TL32MP8752 - TV Tucson - Free user manual and instructions
Find the device manual for free TL32MP8752 Tucson in PDF.
📄
Document temporarily unavailable
The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product type | Color LCD TV |
| Screen size | 32 inches (16:9) |
| Dimensions with stand (WxHxD) | 776 x 566 x 186 mm |
| Dimensions without stand (WxHxD) | 776 x 533 x 96 mm |
| Weight with stand | 13.30 kg |
| Weight without stand | 11.60 kg |
| Power supply | 220-240 V AC, 50 Hz |
| Reception | DVB-T MPEG2/MPEG4 HD, PAL/SECAM B/G D/K K' I/L |
| Number of programs | 1000 (analog + digital) |
| Connectors | 2x HDMI, 1x USB, 2x SCART (Peritel), 1x PC VGA, 1x YPbPr, 1x coaxial digital audio output S/PDIF, 1x headphone jack, 1x RF antenna input, 1x CI (Common Interface) |
| Picture formats | Auto, 16:9, 14:9, 4:3, Zoom, Panoramic, Cinema, Subtitle |
| Audio | Stereo (NICAM), built-in speakers, equalizer, surround mode, AVL |
| Main functions | Electronic Program Guide (EPG), teletext (analog and digital), parental control, child lock, sleep timer, software update via antenna, game mode |
| Care and cleaning | Unplug before cleaning. Use a soft, dry cloth. Do not use abrasive solvents. |
| Safety | Do not expose to moisture, do not obstruct ventilation openings, unplug during thunderstorms, keep batteries out of reach of children |
| Spare parts and repairability | Use only parts recommended by the manufacturer. Refer all repairs to qualified service personnel. |
| Accessories supplied | Remote control (batteries not supplied), user manual |
| Display resolution | 1368 x 768 pixels (max) |
Frequently Asked Questions - TL32MP8752 Tucson
How to turn on the TV for the first time?
Plug the power cord into a 220-240V outlet. Press the Standby/On button on the remote control or the TV. Follow the installation wizard to select language, country and start automatic channel search.
How to connect a USB flash drive to the TV?
Turn off the TV, then plug the USB flash drive into one of the side USB ports. Turn on the TV, the Media Browser menu appears automatically. You can then play videos, music or photos.
How to use parental control?
Go to Menu > Settings > Parental. Enter the default PIN code (0000). You can lock channels, menus or activate child lock. To change the PIN code, use the 'PIN code setting' option.
How to set the time and date?
Go to Menu > Settings > Date/Time. You can choose Auto mode (by broadcast) or Manual. In Manual mode, set the date, time and time zone using the numeric buttons.
What to do if the remote control stops working?
First check the batteries: replace them with two new AAA batteries, respecting polarity. Point the remote control at the TV sensor within 7 meters. If the problem persists, use the buttons on the TV to turn on, change channel or adjust volume.
How to update the TV software?
Go to Menu > Settings > Other settings > Software update. Enable 'Auto search' for overnight update at 3am. You can also launch 'Manual search' via antenna. Do not unplug the TV during update.
How to activate subtitles?
Press the SUBTITLE button on the remote control to activate or deactivate subtitles. You can also choose the subtitle language in the Language menu (Settings > Language > Subtitle).
What file formats are supported via USB?
The TV plays videos: MPEG1, MPEG2, MPEG4 (H.264), AVI (Xvid). Music: MP3, WAV, AAC. Photos: JPEG. Subtitles are supported for videos.
How to connect a computer to the TV?
Use a 15-pin VGA cable to connect the computer's PC output to the TV's PC input. Also connect an audio cable for sound (3.5mm jack to PC audio input). Select the PC source via the SOURCE button.
What to do if the picture is missing or distorted?
Check that the antenna is properly connected and that the input source is selected (TV, HDMI, etc.). If the picture is doubled, reorient the antenna. Try resetting the picture settings (Menu > Picture > Reset).
