Retro TR9150 - Toaster RUSSELL HOBBS - Free user manual and instructions

Product type	Toaster
Brand	Russell Hobbs
Model	Retro TR9150
Color	Retro, chrome finish and cream white
Dimensions (L x W x H)	Approximately 30 x 20 x 18 cm
Weight	Approximately 1.5 kg
Power supply	Mains 220-240 V ~ 50/60 Hz, estimated power 800 W
Number of slots	2 wide slots (25 mm max)
Browning control	6 levels (1 = light, 6 = dark)
Special functions	Frozen, Bagel, Warming rack, Emergency stop
Display	Toasting time gauge with countdown
Crumb tray	Removable drawer (ref. TR9150-01)
Warming rack	Removable rack for small buns (ref. TR9150-02)
Housing material	Stainless steel and plastic
Safety	Automatic shut-off, polarized plug, captive screw, overheat protection
Care and cleaning	Wipe with a damp cloth; unplug before cleaning; removable crumb tray
Included accessories	Warming rack, crumb tray
Warranty	2 years (additional 1 year upon online registration in Canada)
Customer service	1-800-947-3744

Frequently Asked Questions - Retro TR9150 RUSSELL HOBBS

How to clean the toaster?

Unplug the appliance and let it cool. Wipe the external surfaces with a damp cloth. The removable crumb tray should be emptied regularly. Never immerse the toaster in water.

How to use the frozen function?

Place the frozen bread in the slots, set the desired browning level, lower the lever and press the Frozen button. The toasting time adjusts automatically.

How to toast bagels?

Cut the bagel in half and place the halves in the slots, cut sides facing outwards. Set the browning level, lower the lever and press the Bagel button. Only the inner side will be toasted.

What to do if the lever does not stay down?

Check that the toaster is properly plugged in. The lever only locks when the appliance is powered on. If the problem persists, contact customer service.

Can I use the warming rack for frozen buns?

No, the warming rack is designed only for non-frozen, unbuttered, unfilled, unglazed buns. For frozen buns, use the frozen function in the slots.

How to adjust the browning level?

Turn the browning control dial from 1 (light) to 6 (dark) according to your preference. For first use, set to 6 and run empty to condition the heating element.

Why is my bread burning or too pale?

Adjust the browning level. If the bread is too light, increase the setting; if it burns, decrease it. Make sure the bread is not too thick (max 25 mm) and that the slots are not obstructed.

Does the toaster turn off automatically?

Yes, the toaster turns off automatically at the end of the toasting cycle and ejects the bread. You can also interrupt the cycle at any time by pressing the stop button.

How to obtain warranty service?

Keep your receipt as proof of purchase. Contact customer service at 1-800-947-3744 or visit www.prodprotect.com/russellhobbs for more information. Do not return the product to the store.

What to do in case of malfunction?

Unplug the appliance. Check that the plug and cord are not damaged. Do not attempt to repair yourself; contact customer service for assistance from an authorized service center.

USER MANUAL Retro TR9150 RUSSELL HOBBS

Red and silver RoR ball heater with a digital display, no visible text or symbols on the device itself.

instructions

2

mode d'emploi 8

14

instrucciones

Please Read and Save this Use and Care Book.

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed, including the following:

- Read all instructions.

- Do not touch hot surfaces. Use handles or knobs.

- To protect against fire, electric shock and injury to persons do not immerse cord, plugs or appliance in water or other liquid.

- Close supervision is necessary when any appliance is used by or near children.

- Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts, and before cleaning the appliance.

- Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions or has been damaged in any manner. Contact Consumer Support.

- The use of accessory attachments not recommended by the appliance manufacturer may cause injuries.

- Do not use outdoors.

- Do not let cord hang over edge of table or counter, or touch hot surfaces.

- Do not place on or near a hot gas or electric burner, or in a heated oven.

- To disconnect, push ▲ button, then remove plug from wall outlet.

- Do not use this appliance for other than intended use.

- Oversized foods, metal foil packages, or utensils must not be inserted in a toaster, as they may create a risk of fire or electric shock.

- A fire may occur if the toaster is covered or touching flammable material, including curtains, draperies, walls and the like, when in operation.

- Do not attempt to dislodge food when toaster is plugged in.

Warning: To prevent electrical shock, unplug before cleaning.

Warning: To reduce the risk of fire or electric shock, operate with crumb tray in place.

- This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

- Children should be supervised to ensure that they do not play with the appliance.

- The appliance is not intended to be operated by means of an external timer or separate remote-control system.

SAVE THESE INSTRUCTIONS.

This product is for household use only.

POLARIZED PLUG

This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to modify the plug in any way.

TAMPER-RESISTANT SCREW

Warning: This appliance is equipped with a tamper-resistant screw to prevent removal of the outer cover. To reduce the risk of fire or electric shock, do not attempt to remove the outer cover. There are no user-serviceable parts inside. Repair should be done only by authorized service personnel.

ELECTRICAL CORD

a) A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord.
b) Extension cords are available and may be used if care is exercised in their use.
c) If an extension cord is used:

1) The marked electrical rating of the extension cord should be at least as great as the electrical rating of the appliance;
2) If the appliance is of the grounded type, the extension cord should be a grounding-type 3-wire cord; and
3) The cord should be arranged so that it will not drape over the counter top or tabletop where it can be pulled on by children or tripped over.

Note: If the power cord is damaged, please contact the warranty department listed in these instructions.

How to Use

This appliance is for household use only.

GETTING STARTED

• Remove all packing materials, any stickers and the plastic band around the power plug.
  • To register your product, go to www.prodprotect.com/russellhobbs.
• Wash all parts as instructed in CARE and MAINTENANCE section.
• Select a level surface where this unit is to be used allowing enough space for steam to escape without damage to counters, cabinets and walls.
• Set the browning level to maximum (6). Operate the appliance empty, to cure the new elements. This may smell a bit, but it's nothing to worry about. Ensure the room is well ventilated.

PARTS

1. toasting slots
2. warming rack
3. lever
   (part no. TR9150-02)
4. browning control
5. handle
6. crumb tray (part no. TR9150-01)
7. toasting time gauge

TOASTING BREAD

1. Set the toaster upright on a firm, level, heat-resistant surface.
2. Put the plug into the power socket.
3. Turn the browning control to the required setting (1 = light, 6 = dark).
4. Put bread into the toasting slots (maximum thickness 25mm).
5. Press the lever down fully. It won't lock down unless the toaster is connected to the electricity supply.
6. The toasting time gauge will show the toasting time and start to count down.
7. When it reaches 0, the toast will pop up.
8. To stop toasting, press the ▲ button.

FROZEN BREAD

1. Leave the browning control at your favoured setting, insert the frozen bread, lower the lever, then press the button.
2. The light will come on, and the toasting time will be altered automatically to give the same degree of browning you get with unfrozen bread.
3. The toasting time gauge will show the toasting time and start to count down.
4. When it reaches 0, the toast will pop up.

BAGELS

1. Insert cut bagel into the slots with cut side toward the outside of the toaster.
2. Leave the browning control at your favoured setting, lower the lever, then press the button.
3. The toasting time gauge will show the toasting time and start to count down.
4. When it reaches 0, the bagel will pop up.

TOASTING TIME GAUGE

The gauge shows the time it will take to make the toast at the selected browning control setting.

• If you cancel toasting by pressing the button, the gauge will stay at the time it was showing when you pressed the button. If you restart toasting by lowering the lever, the gauge will move to the 6 mark then readjust to show the correct toasting time.
• If you change the position of the browning control during toasting, the gauge will move to the 6 mark then readjust to show the correct toasting time.
• It will also adjust itself automatically when you use the frozen bread or bagel buttons.

WARMING RACK

Note: Don't use the warming rack to warm frozen, buttered, coated, iced, or filled buns.

1. Place the warming rack on top of the toaster, with the feet inside the slots.
2. Place the buns on top of the warming rack.
3. Set the browning level to 2. Then lower the lever.
4. When the lever pops up, remove the warmed buns.
5. Don't touch the warming rack wires – they'll be hot.
6. Remove the warming rack before using the toaster normally.

CARE AND MAINTENANCE

1. Unplug the appliance and let it cool.
2. Wipe outer surfaces with a damp cloth.

NEED HELP?

Warranty Information

(Applies only in the United States and Canada)

For service, repair or any questions regarding your appliance, please call our Customer Service Line at 1-800-947-3744. Please DO NOT return the product to the place of purchase. Also, please DO NOT mail product back to manufacturer, nor bring it to a service center. You may also want to consult www.prodprotect.com/russellhobbs.

What does it cover?

- Any defect in material or workmanship provided; however, the liability of Spectrum Brands, Inc. will not exceed the purchase price of product.

How long is the warranty valid?

- In the United States: Two years from the date of original purchase with proof of such purchase.

- In Canada: Two years from the date of original purchase with proof of such purchase. Canadian residents can register online for an extra year of warranty at: www.prodprotect.com/russellhobbs.

What will we do to help you?

- Provide you with a reasonably similar replacement product that is either new or factory refurbished.

How do you get service?

- Save your receipt as proof of date of sale.

- Visit the online service website at www.prodprotect.com/russellhobbs, or call toll-free 1-800-947-3744, for general warranty service.

- If you need parts or accessories, please call 1-800-738-0245.

What does your warranty not cover?

• Damage from commercial use

- Damage from misuse, abuse or neglect

- Products that have been modified in any way

- Products used or serviced outside the country of purchase

• Glass parts and other accessory items that are packed with the unit

• Shipping and handling costs associated with the replacement of the unit

- Consequential or incidental damages (Please note, however, that some states do not allow the exclusion or limitation of consequential or incidental damages, so this limitation may not apply to you.)

How does state law relate to this warranty?

- This warranty gives you specific legal rights. You may also have other rights that vary from state to state or province to province.

Utilisation

Como Usar

RUSSELL HOBBS and the RH logo are Trademarks of Spectrum Brands, Inc. or one of its subsidiaries. All rights reserved.

© 2017 Spectrum Brands, Inc., Middleton, WI 53562

TR9150BKRC / TR9150RDRC / TR9150BKR / TR9150RDR / TR9150CRR / TR9150WTR 18059-00
