Cambria - Car seat Diono - Free user manual and instructions

Product Type	High-back booster seat
Brand	Diono
Model	Cambria
Category	Child car seat
Child height	97 cm to 160 cm (38\" to 63\")
Child weight	18 kg to 54 kg (40 lb to 120 lb)
Recommended age	From about 4 years old (depending on height and weight)
Installation position	Forward-facing only
Vehicle location	Rear seat, away from airbags
Restraint system	Vehicle seatbelt (3-point lap/shoulder)
Universal Anchorage System (UAS)	Yes, with connectors and adjustment straps
Use without backrest	Possible (base only)
Shoulder belt guide	Yes, red guide included
Adjustable headrest	Yes, height adjustable
Safety standards	Complies with Canadian standards (213, 213.1, 213.2) and US standards (FMVSS 213)
Recommended lifespan	Up to 6 years after purchase or 10 years maximum
Airplane certification	Not certified
Cover maintenance	Machine washable, do not use hot water or bleach
Chassis cleaning	Sponge with warm water and mild soap; do not use solvents
Warranty	Limited manufacturer's warranty for original purchaser

Frequently Asked Questions - Cambria Diono

What is the minimum height and weight for using the Diono Cambria seat?

The child must be at least 97 cm (38") tall and weigh at least 18 kg (40 lb).

Can I use this seat without the backrest?

Yes, the base can be used as a backless booster. Simply detach the backrest. Make sure to use the shoulder belt with the provided guide.

How to install the seat with the Universal Anchorage System (UAS)?

1) Disengage the UAS connectors. 2) Attach the connectors to the vehicle's lower anchors. 3) Push the seat against the seatback and tighten the adjustment straps. See the manual for more details.

When is my child too tall for this seat?

The child is too tall if the top of their ears is above the top of the seat headrest or the vehicle headrest at its highest position. The maximum height is 160 cm (63").

Can I use this seat in the front with an airbag?

No, never place the seat on a front seat equipped with an airbag. The rear seat is the safest place for children under 12 years old.

How to maintain the seat cover?

The cover is machine washable. Follow the labels: no hot water, no bleach. For the chassis, clean with a sponge using warm water and mild soap.

What is the lifespan of this booster seat?

The seat must not be used beyond 6 years after purchase or 10 years from manufacture. After a major accident, it must be replaced.

What types of seat belts are compatible?

Only non-motorized, non-door-mounted 3-point lap/shoulder belts. 2-point, automatic retractor, or door-mounted belts are not compatible.

How to adjust the headrest?

Squeeze the red handle at the back of the headrest to raise or lower it. The upper guide should be just above (at least 1 cm) the child's shoulders.

Is the seat certified for use on airplanes?

No, this seat is not certified for airplanes. Lap belts on airplanes cannot be safely used with this booster.

USER MANUAL Cambria Diono

50 Northland Road, Suite 400

Waterloo, Ontario N2V 1N3 Canada

model series: 310000

mfg.by: Diono Canada, ULC

50 Northland Road, Suite 400

Waterloo, Ontario N2V 1N3 Canada

Customer Care

Tel: [phone]

ca.diono.com

© 2016 Dino Canada, ULC. All rights reserved. Cambria CA Eng 06232016
