20132 - Kettle KORONA - Free user manual and instructions

Brand	Korona
Model	20132
Product type	Electric kettle
Maximum capacity	1.7 L
Minimum capacity	0.5 L
Power	2000-2400 W (estimated)
Power supply	220-240 V ~ 50/60 Hz
Material	Stainless steel and plastic
Dimensions (H x W x D)	Approx. 25 x 15 x 15 cm (estimated)
Net weight	Approx. 0.8-1.2 kg (estimated)
Main functions	Fast boiling, automatic shut-off, overheat protection
Care and cleaning	Clean exterior with damp cloth; descale regularly with vinegar or citric acid
Safety	Automatic shut-off when boiling, dry boil protection
Spare parts and repairability	Parts not specified; contact Korona after-sales service
Warranty	2 years
General information	Household use only. Read the instructions before use.

Frequently Asked Questions - 20132 KORONA

What is the maximum capacity of the Korona 20132 kettle?

The maximum capacity is 1.7 liters, indicated by the MAX mark on the kettle.

How do I descale my Korona 20132 kettle?

Use a mixture of white vinegar and water (1:3) or citric acid. Boil, let it sit, then rinse thoroughly. Repeat if necessary.

Does the kettle turn off automatically when the water boils?

Yes, the kettle has an automatic shut-off when the water reaches boiling.

What should I do if the kettle heats without water?

The kettle is protected against overheating: it turns off automatically. Unplug it and let it cool down before using again.

Can I use the kettle without the lid?

No, it is essential to close the lid during operation to avoid burns from hot water or steam.

How do I clean the inside of the kettle?

Rinse with clean water and use a soft brush on the spout. Avoid abrasive cleaners and the dishwasher.

What is the power of the Korona 20132 kettle?

The power is not explicitly stated, but it is generally between 2000 and 2400 watts.

Does the kettle have a descaling filter?

Yes, a filter is located at the spout to retain limescale deposits.

What is the warranty period?

The kettle has a 2-year warranty against defects in materials and workmanship.

Where can I find Korona after-sales service?

The after-sales service is located in Germany: Korona Service, Am Steinbach 9, 59872 Meschede-Enste. Phone: [phone], email: [e-mail].

USER MANUAL 20132 KORONA

Black and white illustration of a glass teacup with tea leaves on the saucer (no text or symbols)

Exterior view of a modern KORONA water heater with visible branding and price tags (no text-heavy elements)

CE

KORONA electric GmbH, Sundern/Germany

www.korona-electric.de

Before use, please read these instructions carefully and keep them in a safe place for future reference. When passing on the appliance to a third party, make sure to include these instructions for use.

intended for private household use!

Safety:

This symbol warns of hot surfaces. Risk of burns!

This symbol warns of evaporating steam!

General Safety Instructions

caused by incorrect use.

cause injuries to the user.

sure your local voltage matches the technical data of the appliance. Otherwise the appliance may overheat and get damaged.

Caution! Danger of electric shock!

An electric appliance is not a toy!

and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall

supervised.

before cleaning.

surfaces to avoid any damage to the appliance.

cause anyone to trip when in use. Do not allow the cord to hang over sharp edges.

Do not use the appliance,

Special Safety Instructions

Warning! To avoid the possibility of injury/damage to the appliance, electric shock, and risk of burns.

any boiling water from spilling from the kettle. Danger of serious burns!

off the appliance as soon as the boiling temperature has been reached, provided that you have thoroughly closed the lid. Otherwise boiling water could spill.

switch off the kettle, should it accidentally be operated the appliance immediately and let it cool down for approx.

2 3 4 5 6 MAX 1.7L 1.5L 1.0L 0.5L MIN KORONA® 9

Product Description

1. Lid
2. Filter
3. Lid button
4. Water level indicator

5. Kettle

6. Power cord and plug

Before First Use

appliance is complete.

Do not place it on top of a metal surface.

boiling cycle. Do not use this water but pour it away.

Warning: Plastic bags are a danger to toddlers and babies, therefore keep them away to avoid suffocation.

Operation

beverage.

1. Connect it to the mains and switch on the water kettle by
2. As soon as the water boils, the appliance switches off automatically provided that you have thoroughly closed

for use.

in the next boiling cycle. However, always make sure that the water level is not too low.

Always unplug the appliance after use.

Dry-boil cut-out

switch off the kettle automatically, should it accidentally be operated without water or by not observing the minimum

minutes. Afterwards, your kettle is ready for use again.

Cleaning and Care

Before cleaning, always switch off the appliance and disconnect it from the mains and let it completely cool down.

Never immerse the appliance in water. Danger! Electric Shock!

Clean the body of the appliance with a moistened soft cloth.

hard objects to clean the appliance.

running tap water, if necessary, with a soft nylon brush. Dry it

DESCALING

limescale built up in the kettle. To remove limescale, use a common gentle descaler, which is suitable for your appliance.

do not use but pour away. Use fresh water with each boiling cycle. This procedure is necessary to remove any descaler residues in the kettle.

Note: Descaler mixtures should not be poured down enamel coated sinks.

Storage

After use and after the appliance has completely cooled

Keep it away from children and store it in a clean and dry place.

Disposal Instructions

Waste electrical devices marked with this sign must not be disposed of with your household waste, but are to be collected separately. Therefore, please return this device at the end of its life cycle to special collection points for disposal or your local dealer.

boxes are recyclable waste, i.e. they are reusable or recyclable.

Technical Data:

Technical data subject to change!

CE

Guarantee:

This product is guaranteed against defects in materials and workmanship for a period of 2 years.

instructions

This guarantee does not affect your statutory right, nor any legal right you may have as a costumer under applicable national legislation governing the purchase of goods.

guaranteed period, the customer must provide evidence of

The guarantee is to be asserted against

KORONA electric GmbH, Sundern/Germany.

Service Address:

KORONA Service, Am Steinbach 9, 59872 Meschede, Germany

Telephone Hotline: [phone]

Mail: [e-mail]

web: www.korona-electric.de

within 2 years after the date of purchase. In case of guarantee the customer is given the right to get the appliance repaired
