USER MANUAL 103001 PRINCESS

Congratulations! You have purchased a Princess product. Our aim is to provide quality products with a tasteful design and at an affordable price. We hope that you will enjoy this product for many years. The appliance can be used by children from 8 years and above and by persons with a physical, sensory, mental or motorial disability, or lack of experience and knowledge if they are supervised or instructed on how to use the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and maintenance shall not be made by children unless they are older than 8 years and supervised. Keep the appliance and the mains cable out of the reach of children younger than 8 years. Description (fig. A) Your 103001/103002/103003 Princess Table Chef has been designed for frying or grilling food without using fat. The appliance is equipped with a grill plate with a non-stick coating. The appliance is equipped with a thermostat that keeps the grill plate at the required temperature. The appliance is suitable for domestic use only.

Before you proceed, we need you to pay attention to the following notes: - Always fully insert the thermostat into the thermostat socket. Initial use (fig. A) Before you proceed, we need you to pay attention to the following notes: - Make sure that there is sufficient space around the appliance to allow heat to escape and provide sufficient ventilation. Clean the appliance. Refer to the section • "Cleaning and maintenance". Place the appliance on a stable and flat • surface. Insert the thermostat (1) into the • thermostat socket (4). Insert the mains plug into the wall socket.• Set the thermostat dial (2) to the • maximum temperature (210 °C). Wait for a few minutes until the temperature • indicator (3) goes off. The grill plate (5) has reached the required temperature. After use, remove the mains plug from the • wall socket and allow the appliance to cool down completely. Note: If you switch on the appliance for the first time, the appliance may emit a little smoke and a characteristic smell for a short period. This is normal operation. Use Switching on and off (fig. A) To switch on the appliance, insert the • mains plug into the wall socket. The temperature indicator (3) remains on while the grill plate (5) is being heated. The temperature indicator (3) goes off when grill plate (5) has reached the required temperature. While the appliance is switched on, the • temperature indicator (3) will illuminate and extinguish as the thermostat (1) switches on and off to maintain the required temperature. To switch off the appliance, set the • thermostat dial (2) to the minimum temperature (0 °C) and remove the mains plug from the wall socket.8

Setting the temperature (fig. A) Turn the thermostat dial (2) clockwise to • increase the temperature of the grill plate (5). Turn the thermostat dial (2) • counterclockwise to decrease the temperature of the grill plate (5). Hints for use (fig. A) Prepare the ingredients.• Place the appliance on a stable and flat • surface. Clean the grill plate (5) with a soft, damp • cloth. Insert the thermostat (1) into the • thermostat socket (4). Insert the mains plug into the wall socket.• Turn the thermostat dial (2) to set the • required temperature (0-210 °C). Wait for a few minutes until the temperature • indicator (3) goes off. The grill plate (5) has reached the required temperature. Put the food onto the grill plate (5).• Grill the food until it is ready for • consumption. Experiment with the required time and the required temperature to achieve the best results. Note: Small pieces will grill or fry better • and more quickly than large pieces. Turn the food using the spatula (7). Turn • meat and fish only once in order to prevent them from drying out. Do not let metal cutlery touch the grill plate • (5) to prevent damage to the non-stick coating. After use, set the thermostat dial (2) to the • minimum temperature (0 °C). Remove the mains plug from the wall socket.• Remove the thermostat (1) from the • thermostat socket (4). Allow the appliance to cool down • completely. Defrosting food In order to defrost food, put the food on the grill plate. Make sure that the mains plug is not inserted into the wall socket. Defrosting food on the grill plate is considerably faster than defrosting food on, for example, a ceramic or plastic dish. Cleaning and maintenance Before you proceed, we need you to pay attention to the following notes: - Before cleaning or maintenance, remove the mains plug from the wall socket and wait until the appliance has cooled down. - Do not immerse the appliance in water or other liquids. - Do not immerse the thermostat in water or other liquids. Before you proceed, we would like you to focus your attention on the following notes: - Do not use aggressive or abrasive cleaning agents to clean the appliance. - Do not use sharp objects to clean the appliance. Regularly check the appliance for possible • damage. Clean the appliance after each use:• - Remove any residues with a paper towel. - Clean the grill plate with a soft, damp cloth. Thoroughly dry the grill plate with a clean, dry cloth. Thoroughly dry the thermostat socket. - Clean the thermostat with a soft, damp cloth. Thoroughly dry the thermostat with a clean, dry cloth. - Clean the spatula in soapy water. Rinse the spatula under running water. Thoroughly dry the spatula with a clean, dry cloth. Storage Put the appliance and the accessories in • the original packaging. Store the appliance with the accessories in • a dry and frost-free place, out of the reach of children. Safety instructions General safety Read the manual carefully before use. • Keep the manual for future reference. Only use the appliance and the accessories • for their intended purposes.9

Do not use the appliance and the accessories for other purposes than described in the manual. Do not use the appliance if any part or any • accessory is damaged or defective. If a part or an accessory is damaged or defective, it must be replaced by the manufacturer or an authorised repair agent. Children should be supervised to ensure • that they do not play with the appliance. The use of this appliance by children or • persons with a physical, sensory, mental or motorial disability, or lack of experience and knowledge can give cause to hazards. Persons responsible for their safety should give explicit instructions or supervise the use of the appliance. Do not use the appliance near bathtubs, • showers, basins or other vessels containing water. Do not immerse the appliance in water or • other liquids. If the appliance is immersed in water or other liquids, do not remove the appliance with your hands. Immediately remove the mains plug from the wall socket. If the appliance is immersed in water or other liquids, do not use the appliance again. Electrical safety Keep the appliance and the mains cable • out of the reach of children younger than 8 years. Before use, always check that the mains • voltage is the same as the voltage on the rating plate of the appliance. Connect the appliance to an earthed wall • socket. If necessary, use an earthed extension cable of a suitable diameter (at least 3 x 1 mm

For additional protection, install a residual • current device (RCD) with a rated residual operating current that does not exceed 30 mA. The appliance is not intended to be • operated by means of an external timer or separate remote-control system. Only use the appropriate connector to • operate the appliance. Make sure that water cannot enter the • contact plugs of the mains cable and the extension cable. Always fully unwind the mains cable and • the extension cable. Make sure that the mains cable does not • hang over the edge of a worktop and cannot be caught accidentally or tripped over. Keep the mains cable away from heat, oil • and sharp edges. Do not use the appliance if the mains cable • or the mains plug is damaged or defective. If the mains cable or the mains plug is damaged or defective, it must be replaced by the manufacturer or an authorised repair agent. Do not pull the mains cable to disconnect • the mains plug from the mains. Disconnect the mains plug from the mains • when the appliance is not in use, before assembly or disassembly and before cleaning and maintenance. Safety instructions for Table Chef Do not use the appliance outdoors.• Place the appliance on a stable and flat • surface. Place the appliance on a heat-resistant and • splash-proof surface. Do not place the appliance on a hob.• Make sure that there is sufficient space • around the appliance to allow heat to escape and provide sufficient ventilation. Make sure that the appliance does not • come into contact with flammable material. Keep the appliance away from heat sources.• Do not cover the appliance.• Do not use charcoal or similar combustible • fuels. Do not immerse the thermostat in water or • other liquids. Do not remove the thermostat from the water with your hands. Immediately remove the mains plug from the wall socket. If the thermostat is immersed in water or other liquids, do not use the appliance again. Do not let metal cutlery touch the grill • plate to prevent damage to the non-stick coating.10

Beware of steam and splashes when • putting food on the hot grill plate. Caution: Hot grease can splash from the • grill plate. Do not pour cold water onto the hot grill • plate. The water will splash and damage the grill plate. Always be careful when touching the • appliance. Use oven gloves if you need to touch the appliance during or shortly after use. The grill plate becomes very hot during • use. Do not touch the hot grill plate. Only touch the handgrips when the grill plate is hot. The accessible surfaces of the appliance can • become very hot during use. Do not touch the accessible surfaces. Make sure that your hands are dry before • touching the appliance. Do not move the appliance while it is • switched on or is still hot. Remove the mains plug from the wall socket and wait until the appliance has cooled down. Do not use the appliance near birds (e.g. • tropical birds such as parrots). The grill plate is finished with a non-stick coating based on PTFE. Upon heating, the coating may release small amounts of gases which are fully harmless for people. However, the nervous systems of birds are extremely sensitive to these gases. Store the appliance in a dry place when • not in use. Make sure that children do not have access to stored appliances. U.K. Wiring instructions The wires in the mains lead are coloured in accordance with the following code: BLUE NEUTRAL BROWN LIVE

As the colours of the wire in the mains lead of this appliance may not correspond with the colour markings identifying the terminals on your plug, proceed as follows: The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured black. The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured red. The wire which is coloured GREEN/YELLOW must be connected to the terminal which is marked with the letter E or and is coloured GREEN or GREEN/YELLOW. Warning! This appliance must be earthed. Disclaimer Subject to change; specifications can be changed without further notice.11
