if a child puts the packing materials on his or her head.

• Do not install this appliance in a humid, oily or dusty location, in a location exposed to direct sunlight and water (rain drops). - Deteriorated insulation of electrical parts may cause an electric shock or re.

• If any dust or water is in the refrigerator, pull out power plug and contact your Samsung Electronics service center. - Otherwise there is a risk of re. Untitled-23 11 2022-05-17 6:16:43Safety information English12 Safety information

• Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. - This may result in an electric shock, re, problems with the product, or injury.

• You need to remove all the protective plastic lm before you initially plug the product in.

• Children should be supervised to ensure that they do not play with the snap rings used for door adjustment or the water tube clips. - There is risk of death by suffocation if a child swallows a snap ring or water tube clip. Keep the snap rings and water tube clips out of children’s reach.

• The refrigerator must be safely grounded. - Always make sure that you have grounded the refrigerator before attempting to investigate or repair any part of the appliance. Power leakages can cause severe electric shock.

• Never use gas pipes, telephone lines, or other potential lightning attractors as an electrical ground. - You must ground the refrigerator to prevent any power leakages or electric shocks caused by current leakage from the refrigerator. - This may result in an electric shock, re, explosion, or problems with the product.

• Plug the power plug into the wall socket rmly. Do not use a damaged power plug, damaged power cord, or loose wall socket. - This may result in an electric shock or re.

• The fuse on the refrigerator must be changed by a qualied technician or service company. - Failing to do so may result in an electric shock or personal injury. Untitled-23 12 2022-05-17 6:16:43English 13 Safety information Installation cautions CAUTION

• Allow sufcient space around the refrigerator and install it on a at surface. - If your refrigerator is not level, cooling efciency and durability can be declined.

• Allow the appliance to stand for 2-3 hours before loading foods after installation and turning on.

• We strongly recommend you have a qualied technician or service company install the refrigerator. - Failing to do so may result in an electric shock, re, explosion, problems with the product, or injury. Critical usage warnings WARNING

• Do not insert the power plug into a wall socket with wet hands. - This may result in an electric shock.

• Do not store articles on the top of the appliance. - When you open or close the door, the articles may fall and cause personal injury and/or material damage.

• Do not insert hands, feet or metal objects (such as chopsticks, etc.) into the bottom or the back of the refrigerator. - This may result in an electric shock or injury. - Any sharp edges may cause a personal injury.

• Do not touch the inside walls of the freezer or products stored in the freezer with wet hands. - This may cause frostbite.

• Do not put a container lled with water on the refrigerator. - If spilled, there is a risk of re or electric shock. Untitled-23 13 2022-05-17 6:16:43Safety information English14 Safety information

• Do not keep volatile or ammable objects or substances (benzene, thinner, propane gas, alcohol, ether, LP gas, and other such products) in the refrigerator. - This refrigerator is for storing food only. - This may result in re or explosion.

• Children should be supervised to ensure that they do not play with the appliance. - Keep ngers out of “pinch point” areas. Clearances between the doors and cabinet are necessarily small. Be careful when you open the doors if children are in the area.

• Do not put your ngers or children's ngers between the doors. - Keep ngers out of the left and right door gaps. Be careful when you open the doors if your ngers are in between the doors.

• Do not let children hang on the door or door bins. A serious injury may occur.

• Do not let children go inside the refrigerator. They could become trapped.

• Do not insert your hands into the bottom area under the appliance. - Any sharp edges may cause personal injury.

• Do not store pharmaceutical products, scientic materials, or temperature sensitive products in the refrigerator. - Products that require strict temperature controls must not be stored in the refrigerator.

• If you smell pharmaceutical or smoke, pull out power plug immediately and contact your Samsung Electronics service center.

• If any dust or water is in Refrigerator, pull out power plug and contact your Samsung Electronics service center. - Otherwise there is a risk of re. Untitled-23 14 2022-05-17 6:16:43English 15 Safety information

• Do not let children step on a drawer. - The drawer may break and cause them to slip.

• Do not leave the doors of the refrigerator open while the refrigerator is unattended and do not let children enter inside the refrigerator.

• Do not allow babies or children go inside the drawer. - It can cause death from suffocation by entrapment or personal injury.

• Do not overll the refrigerator with food. - When you open the door, an item may fall out and cause personal injury or material damage.

• Do not spray volatile material such as insecticide onto the surface of the appliance. - As well as being harmful to humans, it may also result in an electric shock, re, or problems with the product.

• Never put ngers or other objects into the water dispenser hole, ice chute and ice maker bucket. - It may cause a personal injury or material damage.

• Do not use or place any substances sensitive to temperature such as ammable sprays, ammable objects, dry ice, medicine, or chemicals near or inside of the refrigerator.

• Do not use a hair dryer to dry the inside of the refrigerator. Do not place a lighted candle in the refrigerator for removing bad odours. - This may result in an electric shock or re.

• Fill the water tank, ice tray and water cubes only with potable water (mineral water or puried water). - Do not ll the tank with tea, juice or sports drink, this may damage the refrigerator. Untitled-23 15 2022-05-17 6:16:43Safety information English16 Safety information

• Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. This may result in an electric shock, re, problems with the product, or injury. Do not put a container lled with water on the appliance. - If spilled, there is a risk of re or electric shock.

• Never stare directly at the UV LED lamp for long periods of time. - This may result in eye strain due to the ultraviolet rays.

• Do not put shelf in upside down. Shelf stopper could not work. - It may cause a personal injury because of glass shelf drop.

• If a gas leak is detected, avoid any naked ames or potential sources of ignition, and air the room in which the appliance is standing for several minutes. - Do not touch the appliance or power cord. - Do not use a ventilating fan. - A spark may result in explosion or re.

• Bottles should be stored tightly together so that they do not fall out.

• This product is intended only for the storage of food in a domestic environment.

• Never put ngers or other objects into the water dispenser hole, ice chute and ice maker bucket. - It may cause a personal injury or material damage.

• Do not attempt to repair, disassemble, or modify the refrigerator yourself.

• Do not use any fuse (such as cooper, steel wire, etc.) other than a standard fuse. Untitled-23 16 2022-05-17 6:16:43English 17 Safety information

• If your refrigerator needs to be repaired or reinstalled, contact your nearest service center. - Failing to do so may result in an electric shock, re, problems with the product, or injury.

• If the refrigerator emits a burning smell or smoke, unplug the refrigerator immediately and contact your Samsung Electronics service center. - Failing to do so may result in an electric or re hazards.

• Pull the power plug out of the socket before changing the interior lamps of the refrigerator. - Otherwise, there is a risk of electric shock.

• If you experience difculty changing a non-LED light, contact a Samsung service center.

• Plug the power plug into the wall socket rmly.

• Do not use a damaged power plug, damaged power cord or loose wall socket. - This may result in an electric shock or re. Untitled-23 17 2022-05-17 6:16:43Safety information English18 Safety information Usage cautions CAUTION

• Do not refreeze thawed food. - Frozen and thawed food will develop harmful bacteria faster than fresh. - The second thaw will break down even more cells, leaching out moisture and changing the integrity of the product.

• Do not thaw meat at room temperature. - Safety will depend on whether the raw product was handled properly.

• Do not place glass bottles or carbonated beverages into the freezer. - The container may freeze and break, and this may result in injury.

• Use only the ice maker provided with the refrigerator.

• If you will be away from home for a long period of time (on vacation, for example) and won’t be using the water or ice dispensers, close the water valve. - Otherwise, water leakage may occur.

• If you won’t be using the refrigerator for a very long period of time, (3 weeks or more) empty the refrigerator including the ice bucket, unplug it, close the water valve, wipe excess moisture from the inside walls, and leave the doors open to prevent odors and mold.

• To get the best performance from the product: - Do not place food too close to the vents at the rear of the refrigerator as this can obstruct free air circulation in the refrigerator compartment. - Wrap food up properly or place it in airtight containers before putting it into the refrigerator. Untitled-23 18 2022-05-17 6:16:43English 19 Safety information - Please observe maximum storage times and expiration dates of frozen goods. - There is no need to disconnect the refrigerator from the power supply if you will be away for less than three weeks. However, if you will be away for more than three weeks, remove all the food and ice in the ice bucket, unplug the refrigerator, close the water valve, wipe excess moisture from the inside walls, and leave the doors open to prevent odors and mold.

• Service Warranty and Modication. - Any changes or modications performed by a 3rd party on this nished appliance are not covered under Samsung warranty service, nor is Samsung responsible for safety issues that result from 3rd party modications.

• Do not block the air vents inside the refrigerator. - If the air vents are blocked, especially with a plastic bag, the refrigerator can be over cooled. If a cooling period lasts too long, the water lter may break and cause water leakage.

• Use only the ice-maker provided with the refrigerator.

• Wipe excess moisture from the inside and leave the doors open. - Otherwise, odor and mold may develop.

• If the refrigerator is disconnected from the power supply, you should wait for at least ve minutes before plugging it back in.

• When the refrigerator got wet by water, pull out the power plug and contact your Samsung Electronics service center.

• Do not strike or apply excessive force to any glass surface. - Broken glass may result in a personal injury and/or property damage. Untitled-23 19 2022-05-17 6:16:43Safety information English20 Safety information

• Fill the water tank and ice cube trays with potable water only (tap water, mineral water, or puried water). - Do not ll the tank with tea or a sports drink. This may damage the refrigerator.

• Be careful that your ngers are not caught in.

• If the refrigerator is ooded, make sure to contact your nearest service center. - There is a risk of electric shock or re.

• Do not keep vegetable oil in your refrigerator’s door bins. The oil can solidify, making it foul-tasting and difcult to use. In addition, the open container can leak and the leaked oil can cause the door bin to crack. After opening an oil container, it is best to keep the container in a cool and shaded place such as a cupboard or pantry. - Examples of vegetable oil: olive oil, corn oil, grape-seed oil, etc. Cleaning cautions CAUTION

• Do not spray water directly on the inside or outside the refrigerator. - There is a risk of re or electric shock.

• Do not use a hair dryer to dry the inside of the refrigerator.

• Do not place a lighted candle in the refrigerator to remove bad odors. - This may result in an electric shock or re.

• Do not spray cleaning products directly on the display. - Printed letters on the display may come off.

• If any foreign substance such as water has entered the appliance, unplug the power plug and contact your nearest service center. - Failing to do so may result in an electric shock or re. Untitled-23 20 2022-05-17 6:16:44English 21 Safety information

• Use a clean, dry cloth to remove any foreign matter or dust from the power plug blades. Do not use a wet or damp cloth when cleaning the plug. - Otherwise, there is a risk of re or electric shock.

• Do not clean the appliance by spraying water directly onto it.

• Do not use benzene, thinner, or Clorox, Chloride for cleaning. - They may damage the surface of the appliance and may cause a re.

• Never put ngers or other objects into the dispenser hole. - It may cause a personal injury or material damage.

• Before cleaning or performing maintenance, unplug the appliance from the wall socket. - Failing to do so may result in an electric shock or re.

• Use a clean sponge or soft cloth and a mild detergent in warm water to clean the refrigerator.

• Do not use abrasive or harsh cleansers such as window sprays, scouring cleansers, ammable uids, muriatic acid, cleaning waxes, concentrated detergents, bleaches, or cleansers containing petroleum products on exterior surfaces (doors and cabinet), plastic parts, door and interior liners, and gaskets. - These can scratch or damage the material.

• Do not clean glass shelves or covers with warm water when they are cold. Glass shelves and covers may break if exposed to sudden temperature changes or impacts such as bumping or dropping. Untitled-23 21 2022-05-17 6:16:44Safety information English22 Safety information Critical disposal warnings WARNING

• Please dispose of the packaging material from this product in an environmentally friendly manner.

• Ensure that none of the pipes on the back of the refrigerator are damaged prior to disposal.

• R-600a or R-134a is used as a refrigerant. Check the compressor label on the rear of the appliance or the rating label inside the fridge to see which refrigerant is used for your refrigerator. If this refrigerator contains ammable gas (Refrigerant R-600a), contact your local authority in regard to safe disposal of this product.

• When disposing of this refrigerator, remove the door/door seals and door latch so that small children or animals cannot become trapped inside. Children should be supervised to ensure that they do not play with the appliance. If trapped inside, a child may get hurt or suffocate to death. - If trapped inside, the child may become injury and suffocate to death.

• Cyclopentane is used in the insulation. The gases in the insulation material require a special disposal procedure. Please contact your local authorities in regard to the environmentally safe disposal of this product.

• Keep all packaging materials well out of the reach of children, as packaging materials can be dangerous to children. - If a child places a bag over his or her head, the child could suffocate. Untitled-23 22 2022-05-17 6:16:44English 23 Safety information Additional tips for proper usage

• In the event of a power failure, call the local ofce of your electric company and ask how long the failure is going to last. - Most power failures that are corrected in an hour or two will not affect your refrigerator temperatures. However, you should minimize the number of door openings while the power is off. - Should the power failure last more than 24 hours, remove and discard all frozen food.

• The refrigerator might not operate consistently (frozen contents can thaw or temperatures can become too warm in the frozen food compartment) if sited for an extended period of time in a location where ambient air temperatures are constantly below the temperatures for which the appliance is designed.

• In case of particular foods, keeping it under refrigeration can have a bad effect on preservation due to its properties.

• Your appliance is frost free, which means there is no need to manually defrost your appliance. This will be carried out automatically.

• Temperature rise during defrosting complies with ISO requirements. If you want to prevent an undue rise in the temperature of frozen food while the appliance defrosts, wrap the frozen food in several layers of newspaper.

• Do not re-freeze frozen foods that have thawed completely.

• The temperature of two star section (sections) or compartment (compartments) which have two star symbol ( ) is slightly higher than other freezer compartment (compartments). The two star section (sections) or compartment (compartments) is (are) based on the instruction and/or the condition as delivered. Untitled-23 23 2022-05-17 6:16:44Safety information English24 Safety information Instructions about the WEEE Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or their local government ofce, for details of where and how they can take these items for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For information on Samsung’s environmental commitments and product regulatory obligations, e.g. REACH, WEEE or Batteries, visit our sustainability page available via www.samsung.com (For products sold in European countries and in the UK only) Untitled-23 24 2022-05-17 6:16:44English 25 Installation Follow these instructions carefully to ensure a proper installation of this refrigerator and to prevent accidents before using it. WARNING

• Use the refrigerator only for its intended purpose as described in this manual.

• Any servicing must be performed by a qualied technician.

• Dispose of the product packaging material in compliance with the local regulations.

• To prevent electric shock, unplug the power plug before servicing or replacing parts. Installation Untitled-23 25 2022-05-17 6:16:44Installation English26 Installation Refrigerator at a glance The actual refrigerator and provided component parts of your refrigerator may differ from the illustrations in this manual, depending on the model and the country. Type A

• Applicable models only ** Dispenser models only NOTE

• For energy efciency, keep all shelves, drawers, and baskets in their original positions.

• When closing the door, make sure the vertical hinged section is in the correct position to avoid scratching the other door.

• If the vertical hinged section is reversed, put it back into the correct position, and then close the door.

• Moisture may form at times on the vertical hinged section.

• If you close a door forcefully, the other door may open.

• If the internal or external LED lamp is out of order, contact a local Samsung service center. Untitled-23 28 2022-05-17 6:16:44English 29 Installation Door bins Your refrigerator ships with door bins of different types and sizes. If the door bins for your refrigerator were packaged separately, use the gure below to help you position the bins properly. NOTE The actual refrigerator and provided component parts of your refrigerator may differ from the illustrations in this manual, depending on the model and the country. Untitled-23 29 2022-05-17 6:16:44Installation English30 Installation Step-by-step installation STEP 1 Select a site The site must:

• Have a solid level surface without carpeting or ooring that may obstruct ventilation

• Be out of direct sunlight

• Have adequate room for opening and closing the door

• Be away from any heat source

• Provide room for maintenance and servicing

• Have a temperature range between 10 °C and 43 °C Effective temperature range The refrigerator is designed to operate normally in the temperature range specied by its class rating. Class Symbol Ambient Temperature range (°C)

IEC 62552 (ISO 15502) ISO 8561

Extended Temperate SN +10 to +32 +10 to +32 Temperate N +16 to +32 +16 to +32 Subtropical ST +16 to +38 +18 to +38 Tropical T +16 to +43 +18 to +43 NOTE The cooling performance and power consumption of the refrigerator may be affected by the ambient temperature, the door-opening frequency, and the location of the refrigerator. We recommend adjusting the temperature settings as appropriate. Untitled-23 30 2022-05-17 6:16:44English 31 Installation Clearance See the following gures and tables for installation space requirements.

Model RF65A* RF71A* RF60A* (BESPOKE) 01 more than 50 mm recommended 02 125° 125° 105° 03 1472 mm 1472 mm 1126 mm 04 282 mm 282 mm 109 mm 05 610 mm 748 mm 610 mm 06 47 mm 47 mm 7 mm 07 1093 mm 1231 mm 1112 mm Model RF85A* RF85A* (BESPOKE) 01 more than 50 mm recommended 02 125° 125° 03 1472 mm 1498 mm 04 282 mm 295 mm 05 785 mm 785 mm 06 47 mm 55 mm 07 1268 mm 1268 mm Untitled-23 31 2022-05-17 6:16:45Installation English32 Installation NOTE The measurements in the tables may differ slightly from the actual measurements, depending on the measuring and rounding method. STEP 2 Flooring If the refrigerator cannot pass through the entrance due to its size, see Door removal for entrance. NOTE To prevent oor damage, make sure the front leveling legs are in the upright position.

• The surface you install the refrigerator on must support a fully loaded refrigerator.

• To protect the oor, put a large piece of cardboard along the path to the refrigerator's nal installation location.

• Once the refrigerator is in its nal position, do not move it unless necessary to protect the oor. If you have to move the refrigerator, place thick paper or cloth such as old carpets along the path of movement. Untitled-23 32 2022-05-17 6:16:45English 33 Installation STEP 3 Door removal for entrance If the refrigerator cannot pass through the entrance to your home or kitchen due to its size, follow these instructions to remove and then re-install the refrigerator's doors. If you do not need to remove the doors, go to page 41 to continue the installation procedure. WARNING Unplug the power cord of the refrigerator before removing the doors. Tools required (not provided) Phillips screwdriver Flat-head screwdriver Socket wrench

1. With the doors closed, use a Phillips

screwdriver to remove the screws (x3) from the top cover. Pull up and remove the top cover with the connectors. Untitled-23 33 2022-05-17 6:16:45Installation English34 Installation

2. Disconnect the two wire connectors

on the left door. The position of the connectors differs with the model. CAUTION

• Do not remove both doors simultaneously. Make sure to remove one door at a time. Otherwise, any of the doors may fall and cause physical injury.

• Make sure the refrigerator is off before disconnecting the connectors.

3. Disconnect the water tube from the

coupler on the left door as shown. - This step does not apply to the models without the AutoFill pitcher and the water dispenser.

4. Gently draw up the clamp in several

steps. To prevent nger injuries, do not apply a sudden force to the clamp.

5. Pull up the clamp to remove.

holding the door, pull up and remove the top hinge. Be careful not to damage the connector wires when you remove the hinge.

7. Gently pull up the door vertically to

remove. Do not apply excessive force to the door. The door may fall, causing physical injury.

8. Lay the door down on a at surface.

9. Repeat steps 1-8 for the other door,

except for step 3. There is no water tube on the right side door. - Step 2 does not apply to the models without the Showcase door. Untitled-23 35 2022-05-17 6:16:46Installation English36 Installation Detach the freezer doors CAUTION

• Be sure to remove the fridge doors before removing the freezer doors.

• Use caution when disconnecting the bottom connectors.

1. Open the freezer door.

2. Use a Phillips screwdriver to remove

the screw holding the cover (A). - This step only applies to the right side freezer door (Cool Select+ door).

3. Disconnect the wire connectors.

- This step only applies to the right side freezer door (Cool Select+ door).

4. Locate the hinge shaft. While holding

the door with one hand, use a at-head screwdriver or Allen wrench to press the shaft down. Make sure to hold the door to prevent the door from falling. Untitled-23 36 2022-05-17 6:16:46English 37 Installation

5. To prevent contact with the middle

hinge, slightly tilt the door to the front, and then lift it up to remove.

6. Repeat steps 1-5 for the other door,

except for steps 2 and 3. To reattach the freezer doors CAUTION

• After re-attaching the doors, make sure all the electrical connectors are properly connected.

• The freezer doors must be re-attached before the fridge doors.

• Be careful not to damage or step on the wires during this process.

1. Insert the freezer door into the bottom

hinge while pushing the freezer door in the direction of the arrow. CAUTION

• Be careful not to damage or step on the wires during this process. Untitled-23 37 2022-05-17 6:16:46Installation English38 Installation

2. While pressing the hinge shaft down,

position the door so that the hinge shaft is below the shaft hole in the middle hinge. Release the hinge shaft so that it enters the shaft hole.

3. With the door open, connect the bottom

connectors in the direction of the arrows. - This step only applies to the right side freezer door (Cool Select+ door).

4. Attach the cover using a Phillips

screwdriver. Be careful not to damage or step on the connectors. - This step only applies to the right side freezer door (Cool Select+ door).

5. Repeat steps 1-5 for the other door,

except for steps 3 and 4. Untitled-23 38 2022-05-17 6:16:47English 39 Installation To reattach the fridge doors

1. While holding the door open by more

than 90 degrees, insert the shaft on the middle hinge into the hole on the bottom of the door.

2. Put the top hinge into position on the

top of the refrigerator, and then insert the hinge shaft into the top hole of the door. Make sure the wires from the door pass through the hole in the hinge shaft.

3. Insert the clamp in the direction of the

4. Push back the clamp as shown.

Untitled-23 39 2022-05-17 6:16:47Installation English40 Installation

5. Connect the wire connectors.

• Make sure the wire connectors are connected properly. Otherwise, the display will not operate.

6. Connect the water tube.

- This step does not apply to the models without the AutoFill pitcher and the water dispenser. CAUTION

• To prevent water leaks, make sure the red clips tighten the coupler properly.

• Keep the clips out of children’s reach.

7. Repeat steps 1-5 for the other door.

- Step 5 does not apply to the models without the Showcase door.

8. Attach the top cover with the front side

rst, and then press down on its back to get it into position. Then, tighten the screws (x3). Untitled-23 40 2022-05-17 6:16:47English 41 Installation STEP 4 Leveling the refrigerator CAUTION

• When installed, the refrigerator must be leveled on a at, solid oor. Not leveling the refrigerator can cause damage to the refrigerator or physical injury.

• Leveling must be performed with the refrigerator empty. Make sure no food items are inside the refrigerator.

• For safety reasons, adjust the front a little higher than the rear. Level the refrigerator using the special screws (levelers) on the front legs. Use a at-head screwdriver to turn the levelers.

• To adjust the height of the left side: Insert a at-head screwdriver into the leveler of the left side front leg. Turn the leveler clockwise to raise the left side or turn it counterclockwise to lower.

• To adjust the height of the right side: Insert a at-head screwdriver into the leveler of the right side front leg. Turn the leveler clockwise to raise the right side or turn it counterclockwise to lower. Untitled-23 41 2022-05-17 6:16:47Installation English42 Installation STEP 5 Adjust the door height Adjusting the height with the height lever (applicable models only)

• Before aligning the door height, make sure the refrigerator is level. Use the leveling legs for this purpose.

• You can use the height lever at the bottom of the right-side door of the fridge. Open the right-side door of the freezer with both fridge doors closed and use the lever to adjust the door height.

• Turn the height lever (A) until the two doors are aligned at the top. Turn the lever toward UP (as marked) to raise the right-side door and turn it toward DOWN (as marked) to lower the door.

• Lift the fridge door slightly to make alignment easier. The maximum adjustable height is 3 mm. - The lever will not turn past the maximum limit. It may make a noise it if is turned too far. - Excessive height may interfere with the upper hinge cover of the fridge door.

• If you align the door height with the door bins empty and then store items in the bins, the heights may differ again. If this happens, follow the steps above to realign the doors. Untitled-23 42 2022-05-17 6:16:47English 43 Installation Adjusting the height with the snap rings For the models with the height lever on the right-side door of the fridge, use the snaps rings only if you cannot align the doors with the height lever. NOTE The height of a door can be adjusted using the provided snap rings, which come in 4 different sizes (1 mm, 1.5 mm, 2 mm, and 2.5 mm).

1. Check the height difference between

the doors, and then lift up and hold the door with the lower height.

between the door grommet (B) and the hinge as shown. CAUTION

• Insert only one snap ring. If you insert two or more snap rings, the rings may slip out or make a rubbing noise.

• Keep the snap rings out of children’s reach and keep them for future use.

• Do not raise the door too much. The door can contact and damage the top cover. Untitled-23 43 2022-05-17 6:16:48Installation English44 Installation Adjusting the freezer door height (applicable models only)

• Before aligning the door height, make sure the refrigerator is level. Use the leveling legs for this purpose.

• You can adjust the height of both freezer doors using the lever located at the bottom hinge.

• Open the door, lift it a little, and then turn the lever left or right to adjust the height. Adjusting the gap between the fridge doors and the main body of the refrigerator (applicable models only)

• You can adjust the gap between both fridge doors and the main body of the refrigerator using the adjustment bolt located at the bottom of the fridge compartment.

• Lift the door gasket and located the adjustment bolt underneath the gasket. Use the 4 mm Allen wrench to adjust the gap. CAUTION Make sure you rmly attach the gasket. Otherwise, cold air from the refrigerator may leak. Untitled-23 44 2022-05-17 6:16:48English 45 Installation Adjusting the gap between the doors and the main body of the refrigerator (applicable models only) You can adjust the gap between all four doors and the main body of the refrigerator using the adjustment dial. (Refer to the gure for the location of the adjustment dial.)

1. Open the door that is closer to the main

body than the others. Then, turn the adjustment dial (A) counterclockwise until the gap becomes even with the others.

2. After adjusting the gap, turn the locking

nut (B) to lock the adjustment dial. NOTE Each time you turn the adjustment dial, the gap is adjusted by 1 mm. However, the door may not close properly if you adjust the door by more than 1.5 mm. Untitled-23 45 2022-05-17 6:16:48Installation English46 Installation STEP 6 Connect to a water source (applicable models only) CAUTION

• The new hose-sets supplied with the appliance are to be used and that old hose-sets should not be reused.

• The water line must be connected by a qualied technician.

• The warranty for your refrigerator does not cover the water line installation. The water line installation will be performed at your own costs unless the installation fee is included in the retailer’s price.

• Samsung takes no responsibility for the water line installation. If water leaks occur, contact the installer of the water line. To connect the cold water pipe to the water ltering hose CAUTION

• Make sure the water ltering hose is connected to a cold, potable water source pipe. Connecting to the hot water pipe may cause the purier to malfunction.

A. Close Main Water pipe B. No gap

1. Shut off the water supply by closing the

2. Locate the cold, potable water pipe (1).

3. Follow the Water Line Installation to

connect to the water pipe.

4. When connection is complete, open the

main water valve and dispense about 3 liters of water. This is to remove impurities inside the pipe. Untitled-23 46 2022-05-17 6:16:48English 47 Installation To connect the water ltering hose to the water line Remove cap

A. Water Line from unit B. Water Line from Kit

1. Loosen and remove the compression

nut (a) from the water line of the refrigerator, and insert it to the water ltering hose.

2. Tighten up the compression nut (a) to

connect the water ltering hose and the water line.

3. Open the main water valve and check

4. If there are no leaks, dispense about a

3 liters of water before actually using the refrigerator to remove impurities inside the water ltering system. NOTE If you have to relocate the refrigerator after connecting the water line, make sure the joined section of the water line must is straight. CAUTION Do not mount the water lter on any part of the refrigerator. This may damage the refrigerator. To repair the water line CAUTION The waterline must be repaired by a qualied professional. If you encounter a water leak, contact a local Samsung service centre or the installer of the waterline. Untitled-23 47 2022-05-17 6:16:49Installation English48 Installation STEP 7 Initial settings By completing the following steps, the refrigerator should be fully functioning.

1. Plug the power cord into the wall socket to turn the refrigerator on.

2. Open the door, and check if the interior light lights up.

3. Set the temperature to the coldest setting, and wait for about an hour. Then, the

freezer will be slightly chilled, and the motor should be running smoothly.

4. Wait until the refrigerator reaches the set temperature. Now the refrigerator is ready

for use. STEP 8 Final check When installation is complete, conrm that:

• The refrigerator is plugged into an electrical outlet and grounded properly.

• The refrigerator is installed on a at, level surface with a reasonable clearance from walls and cabinets.

• The refrigerator is level and is sitting rmly on the oor.

• The door opens and closes freely, and the interior light turns on automatically when you open the door. Untitled-23 48 2022-05-17 6:16:49English 49 Operations Control panel

• When the display is off, tap any button to wake up the display.

• Tap or to navigate left and right.

• Tap to conrm your selection.

• Tap and hold to enter the AP mode. (For more information, see the “SmartThings > Getting started” section on page 54.) NOTE

• The control panel is designed to stay off when the refrigerator is not in use. It only becomes active and lights up when you open the door or tap the buttons.

• If the door is left open for 5 minutes, the internal light will blink for 5 minutes and turn off. It is to alert deaf and hard of hearing users that a door is open. Note that this function is normal.

• When you change the temperature on the panel, the panel displays the actual temperature inside the refrigerator until the temperature matches the temperature you set. Then, the panel displays the new set temperature. Note that it will take time for the refrigerator to reach the new temperature. It is normal. During this time, you need not set the temperature again. Using the control panel

1. Tap any button ( , , or ) to wake up the display.

2. Tap or to select the desired menu, and then tap to conrm.

3. Tap or to select the desired setting, and then tap to conrm.

- For more information on available settings, see the Menu descriptions section. Operations Untitled-23 49 2022-05-17 6:16:49Operations English50 Operations Menu descriptions Fridge

• You can set the fridge temperature from 1~7 °C or set the Power Cool function.

• Power Cool speeds up the cooling process at maximum fan speed. The fridge keeps running at full speed for two and a half hours and then returns to the previous temperature. Freezer

• You can set the freezer temperature from -23 ~ -15 °C or set the Power Freeze function.

• Power Freeze speeds up the freezing process at maximum fan speed. The freezer keeps running at full speed for 50 hours and then returns to the previous temperature. To freeze large amounts of food, activate Power Freeze for at least 20 hours before putting food in the freezer. Cool Select+

• You can set the Cool Select+ mode from one of the following modes. - Freeze: The temperature sets to the same temperature as the freezer. - Soft Freeze: The temperature sets to -5 °C. - Meat/Fish: The temperature sets to -1 °C. - Fruit/Veggies: The temperature sets to 2 °C. - Beverage: The temperature sets to 4 °C. CAUTION

• Select the Cool Select+ mode accordingly to the type of food you store in there.

• Do not store meat or food in the Cool Select+ with the Fruit/ Veggies or Wine mode. Meat or food may spoil.

• Do not store glass bottles in the Cool Select+ in Freeze or Soft Freeze mode. They may break and cause physical injury. Untitled-23 50 2022-05-17 6:16:49English 51 Operations Flex Crisper * You can set the Flex Crisper mode from one of the following modes.

• Meat/Fish: Select this mode to store meat and sh fresh. (We recommend setting the fridge temperature below 3 °C to store meat and sh fresher in the Flex Crisper) NOTE Meat and sh can be store in the Flex Crisper for 3 to 5 days (with some exceptions like ground meat, which should only be kept for one or two days). Store them in the freezer if you want to keep it longer than 5 days.

• Fridge: The temperature sets to the same temperature as the fridge.

• Grains: Select this mode to keep grains fresh even longer than leaving them at room temperature. CAUTION Store rice or grains in an airtight container or containers with a lid.

• Tropical Fruit: Select this mode to store tropical fruits that are easy to turn mushy. NOTE Storing tropical fruits under this mode will keep that fresh longer than storing them at room temperature or in the fridge. AutoFill Pitcher *

• You can set the AutoFill Pitcher mode from one of the following modes. - On: Set to ll your water pitcher automatically. - Off: Set to turn off the function. NOTE You can put tea or fruit into the infuser to make infused tea or water. If you want to keep the infused water in its initial concentration, turn the AutoFill Pitcher function off. (For more information, see the Water pitcher (Autoll Pitcher) (applicable models only) section on page 56.) Cubed Ice * (Ice Maker *) You can start or stop making cubed ice. Ice Bites * You can start or stop making ice bites. Untitled-23 51 2022-05-17 6:16:49Operations English52 Operations More Options You can change the settings for the following functions. Tap or to select the menu, and then tap to conrm. Filter Reset *: When you get the lter replacement message on the display, select this menu, and replace the lter according to onscreen instructions. Temp. Unit: You can set the temperature scale to Celsius or Fahrenheit. Door Alarm: You can turn on or off the Door Alarm. Wi-Fi Connect: You can turn on or off the Wi-Fi Connect. Turn it on to control and monitor your refrigerator on the SmartThings app. (For more information on SmartThings, see the SmartThings section on page 53.)

• applicable models only NOTE Using Power Cool or Power Freeze increases power consumption. Untitled-23 52 2022-05-17 6:16:49English 53 Operations SmartThings Installation Visit the Google Play Store, Galaxy Apps, or Apple App Store and search for “SmartThings”. Download and install the SmartThings app provided by Samsung Electronics to your smart device. NOTE

• The supporting software version of the SmartThings app is subject to change according to the OS supporting policy the manufacturer provides. In addition, as for the SmartThings app or the functions that the app supports, the new application update policy on the existing OS version can be suspended due to usability or security reasons.

• The SmartThings app is subject to change without notice to improve usability or performance. As the mobile phone OS version is updated every year, the SmartThings is also updated continually according to the latest OS. If you have enquiries regarding the items mentioned above, please contact us on st.service@samsung.com

• Recommended encryption systems include WPA/TKIP and WPA2/AES. Any newer or non-standard Wi-Fi authentication protocols are not supported.

• Wireless networks may be affected by the surrounding wireless communication environment.

• If your Internet service provider has registered the MAC address of your PC or modem for identication, your Samsung Smart Refrigerator may fail to connect to the Internet. If this happens, contact your Internet service provider for technical assistance.

• The rewall settings of your network system may prevent your Samsung Smart Refrigerator from accessing the Internet. Contact your Internet service provider for technical assistance. If this symptom continues, contact a local Samsung service center or retailer.

• To congure the wireless access point (AP) settings, see the user manual of the AP (router).

• Samsung Smart Refrigerators support both Wi-Fi 2.4 GHz with IEEE 802.11 b/g/n and Soft-AP protocols. (IEEE 802.11 n is recommended.)

• Unauthorized Wi-Fi wireless routers may fail to connect to applicable Samsung Smart Refrigerators. Untitled-23 53 2022-05-17 6:16:49Operations English54 Operations Samsung account You are required to register your Samsung account to use the app. If you don’t have a Samsung account, follow the app’s onscreen instructions to create a free Samsung account. Getting started Turn on the device you want to connect, open the SmartThings app on your phone, and then follow the instructions below. If a pop-up appears saying that a new device has been found, tap ADD NOW. If a pop-up doesn't appear, tap the + button, and then select the device you want to connect from the list of available devices. If your device isn't in the list of available devices, tap Supported Devices, select the device type (Refrigerator), and then select the specic device model. Follow the instructions in the app to set up your device. Once setup is complete, your refrigerator will appear as a "card" on your Devices screen. Refrigerator app Integrated control You can monitor and control your refrigerator at home and on the go.

• Tap the refrigerator icon on the SmartThings Dashboard or tap the Devices icon at the bottom of the Dashboard, and then tap the refrigerator "card" to open the Refrigerator page.

• Check the operation status or notications related to your refrigerator, and then change options or settings if necessary. NOTE Some options or settings of the refrigerator may not be available for remote control. Untitled-23 54 2022-05-17 6:16:49English 55 Operations Category Item Description Monitor & Control Fridge Temperature You can set and monitor the desired temperature of the fridge. Freezer Temperature You can set and monitor the desired temperature of the freezer. Power Cool You can turn Power Cool on or off, and check the current settings. Power Freeze You can turn Power Freeze on or off, and check the current settings. Flex Crisper You can set and monitor the desired mode of the Flex Crisper. Cool Select+ You can set and monitor the desired mode of the Cool Select+. Cubed Ice / Ice Bites You can turn the ice making function on or off, and check the current settings of the function. AutoFill Pitcher You can turn the AutoFill Pitcher function on or off, and check the current settings of the function. Alarms Abnormally high temperature This alarm is triggered when the fridge, the freezer, or the Cool Select+ has abnormally high temperatures. Door opening This alarm is triggered if the fridge door, the freezer drawer, or the Cool Select+ drawer is open for a specic time. Autoll Pitcher overowing If the Autoll Pitcher function senses an overow, it triggers this alarm to let you know the status of the overow. Water lter replacement This alarm reminds you that the water lter must be replaced. Untitled-23 55 2022-05-17 6:16:49Operations English56 Operations Special features Beverage Center (applicable models only) B A A. Fridge door handle B. Beverage Center handle The left fridge door has two handles on the bottom. To use the autoll pitcher, drink cold or puried water, press handle (B) to open the Beverage Center. Water pitcher (Autoll Pitcher) (applicable models only) Cold, puried water is always ready in the AutoFill Pitcher. You can put tea or fruits in the infuser to enjoy the various infused water you like.

01 Lid 02 Infuser holder 03 Infuser 04 Body Untitled-23 56 2022-05-17 6:16:50English 57 Operations To ll the Water pitcher

1. Grasp a handle groove of the lid, and

then pull up to open the lid.

2. Put tea leaves or fruit to your taste into

the infuser. NOTE If you want to keep the infused water in its initial concentration, turn the Autoll Pitcher function off.

3. Enable the Autoll Pitcher function on

the control panel. Open the Beverage Center door, and then mount the water pitcher onto the holder. Push it straight in as shown in the gure.

4. Close the door. The water pitcher will

start to ll with chilled water a short time later. CAUTION Make sure the water pitcher ts in the water pitcher holder.

5. To drink tea, open the Beverage Center

door, and then detach the water pitcher. Pull it straight out. CAUTION

• We recommend consuming fruit infused water within 24 hours. After that, the infused water can spoil over time.

• You must clean the water pitcher after you have consumed the infused water. Also clean the water pitcher if you haven't used it for a long time. Untitled-23 57 2022-05-17 6:16:50Operations English58 Operations

• To prevent the water pitcher from tipping over or leaking, make sure the water pitcher ts in the water pitcher holder.

• To prevent the water pitcher from spilling over or leaking, make sure the infuser holder is properly inserted. NOTE

• If the front side (specically marked area) of the water pitcher has too much moisture, the water pitcher may not fully ll. Remove the moisture, and then try again.

• Autoll Pitcher function will stop supplying water to the water pitcher if the water pitcher does not ll after a certain amount of time. If this happens, check if the water line is properly connected. Remove and reinsert the water pitcher, and then try again. Untitled-23 58 2022-05-17 6:16:50English 59 Operations NOTE

• Wipe around the water pitcher holder if the water pitcher overows or leaks.

• Water drops off if the rubber cap is opened.

• An alert message appears on the control panel if there is a leak. In case of a leak, open the rubber cap so that the leaked water drains. If the alert message does not disappear after draining, there might be a system failure. Contact your local Samsung service center. Untitled-23 59 2022-05-17 6:16:50Operations English60 Operations Water dispenser (applicable models only) To dispense chilled water, open the Beverage Center and press the dispenser lever. NOTE

• The dispenser will stop dispensing if you keep pushing the dispenser lever for about 1 minute. To dispense more water, release and push the lever again.

• Make sure the glass is in line with the dispenser to prevent the dispensed water from spilling out.

• If you do not use the water dispenser for 2-3 days, the dispensed water may have an abnormal smell or taste. This is not a system failure. Discard the rst 1-2 glasses of water. Water clouding Water supplied to the refrigerator ows through a core alkaline lter. During this ltering process, the water pressure of the water increases and the water becomes saturated with oxygen and nitrogen. This causes the water to look misty or cloudy temporarily when dispensed. This is normal and the water will look clear after a few seconds. Untitled-23 60 2022-05-17 6:16:51English 61 Operations Auto Ice maker (applicable models only) The refrigerator has a built-in ice maker that automatically dispenses ice.

• The overall design and/or accessories may differ with the model.

• This product has two types of ice makers. Ice making After you have installed your refrigerator and plugged it in, follow these instructions to ensure proper ice making and to keep the ice bucket full of ice. For rst-time use

• Let the ice maker make ice for 1-2 days.

• Discard the rst 1-2 buckets of ice to remove impurities in the water supply system. Diagnosis

• The overall design and/or accessories may differ with the model.

• If ice does not dispense, rst check the status of ice maker using the Test button on the bottom of the ice maker.

• Press the Test button on the back of the ice maker. You will hear a chime (ding- dong) when you press the button. You will hear another chime if the ice maker is operating properly.

• Ice accumulating on one side of the tray is normal. Arrange the ice evenly in the tray to store more ice. Untitled-23 61 2022-05-17 6:16:51Operations English62 Operations CAUTION

• Leaving the water line disconnected may cause the water valve to produce a buzzing sound over time. If this is the case, make sure to turn the ice making function (Cubed Ice / Ice Bites ) off.

• If the ice making chime rings repeatedly, contact the waterline installer or a local Samsung service center.

• Do not put food in the ice bucket. The frozen food may damage the ice maker, especially when you open or close the door.

• When the refrigerator recovers power after a power failure, the ice bucket may contain a mix of melted and jammed ice cubes, which can prevent the ice maker from working properly. To prevent this, make sure to empty the ice bucket before using the refrigerator.

• Do not put ngers or any objects into the ice maker. This can cause physical injury or property damage.

• Due to sublimation, ice stored in the freezer for a long time gets smaller and then forms large ice chunks. Therefore, if it will be a long time before you use ice, turn the ice maker off as follows.

• Use the new hose-sets supplied with the appliance only. Do not re-use an old hose set. Twist ice maker (applicable models only)

1. Open the freezer door, and slide open

2. Fill the tray with water up to the

maximum level (A) marked on the inner rear of the tray.

3. Slide the tray back into position.

Untitled-23 62 2022-05-17 6:16:51English 63 Operations

4. When the water freezes into ice cubes,

turn the ice tray handle clockwise to empty the ice cubes into the ice box. Repeat this until all the ice cubes are emptied into the ice box.

5. To remove the ice box, gently lift up

and pull out. CAUTION

• Do not use the ice box specically for making ice. The box may break.

• Make sure the ice box is in place under the ice tray.

• The ice box has a drain hole at the bottom. - Do not store ice in the box in ambient temperatures. The ice melts and runs out. - In case of a power failure, the ice melts into water and runs out. After the power recovery, the water may freeze back and cause the box to break. To prevent damage to the box, remove and empty the box after the power failure. - Use only potable water. NOTE

• The ice making time depends on your temperature settings. Untitled-23 63 2022-05-17 6:16:51Operations English64 Operations Slim Ice Maker (applicable models only)

01 Water bin 02 Ice maker lever 03 Ice bucket 04 Ice template cover 05 Ice template (inside the cover) NOTE If you do not intend to make ice, remove the slim ice maker to secure more room for storage. In this case, you can use the ice bucket as a multipurpose storage bin. Untitled-23 64 2022-05-17 6:16:51English 65 Operations

1. Pull up the handle of the water bin to

open, and then ll the bin with water up to the max line (). Do not exceed the max line. CAUTION

• Excessive (above the max line) or frequent rells (even below the max line) of water causes the ice to jam and not dispense well.

• Use only potable water. Other liquids, such as green tea or milk may not dispense well. NOTE

• Gently close the bin so that water does not drop or leak.

• If you encounter a water leak, open the water bin and check if the ice bin's passage to the ice template is frozen. If this is the case, pour lukewarm water into the water bin up to the max line. Let the passage melt.

• It is recommended to clean the ice bin’s passage to the ice template on a regular basis because the passage is likely to freeze. Untitled-23 65 2022-05-17 6:16:52Operations English66 Operations

2. Check if the ice freezes completely.

Only when the ice has frozen completely, pull up the lever. Then, the ice template rotates and dispenses ice to the ice bucket. Keep pulling up the lever until the ice dispenses completely. CAUTION

• Do not pull up the lever until the ice has frozen completely. Half-frozen ice may jam and damage the ice bucket.

• Do not ll the ice bin with water while ice remains in the ice template. This causes the ice to jam and not dispense well to the ice bucket.

• If this is the case, remove and empty the ice template.

3. To dispense ice, tilt the ice bucket to the

front. To tilt the ice bucket, put your nger between the slim ice maker and the ice bucket while holding the bucket with the other ngers. CAUTION

• Do not pour water directly into the ice bucket for ice making. The ice bucket may break.

• Do not leave the freezer door open. The ice in the ice bucket melts and jams.

• In case of a power failure, make sure to empty the ice bucket before making ice.

• Use only potable water.

• Do not put your nger between the ice maker and the ice bucket when opening or closing the ice bucket. Your nger may be caught inbetween. Untitled-23 66 2022-05-17 6:16:52English 67 Operations NOTE If no ice dispenses because too much water was input and frozen, remove and empty the ice template. Water tank (applicable models only) You can add drinking water to make ice. CAUTION

• Fill the tank only with potable water such as mineral or puried water. Do not use other liquid.

• Use caution when moving a lled tank. Physical injury may occur if the tank is dropped. To ll the water tank For rst-time use, clean the inner side of the water tank and dry well.

1. Open the refrigerator door and pull out

the water tank to take it out.

2. Open the front lid and add water

according to the marks in the water tank. Untitled-23 67 2022-05-17 6:16:52Operations English68 Operations CAUTION Do not exceed the max line. Water overows.

3. Close the front lid and push the water

tank all the way in. Turn the Ice Maker ON in the control panel. Ice that is made will be stored in the freezer’s ice bucket. NOTE

• Even if the water tank is full, ice will not be made if the Ice Maker is turned off.

• The pump that sends water to the Ice Maker may make noise if the water tank is empty. Turn off the Ice Maker to avoid this.

• There may be noise for about 5 seconds when sending water to the Ice Maker. This is normal and is not a malfunction. CAUTION

• Do not put water directly in the ice bucket to freeze it. There is a risk of damage.

• Empty the water tank when it is not in use.

• When the refrigerator recovers power after a power failure, the ice bucket may contain a mix of melted and jammed ice cubes, which can prevent the ice maker from working properly. To prevent this, make sure to empty the ice bucket before using the refrigerator.

• Do not put ngers or any objects into the ice maker. This can cause physical injury or property damage. Untitled-23 68 2022-05-17 6:16:52English 69 Operations Cleaning and maintenance

• Clean the water tank every one or two weeks. Be sure to detach every component part including the cover and the nozzle (A).

• Completely empty the water tank before cleaning with clean water. And dry out the tank for later use.

• Use a soft brush to clean the lter (B). CAUTION Do not leave the water tank with moisture inside before relling with water. Otherwise, the tank may have impurities built up inside over time. For rst-time use Discard the rst bucket of ice before using the device as it may contain impurities. Diagnosis

• Ice accumulating on one side of the tray is normal. Arrange the ice evenly in the tray to store more ice. Untitled-23 69 2022-05-17 6:16:53English70 Maintenance Handling and care Ice bucket (applicable models only) If you do not dispense ice for an extended period, ice may form clumps inside the bucket. If this happens, remove and empty the ice bucket. CAUTION

• To prevent injury, make sure to clean up any ice or water that has fallen on the oor.

• To prevent accidents or injury, do not let children play with the water dispenser or the ice maker.

• Use only the provided ice bucket. Third-party ice buckets may cause a system failure. NOTE

• The water pressure required for ice making is between 206-861 kPa.

• Noise from the ice maker as it produces ice during the ice making process is normal. Autoll pitcher (applicable models only)

1. Grasp a handle groove of the lid, and

then pull up to remove.

2. Grasp both sides of the infuser holder,

and then lift to remove. Maintenance Untitled-23 70 2022-05-17 6:16:53English 71 Maintenance

3. While slightly twisting the infuser, pull

it out of the sealed mouth.

4. Clean the infuser with neutral agents

and running water. Rinse and dry well.

5. Reassemble the Autoll pitcher in the

reverse order of disassembly. CAUTION The water pitcher and lid are not microwave safe and can melt or deform if exposed to heat (including hot water). Please hand wash in cool or warm water as needed. Untitled-23 71 2022-05-17 6:16:53Maintenance English72 Maintenance Fridge shelves The appearance of the shelves differs by model.

• To remove a shelf, fully open the corresponding door. Hold the front of the shelf, and then gently lift up and pull out. NOTE Do not lift up the shelf fully when removing or reinserting the shelf. The rear wall of the fridge room can be dented.

• To reinsert, hold the shelf at an angle so the front is higher than the back, and then insert the top hook into the top shelf notch. Then, lower the shelf and insert the bottom shelf hook into the bottom shelf notch. CAUTION

• The tempered glass shelves are heavy. Use caution when removing them.

• The shelf must be inserted correctly. Do not insert upside down.

• Glass containers may scratch the surface of glass shelves. Untitled-23 72 2022-05-17 6:16:54English 73 Maintenance Door bins

• To remove the door bin, hold the front sides of the bin, and then gently lift up to remove.

• To reinsert, insert the door bin slightly above its nal location making sure that the back of the bin is against the door. Hold the rear of the door bin with both hands, and then press down so that it ts snugly. CAUTION

• Do not remove a bin that is lled with food. Empty the bin beforehand.

• Use caution when opening the door if the bottom bin contains larger bottles, which may fall over.

• Do not allow children to play with the bins. Sharp corners of the bin may cause injury. Fridge drawers Gently lift up the front of the drawer and slide out.

• We recommend that you remove the door bins before removing the drawer. This is to prevent damage to the door bins.

• To reinsert, insert the drawer into the frame rails and then slide inward. Untitled-23 73 2022-05-17 6:16:54Maintenance English74 Maintenance Slim ice maker (applicable models only) NOTE

• Disassemble it into component parts such as the ice bin and ice template. Then, clean each component part and use a dry cloth to wipe up and dry well.

• If you have cleaned the ice maker as a whole, the ice maker lever may not operate properly. If this is the case, dry the slim ice maker well for 2-3 days. To remove each component part Ice bucket Tilt the ice bin to the front, and then lift up to remove. Water bin Fully open the water bin, and then pull out. Ice template

1. Open the ice template cover to reveal

the ice template. Untitled-23 74 2022-05-17 6:16:54English 75 Maintenance

2. Slightly pull out the left side of the ice

template, and then pull out the other side to remove. Slim ice maker While holding the marked area on either side of the slim ice maker, pull out in the arrow directions. Reinstallation Ice bucket Fit either side of the ice bucket into the corresponding hook on the bucket housing, and then push in to close. Untitled-23 75 2022-05-17 6:16:54Maintenance English76 Maintenance Water bin Fit either side of the water bin into the corresponding hook on the water bin housing. Make sure to t until you hear a clicking sound. Ice template Reinserting the ice template is in the reverse order of the removal. The ice template ts only in one direction so make sure to reinsert the ice template in the right direction.

1. Fit the bottom right side of the ice

template into the right hook on the ice template housing.

2. Fit the bottom left side of the ice

template into 2 hooks on the left of the housing. Then, push in until you hear a clicking sound. Untitled-23 76 2022-05-17 6:16:55English 77 Maintenance Slim ice maker Fit either side of the slim ice maker into the corresponding hook on the ice maker housing, and then push in to the end. Untitled-23 77 2022-05-17 6:16:55Maintenance English78 Maintenance Cleaning Interior and exterior WARNING

• Do not use benzene, thinner, home/car detergent, or Clorox™ to clean the refrigerator. They may damage the surface of the refrigerator and cause a re.

• Do not spray water onto the refrigerator. This may cause electric shock. Regularly use a dry cloth to remove all foreign substances such as dust or water from the power plug terminals and contact points.

1. Unplug the power cord.

2. Use a moistened, soft, lint-free cloth or paper towel to clean the refrigerator’s interior

3. When done, use a dry cloth or paper towel to dry well.

4. Plug in the power cord.

Dispenser nozzle (applicable models only)

1. Hold the end of the dispenser nozzle

2. While turning the dispenser nozzle (A)

left, pull it down to remove it from the dispenser.

3. Clean the dispenser nozzle thoroughly,

and then assemble it back. CAUTION

• Fully insert the dispenser nozzle, so it is back to its original position.

• Do not use a sponge with rough textures for cleaning the dispenser nozzle. Untitled-23 78 2022-05-17 6:16:55English 79 Maintenance Rubber seals If the rubber seals of a door become dirty, the door may not close properly and reducing refrigerator performance and efciency. Use a mild detergent and damp cloth to clean the rubber seals. Then, dry well with a cloth. Rear panel To keep cords and exposed parts of the rear panel free of dirt, vacuum the panel once or twice a year. CAUTION Do not remove the rear panel cover. Electric shock may occur. Replacement Water lter (applicable models only) WARNING

• Do not use third-party water lters. Use only Samsung-provided or -approved lters.

• Unapproved lters may leak and damage the refrigerator, causing electric shock. Samsung is not responsible for any damage that may occur from use of third-party water lters. The “Replace water lter” message appears on the control panel to let you know it is time to replace the water lter. Before replacing the lter, make sure the water supply line is shut off. Untitled-23 79 2022-05-17 6:16:55Maintenance English80 Maintenance

1. Shut off the water supply line.

2. Open the lter cartridge cover.

3. Turn the knob of the lter cartridge

4. Pull out to remove the cartridge.

- If the water lter is severely contaminated, the cartridge may not be easy to remove. If that is the case, use force to remove the cartridge. - To prevent water leaks from the lter opening, pull the cartridge straight out while removing it.

5. Insert a new lter cartridge. Use only

Samsung-provided or approved lters.

7. Close the lter cartridge cover.

8. On the control panel, go to More

Options, and then run Filter Reset. Untitled-23 80 2022-05-17 6:16:56English 81 Maintenance NOTE

• A newly installed lter may cause the water dispenser to spurt water briey. This is because air has entered the waterline.

• The replacement process may cause the water dispenser to drip for a short period of time. If it drips, simply wipe up any water on the oor with a dry towel. Reverse osmosis water ltration system The water pressure of the water supply system to a reverse osmosis water ltration system must be between 206-861 kPa. The water pressure of the reverse osmosis water ltration system to the refrigerator’s cold water line must be at least 206 kPa. If the water pressure is below these specications:

• Check if the sediment lter in the reverse osmosis system is blocked. Replace the lter if necessary.

• Rell the water tank in the reverse osmosis system with water.

• If your refrigerator has a water lter, it may further reduce the water pressure when used in conjunction with a reverse osmosis system. Remove the water lter. For more information or servicing, contact a licensed plumbing professional. Ordering a new lter To purchase a new water lter, contact a local Samsung service center. LED Lamps To replace the lamps of the refrigerator, contact a local Samsung service center. WARNING

• The lamps are not user-serviceable. Do not attempt to replace a lamp yourself. This can cause electric shock. Door panel (applicable models only) NOTE You may not be able to purchase the Door panel separately in some countries. You can select the door panel you prefer for your BESPOKE refrigerator. Purchase the door panel at a Samsung retail store and an authorized installer will install the panel for you. CAUTION

• Disassembling or assembling the door panel on your own may result in product damage or personal injury. If you nd any problems with the door panel, contact a Samsung service center

• A service fee may be charged for panel replacement even within the warranty period. Untitled-23 81 2022-05-17 6:16:56English82 Troubleshooting Before calling for service, review the checkpoints below. Any service calls regarding normal situations (No Defect Cases) will be charged to users. General Temperature Symptom Possible causes Solution Fridge/freezer does not operate. Fridge/freezer temperature is warm.

• Power cord is not plugged in properly.

• Properly plug in the power cord.

• Temperature control is not set correctly.

• Set the temperature lower.

• Refrigerator is located near a heat source or direct sunlight.

• Keep the refrigerator away from direct sunlight or a heat source.

• Not enough clearance between refrigerator and nearby walls or cabinets.

• Make sure there is a gap of at least 5 cm between the refrigerator back and sides and any nearby walls or cabinets.

• The refrigerator is overloaded. Food is blocking the refrigerator vents.

• Do not overload the refrigerator. Do not allow food to block vents. Fridge/freezer is over-cooling.

• Temperature control is not set correctly.

• Set the temperature higher. Interior wall is hot.

• Refrigerator has heat-proof piping in the interior wall.

• To prevent condensation from forming, the refrigerator has heat-proof piping in the front corners. If the ambient temperature rises, this equipment may not work effectively. This is not a system failure. Troubleshooting Untitled-23 82 2022-05-17 6:16:56English 83 Troubleshooting Odors Symptom Possible causes Solution Refrigerator has odors.

• Clean the refrigerator and remove any spoiled food.

• Food with strong odors.

• Make sure strong smelling food is wrapped airtight. Frost Symptom Possible causes Solution Frost around the vents.

• Food is blocking the vents.

• Make sure no food blocks the refrigerator vents. Frost on interior walls.

• Door is not closed properly.

• Make sure food does not block the door. Clean the door gasket. Fruits or vegetables are frozen.

• Fruits or vegetables are stored in the Cool Select+.

• Do not store most kinds of fruit or vegetables in the Cool Select+. Condensation Symptom Possible causes Solution Condensation forms on the interior walls.

• If door is left open, moisture enters the refrigerator.

• Remove the moisture and do not leave a door open for extended periods of time.

• Food with high moisture content.

• Make sure food is wrapped airtight. Untitled-23 83 2022-05-17 6:16:56Troubleshooting English84 Troubleshooting Water/ice (dispenser models only) Symptom Possible causes Solution Water ow is weaker than normal.

• Water pressure is too low.

• Make sure the water pressure is between 206- 861 kPa. Ice maker makes a buzzing sound.

• The ice maker function is activated, but the water supply to the refrigerator has not been connected.

• Turn off the Ice Maker. Ice maker does not make ice.

• Ice maker has just been installed.

• You must wait for 12 hours for the refrigerator to make ice.

• Freezer temperature is too high.

• Set the freezer temperature below -18 °C or -20 °C in warm ambient air.

• Ice maker is off. • Turn on the ice maker. Ice does not dispense.

• Ice may jam if the ice dispenser is not used for a long time (approx. 3 weeks).

• If you won't be using the refrigerator for a long time, empty the ice bucket and turn off the ice maker.

• Ice bucket is not properly inserted.

• Make sure the ice bucket is properly inserted.

• Water line is not connected properly or water supply is not on.

• Check the water installation conditions. Untitled-23 84 2022-05-17 6:16:56English 85 Troubleshooting Symptom Possible causes Solution Water does not dispense.

• Water line is not connected properly or water supply is not on.

• Check the water installation conditions.

• A third-party water lter was installed.

• Use only Samsung-provided or approved lters.

• Unapproved lters may leak and damage the refrigerator.

• The "Replace water lter" message appears on the control panel.

• Replace the water lter. Then, on the control panel, go to More Options, and then run Filter Reset. Untitled-23 85 2022-05-17 6:16:56Troubleshooting English86 Troubleshooting Do you hear abnormal sounds from the refrigerator? Before calling for service, review the checkpoints below. Any service calls related to normal sounds will be charged to the user. These sounds are normal.

• When starting or ending an operation, the refrigerator may make sounds similar to a car engine igniting. As the operation stabilizes, the sounds will decrease. Clicking! or Chirping!Buzzing!

• While the fan is operating, these sounds may occur. When the refrigerator reaches the set temperature, no fan sound will occur. SSSRRR!Whir!

• During a defrost cycle, water may drip on the defrost heater, causing sizzling sounds. HiSS! Untitled-23 86 2022-05-17 6:16:57English 87 Troubleshooting

• As the refrigerator cools or freezes, refrigerant gas moves through sealed pipes, causing bubbling sounds. Bubbling!

• As the refrigerator temperature increases or decreases, plastic parts contract and expand, creating knocking noises. These noises occur during the defrosting cycle or when electronic parts are working. Cracking!

• For ice maker models: When the water valve opens to ll the ice maker, buzzing sounds may occur.

• Due to pressure equalizing when opening and closing the refrigerator door, whooshing sounds may occur. Untitled-23 87 2022-05-17 6:16:57Troubleshooting English88 Troubleshooting SmartThings Symptom Action Could not nd “SmartThings” in the app market.

• The supporting software version of the SmartThings app is subject to change according to the OS supporting policy the manufacturer provides. In addition, as for the SmartThings app or the functions that the app supports, the new application update policy on the existing OS version can be suspended due to usability or security reasons. The SmartThings app fails to operate.

• The SmartThings app is available for applicable models only.

• The old Samsung Smart Refrigerator app cannot connect with Samsung Smart Home models. The SmartThings app is installed but is not connected to my refrigerator.

• You must log into your Samsung account to use the app.

• Make sure that your router is operating normally.

• If the Wi-Fi icon on the refrigerator’s display is off, this indicates that no network connection has been established yet. In this case, use the SmartThings app to connect and register your refrigerator to the access point (AP) of your house. Could not log into the app.

• You must log into your Samsung account to use the app.

• If you don’t have a Samsung account, follow the app’s onscreen instructions to create one. An error message appears when I try to register my refrigerator.

• Easy Connection may fail due to the distance from your access point (AP) or electrical interference from the surrounding environment. Wait a moment and try again. The SmartThings app is successfully connected to my refrigerator but does not run.

• Exit and restart the SmartThings app, or disconnect and reconnect the router.

• Power off the refrigerator, and then power it on again after 1 minute. Untitled-23 88 2022-05-17 6:16:57English 89 Open Source Announcement The software included in this product contains open source software. The following URL http://opensource.samsung.com/opensource/SMART_TP2_0/seq/0 leads to open source license information as related to this product. Untitled-23 89 2022-05-17 6:16:57Memo Untitled-23 90 2022-05-17 6:16:57Memo Untitled-23 91 2022-05-17 6:16:57Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Country Contact Center Web Site EGYPT 08000-7267864
