USER MANUAL Superocean GMT Breitling

Close-up of a SuperOcean GMT watch with visible dials and wrist strap (no text or symbols on the watch face itself)

BREITLING 1914 Automatic SOOM M500FT A 24H

Aiguille des heures Hour hand Stundenzeiger Lancetta delle ore Aguja de horas Ponteiro das horas Часовая стрелка 時針 時針 時針

Alguille des minutes Minute hand Minutenzeiger Lancetta dei minuti Aguja de minutos Ponteiro dos minutos Минутная стрелка 分 针 分 针 分 针

Alguille des secondes Seconds hand Sekundenzeiger Lancetta dei secondi Aguja de segundos Ponteiro dos segundos Секундная стрела 19 31 20 21 21 22

PREPARING THE WATCH FOR USE 13

SPECIAL CHARACTERISTICS 14

MAINTENANCE 17

DEUTSCH

INBETRIEBNAHME 21

BESONDERHEITEN 22

WARTUNG 25

ITALIANO

A chronometer is a high-precision instrument that has successfully passed the entire battery of tests imposed by the COSC (Swiss Official Chronometer Testing Institute), a neutral and independent body which individually tests each movement according to the prescriptions in force.

The certification test for wristwatches with sprung balance oscillators, according to the ISO 3159 norm, consists of observing each movement for 15 days and 15 nights, in 5 positions and at 3 different temperatures (8°, 23°C, 38°C). In order to earn the prestigious chronometer label, a movement's performances must meet 7 very strict criteria, including a daily variation in rate ranging between only -4/+6 seconds.

The term “chronometer” should not be confused with that of “chronograph”, which is a complicated watch fitted with an additional mechanism enabling the measurement of the duration of an event. A chronograph is not necessarily chronometer-certified, but all B REITLING chronographs carry the much-coveted title of “chronometers”.

PREPARING THE WATCH FOR USE

WINDING - TIME-SETTING

Nota bene: mechanical watches endowed with a date, day, month or moon-phase indicator are equipped with a complex mechanism that is set into motion between 8 pm and 3 am. It is therefore vital to avoid adjusting the calendar or moving the time backwards during this period.

1. Unscrew the water-resistant crown in an anti-clockwise direction. Wind the watch by 40 clockwise turns of the crown.

1. Pull the crown out to position 2, turn it anti-clockwise to adjust the calendar to the day prior to the date when it is set into operation.

1. Pull the crown out to position 3. Turn the hands so as to make the calendar jump once when the hands pass through midnight. Then adjust the hour and minute.

1. Push the crown back to position 1. Press it gently, turning it gently in a clockwise direction, then tighten it again until you feel some resistance. Do not force!

SPECIAL CHARACTERISTICS

SECOND TIMEZONE

The second, independent hour hand (A) makes a complete sweep of the dial in 24 hours. Its position relative to the 24-hour markings inscribed on the dial rim can serve as a second timezone indication. The hand is reset by pulling the crown out of position 2 and rotating it clockwise.

24H BEZEL

The bidirectional rotating bezel features a 24-hour graduation that may be used as a 3^rd timezone. According to the hour previously selected as the 2^nd timezone, simply line up the hour in the ^35rd timezone indicated on the bezel with the hand (Å).

SPEKTIPL ON A

SUN COMPASS

Your BREITLING chronometer may be used as a sun compass, thus enabling you to determine the Northerly-Southerly direction. For regions that have instated daylight saving time, subtract one hour when directing the watch.

In the Northern hemisphere

Point the hour hand precisely towards the sun. In relation to the watch dial, the point located midway between the current time and 12 o'clock indicates the South, the North being exactly opposite.

In the Southern hemisphere

Point the hour-marker located at 12 o'clock on the dial precisely towards the sun. In relation to the watch dial, the point located midway between the current time and 12 o'clock indicates the North, the South being exactly opposite.

MAINTENANCE

Your BREITLING chronometer is a sophisticated instrument which is constantly subjected to a wide variety of stresses and strains. Within a very small volume, a large number of components contribute to handling all the functions. Their mechanical action inevitably leads to a certain amount of wear and tear, which may be controlled by maintenance consisting of renewing the lubrication and replacing worn components. Like any precision measurement instrument, your watch must be regularly maintained in order to function at its highest level of potential: we recommend a regular service every two years, while the complete overhaul should be scheduled about every five years. Your authorized BREITLING dealer will be pleased to handle this for you.

WATER-RESISTANCE

The movement of your chronometer is protected by a complex case fitted with gaskets to ensure its water-resistance. Under the influence of various external agents – perspiration, chlorinated or salt water, cosmetics, fragrances or dust – these gaskets gradually deteriorate and must be regularly replaced. If used intensively in water, we recommend that this be done once a year as part of a service. If the watch is only occasionally used in water, this operation may be carried out every two years. Moreover, a

water-resistance test should be done every year; it takes only a few minutes and can be performed by your authorized B REITLING dealer.

BREITLING models are water-resistant to varying degrees. The extent of the water-resistance, expressed in meters (M) is a standard value and does not indicate an absolute depth of immersion. The crown and pushpieces must not under any circumstances be operated under water or when the watch is wet. The table below indicates the conditions in which your watch may reasonably be used, according to its degree of water-resistance.

ACTIVITIES/DEGREE OF WATER-RESISTANCE	3bars/30M/100FT 5bars/30M/165FT 10bars/30M/330FT 50bars/500MT/650TT+
Splashing	√	√	√	√
Shower, swimming, surface water sports		√	√	√
Water-skiing, dives, snorkeling			√	√
Diving				√

USEFUL TIPS

BREITLING genuine leather straps are crafted with the most refined materials and represent extremely high-quality products. Like all objects in natural skin (shoes, gloves, etc.), their length of life varies considerably,

according to the conditions in which they are worn. In particular, water, cosmetics and perspiration accelerate the aging process. A metal or synthetic BREITLING bracelet is thus better suited to activities involving frequent contact with water or humidity.

BREITLING metal cases and bracelets are made from the finest alloys and guarantee sturdiness and wearer comfort. Regular cleaning by rinsing and brushing in clear water will keep your watch shiny. This operation is strongly recommended after each immersion in salty or chlorinated water. For watches fitted with a leather strap, proceed in the same manner, while avoiding getting the strap wet.

WHAT TO AVOID

Like any valuable objects, B REITLING chronometers deserve special care. It is important to protect them from jarring and knocks by hard objects, and not to expose them to chemical products, solvents, dangerous gases, or magnetic fields. Moreover, your B REITLING chronometer is designed to run smoothly at temperatures ranging between 0°C and 50°C.

IHR BREITLING CHRONOMETER

Simple diagram with pink lines and sun icons on black background, no text or symbols present

メンテナンス

Two analog clocks showing suns and directional arrows, likely illustrating solar or wind patterns.

保養

Diagram showing mechanical components with labels like 'O' and 'S', including a warning triangle and gear icons.

特性

第二地时间显示
