USER MANUAL HUI30253UC BOSCH

• What this warranty covers & who it applies to p. 18
• How long this warranty lasts p. 18
• Repair/replace as your exclusive remedy p. 18
• Out of warranty product p. 19
• Warranty exclusion p. 19
• Obtaining warranty service Additional information on products, accessories, replacement parts and services can be found at www.bosch-home.com and in the online shop www.bosch-home.com/us/shopEnglish 3 SAFETY DEFINITIONS WARNING This indicates that death or serious injuries may occur as a result of non-observance of this warning. CAUTION This indicates that minor or moderate injuries may occur as a result of non-observance of this warning. NOTICE: This indicates that damage to the appliance or property may occur as a result of non-compliance with this advisory. NOTE: This alerts you to important information and/or tips.English 4 p. 19

IMPORTANT SAFETY INSTRUCTIONS

READ AND SAVE THESE INSTRUCTIONS

WARNING When properly cared for, your new appliance has been designed to be safe and reliable. Read all instructions carefully before use. These precautions will reduce the risk of electrical shock, fi re and injury to persons. When using kitchen appliances, basic safety precautions must be followed including those in the following pages. Examine the appliance after unpacking it. In the event of transport damage, do not plug it in. WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:

Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer.

Before servicing or cleaning unit, switch power off at service panel and lock the service disconnecting means to prevent power from being switched on accidentally.

When the service disconnecting means cannot be locked, securely fasten a prominent warning device, such as a tag, to the service panel. WARNING WARNING – TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:

Installation work and electrical wiring must be done by qualifi ed person(s) in accordance with all applicable codes and standards, including fi re-rated construction.

Suffi cient air is needed for proper combustion and exhausting of gases through the fl ue (chimney) of fuel burning equipment to prevent back drafting. Follow the heating equipment manufacturer’s guideline and safety standards such as those published by the National Fire Protection Association (NFPA), and the American Society for Heating, Refrigeration and Air Conditioning Engineers (ASHRAE), and the local code authorities.

When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities.

Ducted fans must always be vented to the outdoors. WARNING If the information in this manual is not followed exactly, a fi re or explosion may result causing property damage, personal injury or death. -- DO NOT store or use gasoline or other fl ammable vapors and liquids in the vicinity of this or any other appliance. -- WHAT TO DO IF YOU SMELL GAS

• DO NOT try to light any appliance.

• DO NOT touch any electrical switch.

• DO NOT use any phone in your building.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the fi re department. -- Installation and service must be performed by a qualifi ed installer, service agency or the gas supplier.

LOCAL INSPECTOR’S USE. Fire safety WARNING Use this appliance only for its intended use as described in this manual. Always have a working smoke detector near the kitchen. In the event that personal clothing or hair catches fi re, drop and roll immediately to extinguish fl ames. Have an appropriate fi re extinguisher available, nearby, highly visible and easily accessible near the appliance. Smother fl ames from food fi res other than grease fi res with baking soda. Never use water on cooking fi res. WARNING TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A RANGE TOP GREASE FIRE, OBSERVE THE FOLLOWING:

a. SMOTHER FLAMES with a close-fi tting lid, cookie sheet, or metal tray, then turn off the burner. BE CAREFUL TO PREVENT BURNS. If the fl ames do not go out immediately, EVACUATE AND CALL THE FIRE DEPARTMENT. b. NEVER PICK UP A FLAMING PAN – You may be burned. c. DO NOT USE WATER, including wet dishcloths or towels – a violent steam explosion will result. d. Use an extinguisher ONLY if: - You know you have a Class ABC extinguisher, and you already know how to operate it. - The fi re is small and contained in the area where it started. - The fi re department is being called. - You can fi ght the fi re with your back to an exit.

Based on “Kitchen Fire Safety Tips” published by NFPA.English 5 Whenever possible, do not operate the ventilation system during a cooktop fi re. However, do not reach through fi re to turn it off. WARNING

When gas burners are in operation without any cookware placed on them, they can build up a lot of heat. A ventilation appliance installed above the cooker may become damaged or catch fi re. Only operate the gas burners with cookware on them. WARNING

Hot oil and fat catch fi re fast. Never leave hot oil and fat unsupervised. Never extinguish a fi re with water. Switch off the burner or element. Suffocate fl ames carefully with a lid, a fi re blanket or similar. WARNING

Grease deposits in the grease fi lters can catch fi re. Never work with a naked fl ame near the appliance (e.g. fl ambéing). Install the unit near a heat-producing appliance for solid fuels (e.g. wood or coal) only if there is a closed, non-detachable cover. There must be no fl ying sparks. Clean the grease fi lters at least every two months, or as frequently as necessary. Never operate the appliance without the grease fi lters. WARNING

The accessible parts get hot during operation. Never touch hot parts.

IMPORTANT SAFETY INSTRUCTIONS

READ AND SAVE THESE INSTRUCTIONS

Child safety When children become old enough to use the appliance, it is the responsibility of the parents or legal guardians to ensure that they are instructed in safe practices by qualifi ed persons. Do not allow anyone to climb, stand, lean, sit, or hang on any part of an appliance. This can damage the appliance or cause injury. WARNING Be sure the entire appliance (including the grease fi lters and light bulbs, if applicable) has cooled and grease has solidifi ed before attempting to clean any part of the appliance. Do not use steam cleaners to clean the appliance. State of California Proposition 65 Warnings WARNING This product may contain a chemical know to the State of California, which can cause cancer or reproductive harm. Therefore, the packaging of your product may bear the following label as required by California: STATE OF CALIFORNIA PROPOSITION 65 WARNING: WARNING Cancer and Reproductive Harm - www.P65Warnings.ca.govEnglish 6 Operation and maintenance This appliance is intended for normal family household use only. It is not approved for outdoor use. See the Statement of Limited Product Warranty on pages 18 and

19. If you have any questions, contact the manufacturer.

Do not store or use corrosive chemicals, vapors, fl ammables or nonfood products in or near this appliance. It is specifi cally designed for use when heating or cooking food. The use of corrosive chemicals in heating or cleaning will damage the appliance and could result in injury. Do not operate this appliance if it is not working properly, or if it has been damaged. Contact an authorized servicer. Do not repair or replace any part of the appliance unless specifi cally recommended in this manual. Refer all servicing to a factory authorized service provider. WARNING Improper installation of gas appliances and ventilation hoods can create a risk for carbon monoxide which can be harmful. To reduce the risk of carbon monoxide poisoning, ensure the gas appliance is properly installed according to the manufacturer’s instructions, as well as ensuring the hood is vented to the outside for proper exhausting of gases or fumes. Refer to local building codes for latest requirements and restrictions when installing ventilation products in recirculation mode. CAUTION Grease left on fi lters can melt and move into the vent and catch fi re. WARNING Hidden surfaces may have sharp edges. Use caution when reaching behind, in or under appliance. WARNING Tie long hair so that it does not hang loose, and do not wear loose fi tting clothing or hanging garments, such as ties, scarves, jewelry, or dangling sleeves. WARNING When the hood is operated in exhaust-air mode simultaneously with a different appliance which also makes use of the same chimney (such as gas, oil or coal- fi red heaters, continuous-fl ow heaters, hot-water boilers) care must be taken to ensure that there is an adequate supply of fresh air which will be needed by the appliance for combustion. This can be achieved if combustion air can fl ow through non-lockable openings, e.g. in doors, windows and via the air-intake/exhaust-air wall box or by other technical measures, such as reciprocal interlocking, etc. WARNING Avoid carbon monoxide poisoning – Make sure there is adequate make up air so that combustion gases are extracted

NOTE: When assessing the overall requirement, the combined ventilation system for the entire household must be taken into consideration. This rule does not apply to the use of cooking appliances, such as cooktops and ovens.

IMPORTANT SAFETY INSTRUCTIONS

READ AND SAVE THESE INSTRUCTIONSEnglish 7 Causes for damages NOTICE Risk of damage due to corrosion. Always turn appliance on when cooking to avoid condensation buildup. Condensation can lead to corrosion damage. Risk of damage due to moisture entering into the electronic circuitry. Never clean the touch control panel with a wet cloth. Surface damage due to incorrect cleaning. Clean stainless steel surfaces in the grain direction only. Do not use any stainless steel cleaners on operator controls. Never use strong or abrasive cleaning agents, since they can cause surface damage. Home Connect User’s Information Wi-Fi

Module FCC/IC Statements CMIIT ID: 2017AJ4134 (M) FCC: 2AHES-COM2 IC: 21152-COM2 The Home Connect module is a communication device designed to provide communication between appliances and smart devices. This module is integrated at the factory, under direct control of BSH Home Appliances Corporation, and is not user serviceable or upgradable. At least 20 cm separation distance should be maintained from device to user.

FCC COMPLIANCE STATEMENT

CAUTION: Changes or modifi cations not expressly approved could void your authority to use this equipment. This device complies with Part 15 of the FCC Rules. Operation to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

INDUSTRY CANADA STATEMENT

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.English 8 OPERATING MODES You can use this appliance in the air extraction or the recirculation mode. NOTE: All openings in ceiling and wall where the hood will be installed must be sealed. Fan operation The air that is drawn in is cleaned by the grease fi lters and exhausted outdoors by a ductwork. NOTE: Ventilation may not exit through an already operational smoke or exhaust chimney, nor a duct used for ventilating furnace installation areas.

If the ventilation is intended to pass through a smoke or exhaust chimney that is not in operation, the responsible area heating inspector must give approval.

If the ventilation passes through an external wall, use a telescopic wall sleeve. Recirculating mode The air that is drawn in is cleaned by the grease fi lters and activated carbon fi lters and returned back into the kitchen. WARNING Improper installation of gas appliances and ventilation hoods can create a risk for carbon monoxide which can be harmful. To reduce the risk of carbon monoxide poisoning, ensure the gas appliance is properly installed according to the manufacturer’s instructions, as well as ensuring the hood is vented to the outside for proper exhausting of gases or fumes. Refer to local building codes for latest requirements and restrictions when installing ventilation products in recirculation mode. Recirculating mode fi lters To bind odors in recirculating mode, charcoal fi lters must be installed. The required charcoal fi lter kits are available for purchase from specialist retailers, from customer service or from the Online Shop. See table below to fi nd out the fi lter kit part number corresponding to the unit model. Unit Model Charcoal Filter Kit HUI34253UC

1. Remove the grease fi lters from the hood. Install a charcoal

fi lter (included in the charcoal fi lter kit) on each metal grease fi lter back (A). Hold the charcoal fi lter in place by inserting both ends of 2 metal strips (included in the charcoal fi lter kit) in each metal grease fi lter frame slot (B).

2. Reinstall the grease fi lters by simultaneously using your

other hand to grasp under the metal grease fi lter, then fl ip metal grease fi lter up and snap the latch into place. UNIT OVERVIEW Refer to the illustration at right to identify the parts of your appliance: A: Filters B: LED modules C: Touch control panel.

ON/OFF ON/OFF Touch ON/OFF once to turn the blower off and reset the control. 1 – BOOST Fan Speed Increases or decreases the blower speeds. The chosen blower speed LED will remain illuminated while in operation. 1 – Low 2 – Medium 3 – Medium/High boost – High Boost: When blower is working, delay and boost are deactivated, short pressing boost button enable boost function. When boost is activated, the bar above this button is illuminated and blower is working at speed level 4 for additional 5 minutes. After 5 minutes, unit returns to previous speed level. When boost is activated: (1) Pressing boost button can return to previous speed level. (2) Pressing manual speed deactivates boost and selects the manual speed level. (3) Pressing delay can cause an inactive tone to sound. (4) Pressing on/off button turns off boost and return to standby mode. DELAY Delay Shut Off If the blower is off when the DELAY button is pressed, the blower will turn on to speed 3 setting for 10 minutes. Once time has elapsed, the blower will automatically turn off. If the blower is on when the DELAY button is pressed, the blower runs for 10 minutes from the time the DELAY button was pressed at the current speed then turns off. During the 10 minute timed period, the DELAY button is illuminated. To interrupt a timed period, press one of the fan speed buttons or “on/off” button to turn off. Ability to choose a different time period and speed than the default setting is possible through the Home Connect™ app in the settings menu. GREASE FILTER Clean Grease Filter Reminder After 40 hours of operation, the GREASE FILTER button will illuminate indicating that the fi lters need to be cleaned. When this indicator illuminates, clean the fi lters. After cleaning, press and hold the GREASE FILTER button for 3 seconds until it beeps to reset the 40-hour period and to turn the reminder off. Receive clean fi lter reminder notifi cation through the Home Connect™ app when activated in settings section, as well as see fi lter saturation status. CHARCOAL FILTER Charcoal Filter Replacement Reminder After 120 hours of operation, the CHARCOAL FILTER button will illuminate indicating that the fi lters need to be changed. When this indicator illuminates change the fi lters. After changing, press and hold the CHARCOAL FILTER button for 3 seconds until it beeps to reset the 120-hour period and to turn the reminder off. Receive clean fi lter reminder notifi cation through the Home Connect™ app when activated in settings section, as well as see fi lter saturation status. CONNECT Home Connect™ This function allows the user to connect the hood with a mobile device. See “With the Home Connect™ feature” on page 11. Control tone To turn OFF/ON the control tone, hold the ON/OFF and DELAY button for 3 seconds. Control tone can also be turned OFF/ON through the settings section of the Home Connect™ app. LIGHTS LED Light Control This button controls the LED lighting. The fi rst press turns the lights on. A second press dims the lights. A third press turns the lights off. 0-100% light slider in Home Connect™ app allows additional control to obtain the perfect level of light.English 10 OPERATION OF THE HOOD, HOW TO USE IT Notes

• The blower should be turned on for about 5 minutes before cooking in order to establish air currents upward through the hood. Thus when heat, smoke, moisture, grease and cooking odors are produced, they will be carried outside instead of drifting into other rooms.

• Use the low speeds for normal use and the higher speeds for strong odors or fumes.

• Drafts across the range or cooktop will reduce the effectiveness of the hood. Such drafts should be prevented when possible.

• The best job of ventilation in the kitchen is done where the only air currents are those created by the blower itself.

• Regular use of the fan system while cooking helps keep the kitchen comfortable and less humid.

• Use a rear burner when browning or pan frying meat.

• For optimal performance, the width of the hood should equal that of the cooktop or rangetop or exceed it by 3 inches (76,2 mm) on either side. Environmental protection Your new appliance is particularly energy-effi cient. Here you can fi nd tips on how to save even more energy when using the appliance, and how to dispose of your appliance properly. Saving energy

• During cooking, ensure that there is a suffi cient supply of air to enable the hood to work effi ciently and with a low level of operting noise.

• Adjust the fan speed to the amount or steam produced during cooking. Only use boost mode when required. The lower the fan speed, the less energy is consumed.

• If cooking produces large amount of steams, select a higher fan speed in good time. If the cooking steam has already spread around the kitchen, the hood will need to be operated for longer.

• Switch off the hood if you no longer require it.

• Switch off the lighting if you no longer require it.

• Clean and (if required) replace the fi lters at regular intervals in order to increase the effectiveness of the ventilation system and to prevent the risk of fi re.

• Put the lid on to reduce cooking steam and condensation.English 11

WITH THE HOME CONNECT™ FEATURE

With Home Connect™, the appliance is Wi-Fi-capable and can be remotely controlled using a mobile device (e.g. tablet PC, smartphone). Home Connect™ app offers additional functions which are a perfect complement to the networked appliance. Home Connect™ does not work over Wi-Fi networks that require browser registration, i.e. a user name and password entered via a web browser. You should have a stable wireless network with good reception and access to the internet. If the appliance is not connected to the WLAN network (home network), it functions in the same way as a typical hood with no network connection and can be operated as usual via the Touch Panel. NOTE: Please ensure that you follow the safety instructions given at the beginning of this instruction manual and that these are also observed when operating the appliance via the Home Connect™ app and when away from home. Please also follow the instructions in the Home Connect™ app. NOTE: Operation on the appliance itself always takes priority, and during this time it is not possible to operate the appliance using Home Connect™ App. Cooktop-hood sync You can connect this appliance to a matching cooktop (if the cooktop supports connection to the hood) and then control the functions of the hood via your cooktop. There are various options for connecting the appliances: Home Connect™ Two appliances can be connected using the Home Connect™ app provided that both appliances are Home Connect™ compatible. Refer to the Home Connect™ documents supplied for more information. Connecting appliances directly If the appliance is connected directly to a cooktop, it cannot be connected to your home network as well. The appliance will function in the same way as a hood that is not connected to the network and you can continue to operate it via the touch control panel. Connecting appliances via your home network If the appliances are connected to each other via your home network, both the hood controls on the cooktop and Home Connect™ can be used to operate the appliance. NOTES:

• Make sure you follow the safety instructions in the instruction manual for your hood and that these are complied with even when operating the appliance via the hood controls on the cooktop.

• If the hood is being operated by means of the touch control panel on the hood itself, this mode of operation always has priority. It is not possible to use the hood controls on the cooktop during this time. Setting up a connection To set up the connection between the hood and the cooktop, the hood must be switched off and the cooktop must be switched on before you can connect the cooktop and hood. Connecting directly Ensure that the cooktop is switched on and is in search mode. To do this, refer to the section entitled “Connecting to the hood” in the instruction manual for your cooktop. NOTES

• If your hood is connected directly to the cooktop, it cannot be connected to your home network as well and you will not be able to use Home Connect™.

• The cooktop must not be connected to your home network. To break a connection, follow the instructions in the section entitled “Disconnecting from the network”. Press and hold the CONNECT button until it starts to fl ash. The hood has been connected to the cooktop when the CONNECT button stops fl ashing and remains continuously lit. Connecting via your home network Follow the instructions in the section entitled “Connecting your hood to your home network (Wi-Fi)” on page 12. Once the hood is connected to your home network, you can connect to the hob via the Home Connect™ app. To do this, follow the instructions on your mobile device. Setting up To implement settings via Home Connect™, you must have installed the Home Connect™ App on a mobile device (e.g. tablet PC, smartphone). Follow the steps specifi ed by the app to implement the settings. What do you need to connect your hood to Home Connect™?

• Your smartphone or tablet PC must be running the latest version of the operating system it uses.

• A home network signal (Wi-Fi) at the location where the home appliance is located.

• Name and password for your home network (Wi-Fi): (SSID):.......................................................................... Password:..................................................................... Step 1: Installing the Home Connect™ app

1. On your smartphone or tablet PC, go to the App Store

3. Select the “Home Connect (America)” app published by

BSH Home Appliances Corporation and install it on your smartphone or tablet.English 12

WITH THE HOME CONNECT™ FEATURE

4. Open the Home Connect™ app and press “Register” to

create a new Home Connect™ account. The app will guide you through the registration process. Don’t forget to make a note of your e-mail address and password afterwards. Save your Home Connect™ login details here: Email:......................................................................... Password:.................................................................. Step 2 (initial start-up): Connecting your hood to your home network (Wi-Fi) A. Connect the appliance. B. Check whether your home network router has A WPS function (automatic connection) and locate the WPS button. Refer to the router manual for more information. C. Does your router have a WPS function (automatic connection)? Now go on to Step 2.1 – Yes Automatic connection (WPS Connection). Now go on to Step 2.2 –

Manual connection (Professional mode). Step 2.1: Connect to your home network (Wi-Fi) via WPS

• Press SPEED 1 button.

• CONNECT and SPEED 1 buttons fl ash.

• WPS connection process started. A. NOTE: To connect the hood to your home network, the hood and the light must be switched off. You can cancel the process at any time by pressing “0”. B. Press and hold the “CONNECT” button until “0” and “CONNECT” start fl ashing. C. Press “1”. NOTE: “1” and “CONNECT” will fl ash. D. If you have WPS, press the WPS button on your router. NOTE: Please consult your router’s manual to locate the WPS button. E. When “CONNECT” and “3” fl ashes your appliance is connected to the home network. Go on to step 3. Step 2.2: Manually connecting your hood to your home network (Wi-Fi) Before connecting make sure you have opened the Home Connect app and created an account. A. NOTE: To connect the hood to your home network, the hood and the light must be switched off.You can cancel the process at any time by pressing “0”. B. Press and hold the “CONNECT” button until it starts fl ashing. C. Press “2”. NOTE: “2” and “CONNECT” will start fl ashing. D. Follow directions in the Home Connect app. You will be directed to connect to network named “HomeConnect”. This is your hoods Wi-Fi-network. Use the following login information to connect: Wi-Fi-Name/SSID: HomeConnect Password/Key: HomeConnect E. Open the Home Connect™ App on your mobile device. F. The app will prompt you to enter your home Wi-Fi’s network name and password. NOTE: The app may take a few minutes to fi nd your hood. G. Next, follow directions in the App. H. When “CONNECT” and Fan Setting “3” fl ashes your appliance is connected to the home network. Go on to step 3. Error: If the “CONNECT” and “2” light fl ashes then the hood could not establish a connection with your home Wi-Fi within 2 minutes. Fix: Check whether your hood is in range of your Wi-Fi and repeat the process. If unsuccessful, refer to step 2.2 to connect the hood manually. Error: The appliance fails to connect to the app (The “CONNECT” light will turn off). Fix: Ensure your smartphone or tablet is connected to the same home network (Wi-Fi). Check that your wireless connection is stable and has a strong signal. Then repeat the process from step 2.English 13

WITH THE HOME CONNECT™ FEATURE

Step 3: Connecting your hood to another Home Connect™ account A. Open general settings on your mobile device and then open Wi-Fi settings. Connect to the same home network (Wi-Fi) as the hood. B. Press and hold the “CONNECT” button until the “CONNECT” and 3 buttons start fl ashing. C. Open the app on your mobile device and follow the instructions. D. The registration process is complete once “CONNECT” stops fl ashing on the hood. Software update Using the software update function, your hood’s software can be updated (e.g. for the purpose of optimization, troubleshooting or security updates). To do this, you need to be a registered Home Connect™ user, have installed the app on your mobile device and be connected to the Home Connect™ server. As soon as a software update is available, you will be informed through the Home Connect™ app and will be able to start the software update via the app. Once the update has been successfully downloaded, you can start installing it via the Home Connect™ app if you are on your local area network. The Home Connect™ app will inform you once installation is complete. NOTES

• You can continue to use your hood as normal while updates are downloading.

• Depending on your personal settings in the app, software updates can also be set to download automatically.

• We recommend that you install security updates as soon as possible. Resetting the connection You can reset the connections you have saved on your home network and on Home Connect™ at any time.

• Press and hold the 0 and CONNECT buttons at the same time until the CONNECT symbol is no longer illuminated. If you want to change the wireless home network that is connected to the hood, reset the connection to your hood by: A. Press and hold the “CONNECT” and fan setting “0” buttons on your hood for at least 3 seconds. The “CONNECT” button will turn off. B. Repeat the process from step 2. About Data Protection When your appliance is connected for the fi rst time to a WLAN network, which is connected to the Internet, your appliance transmits the following categories of data to the Home Connect™ server (initial registration):

• Unique appliance identifi cation (consisting of appliance codes as well as the MAC address of the installed Wi-Fi communication module).

• Security certifi cate of the Wi-Fi communication module (to ensure a secure IT connection).

• The current software and hardware version of your domestic appliance.

• Status of any previous resetting to factory settings. This initial registration prepares the Home Connect™ functions for use and is only required when you want to use these Home Connect™ functions for the fi rst time. NOTE: Ensure that the Home Connect™ functions can be used only in conjunction with the Home Connect™ app. Information on data protection can be accessed in the Home Connect™ app.English 14

CLEANING AND MAINTENANCE

WARNING: To avoid risk of fi re and explosion,

do not use fl ammable liquids or solvents. Always switch power off at the service panel and lock the panel to prevent the power from being switched on accidentally. Do not use steam cleaners to clean the appliance. Hidden surfaces may have sharp edges. Use caution when reaching behind, in or under appliance.

WARNING: RISK OF ELECTRIC SHOCK

Moisture penetration can cause electric shock. Only clean appliance with a damp cloth. Prior to cleaning, switch power off at the service panel and lock the panel to prevent the power from being switched on accidentally. Cleaning agents To prevent various surfaces from becoming damaged due to incorrect cleaning agents, follow the specifi cations given in the table. Do not use:

• cleaning agents that are harsh or scouring,

• cleaning agents with high alcohol content,

• hard scouring pads or sponges,

• high-pressure cleaners or steam cleaners. Thoroughly rinse all new sponges before use. Observe all instructions and warnings accompanying cleaning agents. Area Cleaning agents Stainless steel Warm soapy water: Clean with a non-abrasive, non- sponge dish towel and dry with a clean, soft towel. Clean stainless steel surfaces in the grain direction only. Stainless steel care (such as the Bosch Stainless Steel Conditioner #00576696 is available for purchase from customer service). (Not to be used with black steel.) Apply a thin layer of the care product with a soft cloth. Painted surfaces Warm soapy water: Clean with a non-abrasive, non- sponge dish towel and dry with a clean,soft towel. Do not use stainless steel cleaner. Aluminum and plastic Glass cleaner: Clean with a soft cloth. Glass Glass cleaner: Clean with a soft cloth. Do not use a glass scraper. Controls Warm soapy water: Clean with a non-abrasive, non- sponge dish towel and dry with a clean, soft towel. Risk of damage to electronics due to moisture penetration. Never clean controls with a wet cloth. Do not use stainless steel cleaner.English 15

CLEANING AND MAINTENANCE

Cleaning the metal grease fi lters

WARNING: RISK OF FIRE

Grease deposits in the grease fi lters can ignite. Clean the grease fi lters at least every two months, or as frequently as necessary. Never operate the appliance without the grease fi lters.

Do not reach inside the hood, there can be sharp points and hidden edges. NOTES

• Do not use any aggressive, acidic or alkaline cleaning agents.

• When cleaning the metal grease fi lters, also clean the metal grease fi lter holder in the appliance with a moist cloth.

• You can clean the metal grease fi lters in a dishwasher or by hand. Uninstalling metal grease fi lters

1. For each fi lter, open the latch and fold down the metal

grease fi lter. Simultaneously use your other hand to grasp under the metal grease fi lter.

2. Remove the metal grease fi lter from its mounting.

• Grease can gather in the bottom of the metal grease fi lters.

• Hold metal grease fi lters horizontally to prevent grease from dripping.

3. Clean metal grease fi lters.

By hand: NOTE: You can use a special grease solvent if soiling is stubborn. You can order it via the online shop.

• Soak the metal grease fi lters in hot soapy solution.

• Use a brush for cleaning and then rinse the fi lters well.

• Allow the metal grease fi lters to drip dry. In the dishwasher: NOTE: Slight discoloration is possible when cleaning the grease fi lters in the dishwasher. This does not affect the metal grease fi lter’s functioning.

• Do not clean extremely dirty metal grease fi lters with dishes.

• Loosely position the metal grease fi lter in the dishwasher. The metal grease fi lters must not be jammed in. Reinstalling metal grease fi lters

1. Insert each metal grease fi lter and simultaneously use your

other hand to grasp under the metal grease fi lter.

2. Flip metal grease fi lter up and snap the latch into place.English 16

TROUBLESHOOTING You can often easily eliminate issues that may occur on your own. Before calling customer service, take into account the following information.

WARNING: RISK OF ELECTRIC SHOCK

Improper repairs are dangerous. Only an authorized servicer provider may perform repairs and may replace damaged connecting leads. Remove the fuse or deactivate the breaker in the fuse box or breaker box if the appliance is damaged. Call Customer Service. Disruption Possible Cause Solution The hood is not venting properly

• The hood may be too high above the cooktop.

• The hood may not be centered above the cooktop.

• Make up air not suffi cient.

• The wind from opened windows in the surrounding area is affecting the ventilation of the hood. Close all the windows to eliminate the outside air fl ow.

• Blockage in the duct opening or ductwork. Remove all blockage from the ductwork or duct opening.

• Duct length too long, too many elbows, “back to back” elbows, or too small roof or wall cap, will all cause issues with air draw. Fault tone • Two short beeps will sound whenever the pressing of a button by the user results in a possible function that is not possible by the system. The beep tone can be disabled by pressing the FILTER and LIGHTS buttons simultaneously for at least 3 seconds. Pressing the FILTER and LIGHTS buttons simultaneously when the beep sound is turned off will turn on the beep sound. Lighting not working. LED lighting module have failed The LED modules are replaceable by an authorized service provider only. See the support contact information in Customer Service section. Disruption Possible Cause and Solution Noise during operation Some noise is normal due to vibration and air movement.

• Excessive noise could indicate one of the following: -- ductwork is too small / undersized -- ductwork is too large / oversized -- ductwork is loose -- transition is too small or is loose -- wood screws are not fully tightened -- loose screws in trim parts, etc. Check installation manual to verify that ductwork is the proper size. Tighten screws. Noise when unit is off.

• Backfl ow fl ap on outside of duct wall cap moves with the wind. This is normal. Lights and fan blower do not work

• Hood circuit breaker may be tripped. Reset breaker. Fan blower does not work.

• Power supply is insuffi cient.

• Electrical wiring is incorrectly connected. See the installation manual for more information. Hood trips breaker.

• Electrical wiring is incorrectly connected.

• Circuit is not suffi cient.English 17 Before calling service First, refer to the troubleshooting section. Refer to the “Statement of Limited Product Warranty”. To reach a service representative, see the contact information at right. Please be prepared with the information printed on your product rating plate when calling. Rating plate The rating plate shows the model and serial number. Refer to the rating plate on the appliance when requesting service. The rating plate can be found inside the hood shell. To avoid having to search for each piece of information when calling, you can enter the four items needed in the spaces below. Keep your invoice or escrow papers for warranty validation if service is needed. Service We realize that you have made a considerable investment in your kitchen. We are dedicated to supporting you and your appliance so that you have many years of creative cooking. Please don’t hesitate to contact our Customer Support Department if you have any questions or in the unlikely event that your Bosch

appliance needs service. Our service team is ready to assist you. USA 800-944-2904 www.bosch-home.com/us/support Canada 800-944-2904 www.bosch-home.ca/en/support Parts and accessories Parts, fi lters, descalers, stainless steel cleaners and more can be purchased in the Bosch

eShop or by phone. USA www.bosch-home.com/us/shop Canada www.bosch-home.ca/en/service/cleaners-and-accessories BOSCH

SUPPORT Model No. / FD date 4 digits Serial No. 18 digits Date of Purchase / /English 18 What this Warranty Covers & Who it Applies to The limited warranty provided by BSH Home Appliances (“Bosch“) in this Statement of Limited Product Warranty applies only to the Bosch appliance sold to you (“Product“), provided that the Product was purchased:

For your normal, household (non-commercial) use, and has in fact at all times only been used for normal household purposes.

New at retail (not a display, “as is”, or previously returned model), and not for resale, or commercial use.

Within the United States or Canada, and has at all times remained within the country of original purchase. The warranties stated herein apply to the original purchaser of the product warranted herein and to each succeeding owner of the product purchased for ordinary home use during the term of the warranty. Please make sure to return your registration card; while not necessary to effectuate warranty coverage, it is the best way for BSH to notify you in the unlikely event of a safety notice or product recall. How Long the Warranty Lasts Bosch warrants that the Product is free from defects in materials and workmanship for a period of three hundred sixty-fi ve (365) days from the date of the original purchase. The foregoing timeline begins to run upon the date of the original purchase, and shall not be stalled, tolled, extended, or suspended, for any reason whatsoever. This Product is also warranted to be free from cosmetic defects in material and workmanship (such as scratches of stainless steel, paint/porcelain blemishes, chip, dents, or other damage to the fi nish) of the Product, for a period of thirty (30) days from the date of purchase or closing date for new construction. This cosmetic warranty excludes slight color variations due to inherent differences in painted and porcelain parts, as well as differences caused by kitchen lighting, product location, or other similar factors. This cosmetic warranty specifi cally excludes any display, fl oor, “As Is”, or “B” stock appliances. Repair/Replace as Your Exclusive Remedy During this warranty period, Bosch or one of its authorized service providers will repair your Product without charge to you (subject to certain limitations stated herein) if your Product proves to have been manufactured with a defect in materials or workmanship. If reasonable attempts to repair the Product have been made without success, then Bosch will replace your Product (upgraded models may be available to you, in Bosch’s sole discretion, for an additional charge). Nothing in this warranty requires damaged or defective parts to be replaced with parts of a different type or design than the original part. All removed parts and components shall become the property of Bosch at its sole option. All replaced and/or repaired parts shall assume the identity of the original part for purposes of this warranty and this warranty shall not be extended with respect to such parts. Bosch’s sole liability and responsibility hereunder is to repair manufacturer-defective Product only, using a Bosch-authorized service provider during normal business hours. For safety and property damage concerns, Bosch highly recommends that you do not attempt to repair the Product yourself, or use a non-authorized service provider; Bosch will have no responsibility or liability for repairs or work performed by a non-authorized service provider. Authorized service providers are those persons or companies that have been specially trained on Bosch products, and who possess, in Bosch’s opinion, a superior reputation for customer service and technical ability (note that they are independent entities and are not agents, partners, affi liates or representatives of Bosch). Notwithstanding the foregoing, Bosch will not incur any liability, or have responsibility, for the Product if it is located in a remote area (more than 100 miles from an authorized service provider) or is reasonably inaccessible, hazardous, threatening, or treacherous locale, surroundings, or environment; in any such event, if you request, Bosch would still pay for labor and parts and ship the parts to the nearest authorized service provider, but you would still be fully liable and responsible for any travel time or other special charges by the service company, assuming they agree to make the service call. STATEMENT OF LIMITED PRODUCT WARRANTYEnglish 19 Out of Warranty Product BSH is under no obligation, at law or otherwise, to provide you with any concessions, including repairs, prorates, or Product replacement, once this warranty has expired. Warranty Exclusions The warranty coverage described herein excludes all defects or damage that are not the direct fault of Bosch, including without limitation, one or more of the following:

Use of the Product in anything other than its normal, customary and intended manner (including without limitation, any form of commercial use, use or storage of an indoor product outdoors, use of the Product in conjunction with air or water-going vessels).

Any party’s willful misconduct, negligence, misuse, abuse, accidents, neglect, improper operation, failure to maintain, improper or negligent installation, tampering, failure to follow operating instructions, mishandling, unauthorized service (including selfperformed “fi xing” or exploration of the appliance’s internal workings).

Adjustment, alteration or modifi cation of any kind.

A failure to comply with any applicable state, local, city, or county electrical, plumbing and/or building codes, regulations, or laws, including failure to install the product in strict conformity with local fi re and building codes and regulations.

Ordinary wear and tear, spills of food, liquid, grease accumulations, or other substances that accumulate on, in, or around the Product.

Any external, elemental and/or environmental forces and factors, including without limitation, rain, wind, sand, fl oods, fi res, mud slides, freezing temperatures, excessive moisture or extended exposure to humidity, lightning, power surges, structural failures surrounding the appliance, and acts of God.

Service calls to correct the installation of your Product, to instruct you how to use your Product, to replace house fuses or correct house wiring or plumbing. In no event shall Bosch have any liability or responsibility whatsoever for damage to surrounding property, including cabinetry, fl oors, ceilings, and other structures or objects around the Product. Also excluded from this warranty are Products, on which the serial numbers have been altered, defaced, or removed; service visits to teach you how to use the Product, or visits where there is nothing wrong with the Product; correction of installation problems (you are solely responsible for any structure and setting for the Product, including all electrical, plumbing or other connecting facilities, for proper foundation/fl ooring, and for any alterations including without limitation cabinetry, walls, fl oors, shelving, etc.); and resetting of breakers or fuses. TO THE EXTENT ALLOWED BY LAW, THIS WARRANTY

WILL THE MANUFACTURER BE LIABLE FOR

CONSEQUENTIAL, SPECIAL, INCIDENTAL, INDIRECT, “BUSINESS LOSS”, AND/OR PUNITIVE DAMAGES,

LOSSES, OR EXPENSES, INCLUDING WITHOUT

LIMITATION TIME AWAY FROM WORK, HOTELS

AND/OR RESTAURANT MEALS, REMODELLING

INCIDENTAL OR CONSEQUENTIAL DAMAGES, AND

SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE

ABOVE EXCLUSIONS OR LIMITATIONS MAY NOT

APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE No attempt to alter, modify or amend this warranty shall be effective unless authorized in writing by an offi cer of BSH. Obtaining Warranty Service: To obtain warranty service for your product, you should contact Bosch Customer Service at 1-800-944-2904 to schedule a repair.Français 20
